Swivelling groove table Swivel range 80° Table area 600 x 200mm Auction-ID: A7-49782-654
Key data: 318 t, 318
Parotec Slot Plate Pallet Power Grip 160 Stitch Partool Zero Point Clamping System Very good used condition. the dimensions can be found in the pictures. Weight approx. 30kg. There are other Parotec accessories in stock More used interchangeable plates, one face plate D.52cm You will receive an invoice in paper form. For this item, VAT (19 percent) is shown on the invoice.
Rotary table disc conveyor 1700-1600-Ø1500 with ejector 1330-100 RA2025 Technical data rotary table: Length table: 1700 mm width table: 1600 mm diameter turntable: 1500 mm Overall height: 100 mm Adjusted table height: 790 mm, can be moved down to 590 mm Electrical data SEW motor: 380-415 V, 0,37 kW Electrical data drum motor: 24V Technical data diverter: Length/ belt length: 1330 mm belt width: 100 mm overall height: 840 mm Electrical data: 380-415 V, 0,25 kW Included in delivery: Turntable with feet Side guide Ejector with stand Optional: Light barriers 24V power supply for drum motor control cabinet/control Prices net plus VAT ex central warehouse Dr. Sonntag GmbH & Co KG, 97076 Würzburg, Germany Features: Electric data: 0,25 kW, 0,37 kW, 24 V, 380-415 Rotating plate diameter: 1500 Overall length in mm: 1700 Nominal / outside width in mm: 1600 Conveying length in mm: 1330 Belt width ...
Specifications Table diameter 3,400 mm Total height approx. 1,230 mm Centering bore Ø 250H7X 25 mm Permissible transport load 20,000 kg Holding torque of the table clamping 2,400 daNm Table speed 0.002 – 2 min Net weight approx. 22,000 kg Operating voltage 380 V, 50 Hz. 3 phases Control voltage 24V Positioning accuracy (without control errors) ± 1" Plan accuracy 0.02 mm Axial running accuracy 0.01 mm Concentricity deviation of the centering bore 0.01 mm Resolution of the displacement measuring systems 0.0001°
Swivelling groove table Swivel range 45° Table area 400 x 390mm Auction-ID: A7-49782-650
Prepared for CNC control Siemens 840 DSL Precision turntable make EIMELDINGEN with aerostatic axial bearings Specifications Table diameter 5,600 mm Total height approx. 1,230 mm Centering bore Ø 250H7X 25 mm Permissible transport load 30,000 kg Holding torque of the table clamping 2,400 daNm Table speed 0.002 – 2 min Net weight approx. 30,000 kg Operating voltage 380 V, 50 Hz. 3 phases Control voltage 24V Positioning accuracy (without control errors) ± 1" Plan accuracy 0.02 mm Axial running accuracy 0.01 mm Concentricity deviation of the centering bore 0.01 mm Resolution of the displacement measuring systems 0.0001°
Key data: 1180 mm, 990 mm, 765 mm
Heavy welding and clamping table 1,180 x 990 mm Height 765 mm Clamping groove width 34 mm Material thickness 40 mm Weight approx. 1,020 kg
Rail guide table, linear unit with drive REXROTH THK LM GUIDE ACTUATOR KR stroke approx. 500 mm table: 105 x 55 mm top table: 90 x 80 x 35 mm Drive: REXROTH INDRAMAT MKD041B-144-KG0-KN New !' Dimensions: 1010 x 120 x 90 mm
used
GeneralUniversal Milling Machines; Control: DMG MORI SLIMline® Multi-Touch control Working area 1Longitudinal500 mmCross450 mmVertical400 mmTechnical DataFeed rate longitudinal/transverse/vertical30000/30000/30000 mm/minRapid traverse longitudinal/transverse/vertical30/30/30 m/minFloor space/WeightDimensions (L x W x H)3,15 x 2,86 x 2,71 (4,82 x 4,16 x 2,71) mWeight approx.5000 KgSwivel Rotary Table Powered B/C AxesSwivel Rotary Table Powered B/C Axes with automatic hydraulic clamping Electronic angle indication (B&C Axes) and Working Plane transformation For positioning only!Type of Measuring system Direct measuring systemMode for positioning only5. Axes (swivelling range) -5/+110 x 0,001 degree4. Axes (swivelling range) 360 x 0,001 degreeDistance between T-Slots 63 mmNumber of Slots 7Slot width 14 mmMaximum load (table centre) 200 KgTable surface Ø 630 x 500 mmDirect measuring system ...
Rail guide table, linear unit BAHR EL60 stroke approx. 960 mm table: 152 x 67 mm used, tested ! Dimensions: 1250 x 170 x 80 mm
Rotary table, rotatable and swivelling WMW Ø 450 mm swivel 360° x 90° groove width: 14 / 25 mm Foot size: 400 x 500 mm used ! Dimensions: 860 x 800 x 400 mm
used
GeneralUniversal Milling Machines; Control: 3D-control Heidenhain TNC 620 Working area 1Longitudinal500 mmCross450 mmVertical400 mmTechnical DataFeed rate longitudinal/transverse/vertical30000/30000/30000 mm/minRapid traverse longitudinal/transverse/vertical30/30/30 m/minFloor space/WeightDimensions (L x W x H)3,15 x 2,86 x 2,71 (4,14 x 4,16 x 2,71) mWeight approx.5000 KgSwivel Rotary Table Powered B/C AxesSwivel Rotary Table Powered B/C Axes with automatic hydraulic clamping Electronic angle indication (B&C Axes) and Working Plane transformation For positioning only!Type of Measuring system Direct measuring systemMode for positioning only5. Axes (swivelling range) -5/+110 x 0,001 degree4. Axes (swivelling range) 360 x 0,001 degreeDistance between T-Slots 63 mmNumber of Slots 7Slot width 14 mmMaximum load (table centre) 200 KgTable surface Ø 630 x 500 mmDirect measuring system X,Y,ZDire ...
Welding table, straightening table, straightening plate, work table, clamping table measuring table FEINMESSZEUGFABRIK SUHL measuring range: 160 mm projection: 100 mm working surface: Ø 100 mm working height: 125 mm solid design, with dial gauge ! used, tested !' Dimensions: 210 x 270 x 420 mm
Measuring table, measuring plate with measuring column and dial gauge holder PAGUS measuring range: 180 mm working surface: 125 x 125 mm working height: 54 mm projection: 140 mm in wooden box New ! still preserved ! Dimensions: 310 x 250 x 160 mm
Rotary table DSZ MKA 250 Ø 250 mm table height: 115 mm groove width: 14 / 20 mm Dimensions: 340 x 410 x 150 mm
Welding table, straightening table, straightening plate, work table, clamping table measuring table FEINMESSZEUGFABRIK SUHL measuring range: 160 mm projection: 100 mm working surface: Ø 100 mm working height: 125 mm solid design ! with dial gauge and second work surface ! used, tested ! Dimensions: 210 x 270 x 420 mm
Welding table, straightening table, straightening plate, work table, clamping table measuring table FEINMESSZEUGFABRIK SUHL measuring range: 160 mm projection: 100 mm working surface: Ø 100 mm working height: 125 mm solid design, with dial gauge ! used, tested ! Dimensions: 210 x 270 x 420 mm
Welding table, straightening table, straightening plate, work table, clamping table measuring table FEINMESSZEUGFABRIK SUHL measuring range: 160 mm projection: 100 mm working surface: Ø 100 mm working height: 125 mm solid design !' with dial gauge and lighting ! used, tested !' Dimensions: 210 x 270 x 420 mm
Magnetic clamping table, electric ELECTROMAGNET ELSTERWERDA C400 TGL10272 Outer diameter: Ø 400 mm Power consumption: 125 W Operating voltage: 115 V DC Current consumption: 1,15 A Flange diameter: Ø 250 mm Bolt circle diameter: Ø 315 mm 4x Threaded hole: M12 x 1.75, Depth: 15 mm used, tested ! Dimensions: 400 x 400 x 90 mm
Rotary table with 4 jaw chucks PAGUS diameter: Ø 160 mm table height: 160 mm lathe chuck 360° rotatable ( manual, without gearbox ) with 15° detent ( small lever ) two levers for clamping the lathe chuck used, tested ! Dimensions: 390 x 330 x 160 mm
Machine vise STANKO / BZSP (Made in USSR) jaw width: 300 mm span: 20 - 275 mm on rotary table with graduation solid design ! Dimensions: 550 x 370 x 225 mm
Machine vise PAGUS jaw width: 125 mm jaw height: 50 mm span: 0...110 mm rotatable on rotary table with graduation 360° dimensions: 350 x 200 x 140 mm
Tilting table, clamping table PAGUS Clamping surface: 285 x 260 mm 90° Tiltable 360° rotatable 3 grooves Groove width: 14 / 25 mm Dimensions: 370 x 300 x 175 mm
