mori seiki sl used for sale

Manufacturer: Mori Seiki Model NLX 2500 Y/700 Top condition Year of construction 2012 only approx. 6000 operating hours incl. 12 antr. WZ Holders + 17 Static WZ Holders Quick-change system from EWS Hollow clamping device KITAGAWA BB210A821 + KITAGAWA SS1881K21 for the main spindle Coolant system with increased pressure 5 bar Hinged belt conveyor, right ejection Integrated part catcher for main spindle I/F for bar replenishment, LNS Double foot switch with protective cover Signal light (red, yellow, green) Total Counter Workpiece counters EU Tool Holder Package SAUTER BMT60 (T32259, T32260, T32261, T32262) SKM253 MSQP Transformer 45.0 kVA 15 bar Grundfos pump incl. Hydac Filter Cantilever length for driven tools 100 mm (limited Y-axis travel) (Y, SY, SMC)

Machining center Mori Seiki M25 – FH 2/35

Fabricante MORI SEIKI Modelo NLX2500SY/700 Mes / Año 12/2011 CNC MORI SEIKI M730 BM Capacidades Volteo sobre bancada/carro 590/360 mm. Diámetro máximo torneable 460 mm. Longitud máxima torneable 795 mm. Paso de barra 80 mm. Eje Y INCLUIDO Recorridos y avances Recorrido eje X/Z 260/795 mm. Rango eje Y ±50 mm. Recorrido sub-cabezal eje B 734 mm. Avance rápido ejes X, Z, B 30.0000 mm/min Avance rápido eje Y 10.0000 mm/min Avance trabajo ejes X, Y, Z, B 0-5.000 mm/min Cabezal Eje C en cabezal INCLUIDO Indexación eje C cabezal 0.001º Velocidad cabezal 4.000 rpm Número gamas velocidad cabezal 2 Tipo nariz cabezal JIS A2-8 Diámetro paso cabezal 91 mm. Potencia motor principal 18.5 kW Sub-cabezal Eje C en sub-cabezal INCLUIDO Indexación eje C sub-cabezal 0.001º Velocidad sub-cabezal 6.000 rpm Número gamas velocidad sub-cabezal 1 Tipo nariz sub-cabe ...

Key data: 260 mm, 500 mm

Turning-milling centre Manufacturer: Mori Seiki Type NL1500SY/500 Year of construction 2007 In operation 03/2008 Control MSX-850-III Y and C axis All 12 turret stations are powered Max. turning length 500mm max. turning diameter 260mm Spindle Passage 50mm Speed of the driven tools 6,000 rpm Feeds X Z B 30,000 Y 10,000 with LNS rod loading magazine, length 1000mm, max D 65mm reducer sleeves. Machine is sold with all accessories, steel holders, AGWs (all still very good) collets, chuck, pick-up chuck, documentation, extraction system. Machine only ran in single-shift operation.

This 4-axis MORI SEIKI NL2500MC was manufactured in 2006, offering robust capabilities for horizontal turning. Ideal for precision machining, this unit ensures reliable performance with its advanced design. If you are looking to get high-quality turning capabilities consider the MORI SEIKI NL2500MC machine we have for sale. Contact us for more information.

This MORI SEIKI CL2000B was manufactured in 2008. A robust horizontal turning machine featuring a max turning diameter of 440 mm and length of 363 mm. It includes a 10-station turret and an 8-inch chuck. The control system is the Mori Seiki MSX-805II. Consider the opportunity to buy this MORI SEIKI CL2000B horizontal turning machine. Contact us for more information.

This 5-axis MORI SEIKI NLX 2500 SY/700 was manufactured in 2010, featuring a max swing over bed of 590 mm and a cutting length of 795 mm. It includes Y and C axes, a sub-spindle, and high-pressure coolant system. Capable of handling bar work up to 80 mm, its equipped with a chip conveyor and automatic bar feeder. Consider the opportunity to buy this MORI SEIKI NLX 2500 SY/700 turn-mill centre. Contact us for more information about this machine.

This 6-axis MORI SEIKI NL2000SY/500 was manufactured in 2005, featuring X-axis travel of 260 mm, Z-axis travel of 590 mm, spindle power of 5.5 kW, and a spindle speed of 6,000 rpm. It includes a 12-position tool turret. If you are looking to get high-quality turning capabilities, consider the MORI SEIKI NL2000SY/500 machine we have for sale.Contact us for more information.

This 3-axis MORI SEIKI CV-500 was manufactured in 1999. Ideal for precision CNC milling, this machine maintains robust construction and reliable performance. If you are looking to get high-quality milling capabilities, consider the MORI SEIKI CV-500 machine we have for sale. Contact us for more information.

This 9-axis MORI SEIKI NZ2000 was manufactured in 2008, offering advanced capabilities for precision horizontal turning. Ideal for complex machining tasks, this machine ensures efficient production with its multi-axis configuration. Consider the opportunity to buy this MORI SEIKI NZ2000 horizontal turning machine. Contact us for more information about this machine.

This 4-axis MORI SEIKI NH-5000 40 was manufactured in 2003, featuring a robust horizontal machining centre with a spindle speed up to 20,000 rpm and a power range of 22-30 kW. It includes a versatile tool magazine with a capacity up to 180 tools and a dual-pallet automatic changer to enhance productivity. Pallet size is 500 × 500 mm, supporting a maximum workpiece height of 1,000 mm. Consider the opportunity to buy this MORI SEIKI NH-5000 40 horizontal machining centre. Contact us for more information.

turning diameter: 190 mm turning length: 235 mm control: FANUC/Mori MSX 501 spindle turning speed range: 50-5000 U/min turret head: 2x 16 weight of the machine ca.: 7.5 t Y- & B- axes Misc. accessories more details on www.marcels-maschinen.ch The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

turning diameter: 190 mm turning length: 235 mm control: FANUC/Mori MSX 501 spindle turning speed range: 50-5000 U/min turret head: 2x 16 weight of the machine ca.: 7.5 t Y- & B- axes Misc. accessories more details on www.marcels-maschinen.ch The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

turning diameter: 370 mm turning length: 424 mm control: Fanuc total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

This 3s DMG Mori Seiki NLX1500MC/500 horizontal turning machine was manufactured in 2014. It features a maximum turning diameter without interference of 366 mm, X-axis travel of 260 mm, and Z-axis travel of 590 mm. With a spindle speed of 6,000 rpm and a turret with 12 driven stations, consider the opportunity to buy this DMG Mori Seiki NLX1500MC/500 horizontal turning machine. Contact us for further details.

This 5-axis MORI SEIKI SH8000/5AX was manufactured in 2002. Fully overhauled in 2016, it features a Fanuc 16iMA control, a spindle speed of 10,000 rpm, and a tool magazine with a capacity of 150 tools. The machine has a pallet size of 630 × 630 mm and a loading capacity of 1000 kg. If you are looking to get high quality milling capabilities consider the MORI SEIKI SH8000/5AX machine we have for sale. Contact us for more information.

This 3-axis MORI SEIKI NV4000 was manufactured in 2003. It features a CNC control system, typically FANUC/MAPPS, and a vertical machining center design. Key specifications include a 600 mm x 400 mm x 400 mm axis travel, a table size of 700 mm x 450 mm, and a maximum spindle speed of 12,000 rpm. The tool magazine holds up to 40 tools. Consider the opportunity to buy this MORI SEIKI NV4000 vertical machining center. Contact us for more information.

This 5-axis DMG Mori Seiki LaserTec 50 was manufactured in 2019. It features a Celos with Siemens 840D sl Operate control, integrated ytterbium cw fiber laser, and a compact design with a 4 m² footprint. Ideal for machining diamond tools with dimensions up to Ø 355 mm and 420 mm in length. If you are looking to get high-quality laser machining capabilities, consider the DMG Mori Seiki LaserTec 50 machine we have for sale. Contact us for more information.

This 4s MORI SEIKI NHX 5000 was manufactured in 2011. It features a dual pallet system with a pallet size of 500 × 500 mm and a maximum pallet load of approximately 500 kg. The spindle speed reaches up to 12,000 rpm, with a tool magazine capacity of 40 tools. If you are looking to get high-quality machining capabilities, consider the MORI SEIKI NHX 5000 horizontal machining center we have for sale. Contact us for further details.

This 3s MORI SEIKI SV-50s was manufactured in 1997. The CNC milling machine is in good working condition and has been used only a few times for prototype work. It features a FANUC spindle with a speed of 10,000 rpm and a tool changer with 30 positions. Consider the opportunity to buy this MORI SEIKI SV-50 vertical machining centre. Contact us for further details.

This 5-axis MORI SEIKI ZV 400 SUPER MILLER was manufactured in 2005. It features an X-axis travel of 600 mm, Y-axis travel of 425 mm, and Z-axis travel of 450 mm. The machine includes a table diameter of Ø 350 mm and a maximum workpiece weight of 200 kg. If you are looking to get high-quality machining capabilities, consider the MORI SEIKI ZV 400 SUPER MILLER vertical machining centre we have for sale. Contact us for further details.

This 5-axis MORI SEIKI NMV 5000DCG was manufactured in 2008. It features a maximum X-axis travel of 730 mm, Y-axis travel of 510 mm, and Z-axis travel of 510 mm. The machine includes a spindle speed of 12,000 rpm, a magazine capacity of 60 tools and an automatic pallet system. If you are looking to get high-quality machining capabilities, consider the MORI SEIKI NMV 5000DCG universal machining centre we have for sale. Contact us for further details.

Used machine Universal Machining Center Machine type: DMG MORI CMX70U 3+2 Control: Heidenhain TNC 620 Year of Make: 2021 #001350 Optimal area of application. Bearing seats on long shafts, crankshaft bearing seats, balancer shafts, etc. TECHNICAL DATA: Max. turning length: [mm] 1,055 Turning diameter: [mm] 120 Max. Rotary Ø over bed: [mm] 285 Rapid traverse: (X/Z) [m/min] 20 Main spindle Max. speed: [1/min.] 3,500 Drive power: [kW] 7.5 / 5.5 Bar Passage: [mm] 43 Spindle Nose: A2-6 Number of turrets: 2 Tool positions: 6 + 6 Tool holder: Capto Tailstock This offer is subject to change and non-binding. Changes, errors and prior sale expressly reserved.

Offered is a horizontal machining center (HMC). Travels X/Y/Z: 560mm/510mm/510mm, max. dynamics: 40000mm/min, spindle: 12000rpm, tool holder: MAS BT 40, tool magazine: 60 positions (chain magazine), pallet system: 2-station pallet changer, pallet size X/Y: 400mm/400mm, accessories: approx. 200 tool holders (BT 40), 2 MMI towers with 8 clamping bars, hinged belt chip conveyor, Blum laser/probe, Renishaw 3D probe, machine weight: approx. 9000kg. Inspection possible by appointment.

x-travel: 1.020 mm y-travel: 510 mm z-travel: 510 mm control: MSC 501 Fanuc table surface area: (APC) 1.200 x 480 mm max. table load: (APC) 550 kg Main spindle:: turning speed range - milling: 10.000 U/min power capacity - milling spindle: 22 / 18,5 kW tool taper: BT 40 Tool-Presetter:: number of toolpositions: 30 pos. tool taper: BT 40 max. tool diameter: 80 mm max. tool-dia with free toolbox: 125 mm max. tool length: 300 mm max. tool weight: 8 kg rapid traverse: 32 m/min feed: 1 ~ 16.000 mm/min Tipp feed: 0 ~ 1.260 mm/min spindle bearing diameter: 85 mm total power requirement: 59,5 kVA weight of the machine ca.: 6,9 t dimensions of the machine ca.: 3,9 x 2,7 x 2,9 m Documents: Chip conveyor: 2x Coolantsystem: high pressure coolant: through spindle coolant: Signal-Light: pallet changer: 2 pos. CNC - Machining Center - Vertical MORI SEIKI - SV 500 B/40 - Clamping devices are NOT  ...

Key data: 730 mm, 730 mm, 850 mm

Basic machine data Used 4-axis horizontal machining center from MORI SEIKI Make: MORI SEIKI Type: NH5000 DCG Year of Make: 2011 Condition: Mint Control: Name: FANUC 32iA MAPPS Travels: x-travel: 730 mm // y-travel: 730 mm // z-travel: 850 mm Technical data: • Spindle: max. 14000 rpm • HSK A-63 Tool Holder • 60-fold tool changer • Feed speed: 50 m/min • Rapid traverse: 50 m/min • B-axis indexing: 360° • 2 pallets • Pallet dimensions: 500 mm x 500 mm • Max. workpiece size: 800 mm x 1000 mm • 680 l IKZ • Chip conveyor The machine is in mint condition. Machine has only 5203 PGM hours Prior sale is reserved. No liability is assumed for the technical information provided here. The legal provisions apply.

Horizontal turning machine manufactured in 1998. This DMG Mori Seiki CL-200B features an X-axis travel of 398 mm and Z-axis travel of 214 mm. It is equipped with a Renishaw tool setter and a workpiece catcher that has never been used. The machine has approximately 10,000 operating hours and has always been operated in a single-shift environment. If you are looking to get high-quality turning capabilities, consider the DMG Mori Seiki CL-200B machine we have for sale. Contact us for further details.

This 4-axis MORI SEIKI SH633 was manufactured in 2001. It features an X-axis travel of 840 mm, Y-axis travel of 760 mm, and Z-axis travel of 840 mm. The machine is equipped with 2 pallets, each measuring 630 x 630 mm, and can handle a maximum workpiece weight of 1,200 kg. If you are looking to get high-quality machining capabilities, consider the MORI SEIKI SH633 horizontal machining centre we have for sale. Contact us for further details.

x-travel: 885 mm y-travel: 600 mm z-travel: 600 mm c-axis: 360 ° b-axis: +10 / -110 ° control: Heidenhain iTNC 530 : : 42000 min/-1 : 20 / 15 kW table surface area: dia 750 mm max. table load: 800 kg : : 30 pos. tool taper: HSK E 50 feeds:: feed speeds: max. 90.000 mm/min rapid traverse: 90 m/min total power requirement: 73 kVA weight of the machine ca.: 11 t dimensions of the machine ca.: 3,3 x 2,9 x 3,1 m High dynamic 5-Axis-Precision Center equipped with: - CNC ControlHeidenhein iTNC 530 - ATC 30-fold (HSK E50) - Chip Conveyor approx 57000H working hours The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 750 mm y-travel: 210 mm z-travel: 1150 + 100 mm control: Fanuc MSX-701III Maximum turning diameter: 660 mm Max. turning length: 1498 mm Diameter over cross slide max.: 400 mm number of spindle speeds: 3000 U/min tool piece magazine with: 40 Plätzen turret: 10 Fach total power requirement: 90 kVA weight of the machine ca.: 26,6 t dimensions of the machine ca.: 5301 x 2997 x 2788 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

This 4-axis MORI SEIKI NH 4000 DCG was manufactured in 2010. It features an X-axis travel of 560 mm, Y-axis travel of 560 mm, and Z-axis travel of 630 mm. The machine has a spindle speed of 14,000 rpm and a tool magazine capacity of 60 positions. If you are looking to get high-quality machining capabilities, consider the MORI SEIKI NH 4000 DCG horizontal machining centre we have for sale. Contact us for further details.

This 4-axis MORI SEIKI NV-5000α1/40 was manufactured in 2006. It features an X-axis travel of 800 mm, Y-axis travel of 510 mm, and Z-axis travel of 510 mm. The machine includes a robust table size of 1,100 × 600 mm with a maximum table load capacity of 1,000 kg. If you are looking to get high-quality machining capabilities, consider the MORI SEIKI NV-5000α1/40 vertical machining centre we have for sale. Contact us for further details.

This 4-axis MORI SEIKI SV-400 was manufactured in 1998. It features a table size of 900 × 500 mm and impressive travels of 600 mm in the X-axis, 430 mm in the Y-axis, and 460 mm in the Z-axis. The machine includes a maximum spindle speed of 12,000 rpm and a tool magazine capacity of 30 stations. If you are looking to get high-quality machining capabilities, consider the MORI SEIKI SV-400 vertical machining centre we have for sale. Contact us for further details.

This 8-axis MORI SEIKI NZ-2000/T2/Y2 was manufactured in 2008. It features a twin-spindle design with a maximum Z-axis travel of 810 mm and X-axis travel of 210 mm. The machine is equipped with two turrets, each with 16 stations, suitable for complex multi-process turning and milling operations. If you are looking to get high-quality turning capabilities, consider the MORI SEIKI NZ-2000/T2/Y2 turn-mill centre we have for sale. Contact us for further details.

Description WE OFFER AN HIGH TECH CNC LATHE TURNING AND MILLING CENTRE MACHINE IS COMMING OUT FROM FORMULA 1 - MERCEDES WORKSHOP MACHINE WAS FROM NEW HIGEST POSSIBLLE MAINTAINED WITH OFFICAL MORI SEIKI TECHNICAL DATA: Mori Seiki MT2000 CNC Lathe Description: Swing over bed - 700mm, Distance between centres - 1080mm, Max turning dia meter - 550mm, Max turning length - 1020mm, Bar capacity - 65mm, X Travel - 565mm, Y Travel - +/-80mm, Z Travel - 1077mm, B Indexing - +/-120deg, X Travel Turret 2 - 155mm, Z Travel Turret 2 - 1067mm, Spindle Speed - 4500rpm, Spindle nose - JIS A2-6, Tool Spindle Speed - 6000rpm, Tool Spindle type - Capto C6, ATC - 40 Tools, Max tool length - 280mm, Max tool weight - 7kg, Turret 2 Tools - 12, Square shank - 25mm, Boring bar shank diameter - 40mm, ...

Key data: 550 mm, 1020 mm

Ex-Mercedes-Benz F1 Motorsport – Excellent condition Mori Seiki MT2000Z/1000 5-axis turning / milling center Year of manufacture 2001 MSG 502 MAPPS Control (Dialog) Circumferential diameter over bed 850 mm Circumferential diameter over carriage 600 mm Max. turning diameter 550 mm Max. turning length 1,020 mm Max. spindle speed 4,500 rpm. C-axis 0.001° Upper tool carriage – single tool for turning/milling/drilling with automatic tool change X-axis travel (transverse) 565 mm Z-axis travel (longitudinal) 1,077 mm Y-axis axis travel (vertical/off-center) 160 mm (+/- 80 mm) B-axis swivel range +/- 120° Milling spindle drive power 15 kW Milling spindle speeds up to 6,000 rpm. Tool holder CAPTO C6 40-cavity tool magazine Lower Tool Carriage – 12-Station Turret with Live Tools Tool drive power 7.5 kW Tool speeds up to 4,0 ...

This 4-axis MORI SEIKI NLX 2500Y was manufactured in 2013. It features a maximum swing over bed of 742 mm and a maximum turning diameter of 366 mm. The machine includes a powerful spindle motor with 18.5 kW and a maximum spindle speed of 4,000 rpm. If you are looking to get high-quality turning capabilities, consider the MORI SEIKI NLX 2500Y horizontal turning machine we have for sale. Contact us for further details.

This 5-axis MORI SEIKI NL 2500 SY was manufactured in 2009. It features a maximum spindle speed of 4,000 rpm, a Y-axis travel of ±60 mm, and a Z-axis travel of 795 mm. The machine is equipped with a robust turret capacity of 12 stations and offers simultaneous turning and milling capabilities. If you are looking to get high-quality machining capabilities, consider the MORI SEIKI NL 2500 SY turn-mill centre we have for sale. Contact us for further details.

This 3-axis MORI SEIKI DuraVertical 5100 was manufactured in 2007. It features an X-axis travel of 1,050 mm, Y-axis travel of 530 mm, and Z-axis travel of 510 mm. The machine has a robust table size of 1350 x 600 mm and a maximum table load capacity of 1000 kg. If you are looking to get high-quality machining capabilities, consider the MORI SEIKI DuraVertical 5100 vertical machining center we have for sale. Contact us for further details.

turning diameter: max. 356 mm turning length: 705 mm control: MSX 850 III MAPPS Mitsubishi greates pass round over bed: 923,8 mm Swing dia. over traverse guideway: 755 mm standard turning dia.: 275 mm Main spindle:: max. spindle speed: 4.000 min/-1 power capacity - main spindel: 18,5 / 15 kW spindle nose: JIS A2-8 spindle bearing diameter: 140 mm spindle bore: 91 mm max. bar capacity: 80 mm chucking diameter: 305 mm C-Axis: 0,001 ° Subspindle:: Spindle speed range subspindle: max. 6.000 min/-1 power capacity - Sub spindle: 11 / 7,5 kW spindle nose: JIS A2-5 spindle bearing diameter: 85 mm spindle bore: 43 mm chucking diameter: 210 mm C-Axis: 0,001 ° turret:: number of toolpositions: 12 pos. Number of driven toolspositions: 12 pos. Shank diameter: 26 mm Drill shank diameter: 50 mm Spindle speed - driven tool stations: max. 6.000 min -1 turret change time: 0,25 sec. axis stroke:: x-a ...

turning diameter: 200 mm turning length: 393 mm control: MSX 853 weight of the machine ca.: 3,5 t total power requirement: kW dimensions of the machine ca.: m MSX 853 cnc control 3-jaw chuck diameter 210mm 12-fold revolver C-axis driven tools tail stock coolant device chip conveyor Technische Daten: / technical details Drehdurchmesser / turning diameter 200 mm Drehlänge / turning lenght 393 mm X-Weg / X-travel 160 mm Z-Weg / Z-travel 450 mm max. Drehzahl Spindel / max. spindle speed 50-3000 UpM /rpm Eilgang X/Z / rapid feed X/Z 24/30 Anzahl der Revolverplätze / number of tool places 12 max. Stangendurchmesser / max. bar diameter 51 mm Antriebsleistung Spindel / drive capacity spindle 13,5 kW Gewicht ca. / weight ca. 3500 kg Technische Daten, Zubehör und Beschreibung der Maschine sind unverbindlich - Technical data, accessories and description of the machine are n ...

This 3-axis MORI SEIKI NLX 2500M was manufactured in 2011. It features a maximum turning diameter of 366 mm and a maximum turning length of 705 mm. The machine is equipped with a powerful spindle motor of 18.5 kW and a turret with 12 positions for enhanced productivity. If you are looking to get high-quality turning capabilities, consider the MORI SEIKI NLX 2500M horizontal turning machine we have for sale. Contact us for further details.

Vertical Machining Center MORI SEIKI GV-503/5ax x-travel 610 mm y-travel 765 mm z-travel 460 mm pallet table size 550 x 550 mm taper BT 40

A Mori Seiki CNC turning and milling center with counter spindle including automation is available. Tool turrets: 3, tool stations: 3×16, live tools: all stations, X-axis travel: 210mm, Z1/Z2/Z3-axis travel: 300mm/810mm/300mm, main spindle bore: 55mm, spindle speed: 6000rpm, automation robot: LR Mate 200iC 5L, payload: 5kg, reach: 892mm, repeatability: 0.03mm. Machine dimensions X/Y/Z: approx. 3800mm/2700mm/2500mm, weight: approx. 8900kg, control: Fanuc 31i-A, power-on hours: 101035h, operating hours: 68322h, process hours: 34697h. Including an automated CO2 fire detection system, transformer, machine extraction system, 4× workpiece carriers and an automatic diameter detection system. Documentation available. An on-site inspection is possible.

A Mori Seiki CNC turning and milling center with counter spindle including automation is available. Tool turrets: 3, tool stations: 3×16, live tools: all stations, X-axis travel: 210mm, Z1/Z2/Z3-axis travel: 300mm/810mm/300mm, main spindle bore: 55mm, spindle speed: 6000rpm, automation robot: LR Mate 200iC 5L, payload: 5kg, reach: 892mm, repeatability: 0.03mm. Machine dimensions X/Y/Z: approx. 3800mm/2700mm/2500mm, weight: approx. 8900kg, control: Fanuc 31i-A, power-on hours: 101035h, operating hours: 68322h, process hours: 34697h. Including an automated CO2 fire detection system, transformer, machine extraction system, 4× workpiece carriers and an automatic diameter detection system. Documentation available. An on-site inspection is possible.

The machine is in good technical condition; testing is possible by prior arrangement. SPACESAVER SS 2101. Fanuc MSX-850 system.

x-travel: 510 mm y-travel: 510 mm z-travel: 510 mm total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m CNC control MSC 803 25-fold automatic tool changer coolant device Technische Daten / technical details: Verfahrweg X / X-Travel 510 mm Verfahrweg Y / Y-Travel 510 mm Verfahrweg Z / Z-Travel 510 mm Tischgröße / table size 750x548 mm Drehzahlbereich / spindle speed 8000 UpM /rpm Anzahl der Werkzeugplätze / tool places in changer 25 fach Antriebsleistung Spindel / drive capacity spindle 11 kW Gewicht der Maschine ca. / weight 4500 Kg Technische Daten, Zubehör und Beschreibung der Maschine sind unverbindlich - Technical data, accessories and description of the machine are not binding. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

turning diameter: 660/275 mm turning length: 1498 mm control: Fanuc/Mori Seiki MSX 701 total power requirement: 90 kVA weight of the machine ca.: 26,6 t dimensions of the machine ca.: 5301 x 2997 x 2788 mm 9-axis CNC turning and milling centre Fanuc MSX-701 CNC control Milling spindle at top (B axis), as full 4th axis, positioning 0.0001 deg. 40-position tool magazine 10-position turret at bottom, all positions driven 2 x 3-jaw quick-change chuck KNCS-N 315/91 KNOLL high-pressure coolant system, pressure setting 12/25/35/45/55/62 and 72 bar, with maintenance-free rotary filter system Chip conveyor Drain system for main spindle chuck (controlled via M function) Drain system for tool cutting edge (controlled via M function) Coolant gun incl. accessories Oil mist extraction Direct measuring system X1, X2, Y-axis Bar loader interface Double foot switch for both spindles Island ...

x-travel: 600 mm y-travel: 530 mm z-travel: 510 mm Control: M 730 BM MAPPS IV Main spindle:: max. spindle speed: 10.000 min/-1 power capacity - main spindel: 15 / 11 kW tool taper: SK 40 transmission ratio: 1 spindle diameter in front bearing: 80 mm work table:: table surface area: 900 x 600 mm max. table load: 800 kg T-slots: 6x 18 x 100 mm distance spindle /table: 150 - 660 mm Tool-Presetter:: number of toolpositions: 30 pos. tool taper: SK 40 max. tool diameter: 80 mm max. tool-dia with free toolbox: 150 mm max. tool length: 300 mm max. tool weight: 8,0 kg change-time tool to tool: ca. 1,3 sec change-time chip to chip: ca. 3,45 sec feeds:: rapid traverse ( X / Y / Z ): 30 m/min feed speeds: 1 - 30.000 mm/min Tipp feed: 0 - 5.000 : 20 mm/min total power requirement: 30 kVA weight of the machine ca.: 6,0 t dimensions of the machine ca.: 4,5 x 3,5 x 2,7 m Documents: Chip conveyor:  ...

x-travel: 800 mm y-travel: 530 mm z-travel: 510 mm Control: MSC 504 Mori Seiki Main spindle:: turning speeds: max. 10.000 min/-1 power capacity - main spindel: 15 / 11 kW tool taper: SK 40 spindle bearing diameter: 70 mm distance spindle /table: 150 - 660 mm work table:: table surface area: 1.100 x 600 mm max. table load: 800 kg T-slots: 6x 18 mm table height over floor: 900 mm turret:: number of toolpositions: 30 pos. tool taper: SK 40 max. tool diameter: 80 mm max. tool-dia with free toolbox: 125 mm max. tool length: 300 mm max. tool weight: 8,0 kg change-time tool to tool: 1,3 sec change-time chip to chip: 4,1 - max. 9,2 sec feeds:: rapid traverse ( X / Y / Z ): 36 / 36 / 20 m/min feed speeds: max. 6.000 mm/min Tipp feed: 1 - 5.000 mm/min total power requirement: 27 kVA weight of the machine ca.: 6,1 t dimensions of the machine ca.: 3,5 x 3,0 x 2,8 m Documents: Chip conveyor: Co ...
