Stop for press brake, bending machine, guillotine shear, drive shaft -Drive shafts: for stop, from press brake EHT type EHP 11-40, 2 pieces -Length: 515 mm -Hole: Ø 25 mm -Price: complete -Dimensions: Ø 50 x 515 mm -Weight 5.1 kg/pc.

Bending tool, die, upper knife, upper tool, straight tool, die tool, seam closing tool -Tool: for press brake, die tool -Measures: see drawing in the photos -Dimension: 3060/20 / H79 mm -Weight.: 30.3 kg

Bending tool, die, upper knife, upper tool, straight tool -Tool: split, for press brake -Tool angle: 90° -Drawing: in the photos -Dimension: 33 x 170 mm -Length: 1485 mm (1 x 855/630 mm each) -Weight: 44.6 kg

Bending tool, die, upper knife, upper tool, straight tool -Tool: split, for press brake -Tool angle: 90° -Drawing: in the photos -Dimension: 29 x 171 mm -Length: 1570 mm (1x 650/500/420 mm each) -Weight: 41.2 kg

Bending tool, die, upper knife, upper tool, deer foot tool, deer foot tool for press brake -Tool: for press brake -Angle: 90° -Dimensions: 55 x 133 mm, see drawing in the photos -Length: 365 mm -Weight: 9.8 kg

Bending tool, die, upper knife, upper tool, straight tool -Tool for: press brake -Dimensions: 10 x 88 mm -Length: 2000 mm -with: storage box -Weight: 13.2 kg

Bending tool, die, upper knife, upper tool, straight tool -Tool for: press brake -Tool as: die -Thickness: 25/13 mm -Drawing: with the pictures -Total length: 400 mm -Total height: 108 mm -Weight: 6.5 kg

Bending tool, die, upper knife, upper tool, straight tool -Tool: split, for press brake -Tool angle: 60° -Drawing: in the photos -Dimension: 25 x 165 mm -Length: 3562 mm (each 1 x 1818/800/387/190/122/85/60/55/45 mm) -Weight: 124 kg

Standard configuration ? Stable machine frame as a welded, all-steel construction ? Ram (press beam), highly resistant to torsional forces ? Electrohydraulic downstroke drive via proportional valves ? Modern block hydraulics ? CNC backgauge with rack-and-pinion drive, for X and R axis, safe adjustment of stop fingers from the front ? Modufix upper tool clamping system, manual ? Lower tool holder for single-V dies, manual clamping, programmable shifting ? Control system: 2D/3D graphic control, Delem DA 69 with 12 color screen (LCD) ? Safety equipment Additional equipment Crowning options ? CNC crowning Backgauge system options ? 4-axis backgauge system ? 2 additional clip-on stop fingers Tool clamping and angle messuring system ? Upper tool claming, hydraulic ? Lower tool clamping, hydraulic ? ACB Preparation Material handling options ? 2 front support brackets

Bending tool, die, lower knife, lower tool, prism tool -Tool for: press brake -Groove: W/D 9 x 12, 5 x 8, 17 x 20 mm -Length: 3 x 835 mm, 1 x 272 mm -Width/height: 60 mm -Drawing: with the pictures -Weight: 67.5 kg

Bending tool, die, upper knife, upper tool, straight tool -Tool for: press brake -Tool for: closing folds -Recording: 25 mm -Drawing: in the photos -Dimension: 40 x 130 mm -Length: 495 mm -Weight: 12.5 kg

Bending tool, die, upper knife, upper tool, straight tool -Tool for: press brake -Tool: 26° -Drawing: in the photos -Dimension: 13 x 180 mm -Length: 45 mm -Weight: 0.7 kg

Bending tool, die, lower knife, lower tool, prism tool -Tool for: press brake -Prisms: 90° 12 mm -Drawing: in the photos -Length: 4200 mm (2 x 2100 mm) -Dimension: 20 x 75 mm -Weight: 44 kg

Bending tool, die, upper knife, upper tool, straight tool -Tool for: press brake -Tool as: die -Thickness: 25/13 mm -Drawing: with the pictures -Total length: 400 mm -Total height: 120 mm -Price: per piece -Number: 2 pieces -Weight: 13 kg

Bending tool, die, lower knife, lower tool, prism tool, reversible prism, 1-part die block for die bending machine, die tool, hemming tool -Tool: for press brake, die / hemming tool -Measures: see drawing in the photos -Dimensions: 150/101 / H75 mm / 150/77 / H159 mm -Weight: 7.2 kg / 11.4 kg

Bending tool, die, lower knife, lower tool, prism tool, reversible prism, 1-part die block for die bending machine, die tool, hemming tool -Tool: for press brake, die / hemming tool -Measures: see drawing in the photos -Dimensions: 150/101 / H77 mm / 150/77 / H160 mm -Weight: 6.9 kg / 11.2 kg

Bending tool, die, lower knife, lower tool, prism tool, reversible prism, 1-part die block for die bending machine -Tool: for press brake, 12 pieces -Prisms: 25 ° x 10 mm -Drawing: in the photos -Lengths: see parts list in the photos -Dimensions total: 30/79/2917 mm -Weight: 47 kg

Bending tool, die, upper knife, upper tool, straight tool, die tool, seam closing tool -Tool: for press brake, 6 pieces -Tool: for closing folds -Drawing: in the photos -Dimension: 20 x 70 x 495 mm -Price / fee: complete -Length total: 2970 mm -Total weight: 31.3 kg

Bending tool, die, upper knife, upper tool, straight tool -Tool: for press brake, 14 pieces -Tool angle: 25° -Drawing: in the photos -Dimension: 25 x 158 mm -Length total: 2615 mm (lengths see parts list photo) -Weight: 47.3 kg

Bending tool, die, upper knife, upper tool, straight tool -Tool for: press brake -Tool as: die -Thickness: 25/13 mm -Drawing: with the pictures -Total length: 400 mm -Total height: 99 mm -Price: per piece -Number: 2 pieces -Weight: 9.7 kg

Bending tool, die, upper knife, upper tool, straight tool -Tool for: press brake -Dimensions: 20 x 70 mm -Length: 3020 mm -Weight: 22 kg

Bending tool, die, upper knife, upper tool, tool for press brake -divided -Dimensions: 31.007.2101 -Height: 86 mm -Length: 2x100 mm -Dimensions: 21.002.01.01 -Height: 155 mm -Length: 2x100 mm -Packed: in wooden box -Weight: 11.9 kg

Tool trolley for bending tool, die, upper knife, upper tool, straight tool -Tool trolley for the: Tool for a press brake -with several compartments -Dimensions: 1165/720/H1000 mm -Weight: 208 kg

Stop, depth stop, length stop for press brake, bending machine, guillotine shear... -Recording with: Slotted hole -Length (unit of measurement): approx. 300 mm - Fine-tuning -Quantity: 2 available Price: complete -Dimensions: 2x 410/320/H120 mm -Weight: 28 kg

Bending tool, die, upper knife, upper tool, straight tool -Transfer in current condition as seen -Tool for: press brake -Tool: 45° -Thickness: 25 mm -Total length: 600 mm -Total height: 195 mm -Weight: 20 kg

Bending tool, die, lower knife, lower tool, prism tool -Tool for: press brake -Prisms: R14.5 mm -Square: 101 x 71 mm -Total length: 552 mm -Weight: 26 kg

Bending tool, die, upper knife, upper tool, straight tool -Tool for: press brake -Tool as: die -Thickness: 25/13 mm -Drawing with the pictures -Total length: 200 mm -Total height: 188 mm -Weight: 6 kg

Bending tool, die, upper knife, upper tool, straight tool -Tool for: press brake -Tool as: die -Thickness: 25 mm -Drawing with the pictures -Total length: 303 mm -Total height: 171 mm -Weight: 10 kg

Bending tool, die, upper knife, upper tool, straight tool -Tool for: press brake -Tool as: die -Radius: R8 -Thickness: 60/25 mm -Drawing with the pictures -Total length: 569 mm -Total height: 176 mm -Weight: 30 kg

Bending tool, die, upper knife, upper tool, straight tool -Tool for: press brake -Tool as: die -Thickness: 25/40 mm -Drawing with the pictures -Total length: 599 mm -Total height: 68 mm -Weight: 28 kg

Bending tool, die, upper knife, upper tool, straight tool -Tool for: press brake -Tool: 60° -Thickness: 25 mm -Total length: 1570 mm -Lengths: 75/75/120/120/590 mm -Total height: 246 mm -Weight: 44 kg

Bending tool, die, upper knife, upper tool, deer foot tool, deer foot tool for press brake -Tool for: press brake -Dimensions: 175 x 26 mm -Total length: 315 mm -Weight: 8 kg

Bending tool, die, upper knife, upper tool, straight tool -Tool for: press brake -Tool radius: 10 mm -Thickness: 20mm -Total length: 471 mm -Total height: 188 mm -Recording width: 80 mm -Weight: 19.8 kg

Bending tool, die, upper knife, upper tool, deer foot tool, deer foot tool for press brake -Tool for: press brake -divided -Tool: 88° -Dimensions: 188 x 55 mm -Total length: 351 mm -Lengths: 341/10 mm -Weight: 18.6 kg

Bending tool, die, upper knife, upper tool, deer foot tool, deer foot tool for press brake -Tool for: press brake -divided -Tool: 82° -Dimensions: 190 x 45 mm -Total length: 800 mm -Lengths: 45/50/55/60/90/500 mm -Weight: 28 kg

Bending tool, die, upper knife, upper tool, deer foot tool, deer foot tool for press brake -Tool for: press brake -divided -Tool: 88° -Dimensions: 190 x 55 mm -Total length: 1126 mm -Lengths: 338/338/450 mm -Weight: 54 kg

Bending tool, die, upper knife, upper tool, deer foot tool, deer foot tool for press brake -Tool for: press brake -divided -Tool: 82° -Dimensions: 190 x 45 mm -Total length: 2125 mm -Lengths: 20/25/30/35/40/45/50/55/60/65/70/75/80/85/90/100/200/500/500 mm -Weight: 84 kg

Bending tool, die, upper knife, upper tool, straight tool -Tool for: press brake -Tool: 82° -Thickness: 25 mm -Edge length: 1039 mm -Total height: 162 mm -Weight: 26 kg

Bending tool, die, upper knife, upper tool, deer foot tool, deer foot tool for press brake -Tool for: press brake -divided -Tool: 82° -Dimensions: 145 x 43 mm -Total length: 2946 mm -Lengths: 25/30/35/40/50/70/100/200/200/300/400/500/996 mm -Weight: 92 kg

Bending tool, die, lower knife, lower tool, prism tool -Tool: for press brake -Prism groove: 7/10 mm -Square: 66 x 26 mm -Length: 2505 mm -Weight: 24 kg

Bending tool, die, upper knife, upper tool, deer foot tool, deer foot tool for press brake -Tool: for press brake -Tool radius: mm -Dimensions: 60 x 120 mm -Length: 415 mm -Weight: 10 kg

Bending tool, die, upper knife, upper tool, upper beam -Tool: for folding machine -Dimensions: 60 x 15 mm -Length: 1020 mm -Weight: 6 kg

Bending tool, die, upper knife, upper tool, deer foot tool -Tool: for press brake -Tool radius: mm -Dimensions: 30 x 169 mm -Length: 2500 mm -Weight: 89 kg

Bending tool, die, lower knife, lower tool, lower beam, -Tool: for folding machine -Widening: for lower cheek -Dimensions: 33/76/3040 mm -Bore distance: 280 mm -Hole diameter: 18 mm -Length: 3040 mm -Weight: 33 kg

Bending tool, die, upper knife, upper tool, straight tool -Tool: for press brake -Tool radius: mm -Dimensions: 14 x 94 mm -Length: 2500 mm -Weight: 20 kg

Console, device, clamping angle, clamping table, clamping plate, support console -Support consoles: 2 pieces, from press brake Promecam STPC 250 40 121 -Support table extension: adjustable in height -Dimensions: 515/300/H785 mm -Transport dimension: 840/540/H310 mm -Total weight: 56 kg

Crowning for press brake, bending bench, die holder with displacement device -Manufacturer: HACO, die holder with crowning for press brake type PPES 30135 -Matrix length total: 3050 mm -Individual components: see photos -Transport dimensions: 3570/260/H405 mm -Weight 374 kg

Stop, depth stop, length stop for press brake, bending machine, guillotine shear... -Stop: for press brake, bending machine, guillotine shear ... -Reference: M16 x 2 -Dimensions: see photos -Quantity: 2 available -Price: complete -Dimensions: 345/175/H115 mm -Weight: 4.2 kg/pc.

Auction-ID: A1-45188-115

machine ready for transport and to be assessed on viewing day.
