Code: 0037 Brand: ALTENDORF Model: F 45 - CE Standard Panel saw with tilting blade and scoring unit for furniture, custom-made furniture, panels, doors, window frames, plastics, aluminium, plexiglass, composites and various materials - CE Standard Technical data: Double roller carriage length mm 3000 Electromotorised adjustment of height and inclination of blade unit with automatic correction of cutting height during inclination Input of values via keyboard (CNC control) Digital display of cutting height Digital display of blade inclination Digital display of blade revolution Continuous micrometric adjustment Machine diagnostics with symbol display Max blade diameter mm 500 F 30 Blade motor Hp 5,5 Max cutting height mm 175 Max cutting height at 45° mm 123 Independent scoring unit Register for square cuts Digital display of parallel register cutting width (DIGIT ...
Cutting length mm: 4500. Cutting depth mm: 4500 Number of pliers: 7 Installed power KW: 15 Diameter saw blade mm: 300 Vorritzer: Yes Discharge tables pneumatic: 3 Weight Kg: 3100 CE marking
Vertical panel saw with pliers Cutting length 5200 mm Cutting height 2200 mm cutting depth 70 mm Saw blade diameter 300 mm Scoring unit incl. adjustable Automatic sliding erost
Cutting length: 4300 mmCutting height: 2150 mmautomatic: , ELCON precision panel saw type D 215-----------------------------------------------------Cutting height: vertical 2,150mm, horizontal 2,100mmCutting length: 4,300mm-----------------------------------------------------Technical description:Cutting depth: max. 60mmSaw blade outlet behind the plate: max. 25mmSaw blade: diameter 250mm, bore 30mm, Z=48 hollow roof toothSaw blade rotation: 5,100 rpm.Motor: 4 kW (S 6)Measurement reading for:horizontal saw cuts: via scale and strip cutting stopvertical saw cuts: above scaleExtraction nozzle: 100 & 80mmRequired air pressure: 6 barFeatures:-Material support with 1 roll per meter of cutting length, switched on and off by foot pedalsuspendable-1 infeed and outfeed roller-pneumatically yielding slatted frame-Central support, 1 support element per meter of cutting length, individually manually ...
Code: 0420 Brand: GMC Model: KGS 400 E - CE Standard Manual vertical panel saw for cutting wood panels, blockboard, coated panels, plastic materials, aluminium, non-ferrous metals, various materials, sandwich panels, polycarbonate, compocel, pet foam, polypropylene, etc. - CE Standard Technical data: Cutting length mm 4200 Cutting height mm 1900 Maximum cutting thickness mm 50 Blade diameter mm 250 F 20 Motor power Hp 4 (Kw 3) Support for small pieces Moving frame Support rollers for the sliding of boards Overall dimensions of assembled machine: mm 5300 x 1400 x 2830 h Overall dimensions for transport : Frame mm 5020 x 450 x 2250 h - Beam mm 2800 x 850 x 850 h Weight kg 500
SPECIFICATIONS: Working area mm: 4500 x 2200 Saw blade diameter mm: 250 Power KW: 3.0
I sell a vertical panel saw standing with vorritzer GMC KGS400E, built in 2007, as good as new. Cutting surface 4500x2100mm Engine 3kW. Sawing unit swivel 0-90° Main saw blade diameter 240-250mm / 5200rpm. With vorritzer 104-110 x 20mm / 7000rpm. Manual cutting. Weight 665kg. Condition as new. Available the same.
cutting length 5200mm height 2200mm motor power 4kW pneumatic adjustment of the aggregate cutting in the machine feed speed 5-25m/min saw rotation 4500 rpm year of manufacture 2000
Cutting length: 4300 mmCutting height: 2200 mmThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
KW saw unit 4.6 Length 5300 mm Cutting height 2100 mm Cut depth 80 mm Overall machine height 2900 mm Strip stop Weight approx. 700 kg Saw blade ø 300 mm Folding bar
Cutting area 5300 x 2200 mm, 4 KW, sheet of 300. Sales on behalf of customers
Cutting area 3200 x 2070 mm, three middle runs pneum. selectable digital dimension recognition, tension pneum., manual saw feed. Was manufactured in IMA training workshop. Sales on behalf of customers.
Code: 0031 Brand: MAGIC Model: MSW Panel saw with tilting blade and scoring unit for furniture, finished panels, panels in general, plastic materials, aluminium, sandwich panels, plexiglass, composite materials and various materials Technical data: Aluminium carriage mm 3200 Scoring unit diameter mm 125 Blade motor Hp 5,5 Scoring unit motor Hp 0,75 Parallel guide mm 1200 Max blade diameter mm 400 Overall dimensions mm 3200 x 1200 x 1100 h Weight kg 800
Panel saw PANHANS Gematec PAS 3201 Cutting length maximum 3200 mm Cutting width 2850 mm Cutting height maximum 60 mm The machine can be used to cut sawn timber Machine already available in stock
I sell a panel dividing saw Paoloni Fimal Concept 350. Built in 2016. Cutting length 3200mm. Cutting height 95mm. Saw blade swivel 0-45° Main motor 5,5kW MOTEK Combined area W.4000mm x D.3000mm 3 pcs. Parallel posizionaire with double posizion regulazion for short or wide dimensions. 2 pcs. Posozionary manual on the additional rear stop 2 pcs posozionary left manual with digital display 2 posozionary on the angular stop Very good condition. Available the same. Incl. full documentation and CE certificate.
PUTSCH panel saw Product Name: Putsch Panel Saw Type: SVP 420 M Machine number: S-420-10.420.013 Condition : New device Technical details: • max. cutting length: 4,200 mm • max. cutting height: 2,200 mm • highest horizontal cut: 2,080 mm • max. cutting depth: 60 mm • Connection for suction: 100 mm diameter • Engine power: 5 hp/3.75 kW • Saw blade speed: 5,300 rpm • Saw blade diameter: 250 mm • Dimensions: L x W x H = 5,750 x 1,400 x 3,150 mm • Weight: approx. 1,000 kg Transport dimensions: L x W x H 1st box 1,150 x 3,100 x 1,200 mm 2nd box 5,300 x 150 x 235 mm Number of packaging units: 2 • the model series 420 is particularly suitable for continuous use in confined spaces • electr. driven, automatic shifterost • swung away center support f ...
SPECIFICATIONS: Workspace: Horizontal cutting length mm: 6000 Vertical cutting height mm: 2200 Workpiece height mm: 78 Saw blade diameter mm: 300
Inv. Num. : 5713 Type: FW 430 Producer: Schelling Created: 1992 Parameters: Saw blade diameter: 400 mm Cutting length: 4300 mm Cutting width: 4300 mm Cutting height: 100 mm Retraction speed: 0-40 m/min Engine power: 1 5-11 kW Space requirement: 6950x7485 mm
Code: 0495 Brand: SCM Model: ALFA 32/C Automatic horizontal panel saw with electronic programming and clamps for cutting wood panels, plywood, furniture, composite materials, sandwich panels, and various materials Technical data: Cutting length mm 3220 Cutting depth mm 3000 Max cutting height mm 90 Main blade diameter mm 350 F 80 Scoring unit diameter mm 160 F 55 Main blade motor power Hp 10 Scoring unit motor power Hp 2 Blade advancement speed mt/min 13,5 - 27 Pusher fast feeding speed mt/min 6 Pusher slow feed speed mt/min 0,2 Pusher return speed mt/min 6 Blade rotation speed 3800 rpm Scoring unit rotation speed 5800 rpm Electronic pusher with n° 6 pneumatic clamps for workpiece clamping Automatic side alignment device N° 3 Bakelite front tables mm 2500 N° 5 pneumatic stops for cross cuts Electronic programmer MASTER X-PLUS Diameter of suction mouths ...
working dimensions 3200x3200mm maximum disc diameter 350mm scoring diameter 160mm installed power 10kW cutting height 85mm 4 grippers
Cutting length 4500 mm Pliers slide depth 4500 mm Saw blade projection 95 mm Gate valve 1-60 m/min Motor 9 kw Scoring motor 0.75 KW/1PS Machine cuts in format4 sides
Code: N0004 Brand: SICAR Model: SEGA 315 - Norme CE Professional panel saw SEGA 315 with carriage 3200 mm , blade 315 and scoring unit with separate motor - CE Standard Three-phase main motor 7,5 hp. Parallel guide on round bar with cast iron support and micrometric adjustment, blade lifting and tilting by handwheels, tilting blade unit with integrated scoring unit, aluminium carriage sliding on ball bearings, fence on extendable frame with two reversible stops. TECHNICAL DATA: Main worktable mm 910x550 Additional worktable mm 910x760 Additional lateral worktable mm 500x550 Main blade speed rpm 4000 Scoringunit speed rpm 8000 Blade diameter mm 300x30 Scoring diameter mm 120x20 Cutting height at 45° mm 75 Cutting height at 90° mm 100 Max cutting distance between blade and scale mm 1250 Carriage dimensions mm 3200 Three-phase moto ...
- Welded, multi-strutted, Construction - Support rollers braked - Slatted frame with wooden pads - Powerful, low-vibration motor Cutting length horizontal mm : 5.300 Cutting length vertical mm : 2.200 Cutting depth mm : 80 Machine length mm : 6.300 Transport heightmin mm : 2.550 Diameter saw blade mm : 303 Space requirement LxH : 6300x2990 mm
Code: 0146 Brand: UNIVER Model: M/1 Manual vertical panel saw Length of cut mm 4000 Height of cut mm 2400 Blade diameter mm 250 Motor power Hp 1,9 Support device for small parts Rollers on the base Overall dimensions: mm 4100 x 700 x 3200 h Weight kg 600
Dimension of sliding table- 1600x375mm Gross cut capacity- 1500mm Width of cut between saw blade and rip fence - 1140mm Saw blade diameter - 400mm Height of cut (90°) - 115mm Height of cut (45°)- 105mm Speed of main saw spindle - 4500/6000rpm Main spindle diameter - 30mm Tilting saw blade - 0-45º Saws lifting, up and down, electrical control. Main motor - 5,5 kW Scoring saw blade diameter - 120mm Speed of scoring saw blade - 7000-8000rpm Scoring saw diameter - 20mm Scoring motor - 1,1 kW Weight: 650 kg Transport dimensions - 1800x1000x1200mm Using the blade 400mm, the smaller should be removed. Reduced saw blade should be used with not more than 350 mm main shield.
Dimension of sliding table- 2200x375mm Gross cut capacity- 1500mm Width of cut between saw blade and rip fence - 1140mm Saw blade diameter - 400mm Height of cut (90°) - 115mm Height of cut (45°)- 105mm Speed of main saw spindle - 4500/6000rpm Main spindle diameter - 30mm Tilting saw blade - 0-45º Saws lifting, up and down, electrical control. Main motor - 5,5 kW Scoring saw blade diameter - 120mm Speed of scoring saw blade - 7000-8000rpm Scoring saw diameter - 20mm Scoring motor - 1,1 kW Weight: 700 kg Using the blade 400mm, the smaller should be removed. Reduced saw blade should be used with not more than 350 mm main shield.
Best price 4150 Eur (EXW Jonava, Lithuania) Buying this machine, dust exhausting system HOLZMANN ABS 3880 only 320 Eur (EXW Jonava, Lithuania) or HOLZMANN ABS 2480 only 250 Eur (EXW Jonava, Lithuania) Dimension of sliding table- 2800x375mm Gross cut capacity- 2800mm Width of cut between saw blade and rip fence - 1140mm Saw blade diameter - 400mm Height of cut (90°) - 125mm Height of cut (45°) - 115mm Speed of main saw spindle - 4500/6000rpm Main spindle diameter - 30mm Tilting saw blade - 0-45º Main motor - 5,5 Kw Saws lifting, up and down, electrical control. Scoring saw blade diameter - 120mm Speed of scoring saw blade - 7000-8000rpm Scoring saw diameter - 20mm Scoring motor - 1,1 kW Transport dimensions - 2800x1000x1100mm Weight - 800 Kg
Best price 4500 Eur (EXW Jonava, Lithuania) Dimension of sliding table- 3200x375mm Gross cut capacity- 3200mm Width of cut between saw blade and rip fence - 1250mm Saw blade diameter - 400mm Height of cut (90°) - 125 mm Height of cut (45°) - 115 mm Speed of main saw spindle - 4500/6000rpm Main spindle diameter - 30mm Tilting saw blade - 0-45º Saws lifting, up and down, electrical control. Main motor - 5,5 Kw Scoring saw blade diameter - 120mm Speed of scoring saw blade - 7000-8000rpm Scoring saw diameter - 20mm Scoring motor - 1,1 kW Transport dimensions - 3200x1000x1100mm Weight - 850 Kg
Best price 4600 Eur (EXW Jonava, Lithuania) Buying this machine, dust exhausting system HOLZMANN ABS 3880 only 320 Eur (EXW Jonava, Lithuania) or HOLZMANN ABS 2480 only 250 Eur (EXW Jonava, Lithuania) Dimension of sliding table- 3800x375mm Gross cut capacity- 3800mm Width of cut between saw blade and rip fence - 1140mm Saw blade diameter - 400mm Height of cut (90°) - 125 mm Height of cut (45°) - 115mm Speed of main saw spindle - 4500/6000rpm Main spindle diameter - 30mm Tilting saw blade - 0-45º Main motor - 5,5 Kw Saws lifting, up and down, electrical control. Scoring saw blade diameter - 120mm Speed of scoring saw blade - 7000-8000rpm Scoring saw diameter - 20mm Scoring motor - 1,1 kW Transport dimensions - 3800x1000x1100mm Weight - 820 Kg
