plano milling used for sale

Stored in working condition. The buyer must provide his own transport. Elevator available to charge it. Auction-ID: A3-43519-17032

Serial number: 36434 Operating voltage: 380 - 415 V Connection: 1.5 kW Speed: up to 1400 rpm Rated current: 5.7 A Speed: from 70 to 2590 rpm Drilling depth: up to 170 mm Table dimensions: 650 x 270 mm with three grooves incl. three-axis digital display from the manufacturer HEIDENHAIN also an attached vice, jaw width: 85 mm and a matching dividing head Auction-ID: A7-46287-93

Table dimensions: 630 x 150 mm incl. clamped vice, jaw width: approx. 110 mm Auction-ID: A7-46287-29

Includes: (1x) Gedore tool trolley, Adjutant 1580. Auction-ID: A1-45979-106

Machine hours reading approx. 80,276 hours, spindle hours reading approx. 23,414 hours. Equipped with: 5-axis milling head type VH30 with A- and C-axis (A-axis ±110°, C-axis 360°), suitable for simultaneous 5-axis milling. Equipped with high-frequency spindle with HSK 63A mount, max. speed 22,000 min⁻¹, power 60 kW (constant from approx. 6000 min⁻¹) and max. torque approx. 95 Nm. Automatic tool changer KTC Handlingstechnik, type: ATC 60/HSK-A63 (60 positions) with carousel magazine. Includes chip evacuation and peripherals consisting of: (1x) KÜMA refrigerant/filter system type KF1/515WB, (1x) KÜMA filter unit type BF Gr.3, (1x) KÜMA pump unit type FA10/03, (1x) H.I.B Systemtechnik industrial chiller type RKH/W-14300 (R134a), (1x) LTA Industrial Air Cleaning oil mist extraction type AC 2000 H Solid. Suitable for high-speed processing of aluminum and composite, amon ...

Heavy-duty Korean-built machine, suitable for demanding metalworking operations and machining of large workpieces. Equipped with an adjustable spindle enabling angular machining, with an angle table mounted on the machine. Technical data: • Model: KMB-U3 • Year of manufacture: 1997 • Country of origin: South Korea (Kiheung Machinery Co., Ltd.) Table size: • 1700 x 470 mm T-slots: • 5 x 20 mm • spacing: 80 mm Max. table load: • approx. 1500 kg Spindle taper: • NT50 Max. spindle speed: • 1720 rpm Feed rate: • X/Y: 2000 mm/min • Z: 1000 mm/min Auction-ID: A7-46285-4

Serial number: 100451 Clamping surface: approx. 400 x 120 mm with hand lever operation Auction-ID: A7-46287-200

Portable end mill sharpener is accurate and rapid, easy operation with no skill to grind. Can grind 2-flute, 3-flute, 4-flute end mill. With diamond grinding wheel, it can be equipped directly with an accurate angle and long service life. Standard with SDC grinding wheel for the Carbide material. Grinding Range:Φ4-Φ14, Point Angle:0°~5°, Power:220V, Motor:160W, Speed:4400rpm, Standard Equipment:Grinding wheel:SDC (for carbide material)×1, Six collets:Φ4,Φ6,Φ8,Φ10,Φ12,Φ14 Machine condition: unchecked. Approx. Transport dimension: LxWxH 350 x 250 x 250 mm; Approx. Weight: 15kg The item for sale may not be the one shown in pictures, but will have equal specifications and performance. Auction-ID: A7-45991-37

Serial number: 4432 Operating voltage: 380 V Frequency: 50 Hz Rated current: 13 A Speed: from 40 to 2000 rpm Tool holder: SK 40 Feed range infinitely adjustable: 5 - 500 mm/min Creep traverse: 4 mm/min Rapid traverse: 1200 mm/min Table Longitudinal movement: 300 mm Spindle block Transverse movement by hand: 160 mm Support Vertical movement motorized: 280 mm by hand: 290 mm without protective bar: 330/340 mm Vertical milling head on spindle block can be moved by hand: 100 mm Table dimensions: 600 x 210 mm with 4 grooves and an attached vice, jaw width: 160 mm Auction-ID: A7-46287-78

Batch of cutting tools, cutters, inserts and measuring components, various brands including Seco and Renishaw. Auction-ID: A1-45979-39

Auction-ID: A1-45979-101

Serial number: 100135 Power: 1.1 kW Max. spanwidth: approx. 250 mm Auction-ID: A7-46287-191

CONTROLS    HEIDENHAIN TNC 128 WORKING RANGE -CUBIC-   X-axis travel: 610 mm   Y-axis travel: 400 mm   Z-axis travel: 450 mm TABLE   table surface (left-right): 800 mm   table surface (front-back): 425 mm   workpiece load (max): 300 kg SPINDLE / HEAD   spindle revolutions (max): 4500 /min   tool fixture: ISO SK 40 AXIS DRIVES   traverse velocity X (max): 2000 mm/min   traverse velocity Y (max): 2000 mm/min   traverse velocity Z (max): 2000 mm/min   rapid traverse X: 5000 mm/min   rapid traverse Y: 5000 mm/min   rapid traverse Z: 4000 mm/min DIMENSIONS / WEIGHTS   space requirements -left/right-: 1800 mm   space requirements -front/back-: 1800 mm   total height: 2000 mm   total weight approx.: 2300 k ...

A CNC 3-axis milling machine Emco is available. Travel X/Y/Z: 900mm/500mm/500mm, table dimensions X/Y: 1000mm/520mm, max. table load: 800kg, speed: 10000rpm, spindle power: 11kW, tool holder: SK40, rapid traverse: 24m/min. Machine dimensions X/Y/Z: approx. 2600mm/2450mm/2950mm, weight: approx. 4800kg, control: Siemens Sinumerik 828D. Documentation available. An on-site inspection is possible.

MAZAK MTV 414 CNC vertical machining center was built in 1992 in the United Kingdom by YAMAZAKI MACHINERY UK LTD. The offered machine is an excellent choice for machining workpieces with a maximum weight of 500 kg. Thanks to its reliable components and extremely rigid design, the MAZAK MTV 414 guarantees the best machining results throughout its service life. The machining process is performed inside a large work area with a work table with a length of 900 mm and a width of 410 mm, a spindle and a capacious tool magazine. The spindle, driven by a powerful motor, rotates at a maximum speed of 7000 rpm and operates in three X,Y,Z axes with feeds of 560 mm, 410 mm and 460 mm respectively. All cutting tools are stored in a 24-position tool magazine with an automatic tool changing system (ATC). All this is complemented by the intelligent MAZATROL M32B CNC controller with its intuitive interfa ...

Carousel milling machine Comec FGS-1T Number of generators 1 Unit system: milling unit Pneumatic material central clamp Motor power 11kw Rotational speed adjustable by variator Net price

Main spindle with drive motor, universal milling head, milling chuck, milling extension, angle milling head, top slide, top slide, dovetail guide, tool slide, cross table -Manufacturer: Mikron, upper tool slide from Mikron VC500D CNC milling machine -Motor: INNDRAMAT 165V 5.5 kW see photo type plate 100C-B050B1-AS03 -Speed: 1500/8000 rpm -Spindle head: SK40 mount -Dimensions: 910/1120/H510 mm -Weight: 365 kg

Key data: 500 mm, 400 mm, 400 mm

Universal Milling & Drilling Machine DECKEL MAHO DMU 50 M With control Heidenhain TNC 310 Year of Make: 2001 Travel: X 500 Y 400 Z 400 Speed range: 20 – 4,500 rpm infinitely variable With the following accessories: Manual swivel – rotary table with digital display for C + B axis 700 mm x 500 mm clamping surface Electronic handwheel for X, Y, Z axis Splash guard cabin Machine Light 4 Height Adjustable Machine Shoes Coolant Setup Operating instructions

Technical Specifications Longitudinal stroke: 4000 mm Vertical travel: 1250 mm Ram stroke: 1000 mm Fast feeds: L-T-V 16 - 15 - 15 m/min Table dimensions: 5000 x 1000 mm Table height from floor level: 1100 mm Maximum spindle speed: 3000 rpm; 28 kW; ISO 50 Head: Manual Bi-rotary Random tool magazine: 20 positions Control: SELCA S3045 Range Change: 2 Speed Accessories: Remote handwheel ; Chip evacuator Notes: Head on TUH 10LT ram Item sold in unverified status Auction-ID: A1-44614-4

Auction-ID: A7-46327-40

This 3-axis Auerbach FBE 3000 Bed Type Milling Machine was manufactured in 2011. It features a robust clamping surface of 3100 x 800 mm, capable of handling a maximum table load of 10,000 kg. The machine is equipped with a multi-position milling head KFM 1, a tool holder SK 50, and offers a spindle power of 25 kW with speeds up to 4000 rpm. If you are looking to get high-quality milling capabilities, consider the Auerbach FBE 3000 machine we have for sale. Contact us for more information.

Automatische roterende freeskop: 90° en 45° Automatische gereedschapswisselaar met 30 posities spanentransporteur koelunit + filter maximaal werkstukgewicht 6 ton Longitudinal travel X-axe: 1700 mm Cross travel Y-axe: 1200 mm Travel Z-axe: 1000 mm Dimensions clamping space- table: 2000 x 1000 mm Max height workpiece: 934 mm Power on spindle: 22 kW Admission in millinghead (ISO): BT50 Max speedrange: 35 > 3000 rpm Control: Heidenhain Power needed (KVA): 56 kVa Length : 5300 mm Depth: 4950 mm Height: 2800 mm Weight: 18 ton

Gromatic X6130 milling machine; in original condition with power supply and rapid traverse on all 3 axes; suitable for precise metalworking; Voltage: 380 volts ; Speed: 30–1200 rpm ; Table size: 1120 x 300 mm ; T-slot: 14 mm ; Auction-ID: A1-45170-26

40-fold tool changer, Internally cooled spindle 10,000 rpm, Bluhm Tool and Parts Measurement, glass scales, Including CAM program Auction-ID: A1-46315-1

DETA Simplex milling machine ; Original condition with power supply and rapidity on all 3 axes; suitable for precise metalworking; Voltage: 380 volts ; Speed: 30–1190 rpm ; Table size: 1300 x 300 mm ; Recording: ISO 30 ; Cooling pump: yes ; Auction-ID: A1-45170-25

CONTROLS   CNC controls FANUC 31I MODEL A BASIC FUNCTIONS   number of spindles: 2   number of turrets: 3   live positions: yes   number of c-axes: 3   number of y-axes: 3 WORKING RANGE TURNING   turning diameter (max): 170 mm   bar diameter (max): 45 mm   worpiece length max.: 588 mm MAIN SPINDLE   spindle revolutions (max): 6000 /min   spindle bore diameter: 42 mm   spindle positioning: 0.001 °   c-axis: yes COUNTER SPINDLE   spindle revolutions (max): 6000 /min   spindle positioning: 0.001 °   c-axis: yes ELECTRICAL SPECIFICATIONS   mains voltage: 400 V   mains frequency: 50 Hz DIMENSIONS / WEIGHTS   space requirements -left/right-: 3400 mm   space requirements -front/back ...

CONTROLS   CNC controls FANUC 16 ITB BASIC FUNCTIONS   design principle: inclined bed   number of spindles: 2   number of turrets: 3   live positions: yes   number of c-axes: 2   number of y-axes: 2 WORKING RANGE TURNING   bar diameter (max): 50 mm MAIN SPINDLE   spindle revolutions (max): 4000 /min   drive power S1 100%: 18.5 kW   spindle bore diameter: 50 mm   c-axis: yes COUNTER SPINDLE   spindle revolutions (max): 5000 /min   drive power S1 100%: 11 kW   c-axis: yes X/Z SLIDE   tool fixture: Turret   - rotation speeds (max): 6000 /min ELECTRICAL SPECIFICATIONS   mains voltage: 400 V   mains frequency: 50 Hz DIMENSIONS / WEIGHTS   total weight approx.: 10000 kg ATTACHMENTS (TURNING ...

HERMLE UWF 802 M universal milling machine with HS 401 route control -HS 401- Track control -Travel X / Y / Z 500x430x400mm -Rigid angle table -Speed range 18-3550 rpm -Feed continuously variable in all three axes 0-1600 mm/min -Rapid traverses 0-1.6 m/min in all three axes -Vertical - Horizontal milling device -Tool holder ISO 40 -Hydraulic tool clamping -Central lubrication -Chip tray -Drive power 6 KW -Work light -Spindle protection -Documentation Dimensions LxWxH 1.9x1.8x1.9 meters / Weight: 1800Kg

Tool milling machine Deckel FP 2 / 3-axis digital display Heidenhain ND 780 -Travel paths X/Y/Z: 450 x 200 x 400 mm -Table clamping surface 700 x 350/tilt-swivel rotary table -Speed range: 40–2000 rpm -Feeds & rapid traverses in all three axes -Tool holder: ISO 40 -Vertical/horizontal milling device with vertical sliding head -Coolant device -3-axis digital display: Heidenhain ND 780 -Documentation -Chip tray -Various tool holders -Collets Dimensions: LxW xH 1.5x1.7x1.8 meters / Weight 1600Kg

Macmon M100 Universal Milling Machine with Vertical Head -Milling spindle -Number of spindle speeds: 16 -Spindle speeds: 40, 63, 80, 100, 125, 160, 200, 250, 320, 400, 500, 630, 800, 1000, 1250, 2000 rpm -Spindle Inner Taper: ISO 40 -Collet bore up to: 25 mm Ø -Spindle block -Spindle block displacement by hand: 170 mm -Vertical milling table -Size of the clamping surface: 640 × 195 mm -2 T-slots, width/spacing: 12 / 90 mm -Longitudinal movement automatic/manual: 290 / 310 mm -Vertical movement automatic/manual: 310 / 340 mm -Feed gearbox -Number of feeds: 16 - Feed size (mm/min): 9, 14, 18, 22.4, 28, 35.5, 45, 56, 71, 90, 112, 140, 180, 224, 280, 450 -Motion spindles -Longitudinal movement of the table (1 turn): 5 mm -Vertical movement of the table (1 turn): 2.5 mm -Spindle block movement (1 turn): 2 mm -1 graduation line (longitudinal and vertical): 0.02 mm -1 G ...

Macmon M100 Universal Milling Machine with Horizontal Head -Milling spindle -Number of spindle speeds: 16 -Spindle speeds: 40, 63, 80, 100, 125, 160, 200, 250, 320, 400, 500, 630, 800, 1000, 1250, 2000 rpm -Spindle Inner Taper: ISO 40 -Collet bore up to: 25 mm Ø -Spindle block -Spindle block displacement by hand: 170 mm -Vertical milling table -Size of the clamping surface: 640 × 195 mm -2 T-slots, width/spacing: 12 / 90 mm -Longitudinal movement automatic/manual: 290 / 310 mm -Vertical movement automatic/manual: 310 / 340 mm -Feed gearbox -Number of feeds: 16 - Feed size (mm/min): 9, 14, 18, 22.4, 28, 35.5, 45, 56, 71, 90, 112, 140, 180, 224, 280, 450 -Motion spindles -Longitudinal movement of the table (1 turn): 5 mm -Vertical movement of the table (1 turn): 2.5 mm -Spindle block movement (1 turn): 2 mm -1 graduation line (longitudinal and vertical): 0.02 mm -1 ...

turning diameter:120 mm turning length:100 mm control:Fanuc Spindle 1 power:7,5 kW Spindle 1 RPM:4500 1/min Spindle 2 power:7,5 kW Spindle 2 RPM:4500 1/min Distance between spindle noses:600 mm Turret No.1 stations / rotary tools:15/15 Power rotary tools turret 1:2,7 kW RPM of rotary tools turret 1:4000 1/min Turret No.2 stations / rotary tools:15/15 Power rotary tools turret 2:2,7 kW RPM of rotary tools turret 2:4000 1/min Travel x/z turret 1:250 / 300 mm Travel x/z turret 2:250 / 920 mm Bar capacity spindle 1:51 mm Bar capacity spindle 2:51 mm power chuck:165 mm Spindle bore sp. 1:62 mm Spindle bore sp. 2:62 mm dimensions of the machine ca.:3700 x 2300 x 3000 mm weight of the machine ca.:5600 kg Used CNC-2-spindle CNC turning and milling center with gantry loader - 2x 15 station turret -automatic gantry loader with turnaround station. 14 station-magazin right side Max. Parts size Ø 12 ...

turning diameter:356 mm turning length:705 mm control: CELOS M730 UM MAPPS swing dia.:742 mm standard turning diameter:275 mm travel -x axis:260 mm travel -y axis:100 ( ±50) mm travel -z axis:795 mm rapid travel - longitudinal/face:30 / 30 m/min Rapid travel B-axis (parts transfer subspindle):734 m/min Spindle 1 RPM:4000 1/min Spindle 1 Power:15/18,5/18,5 kW Spindle 1 Torque:409/505 /599 Nm Spindle 1 max. bar diameter:80 mm Spindle 2 RPM:4500 1/min Spindle 2 power:7,5/11 kW turret stations / rotary tool stations:20 / 20 BMT40 speed of driven tools:10000 1/min :3.7/5,5/5,5 kW torque rotary tools:14 / 24 Nm total power requirement:38 kVA weight of the machine ca.:6,3 t dimensions of the machine ca.:4 (9) x 2,1 x 2,2 m Parts catcher:Sp. 1 und Sp. 2 Spindle 1 Chuck:Kitagawa B 210 (250 mm) Spindle 2 Chuck:Kitagawa B 206 (160 mm) Tool presetter:Spindle 1 & 2 High precision Turning and Millin ...

turning diameter:370 mm turning length:200 mm Spindle 1 RPM:4000 1/min control:Siemens 840 D Spindle 2 RPM:4000 1/min power capacity:L / R 18/24 kW max. torque on the spindle:630 nM C-Axis:0,001° Turret No.1 stations / rotary tools:12/12 VDI 40 Turret No.2 stations / rotary tools:12/12 VDI 40 turning speed range - milling:3000 1/min power capacity - milling spindle:8,8 kW torque rotary tools:28 Nm Bar capacity spindle 1:85 mm total power requirement:65 kVA weight of the machine ca.:13 t dimensions of the machine ca.:5,7x2,4x2,1 m Travel x1:260 mm Travel x2:260 mm Travel Y1:600 mm Travel y2:600 mm Power Chuck:2 x 250 mm manual tool eye:l & r High performance 6-axis subspindle CNC-Lathe with twin turren and rotating tools.

turning diameter:65 mm turning length:120 mm control:Index C200-4D SL z-axis main spindle travel:390 mm z-axis subspindle travel:390 mm x-axis subspindle travel:600 mm Travel Y1:± 80 mm Travel y2:± 80 mm x-axis rapids:45 m/min y-axis rapids:15 m/min z-axis rapid travel:45 m/min Spindle 1 RPM:5000 1/min Spindle 1 Power:35,5/27,5 kW Spindle 1 Torque:170 /125 Nm Spindle 2 RPM:5000 1/min Spindle 2 power:35,5/27,5 kW Spindle 2 torque:170/125 Nm c-axis:0,00014 ° bar material dia.:65 mm spindle nose:AD 140 spindle bore:85 mm Milling spindle 1 RPM:18000 1/min Milling spindle 1 power:11 kW Milling Spindle1 torque:19 Nm Milling spindle 2 RPM:18000 1/min Milling Spindle 2 power:11 kW Milling spindle 2 torque:19 Nm B-axes swivel angle:230 ° B-axes torque:440 Nm B-axes angle resolution:0,001 ° Milling spindle 1 & 2 tool magazine:80 HSK A40 Milling spindle 2 tool magazine static tools :6 x VDI 25 ...

turning diameter:640 / 400 mm turning length:1500 mm control:Siemens 840 D Powerline Travel turret No.1 (milling spindle) x/y/z:550 / 180 (±90) / 1585 mm Swivle angle milling spindle (B-axis):±120° interpol. ° Rapid traverse feeds turret 1 (milling head) x/y/z:40/24/60 m/min RPM milling spindle:12000 1/min power capacity - milling spindle:12 / 23 kW Torque of milling spindle:100 Nm Tool magazine for milling spindle (turret 1):120 HSK-A 63 Tool change time tool/tool, milling spindle:1,6 s Spindle 1 RPM:4000 1/min Spindle 1 power:36/ 45 kW Spindle 1 Torque:730 Nm Spindle 1 max. bar diameter:90 Spindle 2 RPM:4000 1/min Spindle 2 power:36 / 45 kW Spindle 2 torque:730 Nm Spindle 2 max. bar diameter:90 c-axis:0,001 ° Travel turret 2 x:225 mm Travel Turret 2 z:1595 mm RPM of rotary tools turret 2:4000 1/min no. of tools in turret 2:12 VDI 40 high-pressure pump:20 bar total power requiremen ...

turning diameter:670 mm turning length:1540 mm control:F31iB5 Celos Fanuc 35iB5 swing diameter max. over bed cover:700 mm Travel turret No.1 (milling spindle) x/y/z:495 / ± 150 / 1562(+164) mm Rotation B-axis:-30° / +210° Rapid traverse feeds turret 1 (milling head) x/y/z:40/40/40 m/min RPM milling spindle:12000 1/min power capacity - milling spindle:20,2/18,8 kW Torque of milling spindle:120 / 44 Nm tool taper milling spindle:Coromant Capto C6 Tool magazine for milling spindle (turret 1):76 Tool change time tool/tool, milling spindle:1,25 s Spindle 1 RPM:3000 1/min Spindle 1 Power:36 / 30 / 25 kW C-axis spindle 1:0,001 ° Bar capacity spindle 1:102 mm Spindle 2 RPM:4000 1/min Spindle 2 power:26 / 22 / 15 kW C-axis spindle 2:0,001 ° Bar capacity spindle 2:80 mm dimensions of the machine ca.:7,8 x 3,6 x 2,9 m Linear scales on axis:X, Y programmable steady:KLU-A530 & SLU-X3.2 Spindle 1 ...

turning diameter:500 mm turning length:1000 mm control:Siemens 840 D spindle:42 / 28 kW spindle turning speed - stepless:31 - 4000 1/min max. torque on the spindle:345 Nm c-axis:360000 x 0,001° feeds -stepless-:0 - 10000 mm/min rapid traverse:10000 mm/min turret stations / rotary tool stations:12/12 VDI 40 RPM of rotary tools:2000 1/min diameter of quill:90 mm quill stroke:80 mm tailstock quill taper ISO:SK 30 Tailstock Travel:600 mm Power rotary tools:3,5 kW :22,5 Nm Rotary tool holders:4 ax./ 4 rad. spindle passage:66 mm total power requirement:30 kW weight of the machine ca.:7,5 t dimensions of the machine ca.:8x 3 x 4 m

turning diameter:356 mm turning length:705 mm control:MSX 850 MAPPS II swing dia.:755 mm standard turning diameter:275 mm travel -x axis:260 mm travel -y axis:100 (+-50) mm travel -z axis:795 mm rapid travel - longitudinal/face:30 / 30 m/min rapid traverse Y-axis:10 m/min Rapid travel B-axis (parts transfer subspindle):30 m/min Spindle 1 RPM:4000 1/min Spindle 1 Power:18,5/18,5/15 kW Spindle 1 max. bar diameter:80 mm Spindle 2 RPM:6000 1/min Spindle 2 power:11 / 7,5 kW turret stations / rotary tool stations:16 / 16 VDI 30 :5.5/5,5/3,7 kW speed of driven tools:6000 1/min total power requirement:39,2 kVA weight of the machine ca.:6,2 t dimensions of the machine ca.:3,1 x 2,0 x 2,2 m Spindle 1 Chuck:Kitagawa B 210 (250 mm) Spindle 2 Chuck:Kitagawa B 206 (160 mm) High precision Turning and Milling Centre with Y-axis and sub spindle. Easy programming by MAPPS II Control.

x-travel:14000 mm y-travel:3100 mm z-travel:1.200 mm (220 - 1.420) mm distance between columns:4.417 mm table-size:14.000 x 2.500 mm workpiece weight:15.000 kg/m drive capacity - spindle motor:25 kW spindle cone:63 HSK spindle turning speed range:18000 rpm milling feeds:30000 mm/min dimensions of the machine ca.:15.000 x 8.418 x 6.033 mm weight of the machine ca.:135 t CNC controller: SIEMENS 840 D universal milling head:5 Achsen mit ?C5C? Elektrospindel automatic tool changer:24 fach

x-travel:2000 mm y-travel:800 mm z-travel:800 mm table-size:2.000 x 700 mm workpiece weight:3500 kg drive capacity - spindle motor:17 kW spindle cone:50 ISO spindle turning speed range:3000 U/min dimensions of the machine ca.:5265 x 3250 x 2730 m weight of the machine ca.:9 t CNC controller:HEIDENHAIN TNC-426 :manuell used universal bed type milling machine with chip conveyor, automatic 2 position (vertical/horizontal) head 3000Rpm The retrofitting jobs done in this machine, are the same than those done to all of our machines. - Completely repair of the head, replacing bearings, shafts and engaging gears. - Completely replacement of all the bearings of the machine. - Replacing the joining screws of the bodies. - Completely repair of spindles. - Adjustment and repair of axis. - Grinding and adjusting all guides, because of deterioration. - Grinding and adjusting of the guide ways of the ...

x-travel:600 mm y-travel:580 mm z-travel:530 mm distance spindle center to column:630 mm distance spindle center to table:100-600 mm milling feed range:1-10.000 mm/min max. table load:200/100 kg max. tool weight:8 kg positioning accuracy:+/- 0,01 mm :8000/15000 1/min spindle drive:7,5/11,5 /5,5 kW repeating accuracy:+/- 0,008 mm weight of the machine ca.:7,4 / 7,65 t Brand-new CNC vertical machining center with CNC control FANUC or HEIDENHAIN Warranty: 12 months More information can be found in the Appendix.

x-travel:1000 mm y-travel:1150 mm z-travel:700 mm table-size:900 mm table load:1500 kg spindle speeds:10.000 1/min spindle drive:Motorspindel von Cytec CS34-180-A 34&42KW/160&200 Nm spindle taper:A100 HSK T-slots:18mm/7/100 mm milling feed range:20.000 mm/min rapid traverse feeds:X/Y/Z: 24 m/min diameter of tools max.:150 mm workpiece length:300 mm weight of tools max.:20 kg weight of the machine ca.:15 t dimensions of the machine ca.:s. Katalog m CNC controller:Heidenhain iTNC-640 HSCI-Steuerung cnc rotary table:von Cytec; mit Ø900mm; 800 1/min Drehmomenttisch (AS3347) + HSK-T63/100 Spindel & ATC + TNC-640 Fräsdrehzahlregelung B-axis:Fräskopf, 0-180° c-axis:0,001° automatic tool changer:HSK-A/T100; 60 fach Scales:in X/Y/Z von Heidenhain mit Druckluft inner coolant:20

x-travel:6000 mm y-travel:2100 mm z-travel:1500 mm Controls:HEIDENHAIN iTNC 530 BASIC DESIGN:. - basic design : travelling column :. WORKING RANGE -MILLING-:. - x-axis travel:6000 mm - y-axis travel:2100 mm - z-axis travel:1500 mm FLOOR PLATE:. - clamping surface (left-right):7000 mm - clamping surface (front-back):2000 mm WORKING SPINDLE / HEAD:. - spindle type : orthogonal head :. - tilting range:360 ° - - mode of operation : automatic :. - - positioning/indexing:1 ° - tilting range (2nd axis):270 ° - - mode of operation : automatic :. - - positioning/indexing:1 ° - spindle revolutions (min):20 /min - spindle revolutions (max):4000 /min - spindle diameter:90 mm - taper fixture : ISO SK 50 :. - spindle power (continuous):32 kW - torque (max.):910 Nm AXIS DRIVES:. - feed velocity (min):2 mm/min - feed velocity (max):20000 mm/min - rapid traverse:25000 mm/min ELE ...

rotor dia:30-500 mm hobbing length:500-1000 mm total power requirement:80 kW weight of the machine ca.:15 t dimensions of the machine ca.:3,6 x 2,5 x 3,0 m max. module:8 Max. module Et milling = 12 Max. module hobbing = 12 Max. axial travel = 110 to 1100mm Max. cutter speed = 300rpm Max. cutter displacement tangential = -350 to -55mm Max. table speed = 100rpm Table drive: torque motor Filter system: chip conveyor is for magnetic materials, belt filter is for all suspended matter that floats in the oil Including milling mandrel

turning diameter:270 mm turning length:710 mm weight of the machine ca.:6,5 t max. swing diameter:590 mm with automatic loading and unloading system G300 with "spindle bore clamping capacity 90mm" in tailstock version The machine has no driven tools. The information in the circuit diagram refers to the rotary drive for indexing the turret, not to driven tools.

turning diameter:270 mm turning length:710 mm weight of the machine ca.:6,5 t max. swing diameter:590 mm with automatic loading and unloading system G300 with "spindle bore clamping capacity 90mm" in tailstock version Chip conveyor, belt filter press, hydraulic unit, as well as infeed and outfeed chain conveyor EWAP, with 33 pallets. The machine has no driven tools. The information in the circuit diagram refers to the rotary drive for indexing the turret, not to driven tools.

turning diameter:270 mm turning length:710 mm weight of the machine ca.:6,5 t max. swing diameter:590 mm with automatic loading and unloading system, chip conveyor G300 with "spindle bore clamping capacity 90mm" in tailstock version The machine has no driven tools. The information in the circuit diagram refers to the rotary drive for indexing the turret, not to driven tools.

turning diameter:120 mm turning length:650 mm weight of the machine ca.:11 t dimensions of the machine ca.:5,032 x 3,048 x 2,445 m Gildemeister MF Twin 65-II lathe with loading automation. This machine is suitable as a counter spindle machine for 4-axis machining on the main and counter spindles, complete machining (turning, drilling, milling, Y-axis, B-axis) of bar and shaft parts.

turning diameter:120 mm turning length:650 mm weight of the machine ca.:11 t dimensions of the machine ca.:5,032 x 3,048 x 2,445 m Gildemeister MF Twin 65-II lathe with loading automation. This machine is suitable as a counter spindle machine for 4-axis machining on the main and counter spindles, complete machining (turning, drilling, milling, Y-axis, B-axis) of bar and shaft parts.
