ona edm used for sale

Manufacturer:Agie Model: Agiecut Challenge 2 Year of Manufacture: 2001 Machine Type : Wire EDM Machine Find more here - / Contact us at -

This 3-axis CHARMILLES HD10 start hole drilling machine was manufactured in 2002. It features a work table size of 600x300mm, XY-travel of 350x250mm, and can handle a maximum workpiece weight of 450kg. Ideal for precise erosion tasks, the CHARMILLES HD10 machine we have for sale represents a robust addition to any machining setup. Contact us for further details regarding this machine.

Suitable for automatic processing of PCD-tipped milling cutters, shank tools, disc-shaped tools such as Saws, milling cutters, etc. using the wire electro-erosion process. Accesories: Total enclosure,, Mist extractor, Probe,, Machine lamp,, Automatic central lubrication,, Coolant system dielectric fluid, Fire extinguishing system, Measuring mandrel, Alphanumeric keyboard, cutter outer diameter max: 250 mm, cutting length max.: 200 mm, shank tool diameter: 10 - 250 mm, cutting length: 200 mm, Outside diameter of disc-shaped tools max.: 250 mm, tool weight max.: 20 kg, X-axis travel: 220 mm, Y-axis travel: 300 mm, W axis travel: 200 mm, A-axis rotation range: 60 °, A-axis taper: ISO 40, E-axis swivel range: 120 °, number of revolutions: 80 - 2000 rpm., Dimensions L x W x H: 2235x2630x2130mm, mass: approx. 4500 kg, Connected load approx.: 400V / 50Hz / 4.5KW, colour: turquoise RAL 5021/gr ...

This 3-axis Mitsubishi Electric MV2400R wire EDM machine was manufactured in 2013. It features a PC-based control unit with a 15 LCD touchscreen, supporting 2D/3D CAM and graphics verification. Capable of handling workpieces up to 1050 x 820 x 305 mm and 1500 kg, it offers a machining travel of 600 x 400 x 310 mm. If you are looking to get high-quality EDM capabilities, consider the Mitsubishi Electric MV2400R machine we have for sale. Contact us for more information.

CONTROLS   CNC controls WORKING RANGE -WIRE CUTTING-   X-axis travel: 500 mm   Y-axis travel: 350 mm   z-axis travel (vertical): 426 mm   conical operation for max.: 30 °   U-axis travel: 140 mm   V-axis travel: 140 mm WIRE SYSTEM   wire diameter (min): 0.15 mm   wire diameter (max): 0.33 mm ELECTRICAL SPECIFICATIONS   mains voltage: 400 V   mains frequency: 50 Hz DIMENSIONS / WEIGHTS   space requirements -left/right-: 1940 mm   space requirements -front/back-: 2300 mm   total height: 2600 mm   total weight approx.: 4200 kg

This 5-axis AGIE CUT 300 wire EDM machine was manufactured in 2013. It features a maximum taper angle of 30/100° mm, can handle workpieces up to 1050 x 650 x 250 mm, and supports a maximum weight of 400 kg. If you are looking to get high-quality EDM capabilities, consider the AGIE CUT 300 machine we have for sale. Contact us for more information about this machine.

Agie Wire Cutting EDM Machine High-Precision Wire EDM System This 2018 Agie AC Progress VP3 represents top-tier wire electrical discharge machining (EDM), offering flawless contour accuracy and superior surface finishes for critical components. Technical Details ‍ 1. Machine identification data Name: Wire Cutting EDM Machine (Electric Discharge Machining) Manufacturer: Agie Model: AC Progress VP3 Machine number: 591.3.020.530 Year of manufacture: 2018 2. Operational parameters Travel (X / Y / Z): 500 x 350 x 426 mm Travel (U / V): ± 70 mm Max. taper angle: 30° at 100 mm height Max. workpiece dimensions (X / Y / Z): 1050 x 650 x 420 mm Max. workpiece weight (without water): 400 kg Max. workpiece weight (with water): 800 kg Wire diameters: 0.15 – 0.33 mm Generator: IPG-VPC Max. cutting rate: > 500 mm²/min Best surface roughness: Ra 0.2  ...

Agie Wire Cutting EDM Machine Precision Wire Cutting EDM Machine A staple in advanced toolmaking, this 2006 Agiecut Progress V3 delivers highly reliable and accurate wire EDM capabilities for intricate metal cutting applications. Technical Details ‍ 1. Machine identification data Name: Wire Cutting EDM Machine (Electric Discharge Machining) Manufacturer: Agie Model: Agiecut Progress V3 Machine number: 333.010.008 Year of manufacture: 2006 Control: AGIEVision 5 2. Operational parameters Working area (X / Y / Z): 500 x 350 x 426 mm U-V Axis: +/- 30° / +/- 70 mm Max. workpiece dimensions (L x W x H): 1,050 x 650 x 420 mm Max. workpiece weight (with/without Dielectric): 800 kg / 400 kg Resolution of axes: 0.0001 mm Positioning speed: Up to 3 m/min Clamping system: Universal beams with fixing holes Cutting wire diameter: 0.2 – 0.33 mm  ...

This 5-axis AgieCharmilles CUT 300MS was manufactured in 2016, featuring submerged wire-cutting technology. It supports a maximum workpiece size of 1200 × 700 × 400 mm and a weight up to 1500 kg. The machine offers rapid movement across X, Y, U, V axes at 9.8 m/min and includes integrated collision protection. If you are looking to get high-quality precision cutting capabilities, consider the AgieCharmilles CUT 300MS machine we have for sale. Contact us for more information.

This AGIE Agiecut VERTEX 3 Erosion machine was manufactured in the year 2006 in Switzerland and has 37021 erosion hours. It is equipped with an Agievision 5 Software version 07.08.01 control unit.

This 3-axis Zimmer+Kreim Genius 700 Magic 3 was manufactured in 2009. It features a table with T-slots, dimensions of 575 x 500 mm, and a 24-position electrode changer. The machine can handle a maximum workpiece weight of 700 kg and offers a travel range of 400 x 350 x 350 mm. Consider the opportunity to buy this Zimmer+Kreim Genius 700 Magic 3 die-sinking EDM machine. Contact us for more information about this machine.

Technical Specifications X-axis travel: 450 mm Y-axis travel: 300 mm Z-axis travel: 320 mm U/V axis travel: ± 101 mm Maximum piece weight: 800 Kg Maximum workpiece size: 730 x 500 x 300 mm Bowl dimensions: 730 x 500 mm Control: MAKINO MGW-R Accessories: Remote Flyer Item sold in unverified status Auction-ID: A1-44614-5

This 6-axis VOLLMER QXD 250 grinding machine was manufactured in 2017. It features a robust 3 Phase 380Volts, 50hz, 8.7KVA power supply and a substantial coolant tank capacity of 310 liters. With a machine weight of 7,200kg and comprehensive axis movement, including a 360-degree swivel angle on the A-Axis and +/-20 degrees on the B-Axis, consider the opportunity to buy this VOLLMER QXD 250 grinding machine. Contact us for more information about this machine.

Includes CAM program/license Auction-ID: A1-46315-30

This 4-axis AgieCharmilles FORM 30 was manufactured in 2017. It features a stroke of 600mm x 400mm x 400mm, with axis speeds up to 6 m/min. The machine can handle workpiece weights up to 1000kg and dimensions of 1000 x 700 x 400 mm. It includes a dielectric unit with a 750l capacity and a robust weight of 4400kg. Consider the opportunity to buy this AgieCharmilles FORM 30 die-sinking EDM machine. Contact us for more information about this machine.

Including print run and contents Auction-ID: A1-46315-21

This 3-axis AGIE Challenge 2 eCut wire EDM machine was manufactured in 2006. It offers precision electrical discharge machining capabilities, ideal for detailed and intricate metal work. Consider the opportunity to buy this AGIE Challenge 2 eCut wire EDM machine. Contact us for more information about this machine.

Included content Auction-ID: A1-46315-28

This Sodick AQ537L was manufactured in 2007. It operates optimally between 20°C and 25°C ambient temperatures, with a full load current of 43 A and a rated capacity of 15 kVA. It requires a supply voltage of 200 V and is designed for three-phase power. Contact us for more information about this machine.

\" System 3R EDM Tooling Set – Art. 3R-901-20E / 3R-90°-01 – Made in Sweden System 3R Clamping and Tool Holder Set for EDM Machines. The set is in mint condition and comes from stock. Scope of delivery (4 packs): • System 3R base plates / tension strips • Angle plate / clamping bracket • 3R clamping brackets / mounting elements • Set of 3R collets (in the magazine) • Screwdriver / assembly tool • Accessories and fasteners 1. System 3R base plate / tension strip Manufacturer: System 3R Type / Item no.: 3R-901-20E Condition: as good as new (stock) Description: System 3R clamping strip / base plate for the System-3R EDM clamping system. Precision component for holding and positioning electrode holders or workpiece holders on EDM machines. Origin: Made in Sweden Scope of delivery: Base plate according to the picture. 2. System 3R Angle Plate 90° Manufacturer: System 3R  ...

This 5-axis Brother HS-70A wire EDM machine was manufactured in 2003. It features a CNC-A50 control, working strokes of 410 x 260 x 170 mm, and can handle workpieces up to 350 kg. The wire diameter ranges from 0.1 to 0.3 mm, supporting precise cutting. If you are looking to get high-quality EDM capabilities, consider the Brother HS-70A machine we have for sale. Contact us for more information about this machine.

Wire cutter Type: AU-1000 iA Manufacturer: ACCUTEX Year: 2015 Max size of the work piece:1330 x 900 x 595 mm Max. weight of the work piece: 5000kg X/Y/Z/U/V 800 / 600 / 400 / 150 / 150 mm Diameter of the wire: 0.15-03 mm Continuously controlled 4 axes X, Y, U, V Drive system using AC servo drives Max. cut cone ± 22.5 °/ 100 mm Accuracy class of ball screws rpm C1 - the highest Filter system capacity l Main tank 1630 l, secondary tank (Z=600) 1280 l Max. cutting speed mm²/min 250 Dielectric conductivity measurement Auto – 5  200 k-cm Auto dielectric temperature measurement with an accuracy of ± 1°C Input kVA 15 Weight of the machine: 8500 kg Windows CE control system product for vertical alignment paper filter 2 pcs deionization resin - 1st filling container for deionization resin upper and lower nozzles – 2 pcs diamond guide 2 pcs tool for removin ...

This 5-axis Mitsubishi FX10K wire EDM machine was manufactured in 2001. It features a 32-bit CNC control, automatic wire threading, and a generator for brass wire cutting. Capable of handling workpieces up to 630 × 530 mm and 500 kg, it includes a water purifier tank and central lubrication. Reach out for more information about this machine.

This 3-axis SEIBU M50AG wire EDM machine was manufactured in 2015. It supports workpiece dimensions up to 800x650x300 mm and a maximum weight of 800 kg. Features include a rapid traversing speed of 1200 mm/min and a fine increment capability of 0.0001 mm for precise machining. If you are looking to get high-quality EDM capabilities, consider the SEIBU M50AG machine we have for sale. Contact us for more information about this machine.

According to photos Documents are available electronically Auction-ID: A1-45666-3

This 3-axis AgieCharmilles CABINET FORM20 die-sinking EDM machine was manufactured in 2012. Ideal for precision mold making and tooling applications, it offers robust performance and reliability. If you are looking to get high-quality die-sinking capabilities, consider the AgieCharmilles CABINET FORM20 machine we have for sale. Contact us for more information.

Equipped with isobus; edge spreader; control box; Auction-ID: A1-40137-196

This FANUC Robocut Alpha-1iA erosion machine was manufactured in 1999. It is equipped with a FANUC Series 18i-W control unit, ensuring precise and efficient operations. The machine offers movements of 520 mm in the X-axis, 370 mm in the Y-axis, and 310 mm in the Z-axis, with additional U and V-axis movements of 120 mm each. It supports a table load of up to 1000 kg, making it suitable for handling substantial workpieces. The FANUC Robocut Alpha-1iA machine we have for sale is an excellent choice for intricate EDM tasks. Contact us for more information.

This 5-axis AccuteX AP 4030A wire EDM machine was manufactured in 2022, featuring a submerged design for enhanced precision and stability. It supports a maximum workpiece size of 800 x 560 x 245 mm and a weight up to 800 kg. Key features include AWT for reliable wire threading and a high-resolution 17” LCD-TFT screen for advanced control. Ideal for complex, high-accuracy tasks. Contact us for more information about this machine.

Make: Sodick Type: CNC Die Sinking EDM Machine Model: AM3L Control: Sodick LN1 Technical data: - Working tank: Die sinking EDM - Table size: approx. 600 x 400 mm (estimated) - Axes: X / Y / Z - CNC control: Sodick LN1 Equipment: - Die-sinking EDM generator - Enclosed working area with safety guard - Control cabinet with monitor & keyboard - System 3R tooling interface - Oil unit (Oilmatic temperature regulator) - Dielectric filtration system Condition: Used Auction-ID: A7-45993-51

2011 OPS Ingersoll Gantry Eagle 5 (often referred to as the Eagle G5 or Gantry Eagle 500) is a high-precision Sinker EDM (Electric Discharge Machining) machine. Feature Specification X / Y / Z Travels 525 mm / 400 mm / 450 mm Work Tank Type Drop-tank (rises/falls for easy access) Max Workpiece Weight 1,000 kg (2,205 lbs) Generator Eagle PowerSPARK (60 Amp standard, 110 Amp optional) Z-Axis Jump Speed 18 m/min (This is exceptionally fast for EDM) Find more here - / Contact us at -

This 5-axis FANUC ROBOCUT alpha C800iB was manufactured in 2016, featuring a large work area with X-axis travel of 800 mm, Y-axis travel of 600 mm, and Z-axis travel of 310 mm. It supports a maximum workpiece weight of 3000 kg and utilizes a CNC control FANUC 31i-WB for precise operations. If you are looking to get high-quality wire EDM capabilities, consider the FANUC ROBOCUT alpha C800iB machine we have for sale. Contact us for more information.

This 5s Sodick VN 600 Q wire edm machine was manufactured in 2024. It features a maximum workpiece weight of 1,874 lbs and advanced capabilities such as high-speed automatic wire threading and improved surface finish circuit for smoother machining. With a robust design and user-friendly software, consider the opportunity to buy this Sodick VN 600 Q wire edm machine. Contact us for further details.

Excellent condition - Fully operational - Loading / Transport possible! Positioning resolution : 0.5 a Tool changer Number of electrodes places: 4 Max. electrode dimension : 75 mm Max. electrode length Electrode length : 280 mm Max. electrode weight : 5 kg Max. total weight : 20 kg The tool changer runs sluggishly and would have to be checked. Machining table Usable area : 800 x 600 mm Load capacity : 1000 kg Number of T-slots for mounting : 5 pcs. Dimension of the grooves : 12 mm Working container Max. internal dimensions : 1200 x 800 x 500 mm Capacity : 475 L Fuse box Cabinet dimensions : 900 x 750 x 1950 mm Cabinet weight : 300 kg Protection class of the cabinet : IP 32 Processing head with high rigidity Max. electrode weight : 100 kg Insulated interface : 250/650 mm

Two Wire EDM machines manufactured in 2015 and 2019. These 4 axis ZK Genius 700 (2015) + ZK Genius 700 (2019) + Chameleon- Quad (2015) features a travel distance of 400 x 350 x 350 mm and a table size of 575 x 500 mm, accommodating workpieces up to 700 kg. Includes a controlled C axis and rotary spindle, along with a CO/2 Kraft & Bauer fire extinguishing system. Consider the opportunity to buy this ZK Genius 700 (2015) + ZK Genius 700 (2019) + Chameleon- Quad (2015) wire EDM machine. Contact us for further details.

EDM machine. Serial: 203 Estimated weight: 2000 kg Approximate package dimensions: 2300x1900xh2100 and 1200x800xh2200 mm Auction-ID: A7-46655-165

This 3s Sodick AG55L die-sinking edm machine was manufactured in 2008. With a magazine capacity of 32 positions and a maximum workpiece weight of 1000 kg, it offers robust capabilities for precision machining. The X travel reaches 550 mm and Y travel extends to 400 mm, making it suitable for various applications. Consider the opportunity to buy this Sodick AG55L die-sinking edm machine. Contact us for further details.

Manufacturer: Mitsubishi Model: FX20K Type: Wire EDM machine (Wire erosion) Year of Manufacture: 1999 Workpiece and Table Specifications - Maximum workpiece size (W x D x H): 1,050 x 800 x 295 mm - Maximum workpiece weight: 800 kg - Table dimensions: 780 x 630 mm - Axis travel (X / Y / Z): 500 x 350 x 300 mm - Maximum table feed rate: 1,300 mm/min Wire and Cutting Specifications - Wire diameter: 0.2 to 0.3 mm - Maximum wire feed rate: 250 mm/sec - Wire tension: 2 to 25 N Machine Dimensions and Weight - Overall machine dimensions (W x D x H): 1,810 x 2,310 x 2,050 mm - Machine weight: 2,550 kg Filter System - Tank capacity: 635 litres - Filter flow rate: 30 l/min - Filter fineness: 3 micrometres - Filtration: Paper filter (2 units) - Conductivity control: 0.5 to 100 x 10 ohm/cm - Filter unit dimensions (W x D x H): 800 x 1,700 x 1,720 mm - Filter unit weight (empty): 230 kg Ge ...

This 3-axis Mitsubishi MV 2400S wire EDM machine was manufactured in 2015. It features an X-axis travel of 600 mm, Y-axis travel of 400 mm, and Z-axis travel of 310 mm. The machine can accommodate workpieces up to 1,050 mm in length and 820 mm in width, with a maximum weight of 1,500 kg. If you are looking to get high-quality wire EDM capabilities, consider the Mitsubishi MV 2400S machine we have for sale. Contact us for further details.

This 3-axis CDM Rovella BF 600 die-sinking EDM machine was manufactured in 1997. It features a 1400x700 mm working area and comes with equipment included. If you are looking to get high-quality die-sinking capabilities, consider the CDM Rovella BF 600 machine we have for sale. Contact us for more information about this machine.

Technical data Manufacturer: AGIE Model No.: EMT 1.10 Machine Type: Die-sinking EDM Machine Year of Make: 1984 Weight: approx. 420 kg Max. workpiece size: 420 x 250 x 160 mm Travel X/Y/Z: 250 x 160 x 200 mm Generator power: up to 30 A Voltage: 220 / 380 V Frequency: 50 / 60 Hz Dimensions: approx. 1900 x 650 x 650 mm Configuration AGIEPULS Generator (60L2) Manual/analog control Servo-controlled feed Separate control unit Documentation available Clamping device mounted Note The technical data was taken from existing nameplates and machine documentation.

" Manufacturer: Novotec / Intech EDM Type / Name: Copper Threaded Electrodes for Die-sinking EDM M2.5 – M16 (various sizes) – Lot of copper threaded electrodes for die-sinking EDM machines (EDM) of various sizes. The electrodes come mainly from Novotec and Intech EDM and are intended for the EDM of threads (Thread EDM). The inventory includes several sizes from M2.5 to M16, some with flush bore and orbital design. The electrodes are mostly in original packaging or protective tubes and are unused or in stock. The electrodes are sorted by size and are located in storage boxes (M2.5 / M4 / M6 / M8 / M10 / M12 / M16). Copper threaded electrodes consisting of different sizes: • M2.5 (with flush hole) • M4 x 0.70 orbital • M6 • M8 • M10 orbital • M12 • M16 Partly in original packaging (Novotec) or protective tubes. Material: Copper Application: Threaded EDM / die-sinking E ...

" System 3R EDM Tooling Set – Art. 3R-901-20E / 3R-90°-01 – Made in Sweden System 3R Clamping and Tool Holder Set for EDM Machines. The set is in mint condition and comes from stock. Scope of delivery (4 packs): • System 3R base plates / tension strips • Angle plate / clamping bracket • 3R clamping brackets / mounting elements • Set of 3R collets (in the magazine) • Screwdriver / assembly tool • Accessories and fasteners 1. System 3R base plate / tension strip Manufacturer: System 3R Type / Item no.: 3R-901-20E Condition: as good as new (stock) Description: System 3R clamping strip / base plate for the System-3R EDM clamping system. Precision component for holding and positioning electrode holders or workpiece holders on EDM machines. Origin: Made in Sweden Scope of delivery: Base plate according to the picture. 2. System 3R Angle Plate 90° Manufacturer: System 3R T ...

This 3-axis CHARMILLES Roboform 350 die-sinking EDM machine was manufactured in 2006. It features travel paths of 350 x 250 x 300 mm and can accommodate a maximum electrode weight of 25 kg. The machine has a power consumption of 7.5 kVA and weighs 2350 kg. If you are looking to get high-quality die-sinking capabilities, consider the CHARMILLES Roboform 350 machine we have for sale. Contact us for further details.

The machine is in good technical condition, after prior agreement it is possible to test it. Workpiece weight (max.): 1,000 kg X-axis travel distance: 600 mm Y-axis stroke: 400 mm Z-axis stroke: 310 mm Wire diameter (max.): 0.3 mm Workpiece height (max.): 310 mm Width (max.): 1,050 mm X-axis feed: 600 m/min Y-axis feed speed: 1,000 m/min Table load: 1,000 kg Equipment: refrigerator, compressor

This 3-axis AgieCharmilles Spirit 3 was manufactured in 2008. It features an integrated C-axis and electrode magazine, multitasking operating system with object-oriented graphical interface (AEP Spirit), and a table size of 850×650 mm. Movement range includes X:550, Y:400, Z:350. Consider the opportunity to buy this AgieCharmilles Spirit 3 wire EDM machine. Contact us for more information about this machine.

This 3-axis HUBER OCT-3020 NA die-sinking EDM machine was manufactured in 2006. It features a travel of 300 mm in the X-axis, 200 mm in the Y-axis, and 350 mm in the Z-axis, accommodating workpieces up to 460 x 210 x 200 mm. If you are looking to get high-quality die-sinking capabilities, consider the HUBER OCT-3020 NA machine we have for sale. Contact us for further details.

This 3-axis AGIE AGIETRON INTEGRAL 2 was manufactured in 2006. It features a travel of 350 mm in the X-axis, 250 mm in the Y-axis, and 350 mm in the Z-axis. The machine can accommodate workpieces up to 840 x 670 x 250 mm and has a maximum electrode weight of 100 kg. If you are looking to get high-quality die-sinking capabilities, consider the AGIE AGIETRON INTEGRAL 2 machine we have for sale. Contact us for further details.

Refurbished 2022 Travel distances: X= 350 mm, Y= 250 mm, Z= 256 mm Travel of U/V axis: +/- 70 mm Maximum conicity: 30° at 100 mm height Maximum workpiece dimensions: 750 x 550 x 250 (150 in the bath) mm Maximum workpiece weight: 200 (in bath) / 450 (without bath) kg Achievable surface quality: Ra: 0.30 μm Medium contour tolerance: +/- 6 μm Maximum cutting rate: 300 mm²/min Available wire diameters: 0.20 – 0.33 mm Water bath machine with autom. Wire threading and rethreading after wire breakage

This 4-axis +GF+ AgieCharmilles FO 350SP die-sinking EDM machine was manufactured in 2013. It features a stable EDM generator, a fully operational 360° C-axis with a rotational speed of 100 rpm, and a substantial work area of 800 × 550 × 370 mm. Well-maintained and operational until its last day, consider the opportunity to buy this +GF+ AgieCharmilles FO 350SP die-sinking EDM machine. Contact us for more information about this machine.
