muhr bender mubea used for sale

Max. punching force: 700 kN Projection: 510 mm Cuts on flat steel shears 500 x 18 mm Punches e.g. 30 mm diameter in 20 mm flat bars Quick-change device Assortment of tools is included in the price Weight: 3,000 kg

: 100 t diameter: 40 mm throat: 760 mm total power requirement: 8,5 kW weight: 3.600 kg Accessories / equipment: - punching table The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Offer 23294 Specifications: - Flat steel shears - knife length 470 mm - for flat material 450 x 15 mm - or 300 x 20 mm - Sectional steel shears - L- steel at 90° 140 x 13 mm - at 45° 70 x 7 mm - T-steel at 90° 70 mm - Bar steel shears - round steel 50 mm - Square steel 42 mm - Notching device - rectangular notching 52 x 90 x 12 mm - Punch punch - punching force approx. 750 KN - - Infinitely variable stroke 0 - 70 mm - Perforates in steel up to 30 mm Ø in 20 mm - Projection 310 mm - Hydraulic drive 400 V / 7.5 kW - Space requirement approx. W 1600 x H 1850 x D 1400 mm - Weight approx. 2400 kg - With: - 2 E. foot switches for two separate workstations - Slewing ring

Specifications: Weight approx. 3 to Drive power 8.5 kW Height approx. 2.1 m Width x depth approx. 2 x 0.8 m Perforated punch 700 kN, projection 510 mm, punches 30 mm in max. 20 mm Flat steel shears : 500 x 18 mm Notching device with rectangular tool up to 13 mm Sectional steel shears, L-steel, 90° mm

Punching force: 750 kN (punches e.g. 30 mm in 22 mm material), with search device via foot switch for punching Projection: 320 mm Cuts 450 x 15 mm or 300 x 20 mm on flat steel shears Support table on the punching side Two separate foot switches for the punching and shearing side, so that independent punching and shearing can be carried out Assortment of tools is included in the price

for sheet thickness up to: 8 mm Flat Plate: 80 x 12 mm Square bar: 20 mm Round bar: 18 mm Weight approx.: 88 kg Dimensions: 620 x 250 x 380/880 mm high (with/without base)

Punching force: 550 kN (e.g. punches 30 m in 16 mm material), with search device via foot switch for punching Cuts 350 x 13 mm or 230 mm on the flat steel shear Projection: 305 mm Two separate footswitches for the punching and shearing side, so punching and shearing can be done independently Support table on the punching side Range of tools is included in the price

Punching force: 400 kN (holes e.g. 20 m in 15 mm steel) Cuts 150 x 10 mm on the flat steel shear Foot switch for stroke release Support table on the punching side Quick-change device Range of tools is included in the price

Max. punching force: 500 kN Projection: 610 mm Includes an assortment of stamps and dies Weight: 1700 kg

Linear rail with folding cam Height-adjustable for mounting on hole punches

Max. punching force: 700 kN Projection: 510 mm Cuts on flat steel shears 500 x 18 mm Holes e.g. 30 mm diameter in 20 mm flat bar Support table on the punching side with stops Range of tools is included in the price Weight: 3,000 kg

round bar steel: 30 mm square edge steel: 28 mm L-beam: 90 x 8 mm : 150 x 8 mm pressure: 35 t total power requirement: 2,8 kW weight of the machine ca.: 0,5 t dimensions of the machine ca.: 0,75 x 1,0 x 1,5 m Profile steel shears combined with: - Foot switch - Length cut The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

round bar steel: 33 mm square edge steel: 30 mm L-beam: 60 x 8 mm hole diameter in sheet thickness: 20 in 13 mm hole punhing press: pressure: 35 t hole punching press: throat: 320 mm hole punching press: max. length of stroke: 24 mm hole punching press: capacity (dia. x thick.): 28 x 10 mm hole punching press: capacity (dia. x thick.): 23 x 12 mm total power requirement: 1,5 kW weight of the machine ca.: 1,7 t dimensions of the machine ca.: 1,5 x 0,7 x 1,8 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

hole diameter in sheet thickness: Ø 30 in 12 mm hole diameter in sheet thickness: Ø 19 in 19 mm pressure capacity max.: 45 to weight of the machine ca.: 1.700 kg dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

sheet width - max.: . mm plate thickness: . mm total power requirement: . kW weight of the machine ca.: . t dimensions of the machine ca.: . m Blade length 300 mm The technical data are manufacturer or operator specifications and therefore not binding for us. We reserve the right to prior sale, only our business and sales conditions apply.About usmore than 400 own machines in stockover 12000 m² storage area, crane capacity 70 tmore than 1000 articles accessories for your workshopYou want to sell machines production lines or your company, then contact us. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

sheet width: 170 mm plate thickness: 0 mm number of rolls: 0 weight of the machine ca.: 0,1 t Please note: The machine is dismantled and ready for loading. It is not possible to show it under power or make a video. Our offer includes already the best pictures. So we don’t have and won’t send additional pictures. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Used for the horizontal winding of profiles, includes control cabinet with main switch of the system, infeed roller conveyor with movable side stop, pneumatically operated lifting device, control panel with emergency stop button, winding unit with height adjustment, outfeed roller conveyor. Connected load: 2.5kW, length: 16,060mm, width: 2485mm, height: 1900mm. With documentation, on-site inspection is possible.

sheet width: 400 mm plate thickness: 4 mm weight of the machine ca.: 0.3 t dimensions of the machine ca.: 0.5x1x2.2 m www.marcels-maschinen.ch The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

round bar steel: div mm square edge steel: div mm L-beam: div mm No. 2984: 1 used plate, profile and bar shear with notcher 50 to manufactured by PEDDINGHAUS, type 210 / 13 Standard, built 1965 No. 3418: 1 used combined section shear 80 tonnes manufactured by PEDDINGHAUS, type 210 Super 16, built ca85 Cuonnbjt0a No. 3668: 1 used steel section shear + punching machine 95 to PEDDINGHAUS, type 210 Super 20, year of construction 1978 Space requirement 2.20 x 1.00 x 2.35 m, weight approx. 4.5 tonnes No. 3286: 1 used steel profile shear 65 to MUBEA / MUHR & BENDER, type KBL 16 N No. 1096 1 used hole punch 26 to EDEL SMO 26, various accessories The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

plate thickness: 6 mm blade length: 300 mm cutting width at round material: 13 mm cutting width at rectangle material: 70 x 6 mm total power requirement: - kW weight of the machine ca.: 0,03 t dimensions of the machine ca.: 0,5 x 0,16 x 1,16 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Max. punching force: 700 kN Projection: 510 mm Cuts on flat steel shears 500 x 18 mm Holes e.g. 30 mm diameter in 20 mm flat bar Range of tools is included in the price Weight: 3,000 kg

Punching force: 500kN, throat depth: 610mm, stroke: 60mm, max. hole diameter in steel thicknesses 15mm/9mm/4.5mm: 30mm/50mm/100mm, max. material thickness: 15mm. Machine dimensions X/Y/Z: approx. 1100mm/1550mm/1750mm, weight: approx. 1650kg. An on-site inspection is possible.

Punching force: 400 kN (holes e.g. 20 m in 15 mm steel) Cuts 150 x 10 mm on the flat steel shear With pipe notch on the steel bar shears Foot switch for stroke release Support table on the punching side Quick-change device Range of tools is included in the price

Punching force: 300 kN For example, punches a 20 mm hole in 12 mm steel Stroke release via foot switch Range of tools is included in the price

pressure: 40 t throat: 175 mm work height max.: 1055 mm stroke: 30 mm sheet thickness - max.: 8 mm total power requirement: 4 kW weight of the machine ca.: 1020 kg dimensions: 910 x 670 x 1930 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

sheet width - max.: 300 mm plate thickness: 8 mm flat steel: 80 x 10 mm blade length: 300 mm machine length: 860 mm machine height: 565 mm weight of the machine ca.: 172 kg Long measuring shear Machine dealer with own stock of 1600 m². The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

pressure: 50 t throat: 610 mm total power requirement: 7,5 kW machine weight ab.: 1700 kg dimensions: 1500 x 650 x 1700 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Punching force: 350 kN (holes e.g. 23 m in 12 mm material) Cuts 150 x 10 mm on the flat steel shear Two separate footswitches for the punching and shearing side, so punching and shearing can be done independently Support table on the punching side with stop cam Range of tools is included in the price

round bar steel: 33 mm square edge steel: 30 mm L-beam: 60 x 8 mm hole diameter in sheet thickness: 20 in 13 mm hole punhing press: pressure: 35 t hole punching press: throat: 320 mm hole punching press: max. length of stroke: 24 mm hole punching press: capacity (dia. x thick.): 30 x 9 mm hole punching press: capacity (dia. x thick.): 20 x 13 mm total power requirement: 1,5 kW weight of the machine ca.: 1,7 t dimensions of the machine ca.: 1,5 x 0,7 x 1,8 m Profile steel shear with: - Hole punch - Notcher - Foot switch - Machine light - Mounted on a trolley The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

A hydraulic profile-steel/universal steel shear with integrated punching unit Muhr & Bender is available. Punching force: 500kN, punching capacity for 15mm steel: 25mm, punching stroke: 60mm, stroke rate: 47/min, throat depth: 750mm, installation height: 215mm, working height: 1150mm, flat-steel cutting capacity X/Y: 180mm/20mm. Machine dimensions X/Y/Z: approx. 1500mm/900mm/1900mm, weight: approx. 2000kg. Includes various round and slotted punches with dies. An inspection on site is possible.

Punching force: 1000 kN Projection: 760 mm For example, punch a 40 mm hole in 22 mm steel Stroke release via foot switch Quick-change device Range of tools is included in the price 3000 kg

Punching force: 560 kN For example, punches a 30 mm hole in 15 mm steel Stroke release via foot switch Range of tools is included in the price

pressure: 100 t throat: 620 mm stroke: 0-100 mm hole diameter in sheet thickness: 40 in 20 mm no. of strokes: 49 Hub/min Control: total power requirement: 15 kW weight of the machine ca.: 3.500 kg The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Profile steel shears, profile shears, punch, punching machine, hole punch, hydraulic flat/profile and bar steel shears -Manufacturer: Mubea, hydraulic profile steel shears type HPSN 350 -Drive: hydraulic -Pressure force: 35 tons -Equipment: large support table with stops for punching -Punching -scissors -Cut -Notch -various punches and dies -Dimensions: 1460/1700/H1690 mm -Weight: 1080kg

Section steel shears, profile shears, punch, punching machine, hole punch -Pressure force: 29 to -Punching: -Scissors: -to cut: -not: -mechanical release: -div. Punches and dies: -Length stop: -Installation dimensions: 1300/1570/H1900 mm -Transport dimensions: 1300/770/H1900 mm -Weight: 1112 kg

Hand lever shears, long-blade sheet metal and round steel shears, lever shears -Manufacturer: Mubea, sheet metal and round steel shear type 3/5 R -Cutting insert length: 200 mm -Steel sheet: up to 8 mm -Lift-down device: -Overall dimensions: 385/160/H1280 mm -Transport dimensions: 960/160/H390 mm -Weight: 22 kg

Hand lever shears, long-blade sheet metal and round steel shears, lever shears -Manufacturer: Mubea, sheet metal and round steel shear type 3S / 6 R -Cutting insert length: 200 mm -Steel sheet: up to 6 mm -Flat/strip iron: up to 70x7 mm -Round steel: up to 13 mm -Cutting capacity: see photo of the nameplate -Lift-down device: -Overall dimensions: 385/160/H1500 mm -Transport dimensions: 1160/160/H400 mm -Weight: 24 kg

Hand lever shears, long-blade sheet metal and round steel shears, lever shears -Manufacturer: Mubea, sheet metal and round steel shear type 3/5 R -Cutting insert length: 200 mm -Steel sheet: up to 5 mm -Flat/strip iron: up to 60x6 mm -Round steel: up to 13 mm -Cutting capacity: see photo of the nameplate -Overall dimensions: 380/160/H1310 mm -Transport dimensions: 970/160/H470 mm -Weight: 23 kg

Hand lever shears, long-blade sheet metal and round steel shears, lever shears -Manufacturer: Mubea, sheet metal and round steel shears -Cutting insert length: 150 mm -Round steel: up to 12 mm -Lever arm: with safety spring -Lift-down device: -Overall dimensions: 320/120/H1260 mm -Transport dimensions: 990/120/H310 mm -Weight: 12 kg

Hand lever shears, long-blade sheet metal and round steel shears, lever shears -Manufacturer: Mubea, sheet metal and round steel shears -Cutting insert length: 200 mm -Round steel: up to approx. 20 mm -Rectangular profile: up to approx. 19x19 mm -Lever arm: with rack and pinion transmission -Overall dimensions: 455/170/H1540 mm -Transport dimensions: 1230/170/H440 mm -Weight: 49 kg

Hand lever shears, long-blade sheet metal and round steel shears, lever shears -Manufacturer: Mubea, sheet metal and round steel shears -Cutting insert length: 200 mm -Steel sheet: up to 7 mm -Flat/strip iron: up to 100x9 mm -Round steel: up to 20 mm -Rectangular profile: up to 18x18 mm -Lever arm: with rack and pinion transmission -Overall dimensions: 540/180/H1570 mm -Transport dimensions: 1250/180/H490 mm -Weight: 44 kg

Die cutter, punching machine, punching device, hole punching machine, hole punch, copy punch, stop punch, hole punch, eccentric punch, row hole punch, punching machine, punch press -Manufacturer: Mubea, punch type KL 100 with 2-axis digital display -Pressure capacity: 100 tons -Punching performance: see photo nameplate -Projection: 535 mm -Material table: 1240 x 615 mm -Travel: x= 1100 mm / y= 600 mm -Digital display: Heidenhain 2-axis digital display -Accessories: incl. see photos -Total dimensions: 2200/2020/H2110 mm -Weight: 3145 kg

Profile steel shears, profile shears, punch, punching machine, hole punch, hydraulic flat/profile and bar steel shears, punching and notching machine -Manufacturer: Mubea, profile steel shear punching and notching machine type HIW 600 -Pressure force: 60 to -Applications: punching, shearing, cutting, notching -Punching: Throat depth 260 mm -Accessories: incl. punching tool, see photos -Dimensions: 1470/960/H2140mm -Weight: 1283 kg

Punch, punching machine, punching device, hole punching machine, hole punch, copy punch, stop punch, hole punch, eccentric punch, row hole punch, punching machine, punching press -Manufacturer: Mubea, hole punch type KL 100 -Printing capacity: 100 tons -Punching capacity: see photo type plate -Thrust: 500 mm -Accessories: incl. see photos -Dimensions: 1460/880/H2100 mm -Weight: 2660 kg

Profile steel shear, profile shear, punch, punching machine, hole punch, hydraulic flat/profile and bar steel shear -Manufacturer: Mubea, hydraulic profile steel shear type HIW1000 -Drive: hydraulic -Pressure force: 100 tons -Equipment: large support table with stops for die-cutting, various stamps and dies -Production: Punching, shearing, cutting, notching -Dimensions: 2360/760/H1800 mm -Weight: 2700 kg

Offer 23145 Technical data: - Flat steel shears - blade length 420 mm - For flat material 400 x 15 mm - Profile steel shears - no knives available - L-steel at 90° 110 x 10 mm - at 45° 65 x 8 mm - T-steel at 90° 90 x 10 mm - Steel bar shears - no knives available - Round steel / square steel 35 / 32 mm - Notching device - for material up to 12 mm - Triangle notch T 60 mm - Hole punch - punching force approx. 500 KN - - Stroke infinitely variable 0 - 40 mm - Punches in steel up to 30 mm Ø in 15 mm - Projection 410 mm - Hydraulic drive 400 V / 7.5 kW - Space requirement approx. W 1400 x H 1800 x D 700 mm - Weight approx. 1800 kg - with: - various punches + dies - Support stop table - Triangular notching device - 2 St. E. footswitches

Offer 23145 Technical data: - Flat steel shears - blade length 420 mm - For flat material 400 x 15 mm - Profile steel shears - no knives available - L-steel at 90° 110 x 10 mm - at 45° 65 x 8 mm - T-steel at 90° 90 x 10 mm - Steel bar shears - no knives available - Round steel / square steel 35 / 32 mm - Notching device - for material up to 12 mm - Triangle notch T 60 mm - Hole punch - punching force approx. 500 KN - - Stroke infinitely variable 0 - 40 mm - Punches in steel up to 30 mm Ø in 15 mm - Projection 410 mm - Hydraulic drive 400 V / 7.5 kW - Space requirement approx. W 1400 x H 1800 x D 700 mm - Weight approx. 1800 kg - with: - various punches + dies - Support stop table - Triangular notching device - 2 St. E. footswitches

Defective. Auction-ID: A1-45188-144

Output: 610mm, Stroke: 60mm, Capacity: Ø 30mm in 15mm, Ø 50mm in 9mm, Ø 100mm in 4.5mm steel, including 1 case with various punch accessories.

Defective.
