om vertical lathe used for sale

Lead and tension spindle lathe Weiler Matador -Center width: 500 mm -Tip height: 140 mm -Feed range longitudinally over belt: 0.05–0.40 mm/rev -Feed range longitudinally via interchangeable gears: 0.018–0.800 mm/rev - Spindle head: size 5 -Drive: three-phase motor -Speed range: 15–3,550 rpm -Coolant pump -Wedge bar chuck Forkardt F 160 -Quick-change holder Multifix -4 lathe chisel holders -Drill chuck -Moving centering tip Dimensions: LxWxH 1.5x0.6x1.2 meters / Weight 600Kg

turning diameter over bed: 330 mm turning diameter over slide rest: 195 mm turning length: 750 mm center height over bed: 160 mm centre distance: 650 mm digital readout: 3 Achsen HEIDENHAIN bed width: 205 mm spindle bore: 36 mm spindle taper: KK5 DIN 55027 turning speed range: 48 - 2500 U/min power requirement: 3,0 kW 4-jaw-chuck diameter: 160 mm quick change toolholder: MULTIFIX Typ A taper in tailstock-quill: MK 3 dia. of quill: 40 mm quill stroke: 100 mm voltage: 400 V total power requirement: 3,2 kW weight of the machine ca.: 680 kg dimensions of the machine ca.: 1,60 x 0,80 x 1,55 m - Serial-No.: 4432 - HEIDENHAIN 3-axis digital readout - MULTIFIX quick-change tool holder - Collet chuck including collets Ø 8 - Ø 27 mm - Face plate Ø 250 mm - Quick-action drill chuck - Center point The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

turning diameter over bed: 320 mm turning diameter over slide rest: 190 mm turning length: 920 mm center height over bed: 160 mm turning diameter in the gap: 430 mm centre distance: 920 mm bed width: 181 mm digital readout: DPA 2000 3 Achsen spindle bore: Ø 38 mm turning speed range: 10 - 2.500 U/min power requirement: 1,5 kW 3-jaw-chuck diameter: 160 mm taper in tailstock-quill: MK 3 dia. of quill: 32 mm quill stroke: 100 mm voltage: 400 V weight of the machine ca.: 410 kg dimensions of the machine ca.: 1,60 x 0,70 x 1,55 m ! ATTENTION ! EXCELLENT CONDITION ! This machine comes from a vocational school! - Serial No.: 832432 - 3-axis digital display DPA 2000 - Constant cutting speed - Stepless speed control - Digital speed display - RÖHM 3-jaw flat spiral chuck - Face plate Ø 255 mm - Fixed steady rest - Rotating steady rest - Machine light - Rotating center point The data for this  ...

turning diameter over bed: 280 mm turning diameter over slide rest: 150 mm turning length: 500 mm center height over bed: 140 mm centre distance: 500 mm bed width: 205 mm spindle bore: 40 mm turning speed range - stepless: 30 - 4.000 U/min 3-jaw-chuck diameter: 140 mm quick change toolholder: MULTIFIX Typ A drive capacity - spindle motor: 4,0 kW taper in tailstock-quill: MK 3 dia. of quill: 40 mm quill stroke: 85 mm voltage: 400 V total power requirement: 7,5 kW weight of the machine ca.: 800 kg dimensions of the machine ca.: 1,40 x 0,95 x 1,55 m - Serial-No.: 154 - SIEMENS 3-axis digital display - MULTIFIX quick-change tool holder - rotating centering tip The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

turning diameter over bed: 280 mm turning diameter over slide rest: 170 mm turning length: 650 mm center height over bed: 140 mm centre distance: 650 mm bed width: 155 mm spindle taper: KK 4 CAMLOCK DIN 55029 spindle bore: 40 mm turning speed range - stepless: 4.000 U/min 4-jaw-chuck diameter: 140 mm quick change toolholder: MULTIFIX Typ A drive capacity - spindle motor: 7,5 kW taper in tailstock-quill: MK 2 dia. of quill: 30 mm quill stroke: 80 mm voltage: 400 V total power requirement: 7,5 kW weight of the machine ca.: 400 kg dimensions of the machine ca.: 1,30 x 0,70 x 1,60 m - Serial-No.: C7D W13 02 - 3-axis digital display - Stepless speed adjustment - Digital speed display - MULTIFIX quick-change tool holder The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

: neu : 2025 : 010105 : prompt, Zwischenverkauf v : Bulgarien : 50210 € : 863.32 € : 1 : 45200 € : 600 mm : 2000 mm : 300 mm : 80 mm : 400 mm : 400 mm : 8 : 90 MK : 21 : 20 - 2000 1/min : 120 : 0.04 - 12 mm/U : 0.02 - 6 mm/U : 64 : 0.5 - 120 mm : 60 - 1/4 Gänge/ : 0.125 - 30 : 315 mm : 130 mm : 90 mm : 5 MK : 230 mm : 7.5 kW : 3600 mm : 1250 mm : 1400 mm : 3110 kg driven by conventional gearbox 3-axes digital readout Fagor 40i quick change toolpostAmestra Multisuisse type C with 4 holders (3 square, 1 round) 3-jaw chuck Bison3204/DIN6350, Ø 250 mm spindle dead center four way rapid traverse device electromagnetic brake longitudinal stop for 1 position coolant equipment full length rear splash guard leadscrew and shaft protection safety guard for the chuck toolholder guard levelling bolts and plates quick release tailstock low voltage machine lamp operating manual machine accordin ...

Turning diameter over face slide: 200 mm Spindle bore: 32 mm Circumferential diameter over bed slide: 315 mm Tip width: 600 mm Turning length: 560 mm Quill stroke: 140 mm Total weight: 1,750 kg Digital display Heidenhain Collet System E163

The machine is equipped with a tailstock, a Multifix clamping system and a 3-jaw chuck, diameter: 300 mm, incl. two steady rests. Year of Manufacturing: presumable 2018

The machine is equipped with a tool holder, a tailstock, and a 3-jaw chuck, diameter: approx. 310 mm. • centre distance over bed: 300 mm • centre distance over support: 200 mm

Includes a 3-jaw chuck, jaw width: 250 mm, tailstock, Multifix basic holder as well as a 3-axis digital readout and a workbench with matching Multifix tool holders and two jaw chucks, indexable inserts, collets, and milling cutters. Additional technical specifications: • Center height over bed: 200 mm • Center height over support: approx. 110 mm • Center height over cross support: approx. 90 mm

• centre length: 1000 mm • centre height over bed: approx. 250 mm • centre height over support: 150 mm • Incl. steady rest.

The machine is equipped with a tailstock, a Multifix tool post, and a quick-action chuck, including a 3-axis digital readout system manufactured by FAGOR.

The machine is equipped with a tailstock, a Multifix clamping system and a 3-jaw chuck, diameter: 300 mm, incl. two steady rests. Year of manufacturing: presumable 2018

: 0330 mm : 210 mm : 1000 mm : 167 mm : 40 mm : 2,2 kW The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

: gebraucht : 2011 : 010192 : prompt, Zwischenverkauf v : Deutschland : 24100 € : 1 : 320 mm : 650 mm : 160 mm : 40 mm : 192 mm : 205 mm : 5 : 5 MK : 16 : 48 - 2500 1/min : 24 : 0.02 - 0.63 mm/U : 0.006 - 0.2 mm/U : 0.25 - 8 mm : 80 - 2 Gänge/ : 0.2 - 4 : 200 - 5 : 150 mm : 100 mm : 40 mm : 3 MK : 85 mm : 2,4 / 3 kW : 1582 mm : 715 mm : 1245 mm : 720 kg Heidenhain 3-axis digital readout NEW Röhm 3-jaw chuck, 160 mm diameter, with internal and external jaws Quick-change tool post with one rectangular insert and one round insert Quick-release collet chuck with collets from 3 to 29 mm diameter (in 1 mm increments) Live centre Drill chuck Chuck guard Lead and feed screw guard Motor brake Coolant system Mounting feet Operating instructions in German with CE declaration of conformity BUYING USED MACHINERY IS A MATTER OF TRUST - OUR TRANSPARENCY PROMISE We offer you maximum security and com ...

: gebraucht : 1992 : 010190 : prompt, Zwischenverkauf v : 17900 € : 1 : 320 mm : 650 mm : 160 mm : 40 mm : 192 mm : 205 mm : 5 : 5 MK : 16 : 48 - 2500 1/min : 24 : 0.02 - 0.63 mm/U : 0.006 - 0.2 mm/U : 0.25 - 8 mm : 0.2 - 4 : 150 mm : 100 mm : 40 mm : 3 MK : 85 mm : 2,4 / 3 kW : 1582 mm : 715 mm : 1245 mm : 680 kg Heidenhain 3-axis digital readout NEWRöhm 3-jaw chuck, 160 mm diameter, with internal and external jaws Quick-change tool post with one rectangular insert and one round insert Quick-release collet chuck with various collets from 1 to 27 mm Live centre Drill chuck Chuck guard Lead and feed screw guard Motor brake Coolant system Mounting feet Operating instructions in German BUYING USED MACHINERY IS A MATTER OF TRUST - OUR TRANSPARENCY PROMISE We offer you maximum security and complete transparency. • HONEST INSIGHTS: Detailed photos and functional videos of the current cond ...

: gebraucht : 2001 : 010191 : prompt, Zwischenverkauf v : Deutschland : 22100 € : 1 : 320 mm : 650 mm : 160 mm : 40 mm : 192 mm : 205 mm : 5 : 5 MK : 16 : 48 - 2500 1/min : 24 : 0.02 - 0.63 mm/U : 0.006 - 0.2 mm/U : 0.25 - 8 mm : 80 - 2 Gänge/ : 0.2 - 4 : 200 - 5 : 150 mm : 100 mm : 40 mm : 3 MK : 85 mm : 2,4 / 3 kW : 1582 mm : 715 mm : 1245 mm : 720 kg Heidenhain 3-axis digital readout NEWRöhm 3-jaw chuck, 160 mm diameter, with internal and external jaws Quick-change tool post with one rectangular insert and one round insert Quick-release collet chuck with collets from 3 to 30,5 mm Live centre Drill chuck Chuck guard Lead and feed screw guard Motor brake Coolant system Mounting feet Operating instructions in German with CE declaration of conformity BUYING USED MACHINERY IS A MATTER OF TRUST - OUR TRANSPARENCY PROMISE We offer you maximum security and complete transparency. • HONES ...

Equipped with automatic rod loader FMB 3200, length maximum 3200 mm, maximum diameter approximately 23 mm; machine disassembled for transport size 2400x1200x1750 mm and 4700x700x1300 mm; Auction-ID: A1-44050-8

Vertical CNC centre lathe, uses / outdated machine type: Emag VSC 200 control: Siemens 840 C construction year: From the in 1995 to the in 2007 overtakes TECHNICAL DATA: speed area / speeds: [1 / min].: 6,000 Drehmoment:/torque [Nm]: 480 Max dreh-? over bed swing diam .: 290 mms impulse achievement / power: [kW] 34 feed ? / chuck diam. 200 mms revolver / turret: 12-fold, VDI 40, shoemaker powered work witness / driven tools 7.8 kW Verfahrwege: X axis / x-travel: 550 mms Z-Achse/z-travel: 200 mms express way / rapidly travel: (X/Z) [m / min] 30 / 20 prepush / feeds: (X/Z) [m / min]. 11 KN connected load: [KW] 36 kW machine weight: [kg] 6,500 equipment signs: filings sponsor / chip conveyor, crowd

CNC Vertical Lathe VTL with Tool Changer.You Ji GTH-35/45 ATC-I.Year of manufacture 2012.Fanuc 0i-TD CNC Control.Face plate diameter 3500 mm.Hydrostatic table - Load max. 50 t.Swing diameter max. 4500 mm.Turning diameter max. 4000 mm.Turning height max. 2200 mm.Ram cross travel X -1750/+2160 mm.Ram vertical travel Z 1500 mm.Table drive 60/75 KW.Table turning speeds 2 ~ 75 mm.Torque at the table 67330 Nm.Tool magazine with 16 positions.Tool taper 7/24 BT 60.Floor space required 12375 x 8210 mm.Machine height 7920 mm.Full guarding.3-colour signal lamp (tower).AS NEW - 200 run hours !Available immediately.; As new

Table diameter: 2,000 mm Max diameter of workpiece: 3,000 mm Main drive: 60 KW Speed rotation of the table: 2.8 - 162 rpm Max workpiece height under the cross member: 2,500 mm Travel RAM: 1,750 mm Tool magazine: 12 workstations Machine Weight: 35 t Accessories: Grinding spindle and various tool holders 3000 rpm Wheel diameter 250 mm

Machine weight: 20,000 kg Faceplate diameter 1250 mm Number of supports: 1 pcs Dimensions: height 4250 mm width 5630 mm depth of 3550 mm Extras: copying apparatus, turret head on the vertical support Technical condition at the time of sale: Replacement rotary amplifier on thyristor converter. Not operated since 1994 p. Small repair and adjustment of electrical and mechanical parts. The maximum dimensions of a workpiece Height 1150 mm The diameter of 1400 mm Weight 8000 kg

chuck diameter, mm 7100 (8000) Max. work piece diameter, mm 8000 Max. work piece height, mm 3200 Max. work piece weight, kg 125000 Chuck speed, rpm 0,22...20,1 Max. ram movement of vertical support, mm 2000 Max. movement of vertical, mm 4275 Support feed range, mm/min 0,0352...285 Support rapid feed, mm/min 2500 Supports possible work angle, deg. -15...+40 Jaws, units 4 Machine overall dimensions, mm 8615 x 17600 x 9800 Machine weight, kg app. 247300

An Emag vertical CNC lathe is available. Clamping chuck diameter: 250mm, max. circulation diameter: 270mm, max. machining diameter: 250mm, max. machining length: 175mm, speed: 4500rpm, tool positions: 12, tool holder: VDI 40, travel X/Z: 660mm/300mm, rapid traverse X/Z: 60m/30m/min. Machine dimensions X/Y/Z: approx. 4300mm/1600mm/3300mm, weight: approx. 7500kg, control: Fanuc Series 32i-Model A, operating hours: 64137h. Including automatic loading and unloading with pick-up spindle and integrated part diverter and workpiece storage. Documentation available. On-site inspection is possible.

CNC vertical lathe Type: SKJ 12 NC Manufacturer: TOS Modernization: 2002 Control: Mefi CNC 856 Max workpiece diameter: 1400 mm Clamping plate diameter: 1250 mm Maximum workpiece height: 1150 mm Maximum workpiece weight: 6000 kg Clamping plate speed: 2.5 - 225 rpm Main motor power: 37 kW Machine weight: 13000 kg In good condition, fully functional Find more here - .ucymachines/ Contact us at - sales@ucymachines

CNC Vertical Turret Lathe with C axis and live tool 3 Turning Plates Changer (translating pallet system) EQUIPPED WITH: Siemens Sinumerik 840C CNC Control (2015 Retrofit) Vertical Ram with Live Spindle Pallet Changer (3-Pallets) 16-Station Automatic Tool Changer C-Axis Table Year 2005 CNC Siemens 840 C Max. turning dia.: 2200 mm Max. turning height: 1800 mm Ram travel: 1500 mm Main drive: 75 kW Live spindle: 15 kW Spindle rotations: 45- 1350 1/min Max. workpiece weight: 12 000 kg Pallet changer with 3 pallets (turning plates) Tool magazine: Right: 8 turning tools Left: 8 boring/milling tools Feeds: 0,1-6000 mm/min Carriage feed: Vertical: 1500 mm Horizontal: 1320 mm Table rotation (2 ranges): 2,5 – 70 / 10-280 Max. table torque: 50 000 Nm Machine weight: 43 Ton Machine HxWxL: 6,8 m x 10 m x 9,7 m

Dörries Contumat VCE 2000-160Year of manuf. : 1991 Control : Siemens 840 Dsl Turning diam. : 1600 mmTurning length : 1800 mm____________Description:In General:Year of manufacture:1991 / 2010Control system retrofit:2010Control system:Siemens 840 DslCircumferential diameter:2,000 mmTurning diameter:1,600 mmTurning height:1,800 mmTable / Faceplate:Technology:Gear-driven tableSpeed:315 rpmPower:105 kWMax. torque:50,000 NmFaceplate:1,600 mmMax. table load:12,000 kgTool carrier:Crossbeam travel (vertical):1,200 mmChisel slide travel:1,500 mmSupport travel (horizontal):2,300 (+/-1,150) mmPenetration diameter:340 mmChisel slide cross-section:240 x 240 mmEquipment:Tool magazine:20 stationsChip removal:Chip conveyorCoolant supply:Coolant system with filterTool measurement:ProbeSet-up:Electronic handwheelTool holders:Various tool holdersControl system overhaul:Year of overhauling:2010Technol ...

vertical turret lathe, year 2000, CNC 840 C. Used machine. More info & price on IndustrialBuyer.

DÖRRIES SCHARMANN VCE 3000 / 280 CNC Vertikaldrehmaschine Modernisierung: im Rahmen des Retrofits im Jahr 2014 auf Siemens SINUMERIK 840D SL Arbeitsbereich Tischdurchmesser: 2.800 mm Max. Umlaufdurchmesser / Drehdurchmesser: 3.000 mm Max. Tischbelastung: 25.000 kg Max. Drehhöhe: ca. 2.100 mm Verfahrweg X-Achse: ±1.550 mm Verfahrweg Z-Achse / RAM-Hub: 1.500 mm Hauptantrieb und Spindeln Hauptantrieb: Siemens-Hauptmotor Antriebsleistung: 130 kW Max. Spindeldrehzahl: 4.500 min⁻¹ Betriebsart: S6, 40 % Ausstattung: 2 vertikale Spindeln Werkzeugwechsler und Peripherie o    2 automatische Werkzeugwechsler o    Kühlschmierstoffanlage o    Späneförderer o    Ölnebelabsaugung o    2 separate Hydraulikaggregate Betriebsstunden: ca. 12.571 Stunden laut mechanischem Betriebsstundenzähler

CONTROLS   CNC controls FANUC BASIC FUNCTIONS   number of spindles: 1   number of turrets: 1 WORKING RANGE TURNING   turning diameter (max): 220 mm   worpiece length max.: 175 mm MAIN SPINDLE   spindle revolutions (max): 6000 /min X/Z SLIDE   Z-axis travel: 300 mm   X-axis travel: 660 mm ELECTRICAL SPECIFICATIONS   total power consumption: 36 kW   mains voltage: 400 V   mains frequency: 50 Hz DIMENSIONS / WEIGHTS   space requirements -left/right-: 3820 mm   space requirements -front/back-: 2040 mm   total height: 2400 mm   total weight approx.: 6500 kg

Max. turning diameter: 1000mm, max. swing diameter: 1250mm, max. workpiece diameter: 1000mm, max. workpiece length: 850mm, max. workpiece weight: 1000kg, X/Z travel: 1250mm/1000mm, max. speed: 900rpm, feed rate: 14m/min, rapid traverse: 20m/min, spindle nose: DIN 55026 short taper size A15, tool interface: DIN 69880 VDI60 tool holder, spindle diameter at the front bearing: 240mm, control: Siemens Sinumerik 840D. Machine weight: approx. 25t, space requirement: 85m². Equipment: SMW IN-D 1000 chuck, chip conveyor. The machine has no driven tools. Documentation available. Inspection possible by appointment.

CONTROLS   CNC controls SIEMENS BASIC FUNCTIONS   number of spindles: 2   number of turrets: 1   number of c-axes: 2 WORKING RANGE TURNING   turning diameter (max): 100 mm   worpiece length max.: 150 mm MAIN SPINDLE   spindle revolutions (max): 6000 /min TOOL MAGAZINE   number of positions: 12 ELECTRICAL SPECIFICATIONS   total power consumption: 36 kW   mains voltage: 400 V   mains frequency: 50 Hz DIMENSIONS / WEIGHTS   total weight approx.: 7000 kg ATTACHMENTS (TURNING)   hydraulic system: yes   European CE standards: yes Machines in good condition: - Integrated pick-up automation - Two EMAG machines configured in a line are for sale. - A robot destacking unit with 100% parts inspection can also be purchased.

Daewoo Puma V 550Year of manuf. : 2001 Control : Fanuc 18i-T Turning diam. : 730 mmTurning length : 750 mm____________Description:In General:Year of manufacture:2005Control system:Fanuc 18i-TMax. speed:2,000 rpmTurning diameter:730 mmTurning height:750 mmX-axis:390 mmZ-axis:780 mmChuck diameter:600 mmTool turret:8 stationsEquipment:Chip removal:Chip conveyorCoolant supply:Coolant pumpChuck:3-jaw chuck

Daewoo Puma V 550Year of manuf. : 2005 Control : Fanuc 21i-TB Turning diam. : 730 mmTurning length : 750 mm____________Description:In General:Year of manufacture:2005Control system:Fanuc 21i-TBMax. speed:2,000 rpmTurning diameter:730 mmTurning height:750 mmX-axis:390 mmZ-axis:780 mmChuck diameter:600 mmTool turret:8 stationsEquipment:Chip removal:Chip conveyorCoolant supply:Coolant pumpTool measurement:Renishaw tool setterChuck:SMW Autoblok 3-jaw chuck

faceplate diameter:4000 mm swing diameter:4300 mm turning height:2500 mm max. workpiece weight:63 t total power requirement:125 kW weight of the machine ca.:134 t dimensions:6100x10400x8400 mm Used Vertical Turret Lathe with 2 plungers and CNC Siemens 840 table is hydrostatically. Machine equipped with a grinding head. CNC was overhauled in 2000.

faceplate diameter:800 mm power requirement:110 kW weight of the machine ca.:37.000 / total 52.000 t transport measurements machine:5,07 x 2,98 x 3,90 m clamping diameter:800 mm :Ø 800 x 720 mm Tool bore:Capto C6 tools in tool magazin:2 x 80 With C-Axis

faceplate diameter:1600 mm power requirement:80 kW weight of the machine ca.:25 t dimensions of the machine ca.:4,4 x 4,62 m max. workpiece diameter:2000 mm max. diameter of face turning:1800 mm tool taper:ISO50 The machine has been regularly serviced and is in good technical condition. With C-Axis

faceplate diameter:1400 mm swing diameter:2000 mm turning height:1500 mm main drive:80 kW faceplate speeds from - to:1 - 365 U/min milling motor:37 kW ram head dimension:240 x 240 mm max. ram stroke:1250 mm total power requirement:133 kVA weight of the machine ca.:50 t dimensions of the machine ca.:11 x 5 x 6,4 m Machine was overhauled in 2008 by OEM New control CNC SIEMENS 840 D automatic tool changer 72-pcs C-axis with driven tools Angle-, straight tool holders with CAPTO holder Coolant device Chipconveyour

faceplate diameter:1800 mm swing diameter:2000 mm turning height:1170 mm z-axis:1000 mm cross rail adjustment - vertical:800 mm faceplate speeds::2,5 - 280 workpiece weight:12 t feeds:1 - 6000 mm/min max. torque on the faceplate:50000 Nm total power requirement:85 kW weight of the machine ca.:41 t dimensions of the machine ca.:5,6 x 4,8 x 4,6 m Machine retrofit and overhould in 2005 with SIEMENS 840 D powerline control - 6 jaw hydraulic power chuck - tool changer for 12 tools - chip conveyor, coolant attachment, splash housing - various tool holders

faceplate diameter:1000 mm swing diameter:1600 mm turning height:1200 mm main drive:75 kW faceplate speeds from - to:7 - 800 U/min milling motor:25 kW milling head speed:7 - 3000 U/min milling spindle - taper:ISO 50 cross rail adjustment - vertical:800 mm ram head dimension:240 x 240 mm weight of the machine ca.:40 to dimensions of the machine ca.:9 x 7,8 x 6,0 m Machine general overhould in 2004 and equiped with Siemens 840 D control - tool changer rack magazine - C-axis, live tooling, - Transmit function electronical Y-axis - angular milling head - complete splash housing - coolant device, chip conveyor

faceplate diameter:1400 mm swing diameter:2000 mm turning height:1270 mm main drive:80 kW faceplate speeds from - to:1 - 355 U/min max. workpiece weight:6.000 kg milling motor:37 kW milling head speed:7 - 3000 U/min milling spindle - taper:ISO 50 cross rail adjustment - vertical:800 (8 x 100 mm) mm ram head dimension:240 x 240 mm max. ram stroke:1250 mm weight of the machine ca.:50 to total power requirement:133 kVA dimensions of the machine ca.:11 x 5 x 6,4 m Machine general overhould in 2008 and equiped with CNC SIEMENS 840 D control - tool changer for 72 tools - C-axis, live tooling - angular- and straight tool holder head with CAPTO taper - Transmit function - complete splash housing - coolant device, chip conveyor - diverse accessories

faceplate diameter:4000 mm swing diameter:4300 mm turning height:330 mm faceplate turning speed range:1 - 92 U/min workpiece weight:18 t feeds:1 - 4000 mm/min main drive motor:55 kW total power requirement:85 kVA weight of the machine ca.:64 t dimensions of the machine ca.:90, x 7,2 x 5,5 m with CNC SIEMENS 840 D for 4 axis 2 Vertical Supports tool Basic holder chip conveyor

faceplate diameter:4770 mm swing diameter:7000 mm turning height:1000 mm slide stroke:1000 mm workpiece weight max.:100000 kg faceplate turning speed range:2 - 20 U/min feed speeds:1 - 10000 mm/min rapid traverse:10 m/min ram head dimension:250 x 250 mm main drive:100 kW total power requirement:200 kW with CNC SIEMENS 840 D 2 Vertical Supports with toolchanger 12 pockets C-axis and driven tooling SK 50 37 Kw 3000 rpm Chip conveyor and coolant attachment

faceplate diameter:1600 mm swing diameter:1800 mm turning height:1500 mm max. ram stroke:1200 mm faceplate turning speed range -stepless-:2,5 - 250 U/min workpiece weight max.:10.000 kg ram head dimension:240 x 240 mm feed range:1 - 3000 mm/min power capacity:45 kW weight of the machine ca.:20 t modernized and overhauled in 2010 with CNC SIEMENS 840 D 12 positions automatic toolchanger telescopic covers splash guarding chip conveyor coolant attachment diverse toolholders

faceplate diameter:5000 mm swing diameter:6100 mm turning height:2400 mm ram stroke each side:1490 mm ram head dimension:340 x 340 mm max. workpiece weight:100.000 kg total power requirement:100 kW weight of the machine ca.:155 t faceplate turning speed range:0,4 - 50 U/min with 2 axes CNC SIEMENS 840 D

faceplate diameter:1400 mm swing diameter:1470 mm turning height:1325 mm ram stroke range:750 mm adjustment of cross-rail:850 mm max. workpiece weight:12000 kg faceplate turning speed range:4,5 - 224 U/min feed per revolution:0,06 - 8 mm rapid speed:1,8 m/min total power requirement:50 kW weight of the machine ca.:16 t Machine was modernized in 2008 with new electric 2-axes digital readout 5-station turret head autom. swivelling diverse toolholders

Technical data: Turning diameter over bed: 1260 mm Turning diameter at opening: 2700 mm Turning diameter at the pit: 3800 mm Turning diameter via slide: 900 mm Turning length: 4000/5000 mm

Technical data: Diameter over bed: 625 mm Turning length: 1500 mm Diameter via slide: 325 mm Spindle head shape: Cam-Lock Spindle drilling diameter: 105 mm

Wood Turning Lathe Precision device for professional users, with grey cast iron variable speed control high degree of spindle concentricity Spindle can be fixed all 15° LCD speedometer One hand operation of the tailstock and tool rest with quick-release mechanism Voltage: 230V / 50 Hz Engine power: 735W (S1 100%) Tip height: 160 mm Top width: 510 mm Speed ranges: 250-750 m-1, 550-1650 min-1, 1300-3850 min-1 Spindle stock rotation: 180 degrees Headstock thread: M33 DIN800 Morsekonusaufnahme: MK2 / MT2 Quill stroke: 63 mm Weight: 52 kg Dimensions: 1035 x 305 x 449 mm G & HM-D510F

Technical data: The machine is completely overhauled in 2011 with new electrics, new wiring, including new control SIEMENS Sinumerik 840D max. circulating and turning diameter: 2,000 mm max. turning height: 1,500 mm Sheet disc diameter: 1,600 mm max. table load: 11.20 to. Cross-beam adjustment: 1,170 mm
