pos used for sale

x-travel: 800 mm y-travel: 700 mm z-travel: 600 mm control: iTNC 530 Heidenhain Main spindle:: turning speed range - main spindle: max. 18.000 min/-1 power capacity - main spindel: 19 / 28 kW max. Torque: 121 Nm tool taper: SK 40 DIN 69871 b - axis: 0,001 ° pallet changer:: numbers of pallets: 2 size of pallet: 800 x 630 mm pallet diameter: Ø 800 mm max. table load: 800 / (1.600) kg rotatable: C: 360 ° resolution: 0,001 ° max. table speed: 13,6 U/min T-slots: 50 H6 tool magazin:: number of toolpositions: 60 pos. tool taper: SK 40 DIN 69871 max. tool diameter: 100 mm max. tool-dia with free toolbox: 160 mm max. tool length: 350 / 315 mm max. tool weight: 10 kg feeds:: feed speeds: 20 - 15.000 mm/min rapid traverse: 50 m/min total power requirement: 59 kVA weight of the machine ca.: 10 t dimensions of the machine ca.: 4,0 x 7,0 x 2,7 m Documents: Coolantsystem: high pressure cool ...

WEINIG / GreCon Short Wood Finger-jointing Line Ultra TT Data of the system: • Wood inlet length (min. - max.) 150 - 1000 mm (1300 mm) • Reference timber inlet length at the finger-jointing line 400 mm • The length of the wood to be processed must be at least 25 percent longer than the width of the wood to be processed • Wood thickness (min. - max.) 20 - 80 mm • Reference wood thickness 28 mm • Wood width (min. - max.) 40 - 205 mm • Reference wood width 90 mm • Reference wood cross-section 28 mm x 90 mm • Wood outlet length (min. - max.) 3000 - 6100 mm • Reference wood outlet length 6100 mm • Tine profile (length) 10 – 11 mm • Max. wood cross-section for processing softwoods (with specified tine length) 100 cm² • Max. wood cross-section for processing hardwoods (with specified tine length) 80 cm² • Glue type PVAC • Species: Softwood / ...

spindle passage: 36 (42) mm turning length: max. 280 mm control: C200-4 / 840C Siemens Main spindle:: turning speed range - main spindle: max. 6.300 min/-1 power capacity - main spindel: 13 / 21 kW max. Torque: 62 / 102 Nm spindle diameter in front bearing: 85 mm spindle hollow: 36 mm C-Axis: 0,001 ° Subspindel:: Spindle speed range subspindle: max. 4.500 min/-1 max. Torque: 10 Nm clamping diameter: max. 42 mm clamping length max.: 38 mm spindle bore: 15,5 mm Turret 1:: number of toolpositions: 8 pos. shaft cross cut: 25 x 48 DIN 69880 change-time tool to tool: 0,2 sec travel -x axis: 90 mm travel -z axis: 280 mm Feed force: 5,5 kN rapid traverse: 24 m/min Driven Tool Positions:: 8 Spindle speed - driven tools: 6.000 min -1 power capacity - driven tools: 3,3 kW max. Torque: 7,5 Nm Backside processing:: Fixed tools max.: 5 pos Turret 2:: number of toolpositions: 6 pos. travel -x axi ...

x-travel: 1.200 mm y-travel: 500 mm z-travel: 600 mm control: iTNC 530 HSCI Heidenhain Main spindle:: turning speed range - main spindle: 30 - 6.000 min/-1 power capacity - main spindel: 30 kW max. Torque: 143,2 Nm tool taper: SK 40 DIN 69871 / A internal coolant system feed: work table:: table surface area: 1.270 x 500 mm max. table load: - kg number of T-slots: 4 T-slot - width: 14H9 mm T-slot - distance: 125 mm 4th Axis: RTA 2-300 Tool-Presetter:: number of toolpositions: 22 pos. max. tool diameter: 85 mm max. tool-dia with free toolbox: 135 mm max. tool length: 400 mm max. workpiece weight: (L=400mm) 5,5 kg max. workpiece weight: (L=200mm) 8,0 kg total power requirement: 55 kVA weight of the machine ca.: 8 t dimensions of the machine ca.: 4,9 x 2,3 x 2,7 m Documents: Coolantsystem: high pressure coolant: 30 bar through spindle coolant: paper band filter: interface 4. axis: 4 ...

max. turning diameter: 580 mm turning length: 1500 mm control: OSP 7000 L greates pass round over bed: 610 mm swing diameter over slide rest: 580 mm Main spindle:: turning speed range - main spindle: 12 - 2.800 min/-1 spindle bearing diameter: 150 mm spindle bore: 110 mm spindle nose: JIS A2-11 power capacity - main spindel: 37 (30) kW C-Axis: 0,001 ° axis stroke:: x-axis: 598 mm y-axis: 230 (+110 / -120) mm z-axis: 1.660 mm feeds:: rapid traverse: X / Y: 12.000 mm/min rapid traverse: Z: 20.000 mm/min rapid traverse: C: 100 min/-1 cutting feed speed: X / Z / Y: 0,001 - 1.000 mm/U turret:: type: H2 ATC number of toolpositions: 2 (1x L-Tool / 1x M-Tool) pos. driven statition: stufenlos / stepless Spindle speed - driven tool stations: 40 - 3.000 min -1 tool shank height: 25 mm Boring bar shank diameter: 50 mm Tailstock:: diameter of quill: 120 mm quill stroke: 170 mm taper of center:  ...

CNC multi spindle bar automatic, Gildemeister GMC 35 ISM, - 6 integretat spidles with C-axis, - 5 compound slides pos. 1; 2; 3, 4; 5;, - intipendend feed for central block, - douple slide in pos. 6, - pick-up spindle in pos. 6, - 5 frontal spindles, rotating, with internal coolant supply, ISO 40, - swarf conveyor, - Fire fihthing system CO2, - ARTIS tool breakage control system, Stangenlademagazin :, Cucchi Pietro PB 41 Compact, Country of origin: Italy, Control: Siemens 840D, Operating hours: 56.000, Number of spindles: 6, Max bar diameter [mm]: 35, Spindle speed [rpm]: 6.000, Spindle motor [kW]: 21, Total power requirement [kVA]: 107, Auto bar loader: Cucchi Pietro PB 41 Compact

bore capacity in steel (diameter): 55,0 mm throat: 300 mm bore stroke: 120 mm threading: M 36 in St 60 turning speeds: 70 - 1.200 U/min table:: 615 x 430 mm bore spindles - Morse Taper: 4 Kurzspindel MK column diameter: 145 mm feed: 0,10 + 0,30 mm/U weight: 380 kg Machine height: 1850 mm Furnishing : - automatic feed - Feed device 0.1 + 0.3 mm / rev - stepless speed adjustment - digital speed display - Feed overload protection - Spindle protection with electr. validation including special equipment: - Coolant device mounted in the foot pos. 24. - Thread cutting device pos. 20.0 (Thread cutting with stop) - LED machine light pos. 12. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

bore capacity in steel (diameter): 50,0 mm throat: 350 mm bore stroke: 200 mm threading: M 42 in St 60 turning speeds: 60 - 1.530 U/min table:: 720 x 510 mm bore spindles - Morse Taper: 4 Kurzspindel MK column diameter: 200 mm feed: 0,15-0,2-0,3-0,36 mm/U engine output: 3,6 / 4,3 kW weight: 605 kg Machine height: 1950 mm Furnishing : - automatic feed with electromagn. Feed clutch - 4 feed levels 0.15 / 02, - 0.3 - 0.36 mm / rev - stepless speed adjustment - digital speed display - Feed overload protection - Spindle protection with electr. validation - digital speed display - machined base plate including special equipment: - Coolant device mounted in the foot pos. 24. - Thread cutting device pos. 20.0 - LED machine light pos. 12. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

grinding diameter: 350 mm grinding length: 650 mm centre height: 175 mm Control: total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m Machine in very good condition run in one shift (20,000 switch-on hours). Available from January 2024 Fanuc 0i-TD control system Centre distance 650mm Centre height 175mm Workpiece table swivelling +8.5° with fine adjustment and pneumatic lift-off Cross axis X travel 285mm Feed rate 0.001-10,000mm/min Direct, linear absolute measuring system, resolution 0.0001mm Longitudinal axis Z Travel 800mm Feed rate 0.001-20,000mm/min Direct, linear absolute measuring system, resolution 0.0001mm H1 wheelhead with B-axis and 1° Hirth serration Three tool positions Swivelling range -15 to +225° Pos T2 - External grinding with grinding discs Ø500x80x203mm Motor spindle with internal cooling 7.5-11kW, 3,200rpm_max, v_max = 50m/s  ...

1 x centrifugal pump ABB motors, used, type: M2AA180 M4 / IEC 180 M / L, 18 KW, flange connections, power approximately 100,000 ltr. / h, picture on the right, POS. 9, price: 1,200 1 x used centrifugal pump Hilge, type: HYGIA S-II / 20 d, 15 KW, connections DN 80/65, capacity approx. 80,000 ltr. / h, pictured left, POS. 10, price: 2.250,- Prices plus 19% VAT from stock Dolgesheim

8 main spindles, Chucker AFH130 for complete machining means front- and back side, Control Siemens Sinumerik 840DI, complete revising and new configuration of this machine in year 2010, loading arm, for loading and disloading, Workpiece turn around station in pos. 4 , position 4 with workpiece length control, CNC compound slide in pos. 5, coolant pump with magnet candle filter, tooling: could be different like pictures option: Ergomat TB42 fot cutting off for half finnishing with FMB-Turbo

working length: 2451 mm Working width: 1670 mm Working height: 800-1000 mm Neue Haberkorn Rückfördereinrichtung nach Vierseitenhobelmaschine ------------------------------------------------------- Förderanlage für Holzlängen von 300 mm-4200 mm Pos.1 Längs-Quer-Länsförderer ca.2451 x 1670 mm - höheneinstellbare Stützböcke (ca.800 mm - 1000 mm) - stufenlos angetriebene Rollenbahn ca.5-25m/min, - Rollendurchm.50mm, 140mm Rollenmantellänge - Übergabe auf Querförderer durch Heben-Senken der Rollenbahn - Querförderer mit 6 Stck. Traversen - Förderbänder 50mm breit, in Kunststoffbahnen geführt - Antrieb ca.5-25m/min, 0,37 KW - ca.1250mm von Anschlag zu Anschlag - Übergabe als Hebesenkeinrichtung - angetriebene PVC beschichtete Stahlrollen, Durchm.50mm, 140mm Mantellänge - Antrieb ca.5-25m/min, 0,37 KW - Rollenabdeckung nach HBG Pos.2 Förderband ca.3000 x 260mm - höheneinst ...

: 34 mm : 40 mm : 40 mm : MK 4 : 100-1.800 U/min. throat: 300 mm : 615x430 mm : 2 x 14 x 224 mm : 138/688 mm column diameter: 145 mm spindle stroke: 160 mm feeds: 0,1-0,2-0,3-0,4 mm/U Machine height: 1865 mm total power requirement: 1,4/2,2 kW Standard equipment: - Electromagnetic feed clutch with overload protection and electrical Cross Handle Switches - Main switch lockable - Motor protection switch - Mushroom pushbutton (latching) for EMERGENCY STOP in the front panel - Speed adjustment stepless - Speed display digital - Protection class IP 54 - Motor insulation class F - Spindle protection with electrical protection Pos. 20.1 Tapping device with foot switch, for thread cutting with Stop, max. 6 threads/min., (Tapping power dependent on spindle speed) Pos. 25. Coolant device B, consisting of: separate container (33 l), pump with Motor protection switch, complete fitting The data for ...

: 26 mm : 30 mm : 30 mm threading in St 60: M 20 threading in GG 20: M 24 : MK 3 : 120-2.200 U/min. throat: 293 mm : 514x360 mm : 2 x 14 x 224 mm : 90/675 mm column diameter: 115 mm spindle stroke: 160 mm feeds: 0,1-0,2-0,3-0,4 mm/U total power requirement: 1,0/1,6 kW Machine height: 1865 mm weight: 380 kg Standard equipment: 7 TFT LCD display with touch function: manual input of spindle speed Setpoint, actual speed display, integrated drilling depth display with touch Zero point transfer, virtual drilling depth scale in the display, machine Status displays and warnings in the display, service information, selectable User language: DE / EN / FR / ES / IT / NL / RU - Thread cutting device, for thread cutting with stop, max. 6th Thread / min (thread cutting performance dependent on spindle speed), thread depth adjustable via depth stop and in the TFT - LCD display (4 tools) - Infinitely va ...

: 34 mm : 40 mm : 40 mm threading in St 60: M 24 threading in GG 20: M 30 : MK 4 : 100-1.800 U/min. throat: 300 mm : 615x430 mm : 2 x 14 x 224 mm : 138/688 mm column diameter: 145 mm spindle stroke: 160 mm feeds: 0,1-0,2-0,3-0,4 mm/U total power requirement: 1,4/2,2 kW Machine height: 1865 mm weight: 470 kg Standard equipment: 7 TFT LCD display with touch function: manual input of spindle speed Setpoint, actual speed display, integrated drilling depth display with touch Zero point transfer, virtual drilling depth scale in the display, machine Status displays and warnings in the display, service information, selectable User language: DE / EN / FR / ES / IT / NL / RU - Thread cutting device, for thread cutting with stop, max. 6th Thread / min (thread cutting performance dependent on spindle speed), thread depth adjustable via depth stop and in the TFT - LCD display (4 tools) - Infinitely v ...

x-travel: 450 mm y-travel: 400 mm z-travel: 320 mm tool taper: HSK 63 spindle turning speed range: 0 - 10000 U/min rapid traverse: 30 m/min System for processing fittings, valve housings, etc. consisting of 1 used flexible manufacturing cell (transfer machine) make RIELLO, model VERTIFLEX VFX 450-2 / 1-0 / 1-V, YOM 2010, with 2 pcs. 3-axis machining modules, each with 8-pos. tool turret, travel paths module 1: X1 / Y1 / Z1 = 450/400/320 mm, travel paths module 2: X2 / Y2 / Z2 = 450/400/320 mm, tool fixture HSK 63, rotary table with 2 integrated workpiece carriers á 400 mmø (B axis per workpiece carrier 360 x 1 °), coolant through spindle Acc.: chip conveyor, coolant device connected by ABB handling robot with 1 used flexible manufacturing cell (transfer machine) make RIELLO, model VERTIFLEX VFX 450-2 / 2-0 / 1-V, YOM 2003, with 3 pcs. 3-axis machining modules, each with 8-po ...

machine: 15 Pos. accessories:: Pos. electric measuring devices: 1 The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

: 34 mm : 40 mm : 40 mm threading in St 60: M 24 threading in GG 20: M 30 : MK 4 : 100-1.800 U/min. throat: 300 mm : 615x430 mm : 2 x 14 x 224 mm : 138/688 mm column diameter: 145 mm spindle stroke: 160 mm feeds: 0,1-0,2-0,3-0,4 mm/U total power requirement: 1,4/2,2 kW Machine height: 1865 mm weight: 470 kg Standard equipment: 7 TFT LCD display with touch function: manual input of spindle speed Setpoint, actual speed display, integrated drilling depth display with touch Zero point transfer, virtual drilling depth scale in the display, machine Status displays and warnings in the display, service information, selectable User language: DE / EN / FR / ES / IT / NL / RU - Thread cutting device, for thread cutting with stop, max. 6th Thread / min (thread cutting performance dependent on spindle speed), thread depth adjustable via depth stop and in the TFT - LCD display (4 tools) - Infinitely v ...

CHIRON MODEL FZ18W MAGNUM 4 axis Vertical machining center with rotopallet and double 4th axis 20 TOOLS ISO 40 Toolchange: 2.1 sec Spindle: 20 - 8000 RPM, 18,5k kW X = 625 Y = 400 Z = 400 Rapids 40m/min Table area: 2 x 900 x 470 - TSUDAKOMA heavy duty double 4th axis (Japan) 360.000 pos. - original HAWE hydraulic unit - FANUC 0M 1995 Can be inspected under power in our warehouse Mimu machine tools (Italy), X: 625, Y: 400, Z: 600, 4th axis: Yes, (2x) Tsudakoma 360 000 pos.

: 40 mm : M 24 : M 30 spindle turning speed - stepless: 160-2250 U/min : MK 3 spindle stroke: 120 mm throat: 293 mm column diameter: 115 mm : 515x360 mm distance spindle /table: min./max. 117/701 mm : 2 x 14 x 224 mm feed: 0,1 + 0,2 mm/U Machine height: 1840 mm Standard equipment: - Main switch with motor protection switch lockable - Mushroom pushbutton (latching) for EMERGENCY STOP - Speed adjustment stepless - Speed display digital - Feed overload protection - Protection IP 54 - Spindle protection with electrical protection Pos. 20.1 Tapping device with foot switch, for thread cutting with Stop, max. 6 threads / min., (Tapping power dependent on spindle speed) Pos. 24 Coolant device A, consisting of: Coolant base plate with machined Workpiece support surface 320x320 mm and 2 T-slots, pump with Motor protection switch, complete fitting The data for this ad was created with ModulMWS -  ...

Pressure: 30 t Sheet length: 2500 mm Sheet width: 1250 mm Positions ATC: 0   CNC Brand: Siemens CNC Model: 840 D Make Rainer OC 3 Type OC 3000 Year 2001 Siemens 840 D !Pressure (metric ton) 30 ton = 6 mm Sheet length (mm) X = 2.500 Sheet width (mm)Y = 1.250 Pos ATC Revolver = 20 Pos Brush table Over taking Under power !- 7 x A Station - 5 x B Station - 2 x C Station - 6 x D Station ( 1 x Multi tool 6 x A)

Table length: 7000 mm Table width: 1200 mm Longitudinal X: 7000 mm Cross Y: 2000 mm Vertical Z: 600 mm CNC Brand: Fanuc CNC Model: 16 iMB Make HNK Daewoo Type HKDB 130 P Year 2000 Fanuc 16 iMB Spindle diameter (mm) 130/26/2500 Table length (mm)  L = 7.000 Table width (mm) W = 1.200 Longitudinal X (mm) X = 7.000 Cross Y (mm) Y = 2.000 Pos ATC Z = 600 Number APC. Duplex borer 2 x Chain ATC 60 Pos. 2 x pallet 7000 x 1200 2 x chip conveyor

Sheet thickness: 8,00 mm Folding length: 1250 mm Depth rear gauge: 1000 mm CNC Brand: _Unknown / Other CNC Model: POS 900 Make Schroder 8 mm Type MAK 4 / 1500 x 8.0 Year 1998 POS 900 - 1000 mm Sheet thickness (mm) T = 8.0 mm Folding length (mm) L = 1.520 Depth rear gauge (mm)X = 1.000Hydr. upper & lower beam Hydraulic top tool clamping 1 set tooling

Machine Details Warehouse number 1105-03677 Machine type machining center - Universal HERMLE brand Type C 600 U Year of construction 2003 Control type CNC Control TNC 530 Heidenhain Storage location FRANCE Country of origin Germany Delivery time ON REQUEST Freight base from location Technical details x-travel 600 mm y-travel 450 mm z-travel 450 mm Control TNC 530 Heidenhain Speed range - main spindle 16000 min/-1 Drive power - main spindle 7 / 9 kW Tool holder SK 40 Spindle bearing diameter 70 mm Displacement measuring system direct Resolution 0.001 mm Table clamping surface Ø 280 mm table load 250 kg Swivel range +/- 110 ° rotatable 360000 ° Number of tool positions 30 pos. tool diameter 80 (125) mm Changeover time chip - chip 5.5 sec Rapid traverse ( X / Y / Z ) 35 / 35 / 35 m/min Feed speed 1 - 30,000 mm/min Feed force 6 kN Total power requirement ...

: 34 mm : 40 mm : 40 mm threading in St 60: M 24 threading in GG 20: M 30 : MK 4 : 100-1.800 U/min. throat: 300 mm : 615x430 mm : 2 x 14 x 224 mm : 138/688 mm column diameter: 145 mm spindle stroke: 160 mm feeds: 0,1-0,2-0,3-0,4 mm/U total power requirement: 1,4/2,2 kW Machine height: 1865 mm weight: 605 kg Standard equipment: 7 TFT LCD display with touch function: manual input of spindle speed Setpoint, actual speed display, integrated drilling depth display with touch Zero point transfer, virtual drilling depth scale in the display, machine Status displays and warnings in the display, service information, selectable User language: DE / EN / FR / ES / IT / NL / RU - Thread cutting device, for thread cutting with stop, max. 6th Thread / min (thread cutting performance dependent on spindle speed), thread depth adjustable via depth stop and in the TFT - LCD display (4 tools) - Infinitely v ...

Machine Details Stock-No. 1105-03677 Type of machine Machining Center - Universal Make HERMLE Type C 600 U Year of manufacture 2000 Type of control CNC Storage location HAGUENAU Country of origin Germany Delivery time IMMEDIATELY Freight basis ex site Technical details X-Travel 600 mm Y-Travel 450 mm Z-Travel 450 mm control TNC 430 Heidenhain Turning Speed Range - Main Spindle 16000 min/-1 Power Capacity - Main Spindle 7 / 9 kW tool taper SK 40 Spindle bearing diameter 70 mm measuring system direct Resolution 0.001 mm table surface area Ø 280 mm table load 250 kg Swivel range +/- 110 ° rotatable 360000° Number of ToolPositions 30 pos. tool diameter 80 (125) mm change-time chip to chip 5.5 sec rapid traverse ( X / Y / Z ) 35 / 35 / 35 m/min Feed Speeds 1 - 30,000 mm/min Feed force 6 kN total power requirement 30 kVA weight of the machine approx. 6.5 t ...

x-travel: 635 mm y-travel: 510 mm z-travel: 460 mm control: 840D ShopMill Siemens Main spindle:: turning speed range - main spindle: 20 - 12.000 min/-1 power capacity - main spindel: 18,9 / 14 kW tool taper: SK 40 DIN 69871 max. Torque: 100 / 74 Nm tension force: 8 kN work table:: table surface area: 790 x 560 mm number of T-slots: 4 + 1 T-slot - distance: 100 mm T-slot - width: 4x 14H12 / 1x 14H7 mm max. table load: 600 kg table height over floor: 720 mm distance spindle nose and table: 120 - 580 mm Tool-Presetter:: number of toolpositions: 30 pos. Max. mould width: 80 / (130) mm max. tool length: 250 mm max. tool weight: 6 kg max. total weight: 80 kg change-time tool to tool: 1,6 sec change-time chip to chip: 6,0 sec feeds:: rapid traverse: 30 m/min feed speeds: max. 20.000 mm/min Feed force: max. 5 kN total power requirement: 21 kVA weight of the machine ca.: 5,0 t dimensions of t ...

Year 2000 CNC SIEMENS 840 D Longitudinal Traverse ( X Axis) 22.000 mm Cross Traverse (Y Axis) 1.500 mm Vertical Traverse (Z Axis) 3.000 mm Stoller Table 6000 X 2000 X 300 mm 2 Unid/ 2 Units Rapid Traverse X Axis 10.000 mm/min Rapid Traverse Y – Z Axis 15.000 mm/min Maximum Working Feed 5.000 mm/min Taper ISO 50 DIN 69871 AD 50 Turning Speeds 6.000 r.p.m. AutoIndex Head 45 º Head 360.000 Pos. Elbow 360.000 Pos. Main Motor Power 37 Kw. Nº Change Range 2 Ranges Automatic Tool Charger INCLUDED Tools at ATC 30 Coolant Through Tool 20 Bar INCLUDED Soluble Oil Tank with filter paper INCLUDED Head Coolant System + CF Box INCLUDED Longitudinal Chip Conveyor INCLUDED Operator?s Platformd with 2000 mm Vertical movement. INCLUDED Ready for Rotor Translating Table (Regulator + Wires) /INCLUDED Coolant System in Electrical Cabinet INCLUDED Machine Weight 68.000 Kg. Mach ...

approx. 8 – 10 pieces continuous scale / Automatic scales for use in a conveyor system, Mettler Toledo – used - Price per piece: 2.950.-€ ex site (net), dismantled, packed and loaded! Manufacturer: Mettler Toledo For example (a more detailed list will follow) Item 48 Automatic Scale Year of construction: 2020 Type: C 21 TLW250Corgo Max. 35,000grams Min: 100gram T= - 35.000gr 230V Strap width: approx. 49cm Item width: approx. 55cm Length: 1.07m Terminal / Dísplay: ICS469d-cargo ICS4x9-1 110-240V – 50/60Hz, 300mA Still without pos.: Automatic Scale Year of construction: 2014 Type: ICS469-100 Max. 40,000gram Min: 200gram D= 5gr T= - 40.000gr 230V Still without pos. (hangs under the ceiling): Automatic Scale Year of manufacture: 20 Type: C21 TLW250 Cargo Type: LCC300 Max. 300kg Min: 200gram D= 5gr T= - 40.000gr 230V

Machine Details Stock number 1105-03812 Machine type CNC turning and milling center Brand GILDEMEISTER Type CTX beta 500 Year of construction 2014 Control type CNC Control 840 D SL SIEMENS Storage location FRANCE Country of origin Germany Delivery time by arrangement Freight base from site Price Technical details Turning diameter 410 mm Turning length 850 mm Control 840 D SL SIEMENS Circumferential diameter over bed 500 mm Speed range - main spindle 25 - 5,000 min/-1 Drive power - main spindle 25 / 34 kW torque 280 Nm C-axis 0.01 ° Spindle nose 170 h5 chuck diameter 210 mm Chuck diameter 250 mm Spindle diameter in the front. Bearing 130 mm Spindle bore 87 mm bar diameter 77 mm Number of tool positions 16 pos. Number of driven tool stations 16 pos. Drive power applied WZ stations 11.3 kW Speed range - antr. Tool stations max. 4.000 min -1 Tool holder VD ...

x-travel: 2.940 (2x 1.220) mm y-travel: 500 mm z-travel: max. 800 mm Control: TNC 426/430 Heidenhain distance spindle nose and table: V: 0 - 770 mm distance spindle nose and table: H: 180 - 980 mm Main spindle:: turning speed range - main spindle: 80 - 8.000 min/-1 power capacity - main spindel: 40 kW max. Torque: 191 Nm spindle diameter in front bearing: 70 mm swivellable: +/- 90 ° tool taper: SK 40 work table:: table surface area: ca. 3.340 x 650 mm T-slots: 14 H9 mm max. table load: 600 kg Tool-Presetter:: number of toolpositions: 22 pos. tool taper: SK 40 change-time tool to tool: 5 sec change-time chip to chip: 9 sec max. tool diameter: 85 mm max. tool-dia with free toolbox: 135 mm max. tool length: 400 mm max. workpiece weight: 8 kg feeds:: rapid traverse ( X / Y / Z ): 25 / 25 / 20 m/min Feed x / y / z: 1 ... 9.999 mm/min feed power: 9 kN total power requirement: 69 KVA weigh ...

Saw blade grinding machine Schmidt Tempo ECE 45 - 4 Technically obsolete in 2023 CBN deep section with A-Pos and automatic chamfering Prepared for the use of grinding oil, so that a much longer service life of all aggregates is guaranteed in contrast to working with emulsion. The automatic measurement of the tooth position for regrinding and chamfering is carried out via the AUTO POS system. A short video of a calibration process can be viewed under the link. Car. Fire extinguishing system Kraft und Bauer For regrinding and production of circular saw blades with angle and arch tooth according to tooth shape A, AW, B, BW, and C according to DIN 1840 for circular saw blades from 20 mm Ø to 550 mm Ø. Cycle and grinding time display automatic central lubrication Control cabinet cooling Centering holder with centering bolt 16 mm Ø Tension nut with mec ...

Min. output: 20t/h, wear plates: 13x Pos. 3, 14x Pos. 9, 20x 325x250mm, 28x 120x160mm, 18x 250x250mm, 23x 150x380mm, with blow bars, jaws, metering channel and 4x set screws with collar.

x-travel: 600 mm y-travel: 450 mm z-travel: 450 mm control: TNC 430 Heidenhain Main spindle:: turning speed range - main spindle: max. 10.000 min/-1 power capacity - main spindel: 7 / 9 kW tool taper: ISO 40 spindle bearing diameter: 70 mm measuring system: direct Resolution: 0,001 mm swiveling-rotary-table:: table surface area: Ø 280 mm max. table load: 250 kg Swivel range: +/- 110 ° rotatable: 360 ° Tool-Presetter:: number of toolpositions: 30 pos. max. tool diameter: 80 (125) mm change-time chip to chip: 5,5 sec feeds:: rapid traverse ( X / Y / Z ): 35 / 35 / 35 m/min feed speeds: 1 - 30.000 mm/min Feed force: 6 kN total power requirement: 30 kVA weight of the machine ca.: 6,5 t dimensions of the machine ca.: 3,5 x 3,5 x 2,8 m Documents: chip tray: Coolantsystem: hydraulic system: test probe: TS 632 elektr. hand wheel: Automatic Tool Changer: 30 pos. full splash guard: 5  ...

turning diameter: max. 320 mm turning length: 450 mm control: 32 i S Fanuc centre height: 190 mm turning diameter over bed: 320 mm turning dia. over face-slide: 260 mm Main spindle:: turning speed range - main spindle: max. 5.000 min/-1 power capacity - main spindel: 11 / 7,5 kW max. Torque: 115 / 86 Nm usable bar diameter: max. ( 52 ) mm spindle bore: 68,5 mm spindle diameter in front bearing: 100 mm C-Axis: 360 x 0,01 ° axis stroke:: travel -x axis: 160 mm travel -z axis: 450 mm turret:: number of toolpositions: 12 pos. tool taper: VDI 30 Shank diameter: 20 x 20 mm Number of driven toolspositions: 6 pos. max. speed driven tool stations: 5.000 min/-1 power capacity - driven tool-stations: 3,7 kW Tailstock:: tailstock adjustment: 400 mm intake pressure max.: 4.000 N feeds:: rapid traverse: X: 20 / Z: 30 m/min Feed force ( X / Z ): 4,5 kN total power requirement: 24 kVA weight of th ...

MCM Clock 600 MP14 FMS consisting of 2 machines CNC FANUC 16i-M, 14 pallets 500mm x 500mm Spindle 15000RPM full 4th axis (360.000 pos) Tool Changer: 200 pos. X=600mm, Y=600mm, Z=700mm JFMX supervisor 2001 Under power in our warehouse in Gussago Mimu Machine Tools (Italy), X: 600, Pallets: 14, Pallet size: 500x500, Spindle: 15000 rpm

Chiron FZ15KS HIGH SPEED, 4 axis vertical machining center, X: 550mm, Y: 400mm, Z: 360mm, 4th axis original Peiseler 360.000 pos, CNC Siemens 840D, Table 1050 x 450mm, Toolchanger 48 pockets, ISO 40, Spindle 12000 1/min, Renishaw tool control, Coolant through spindle, Hydraulic clamping, Swarf conveyor, Under power in our warehouse in Gussago BS, Mimu machine tools, Spindle: 12000 RPM, 4th axis: 360 000 pos

turning diameter: 324 mm turning length: 600 mm control: SINUMERIK 840D ShopTurn bar diameter: 65 mm swing diameter: 680 mm travel -x axis: 260 mm travel -z axis: 635 mm spindle speed:: 5000 1/min spindle bore: 79 mm C-Axis: 0,025 ° turret head: 12 Pos. / VDI 40 Driven Tools: 12 Pos. 4.500 U/min rapid traverse X-axis: 60 m/min rapid traverse Z-axis: 45 m/min taper in tailstock-quill: MK 5 tailstock travel: 580 mm drive capacity - spindle motor: 25 kW voltage: 400 V total power requirement: 50 kVA weight of the machine ca.: 6,0 t dimensions of the machine ca.: 3,50 x 2,46 x 2,10 m chip conveyor: 4,00 x 1,25 x 1,50 m - Serial-No.: 02260001561 - Machine ON: 64.692 h - Programm ON: 18.296 h - control: SIEMENS 840D ShopTurn - electrical hand wheel - C-Axis / driven tools - Spindle bearings NEW - Ball screw Z-Axis incl. bearings NEW - chip conveyor - coolant equipment - machine lamp The dat ...

turning diameter: 324 mm turning length: 600 mm control: Data Pilot 4290 HEIDENHAIN swing diameter: 680 mm bar diameter: 65 mm travel -x axis: 260 mm travel -z axis: 635 mm spindle speed:: 5000 1/min spindle bore: 79 mm C-Axis: 0,025 ° turret head: 12 Pos. / VDI 40 Driven Tools: 12 Pos. 4.500 U/min rapid traverse X-axis: 60 m/min rapid traverse Z-axis: 45 m/min taper in tailstock-quill: MK 5 tailstock travel: 580 mm drive capacity - spindle motor: 25 kW voltage: 400 V total power requirement: 50 kVA weight of the machine ca.: 6,0 t dimensions of the machine ca.: 3,50 x 2,46 x 2,10 m chip conveyor: 4,00 x 1,25 x 1,50 m - Serial-No.: 02260003251 - Machine ON: 19.039 h - Programm ON: 2.676 h - control: HEIDENHAIN Data Pilot 4290 - New main spindle bearings - Z-Axis ball screw reconditioned incl. new bearings - electrical hand wheel - C-Axis / driven tools - chip conveyor - coolant equipmen ...

x-travel: 2.200 mm y-travel: 560 mm z-travel: 720 mm control: 840 D Powerline ShopMill Siemens Main spindle:: turning speed range - main spindle: 20 - 12.000 min/-1 power capacity - main spindel: 35 / 25 kW max. Torque: 130 / 87 Nm tool taper: SK 40 internal coolant system feed: 40 bar work table:: table surface area: 2.600 x 600 mm max. table load: 2.200 kg number of T-slots: 6 T-slot - width: 18 H7 mm T-slot - distance: 100 mm Tool-Presetter:: number of toolpositions: 30 pos. max. tool length: 300 mm max. tool weight: 6 kg max. tool diameter: 80 / 125 mm feeds:: feed speeds: 20.000 mm/min input unit: 0,01 mm rapid traverse ( X / Y / Z ): 100 / 50 / 50 m/min measuring system: Resolution: 0,001 mm total power requirement: 60 kVA weight of the machine ca.: 12,5 t dimensions of the machine ca.: 6,0 x 3,7 x 2,9 m Documents: Chip conveyor: Coolantsystem: high pressure coolant: throu ...

sheet width: 2030 mm plate thickness: 4,0 mm thickness at Niro-steel: 2,5 mm no. of strokes: 34 Hub/min cutting angle: 2,5 Grad table height: 820 mm distance between columns: 2340 mm Control: POS 100 back stop - adjustable: max. 750 mm engine output: 6,8 kW weight of the machine ca.: 2860 kg. range L-W-H: 2870 x 2070 x 1400 mm Machine from a maintenance workshop very well maintained condition - hardly used () Furnishing: - robust / motorized swing-cut guillotine shears - Shatterproof, torsion-free steel welded construction - compact and clear mechanical design - Electric back gauge, with SCHRÖDER POS 100 NC control Digital position display from the backgauge adjustable from the front right with target/actual value input Continuous adjustment over the entire travel range Protection of limit values with limit switches 9-fold programming possible - Duo-Cut drive with two dynamic, p ...

sheet width: 2030 mm plate thickness: 4,00 mm thickness at Niro-steel: 2,50 mm no. of strokes: 34 Hub/min cutting angle: 2,5 Grad table height: 820 mm distance between columns: 2340 mm Control: POS 100 back stop - adjustable: max. 750 mm engine output: 6,8 kW weight of the machine ca.: 2860 kg. range L-W-H: 2870 x 2070 x 1400 mm Machine from a maintenance workshop very well maintained condition - hardly used () Furnishing: - robust / motorized swing-cut guillotine shears - Shatterproof, torsion-free steel welded construction - compact and clear mechanical design - Electric back gauge, with SCHRÖDER POS 100 NC control Digital position display from the backgauge adjustable from the front right with target/actual value input Continuous adjustment over the entire travel range Protection of limit values with limit switches 9-fold programming possible - Duo-Cut drive with two dynamic, ...

turning diameter: max. 1.070 mm turning length: max. 3.076 mm control: Fanuc 31iB5 MAPPS max. swing diameter: 1.070 mm Max. distance between centres: 3.510 mm axis stroke:: x-axis: 1.040 (1.000 + 40) mm y-axis: +/- 330 mm z-axis: 3.150 mm b-axis: +/- 120 ° z-axis: 2: max. 2.440 mm Main spindle:: max. spindle speed: 1.500 min/-1 Number of speed ranges: 2 power capacity - main spindel: 30 / 26 kW max. Torque: 3.254 Nm spindle bearing diameter: 260 mm spindle bore: 185 mm max. usable bar diameter: 164 mm C-Axis: 0,0001 ° spindle nose: JIS A2-15 Subspindle:: max. spindle speed: 1.500 min/-1 Number of speed ranges: 2 power capacity - Sub spindle: 30 / 26 kW max. Torque: 3.254 Nm spindle bearing diameter: 260 mm spindle bore: 185 mm max. usable bar diameter: 164 mm C-Axis: 0,0001 ° spindle nose: JIS A2-15 Work tool spindle:: Max. rpm: 8.000 min/-1 power capacity: 30 / 22 kW max. Torque: ...

turning diameter: 210 mm turning length: 580 mm control: 840 D Siemens centre height: 190 mm turning diameter over bed: 330 mm turning dia. over face-slide: 260 mm Main spindle:: turning speed range - main spindle: max. 4.000 min/-1 power capacity - main spindel: 10 / 7,5 kW max. Torque: 115 / 86 Nm spindle bore: 68,5 mm max. usable bar diameter: 51 mm C - Axis: 0,001 ° axis stroke:: travel -x axis: 185 mm travel -z axis: 455 mm turret:: number of toolpositions: 12 pos. tool taper: VDI 30 Driven Tool Stations:: 6 pos. Tailstock:: tailstock adjustment: 400 mm intake pressure max.: 4.000 N feeds:: rapid traverse: X: 20 / Z: 30 m/min Feed force ( X / Y / Z ): 4,5 kN total power requirement: 21 kW weight of the machine ca.: 3,2 t dimensions of the machine ca.: 8,0 x 2,2 x 2,0 m Documents: Chip conveyor: Coolantsystem: Tailstock: parts catcher: C-axis: driven tool stations: Signa ...

faceplate diameter: 3.000 mm swing diameter: 3.200 mm turning height: 2.200 mm Control: 840 D ShopTurn Siemens cross rail adjustment: 1.500 mm tool travel: 1.250 mm faceplate turning speed range: 0 - 120 U/min power capacity: 75 kW Driven Tool Stations:: speeds: 10 - 3.000 U/min output: 22 kW max. Torque: 320 Nm tool adaptor: HSK 160 (VDI 60) tool magazin:: number of toolpositions: 16 pos. weight of tools max.: 25 kg total power requirement: - kW weight of the machine ca.: 36 t dimensions of the machine ca.: 6,0 x 6,0 x 3,5 m Chip conveyor: Coolantsystem: C-axis: 0,001° hydraulic system: Tool Magazine: 16 pos. tool holders: div. Vertical Turning Machine KONRAD SEIDLER - Vertimaxx 3000 - including clamping material, various tool holders - 1x angle bore and milling head 90° Drive spindle according to SEIDLER HSK 160B Output spindle ABS 63 Gear ratio i 1:1 Max. speed 2300 rpm (co ...

Key data: 510 mm, 670 mm

machine details Stock-No. 1105-03944 Type of machine CNC Turning- and Milling Center Make CMZ Type TL 25 A SM Year of manufacture 2007 Type of control CNC Storage location FRANCE Country of origin espagne Delivery time to be agreed Freight basis EX WORK Technical details turning diameter 510 mm turning length 640 mm control FANUC 31 ITB bar diameter 66 mm Travel -X Axis 240 mm Travel -Z Axis 640 mm Turning speed range - drive spindle 4000 1/min spindle nose JIS A2-6 Spindle Bore 66 mm C-Axis 0.001° Spindle Bearing Diameter 110 mm turret head 12 Pos. Driven Tools 12 Pos. tool changing time 0,2 sec rapid traverse X-axis 18 m/min rapid traverse Z-axis 24 m/min Drive Capacity - Spindle Motor 19/14 kW power capacity - milling spindle 14/8 kW total power requirement 35 kW weight of the machine approx. 5.7 t dimensions of the machine approx. 2.4 x 1.8x 1.9 m  ...

Key data: 3000 mm, 1200 mm, 800 mm

Processing Center Universal Fabriakt: Cheto Type: 9700 H 6 axles Year of construction 2014 Technical details x-axis: 3000 mm y-axes: 1200 mm z-axes: 800 mm Table size 1800x1800 mm Positioning type 360,000 pos. Max. alternating load 30 ton W stroke bore 1700 mm B Table rotation 360.000 pos. A Tilt-Rotation +35º/-25º Max. drilling stroke W+Z 1700+800 mm Drilling capacity ø5-40 mm Spiral Tapping Standard Tapping M34 Milling 500 cm3/min Speed 0-6000 rpm. Recording ISO 50 DIN 69871 Power 24/38 kW Torque 214/338 Nm Total weight 39 Ton Footprint (WxL) 9520x7410 mm Total weight GDATC 52 Ton

turning diameter: 310 mm turning length: 600 mm control: Sinumerik 810 D PL Siemens turning diameter over bed: 425 mm Main spindle: turning speed range - main spindle: 500 - 4.500 min/-1 power capacity - main spindel: 16,5 kW max. Torque: 280 Nm Spindle diameter: 100 mm C-Axis: 360 ° chucking diameter: 210-52 mm spindle bearing diameter: 120 mm clamping cylinder: 65 mm Bar feed: max. 65 / (52) mm spindle nose: A8 DIN 55026 axis stroke:: x-axis: 230 mm z-axis: 740 mm rapid traverse X-axis: 15 m/min rapid traverse Z-axis: 24 m/min turret:: tool positions turret: 12 pos. driven statition: 12 pos. tool taper: DIN 69880 30 mm Spindle speed driven tools: 6.000 min -1 power capacity - driven tools: 3,7 kW max. Torque: 9,5 Nm tail stock: dia. of quill: MK 4 80 mm quill stroke: 120 mm tailstock adjustment: 475 mm tension force: 500 daN total power requirement: - kW weight of the machine ca.: ...

bore capacity in steel (diameter): 40,0 mm threading: M 24 in St 60 throat: 293 mm bore stroke: 120 mm morse taper: 3 Kurzspindel MK table:: 360 x 515 mm turning speeds: 80 - 1.125 U/min feed: 0,10 + 0,20 mm/U total power requirement: 1,0 / 1,6 kW weight: 270 kg height of the machine: 1,84 m Furnishing: - Lockable main switch with motor protection switch - Mushroom pushbutton (latching) for EMERGENCY STOP - Infinitely variable speed adjustment - Digital speed display - Feed overload protection - Protection class IP 54 - Spindle protection with electrical fuse - Operating instructions in German including special equipment: - Thread cutting device pos. 20.0 (Thread cutting with stop) - Coolant device B pos. 25. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Year of production 1993. Bought in 2007 as efficient and operational, it was never launched in Poland. Stored in a dry room and secured with a tavern. Salvagnini S4 + P4 cutting and bending center P4_0387 model 2220 with configuration: TC24155F.CT.CRPD + DU2515.SF + S4.25.DF.H2.SSA.CC.P2R36.BU31.BU32.BU33.BU34.BU35.EI05.EI09.EI13.UL1 + SC115C + IMS2715.RIU + TC27155D + ASPA2420.SFE + P4-2220.RC.GPS.SFE.LSA.LIA.PB.T.DL.CLA.U29 + SPR24.POS + AIP24 + HISRS + PSMVMS + H and S4_0385 about configuration: TC24155F.CT.CRPD + DU2515.SF + S4.25.DF.H2.SSA.CC.P2R36.BU31.BU32.BU33.BU34.BU35.EI05.EI09.EI13.UL1 + SC115C + IMS2715.RIU + TC27155D + ASPA2420.SFE + P4-2220.RC.GPS.SFE.LSA.LIA.PB.T.DL.CLA.U29 + SPR24.POS + AIP24 + HISRS + PSMVMS + H P4: 2200 mm bending length, bending depth 200 mm, bending angle 125 degrees. Bending thickness 1.5 mm.
