niles simmons used for sale

Precision three-jaw chuck, chuck, face plate, 3-jaw chuck -DHK: 200x3 -TGL: 30-2333 -Chuck size: Ø 200 mm -Beeks: individually and completely adjustable -interchangeable jaws -Through hole: 55 mm -Rezess: Ø 160 mm -Number: 1x feed available -Price: per piece -Weight: 16 kg

Precision four-jaw chuck, chuck, face plate, 4-jaw chuck -Manufacturer: WMW Niles, four-jaw chuck type DHK-B/8-250x4 -Chuck size: O 250 mm -Passage: O 80 mm -Bolt circle: O 135 mm -Intake: short taper 6 -Weight: 35kg

3-jaw chuck, three-jaw chuck WMW DH-B 200x3x6 ( DH-B200x3x6 ) TGL 30-2332 Outer Ø: 200 mm bolt circle Ø : 133.5 mm bore Ø: 54 mm height with jaws: 140 mm used, tested ! Dimensions: 200 x 200 x 121 mm

Grinding wheel, cup wheel, bench grinder, surface grinder, cylindrical grinder -Manufacturer: Niles, grinding wheel 20 Jot - Inside: Ø 32 mm -Outside: Ø 200 mm -Width: 20 mm -Weight: 1.3 kg

3-jaw chuck, three-jaw chuck, lathe chuck WMW NILES outer Ø: 250 mm bore Ø:80 bolt circle: 180 mm flange: 220 mm height with jaws: 110 mm 2400 rpm with cross cone and camlock D1- 8 inch (stud M 16) 2 set of jaws (1x drill 1x rotary jaw set) 1 chuck wrench Dimensions: 250 x 250 x 195 mm

3- Jaw chuck WMW NILES DHK 200x3 Outer Ø: 200 mm Flange: 155 mm Bore Ø: 60 mm bolt circle: 175 mm Height with jaws: 125 mm feed number: 507 Dimensions: 200 x 200 x 125 mm

Grinding wheel, cup wheel, bench grinder, surface grinder, cylindrical grinder -Manufacturer: Niles, grinding wheel - Inside: Ø 32 mm -Outside: Ø 200 mm -Width: 20 mm -Number: 2x discs available -Price per piece -Weight: 1.4 kg/pc.

Three-jaw chuck, three-jaw lathe chuck -Manufacturer: Rohm, three-jaw chuck Chuck size: Ø 250 mm -Type: DH-B / 8-250 x 3 TGL 30-2332 -Throughout: Ø 40 mm - Hole circle: Ø 171 mm -Shot: short taper 8 -Weight: 24 kg

3-jaw chuck, three-jaw chuck, lathe chuck WMW NILES DH-B 315 x 3 x 6 outer Ø: 315 mm Bore Ø: 100 mm Height with jaws: 130 mm bolt circle: 33 / 290 mounting: M14 3 jaws extra Speed max.: 1800 rpm min. 20-240 mm max. 75-240 mm complete with inner and outer jaws Dimensions: 315 x 315 x 150 mm

Face plate diameter: 1.250mm Center height above foundation slab: 1,250mm Weight: 19t Power: 55Kw Max. torque on the face plate: 31,500Nm Maximum workpiece mass between centres: 16,000 kg Speed range: 2.24 – 224 rpm

Three-jaw chuck, three-jaw lathe chuck, 3 jaw chuck -Chuck size: Ø 160 mm -DKRD Ø: 160 mm -Weight: 15.5 kg

Three-jaw chuck, three-jaw lathe chuck, 3 jaw chuck -Chuck size: Ø 160 mm -TGL: 30-2312 -Weight: 11.2 kg

Three-jaw chuck, three-jaw lathe chuck, 3 jaw chuck -DH: 200x3-III -TGL: 30-2332 -Chuck size: Ø 200 mm -Weight: 16.7 kg

Three-jaw chuck, three-jaw lathe chuck, 3 jaw chuck -DH: B200x3x6 -TGL: 30-2332 -Chuck size: Ø 200 mm -Cone: Ø 104 mm -Hole circle: Ø 132 mm -Through hole: Ø 54 mm -Weight: 15 kg

Three-jaw chuck, three-jaw lathe chuck -Chuck size: Ø 315 mm -Passage: Ø 104 mm -Weight: 44 kg

Three-jaw chuck, three-jaw lathe chuck, 3 jaw chuck -Fucking size: Ø 200 m -Through hole: Ø 54 mm -Weight: 12 kg

Three-jaw chuck, three-jaw lathe chuck, 3 jaw chuck -Chuck size: Ø 250 mm -Rezess: Ø 210 mm -Throughout: Ø 80 mm -Weight: 20.7 kg

Wedge bar chucks, three-jaw chucks, three-jaw lathe chucks, power chucks -Chuck size: Ø 250 mm -Short taper: 8 -Thread: M30 -Pitch: 1.5 mm -Weight: 38.5 kg

Three-jaw chuck, three-jaw lathe chuck, 3-jaw chuck -Chuck size O 200 mm -Through hole O 54 mm -Short cone 6 -according to pictures, without additional accessories -Weight 14.4kg

Three-jaw chuck, three-jaw lathe chuck -Type: DH315x4-III/TGL 30-2332 -Chuck size: Ø 315 mm -Passage: Ø 98 mm -Rezess: Ø 264 mm -Weight: 32 kg

Three-jaw chuck, three-jaw lathe chuck, 3 jaw chuck -Chuck size: Ø 250 mm -Short taper: 6 -Throughout: Ø 80 mm -Weight: 25.9 kg

Three-jaw chuck, three-jaw lathe chuck, 3 jaw chuck -Fucking size: Ø 200 m -Through hole: Ø 54 mm -Short taper: 5 -Hole circle: 105 mm -Weight: 16.2 kg

Three-jaw chuck, three-jaw lathe chuck, 3 jaw chuck -Chuck size: Ø 200 mm -Thread recording -Through hole: Ø 53 mm -Weight: 19.7 kg

Three-jaw chuck, three-jaw lathe chuck, 3 jaw chuck -Chuck size: Ø 200 mm -Short taper mount for: bayonet mount -Cone size: 6 -Cone: Ø 106 mm -Hole circle: Ø 133.4 mm -Through hole: Ø 54 mm -Weight: 15 kg

Three-jaw chuck, three-jaw lathe chuck, 3 jaw chuck -Chuck size: Ø 250 mm -recess recess: Ø 210 mm -Through hole: Ø 80 mm -Weight: 18 kg

Two-jaw chuck, 2 jaw chucks, vice, face plate -Chuck size: Ø 200 mm -centrically exciting: -Passage: Ø 54 mm -Weight: 15 kg

Three-jaw chuck, three-jaw lathe chuck -Chuck size: Ø 250 mm -one set: hard interchangeable jaws -Passage: 81 mm -Rezess: Ø 210 mm -Hole circle: Ø 230 mm -Weight: 19 kg

Four-jaw chuck, four-jaw lathe chuck, 4 jaw chuck -Type: DH250x4/TGL30-2332 -Chuck size: Ø 250 mm -Throughout: Ø 80 mm -Rezess: Ø 210 mm -Hole circle: Ø 230 mm -Number: 3x available -Price: per piece -Weight: 18 kg

Swivel lining, 3- cheek lining -Type: DHB 200x3x5 TGL 30 2332 -Feed size: Ø 200 mm -Passage: Ø 54 mm -max.: 3000 Rpm -Short cone recording: Ø 105 mm -Weight: 24 kg

Three-jaw chuck, three-jaw lathe chuck, 3 jaw chuck -Chuck size: Ø 250 mm -Cone: Ø 139 mm -Hole circle: Ø 170 mm -Through hole: Ø 80 mm -Weight: 24 kg

turning diameter: 850 mm turning length: 6100 mm control: Siemens type: 840 D turning diameter over slide: 570 mm Tool changer: 12 Pos turning speeds: U/min chip conveyor: 3-jaw-chuck diameter: 600 mm total power requirement: kW weight of the machine ca.: 17 t dimensions of the machine ca.: 12x2x2,8 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Parallel Lathe WMW NILES type DLZ 500 IV L 1000 Between points: 1000 mm Maxi Ø on bench: 500 mm Maxi Ø over saddle: 300 mm Spindle diameter: Ø 50 mm Spindle speed: from 28 to 1400 RPM 3-jaws chuck Ø 200 mm Threadings: Metric + Whitworth Tailstock CM4 Auto Feeds transverse + longitudinal + rapid Lubricant pump Voltage: 380 V Dimensions (L x W x H): 3000 x 1400 x 1500 mm Weight: approx 2,5 T

Niles brand german mali borverk bench x : 1600 mm y : 1600 mm z : 1800 mm Turntable works flawlessly. gear sets bronze nut all maintenance is done. It has an opening mirror. counter bed is available. The opposite bed was sandblasted and painted for cleaning. it is well maintained. There is no non-working place in the electrical unit. the machine is about 20 tons 11 tons of material was processed on the table before. By producing the apparatus, it can be processed with a chuck that opens pipes up to q 1800 mm diameter. gasket surface can be opened to flanges.

WMW Niles DLZ Ø 630 x 2000 mm Distance between centers: 2000 mm Swing over bed: 630 mm Swing over cross-slide: 400 mm Swing in gap: 720 mm Diametre of main spindle bore: 72 mm Power on main spindle: 19 kW Number of speeds: 28 > 1400 rpm Total power needed: 220V Weight: 4,8 ton

turning diameter: 800 mm turning length: 4500 mm control: Siemens workpiece weight: 4000 kg Revolutions milling spindle: 1-5500 U/min milling spindle: HSk 100 type: 840 D positioning accuracy: 0,01 ° Torque: 3000 Nm transmission ratio: 2 turning speeds: 2430 U/min main drive: 77 kW steady: SMW Diameter: 140-510 mm coolant capacity: 980 l coolant pump: 80 Bar paper filter: 3-jaw-chuck diameter: 610 mm tail stock: Tool changer: swing diameter: 1100 mm total power requirement: kW weight of the machine ca.: 52 t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Niles Form wheel generating gear grinder Model ZSTZ 630 C2 s/n 40/21 - 26 This universal gear grinder is perfect for a job shop location the machine is a single wheel form grinding machine for spur and Helical external gear grinding . Machine specifications as follows: Max Diameter gear (Tip circle Diam) 630 mm / 24" Max root circle Diameter 50 Number of teeth 5- 140 module 1- 12 Max Helix Angle 45 Face width 215 mm Rotary Table load 400 Kg grinding wheel diameter 270-350 mm grinding wheel angle degrees 14-26 grinding wheel peripheral speed m/s 30 total connected load 8.5 Kva machine weight 6.3 Kg Machine dimensions 3.8 x 3.3 x 2.3 Meters tall Machine is equipped with the following electrical cabinet machine wheel dresser coolant filtratio ...

turning diameter:480 mm turning length:1250 mm control:H 645 weight of the machine ca.:8 t dimensions of the machine ca.:5 x 2 x 2 m centre distance:1580 mm swing over bed:495 mm swing diameter:üb.Querschlitten ca.350 mm working area:1600 mm control:H645 connected load:50 kW

control: Numeriksteuerung CNC 700 K total power requirement:28 KVA weight of the machine ca.:7,8 t dimensions of the machine ca.:6610 x 2280 x 2235 mm work height max.:1060 mm greates pass round over bed:305 mm spindle bore:82 mm Documents:vorhanden

turning length:630 mm total power requirement:16 kW weight of the machine ca.:5 t dimensions of the machine ca.:3400 x 1500 x 1600 mm swing diameter over slide rest:Hinterdrehschlitten 250 mm centre height:über Hinterdrehschlitten 150 mm center height over bed:300 mm turning spindle:Kopf DIN 55021 Gr. 8 centre distance:1000 mm accessories::2 Schränke Wechselräder

turning diameter:810/680 mm turning length:2.500 mm centre distance:3.040 mm swing diameter over bed slide:530 mm spindle bore:145 mm turning speed range:10 - 2.000 1/min spindle drive:76 / 63 kW turret (x-stations):12 Pos. tool taper:VDI 60 Torque:1150 / 4005 Nm rapid travel range:X12 / Z12 m/min max. workpiece weight between centers:4.000 kg max. workpiece weight -without tailstock:630 kg total power requirement:140 kVA weight of the machine ca.:17,6 t dimensions of the machine ca.:7,7 x 2,85 x 2,7 m CNC-lathe with tailstock - live tools 12 / 8 kW (85 / 105Nm), - spindle 2,5° indexing, - steady 50 -200mm, - hydr. 3-jaw-chuck, - chipconveyor, coolant device, - tailstock, tailstock quill: - MT 5, - dia. 160mm, - stroke 285mm,

turning diameter:300 mm swing diameter:350 mm turning height:275 mm x-axis:925 mm z-axis:250 mm clamping chuck diameter:200 mm Feed speed:30 m/min. total power requirement:45 kW weight of the machine ca.:7 t Machine was used just from time to time in the last years - very good condition! with CNC SIEMENS 840 D 12-station turret head with driven toolings workpiece in and out conveyor belt coolantattachment and chip conveyor diverse accessories

Technical data: Double column vertical turret lathe CNC control Siemens 802 D Weight 66 to 63 kw Dimensions 13,600 x 9,800 x 6,750 mm Faceplate diameter 3,500 mm Maximum workpiece height 2000 mm Max support adjustment 30 ° Maximum workpiece diameter 4,000 mm Maximum workpiece diameter with page support 3,750 mm Number of support 2 Max turning height 1,400 mm Maximum workpiece weight 25 to Max speed 30/min Min. speed 1/min
