126,702 used machines on RESALE, but how to find them? Machine Search
Inv. Num. : 8982 Type: GX 1000 Producer: Bridgeport Hardinge Created: 2007 Parameters: Control system: Siemens 810 D Number of stacking positions: 24 pieces Maximum vertical spindle speed: 8000 1/min X-axis travel: 1020 mm Y-axis travel: 510 mm Travel Z-axis: 510 mm Cone: SK 40 With automatic change
Manufacturer: EWAG AG Model: Laser Line Ultra Machine type: 5-axis laser processing center Serial number: 7195-0022 Release: 5 Year of Make: 2016 Laser Source: Coherent Hyper-Rapid 50 Laserhead Laser manufacturer: Coherent Kaiserslautern GmbH Laser Manufacturing Date: 28.01.2016 Laser classification machine: Laser System Class 1 according to DIN EN 60825-1:2008-05 Axes: X, Y, Z, B, C CNC Control: Fanuc 31i-5 Control Operating voltage: 3 × 400 VAC/N/PE Frequency: 50 Hz Control voltage: 24 V DC Rated current: 17.3 A Connected load: 12 kVA Max. fuse: 25 A (slow-blow) Electrical diagram number: 100211907 Extraction: ULT LAS 200 extraction system Documentation: fully available Operating hours: 3578802 h Note: Laser unit defective and needs to be replaced Robot is currently being expanded and is being overhauled, optionally available Viewing possible under power
Inv. Num. : 8973 Type: MCFV 1680 Producer: ZPS Created: 2010 Parameters: Work table length: 1800 mm Work table width: 780 mm X-axis travel: 1650 mm Y-axis travel: 810 mm Travel Z axis: 810 mm
Manufacturer: EWAG AG Model: Laser Line Ultra Machine type: 5-axis laser processing center Serial number: 7195-0022 Release: 5 Year of Make: 2016 Laser Source: Coherent Hyper-Rapid 50 Laserhead Laser manufacturer: Coherent Kaiserslautern GmbH Laser Manufacturing Date: 28.01.2016 Laser classification machine: Laser System Class 1 according to DIN EN 60825-1:2008-05 Axes: X, Y, Z, B, C CNC Control: Fanuc 31i-5 Control Operating voltage: 3 × 400 VAC/N/PE Frequency: 50 Hz Control voltage: 24 V DC Rated current: 17.3 A Connected load: 12 kVA Max. fuse: 25 A (slow-blow) Electrical diagram number: 100211907 Extraction: ULT LAS 200 extraction system Documentation: fully available Operating hours: 3578802 h Note: Laser unit defective and needs to be replaced Robot is currently being expanded and is being overhauled, optionally available Viewing possible under power
Cutting center Type: TS 90 Manufacturer: Macmazza Year: 2019 Cutting length: 4300 mm Effective Cutting Height: 72 mm Motor power: 10 – 20 hp Main blade diameter: 220–325 mm Weight: 3500 Kg Dust extraction hood diameter: 2×120 mm 2×100 mm Saw carriage advance speed: 3-50 m/min Saw carriage return speed: 30-120 m/min Pusher speed: 2-25 m/min Pusher return speed: 25-70 m/min Suctions: 4000 m³/h 2500 N/m² Label printer Machine in good condition, under power Find more here - / Contact us at -
A CNC tube welding system Weil Technology for longitudinal seam welding is available. Tube diameter range: 76mm-600mm, Tube length range: 250mm-1550mm, Material thickness range: 0.8mm-2mm, Welding process: Laser, Max. welding output: approx. 80pieces/h. Documentation available. An on-site inspection is possible.
Key data: 850 mm, 510 mm, 510 mm
General Manufacturer: Spinner Type: VC 850 Year of Make: 2021 Control: Siemens 840DE ShopMill Travel X/Y/Z: X 850 mm Y 510 mm Z 510 mm Working spindle Spindle speed: 18,000 rpm Tool holder: HSK63 Tool changer: 32-fold Voltage Operating voltage: 3x400V +/-10% Power frequency: 50Hz (+/-2%) Condition Condition: Used Functional: Tested and fully functional Other equipment and accessories included: Direct measuring systems in X/Y/Z Multifunction handheld operator Chip conveyor Preparation of spindle stylus
Key data: 850 mm, 510 mm, 510 mm
General Manufacturer: Spinner Type: VC 850 Year of Make: 2021 Control: Siemens 840DE ShopMill Travel X/Y/Z: X 850 mm Y 510 mm Z 510 mm Working spindle Spindle speed: 18,000 rpm Tool holder: HSK63 Tool changer: 32-fold Voltage Operating voltage: 3x400V +/-10% Power frequency: 50Hz (+/-2%) Condition Condition: Used Functional: Tested and fully functional Other equipment and accessories included: Direct measuring systems in X/Y/Z Multifunction handheld operator Chip conveyor Preparation of standard probes
Key data: 850 mm, 510 mm, 510 mm
General Manufacturer: Spinner Type: VC 850 Year of Make: 2022 Control: Siemens 840DE ShopMill Travel X/Y/Z: X 850 mm Y 510 mm Z 510 mm Working spindle Spindle speed: 18,000 rpm Tool holder: HSK63 Tool changer: 32-fold Voltage Operating voltage: 3x400V +/-10% Power frequency: 50Hz (+/-2%) Condition Condition: Used Functional: Tested and fully functional Other equipment and accessories included: Direct measuring systems in X/Y/Z Multifunction handheld operator Chip conveyor Preparation of standard probes
Manufacturer: MTcut Model: UE110-5A Type of Machine : 5-Axis CNC Vertical Machining Centre Power Supply: 400V / 100A / 70 KVA Compressed Air: 3/8 inch, 6-8 bar Coolant Tank: 120 litres Central Lubrication: R68 (ISO68) Hydraulic Oil: R32 (ISO32) Machine Weight: 9,000 kg Machine Bed: Cast Iron Travel and Work Envelope: - X Axis: 1,100 mm - Y Axis: 610 mm - Z Axis: 610 mm - B Axis (Swivel Head): -30 / +120 degrees continuous - C Axis (Rotary Table): 0.001 x 360 degrees - Spindle Nose to Table: 105 - 715 mm Spindle: - Speed: 14,000 rpm - Torque: 160 Nm - Power: 29 kW - Cooling: Water cooled - Tool Interface: HSK63 Swivel Milling Head: - Swivel Range: +30 / -120 degrees stepless - Speed: 11 rpm - Positioning Accuracy: 10 arc seconds - Max Holding Torque: 1,320 Nm - Drive: Siemens Torque Motor Rotary Table: - Diameter: 610 mm - Speed: 50 rpm - Positioning Accuracy: 15 arc seco ...
Traub TNL 20 – 9B Machine No. 11920182 Year of construction 2022 TX8i-s control (with Polyform / Helical / 19" multi-touch with gesture technology) Alternating operation: Use as a short or long-turning lathe Main spindle D20 (with 10,000 rpm) with C-axis Sub-spindle D20 with X/Z/C axis Tool carrier top X/Y/Z/H/B axis with 8 tool holders Tool carrier lower X/Y/Z/H axis with 8 tool holders Recirculating apparatus with 4 tool positions Cooling lubricant mist extraction and filter system Automatic CO2 extinguishing system Accuracy Package Tool breakage control device (Wkz beam above) Tool breakage control device (Wkz beam below) Hinge Belt Chip Conveyor Coolant system with 20 to 80 bar pump Charging magazine FMB Turbo 2-20 Sliding device for loading magazine Portal workpiece removal unit Workpiece conveyor belt
CNC machining center Emco, type VMC 600, built in 1998 incl. handwheel + 3 vices with clamping device
x-travel: 850 mm y-travel: 500 mm z-travel: 500 mm taper: ISO 40 P.D.B. table-size: 400x1250 mm volt: 400 V Control: Heidenhain TNC 355 total power requirement: 7,5 kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
A vertical CNC 5-axis machining center POS is available. Travel X/Y/Z: 670mm/820mm/600mm, rotary table diameter: 800mm, max. table load: 1200kg, tool positions: 96, tool holder: HSK-63, speed: 18000rpm, A-axis: -100°/120°, C-axis: 360°, weight: approx. 20000kg, control: Heidenhain, operating hours: 22177h, spindle hours: 9601h. Including infrared probe, IKZ and Blum laser tool measurement. Documentation available. An on-site inspection is possible.
A vertical CNC 3-axis gantry machining center POS is available. Travel X/Y/Z: 2050mm/1050mm/780mm, table dimensions X/Y: 2200mm/1000mm, max. table load: 3000kg, tool holder: HSK-63, tool stations: 60, speed: 18000rpm, rapid traverse: 30m/min, feed rate: 10m/min. Machine dimensions X/Y/Z: approx. 6500mm/4200mm/3800mm, weight: approx. 20000kg, control: Heidenhain, spindle hours: 10375h. Including infrared probe, IKZ and Blum tool measurement. Documentation available. An on-site inspection is possible.
Vertical Machining Center YCM - VMC 65A / Fanuc OM -CE marking -Control Fanuc OM -Operational condition / function video available -Travel X / Y / Z 650x410x615mm -Table dimensions 840x420mm -Speed range up to 6000rpm -Tool holder BT 40 -Tool magazine / side changer 16 compartment -Electric handwheel -Coolant device -Motor power 7.5 KW -Machine feet Dimensions: LxWxH 3.5x2.4x2.8 meters / Weight 4500Kg
CNC Turning and Milling Center Okuma LT 2000 EX -MY 2pcs Control: OSP-P300L Year of Make: 2013 Turning diameter over bed: 400 mm Center spacing: 960 mm Turning diameter: 210 mm Speed: 50 – 6,000 rpm Sub-spindle speed 50 – 6,000 rpm Travels: W-axis 730 mm X-axis 205 mm C-axis: 360 degrees (0.001) 2 tool turrets with 16 places each (all places driven) Equipment: - Chip conveyors - Paper belt filter system with high-pressure pump - 2x 3-jaw chuck Kitagawa - OGL gantry loader with approx. 5 kg load capacity - Stacking magazine 20 places - Touchsetter - Renishaw touch probe - Extraction system - Various accessories
CONTROLS CNC controls SIEMENS 840 D SL WORKING RANGE -CUBIC- number of processing axes (excl parallel axes): 4 X-axis travel: 210 mm Y-axis travel: 270 mm Z-axis travel: 360 mm SPINDLE / HEAD spindle revolutions (max): 40000 /min tool fixture: HSK A40 TOOL MAGAZINE number of positions: 64 AUTOMATIC WORKLOAD EQUIPMENT workpiece manipulator: articulated robot number of store positions: 32 ELECTRICAL SPECIFICATIONS mains voltage: 400 V mains frequency: 50 Hz DIMENSIONS / WEIGHTS total weight approx.: 9000 kg ATTACHMENTS chip conveyor: yes coolant unit: yes band filtration unit: yes closed cabin: yes Operating hours: Spindle 1: 4050 h, Spindle 2: 11,114 h Internal cooling 70 bar Fanuc ...
CONTROLS CNC controls SIEMENS 840D SL 4.8 WORKING RANGE -CUBIC- number of processing axes (excl parallel axes): 4 X-axis travel: 210 mm Y-axis travel: 270 mm Z-axis travel: 360 mm SPINDLE / HEAD spindle revolutions (max): 40000 /min tool fixture: HSK A40 TOOL MAGAZINE number of positions: 72 AUTOMATIC WORKLOAD EQUIPMENT workpiece manipulator: articulated robot number of store positions: 36 ELECTRICAL SPECIFICATIONS mains voltage: 400 V mains frequency: 50 Hz DIMENSIONS / WEIGHTS space requirements -left/right-: 8500 mm space requirements -front/back-: 2500 mm total weight approx.: 6000 kg ATTACHMENTS central lubrication system: yes chip conveyor: yes coolant unit: yes &n ...
Manufacturer: Weeke Model: Optimat BHC Venture 1 Year of Manufacture: 2006 Operating Hours: 20000h Electrical: - Power Supply: 400V / 50 Hz / 3-phase + N - Total Power: 18 kW - Current: 35 A - Control Voltage: 24V Find more here - / Contact us at -
Used machine Machine Type: CNC Turning Center Model No.: NLX3000Y/3000 Manufacturer: DMGMORI Control: Celos Year of Make: 2020 #001355 Turning diameter max. approx. 420 mm Turning diameter standard approx. 310 mm Chuck size approx. 300 mm Turning length approx. 3,123 mm Rod diameter max. approx. 90 mm Turret stations approx. 12 X-axis approx. 280 mm Z-axis approx. 3,170 mm Y-axis approx. 120 (±60) mm Tailstock approx. 3,164 mm Spindle speed max. approx. 3,000 rpm Speed AGW max. approx. 6,000 rpm Rapid traverse X/Z approx. 30 m/min Rapid traverse Y approx. 10 m/min Rapid traverse C approx. 300 rpm Power consumption approx. 54 kVA Compressed air bar,L/min approx. 5, 100 bar,L/min Footprint L x W x H approx. 8.30 x 3.50 x 2.41 m (without chip conveyor) Machine weight approx. 14,200 kg Main spindle 22/18,5KW • 3jaw chuck set • rpm 3000 • 12 station turre ...
Manufacturer: Queser Model: MV 154 EL Year of Manufacture: 2012 Type of Machine : Machining Center - Low hours - Very good condition - Many tools Find more here - / Contact us at -
CK 50 CNC turning center was built in 2022. This state-of-the-art, extremely efficient machine is used in both unit and series production. Workpieces with a maximum diameter of 570 mm and a length of 500 mm are machined by means of a reliable spindle and cutting tools taken from a 12-position turret. The spindle, driven by a high-powered motor reaches a speed of 4200 rpm and moves in two X,Z axes with feeds of 270 mm and 610 mm respectively. The hydraulic tailstock, in turn, ensures precise positioning and support of the workpiece during the turning process. The CNC CK50 lathe has an inclined bed, which increases the stability of the design through better distribution of loads during machining. This solution reduces the risk of vibration and oscillation, thus increasing turning accuracy and giving the ability to perform more complex operations. It also makes it easier to evacuate the ...
Used machine Machine Type: CNC Turning Center Model: CLX 750 V3 Manufacturer: DMGMORI Control: SLIMllne® Multi-Touch Control Siemens Year of Make: 2021 Location: Germany #001273 Turning diameter max. approx. 700 mm Turning diameter standard approx. 610 mm Chuck size approx. 400 mm Turning length approx. 1,300mm Rod diameter max. approx. 127 mm Turret stations approx. 12 X-axis approx. 435 mm Z-axis approx. 1,300 mm Tailstock approx. 1,200 mm Spindle speed max. approx. 2,000 rpm Speed AGW max. approx. 4,000 rpm Rapid traverse X/Z approx. 30 m/min Compressed air bar,L/min approx. 5, 100 bar,L/min Machine weight approx. 10,200 kg Facilities - Main spindle A2-11" with AC motor, 36/46 kW (100/40%), 2,000 min-¹ - 3-jaw chuck 300mm - Partial hollow clamping device for the main spindle 127mm - Chuck flush for the main spindle - 12-fold servo tool turret mount VDI ...
Used machine CNC turning-milling center Machine type: DMG MORI CLX450TC Control:DMG MORI SLIMline® Siemens Operate Year of Make: 2022 Location: Germany #0011281 Technical data Turning diameter max. spindle 1+2 approx. 400 mm Turning diameter standard spindle 1+2 approx. 250 mm Rod diameter max. spindle 1 approx. 65 mm X-axis approx. 750 mm Z-axis approx. 1,100 mm Y-axis approx. +-100 mm A-axis (spindle 2) approx. 1,200 mm B-axis approx. 240° (+-120°) mm Spindle speed 1+2 approx. 5,000 rpm Speed milling pindle approx. 12,000 rpm Rapid traverse X/Y/Z approx. 40 m/min Rapid traverse A spindle 2 approx. 40 m/min Rapid traverse B axis approx. 70 m/min Power spindle 1+2 max. approx. 17 (40%) kW Power milling spindle max. approx. 10.5 (40%) kW Facilities Main Drive Spindle 1/2 17KW 40% - 5000rpm - Turning-Milling Spindle HSK63 10,5KW 40% - 12,000rpm - tool magazi ...
Used machine Machine type: CNC turning and milling center Model No.: CTXgamma1250TC4a Manufacturer: DMGMORI Control: Celos with Siemens 840D si First commissioning: 2020 #001348 Location: Germany Technical data - Main spindle as integrated spindle motor, ISM102 - Sub-spindle as integrated spindle motor, ISM 76 - tailstock function for the sub-spindle - C-axis and spindle brake (hydr.) - Chuck rinsing device of the main spindle, external - Absolute, direct displacement measuring systems X-'Y-'Z1-axis - Differential stress main spindle - 36-cavity tool disc magazine - Hinge belt chip conveyor - Coolant system 8/20/80 bar - Coolant supply through the sub-spindle - Coolant spray gun - Mechanical oil mist separator - Automatic work area door - Workpiece probes - Tool turret at the bottom This offer is subject to change and non-binding. Changes, errors and prior ...
Used machine Machine Type: CNC Swiss Automatic Lathe Model: Sprint32/8 Manufacturer: DMGMORI Control: Fanuc 32i First commissioning: 2019 #001328 Location: Germany T-main and sub-spindle - Y-axis on carriage 1 - Y-axis on carriage 2 - C-axis on main spindle - C-axis on sub-spindle - Tank for chips included Coolant Pump - Workpiece unloading belt - Flushing for counter-spindle pliers - Hinge belt chip conveyor - Signal lamp 4-colour - IEMCA Boss 338/32HD bar feeder This offer is subject to change and non-binding. Changes, errors and prior sale expressly reserved.
Used machine Machine type: CNC turning and milling center Model: CTXalpha 500 V6 Manufacturer: DMGMORI Control: Celos with Siemens 840D si First commissioning: 2022 #001272 Technical data Turning diameter max. approx. 240mm Turning diameter standard approx. 200mm Chuck size approx. 210mm Turning length approx. 480mm Rod diameter max. approx. 52/option65mm Turret Stations 12 X-axis approx. 210mm Z-axis approx. 525mm Spindle speed 1/2 approx. 5000/6000 rpm Speed AGW max. approx. 5000U/ Rapid traverse X/Z/Y 30/30/22.5 • Main spindle 5000 Ulmin • Hydraulic 3-jaw chuck 210 mm • Sub-spindle 6000 Ulmin • Hydraulic 3-jaw chuck 170mm • 12 station turret VDI 30 Trifix • Tool drive for all stations • C-axis • Y-axis • Alternating speed • Coolant supply through the sub-spindle • Swivelling tool presetter • Coolant spray gun, 5bar • CTXalpha ...
Used machine CNC Turning and Milling Center Machine Type: CNC Lathe Model No.: NLX2500Y/700 Manufacturer: DMG MORI Control: CELOS Year of Make: 2016 #001252 - Main spindle 4,000 rpm - Clamping cylinder main spindle - 3 cheek chuck - Foot switch (double) for main spindle - Y-axis - 12-speed BMT60-star turret for powered tools - Cantilever length X-axis driven tools 100mm - Scraper belt chip conveyor, rear discharge - High-pressure cooling system (800/1,100 W) 5bar - Line filter for coolant - Mechanical interface for oil mist separator 150mm - Without in-machine tool presetter This offer is subject to change and non-binding. Changes, errors and prior sale expressly reserved.
Used machine Machine Type: CNC Turning Center Model No.: CLX450V4 Manufacturer: DMGMORI Control: SLIMline® Multi-Touch Contr./Fanuc Year of manufacture: 2023 #001354 TECHNICAL DATA: Turning diameter max. approx. 400 mm Turning diameter standard approx. 310 mm Chuck size approx. 260 mm Turning length approx. 755 mm Rod diameter max. spindle/chuck approx. 80/78 mm Turret stations approx. 12 X-axis approx. 276 mm Z-axis approx. 830 mm Y-axis approx. 120(+-60) mm Tailstock approx. 800 mm Spindle speed approx. 4000 rpm Speed AGW max. approx. 4000 rpm Rapid traverse X/Z approx. 30/30 m/min Rapid traverse Y approx. 22.5 m/min Footprint L x W x H approx. 4.30x2.45x2.30 m (with chip conveyor) Machine weight approx. 6,250 kg Main spindle A2-8" 17 / 25.5 kW (100/40% ED), 4,000 rpm - 3-jaw chuck - Differential Compressive Stress for the Main spindle - Foot control ped ...
Used machine CNC lathe Machine type: DMG Gildemeister NEF 600 Control: Heidenhain IT Turn Plus Year of Make: 2006 TECHNICAL DATA: Max. turning length: [mm] 1,250 Max. Rotary Ø over bed: [mm] 600 Max. rotary Ø over slide: [mm] 410 Spindle bore: [mm] 90 Number of controlled axes: 2 Speed range: [1/min.] 3,000 Drive power: [kW] 36.5 / 27.5 Torque: [Nm] 785 Tailstock MK 5 Quill 80mm Number of turrets: 1 Travel X-axis ob. Rev. / unt. Rev.: VDI 40/8 Tool positions: 8 Machine weight: [kg] 5,500 Space requirement (LxWxH): [m] 5.0 x 2.0 x 2.2 m Features: Chip conveyor 3-jaw chuck [mm] 315 This offer is subject to change and non-binding. Changes, errors and prior sale expressly reserved.
CNC Vertical Machining Center DECKEL MAHO DMF 260 linear NEW DMG Design With rail control Siemens 840 D with Shop Mill Year of Make: 2011 Travel: X 2600 Y 700 Z 700 Speed range: 20 – 14000 rpm infinitely variable ( SK 40 ) With the following accessories: Rigid angle table 2920 mm x 750 mm clamping surface Controlled swivel milling head ( B axis ) NC Dividing head Hofmann with tailstock tip height: 200 mm Vertical tool changer with 40 magazine positions ( SK 40 ) Electronic handwheel Full protection cabin with sliding doors and interior lighting IKZ 40 bar Chip conveyor Operating mode 3 + 4 2 x Rotoclear (rotating lens) Partition wall Coolant Setup Control cabinet cooling unit RITTAL 4 Height Adjustable Machine Shoes Operating instructions
The machine is in good technical condition, testing possible after prior agreement. Max. rotating diameter 480 mm (approx. to the current design of the workpiece removal blade) Max. machined diameter 340 mm Max. turning length 785 mm Collet + 10 hydraulic chuck B210-A06-01, 3x soft jaws (Schunk KM-WBL 103) 1x hard jaws (Schunk SHB-J 100) hydraulic through-cylinder SS 1770, draw tube Main spindle Spindle with JIS A2-6 end, bore dia. 80 mm, integrated motor Speed range 45 - 5,000 min-1 Power/continuous operation 22 kW/15 kW Continuously controlled C-axis, 3600 with 0.001 increment Secondary spindle Speed range 50 - 6,000 min-1 Power/continuous operation 11 kW/7.5 kW Spindle with end dia. 14O mm, bore dia. 62 mm, integrated motor Continuously controlled C-axis, 360° with 0.001° increment Collet + 6" hydraulic chuck B206-01, 3 x set of soft jaws (Schunk KM-WBL 62) hydraulic thr ...
At present, for office use (cadastral category A/10), the entrance is \"open space\", ideal for welcoming customers or for organizing different workstations in a flexible way. The main work area is completed at the rear by a second reserved compartment — perfect as a private office or archive — and a dedicated toilet. The property is in good general condition, proti with electrical system and heating by convectors. The transformation into a two-room residential apartment can be achieved thanks to the distribution of the spaces. CADASTRAL DATA: - Province of Pesaro/Urbino - Municipality of Macerata Feltria - Land Registry of Buildings, sheet 41 parcel 342, sub. 2, cat. A/10, class U, 3-room consistency, income € 402,84 URBAN PLANNING AND CADASTRAL COMPLIANCE: No urban planning checks were carried out, as the unit is located within a larger building built in the pre-1967 era a ...
Manufacturer: EMCO Model: MC 120-60 Year of Manufacture: 2008 Type of Machine : Machining Center Spindle hours: 10,459 CNC Control: Fanuc 18i-MB Tool holder: SK40 Condition: Used, fully functional Axis Travel - X axis: 1,200 mm - Y axis: 600 mm - Z axis: 500 mm - 4th axis: Yes, installed - 5th axis: No Equipment and Features - Tool magazine: 30 positions - Band filter: Yes - Chip conveyor: Yes - SK40 toolholder package included - Fully operational Lang Eco Compact 10 automation system with 10 vices included - Custom-built slatted loading rack for ergonomic loading and unloading of machine and - automation Find more here - / Contact us at -
Control Siemens 828D Travel X/Y/Z: 1300 x 710 x 610 mm Table size: 1450 x 610 mm Spindle speed: 12,000 min-1 Tool magazine for 30 Wkz., SK 40 Cooling by the spindle 3D Probes
Key data: 800 mm, 900 mm, 650 mm
Double-spindle machining center with swivel beam for mounting tension bridges Spindle spacing 800 mm Spindle speed up to 12,500 1/min Power 10% - 40% - 100% ED = 42 / 35 / 28 KW Torque 10% - 40% - 100% ED = 200/ 165/ 135 Nm Tool changer 2 x 42 tool positions Tool holder HSK 80 Rapid traverse 120 m/min - CNC control Siemens 840 Dsl - Central coolant facility
The machine is in good technical condition, after prior agreement it is possible to test it. Spindle completely overhauled summer 2023 Ball screw replaced in Z axis in 2020. Feeds: X axis 850 mm Y axis 700 mm Z axis 750 mm Working feed 1-24000 Positioning accuracy +/- 0.005 Rapid feed – 48m/min all axes. Distance spindle face – front of table 150-900 mm Distance spindle axis – pallet surface 50-750 mm Pallet – 500 x 500 Spindle alfaP22/8000 Motor power (continuous/15') – 11/15/18.5 Spindle speed – 8000 rpm Base speed – 8000 rpm Tool clamping force – 1000 N Max. torque (15') 29.2 Nm Orientation built-in sensor Taper ISO 40, taper 7/24 Power transmission – synchronizing belt and pulley Cooling through the spindle – 70 kg/cm2, max flow 20 L/min, pump power 3.7 KW Magazine for 60 tools – chain – be careful, the catalogue incorrectly states 40.
CONTROLS CNC controls SIEMENS 840 D WORKING RANGE -CUBIC- number of processing axes (excl parallel axes): 4 X-axis travel: 550 mm Y-axis travel: 320 mm Z-axis travel: 360 mm TABLE table surface (left-right): 820 mm workpiece load (max): 500 kg SPINDLE / HEAD spindle revolutions (max): 24000 /min tool fixture: HSK A50 AXIS DRIVES rapid traverse: 75000 mm/min TOOL MAGAZINE number of positions: 24 AUTOMATIC WORKLOAD EQUIPMENT workpiece manipulator: articulated robot store type: table changer number of store positions: 2 ELECTRICAL SPECIFICATIONS mains voltage: 400 V mains frequency: 50 Hz DIMENSIONS / WEIGHTS total weight approx.: 7700 kg ATTACHMENTS guideway covers: yes &n ...
Machining length X: 5000mm, machine dimensions X/Y/Z: approx. 7500mm/3500mm/3500mm, weight: approx. 14000kg, control system: Heidenhain 426, operating hours: 91758h, running hours: 36086h. Including tool changer and tool holders. Without extraction system. Documentation available. An on-site inspection is possible.
Travel X/Y/Z: 1600mm/400mm/425mm, table dimensions X/Y: 2000mm/400mm, max. table load: 350kg, tool positions: 12, tool holder: SK30, speed: 6300rpm, feed rate: 10m/min, rapid traverse: 20m/min, machine dimensions X/Y/Z: approx. 4000mm/2300mm/2800mm, weight: approx. 5000kg, control: Siemens Sinumerik. The hoses, the Y-axis cover, and the battery (data loss) are in need of repair. An on-site inspection is possible.
A Schüco roll crimping machine for joining aluminum half-shells with polyamide insulating bars in thermally broken profiles is available. Profile throughput speed: approx. 34m/min, max. profile installation depth: 250mm, max. profile height: 400mm, max. insulating bar spacing: 300mm, machine dimensions X/Y/Z: approx. 900mm/900mm/1650mm, weight: approx. 750kg. Including infeed and outfeed. Documentation available. An on-site inspection is possible.
A Bridgeport CNC vertical machining center is available. Travel X/Y/Z: 1020mm/510mm/500mm, rapid traverse: 40m/min, feed rate: 10m/min, table dimensions X/Y: 1150mm/490mm, max. table load: 900kg, tool holder: BT40, tool stations: 30, machine dimensions X/Y/Z: approx. 2700mm/2550mm/2450mm, weight: approx. 3800kg. Documentation vorhanden. An on-site inspection is possible.
Inv. Num. : 9030 Type: EM80 Producer: ADIGE Created: 2015 Parameters: Control system: SIEMENS Switch-on hours: 37558 h Hours: 26407 h Machine weight: 8500 kg The machine is designed to process steel tubes with a length of 20–600 mm and a diameter of 20–80 mm.
CNC turning and milling center MacTurn 30 Control: OSP-U100L Year of Make: 2001 Internal machine no. 51 Turning length: 1,000 mm Turning diameter: max. 500 mm Circumferential diameter over bed: 500mm Circumferential diameter over face slide: 500 mm Tool holder: SK 40 Tool positions: 60 places Travels: X-axis: 430 mm Y-axis: 190(+/-95) mm Z-axis:1,090 mm C-axis: 0.001° - Three-jaw chuck SMW Autoblok - Tailstock programmable - Chip conveyors - Paper belt filter system with high-pressure pump - Oil mist extraction - Touchsetter - One Touch IGF - Door Automatic - Large baking package - Large tool package
Item sold in NOT verified status. Auction-ID: A7-44984-1
A defective CHC stone processing center Intermac is available. Travel X/Y: 2300mm/1000mm, material thickness range: 2mm-25mm, speed: 12000rpm, machine dimensions X/Y/Z: approx. 4700mm/2700mm/2700mm, weight: approx. 3500kg. A cost estimate from the manufacturer is available. Documentation available. An inspection on site is possible.
maximum number of results exceeded
please refine your search
60.000 €
