om vertical lathe used for sale

Condition: unchecked Item is sold as is Weight may be ggbfs. Deviate. Machine must be dismantled by the buyer and transported out of the hall area. It cannot be guaranteed that a forklift is on site. Auction-ID: A1-46354-55

Condition: unchecked Item is sold as is Weight may be ggbfs. Deviate. Machine must be dismantled by the buyer and transported out of the hall area. It cannot be guaranteed that a forklift is on site. Auction-ID: A1-46354-57

Cabinet Dimension 720x805x1045 Condition: unchecked Item is sold as is Weight may be ggbfs. Deviate. Machine must be dismantled by the buyer and transported out of the hall area. It cannot be guaranteed that a forklift is on site. Auction-ID: A1-46354-53

thre pcs. available

Guide and tension spindle lathe machine - Forkardt-3 jaw chuck F 315 - Single steel holder - Bezel - Moving center punch - Lining protection, limit switch monitored - Chip tray Turning diameter over bed 600 mm Turning diameter over support 400 mm Turning length 1000 mm Turning diameter in the offset 850 mm Speed 15 - 810 rpm Center height 300 mm Spindle bore 56 mm Total power requirement 9.0 KW Machine weight approx. 2.9 t Dimensions approx. 2.8 x 1.45 x 1.65 m Auction-ID: A7-46460-417

Lead and pull spindle lathe - 4-jaw chuck 200mm - Multifix steel bracket size B - Foot brake - Chip tray Turning diameter over bed 420 mm Turning diameter over support 290 mm Turning length 900 mm Speed 40 - 2000 rpm Tip height 210 mm Spindle bore 38 mm Total power requirement 4.0 KW Machine weight approx. 0.9 t Space requirement approx. 2.4 x 1.1 x 1.3 m Condition: unchecked (6) Auction-ID: A7-46460-499

Lead and pull spindle lathe Three-jaw chuck 200mm Multifix Steel Bracket Size B 3 Multifix cassettes Emergency Stop Facility Turning diameter over bed 370 mm Turning diameter over support 200 mm Turning length 1000 mm Center height 185 mm Spindle bore 56 mm Tailstock quill holder MK 4 Speed 50 - 2000 rpm Drive power 4.0 kW Machine weight approx. 1.4 t Dimensions approx. 2.3 x 1.1 x 1.3 m Auction-ID: A7-46460-403

Professional Metal Lathe,Gear Cutting Machine - 3-jaw chuck - 4-jaw chuck - Hardened bed sheets - Clamping plate - 4-way chisel holder - Feed protection - Standing and moving bezel - Splash protection wall - Machine light Turning diameter over bed 280 mm Turning diameter over support 158 mm Turning length 600 mm Speed 45 - 2000 rpm Center height 140 mm Spindle bore 26 mm Tailstock quill holder MK 2 Tailstock quill stroke 60 mm Metric threads 0.25 - 2.5 mm Thread - Inch 6 - 96 TPI Connection voltage 230 V Total power requirement 0.75 kW Machine weight approx. 0.16 t Space requirement approx. 1.26 x 0.58 x 0.60 m Condition: never used / new (5) Auction-ID: A7-46460-526

Lathes with: - 4-fold steel holder - 3-jaw chuck 315mm - Centering tip Turning diameter over bed 500 mm Turning diameter over support 320 mm Turning length 2100 mm Center height 250 mm Spindle bore 60 mm Spindle speeds 11 - 2000 rpm Total power requirement 7.0 kW Machine weight approx. 2.9 t Dimensions approx. 4.3 x 1.2 x 1.3 mm Auction-ID: A7-46460-438

Lathes with: - Copying device - Forkardt 3-jaw chuck F250 - Multifix steel holder - Coolant system - Machine light - Feed protection - Chip tray - Chip protection wall - Foot brake Turning diameter over bed 410 mm Turning diameter over support 220 mm Turning length 1000 mm Center height 205 mm Circumferential diameter in offset mm Spindle bore 46 mm Spindle speeds 40 - 2000 rpm Total power requirement 22.0 kW Machine weight approx. 1.8 t Space requirement approx. 2.42 x 1.3 x 1.55 mm Auction-ID: A7-46460-616

Bench lathe 2-axis LCD digital display system. Longitudinal feed. 3-jaw chuck 125 mm. 4-jaw chuck 125 mm. Clamping plate. 4-way steel holder. Drip tray Hardened bed sheets. Emergency stop. Feed protection Set of wheels. Base cabinet is not included Suitable tools. Turning diameter over bed 250 mm Turning diameter over support 140 mm Turning length 550 mm Speed 50 - 2000 rpm Tip height 125 mm Spindle bore 26 mm Tailstock quill holder MK 2 MK Tailstock quill stroke 65 mm Connection voltage 230 V Total power requirement 1.1 kW Machine weight approx. 0.15 t Space requirements approx. 1.3 x 0.6 x 0.65 m Condition: never used / new (5) Auction-ID: A7-46460-408

Longitudinal and transverse feed. 3-jaw chuck 160 mm. 4-jaw chuck 160 mm. Face Plate 4-way steel holder with 4 pcs tool holder 2 pcs steady rests Machine Light Drip tray Hardened bed sheets. Emergency stop. Feed protection Set of wheels. Machine Tools. Turning diameter over bed 290 mm Turning diameter over support 170 mm Turning length 750 mm Speed 75 - 2000 rpm Center height 145 mm Spindle bore 38 mm Tailstock quill holder MK 3 MK Tailstock quill stroke 80 mm Connection voltage 230 V Total power requirement 1.5 kW Machine weight approx. 0.34 t Space requirements approx. 1.3 x 0.75 x 0.7 m Condition: never used / new (5) Auction-ID: A7-46460-420

Table lathe with base cabinet 2-axis LCD digital display system. Longitudinal feed. 3-jaw chuck 125 mm. 4-jaw chuck 125 mm. Clamping plate. 4-way steel holder. Drip tray Hardened bed sheets. Emergency stop. Feed protection Set of wheels. Suitable tools. Turning diameter over bed 250 mm Turning diameter over support 140 mm Turning length 550 mm Speed 50 - 2000 rpm Tip height 125 mm Spindle bore 26 mm Tailstock quill holder MK 2 MK Tailstock quill stroke 65 mm Connection voltage 230 V Total power requirement 1.1 kW Machine weight approx. 0.15 t Space requirement approx. 1.3 x 0.6 x 1.3 m Condition: never used / new (5) Auction-ID: A7-46460-566

Lead and pull spindle lathe - 4-jaw chuck 315mm - Multifix steel bracket size B - Feed in upper support - Bezel - Machine feet - Chip tray Turning diameter over bed 520 mm Turning diameter over support 260 mm Turning length 1600 mm Speed 14 - 710 rpm Tip height 260 mm Spindle bore 60 mm Total power requirement 11.0 KW Machine weight approx. 2.9 t Space requirement approx. 4.0 x 1.4 x 1.6 m Auction-ID: A7-46460-484

Guide and tension spindle lathe machine - With photocopying device - 3-jaw chuck 200mm - 2 Mutifix quick-change steel holders - Moving center punch - Machine light - Chip tray Turning diameter over bed 410 mm Turning diameter over support 260 mm Turning length 1000 mm Turning diameter in the offset mm Speed 40 - 2000 rpm Center height 205 mm Spindle bore 50 mm Total power requirement 4.5 KW Machine weight approx. 1.6 t Dimensions approx. 2.4 x 1.3 x 1.5 m Auction-ID: A7-46460-510

Lathes with: - Digital display - Quick-release steel holder - 3-jaw chuck 200mm and 160mm - Chip tray - Centering tip Turning diameter over bed 460 mm Turning diameter over support 280 mm Turning length 1000 mm Center height 230 mm Circumferential diameter in offset 720 mm Spindle bore 53 mm Spindle speeds 28 - 1250 rpm Total power requirement 4.0 kW Machine weight approx. 1.8 t Dimensions approx. 2.4 x 1.4 x 1.75 mm Auction-ID: A7-46460-450

3-jaw chuck 200mm 4-fold steel holder Turning diameter 350mm Turning diameter via support 210 in offset 500mm Turning length 1000mm Speed 20 - 1400rpm Spindle bore 36mm Motor 2.0 KW Weight 600Kg Dimensions 2.2 x 1.0 x 1.5m Auction-ID: A7-46460-493

Inv. Num. : 9082 Type: SKJ 8 NC Producer: TOS Created: GO 2020 Parameters: Control system: MEFI CNC 872 Max. workpiece diameter: 800 mm Max. workpiece height: 630 mm Max. workpiece weight: 2000 kg Length: 2000 mm Width: 2550 mm Height: 3700 mm Weight: 10000 kg Equipment: Hydraulic table clamping Electric rotation of the cutter head Ball screws GO 2020: Complete machine overhaul with conversion to a new MEFI CNC 872 control system Conversion from the original hydraulic drives to Yaskawa servo motors New electrical installation New hydraulic system and central lubrication

Including various accessories; Quick-release system; Collets round ø3-ø42mm; Collets hexagon 14-32mm; Acurite digital readout; Refrigerant system; Heynau grinding/drilling unit (can be connected separately); Mechanical stop; Gears; Lighting; Occupational health and safety hood; Röhm three-jaw ø160mm; Various attacks; Tool holders; Auction-ID: A1-41995-12

Hyperturn 45 Year of manufacture: 2015 Operating hours: 36,315 h Belt filter system with immersion cooler 600 L / 40 bar Bar loader External turning holders: 6 pcs Drill bar holders: 6 pcs Driven angle heads: 5 pcs Radially driven: 3 pcs Parting tool holder: 1 pc Hainbuch HS/GS collet chucks Presetting device Find more here - / Contact us at -

A cycle-controlled CNC lathe Böhringer is available. Swing diameter over bed/faceplate: 570mm/365mm, center height: 280mm, bed width: 360mm, travel X: 345mm, cross slide dimensions X/Y: 260mm/680mm, bed slide guide length: 520mm, speed: 2500rpm, feed: 50mm/rev, rapid traverse X/Z: 10m/min/5m/min, quill stroke: 190mm, center angle: 60°, max. workpiece weight: 400kg/1000kg/1600kg. Documentation available. An on-site inspection is possible. Expected to be available July 2026.

Manufacturer: HK-CON Model: L2SDZ-6 SUS-090 Type of Machine : Lathe Find more here - / Contact us at -

Manufacturer:TRAUB Model: TNX 80/65 Year of Manufacture: 2008 Type of Machine : CNC Lathe Total Power Requirement: 95 kW Voltage: 400 V, 50 Hz Machine Weight: approx. 14,000 kg Machine Dimensions (L x W x H): approx. 5.5 m x 7.8 m x 2.52 m Floor Space Required: approx. 5.5 m x 7.8 m Spindle Specifications - Spindle head DIN 55026: HSP A8 / GSP A6 - Spindle bore diameter: 65 mm - Maximum spindle speed: 4,300 min-1 (HSP) / 5,000 min-1 (GSP) - Main spindle motor output: 25.2 / 30.2 kW - Counter spindle motor output: 17 / 21.5 kW Turret System - Turret positions: 4 turrets (positions 1, 2, 3 and 4) - Turret stroke X-axis: 170 mm - Turret stroke Y-axis: plus/minus 60 mm - Turret stroke Z-axis: 600 / 500 / 950 mm - Number of driven tools per turret: up to 10 - Vertical tool holders DIN 69880: 40 x 63 mm Linear Tool Carrier - B-axis: swivelling - Number of driven tools: 2x2 / 2x2( ...

Manufacturer: TRAUB Model: TNX 80/65 Year of Manufacture: 2005 Type of Machine : CNC Lathe Total Power Requirement: 95 kW Voltage: 400 V, 50 Hz Machine Weight: approx. 14,000 kg Machine Dimensions (L x W x H): approx. 5.5 m x 7.8 m x 2.52 m Floor Space Required: approx. 5.5 m x 7.8 m Spindle Specifications - Spindle head DIN 55026: HSP A8 / GSP A6 - Spindle bore diameter: 65 mm - Maximum spindle speed HSP: 5,000 min-1 - Maximum spindle speed GSP: 5,000 min-1 - Main spindle motor output: 25.2 / 30.2 kW - Counter spindle motor output: 17 / 21.5 kW Turret System - Turret positions: 4 turrets (positions 1, 2, 3 and 4) - Turret stroke X-axis: 170 mm - Turret stroke Y-axis: plus/minus 60 mm - Turret stroke Z-axis: 600 / 500 / 950 mm - Number of driven tools per turret: up to 10 - Vertical tool holders DIN 69880: 40 x 63 mm Linear Tool Carrier - B-axis: swivelling - Number of driv ...

Manufacturer: Gildemeister Model: GMX 400 linear Year of Manufacture: 2007 Total Power Requirement: 100 kVA Voltage: 400 V Machine Weight: 24,000 kg Floor Space Required: 60 m2 Working Range - Centre height: 1,343 mm - Maximum turning diameter: 640 mm - Maximum turning length: 1,930 mm - Maximum turning length over bed: 550 / 180 mm - Slide travel longitudinal X1, X2: 1,585 / 1,400 / 1,500 mm - Slide travel vertical Y: plus/minus 110 mm - B-axis: plus/minus 120 degrees - Maximum circumference: 640 mm - Length of workpiece in crown area: not specified - Maximum workpiece weight: not specified Spindle Specifications - Spindle head flat flange DIN: Flachflansch - Spindle nose diameter front bearing: 220h5 mm - Spindle bore diameter: 107 mm - Spindle nose diameter: 150 mm - Max. chuck bore diameter in front bearing: 250 / 315 / 400 mm (internal taper) - Spindle speed HSP: 3,200 / 4 ...

Technical data see pictures Auction-ID: A1-46607-99

Description WEILER E110 conventional lathe with automatic cycle Machine unused in the guides, as only plastic parts were manufactured. Details Type E110 Year of construction 1998 Center width 3,000 mm Center height 550 mm Circumferential diameter over bed 1,100 mm Circumferential diameter over face slide 730 mm Bed width 600 mm Spindle head according to DIN 55027/55026 Gr. 15 Spindle diameter in the front bearing 235 mm Spindle bore 165 mm Machine dimensions 5,400 x 2,600 x 2,120 mm incl. documentation

Turning length: 1000mm; Factory number: 37895; Turning diameter over bed: 500mm; Turning diameter over support: 280mm; Tip height: 250mm; Spindle Passage: 71mm; Speed range: 18-1800/36 step rpm ; equipped with digital display, Make: Fagor ; various accessories, Top grains, Turning steels etc. Auction-ID: A7-46619-270

NEW UNUSED MACHINE WITH DRIVEN TOOLING AND Y-AXIS! Specifications: Spindle: - Spindle hole diameter: 65mm - Bar capacity: 51mm - Chuck: 10” - Max spindle speed: 2600rpm Capacity: - Max. Swing diameter over bed: 600mm - Max. Turning diameter: 420mm - Max. Turning length: 550mm - X-axis: 280mm - Z-axis: 650mm - Y-axis: +/- 50mm - C-axis: yes Feedrate: - Rapid traverse X: 20m/min - Rapid traverse Z: 25m/min Turret: - Positions on turret: 12 - Driven tooling: yes - Tool shank: BMT-55 Tailstock: - Tailstock quill taper: MT-5 - Travel: 600mm Accuracy: - Positioning accuracy: 0.008mm - Repeated positioning accuracy: 0.008mm Machine is equipped with: - Chip conveyor - Tool setter - All tooling in turret included - Tailstock - Tooling as showed in pictures Auction-ID: A1-45752-4

Specifications: Control: Fanuc 0i-TD Hours: 12009 Capacity: - Swing over bed: 970mm - Swing over cross slide: 600mm - Centre height: 490mm - Width of carriage: 885mm - Width of cross slide: 350mm - Distance between centers: 4300mm - Width of bed: 560mm Headstock: - Chuck size: 605mm - Spindle bore: 153mm - Spindle nose: A2-11 - Spindle speed: 6.5 ~ 600rpm - Spindle power: 22/26kW Turret: - Tool size: 32mm - 4 positions Tailstock: - Quill diameter: 165mm - Quill traverse: 200mm - Tailstock center: MT#6 - Body movement: motorized Machine is equipped with: - 2 chip conveyors - Motorized tailstock body - Steady rest - Tooling as showed in pictures - Auction-ID: A1-45752-7

Max. turning length: 760mm, Max. turning diameter: 405mm, Max. turning diameter over bed: 405mm, Diameter over slide: 216mm, Feeds in the x-z: 203/762mm, Spindle speed:800 rpm, Passage over the slide: 508mm, equipped with CNC control: Hass-control, incl. accessories on multifix holders, Turning steels and drill chucks; see photos for more details Auction-ID: A7-46619-340

Pallet with various accessories Collets Cheek chuck Auction-ID: A1-46607-117

Kity 663 wood lathe in excellent condition. Perfectly functional, ready-to-use machine. Works without any problems, ideal for precision work as well as for regular use. Robust and reliable construction, typical of the Kity brand. The lathe is sold with the accessories and tools shown in the photos (complete set supplied with the machine), which allows immediate use. Very good overall condition. Auction-ID: A3-43528-36039

- Powered tool stations Auction-ID: A1-46607-41

An old Colchester engine lathe is available. Center height: 216mm, swing diameter over bed/cross slide/in gap: 432mm/267mm/711mm, distance between centers: 2000mm, spindle bore: 76mm, speed: 1600rpm, bed width: 343mm. Machine dimensions X/Y/Z: approx. 3200mm/1100mm/1400mm, weight: approx. 2500kg. An on-site inspection is possible.

Travels: X-axis: 210 mm Z-axis: 520 mm Auction-ID: A1-46607-52

Tip height: 165mm, Center width: 750-1000mm, Bore main spindle: 42mm, Spindle speed: 60-2000 rpm, Main motor power: 2.2kW, Machine number: 43503, equipped with digital display, Make: Acu-rite, Multifix holder, 3 jaw chucks, Assortment of clamping jaws, Drawer cabinet with assortment of turning steels, Sprial drills, Multifix holder etc. ; see photos for more details Auction-ID: A7-46619-330

turning diameter:1600 mm turning length:12000 mm control:FAGOR 8050 Used CNC Lathe with FAGOR 8050 and extensive accessories. For further technical data and accessories, pls browse the Appendix. Parallellathe WMW mod. 4 GUIDE-WAYS ¦ CNC: FAGOR 8050 ¦ bed: monolithic ¦ centres height: 800 mm ¦ centres distance: 12000 mm ¦ swing over cross-slide: 1250 mm ¦ turret: automatic 4 positions ¦ tailstock: motorized ¦ tailstock connection: hydraulic ¦ platform: diam. 1000 mm ¦ steady rests: nr.02 ¦ chip conveyor Warranty: none Take advantage of the favorable leasing and hire-purchase terms from IKB Leasing. Ask us about it.

turning diameter over bed:2600 mm turning diameter over slide rest:2200 mm turning length:5000 mm faceplate:2050 mm number of spindle speeds:0,7 - 70 rpm total power requirement:ca. 22 kw Height of centres: 1350 mm Distance between centres: 5000 mm Swing over cross slide: 2600 mm Spindle power: 30 HP Spindle speed: 0,7 - 70 rpm Longitudinal swift Control on the carriage Chuck: diam. 2050 mm

turning diameter:570 mm turning length:1000 mm dimensions of the machine ca.:3,25 x 2,03 x 1,95 m Tool disc turret for 8 tools with VDI 30. Not for power tools machine manual, technical documentation; Accessories: 3-jaw chuck, various tool holders Video is available

number of spindles:6 spindle passage:22 mm ?Bar feeder complete is 4.70 meters - for 3 meters of material ?The machine is still on ?Materail to be processed on the machine: Steel ?Production with OIL Machine has only Single-NCU without PCU. The complete energy supply of all 6 main spindles was replaced in April 25. No socket for powered tools!

Technical Specifications Maximum Rotating Diameter: 420mm Maximum turning length: 291 mm Maximum turning diameter: 320 mm Left rpm: 3200 rpm; 7.5-11 kW X-axis travel: 190 mm Z-axis travel: 350 mm X-Z rapid feed speeds: 24 - 30 m/min Tool Holder: 12 Positions Control: FANUC 0i-TF Approximate weight: 3500 Kg Approximate Footprint: 2214mm x 2220mm x 2713mm Accessories: Chip evader ; Remote handwheel Notes: Complete with 16-position gantry loading system Item sold in unverified status Auction-ID: A1-44614-2

Technical data Manufacturer: WEILER Model: Commodor B Machine Type: Lead and Pull Spindle Lathe Turning diameter over bed: 380 mm Turning diameter over slide: 190 mm Center width: 750 / 1000 mm Spindle bore: approx. 56 mm Spindle speed: 25 – 2000 rpm Connected load: 4 kW Voltage: 380 V Weight: approx. 1300 – 1500 kg Configuration Lead and pull spindle Tapping function (metric / inch) 3-jaw chuck Additional chuck Multifix tool holder Tailstock Coolant Setup Chip tray Note Technical data was taken from the nameplate and machine documentation. Specifications may vary depending on the version. Auction-ID: A1-46315-52

turning diameter:270 -300 mm turning length:710 mm total power requirement:43 kW weight of the machine ca.:8,5 t dimensions of the machine ca.:3,16 x 2,15 x 2,15 m The machine does not include a chuck or tools ? the machine was originally purchased without these accessories. The G300 has X, Z, Y, C, SP, and driven tools. A bar feeder can be used, but the machine does not have one.

turning diameter:220 mm turning length:310 mm total power requirement:17 kW weight of the machine ca.:3,3 t dimensions of the machine ca.:2,25 x 1,63 x 1940 m greates pass round over bed:430 mm bore diameter:45 mm centre distance:687 mm slide travel radial ( X-axis ):160 mm slide travel axial ( Z-axis ):310 mm spindle turning speed range:0-6.300 U/min

turning diameter:220 mm turning length:700 / 665 mm total power requirement:17 kW weight of the machine ca.:2,6 t dimensions of the machine ca.:2,63 x 1,98 x 1,94 m greates pass round over bed:430 mm Part length max.:510 slide travel radial ( X-axis ):160 mm bore diameter:45 mm Texte, Bilder, Grafiken, Layout, Strukturen und Algorithmen etc. unterliegen weltweitem Urheberrecht. Unerlaubte Verwendung der Daten, werden sowohl strafrechtlich als auch zivilrechtlich verfolgt. Das ausschließliche Urheber- / Nutzungsrecht dieser Daten wurde nachfolgender Person eingeräumt. Copyright © 2005-2026, Josef Weber. All rights reserved.

WEILER LZ330 / From educational institution incl. new 3-axis digital display -Turning diameter over bed 330mm -Turning diameter over support 165mm -Turning length 800mm -Speed range 25 - 2800 rpm -Automatic / longitudinal plan feeds -Multifix with 3x inserts -Drive power 3KW -Three-jaw chuck -Collet device with 20x collets -Copying device -Miscellaneous Accessories -Documentation Dimensions: LxWxH 1.8x0.7x1.6 meters / Weight 750Kg

\" Lot of approx. 300 kg of turning steels – mixed lot for lathes An extensive lot of turning steels for machine tools is for sale. Inventory according to visual inspection: • External turning steels • Internal turning steels / boring rods • Parting steels • Shaped steels • Partly equipped with carbide • Partly with indexable insert holders Different dimensions and designs. Sale exclusively as a total item. Total weight: approx. 300 kg Material: tool steel / partly carbide tipped Design: various shaft sizes and lengths \" Auction-ID: A7-46417-369

turning diameter:490 mm turning length:2000 mm total power requirement:15/20 kW weight of the machine ca.:3,6 t dimensions of the machine ca.:2,8 x1,85 x 1,9 m In like new condition Heidenhain cycle control Torsion-resistant bed, made of high-quality cast iron with hardened, precision-ground guideways and a glass scale on the X-axis Safety clutch on the Z and X axes Sealing air with carbon filter in direct position measuring system High accuracy and rigidity of the lathe spindle thanks to precision spindle bearings, spindle bore Ø 93 mm standard, optional Ø up to 130 mm Solid tailstock, quill Ø 90 mm with internal taper MK5 Large overhang above the facing slide for easy accessibility during shaft machining. The machine has Teach-in CNC Programms. Control: MC420. Tool holder: SAUTER.

Batch of two four-jaw lathe chucks for independent workpiece clamping. The chucks come from the manufacturers WMW and ROTO RECORD and are ideal for eccentric, asymmetrical or irregular clamping on lathes. Technical data:     •    Type: Four-jaw lathe chuck, independently adjustable     •    Included: &nbs p;   •    1× WMW DH 130×4-II, Ø130 mm     •    1× ROTO RECORD DH 160×4-II, Ø160 mm Auction-ID: A7-46417-114
