opt used for sale

Electronic measuring and display system Weinig type OptiControl with PowerCom and PowerLock for Non-contact measurement of the tool dimensions radius (R) and height (H) using a projector with 20x magnification. By adding the profile data, the computer determines the corresponding setting values, which are sent online to the moulder be transferred. Consisting of: Weinig OptiControl PC with PowerCom software Junction box, Flight circle ø: 0 - 300 mm, tool length: 0-310mm

Optymalizerka Metal Technika OWD 1600 - produkcji Polskiej - rok produkcji 2017 PARAMETRY TECHNICZNE: - szerokość cięcia 250 mm - wysokość cięcia 120 mm - Wydajność Od 3 200 do 8 150 mb /8 h - stół sortujący z 5-ma wybijakami - Elektronika Sterownik z wyświetlaczem dotykowym kolorowym „MITSHUBISHI” - Funkcje - pełna optymalizacja 30 wymiarów w dwóch klasach jakości, - tworzenie programów cięcia dla różnych klientów, - ciecie w miejscu zaznaczenia kredką fluoroscencyjną, - obcinanie marginesu (początek i koniec materiału wejściowego) - cięcie pakietami (kilka elementów na raz) - liczniki metrów, total, zmiany, operatora, miesięczny, - dokładność cięcia ±0,2 mm - Silnik 5,5 KW (piła Ø500 – 140z) - Szerokość mat. wejściowego 12 - 250 mm max. szer/wys ( 250 / 50 mm) - Wysokość mat. wejściowego 12 - 120 mm max. wys/sze ...

A system for planing/splitting and optimizing wood for strips or other workpieces Consisting of: · Flat magazine Weinig EM 12 · Planer and splitting machine Weinig Unimat 23 SP · Cross conveyor belt · Optimization cross-cut saw Dimter OptiCut 150 with inlet and outlet, Technical specifications: tba

grinding length: 600 mm grinding width: 375 mm workpiece height: 375 mm magnetic table diameter: 600 x 350 mm Control: total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Optimization cross-cut saw Dimter type OptiCut 150 for full optimization with chalk line detection and inlet and outlet., Technical specifications: tba

This TOS Optima Horizontal Machining center was manufactured in the year 2005 in Czech Republic and has 83171 production hours, of which 36511 are spindle hours. It is equipped with a HEIDENHAIN iTNC 530 control unit and has 4 axis. The machine has a spindle speed of 6000 rpm.

Single-sided edge banding machine Brandt type OPTIMAT KDF 650 C edition Specifications: • Feed rate (m/min.): 8 - 18 • Feed max. with form milling machine (m/min.): 14 • Working height (mm): 950 • Pneumatic connection (bar): min. 6 • Overall length (mm): 6,060 Workpiece and edge parameters: • Workpiece width min. at workpiece thickness 8 - 22 mm: 70 mm (depending on workpiece length) • Workpiece width min. for workpiece thickness 23 - 40 mm: 120 mm (depending on workpiece length) • Workpiece width min. at workpiece thickness 41 - 60 mm: 150 mm (depending on workpiece length) • Workpiece protrusion (mm): 38 • Workpiece thickness (mm): 8 - 60 • Edge height max. = workpiece height (mm): + 6 • Edge Material Roll (mm): 0.4 - 3 • Max. edge cross-section for PVC: 135 mm² • Max. edge cross-section for veneer: 100 mm² • Roll diameter max. ( ...

Key data: 4200 mm, 1500 mm

Power Control PC85, Woodwop, ATC 12-speed, A lot of accessories, Gluing unit, ... 2 retractable and extendable changing tables, two-part clamping table with 2 processing stations for pendulum occupancy, edge height max. 65 mm, chip and remnant disposal, drill head 17 spindles, main spindle 14.5 KW, speed 24000 1/min Incl. many accessories Condition: dismantled

Meat grinder, make Mado, type Optima, built in 2014, Dimensions of filling bowl: L x W: 740 x 550 mm,, Electrical connection values: 5.6 kW,, power: Machine cycle: 15 - 40 seconds, Dimensions / weight: (WxLxH): 820 x 900 x 1070 mm, 227 kg

Description: Axis Configuration X-Axis: 3690 mm Y-Axis: 1730 mm Z-Axis: 300 mm Max Power Max Electro spindle power: 11/13 kW Max power installed: 20 kW Utilities Vacuum pump capacity: 90 m3/h Compressed air pressure: 0.6 kPa Compressed air consumption: 250 NI/1 Air connection coupling: Gas ½” Dust Extraction Dust extraction outlet: 200 Ø mm Extraction air consumption: 3200/3400 m3/h Extraction air speed: 28/30 m/s Control & Program Control: Genesis evolution runs on Windows system Machine Type 3-Axis CNC Machine Motor Type Horizontal Motor Processing Units Drilling Unit Groove Saw Tool Storage Tool Magazine Fixturing System Pods, Rails, and Clamps  , vacuum pump: 90 m³/h, total electrical load: 20 kW, x-motion: 3,690 mm, y-motion: 1,730 mm, z-motion: 300 mm, Approx. Onsite Dimension. (l x w x h): 3,700 x 1,300 x 2,000 mm, weight  ...

Electricity: Single phase 230v / 5kVa / fuse 25 A / wires 4 mm 50/60 hz The electricity consumption for an 8 hours shift is approximately 2500W x 8h = 20kWh. Cooling water: Since the cooling unit (stainless steel) is a closed water-circuit, there is no water consumption (after a one-time fill). Minimum pressure: 1 bar (15psi) Maximum pressure: 3 bar (45psi) Temperature: between 13°C and 18°C Quality: lime free and reusable Inlet Connection: inch Outlet Connection: inch Compressed Air: Typical consumption of compressed air is 200 Nm / h (120 cfm), with a maximum consumption of 450 Nm / h (300 cfm). Minimum pressure: 6 bar (90 psi) Maximum pressure: 10 bar (145 psi) Quality: iso 8573.1 air quality standard Connection: 1.5 inch

Description: Measuring ranges length 300 mm, diameter 0.2 to 50 mm Includes computer, screen, keyboard and mouse Program unknown Approx. Onsite Dimension. (l x w x h): 700 x 700 x 950 mm, weight approx.: 120 kg

Description: Homag Power Touch Control system large full HD multi-touch monitor in widescreen format, which is used to control machine functions by direct touch contact. Frequency-controlled main saw motor 13.5 kW Package for cutting thin boards  ,  ,  ,This option includes  ,  ,  ,Combi profile rails instead of top hat profile rails  ,  ,  ,4 additional roller rails  ,  ,  ,glide bars on the combi profile rails  ,  , Special run-off for laminate cuts Labeling package  , Labelling software  , Labelling with telegraphic  , Labelling printer Pica II 108 (Thermo-/Thermotransfer pressure) Increased blower output for the air cushion tables due to integrated frequency control Premium Package: Pressure beam height control Regulates the pressure beam´s opening according to the material´s thickness. Conduces m ...

Specifications: Workpiece length: min 200 mm Workpiece length: max 2500 mm Workpiece width: min 70 mm Workpiece width: max 850 mm Workpiece thickness: min 12 mm (for flat machining) min. 16 mm (for horizontal machining) max. 60 mm Workpiece weight: max. 30 kg Speed of axes: Vector speed X/Y = 30 m/min Z = 15 m/min Features: Workpiece Document Area Mechanical support by means of a roller conveyor for workpieces. Workpiece removal area Mechanical support by means of a roller conveyor for workpieces Drill Gear V8 Feed stroke Z-direction: 60 mm Drilling depth: max. 38 mm Direction of rotation: right/left Speed: 2800 1/min, frequency controlled Propulsion: 1.8 kW Drill bit holder: d = 10 mm for Quick-change system Total drill bit length: 70 mm Drill diameter: max. 35 mm Spindle spacing: 32 mm Spindle type: individually controllable power control PC85  ...

This is a tilting frying pan from the premium manufacturer MKN, type Optima 850 60 liters 3/1 GN with manual tilting. The device has undergone a major inspection in our in-house workshop and is fully functional. The tilting frying pan is completely unused and in top condition.The base version is without feet, but can be mounted on request. Our used equipment service for you: •6 months warranty on all electrical parts • High-quality branded appliances at fair prices • Professional Overhaul / Inspection & Professional Cleaning • Tested & fully functional - or money back •Shipping or self-collection can be flexibly selected • Expert advice - before and after the purchase • Provision of operating instructions, connection diagrams and spare parts •Testing according to DGUV V3 Specifications: •W x D x H: approx. 1100 x 850 x 700 mm •Power supply: V: 400 / ...

Description: HOLZMA HPP81/42-CAD Optimat Panel Saw M-No.: 0-240-06-3081 , ,  , , ,  , , ,  , , ,  , , ,  , Year of manufacture: 1999 , ,  , , ,  , , ,  , , ,  , , ,  , Control with Cadmatic Holzma CAD Matic 3 - Ethernet connection , ,  , , ,  , , ,  , , ,  , , ,  , Windows embedded , ,  , ,19' TFT screen , ,  , , ,  , , ,  , , ,  , , ,  , Total connected load: 20 KW, 38A , ,  , , ,  , , ,  , , ,  , , ,  , Cutting length 4.250 mm , ,  , , ,  , , ,  , , ,  , , ,  , Cutting width/depth: 4.300 mm , ,  , ...

Description: serial number: 0-201-06-0390 Technical specifications: 3 axes + axe 'C' vertical milling motor 7,5kW, HSK F63 drilling head with 11(X) + 6(Y) vertical spindles and 4 horizontal spindles (2 on X axis and 2 on Y axis) tools magazine HSK - 30 positions 8 bridges L=1340 mm, with 16 suction cups 4 pneumatical clamps for fixing narrow pieces 4 loading aids vacuum pump Becker 100 m³/h + vacuum pump 2BL2101 (80m³/h) working table: 4000 x 1300 mm axis travel: X=4900mm Y=1800mm Z=280mm waste disposal belt security belt in front of the machine (3 parts) perimetral protective fence total connection: 17 kW software: woodWOP NC control: power control PC85 CE mark without tools vacuum pump: 100 m³/h, serial number: 0-201-06-0390, toolchanger positions: 30, total electrical load: 17 kW, 5-axis machining: No, Number of vacuum pumps: 2 pieces, Integrated C-axis:  ...

Description: Type of work Drilling Routing X axis working area 4250 mm Y axis working area 1500 mm Working Table Pod and Rail Main Electrospindle power 11 KW Number of controlled axes 4 axes Total number of drilling spindles 25 Total number of tool changer positions 26 X axis work area 4250 mm X axis travel 5050 mm Y axis work area 1500 mm Y axis travel 2150 mm X axis movement speed 80 m/min Y axis movement speed 60 m/min Z axis movement speed 20 m/min No. working fields 2 Working table yes Working table Pod and Rail No. of Rails 10 Pod Position Indicators yes Vacuum pump yes No. pumps 2 Single capacity 100 m3/h Boring units 1 BORING UNITS 1 Unit : top Vertical Boring Spindles : 25 Router Spindles 1 ROUTER SPINDLES 1 Unit : top No. controlled axes : 4 Motor power : 11 kw r.p.m. : 24000 RPM Grooving unit 1 GROOVING UNIT 1 Unit : top Grooving unit : yes Unit : Fixed for Grooving in X Max.  ...

main motor: 13.5 kW, serial number: 0-240-06-3129, cutting length: 4,200 mm, cutting depth: 4,200 mm, cutting height: 75 mm, collets: 7 pieces, main saw blade: 380 mm, scoring saw blade: 200 mm, air table: 3, scoring saw: 2,20 kW, control: CADMATIC, total power approx: 17,50 kW, Approx. Onsite Dimension. (l x w x h): 7,000 x 8,500 x 2,000 mm, weight approx.: 6,000 kg

Description: • Horizontal panel saw with lifter table • Serial number 0-240-02-1525 • Total installed power approx. 24 KW • Cutting width 4300 mm • Saw blade projection 125 mm • Cutting height approx. 110 mm • 7 Grippers • Main saw blade: max. diameter 450 mm and motor 13.50 KW • Scoring saw blade: motor 2.20 KW • Saw carriage feed speed: 0 - 120 m/min • Saw carriage return speed: 120 m/min • Pushers maximum speed: 80 m/min • 4 front air tables with dimensions 2160 x 650 mm • Max. panel dimensions on platform approx. 4300 x 2200 mm • Max. height of panel stack on platform approx. 680 mm • Max. weight supported by the lifting table 7000 kg • CADMATIC control Approx. Onsite Dimension. (l x w x h): 12,600 x 7,000 x 2,100 mm, weight approx.: 12,000 kg

Description: Total processed length: 205,152 m Operating voltage 400 V Frequency 50 Hz Working width min. 10 mm (with tool diameter 125 mm) Workpiece width after processing min. 10 mm and max. 250 mm Working height min. 10 mm (for tool diameter 125 mm) Workpiece height after processing min. 10 mm and max. 160 mm Control: powerControl with Powertouch MOULDTEQ M-300 Feed: Feed system - 6 spindles Feed speed 24 m/min infinitely adjustable via powerTouch Feed speed min. 6 m/min and max. 24 m/min Maximum tool weight 22 kg with CE certificate and documentation without tools 1. spindle: 7.5 kW, 2. spindle: 7.5 kW, 3. spindle: 7.5 kW, 4. spindle: 7.5 kW, 5. spindle: 7.5 kW, 6. spindle: 7.5 kW, serial number: 0-254-11-2760, planing width: 250 mm, planing height: 160 mm, length of surfacing-table: 2,500 mm, number of spindles: 6 pieces, feed: 24 m/min, Approx. Onsite Dimension. (l x w x h): 4,800  ...

Description: Control voltage on: 35'849 h Main spindle BE1: 23749 h Boring head BE1: 3709 h Drill head: 17 spindles Main spindle: 18.5 kW controlled Chain changer 30-fold HSK F63 Speed range 0-18'000 rpm Drilling head 35 spindles vertical, for automatic changing into the main spindle Control system was converted in 2014: RECHNER IPC 5.11.0.0 WITH DVD, Industrial PC IPC 5.11 from Eltec with Windows XP operating system, hardware: Industrial PC Intel Core 2 Duo E8400 3.0 GHZ, working memory 4 GB RAM, 2 COM interfaces RS232, internal DVD-ROM drive, 1 fixed hard disk with 250 GB, 1 USB hard disk for data backup, 4 USB ports, Ethernet network connection with EC Declaration of Conformity Series no. 0-201-19-1527 without tools or units and without vacuum pump ( central vacuum system ) Translated with DeepL.com (free version) working width y-axis: 1,600 mm, working height z-axis: 950 mm, work ...

Description: Powerful CNC machining centre equipped with: 2 pcs. main spindles, each with C-axis one of them with Flex-5 interface, 2 x 11 kW - HSK 63 drilling unit with 25 drilling spindles and groove saw 0/90° 2 pcs. 10-fold tool changers 2 console-tables for pedular processing and 4-fold processing max length of workpiece 3740 mm, while pedular processing 1830 mm, while 4-fold processing 700 mm max width of workpiece 1600 mm for processing with milling tool diameter of 25 mm, 1300 mm for all aggregates stop pin for workpieces with overhang of top layer LED positioning system vacuum loader Homag TBP 370 Traverse length approx. 13 metres Installation height from floor 1300 mm with 8 vacuum cups (130 mm and 100 mm diameter) new vacuum pumps in 2023 for further technical details please have a look at the pdf file (German language) working width y-axis: 1,600 mm, working l ...

Description: Three axes, axis travel: X  ,- 3860 mm, Y - 1822 mm, Z1 - 325 mm, Z2 - 185 mm, Operating hours approx. 48'369, work table: X - 3250mm Y - 1250 mm, Z - 125 mm, automatic tool spindle in combination with tool change magazine, tool holder: HSK 63, rotation speed: 1250 - 24,000 rpm infinitely programmable, maximum power at the tool up to 7.5/9 KW, C - axis aggregate interface, automatic tool change magazine with 14 places maximum tool weight 5 kg without units, with CE certificate, Lista drawer cabinet, contents: dowel drills, milling cutters, collets, various tool holders, some with tools, Windows 10 operating system working width y-axis: 1,250 mm, working height z-axis: 125 mm, working length x-axis: 3,250 mm, drilling spindles horizontal x-axis: 4 pieces, drilling spindels horizontal y-axis: 2 pieces, drilling spindels vertical x-axis: 9 pieces, drilling spindles vertical ...

Description: Eccentric connector drilling / cup hinge drilling Connector drilling Hole line system / Frame drilling 4 clamps / 4 hold-down devices Technical data: Motor: 1.5 kW Spindle speed: 2800 rpm Max. clearance between the side stops: 750 mm Working height: 850 mm Clamping height max. workpiece thickness: 100 mm max. hole row position dimension: 300 mm Tool shank diameter: 10 mm Weight: approx. 390 kg Space requirement (depth width height): 115x120x125 PRICING IN OVERHAULED CONDITION SOLD WITHOUT WARRANTY! Data is taken from the manufacturer's brochure/documents and may differ from the actual values. ATTENTION: It is expressly pointed out that this lot only corresponds to the scope of the lot description. If objects can be seen in the photo that are not expressly listed in the lot description, these are not part of the sale. part of the sale. This naturally also applies to tools ...

Description: • CNC machining centre • Serial number 0-250-06-1632 • Total installed power approx. 18 KW • Useful working area approx. 2750 x 1000 mm • Travelling way X-axis: 3455 mm, Y-axis: 1480 mm, Z-axis: 260 mm • Maximum travel speed in the axes direction x-y-z: 80-60-20 m/min • Tool magazine with 8 positions •  ,Electrospindle: power 7.50 KW-max. 24000 rpm, automatic tool change, for HSK F63 tool holder, liquid cooled • Milling / saw group with 1.50 KW motor • Saw unit to groove • Vertical drilling spindles in X-axis direction: 11 • Vertical drilling spindles in Y-axis direction: 8 • Horizontal drilling spindles in X-axis direction: 3 + 3 • NUM 1040 numerical control • Software Windows 95 / HOMAG WOODWOP • 6 consoles with 2 vacuum suction cups each • 6 lifting modules for heavy workpieces • BECKER KVT 3.100 vacuum pump with capacity 100 m³/h  ...

Description: • CNC machining centre • Serial number 0-250-06-2992 • Total installed power approx. 18 KW • Useful working area approx. 3250 x 1300 mm • Travelling way X-axis: 3955 mm, Y-axis: 1685 mm, Z-axis: 260 mm • Maximum travel speed in the axes direction x-y-z: 80-60-20 m/min • Tool magazine with 8 positions •  ,Electrospindle: power 9 KW-max. 24000 rpm, automatic tool change, for HSK F63 tool holder, liquid cooled • Saw unit to groove • Vertical drilling spindles in X-axis direction: 10 • Vertical drilling spindles in Y-axis direction: 11 • Horizontal drilling spindles in X-axis direction: 2 + 2 • Horizontal drilling spindles in Y-axis direction: 1 + 1 • NUM numerical control • Software Windows / HOMAG WOODWOP • Remote control panel • 6 consoles with 22 vacuum suction cups in total • 5 lifting modules for heavy workpieces • BECKER KVT 3.100 ...

Description: Workpiece and edge parameters Workpiece width min: For workpiece thickness 8-22 mm | 70 mm For workpiece thickness 23-40mm | 120 mm For workpiece thickness 41-60mm , 150 mm depending on the workpiece length Workpiece protrusion | 38 mm Workpiece thickness | 8 - 60 mm Max. edge height = workpiece height, + 6 mm Edge material roll / 0.4 - 3 mm Edge cross-section max. For PVC | 135 mm For veneer | 100 mm Max. roll diameter , 830 mm Edge material strip , 0.4 - 15 mm (or 12 mm) (When using the VKNR 4845 exchange trimming unit, the max. edge thickness is 12 mm!) Max. edge cross-section For strips ' 600 mm If no radius is specified, R=2 mm is retracted and delivered serial number: 0-261-20-5413, workpiece thickness: 8 - 60 mm, feed: 8 - 18 m/min, joint trimming unit: 2 x 2,2 kW, gluing unit: A12, snipping unit: 2 x 0,35 kW, rough trimming unit: 2 x 0,55 kW, ...

Edge chamfering machine KF 6000 OPTIEDGE is a powerful portable edge cutter that has proven itself in harsh operating conditions. The device is the optimal choice for chamfering large metal sheets or heavy, bulky workpieces without having to move them. - Length of guide rails 230 mm - Width of the bevel max. 10 mm - Angle adjustment 15 - 45° - Motor power main drive 0.75 kW - Powerful servo motor - Infinitely variable speed If you are interested, we will be happy to send you our complete data sheet.

Description: Machine Specifications Axis processing movement : Stationary table with X-Y-Z movement Maximum work piece size X-Y : 1525mm x 3050mm Work table height : 900mm Axis travel X-Y : 1580mm x 3100mm Zaxis travel : 150mm Rapid traverse rate X-Y : 60m/min Rapid traverse Z : 60m/min Design : Bridge gantry style Axis drive system X1/X2-Y : Rack & pinion drive Axis drive system Z : Belt drive Positional accuracy X-Y : +/- 0.05/ 500mm Positional accuracy : +/1 0.01/ 100mm Repeatability X-Y-Z : +/- 0.03mm Cutting head : Mazak multi-control torch 2 Z axis profiler : Non-contact type/Z-axis follow type Lighting system : LED light Operation status indicator lights : Yellow/laser source on, red/laser beam on Programmable assist gas ports : 3 types (Oxygen, air and assist gas Noise level laser : Max 80dBA Machine base : Precision machined single cast iron System weight : ...

Description: measuring range: X = 2,700 mm / Y = 1,250 mm / Z = 85 mm (other dimensions on request) resolution: 0.01 mm accuracy (tolerance): <, +/- 0.1 mm connected load: min. 2 sockets 230 Volt AC field of application incoming goods: quality inspection of delivered parts quality assurance: sample measurement directly on the production line production: for regular checking of machine settings before the start of production of a series process control (safety in production) reduction in set-up time through automatic feedback to the operator of the drilling spindles to be adjusted in the X, Y and Z directions. quality check before delivery - assembly & training by HECHT AG, possible by exclusive arrangement. - factory overhaul 2023 - 12 months warranty with max. 2-shift operation (not valid for spare and wear parts) Approx. Onsite Dimension. (l x w x h): 3,364 x 2 ...

Description: ATTENTION: Location 35614 Aßlar, Germany Well-maintained HOMAG Optimat BAZ 311/52/K CNC machining center with HOMAG Optimat TBA 330/20/16 vacuum feeder, main spindle with Flex5 interface and web edge press unit. ,The main spindle was replaced at the beginning of March 2024 and the costs were EUR 19,000! HOMAG Optimat BAZ 311/52/K, machine no. 0-201-21-4391 HOMAG Optimat TBA 330/20/16, machine no. 0-205-21-4383 Workpiece length: - Single occupancy with tool diameter. 25mm max. 5200mm - Pendulum assignment with tool diameter. 25 mm max. 2150 mm with pendulum occupancy Workpiece width front stop: - max. 1525 mm with tool diameter 25mm - max. 1525 mm with web edge pressing unit - max. 1450 mm for all units Workpiece width stop at the back: - max. 1730 mm with tool diameter 25mm - max. 1650 mm with web edge press unit - max. 1600 mm for all units Main spindle:  ...

Description: - Workpiece length  , All units max. approx. 5200 mm  , Milling cutter 25 mm max. approx. 5375 mm - Workpiece width  , Rear stop for all units max. approx. 1400 mm  , Rear stop cutter 25 mm max. approx. 1550 mm  , Front stop for all units max. approx. 1150 mm  , Front stop milling cutter 25 mm max. approx. 1220 mm - Main spindle 18.5 KW with C-axis  , Speed 0 - 24000 rpm - 72-speed chain changer - Milling spindle 6 KW - LED console position indicator - Chip conveyor belt and articulated belt conveyor (Further tools and units for the tool changer are not included within delivery. Availability depends on the delivery of the new machine. A transport rack from HOMAG is required for transportation of the dismantled machine. This results in costs of EUR 6,500,-- (plus tax). After the transport rack has been returned to Helmut Meier (Germany Burgthann), ...

Description: - Inlet ruler with automatic adjustment and extension 500 mm - BONDING PART A20 BASIC - Pressure zone C with automatic adjustment - Release agent spray unit - Pre- and profile milling unit with pneumatic adjustment - Edge sanding unit KS10 - Profile sanding unit top/bottom PS41 / PS42 edge magazine with: 2 -fold roller, serial number: 0-200-21-6055, edge thickness: 0,3 - 3 (20) mm, workpiece thickness: 8 - 60 mm, workpiece overhang: 30 mm, feed: 18 - 25 m/min, joint trimming unit: 2 x 3 KW, gluing unit: A20/QA34/C, snipping unit: HL84 (2 x 0,8 KW), rough trimming unit: 2 x 1,5 KW, fine trimming unit: 2 x 0,4 KW, profile trimming unit: FF12 (4 x 0,4 KW), edge sanding unit: KS10 / PS41 / PS42, flat scraping unit: ja / yes, profile scraping unit: MN21 automatic, edge buffing unit: ja / yes, control: Power Control PC 22, return system: Nein / No, Approx. Onsite Dimension. (l x w ...

turning diameter:220 mm turning length:200 mm control:Fanuc 0i-TF Manual Guide bar material dia.:26 mm spindle speeds:6000 1/min. spindle drive:7,5/11 kW rapid speed:20 m/min travel -x axis:155 mm travel - z:200 mm CNC controller:Fanuc 0i-TF Manual Guide (Werkstattprogrammierung) + 10,4" LCD turret:12 (hydr.) fach hydraulic unit:mit Lufkühlung hollow chuck:hydraulisch, 150 mm tool holder:4 Stück Innen (Ø32mm), 6 Stück Außen, 2 Stück Plan bar loader:optional Tool setter:manuel soft jaw:1 Satz BORING SLEEVES :6 Stk. (Durchm. 8, 10, 12, 16, 20, 25 mm) Contains: 1.Control system Fanuc 0i-TD (8.4"COLOR LCD) 2.Spindle motor 7.5/11KW Fanuc â8/8000i 3.Spindle speed 6.000 RPM (Bar capacity: Dia 26mm) 4.X/Z-Axis stroke 155/220 mm 5.X/Z Axis rapid traverse 20/20 m/min 6.Hyd.hollow chuck 6" x 3 jaws 7.Hydraulic turret system 12 stations 8.Hyd. Unit for chuck with air cooler 9.Without tails ...

turning diameter:520 mm turning length:600 mm control:Fanuc 0i TF swing diameter over bed slide:320 mm max. turning diameter:280 mm Bar capacity:51 mm spindle speeds:4500 1/min. x-travel:200 mm z-travel:600 mm rapid power traverse in X-and Z direction:30 m/min tailstock quill stroke:100 mm tailstock adjustment:500 mm spindle drive:11/15 kW Machine size (LxWxH):3,440x1,820x2,380 mm machine weight:4100 kg live center:4 MK turret:12-fach, VDI 40 Boring bar holder:BMT 65 hollow chuck:hydr. 250 mm brand new CNC turning center with Contains: 1. Control system Fanuc Oi-TD (8,4" LCD monitor) 2. X/Z-axis stroke 200/600 mm 3. X/Z-axis rapid traverse 30/30 M/MIN 4. Spindle motor 11 / 15 Kw 5. Spindle speed 3500 rpm (Belt driven type) 6. Spindle bearing dia. Ø 120 mm 7. Bar capacity Ø dia 64 mm 8. CS axis function 0.001 degree spindle positioning 9. Hydraulic Hollow chuck 10" x 3 jaws 10. Hyd. un ...

Box Width:750 Box Height:1000 dimensions of the machine ca.:1200 m2 Powder Coating Line EISEMANN very less used and in very good condition. New Price of the plant 2.600.000,- EURO Power & Free conveyor system with 250 car trains, 5-Zone Spray Pre-Treatment System, stainless steel - water drying cooling zones. 2 nos.of WAGNER stainless steel powder cabins each with ABB robots & double-automatic powder guns, as well aseach cabin is equipped with a hand-powder device. Powder Curing Oven, direct gas heated three-zone Spray cleaning equipment, Stainless Steel - Sewage Treatment Plant, Evaporator with Reverse Osmosis System & Fresh-Air Device. Opening Cross Section Areal: Width 750 mm, Height 1000 mm Technical Details: Pretreatment conveying speed 2.3 m / min. Pretreatment surface area approx. 200 m2 / h. Painting Surface approx. 120 m2 / h. Throughput of workpieces approx. 4,000 k This Powede ...

Electronic measuring and display system Weinig type OptiControl with PowerLock for non-contact measurement of the tool dimensions radius (R) and height (H) using a projector with 20x magnification., flight circle (ø): 0 - 300 mm, tool length: 0-310mm

CNC processing centre Brand: Weeke Type: Optimat BHC 655 Year: 2004 - axis movement (X-/Y-/Z-direction) via a compact linear guide system, dust-protected - ball screw spindle (Y- and Z-direction) and rack and pinion drive (X direction) Software: WOODWOP, machine data acquisition, provision of teleservice BASIS-table basic equipment 6 traverses 1 low-maintenance vacuum pump with 100 m³/h output 6 traverses, continuously adjustable in the X direction 4 program-controlled workpiece stops, mounted as a rear row of stops 6 program-controlled workpiece stops, mounted as a front row of stops 2 side stops mounted on an aluminium profile in Y-direction, which can be switched off manually when oversized workpieces are being processed. The side stops can be adjusted manually in Y-direction. 6 workpiece lifting arms for heavy workpieces Milling spindle HSK 9 kW (S6 50%), l ...

Dough dividing and warping machine, bread roll press Model: Optimat Size 3 Simple manual operation Range 30 to 90 grams/piece Dough filler 900 to 2800g Stand machine Dough dividing and warping machine Bread roll press with 3 knitting plates TAS System Floor-standing machine 30 pieces for round and square rolls Removable stainless steel dividing knife Approx. dimensions: 650 x 670 x 1490 mm WxDxH Connection 400 V, 1kW, 16A-CEE plug Used machine cleaned Many more dough dividers in stock!

:KDM-12 | KDM-16 | KDM-20 | KDM-23 faceplate diameter:1000|1400|1800|2000 mm swing diameter:1250|1600|2000|2300 mm turning height:1000 (opt. 1400)|1000 (opt. 1400)|1250 (opt. 1650)|1250 (opt. 1650) mm table speeds:5 - 200 (2-360 opt.)|5 - 160 (2 - 300 opt.)|3,2 - 100 (2-200 opt.)|3,2 - 100 (2-180 opt.) 1/min transmission ratio:4 (variabel in jeder Stufe) max. workpiece weight:4|6|8|10 t max. torque on the faceplate:20|25|25|25 KN rapid feed of tool post:8000|3000|3000|3000 mm/min feed speeds:0.1 - 500 mm/min Max. cutting force of tool head :18|25|30|30 KNm Travel of Ram (vertical):600|800 (1000 opt.)|800 (opt. 1000)|800 (opt. 1000) mm Travel of ram (horiz.):850|1000|1115|1400 mm Cross rail travel :600|850/1000 (optional)|890/1240 (optional)|990/1240 (optional) mm power maindrive:22/30|30/37|37/45|37/45 kW weight of the machine ca.:9|12,5|18,5|20,5 t Machine size (LxWxH):2360x2277x3403|26 ...

x-travel:1200 mm y-travel:800 mm z-travel:550 mm distance spindle center to table:150-700 mm distance between columns:920 mm table-size:1320x800 mm table load:2000 kg T-slot (width-distance-quantity):14x120x7 mm spindle taper:HSK-A 63/HSK-E 50 spindle speed:15000 (opt. 24000/36000) U/min spindle drive:7.5/11 (opt. 30/39; 20/26 kW Spindle motor torque:47.7/70 (opt. 29.1/37.8; 10.4/13.5) N.m. rapid traverse in x-y-z axis:30000 (opt. 40000) mm/min Cutting feed rate X/Y/Z axis:1~10000 (opt.1~20000) mm/min Tool changer:20 (opt. 24) max. tool diameter:100/130 (opt. 80/130) mm max. tool length:300 (opt. 220) mm max. tool weight:8 (opt. 4) kg total power requirement:30 (opt. 80) kva Weight approx.:12 t Machine size (LxWxH):5026x4276x3210 mm positioning accuracy:0,014 mm repeating accuracy:0,008 mm CNC controller:Siemens/Fanuc/Mitsubishi/Heidenhain automatic tool changer:20/24 linear scales:Heide ...

x-travel:1600 mm y-travel:1300 mm z-travel:700 mm distance spindle center to table:200-900 (opt. 225-925/250-950) mm distance between columns:1500 mm table-size:1800 x 1300 mm table load:4000 kg T-slot (width-distance-quantity):22x160x8 mm spindle taper:HSK-A 63/HSK-E 50 spindle speed:15000 (opt. 24000/36000) U/min spindle drive:15/18,5 (opt. 25/33 od. 20/26) kW Spindle motor torque:95/118 (opt. 72.6/95.8; 10,4/13,5 N.m. rapid traverse in x-y-z axis:30000 (opt. 40000) mm/min Cutting feed rate X/Y/Z axis:1~20000 mm/min Tool changer:20 (opt. 24) max. tool diameter:100/130 (opt. 80/130) mm max. tool length:300 (opt. 220) mm max. tool weight:8 (opt. 4) kg total power requirement:60 (opt. 80) kva Weight approx.:22 t Machine size (LxWxH):5026x4276x3210 mm positioning accuracy:0,014 mm repeating accuracy:0,008 mm CNC controller:Siemens/Fanuc/Mitsubishi/Heidenhain automatic tool changer:20/24 ch ...

:VL 1400 | VL 1600 x-travel:1.400|1.600 mm y-travel:760 mm z-travel:760 mm table-size:1.600x760|1800x760 mm max. table load:1.200|1.500 kg T-slot (width-distance-quantity):18x125x5 mm distance spindle center to column:780 mm distance spindle center to table:150-910 (opt.100-860) mm rapid traverse in x-y-z axis:20/20/20 m milling feed range:1-10.000 mm/min :10.000 (opt. 6000) 1/min spindle drive:11/20,4 (opt. 15/20,4) kW positioning accuracy:+/- 0,012 mm repeating accuracy:+/- 0,010 mm tool taper:40 (opt. 50) SK/BT max. tool weight:8 (opt. 20) kg tool length:300 (opt. 350) mm Tool diameter:80/150 (opt. 110/200 (angrenzend leer)) mm dimensions:4500x4300x3350 mm weight of the machine ca.:12|13,5 t total power requirement:40 kVA CNC controls from:Siemens/Fanuc/Heidenhain tool measuring system:Blum workpiece measurement system:Blum Brand-new CNC vertical machining center with CNC control Sie ...

:Omicron ET6 600 | Omicron ET6 1000 | Omicron ET6 1500 | Omicron ET6 2000 grinding diameter:355 / 455 mm grinding length:630 | 1030 | 1530 | 2030 mm centre height:180 / 230 mm swing over bed:355 / 455 mm max. workpiece weight:250 (300 opt.) kg grinding headstock:. grinding wheel size:450 (opt. 500) mm x127 x min.20-max.80 mm grinding spindle speed:600-1600 (stufenlos) 1/min feed per revolution of handwheel:0,001/ 0,01 / 0,1 mm grinding head swivellable +/-:±180 ° automatic feeds:0,2-3000 mm/min workhead:. workhead - spindle speed:0-600 (stufenlos) 1/min swiveling workpiece drive:±90 ° workhead - center taper:5 MK tailstock:. xx tailstock quill adjustment:35 (opt. 70) mm tailstock quill diameter:48 (opt. 70) mm taper in tailstock:4 (opt. 5) MK table:. table speeds:1-5000 mm/min swivellable angle of table:+9°/-5° | +8°/-4° | +7°/-3° | +6°/-2° ° table adjustment - longitudinal: ...

HARTFORD LG1000 LG1000 F1 series TABLE Working area mm 1150x510 Table with T-slots mm 18x3x160 Table capacity kg 700 SHIFTS AXIS X mm 1000 Y AXIS mm 510 AXIS Z mm 630 Spindle axis distance to table surface mm 100 ~ 730 Distance of the table axis tip from the column mm 562.5 POSITIONING ACCURACY Positioning accuracy (JIS B6338) mm ± 0.008 Repeatability (JIS B6338) mm ± 0.002 FEEDS Working feed m / min 12 Rapid traverse X / Y / Z m / min 30/30/24 (optional 40/40/32) SPINDLE # 40BT Spindle Nose Spindle speed (belt gear) rpm 8000 (opt. 10000/12000) Spindle speed (DDS) rpm 10000 (opt. 12000/15000) Spindle drive (30 min) 11 kW, belt drive AUTOMATIC TOOL CHANGER Tool magazine capacity A: 24 (opt S: 20) Max. tool weight kg 7 Max. tool dimensions (diameter x length) mm ø75 x 300L (option S: ø90 x 250L) Type of hand ...

Swing over bed – 600 (Ø 23.62) Diameter × length – Ø 300 × 600 (Ø 11.81 × 23.62) Max. diameter – Ø 380 (Ø 14.96) Max. travel range of Z/X axis – 600 / 240 (23.62 / 9.44); Z-axis: FANUC 2.8 kW (4 HP) /3000 rpm; X-axis: FANUC 2.8 kW (4 HP) /3000 rpm Diameter of spindle bore/Draw bar bore – STD: Ø 77 / Ø 52 (Ø 3.03 / Ø 2.04); OPT: Ø 86 / Ø 77 (Ø 3.38 / Ø 3.03) Spindle speed – STD: 8” chuck 3500 rpm; OPT: 8” chuck 4500 rpm, 10” chuck 3500 rpm Chuck diameter – STD: Ø 8” ; OPT: Ø 10” Hydraulic Tailstock – travel 465 (18.3) MT. No.4 VDI Tool stations – OPT: 8 STD: 10 Coolant Chip conveyor Power requirement – 208-220 volts / 100 Amps / 3 Phases / 60 Cycles Floor area (L × W × H) – 4080 ×1675 × 1842 (160.62 × 65.94 × 72.51) Gross weight (approx.) – 5200 kg (11440 Ibs) this extra informa ...

:LL 550 | LL 750 | LL950 turning diameter:550 | 750 | 950 mm turning length:3000/4000/5000/6000/7000/8000/9000/12000/14000 mm control:Siemens/Fanuc/Fagor center height over bed:475|575|675 mm bed width:990 mm spindle bore:153/230/305/405 mm spindle nose:A2-11/A2-15/A2-20/A2-28 spindle speed:9-600/9-500/7-400/5-250 U/min spindle taper:6 MK spindle drive:22/26 (30/37 opt.) kW tool turret:4/8/12 hydraulisch oder elektrisch tool holder -shaft diameter:32 (40 opt.) mm tailstock quill diameter:165|200 mm tailstock quill adjustment:250 mm taper in tailstock:6 MK tailstock movement:über Motor travel -x axis:370 | 480 mm travel - z:= Spitzenweite mm servo motor X-axis:3 | 4 kw servo motor Z-axis:4 | 7 kw rapid power traverse in X-and Z direction:5/4 m/min hydraulic motor:2,2 (2,9 opt.) kW coolant pump drive:3 (15 opt.) | 15 bar weight of the machine ca.:12,7/15,3/18/21,5/24/26,6 | 13,7/16,4/19/2 ...

:Omicron CNC 3606 | Omicron CNC 3610 | Omicron CNC 3615 | Omicron CNC 3620 grinding diameter:355 / 455 mm grinding length:630 | 1030 | 1530 | 2030 mm centre height:180 / 230 mm swing over bed:355 / 455 mm max. workpiece weight:250 (300 opt.) kg grinding headstock:_________________________________________________ __ grinding wheel size:450 (opt. 500) mm x127 x min.20-max.80 mm grinding spindle speed:600-1600 (stufenlos) 1/min feed per revolution of handwheel:0,001/ 0,01 / 0,1 mm grinding head swivellable +/-:±180 ° automatic feeds:0,2-3000 mm/min workhead:________________________________________________ __ workhead - spindle speed:0-600 (stufenlos) 1/min swiveling workpiece drive:±90 ° workhead - center taper:5 MK tailstock:__________________________________________________ __ tailstock quill adjustment:70 mm tailstock quill diameter:70 mm taper in tailstock:5 MK table:_______________ ...

Bakery shop fittings Aichinger ArtLine III sales counter 3.9 m shop counter bakery sales stand CoolMaxx HotMaxx CoolBottle, used from 11/2018 Type: ArtLine III Manufacturer: AICHINGER GmbH, Ostring 2, 90530 Wendelstein, Germany Purchase according to invoice: 11/2018 Properly and professionally dismantled and stored on pallets in our warehouse. Very good condition. Disc type: ARTLine OK 1252mm I ZP 330mm Countertop Type: Postforming APL Depth: 1060 Front Type: Decor APL Decor Edge: A1 MGM_Schwarz APL Postforming: G/A1 MGM_Schwarz Display: table-level Price bar: EV 1 Front décor top: E/H3395 ST12_Corbridge natural oak Front edge top: H3395 ST12_Corbridge natural oak Version: Standard (V20) Front profile: EV 1 Skirting board: EV 1 Pocket tray type: 1-tube/Waab CNS The shop fittings consist of: #Theke Free-standing end side for modules with glass attachment, ...
