punching tools used for sale

Serial number: 24550616 Punching force: 200 kN Connection: 11 kVA Table dimensions: 2450 x 1200 mm including accessories such as various punches and punching tools Reference: CES - Lot 107 Auction-ID: A7-46763-333

Machine number: A0045A0007 Operating voltage: 400 V Frequency: 50 Hz Connection: 17 kVA Rated current: 35 A Travel X-axis: 2015 mm Travel Y-axis: 1215 mm Max. material thickness: 6.4 mm Max. workpiece weight: 150 kg Max. punching force: 165 kN max. hold-down force: 10 kN Max. stroke sequences punching Hole spacing 1 mm: 600 rpm Signing: 1300 rpm Max. axis speed X-axis: 80 m/min Y-axis: 55 m/min simultaneous: 97 m/min max. acceleration X-axis: 10 m/qs Y-axis: 5 m/qs C-axis punching/thread forming: 175/min Number of positions in the linear magazine: 17 Number of tools/claws: 15/2 Number of tools when using multi-tool/claws: 15-150/2 Number of claws location/2: max. 2/3 Reject parts: max. part size via disc chute: standard 180 x 150 mm max. part size via disc chute with movable support table: 460 x 500 mm Accuracy position deviation: +- 0.1 mm Average position spreading width: +- 0.03 mm in ...

Manufacturer: FEHRER Model: NL9/S Year of Manufacture: 1991 Specifications: - Stroke: 60mm / max. 1,200 RPM - Needles: 1x 3,000 N/m - Working width: max. 2,600 mm Including: - Control Panel - Control Cabinet Find more here - / Contact us at -

CNC punching machine manufactured in 2019. This Euromac MBX 6 Plus 1250/30-2250 features a total of 24,439,006 hits and a total working time of 11,309 hours. It includes a CNC control system with a dedicated console and a brush table to prevent sheet scratching. If you are looking to get high-quality punching capabilities, consider the Euromac MBX 6 Plus 1250/30-2250 machine we have for sale. Contact us for further details.

Manufacturer: Automatex Model: CBF Year of Manufacture: 2008 Technical Specifications: - Working width: 2.500 mm - RPM: 1200 - Needle Density: 2x 460 N/m - Needles: 5000 N/m - Stroke: 60 mm - Needle boards: 1 set (two boards) Find more here - / Contact us at -

Electric drive Foot switch actuation, Various tools are included in the delivery: 1 x top/bottom knife with radius 4 mm 1 x top/bottom knife with radius 6 mm 1 x top/bottom knife with radius 7 mm 1 x top/bottom knife with radius 8 mm 1 x top/bottom knife with radius 9 mm 1 x top/bottom knife with radius 15 mm (currently in use)

Punching machine with trump tool holder, back gauge via adjustment wheel with display Working area: approx. 1000 × 500 mm Max. sheet thickness circa. 6 mm steel control voltage: 220 V-required fuse for the machine is 16 Weight: approx. 2000 Kg Auction-ID: A1-46862-11

Maximum punching force: 200-250 kN Compressed air termination: 6 bar Control voltage: 24 V Connection cable: 35 kVA Control: Bosch, control cabinet: BochTC Punching diameter maximum .76.2 mm Sheet thickness maximum. 6.4 mm X Working range without resetting: 2500 mm Y Working range maximum. 1300 mm maximum. X-axis speed: approx. 2500 m/min Y speed maximum. 60 m/min Functions: Punching and riveting Working range: approx. 2,500 × 1,1270 mm Operating pressure: 60/170 bar Tool rotation: yes (rotation vercion) Weight: 17500 + control cabinet: 650 kg + cooling unit: 550 kg, - with air cushion 2 pcs. at the front - With various accessories and spare parts - with approx. 20 pcs scassettes - With 2 scrap hand wagons for small parts and scrap without punching tools, these are sold separately as a mixed lot Auction-ID: A1-46862-3

Stored in working condition Auction-ID: A3-43535-17106

cap. Ø27 mm in 7 mm steel or Ø 16 mm in 12 mm steel; Discharge approx. 175 mm Auction-ID: A1-46386-22

stroke adjustable 10 - 32 mm; projection 510 mm; equipped with punching table; Dim. approx. 500x200 mm Auction-ID: A1-46386-6

Inv. Num. : 9160 Type: Trumatic 500R Producer: Trumpf Created: 2003 Parameters: Compressive force: 22 t

CNC punching machine manufactured in 2013. This EHRT Holecut 40-9 features an automatic infeeding system for materials up to 4.2 m long and gripper jaws accommodating material thickness from 3 to 15 mm. It supports up to 9 tools in storage and has a punching rate of 70 SPM. If you are looking to get high-quality punching capabilities, consider the EHRT Holecut 40-9 machine we have for sale. Contact us for further details.

Manufacturer: Geka (Maquinaria Geka S.A., Spain) Model: HYD 110 CNC controller: Inter Imex PT 500 Year of manufacture: 1997 Serial number: 16306 Machine type: Hydraulic punching and shearing machine (steelworker) Max. punching force: 110 t Throat depth: 250 mm Strokes per minute (20 mm stroke): 37 /min Punching capacity (hole Ø x thickness): 40 x 10 mm Notching capacity: 10 mm Flat steel capacity: 300 x 15 mm or 200 x 20 mm Angle steel capacity 90°: 120 x 120 x 10 mm Angle steel capacity 45°: 70 x 70 x 7 mm Round bar capacity: Ø 40 mm Square bar capacity: 40 mm Operation modes: Manual / Automatic Functions: Punching, flat bar shearing, angle shearing, notching, bar cutting Emergency stop: Yes Condition: Used, industrial condition, signs of wear consistent with age Remarks: Hydraulic ironworker with CNC positioning control via Inter Imex PT  ...

Various sizes, Stamps, Strippers and dies Auction-ID: A1-41998-192

max. format 26 x 38 cm Built in 1964 Inking unit not complete 2 locking frames Dry pollinator Delivery date: immediately from stock

Maximum punching force: 200-250 kN Compressed air termination: 6 bar Control voltage: 24 V Connection cable: 35 kVA Control: Bosch, control cabinet: BochTC Punching diameter maximum .76.2 mm Sheet thickness maximum. 6.4 mm X Working range without resetting: 2500 mm Y Working range maximum. 1300 mm maximum. X-axis speed: approx. 2500 m/min Y speed maximum. 60 m/min Functions: Punching and riveting Working range: approx. 2,500 × 1,1270 mm Operating pressure: 60/170 bar Tool rotation: yes (rotation vercion) Weight: 17500 + control cabinet: 650 kg + cooling unit: 550 kg, - with air cushion 2 pcs. at the front - With various accessories and spare parts - with approx. 20 pcs scassettes - With 2 scrap hand wagons for small parts and scrap without punching tools, these are sold separately as a mixed lot

Complete wheel sets for the production and subsequent sharpening of HSS and carbide tools. Single diamond and CBN discs. for the manufacturing and Resharpening. Grinding wheel shots short and long run. Spacer discs for grinding wheel flanges.

Accessories fur WU 3 ms, apparatus of part of, round loop facility, etc. More info on request

Post driven tools from a Traub CNC lathe VDI 40 As well as some measuring geraete for Traub Rest according to photos Special price

6 x 50/105, right, Ø13 mm 6 x 50/105, left, Ø13 mm 8 x 60/115, right, Ø13 mm 10 x 70/125, left, Ø13 mm

Control cabinet for roller conveyor used from stock All prices are from Station World and the dismantling and all follow-up costs are to be made by the buyer. VAT is not included in the prices. The contractual agreements for the individual offers must be agreed separately and only apply after the contract has been legally signed. Mistake reserved. All technical details; Measurements, etc., are approximate information and are non-binding for the provider. The technical data are manufacturer or operator information and therefore non-binding for us. Used material is sold to the exclusion of any warranty. We do not accept any liability for used material. Warranty exchange and return are excluded. Customer protection is agreed between the parties. The entire process of dismantling and loading as well as transport is carried out at the buyer's own expense and at the buyer's own ...

Technical data: -maximum working length 1250 mm -Stand round 1050 mm -Max pressing force 80 t -Stroke 250 mm -Stand RADIUS 300 mm -Max height betw. Table - press bar 560 mm -Lifting speeds -Backward speed idle max 100 mm / sec. -Forward speed 100 mm / sec. -Backward press speed max. 12 mm / sec. -Total power 15 kW -Space requirement approx. B 1750 x H 3400 X 2000 mm -Weight approx. 8500 kg -with: - CNC - control CYBELEC DNC 7400 PSGY -controlled X - axis back gauge 5-1000 mm -Pneum. Z - axis in three stages. height-adjustable -manually movable and foldable stop fingers -controlled pneumatic die shift - hydr. Tool clamping -Manual crowning - 2 piece support arms -Pointed tool shared H 320 x L 1000 mm -Foot tool H 320 mm x L 1000 mm - universal matrix L 1000 mm

Technical data: -Pressure capacity 2000 kN -Max working width 3100 mm -Stand round 3200 mm -Stand RADIUS 300 mm -Max mounted height 965 mm -Hub, or insertion depth Steplessly adjustable 0-400 mm -Plunger speed forward + reverse per 100 mm / sec -Operating speed in 9 steps selectable 1-10 mm / sec -Drive 400 V / 26.5 kW - space requirement approx. B H 4400 x 3500 X 2200 mm -Weight approx. 18500 kg -with: - CNC - control CYBELEC ModEva 15s BJ. 2007 -Back gauge with 4 controlled pneum. on the side and height-adjustable stop fingers -controlled bending AIDS in the velocity range -Hydr. -Pneum.. Clamp of the upper tool + substation witness -mot. Crowning / hydro cushion in the table -laterally movable support arms -E - foot switch -split pointed tool R 1-100 t / m, split die

Technical data: -Get well plate surface -Length approx. 2000 mm -Width approx. 1000 mm -Height approx. 1600 mm -Top plate thickness approx. 95 mm -Top plate with internal ribbing - 4 piece t grooves on the surface of the table length 2000 mm -Centre distance of the T-slot table top 230 mm each -Table side L 2000 mm with 12 holes M27 -T - slot width approx. 40 / 67 mm -T - groove depth approx. 35 / 60 mm -Space requirement L 2200 x T 1200 x H 1600 mm - weight approx. 4980 kg

6 x 50/105, right, Ø13 mm 17.40 eur 6 x 50/105, left, Ø13 mm 17.40 eur 8 x 60/115, right, Ø13 mm 17.40 eur 10 x 70/125, left, Ø13 mm 18.00 eur

Jig Ingersoll IG750 Bj1992; Travel 500 x 700 x 350 with 6-fold electrode changer for Erowa ITS copper + graphite electrodes.

BUTT END REDUCER consist of cone roller (8 m) with log turner, Cross conveyor 4 strings, butt end reducer (motor 50 kW) steper to feed...

HITACHI WIRE EDM MACHINE MODEL MS 250 H-CUT 8Q X-AXIS STROKE: 1030 MM Y-AXIS STROKE: 810 MM Z-AXIS STROKE: 530 MM

2 pcs. molds with 1-1 cavity, automat with hot runnel control, PP material molds sizes both: 300x245x213 mm machine size min. 25 T

1 cavity from PP material mold sizes: 383x450x384 mm machine size min. 100 T

Travel x 350 mm y 250 mm z 220 mm Water bath machine Automatic wire threading Glass scales x / y incl. box for large coils incl. cooler incl. functional guarantee

Used injection molding tools for the manufacture of plastic slippers. Offer total 43 pcs. refers to two cavities tooling and accessories. From small children (23) to men (45) in size, it is suitable for the manufacture of slippers of various types and colors. For sale total 12,900 Euro

Key data: 500 , 350 , 300

Travel X 500 / Y 350 / Z 300, Water bath machine, automatic wire threading, incl. 20 KG option incl. cooler

Wire EDM machine SODICK A 600 manufactured in 1997. Technical parameters of the SODICK A 600 EDM machine: - table travel (X axis): 600 mm - table travel (Y axis): 400 mm - Z axis travel: 270 mm - maximum dimensions of the processed part (width x depth x height): 800 x 550 x 260 mm - maximum weight of the workpiece: 900 - auxiliary table travel (U axis x V axis): 70 x 70 mm - wire diameter: 0.1 ~ 0.3 mm - maximum wire speed: 250 mm / sec. - wire tension: 0.2 ~ 2.8 kgf - cutting inclination at an angle: + -15 degrees per 100 mm of thickness - height from the floor to the surface of the working table: 1000 mm - machine tool dimensions (width x depth x height): 2188 x 2645 x 2100 mm - machine tool weight: 3700 kg

Fabr. Walter Tip height: 105 mm

X – Axis Travel (600 mm) Y – Axis Travel (400 mm) Z – Axis Travel (270 mm) U, V Axis Travel (80 x 80 mm) Wire Diameter Range (min ~ max) (0.10 ~ 0.30 mm) Work Tank Dimensions (W x D) (1040 x 780 mm) Maximum Workpiece Weight (850 kg)

SPECIFICATIONS: Machining max mm: 330 Ø mm: 40 Computer-aided measuring and displaying system for Measurement of tools, digital display of tool data Input of profile dimensions, calculation of spindle setting data Transfer to the machine by means of a label

Travel distances: 350 x 250 x 315 mm [ X x Y x Z ] Table size X: 576 mm Table size Y: 400 mm workpiece weight: 500 kg C-axis Pinole recording: EROWA

Travel: 825 x 680 x 405 mm [ X x Y x Z ] Table size X: 1200 mm Table size Y: 850 mm workpiece weight: 3000 kg Electrode changer: 50 - fold Generator POCON 60 Pinole recording: EROWA Heavy Duty Adapter O-Module Halogen lamp

according to pdf attached

Capacity: 120 Amp. – 19 kVA X-axis: 800 mm Y-axis: 600 mm Z-axis: 400 mm Table dimensions: 1,100 x 700 mm Distance head - table: 950 mm (max) Oil retainer: 1,700 x 1,000 x 650 mm Workpiece weight: 4,000 kg (Max) Control: CNC Datic S120

Omschrijving Lengte mm Aantal Bovenmes H=66,5mm, R=0,8 85gr 835 2 Bovenmes H=66,5mm, R=0,8 85gr 415 2 Bovenmes H=66,5mm, R=0,8 85gr 300 1 Bovenmes H=66,5mm, R=0,8 85gr 150 1 Bovenmes H=66,5mm, R=0,8 85gr 50 1 Bovenmes H=66,5mm, R=0,8 85gr 40 1 Bovenmes H=66,5mm, R=0,8 85gr 20 1 Bovenmes H=66,5mm, R=0,8 85gr 15 2 Bovenmes H=66,5mm, R=0,8 85gr 10 1 Bovenmes H=66,5mm, R=0,8 85gr LEFT 100 1 Bovenmes H=66,5mm, R=0,8 85gr RIGHT 100 1 Ondermatrijs V10, R=0,8, 85gr 835 2 Ondermatrijs V10, R=0,8, 85gr 415 2 Ondermatrijs V10, R=0,8, 85gr 300 1 Ondermatrijs V10, R=0,8, 85gr 150 1 Ondermatrijs V10, R=0,8, 85gr 50 1 Ondermatrijs V10, R=0,8, 85gr 40 1 Ondermatrijs V10, R=0,8, 85gr 20 1 Ondermatrijs V10, R=0,8, 85gr 15 2 Ondermatrijs V10, R=0,8, 85gr 10 1 Totaal 26 Price € 2250,-- New prijs € 3250,--

Hand - Bending bench Manufacturer: GEKA

Travel distances: 320 x 250 x 220 mm [ X x Y x Z ] workpiece size X: 780 mm workpiece size Y: 570 mm workpiece size Z: 200 mm workpiece weight: 350 kg with automatic wire threading U/V axis: 80 mm x 80 mm  Cutting in a water bath Conicity: +/- 15° at 120mm

Inv. Num. : 6445 Type: BF 74 Producer: CDM ROVELLA Generated: 2008 Parameters: Workpiece length: 800 mm Workpiece width: 550 mm travel length of the X-axis: 700 mm Travel length of the Y-axis: 400 mm Travel length of the Z-axis: 350 mm Maximum table load: 2000 kg Maximum electrode weight: 90 kg Tank dimensions: 1200 x 750 x 505 mm Weight: 4400 kg

Folding bench TEKO Sheet thickness 1.9 mm Usable length 2025 mm Length 2500 mm Width 650 mm Height 1080 mm Weight 500 kg

Travel: 350 x 250 x 220 mm [ X x Y x Z ] max. workpiece size Z: 220 mm max. workpiece weight: 450 kg Table size X: 600 mm Table size Y: 400 mm with automatic wire threading U- / V-axis: 80 x 80 mm Cutting in a water bath Conicity angle 20° at height 80mm

Bending bench Geka Max width 2.03 m Thickness 1 mm Scale 180° Bending beam spring-assisted Length 2.40 m Width 0.80 m Height 1.10 m Weight 500 kg

Type: Die-sinking EDM machine Number: 21958 Category: Die-sinking EDM machines / EDM Manafacture: Makino Model: EDAF 3 Year of construction: 2016 Travel: 450 x 350 x 350 mm [ X x Y x Z ] Table size X: 700 mm Table size Y: 500 mm max. workpiece size X: 850 mm max. workpiece size Y: 650 mm max. workpiece size Z: 400 mm max. workpiece weight: 800 kg C-axis Linear scales (X,Y,Z) Control Hyper i Super Spark iV Super Surface Super Edge (incl. MF 4) Super Surface Graphite EROWA Robot Interface (A-Type)
