milling center used for sale

A CNC universal turning and milling machine DMG Mori is available. Travel X/Z: 160mm/450mm, turning diameter over bed/face slide: 330mm/260mm, distance between centers: 450mm, chuck diameter: 210mm, speed: 5000rpm, spindle power: 16.5kW/11kW, tool positions: 12, rapid traverse: 30m/min. Machine dimensions X/Y/Z: approx. 3200mm/2000mm/1800mm, weight: approx. 3500kg, operating hours: 18127h. Dokumentation vorhanden. On-site inspection is possible.

Horizontal BAZ DECKEL MAHO DMC 60 H Linear with 2-fold pallet changer and 180 magazine locations Year of Make: 2009 Control: Sinumerik 840D Technical data: Spindle speed: 0-18,000 min-1 Drive power: 35KW Torque: Spindle mount: HSK 63 Number of magazine slots: 180 pieces Number of pallets: 2 Pallet size: 500x500mm Travels: X-axis: 630mm Y-axis: 800mm Z-axis: 650mm C-axis: 0.001° All axes have linear actuators Accessories: -Coolant system -Chip conveyor Machine was regularly serviced Video available on request.

Horizontal BAZ DMG MORI NHX 4000 with 2-fold pallet changer Year of Make: 2017 Control: Celos with Sinumerik 840Dsl Operate Program running hours: 21,000h Technical data: Spindle speed: 10 - 20,000 min-1 (motor spindle speedMASTER)® Drive power: 35/25 KW Torque: 130/85 Nm Tool holder: HSK 63 Number of magazine slots: 60 - Ring magazine Travels: X-axis: 560mm Y-axis: 560mm Z-axis: 660mm C-axis: 0.001° Pallet size: 400x400mm Accessories: 2-fold pallet changer Coolant system for IKZ 70bar Chip conveyor Renishaw 3D - Pushbutton

Horizontal machining center Okuma MB 500H with 2-fold pallet changer Year of Make: 2005 Control: Okuma OSP E100M Technical data: Spindle speed: 10 - 15,000 min-1 Drive power: 26 KW Tool holder: BT 40 Number of magazine slots: 60 IKZ: 70 bar Routes: X-axis: 800mm Y-axis: 800mm Z-axis: 800mm 4th axis: index 1° Number of pallets: 2 Pallet size: 500x500mm Accessories: - Coolant system type ConSep 2000 from Mayfran - Chip conveyor Mayfran type ConSep from Mayfran - Tool breakage monitoring in the magazine - Workpiece coolant shower

BASIC FUNCTIONS   number of spindles: 1   number of turrets: 1   live positions: yes WORKING RANGE TURNING   swing diameter (max): 560 mm   turning diameter (max): 275 mm   bar diameter (max): 42 mm   worpiece length max.: 450 mm MAIN SPINDLE   spindle revolutions (min): 5600 /min   drive power: 11 kW X/Z SLIDE   number of tool positions (total): 11   number of live positions: 11   - rotation speeds (max): 4500 /min TAILSTOCK   sleeve stroke: 60 mm   sleeve diameter: 70 mm   holding force (max.): 8600 kN ELECTRICAL SPECIFICATIONS   mains voltage: 400 V   mains frequency: 50 Hz DIMENSIONS / WEIGHTS   space requirements -left/right-: 2700 mm   space requirements -front/back-: 1600 mm   to ...

Tongtai / Topper TMV - 720 A / Fanuc OI-MD Vertical Machining Center -CE marking -Year of construction 2011 -Control Fanuc Oi-MD -Travel X / Y / Z 720x480x530mm -Distance spindle nose / table 100-630mm -Table size 800x480mm -Max. table load 500Kg -Spindle holder BT-40 -Spindle speed 8000 rpm -Spindle motor 7.5 / 5.5 KW -Rapid traverse X / Y / Z each 48 M/min -Feed speed 1-10000 MM/min -Tool changer / 24 compartment -Tool change time (T-T) 3 sec. -Max. tool weight 7Kg -Max. tool diameter 80mm -Work light -Coolant device -Chip conveyor -Electric handwheel Dimensions: LxWxH 2.8x2.2x2.8 meters / Weight 4400Kg

I'm selling parts for a Brother TC-31A pallet milling machine (year 2000). All components are available, including: - indexers (4th axis), - screws and mechanical components, - electronics modules, - motherboards, - tool magazine, - motors, - servos, - and many other components. For pricing on individual parts, please contact me.

I'm selling a Mazak FH-4800 pallet machining center. The machine is in very good condition. The spindle and axes operate quietly. A chip extractor and coolant tank are included. Machine parameters: X-axis travel: 560 mm Y-axis travel: 610 mm Z-axis travel: 560 mm Rotary table: 360/1 degrees Mazatrol PC Fusion CNC 640 M control Table length: 400 mm Table width: 400 mm Max. workpiece weight: 400 kg Tool magazine: 40 Spindle taper: SK40 Max. spindle speed: 12,000 rpm Spindle motor power: 22 kW Length x width x height: 2680.0 x 4160.0 x 2635.0 Weight: 9400 kg

CONTROLS   CNC controls FANUC BASIC FUNCTIONS   number of spindles: 2   number of turrets: 2   live positions: yes   number of c-axes: 2   number of y-axes: 1   number of b-axes: 1 WORKING RANGE TURNING   bar diameter (max): 50 mm MAIN SPINDLE   spindle revolutions (max): 5000 /min   drive power: 11 kW   spindle bore diameter: 50 mm   c-axis: yes COUNTER SPINDLE   spindle revolutions (max): 5000 /min   drive power: 7.5 kW   c-axis: yes   Z-axis travel: 465 mm X/Z SLIDE   tool fixture: Turret   number of tool positions (total): 24   number of live positions: 24   - rotation speeds (max): 6000 /min ELECTRICAL SPECIFICATIONS   mains voltage: 400 V   mains frequency: ...

Horizontal milling center Type: HFZ 2000x1800x6000/444 Manufacturer: Heckert Year: 1983 Table: 1800 x 2000 mm Working length: 6000 mm Machine fully functional Find more here - / Contact us at -

Horizontal BAZ DECKEL MAHO DMC 60 H Linear with 2-fold pallet changer and 180 magazine locations Year of Make: 2009 Control: Sinumerik 840D Technical data: Spindle speed: 0-18,000 min-1 Drive power: 35KW Torque: Spindle mount: HSK 63 Number of magazine slots: 180 pieces Number of pallets: 2 Pallet size: 500x500mm Travels: X-axis: 630mm Y-axis: 800mm Z-axis: 650mm C-axis: 0.001° All axes have linear actuators Accessories: -Coolant system -Chip conveyor Machine was regularly serviced Video available on request.

DOOSAN VM 960L CNC machining center was built in 2016 in South Korea by Doosan Machine Tools. The machine on offer is an excellent choice for both roughing and finishing machining of workpieces with a maximum weight of 4500 kg. It is distinguished by a number of state-of-the-art technical solutions, which, combined with extensive equipment, guarantee excellent repeatability of the manufactured parts over many years of intensive operation. All machining processes, i.e. drilling, threading and milling, are performed by means of a reliable spindle and cutting tools taken from a 40-position magazine. The very accurately balanced spindle ensures vibration-free operation at all speeds. Its taper is cleaned continuously with compressed air to protect it from chips and coolant. The entire workspace, in turn, has been fully maximised to ensure freedom of operation. The offer also includes a ...

EXERON DIGMA HSC 600 milling center was built in 2010 in Germany by Exeron GmbH. It is an extremely versatile yet compact machine designed for the production of precision tools and moulds. A number of state-of-the-art technical solutions, combined with extensive equipment, guarantee excellent repeatability of the manufactured parts over many years of intensive operation. The EXERON DIGMA HSC 600 is distinguished by its extremely rigid gantry structure, made of polymer concrete. The entire workspace has been fully maximised to ensure maximum freedom of operation. It features all the necessary equipment, i.e. a reliable electro-spindle, a 30-position tool magazine and a large work table with a length of 900 mm and a width of 550 mm. The machining process is performed fully automatically in HSM (High Speed Cutting) technology. This technology allows a significant reduction in cycle ti ...

- CNC wireless remote control - Zero-3 / 5-channel stepper motor drive - Base frame (movable on wheels) - Dell PC (with monitor, keyboard, and mouse) - WinPC-NC USB software (Version 2.50) - Accessories

Vertical BAZ MIKRON VC 500 with internal cooling 10 bar Year: 2001 Control: Heidenhain 430 TNC Operating hours: 3,300h Technical data: Spindle speed: 10,000 1/min Drive power: 13 KW Tool holder: SK 40 Number of magazine slots: 21 pcs. Travels: X-axis: 510mm Y-axis: 510mm Z-axis: 560mm Table size: 650x600mm Accessories: - IKZ with 10bar - Späneförderer - Electronic handwheel - Renishaw 3D button - Oil mist extraction - Rotoclear Machine was in a training company

DMG MORI DMC 635 V Ecoline CNC machining center was built in 2014 in Poland by FAMOT Pleszew Sp. z o.o. The machine, designed for precision machining of workpieces, is the perfect solution for both unit and series production. The machining process is performed fully automatically by means of a reliable electro-spindle and tools taken from a 20-position magazine. Process stability, in turn, is ensured by an extremely rigid bed, which continuously eliminates any vibration and oscillation. All this is complemented by an easy-to-use HEIDENHAIN CNC control with many useful functions. The DMG MORI DMC 635V Ecoline CNC vertical machining center weighs 3900 kg. Technical specifications of the DMG MORI DMC 635 V Ecoline CNC milling machine - HEIDENHAIN TNC 620 CNC control with workpiece and machining 3D simulation - feed in the X/Y/Z axis: 635/510/460 mm - rapid traverse in the X,Y,Z axis:  ...

MORI SEIKI NV5000 alpha 1B/40 CNC machining center was built in 2007 in Japan by Mori Seiki Co., LTD. The machine is designed for precision machining of heavy workpieces weighing up to 1200 kg. The machining process is performed fully automatically by means of a reliable spindle and tools taken from a 30-position magazine. High power and rotational speed of the spindle enable performing efficient roughing as well as finishing operations. The workspace, on the other hand, has been fully maximised to ensure the freedom of the performed operations. All this is complemented by an advanced FANUC CNC control with MAPPS interactive programming. The NV5000 alpha 1B/40 CNC vertical machining center is offered with an extensive range of equipment, consisting of, among others, cooling through the spindle, chip conveyor and high-pressure pump. The total weight of the machine is 7300 kg. Technical ...

turning diameter: 890,820 mm turning length: 4000 mm control: Siemens SIN 880T spindle taper: DIN 55026/15 spindle passage: 122 mm cross movement: 500 mm quill stroke: 140 mm tailstock adjustment: 3708 mm spindle turning speed range: 5-1800 U/min milling tool taper: 1500-6000 U/min feed: 0,5-5000 mm/min rapid traverse: 15 m/min feed power: 22000/10000 N Tool changer: 95 St. steady: CNC tail stock: CNC total power requirement: 50/69 kW weight of the machine ca.: 23,5 t dimensions of the machine ca.: 10x4x3,3 m The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, produc ...

Description Machine type: CNC-BAZ Vertical Model: M1 Pro with 4th axle incl. tailstock Manufacturer: DMGMORI Control: Siemens 828 D Year of Make: 2022 #001283 Location: Germany TECHNICAL DATA: Technical data Traversing range X-axis approx. 550 mm Y-axis approx. 550 mm Z-axis approx. 510 mm Table size approx. 850 x 650 mm Workpiece weight max. approx. 600 kg Speed max. approx. 12,000 rpm Spindle motor approx. 13/9 KW Number of tool positions approx. 24 Rapid traverse X / Y / Z approx. 24 m/min Pick-up taper approx. SK40 Footprint L x W x H approx. 3.1 x 2.7 x 2.9 m Machine weight approx. 5,600 kg Facilities Main spindle 12,000 rpm 13/9 kW - Separate electronic handwheel - 24 places chain magazine - SK40 - Coolant tank - IKZ pump 20bar - Filter for coolant - Bed flushing via M-function switchable - coolant spray gun - spindle blowing air switchable via M-funct ...

BMEI BV100 CNC vertical machining center was built in 2007 in China by BMEI CO., LTD. The machine is used for precision machining of workpieces with a maximum weight of 700 kg. The machining process is performed inside a large workspace, which has been fully maximised to ensure the freedom of performed operations. Inside it, there is a stable work table with a length of 1300 mm and a width of 610 mm and with five T-slots for quick and easy attachment of tooling. The spindle, driven by a high-powered motor, reaches a speed of as much as 15000 rpm and moves in three X,Y,Z axes with feeds of 1050 mm, 510 mm and 560 mm respectively. The capacious 21-position tool magazine, on the other hand, allows storage of a large number of tools with a maximum diameter of 160 mm. A short tool change time of just six seconds reduces machine downtime to a minimum. All this is complemented by an advanced FA ...

CORMAK MILL850 CNC machining center was built in 2025. The machine has only undergone a test run and has never been in operation, it is like brand new. The CORMAK MILL850 1000 x 500 is the perfect choice for precision machining of workpieces with a maximum weight of 500 kg. The machine is distinguished by the use of many well-proven components that guarantee reliability and long-term performance. The machining process is performed inside a large, fully illuminated workspace. This space has been fully maximised to ensure the freedom of the performed operations. The hermetic enclosure of the workspace prevents possible dangers, as well as keeping the work area clean. The hardened work table with a length of 1000 mm and a width of 500 mm enables secure fixing of workpieces without overloading the design. The spindle, driven by a high-powered motor, reaches speeds of up to 12000 rpm. A ...

Used machine DMU40eVo with EROWA Magazine Machine type: CNC machining center 5-axis vertical Model: DMU40eVo with EROWA Manufacturer: DMGMORI Control: CELOS Heidenhain TNC640 Year of Make: 2019 Location: Germany #001371 Options: -Motor spindle speedMASTER® HSK-A63 -Spindle speed 20-20,000 min-1 -NC swivel rotary table -Tool magazine 210 places -Scraper chip conveyor -Internal coolant supply (IKZ) paper belt filter 20-80bar -Advanced chip flushing -Blowing air through the center of the spindle -Rotating lens -Oil and emulsion mist separator mechanical - Infrared touch probe -Tool breakage detection TRS2 -Preparation 3D quickSET -Signal light, four-color -DMG MORI automation interface -Pneumatic control of the PowerChuck 210 zero-point clamping system -EROWA Robot Compact (ERC80) -Magazine:15x rack level PC210 with 3 pos. each = total 45 pos. Changes, Thi ...

Used machine CNC machining center horizontal Manufacturer:DMGMORI Type:NH4000DCG Year of construction:2021 Control Type:FANUC F31iB Origin: Japan Location:Germany Delivery Time Technical data Traversing range X-axis approx. 560mm Y-axis approx. 560mm Z-axis approx. 630mm Table 360° 1° Workpiece diameter approx. 630mm Workpiece weight max. approx. 400kg Speed max. approx. 14,000 rpm Spindle motor approx. 18.5/11KW Number of tool positions approx. 40 Rapid traverse approx. 50m/min Mounting Taper BT40 Compressed air bar,L/min approx. 5, 300 bar,L/min Power consumption approx. 34kVA Footprint L x W x H approx. 2,360×3,914x2,711m Machine weight approx. 9,600 kg Automatic Rotary APC Tool Holder: BT40-Max. Spindle speed 14,000 min-1,-18.5/11 kW (10min/100% ED)-Number of Tools: 40 (Chain Type)-Table Indexing 1° Scraper Belt Conveyor with drum filter preparati ...

From now on we can arrange the following services for you! ✔ CAD/CAM programming Experts support you in programming your components – from the simple 2D contour to complex 5-axis simultaneous machining. We work with market-leading CAD/CAM systems and optimize your programs for maximum efficiency. ✔ Cost-per-part calculation We analyze your components with regard to cost-effectiveness. Together we determine your unit costs and help you to make optimal use of the machine and processes. ✔ Feasibility studies Before purchasing, we check the technical feasibility of your applications. How to get Certainty that the machine meets your requirements and that your production is sustainable supported. ✔ Programming Training Our training courses are aimed at beginners as well as advanced learners and are individually tailored to Adapted to your requirements. How to en ...

Used machine DMGMORI NHX6300 Machine type: CNC machining center horizontal Model No.: NHX6300 Manufacturer: DMGMORI Control: CELOS MAPPS Year of Make: 2021 Location: Germany #001396 TECHNICAL DATA: Travels: X-axis: [mm] 1050 Y-axis: [mm] 900 Z-axis: [mm] 1030 B-axis 0.001° Rapid traverse: (X/Y/Z) [m/min.] 60 Speed range: [1/min.] 12,000 Drive power: [kW] 55/30 Tool holder: HSK100 Tool Changer Tool Positions: 120 Pallet system Number of pallets: 2 Pallet size: [mm] 630 x 630 Machine weight: [kg] 18,700 Facilities Control F31iB with CELOS spindle cone HSK-A100 preparation for coolant system by the spindle rotary table with full-fledged 4th axis 120-fold tool magazine (HSK-A100)- Coolant Washer Nozzles for Mist Separator INTERLIT TMF300/980 Setup Station Connection Compact filter system 70 bar-INTERLIT coolant cooler 15 kW in-machine measuring system (spindle ...

Used machine Universal Machining Center Machine type: DMG DMF 360 / 11 linear Control: Heidenhain TNC 640 Celos Year of Make: 2017 TECHNICAL DATA: Travels: X-axis: [mm] 2,600 Y-axis: [mm] 1,100 Z-axis: [mm] 900 B-axis C-axis Number of controlled axes: 5 Dynamic Pack for DMF 360 linear (Y1100) Rapid traverse: (X/Y/Z) [m/min.] 80 / 60 / 60 Speed range: [1/min.] 20 - 15,000 Drive power: [kW] 46 / 30 Tool holder: SK 40 Tool Changer Tool positions: 60 NC rotary table Table size: [mm] 3,200 x 1,100 Max. table load: [kg] 1,200 Features: Internal cooling (IKZ): [bar] 40 Coolant tank: [l] 600 Chip conveyor Chip rinsing gun Oil mist extraction Air through spindle center Probe Spindle Preparation for use 3D quickSet Automatic doors Electronic handwheel This offer is subject to change and non-binding. Changes, errors and prior sale expressly reserved.

Used machine HSC70 linear Machine Type: CNC 5-Axis Milling Center Model: HSC70 linear Manufacturer: DECKEL MAHO Control:3D control Heidenhain TNC 640 Year of Make: 2016 #001347 Equipment: - Spindle speed up to 28,000 rpm - Production package 980I with ICZ and temperature control 01 - Rinsing gun for swarf rinsing - Electronic handwheel - Tropical Pack This offer is subject to change and non-binding. Changes, errors and prior sale expressly reserved.

Used machine Machine Type: CNC Machining Center Vertical Model: NVX5100 2nd with Matris robot cell Manufacturer: DMGMORI Control:DMG MORI Celos Year of construction / Ib: 2019 / 2022 #001312 Technical data Travel range X-axis approx. 1050 mm Y-axis approx. 530 mm Z-axis approx. 510 mm Table size approx. 1,350x600 mm Workpiece weight max. approx. 1,200 kg Speed max. approx. 12,000 rpm Spindle motor approx. 37/22 KW Number of tool positions approx. 30 Rapid traverse approx. 30 m/min Mounting cone approx. BT40 Compressed air bar,L/min approx. 5, 300 bar,L/min Power consumption approx. 45 kVA Footprint L x W x H approx. 3.1 x 2.85 x 2.6 m (without chip conveyor, without robot) Machine weight approx. 7,300 kg Main Drive with Higher Torque - Tool Holder Cone for BT-40 Tool Holder - Tool magazine with 30 places (#40) - Door for tool magazine - Hinged belt conveyor  ...

Used machine Machine Type: CNC Machining Center Vertical Model No.: CMX1100V Manufacturer: DMGMORI Control:DMG MORI SLIMline® Multi-Touch Heidenhain Year of Make: 2022 #001358 Options: - Main spindle 12,000 rpm 13/9kW SK40 - Tool holder BT 40 for tightening bolts DIN 69872 - Direct position measuring system X-Y-Z - Magazine with 30 tool positions - Coolant supply through spindle (IS) bar 20 - Double switching filter - Coolant-blown air switching externally via M-function - Chip conveyor (scraper belt, left side) - Tank capacity left side chip conveyor 250 - Coolant spray gun for chip removal - Automatic cab roof - Signal light - Electronic handwheel - Button kit spindle and table Traversing range X-axis 1100 mm Y-axis 560 mm Z-axis 510 mm Table size approx. 1400 x 560mm Workpiece weight max. approx. 1000kg Rapid traverse X / Y / Z 30 m/min Footprint L x ...

Used machine Universal Machining Center Machine type: DMG MORI CMX70U 3+2 Control: Heidenhain TNC 620 Year of Make: 2021 #001350 TECHNICAL DATA: 5. Axis 3 + 2 axes non-simultaneous X-axis: [mm] 750 Y-axis: [mm] 600 Z-axis: [mm] 520 Rapid traverse: (X/Y/Z) [m/min.] 30 Max. speed: [1/min.] 12,000 Drive power: [kW] 13 Torque: [Nm] 82 Tool holder: HSK63 Tool positions: 60 NC swivel rotary table B-axis -10° / +95° C-axis 360° Table size: [mm] 800 x 620 Max. table load: [kg] 350 Space requirement (LxWxH): [m] 5.35 x 4.14 x 3 Machine weight: [kg] 4,700 Features: Chip conveyor Internal cooling (IKZ):40 [bar] Tool breakage detection Heidenhain TS 27 R Probe Heidenhain Blum Lasers for Tools Direct Path Measurement System Electronic handwheel Machine preparation for DMG MORI PH 150 - Automatic lifting door on the right - Robot interface (DMG MORI standard) - ...

Used machine Universal Machining Center Machine type: DMG MORI CMX70U 3+2 Control: Heidenhain TNC 620 Year of Make: 2021 #001350 Optimal area of application. Bearing seats on long shafts, crankshaft bearing seats, balancer shafts, etc. TECHNICAL DATA: Max. turning length: [mm] 1,055 Turning diameter: [mm] 120 Max. Rotary Ø over bed: [mm] 285 Rapid traverse: (X/Z) [m/min] 20 Main spindle Max. speed: [1/min.] 3,500 Drive power: [kW] 7.5 / 5.5 Bar Passage: [mm] 43 Spindle Nose: A2-6 Number of turrets: 2 Tool positions: 6 + 6 Tool holder: Capto Tailstock This offer is subject to change and non-binding. Changes, errors and prior sale expressly reserved.

Used machine Universal Machining Center Machine type: DMG HSC 75 linear Control: Heidenhain i-TNC530 Year of Make: 2008 TECHNICAL DATA: Travels: X-axis: [mm] 750 Y-axis: [mm] 600 Z-axis: [mm] 560 Feed: (X/Y/Z) [m/min.] 90 Rapid Traverse: (X/Y/Z) [m/min.] 90 / 90 / 90 A-axis -10 B-axis +110 C-axis 360° Speed range: [1/min.] 28,000 Tool Changer Tool holder: HSK-A63 Tool positions: 60 Tool diameter: [mm] 80 / 140 Tool length: [mm] 300 NC rotary table Ø 750 Max. table load: [kg] 800 Table size: [mm] fixed tabe: 950 x 650 Max. table load: [kg] 1,000 Features: Chip conveyor This offer is subject to change and non-binding. Changes, errors and prior sale expressly reserved.

Used machine Vertical machining center Machine type: DMG DMC 635 V/P Control: Heidenhain iTNC 530 Year of Make: 2013 TECHNICAL DATA: Travels: X-axis: [mm] 635 Y-axis: [mm] 510 Z-axis: [mm] 460 Speed range: [1/min.] 10,000 Tool holder: SK 40 Tool Changer Tool positions: 30 Pallet system Number of pallets: 2 Table size: [mm] 560 x 790 Features: No internal cooling (IKZ) Electronic handwheel Probe TS649 Tool breakage detection table switches Chip rinsing gun This offer is subject to change and non-binding. Changes, errors and prior sale expressly reserved.

Manufacturer: EMCO Maxxmill 350 Model: Maxxmill 350 Year of Manufacture: 2017 Type of Machine : Milling Center Spindle hours: 11,000 CNC Control: Heidenhain iTNC620 HSCI Spindle: ISO30, 12,000 rpm, 33 Nm, 7 kW 4th axis: Yes 5th axis: Yes Automation system: Lang Eco Compact 10 - fully operational and pre-configured Condition: Used, fully functional Axis Travel - X axis: 350 mm - Y axis: 250 mm - Z axis: 300 mm Equipment and Features - Tool magazine: 50 positions - Chip conveyor: Yes - Band filter: No - Pallets: No - Comprehensive ISO30 toolholder package included - Lang Eco Compact 10 automation system - fully operational and pre-configured, included - Custom-built workspace cover - special manufacture, included Find more here - / Contact us at -

A CNC 7-axis counter-spindle lathe DMG Mori is available. Turning diameter: 640mm, max. turning length: 1185mm, travel X1/X2: 550mm/180mm, travel Y: +/-90mm, travel Z1/Z2: 1185mm/1050mm, rapid traverse X/Y/Z: 40m/min/24m/min/70m/min, speed: 5000rpm, B-axis: +/-120°, machine dimensions X/Y/Z: approx. 7800mm/4000mm/3000mm, weight: approx. 15000kg, control: Heidenhain plusIT Pilot, machine hours: 51320h, spindle hours: 34158h. Documentation available. An on-site inspection is possible.

CATEGORY — 5 Axis MANUFACTURER — DMG MORI MODEL — DMU 85 MONOBLOCK STOCK NUMBER — ONY100000587 MODEL YEAR — 2013 CONTROL PANEL — SIEMENS 840 D SOLUTIONLINE AXIS STROKE — X 935 MM / Y 850 MM / Z 650 MM ROTARY AXIS MOVEMENTS — A +/- 120 ° / C 360 ° SPINDLE SPEED — 18.000 MIN/-1 POWER CAPACITY-MAIN SPINDLE — 35 kW (40% ED) MAX. TORQUE — 135 Nm (40% ED) TOOL HOLDERS — SK 40 NUMBER OF TOOLPOSITIONS — 30 TABLE SURFACE AREA — 1.000 X 750 MM ( d 850 X 750 MM) MAX. TABLE LOAD — 1.000 KG TOTAL POWER REQUIREMENT — 46 KVA WEIGHT OF THE MACHINE — 13.500 KG DIMENSIONS OF THE MACHINE — 3.15 X 3.92 X 3.21 M

Inv. Num. : 9033 Type: PUMA ST32G Producer: DOOSAN Created: 2018 Parameters: Control System: FANUC Series 31i Model B Switch-on hours: 4,360 h Hours: 2,443 h Maximum turning diameter: 32 mm Max. turning length: 320 mm Maximum spindle speed: 8000 1/min Axis Z: 320 mm Rapid traverse X/Y/Z: 32 m/min Spindle diameter: 32 mm Length: 2640 mm Width: 1400 mm Height: 1840 mm Weight: 3500 kg Equipment: Technical documentation Chip conveyor High-pressure cooling 70 bar IEMCA BOSS 338 Bar Feeder Oil mist extraction Losma

Milling machine Manufacturer: Hermle Type: C600U Year of Make: 2002 CNC control: Heidenhain iTNC 530 Travels: X/Y/Z: 600 x 450 x 450 mm NC swivel rotary table Rotation range: C-axis 360° Spindle speed: 30,000 rpm Tool holder: HSK40 Tool changer: 30-fold Operating hours: approx. 22,000

Table dimensions 1000 x 460 mm X Travel 762 mm Y travel 460 mm Z travel 460 mm Table load 700 kg Chip conveyor Weight 6500 kg Dimensions LxWxH = 2750 x 2160 x 2715 mm Spindle clearance: 0.05 - 0.10 mm Repair: approx. 9,000 € New: 12.000 €

CNC Control: FANUC 18i-T Number of Axes: 5 (Twin-Spindle Configuration) Main Spindle: Present Sub-Spindle: Turrets: 2 Turrets with Motorized Tools Configuration: Combined Turning and Milling Weight (kg): Approx. 9000 Year & Manufacturer: 2004 – HARDINGE Auction-ID: A1-44765-259

machine Manufacturer: DECKEL MAHO Type: DMU 35 M Year of Make: 2001 Machine type: CNC universal milling center (3+2 axes) data Feed drive: AC servo motors for X, Y, Z axis Feed speed X/Y/Z: infinitely programmable up to 5,000 mm/min Rapid traverse X/Y/Z: 5 m/min Input unit X/Y/Z: 0.001 mm Work table: rotary table with swivel axis Clamping surface: 400 × 280 mm T-slot spacing / size: 50 / 12 H7 Centering bore: Ø 30 H6 Rotary table rotation range: 360° Desktop clamping: mechanical Swivel range: 105° / 15° Permissible load rotary table (centre of the table): 100 kg Dimensions Travel X/Y/Z: 350 × 240 × 340 mm Weight: approx. 1,700 kg Electrical details Voltage: 400 V Power: approx. 15 kVA Auction-ID: A7-45416-2143

Table 840 x 420 mm Travel X/Y/Z 600 / 410 / 520 mm, Spindle SK 40, speed up to 60001 rpm, Main drive 8.5kW, Tool changer 22 places Control Heidenhain TNC 370 incl. coolant device

The machine is currently still in production and will be professionally dismantled and prepared for transport in week 19. Due to the installation of the new machine, the planned date may still differ slightly. The loading (by buyer) of the machine will therefore take place in consultation. Auction-ID: A1-41992-1

A deposit of €1500.00 is required in order to submit a bid on this lot. To receive the bank details necessary for the transfer, please contact the auction representative at alessandro.icardi@surplex.com. Rotary table diameter 700 mm 24-position tool changer Cutting speed 15000 mm/min Fast feed speed 30000 mm/min Tables, utensils and accessories included Note: The functionality of the goods has not been verified. They are sold in their existing state, without warranty of operation. Auction-ID: A7-43861-8

turning diameter:356 mm turning length:705 mm control: CELOS M730 UM MAPPS swing dia.:742 mm standard turning diameter:275 mm travel -x axis:260 mm travel -y axis:100 ( ±50) mm travel -z axis:795 mm rapid travel - longitudinal/face:30 / 30 m/min Rapid travel B-axis (parts transfer subspindle):734 m/min Spindle 1 RPM:4000 1/min Spindle 1 Power:15/18,5/18,5 kW Spindle 1 Torque:409/505 /599 Nm Spindle 1 max. bar diameter:80 mm Spindle 2 RPM:4500 1/min Spindle 2 power:7,5/11 kW turret stations / rotary tool stations:20 / 20 BMT40 speed of driven tools:10000 1/min :3.7/5,5/5,5 kW torque rotary tools:14 / 24 Nm total power requirement:38 kVA weight of the machine ca.:6,3 t dimensions of the machine ca.:4 (9) x 2,1 x 2,2 m Parts catcher:Sp. 1 und Sp. 2 Spindle 1 Chuck:Kitagawa B 210 (250 mm) Spindle 2 Chuck:Kitagawa B 206 (160 mm) Tool presetter:Spindle 1 & 2 High precision Turning and Millin ...

turning diameter:370 mm turning length:200 mm Spindle 1 RPM:4000 1/min control:Siemens 840 D Spindle 2 RPM:4000 1/min power capacity:L / R 18/24 kW max. torque on the spindle:630 nM C-Axis:0,001° Turret No.1 stations / rotary tools:12/12 VDI 40 Turret No.2 stations / rotary tools:12/12 VDI 40 turning speed range - milling:3000 1/min power capacity - milling spindle:8,8 kW torque rotary tools:28 Nm Bar capacity spindle 1:85 mm total power requirement:65 kVA weight of the machine ca.:13 t dimensions of the machine ca.:5,7x2,4x2,1 m Travel x1:260 mm Travel x2:260 mm Travel Y1:600 mm Travel y2:600 mm Power Chuck:2 x 250 mm manual tool eye:l & r High performance 6-axis subspindle CNC-Lathe with twin turren and rotating tools.

turning diameter:65 mm turning length:120 mm control:Index C200-4D SL z-axis main spindle travel:390 mm z-axis subspindle travel:390 mm x-axis subspindle travel:600 mm Travel Y1:± 80 mm Travel y2:± 80 mm x-axis rapids:45 m/min y-axis rapids:15 m/min z-axis rapid travel:45 m/min Spindle 1 RPM:5000 1/min Spindle 1 Power:35,5/27,5 kW Spindle 1 Torque:170 /125 Nm Spindle 2 RPM:5000 1/min Spindle 2 power:35,5/27,5 kW Spindle 2 torque:170/125 Nm c-axis:0,00014 ° bar material dia.:65 mm spindle nose:AD 140 spindle bore:85 mm Milling spindle 1 RPM:18000 1/min Milling spindle 1 power:11 kW Milling Spindle1 torque:19 Nm Milling spindle 2 RPM:18000 1/min Milling Spindle 2 power:11 kW Milling spindle 2 torque:19 Nm B-axes swivel angle:230 ° B-axes torque:440 Nm B-axes angle resolution:0,001 ° Milling spindle 1 & 2 tool magazine:80 HSK A40 Milling spindle 2 tool magazine static tools :6 x VDI 25 ...

turning diameter:640 / 400 mm turning length:1500 mm control:Siemens 840 D Powerline Travel turret No.1 (milling spindle) x/y/z:550 / 180 (±90) / 1585 mm Swivle angle milling spindle (B-axis):±120° interpol. ° Rapid traverse feeds turret 1 (milling head) x/y/z:40/24/60 m/min RPM milling spindle:12000 1/min power capacity - milling spindle:12 / 23 kW Torque of milling spindle:100 Nm Tool magazine for milling spindle (turret 1):120 HSK-A 63 Tool change time tool/tool, milling spindle:1,6 s Spindle 1 RPM:4000 1/min Spindle 1 power:36/ 45 kW Spindle 1 Torque:730 Nm Spindle 1 max. bar diameter:90 Spindle 2 RPM:4000 1/min Spindle 2 power:36 / 45 kW Spindle 2 torque:730 Nm Spindle 2 max. bar diameter:90 c-axis:0,001 ° Travel turret 2 x:225 mm Travel Turret 2 z:1595 mm RPM of rotary tools turret 2:4000 1/min no. of tools in turret 2:12 VDI 40 high-pressure pump:20 bar total power requiremen ...

turning diameter:670 mm turning length:1540 mm control:F31iB5 Celos Fanuc 35iB5 swing diameter max. over bed cover:700 mm Travel turret No.1 (milling spindle) x/y/z:495 / ± 150 / 1562(+164) mm Rotation B-axis:-30° / +210° Rapid traverse feeds turret 1 (milling head) x/y/z:40/40/40 m/min RPM milling spindle:12000 1/min power capacity - milling spindle:20,2/18,8 kW Torque of milling spindle:120 / 44 Nm tool taper milling spindle:Coromant Capto C6 Tool magazine for milling spindle (turret 1):76 Tool change time tool/tool, milling spindle:1,25 s Spindle 1 RPM:3000 1/min Spindle 1 Power:36 / 30 / 25 kW C-axis spindle 1:0,001 ° Bar capacity spindle 1:102 mm Spindle 2 RPM:4000 1/min Spindle 2 power:26 / 22 / 15 kW C-axis spindle 2:0,001 ° Bar capacity spindle 2:80 mm dimensions of the machine ca.:7,8 x 3,6 x 2,9 m Linear scales on axis:X, Y programmable steady:KLU-A530 & SLU-X3.2 Spindle 1 ...

turning diameter:500 mm turning length:1000 mm control:Siemens 840 D spindle:42 / 28 kW spindle turning speed - stepless:31 - 4000 1/min max. torque on the spindle:345 Nm c-axis:360000 x 0,001° feeds -stepless-:0 - 10000 mm/min rapid traverse:10000 mm/min turret stations / rotary tool stations:12/12 VDI 40 RPM of rotary tools:2000 1/min diameter of quill:90 mm quill stroke:80 mm tailstock quill taper ISO:SK 30 Tailstock Travel:600 mm Power rotary tools:3,5 kW :22,5 Nm Rotary tool holders:4 ax./ 4 rad. spindle passage:66 mm total power requirement:30 kW weight of the machine ca.:7,5 t dimensions of the machine ca.:8x 3 x 4 m
