plate bending used for sale

Technical data: -Pressure capacity 2000 kN -Max working width 3100 mm -Stand round 3200 mm -Stand RADIUS 300 mm -Max mounted height 965 mm -Hub, or insertion depth Steplessly adjustable 0-400 mm -Plunger speed forward + reverse per 100 mm / sec -Operating speed in 9 steps selectable 1-10 mm / sec -Drive 400 V / 26.5 kW - space requirement approx. B H 4400 x 3500 X 2200 mm -Weight approx. 18500 kg -with: - CNC - control CYBELEC ModEva 15s BJ. 2007 -Back gauge with 4 controlled pneum. on the side and height-adjustable stop fingers -controlled bending AIDS in the velocity range -Hydr. -Pneum.. Clamp of the upper tool + substation witness -mot. Crowning / hydro cushion in the table -laterally movable support arms -E - foot switch -split pointed tool R 1-100 t / m, split die

Technical data: -Length approx. 2500 mm -Width approx. 1000 mm -Height approx. 800 mm -Top plate thickness approx. 90 mm - 4 pieces t grooves in the table surface length 2500 mm -Centre distance of the T-slot table surface each 215 mm -T - slot width approx. 40 / 70 mm -T - groove depth approx. 60 mm -Space requirement L 2700 x T 1200 x H 800 mm - weight approx. 3700 kg

Technical data: -Get well plate surface -Length approx. 2000 mm -Width approx. 1000 mm -Height approx. 1600 mm -Top plate thickness approx. 95 mm -Top plate with internal ribbing - 4 piece t grooves on the surface of the table length 2000 mm -Centre distance of the T-slot table top 230 mm each -Table side L 2000 mm with 12 holes M27 -T - slot width approx. 40 / 67 mm -T - groove depth approx. 35 / 60 mm -Space requirement L 2200 x T 1200 x H 1600 mm - weight approx. 4980 kg

Technical data: -Working width 1030 mm -Material thickness 1.25 mm -Roll diameter 55 mm -Upper roller swing -Rear and front wave about eccentric adjustable -Rear and front wave each with a Groove to round -for sheet metal with wire inlay -Space requirement approx. B H 1350 x 1050 x D 750 mm -Weight approx. 150 kg

Technical data: -maximum working width 750 mm -maximum material thickness approx. 1.0 mm -Beam + upper cheek fold away -Bending rail with cut-outs - space requirement approx. B 1000 x H 1100 x D 750 mm -Weight approx. 70 kg

Round bending machine

Tube bending machine

Original MINGORI® Model OB40 - Mobile hydraulic tube bending machine with manually operated hand pump, suitable for bending pipes according to DIN, API and ASA standard, as well as coated PE-HD pipes. The machine works in the compression bending process. The greatest surmountable material resistance torque that can be overcome with the machine is about 28 cm³. Maximum bending force 18 tons Maximum bendable pipe diameter 88.9 mm Smallest possible bendable pipe diameter 17.2 mm Smallest bending radius depending on the radius of the bending punch from 46.5 mm to 330 mm Smallest bending angle 110° (this machine also available for bending angles up to 180°) Weight of the basic machine approx. 140 kg The machine is delivered in a storage chest – Dimensions of the chest approx. 102 x 32 cm x H 41 cm Weight basic machine 140 kg With electrically operated hand pump (as mo ...

Working width: 3000 mm sheet thickness: 15 mm sheet thickness in bending: 10 mm top rollers Ã?: 320 mm bottom rollers diameter: 310 mm speed: approx. 5.5 m / min. Connection: 380V kW weight: 17000 kg space requirement: 5450 x 2100 x 2450 mm

A generally overhauled blower type GMb 039 is offered.

SHUZ TUNG CNC 50 BRM CNC tube and profile bending machine built in 2014 in Taiwan allows for fully automatic, serial production of complex spatial workpieces in 5 axes with simultaneous hole punching. Excellent precision and accuracy of bending are guaranteed by the reliable servo motors used in the machine, which are responsible for realising the main working movements, i.e. bending, rotation and material feed. The rest of the movements are driven by a central hydraulic system with electronic lubrication. The SHUZ TUNG CNC mandrel bending machine is operated via a control panel with an installed CNC controller with the option of saving an unlimited number of programmes. In addition, the automatic servo bending machine is equipped with several bending rolls, a high-quality mandrel and an actuator to support material feed. The 50 BRM automatic CNC mandrel bending machine weighs 3500 kg ...

The HKB series swivel machines are used for bending thin sheet metal. Due to their compact design, they fit easily into small workshops and cover a wide range of applications with their segmented upper tool. With an adjustable angle stopper, these swivel machines are also suitable for the production of small batches. Compact and torsion-resistant Segmented upper tool for many bending options Integrated, manual bend compensation Adjustable angle stop for series production Hands free Foot control of the upper bolster clamp Workspace Working length 1270 mm Sheet thickness (max.) – 400 N/mm² 2 mm Dimensions (length x width x height) 1.6 m x 0.9 m x 1.18 m Weight 330 kg Angle range of the bending beam 135°

BLM DYNAM 3 CNC tube bending machine was built by BLM S.P.A. in Italy in 1999. Distinguished by its high productivity and bending accuracy, the machine is an indispensable tool in any production facility. The applied technical solutions and reliable components make it possible to perform fully automatic, serial bending of profiles and tubes with a maximum diameter of 60 mm. All process parameters are entered on an intuitive CNC controller with many functions that facilitate the programming of even the most complex shapes in just a few steps. Throughout its lifetime, the DYNAM 3 mandrel bending machine has been regularly serviced. The total weight of the machine is 5070 kg. Technical specifications of the BLM DYNAM 3 CNC tube and profile bending machine - CNC control system: BLM FNC 2000 R - maximum tube diameter: 60 mm - tool set for bending tubes Ø 25 mm - lubricant pump: FLENCO ...

Specifications: 2 castors hydraulically adjustable 3 rollers driven Resistance torque: 80 cm³ Shaft diameter: 100 mm Roll diameter: 315 mm lateral hydr. Controlled arm correctors left and right CE. Mark Bending capacity square: 120 x 60 x 5 mm Bending capacity flat steel: 130 x 25 mm Bending capacity tube: 114.3 x 6 mm Bending power angle: 100 x 10 mm Round steel: 80 mm Motor power: 11 kW Control panel with digital display Dimensions (length x width x height): approx. 1750 x 1850 x 1650 mm Weight: approx. 3.6 tons Accessories: Various bending rollers Condition: we will still carry out a complete service on the machine The seller is not liable for typographical or data transmission errors. The machine is appropriate for its age in terms of appearance, technology and wear; used machines are sold without any warranty.

1 Qty. 1 Second-hand 3 roll bending machine Mfc.: SW GmbH Type: SRMV G Built: 1989 Strip width max.: 2000 mm Wall thickness: max. 25 mm / Ø 530 mm 2 Qty. 1 Second-hand 3 roll bending machine Mfc.: SW GmbH Type: SRMV Hy Built: 1981 Strip width: max. 3500 mm Wall thickness: max. 12 mm 3 Qty. Second-hand 3 roll bending machine Mfc.: SW GmbH Type: SRMV Hy Built: 1983 Strip width: max. 3500 mm Wall thickness: max. 19 mm 4 Qty. 1 Second-hand 4 roll bending machine Mfc.: SW GmbH Type: SVRM Built: 1981 Strip width: max. 2000 mm Wall thickness: max. 16 mm

Bearing number: 3488 Profile steel shears Manufacturer: Mubea, Type: KBLH 500 Machines NR.: 0156085927332, Year of construction: 0 Specifications: Size Printl 50 To Max punching dia 30 x 15 mm mm Stroke length 0-60 mm Number of strokes per min. 16 Extension 410 mm Flat steel 180 x 20 - 400 x 10 mm Angular steel 50 mm Round steel 55 mm Total power 7.5 kW Hydraulic. Length: 1400 mm, Height: 1800 mm, Width: 800 mm, Weight: 1800 kg

MACRI ITALIA PROVAR 6-45 U-D tube and profile bending machine was built in 2015 in Italy by Macri Italia srl. The machine, designed for precision bending of tubes and profiles with a maximum diameter of 45 mm, is an answer to the daily challenges of modern business. The machining process is performed by means of a moving head with reinforced gears, which allows the bending of standard and variable radiuses in 6 axes (X,Y,Z,B1,B2,A). Each axis, in turn, is driven by brushless servomotors, which ensure the achievement of high dynamics, combined with excellent positioning accuracy. The machine’s extensive range of equipment includes e.g. state-of-the-art MACRI software with many useful functions and the ability to run a anti-collision test with 3D simulation. The PROVAR 6-45 U-D mandrel bending machine weighs 4000 kg. Technical specifications of the MACRI ITALIA PROVAR 6-45 U-D tube be ...

SAHINLER 4R HC 10-185 4-roll plate rolling machine was built in 2021 in Turkey by Şahinler Metal Makina Endüstri A.Ş. The machine, distinguished by its high precision and efficiency, is designed to roll conical forms from sheet metal with a maximum thickness of 4 mm. The machining process is performed by four induction-hardened rollers with their own drive, in the form of planetary gears and reliable hydraulic motors. To ensure uninterrupted, long-term operation, each of the four rollers has been subjected to prior heat treatment and resistance tests. This solution, combined with the stable construction made of high-quality steel, guarantees the achievement of high repeatability of the manufactured parts. The 4R HC 10-185 plate bending machine weigh 2545 kg. Technical data of the SAHINLER 4R HC 10-185 plate rolling machine - number of rollers: 4 - rollers working length: 1050 mm  ...

DAVI MCA 1513 4-roll plate rolling machine was built in 2023 in Italy by Promau S.r.l.. This highly efficient machine is the perfect choice for precision rolling of cylindrical, elliptical and conical forms. Sheet metal with a maximum thickness of 6,5 mm is machined fully automatically by four rollers, which are driven by planetary gears. In turn, the advanced control system allows, among others, the generation of a full programme from CAD files and an offline performance test. The offered DAVI MCA 4-roll plate bending machine is a guarantee of achieving repeatable parts of the highest quality. Technical specifications of the DAVI MCA 1513 plate rolling machine - number of rollers: 4 - maximum sheet metal thickness (mild steel, yield point 260 MPa): 6,5 mm - maximum sheet metal length: 1500 mm - control system: DAVI - motor power: 5.5 HP - power supply of the MCA 1513 machine: 4 ...

Key data: 200 mm, 400 , 360

Profile Bending machine Model AR360 -Year 2004 MG brand made in Italy OUTPUT SHAFTS 360 MM Capacity as per the original bending chart here enclosed Configuration installed with the machine -Pyramid dual pinch side rolls independent hydraulic positioning bending and pre-bending performance -The 3 shafts driven with hydraulic motor and gear unit individual on each roll -Synchronized speed automatic hydraulic control between the 3 rotating shafts -hydraulic traction tool to roll HEB_INP_UPN bending on hard-side. -Lateral correctors left/right hydraulic operated in 3 directions Tooling with the machine -Set of rollers for pipe: 6” and 12” -Set of rollers with adjustable opening width up to 400 mm ( for all the profiles bending easy way and hard way ) -Set of rings to increase the rollers opening width up to 500 mm ( for all the symmetric profiles b ...

Key data: 200 mm, 300 , 200

Profile bending roll used equipment hydraulic model AR200 year 2008 make MG Italy Capacity bending chart photo in enclosed -Technical data: Output shafts size 200 mm -Machine complete with set of rollers adjustable for the various shape of profiles. -Traction tool hydraulic operated for the HEB-beam - IPE - UNP bending the hard side. -Lateral correctors left and right side hydraulic operated in 3 direction. -Included additional set of rolls for pipe 6" inches -Machine with 3 rolls driven system with individual hydraulic motor and axial gear-unit on each shaft. -The 3 shafts working on bearings, heavy duty type with sealed lubrication. -Centralized control panel movable on wheels with all electric commands. -Dual rolling speed up to 5 mtr/min with automatic balancing system between the 3 rolls. -Safety devices in compliance with European regulation. CE mark. - ...

Technical data: - Bending capacity - steel pipe of 20 - 60 x 4 mm - - stainless steel pipe of 20 - 50 x 3 mm - max. resistance moment 6.2 cm - max bending angle 180° - max radius 125 mm - Bending speed 8 sec - Drive 400 V / 3 kW - Space requirement approx. L 2400 x H 1600 x D 1000 mm - Weight approx. 1400 kg - with: - Bending angle control via potentiometer with digital display - 6-fold bending angle preselection - Indoor + external pipe deburrer - Bending tools Rx2.5D x 38 ; • 50 , 65 ;

GM-SB-38CNC-2A1S tube bending machine was built in 2019 in China by ZHANGJIAGANG KING-MACC MACHINERY MANUFACTURING CO., LTD. The machine, distinguished by its high precision and ease of operation, is used for bending tubes and profiles with a maximum diameter of 38 mm. All process parameters, including even the most complex shapes, are programmed in an intuitive PLC controller with memory for up to 200 work programmes. Thanks to the high degree of automation, the offered GM-SB-38CNC mandrel bending machine is an indispensable tool in any production facility. The total weight of the machine is approximately 1500 kg. Technical specifications of the GM-SB-38CNC-2A1S tube and profile bending machine - operator panel with PLC controller - bending capacity: ⌀ 38×2 mm - maximum bending angle: 180° - maximum bending radius: 200 mm - minimum bending radius: 20 mm - mandrel length: 32 ...

Qty. 1 Second-hand JCO pipe press bending line Mfc.: Samyul, ROBO, Shinsung, ChangSong, Rotech, FANUC, Hyupshun, Ingersoll Built: 2003, 2008, 2009, 2013, 2014 Plate material: Mild steel Plate dim.: 16.0 x 5.2 x 0.08 m – L x W x T Pipe dia.: Φ400~Φ1650 mm Pipe Length: 6.0m ~ 16.0 m Scope of supply: JCO Hydraulic Press Tack Welder Machine Sealing Welder Pipe Heating & Rotating Device Inside Welder Outside Welder Calibration Presses Milling Cutter Cutting Machine Bevelling Machine Compressor

VLB GROUP ECO 92 NC2 tube bending machine was built in 2022 in Portugal by the VLB Group. The machine has only undergone a test run and has not been used in production conditions. The machine is used for precision bending of tubes and profiles with a maximum diameter of 92 mm. All machining parameters are programmed in an advanced industrial controller with a touchscreen. It allows precise basic movements, i.e. bending angle (Y axis) and tube rotation (Z axis), to be performed fully electrically. The distance between bends (X axis) is, in turn, precisely set using mechanical stops. Thanks to the technical solutions used, the offered ECO 92 NC2 mandrel bending machine is the perfect choice for high-quality workpiece bending in small and medium series. The total weight of the machine is 2420 kg. Technical specifications of the VLB GROUP ECO 92 NC2 tube and profile bending machine -  ...

AMOB MAH 40/3 CNC 3-roll bending machine was built in 2021 in Portugal by AMOB Group. The machine, designed for bending tubes and profiles, ensures the highest precision and repeatability of the produced parts. The machining process is performed by three hardened rollers, of which the upper roller has hydraulic adjustment. Each of these is driven by a reliable, high-power motor, which is located inside a fully welded body. This solution enables bending of even the most complex shapes both vertically and horizontally. All this is complemented by an advanced CNC control with memory for numerous programmes. The MAH 40/3 CNC tube and profile bending machine weighs 540 kg. Technical specifications of the AMOB MAH 40/3 CNC bending machine - control panel with CNC control - number of rollers: 3 - roller diameter: 148 mm - roller rotational speed: 12 rpm - number of shafts: 2 - shaft di ...

Robust, high-quality round sheet bending machine for already profiled workpieces (sheet blades) - with motor drive at the bottom and top adjustable workpiece width between 300 mm and 800 mm, largest sheet thicknesses which can be bent round copper / titanium zinc / aluminium 0.8 mm - galvanized steel sheet 0.7 mm - stainless steel sheet 0.5 mm, smallest possible bending radius 350 mm - bending radius depending on the yield strength - smallest bending radius galvanized steel plate 0.7 mm - 1,000 mm, continuous speed infinitely adjustable 1 to 6 m/min, drive capacity 2 x 0.75 kW, weight 375 kg

Technical data: - bending and rolling by hand, - max working width 1020 mm - max. material thickness St 40 1.25 mm - Bending angle adjustment via end stop 10 - 180 ° - max hub upper cheek approx. 85 mm - max. adjustable bending cheek 20 mm - Shaft diameter 55 mm - Upper shaft can be swivelled - Rear shaft parallel + obliquely adjustable - Space requirement approx. W 1500 x H 1400 x D 750 mm - Weight approx. 400 kg

2.The main structure and performance of the machine tool: This machine tool is designed and manufactured using the latest technology, ensuring its strength, rigidity, and safety. Its simple and elegant appearance and exquisite workmanship demonstrate meticulous machining and component assembly. The machine utilizes a single, high-quality welded steel structure, resulting in a thick, rigid frame. The machine surface is sprayed with imported rust-resistant primer and topcoat, ensuring it remains as good as new for a long time. The frame and upper working slide are machined using imported large-scale CNC floor-type boring and milling machines, ensuring the required positioning accuracy of all mounting surfaces. This machine tool primarily consists of a frame, upper slide, backgauge system, slide, synchronous control device, mold, hydraulic system, and control system. 2.1 Frame: This pa ...

The all-electric servo bending machine is one of the products with independent intellectual property rights developed by our company. Special high-load screw and guide rail structure, imported bearing installation, high load-bearing capacity, high positioning accuracy, long life, machine tool rigidity, precision retention, and reliability are close to perfection. By introducing advanced design concepts and scientific design methods, the shortcomings that traditional designs cannot avoid have been solved. This bending machine is fast and simple to program, can realize concurrent linkage of multiple axes, fast feed positioning, and significantly improves the efficiency, accuracy and consistency of bending, which is far superior to traditional hydraulic bending machines, and does not require the use of hydraulic oil, is environmentally friendly and pollution-free. Compared with traditional ...

Press brake edge machine edge bench press used Manufacturer: Mengele Type: C320-4B Built: 1966 last revision and repair: 2000 Location D-01587 Riesa Dimensions WxH: 6,250 x 3,650 mm Edge knife width: 6,150 mm sheet thickness at 6,000 mm bending length: approx. 7.5 mm. The machines are designed for very deep shaft bends, therefore very deep cheek recesses. Original 300 t pressing force - In 1989 the pressing force was increased to 350 t. The press is in very good condition despite its age. The machine is disassembled and ready for loading. documentation for the machine is available. Weight: about 45 t

Key data: 40 t, 1030 mm

For sale is an automated press brake with 1st hand robot system for serial sheet metal part forming. Press brake 2019 BYSTRONIC Xpert 40/1030 Robot 2019 KUKA KR10R 1100 sixx Specifications Press brake - Press force: 400kN (40t) - Working length: 1030mm - Control: ByVision Robot - Max. nominal load capacity: 11kg - Reach: 1100mm - Axles: 6-axle - Position repeatability: 0.02mm - CE certified safety modules Characteristics - Fully automated bending cell with integrated 6-axis industrial robot - from 1st hand - Dimensions (LxWxH): approx. 3.25m x 2.8m x 2.5m - ByVision Bending control terminal with 22-inch Full HD touchscreen Machine condition - Operating hours: 7,724 h - Cycle counter: 310,212 - Complete service history, regular inspections - Technically perfect condition - Functional test: can be demonstrated during inspection - Location: Niederroh ...

SHUZ TUNG NCR38B tube and profile bending machine was built in 2008 in Taiwan by SHUZ TUNG MACHINERY INDUSTRIAL CO., LTD. The machine, distinguished by its high precision and ease of operation, enables automatic bending and forming of arches from tubes or profiles with a maximum diameter of 38 mm. All process parameters, including even the most complex shapes, are programmed in the intuitive NC controller with memory for up to 500 work programmes. The NCR38B mandrel bending machine is offered with equipment, consisting of, among others, tooling for tubes with 16, 22 and 25 mm diameters. The total weight of the machine is 1500 kg. Technical specifications of the SHUZ TUNG NCR38B tube bending machine - bending capacity: 38×2 mm - bending angle: 0-190° - maximum bending radius: 170 mm - mandrel length: 1800 mm - bending speed: 45°/s - rotation speed: 240°/s - bending accuracy: ...

SCHNELL SHEAR LINE 300 rebar cutting and bending line was built in 2008 in Italy by Schnell S.p.a. The electrical installation was overhauled in 2024. The SCHNELL SHEAR LINE 300 is a reliable system designed for serial machining of rebar with a maximum diameter of 50 mm. It integrates all the necessary equipment that is responsible for cutting, bending, optimising, storing and handling bars. The entire production cycle, from feeding to the collection of the finished parts, is performed fully automatically. The SCHNELL SL 300 stirrup production machine is fully complete and consists of the following components: – control console – FA/6/14 storage rack for steel – SCHNELL CGS 300 HDY guillotine shears – SCHNELL VBM 12/2 measuring and cutting track with single-sided unloading – SCHNELL ROBOMASTER 45 automatic rebar bending machine – rebar storage and retrieval system ...

Max Bending Length 2250mm Machine is in excellent condition - As New LOW HOURS

GM-SB-38CNC-2A1S mandrel bending machine was built in 2022 in China by ZHANGJIAGANG KING-MACC MACHINERY MANUFACTURING CO., LTD. The machine is used for precision bending of bars, profiles and tubes with a maximum diameter of 38 mm. The process is performed by means of a reliable working head, operating in manual or automatic mode. In order to guarantee high positioning dynamics combined with excellent positioning accuracy, all axes are equipped with powerful servomotors. Ease of operation is ensured by a convenient operator panel with PLC control. Its large memory enables the storage of up to 200 working programmes, as well as the rapid programming of even the most complex shapes. All this makes the GM-SB-38CNC the perfect solution for any production facility. The GM-SB-38CNC-2A1S tube and profile bending machine weighs 2000 kg. Technical specifications of the GM-SB-38CNC-2A1S tube be ...

sheet width: 1500 mm plate thickness: 1,5 mm distance between columns: 1500 mm bending angle max.: 135 ° total power requirement: - kW weight of the machine ca.: 0,36 t dimensions of the machine ca.: 1,7 x 0,7 x 1,3 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

specifications: - Pressure capacity 100 KN / 10 t - Compressive force adjustable 0 - 100 kN - Stroke length 0 - 150 mm - Clear width approx. 200 mm - Lifting speed 0 - 0.6 m/min - Tool height up to approx. 100 mm - Bending performance - with prism MW 100 flat to approx. 100 x 12 mm - Tube bending up to approx. 1 inch - Directional power Wy at straightening block distance of 1m 100 cm³ - Drive 400 V / 1.1 kW - Space requirement approx. W 1100 x H 1000 x D 650 mm - Weight approx. 400 kg

chamfer lenght: 0900 mm plate thickness: mm distance between columns: 900 mm pressure: 20 t column arm: 230 mm stroke length max.: 150 mm travel -x axis: 350 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

VERRINA CLR 216 X 4050 Sheet metal round bending machine Double roller with 4 rollers and double pressure Year of manufacture 1979 Capacity 4000 mm x 16 mm Roll length 4050 Roll diameter side rolls 370mm top & bottom roll 410mm Roll rise and fall 370mm Input 400/3/50 Hz 52 kW Rolling speed 2.9 / 3.9 / 6.8 meters per minute Control control panel Equipped with hydraulic drop, safety cable hoist Length 9000mm Width 2350 mm Height 2400 mm Net weight approx. approx. 29,500 kg

tube diameter: . mm wall strength: . mm bending radius min.: . mm Control: total power requirement: kW weight of the machine ca.: . t dimensions of the machine ca.: . m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

tube diameter: . mm wall strength: . mm bending radius min.: . mm Control: total power requirement: kW weight of the machine ca.: . t dimensions of the machine ca.: . m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

: 40 mm : 8,5 U/min : 120 mm roll diameter: 152 / 162 mm engine output: 1,1 kW connected load: 400/50 V/Hz hydraulic pump: 1,1 kW : 80 kN range L-W-H: 900 x 600 x 1000 mm weight: 470 kg Equipment / Accessories: - Three driven rollers - Hydraulic delivery of the upper roller - Digital display with memory function - Working position horizontal and vertical - Bearings with tapered roller bearings - Use of replaceable slide rails on the guide carriage - The standard roller set is included. He can turn used different profiles The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

: 95 mm Shaft diameter: 30 mm Shaft revolutions: 7 U/min roll diameter: 132 mm Drive: 0,75 kW weight: 220 kg range L-W-H: 530x900x660 mm Equipment / Accessories: - Two driven rollers with grooved surface - Manual feed of the upper roller - working position horizontal and vertical (with tilting base) - Bearings with tapered roller bearings - Use of replaceable slide rails on the guide carriage - The standard roller set is included. He can turn different profiles are used e.g. Flat iron, T-iron, solid material etc. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

round material: 40 mm tube diameter: 70x2 mm square material: 80x30x3 mm L-beam: 50 x 5 mm I - beam section - flat steel: 80 x 16 mm I-beam section - upend: 50 x 15 mm roll diameter: 157 mm Shaft diameter: 50 mm bending speed: 2,95 m/min total power requirement: 1,1 kW weight of the machine ca.: 500 kg dimensions of the machine ca.: 1000x950x1450 mm Domestic equipments: - Special steel shafts (42CrMo4) hardened and ground - a set of standard rollers - lower rollers up and down hydraulically deliverable - digital display for lower rollers - separate control panel - in one direction manually adjustable lateral straightening rollers - manual lubrication - horizontal and vertical operation - CE mark / Declaration of Conformity - Operating instructions in German The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

: 40 mm : 8,5 U/min : 120 mm roll diameter: 152 / 162 mm engine output: 1,1 kW connected load: 400/50 V/Hz hydraulic pump: 1,1 kW : 80 kN range L-W-H: 900 x 600 x 1000 mm weight: 470 kg Equipment / Accessories: - Three driven rollers - Hydraulic delivery of the upper roller - Digital display with memory function - Working position horizontal and vertical - Bearings with tapered roller bearings - Use of replaceable slide rails on the guide carriage - The standard roller set is included. He can turn used different profiles The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

sheet width: 1050 mm plate thickness: 1 mm roll diameter: 56 mm dimensions of the machine ca.: 1600 x 700 x 1050 mm Domestic equipments: - Upper roller can be swung out manually The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

: 40 mm : 8,5 U/min : 120 mm roll diameter: 152 / 162 mm engine output: 1,1 kW connected load: 400/50 V/Hz hydraulic pump: 1,1 kW : 80 kN range L-W-H: 900 x 600 x 1000 mm weight: 470 kg Equipment / Accessories: - Two driven rollers - Hydraulic delivery of the upper roller - Digital display with memory function - Working position horizontal and vertical - Bearings with tapered roller bearings - Use of replaceable slide rails on the guide carriage - The standard roller set is included. He can turn used different profiles The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

sheet width: 2100 mm plate thickness: 13 mm pre-bending: 10 mm upper roll diameter: 230 mm lower roll diameter: 210 mm side roll diameter: 190 mm total power requirement: 7,5 kW weight of the machine ca.: 4.620 kg dimensions of the machine ca.: 4150x1400x1300 mm Accessories / equipment: - Conical bending device - induction hardened rolls - digital display for side rollers - Machine made of steel construction - Separate control panel - two speeds - all rollers on ball bearings - Folding and support bearing from the top roller is actuated from the control panel. When the folding bearing is opened, the roller moves automatically upwards. - Conical adjustment of the rollers via control panel - Central rollers are via hydraulic motor and rotary reduction gear driven. (Top and bottom rollers) - Calibration The data for this ad was created with ModulMWS - the software solution of LogoTech oHG ...

: 80 mm roll diameter: 260 mm : 7 U/min : 170 mm : 27 kN : 160 mm : 450 mm total power requirement: 3,7 kW dimensions: 980x1430x1600 mm weight: 1380 kg Accessories / equipment: - Three driven rollers with a smooth surface - Hydraulic delivery of the upper roller - Working position horizontal and vertical - Digital display with memory function - Bearings with tapered roller bearings - Use of replaceable slide rails on the guide carriage - The standard roller set is included. He can bend different profiles are used e.g. Flat iron, T-iron, solid material etc. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
