milling center used for sale

COLCHESTER TORNADO 100 CNC turning center built in 1995 in England is used for precision machining of workpieces with a maximum diameter of 420 mm. The machine features a large, fully illuminated workspace with a 12-position turret and an extremely powerful spindle. The 60° inclined bed ensures remarkable process stability, even during the most intense challenges. This is completed by the intuitive CNC control in which all machining programmes are created in just a few steps. The TORNADO 100 CNC lathe weighs 2400 kg. Technical specifications of the COLCHESTER TORNADO 100 metal lathe - CNC controller - HMI panel: VILUX - feed in the X/Z axis: 180/350 mm - rapid traverse in the X/Z axis: 10/15 m/min - turning diameter over bed: 420 mm - turning diameter over slide: 297 mm - maximum turning diameter: 186 mm - maximum turning length: 350 mm - maximum spindle rotational speed: 60 ...

Inv. Num. : 7917 Type: VF-2SS Producer: HAAS Created: 2015 Parameters: Work table length: 914 mm Work table width: 356 mm Maximum table load (uniform): 680 kg Spindle drive power: 22.4 kW Maximum vertical spindle speed: 12000 1/min X-axis travel: 762 mm Y-axis travel: 406 mm Travel Z-axis: 508 mm Machine weight: 3539 kg

Key data: 635 mm, 510 mm, 460 mm

CNC Vertical Machining Center "DECKEL MAHO DMC 635 eco" With path control Siemens 810 Powerline Year of Make: 2010 Travel: X 635 Y 510 Z 460 Speed range: 20 – 8,000 rpm infinitely variable With the following accessories: Rigid angle table 790 mm x 560 mm clamping surface Vertical tool changer with 20 magazine positions Electronic handwheel Tool length measurement Heidenhain TT 140 Full protection cabin with sliding doors and interior lighting Coolant Setup Signal light 4 colour Conveyor Chip rinsing gun 3 Height Adjustable Machine Shoes Operating instructions

Key data: 1000 mm, 600 mm, 700 mm

Ref.Nr. 00837 Name of the system: Vertical machining center Manufacturer: AXA Model VSC 2-M Year of construction 2000 Operating hours control on 51.155 h:56:02 Machine One 108350:06:047 Program run 34892:28:03 X axis stroke 2360mm/2 x 1000mm Y axis stroke 600mm Z axis stroke 700mm 1 spindle design SK 40 DIN 69 871 A 1 tool changer for 22 mounts side version 1 control panel with CNC path control Heidenhain TNC 426/430 on the left side of the machine 1 control cabinet integrated in the back of the machine Ball screws make Deutsche Star X axis 1510 – 4 – 3914 Ǿ 40 x 20 x 2960lg. Y axis 1510 – 4 – 5103 Ǿ 49 x 29 x 1300 lg. Z axis 1510 – 4 – 4811 Ǿ 40 x 10 x 1190 lg. Measuring system: Make Heidenhain X axis: LS 186 C 2440 ML Y axis: LS 186 C 740 ML Z axis: LS 186 C 940 ML Central lubrication aggregate make Bielomatik Hydraulic ...

Key data: 65 mm, 300 mm

Machine Details Stock-No. 1105-04031 Type of machine CNC Lathe Make GILDEMEISTER Type MF Sprint 65 V Year of manufacture 1998 Type of control CNC Storage location FRANCE Country of origin Germany Delivery time immediately Freight basis ex Warehouse Price Technical details turning diameter 65 mm turning length 300 mm control SIEMENS 840C Additional information CNC-automatic lathe with with 6 - axis, 4 stations for live tools,in 1 revolver WITH bar loader, bar length up to 3000mm Chip Conveyor

4-axis machining centre with 8-fold tool changer for aluminium or PVC profiles Max. machining length: 6,400 mm Y-axis travel: 850 mm Travel Z-axis: 650 mm Swivel angle A-axis: 0° - 180° Max. Speed 21,000 rpm Windows operating system Minimum quantity spraying Tensioner detection and automatic displacement Chip conveyor belt in bed Steam extraction Pendulum operation through two light barrier areas Loading is included in the price Weight: approx. 4,500 kg

live center, live center, live morse taper, live center, live lathe center, live center, centering cone -Manufacturer: Bruckner, rotating centering point centering cone -Type: unfortunately without type designation -Recording: MK5 -Centering tip: Ø mm -Dimensions: Ø 95 x 295 mm -Weight: 6 kg

live center, live center, live morse taper, live center, live lathe center, live center, centering cone -Live center: Mount MK4 -Type: unfortunately without type designation -Dimensions: Ø 70 x 210 mm -Weight: 1.9 kg

fixed center, fixed punch center, fixed Morse taper, fixed center point, center points -Fixed centering tip: Ø 57 mm -Recording: MK4 -Dimensions: Ø 32 x 157 mm -Weight: 1.1 kg

Key data: 700 mm, 800 mm

Machine Details Stock-No. 1105-04033 Type of machine CNC Turning- and Milling Center Make DMG MORI Type CTX beta 800 Year of manufacture 2009 Type of control CNC Storage location HAGUENAU FRANCE Country of origin Germany Delivery time IMMEDIATELY Freight basis ex site Technical details turning diameter max. 390 mm turning length 800 mm control Sinumerik 840D sl Siemens Greates Pass Round Over Bed 700 mm Turning Speed Range - Main Spindle 20 - 4,000 min/-1 Power capacity - main spindle 45 / 35 kW max. torque 700 Nm C-Axis 360° Spindle Nose 220H5 Chucking diameter - mm max. bar capacity 102 mm number of toolpositions 12 pos. Number of driven toolspositions 12 pos. power capacity driven tool-stations 14.2 kW Spindle speed - driven tool stations 40 - 10.000 min -1 tool taper VDI 40 DIN69880 max. torque 34 Nm X-AXIS 290 mm Z-AXIS 800 mm rapid traverse X: 30 / ...

OMZ NT 20 vertical machining center :::TECHNICAL SPECIFICATIONS::: CNC Model: Fanuc CNC Version: 0i MD Tool Attachment: ISO 40 Number of spindle speeds: 10000 Number of tools: 20 X-axis travel: 725mm Y-axis travel: 450mm Z-axis travel: 450mm Fast feeds linear axes X Y Z: 32m/min Guides: roller Pallet change: yes Pallet size: 700x450mm Maximum allowable load: 350Kg Round pallet: yes High refrigerant pressure: yes :::D DIMENSIONS AND WEIGHT::: Length: 2950mm Width: 3360mm Height: 2885mm Weight: 7000Kg

Control Siemens Bar passage 32 mm 2 x 12-speed revolver with attached revolver Competition. Main / sub-spindle Y-axis turret top Parts pick-up device Conveyor IRCO Bar Loading Magazine

Table dimensions: 1.300 x 570 mm Courses (X/Y/Z) 1.050 X 570 X 510 mm - Number of tool stations: 30 - Rapid Traverse (X x Y x Z): 36 x 36 x 30 mm/min - Max. spindle speed: 12.000 rpm - Operating hours: 5.456 - Axes: 3

live center, live center, live morse taper, live center, live lathe center, live center, centering cone -Manufacturer: ABW, live center -Type: ZNB 204 -Recording: MK4 -Dimensions: Ø 100 x 215 mm -Weight: 3.5 kg

fixed center, fixed punch center, fixed Morse taper, fixed center point, center points -Manufacturer: ABW, fixed centering tip 2 pieces -Mounting: Morse taper MK6 -Price/Delivery: complete -Dimensions: approx. Ø 64/270 mm -Weight: 5.4 kg/piece

Used machine in good condition. Available for immediate delivery. - Max. tool length: 300/225 [350/225] - Number of tool stations: 33 - Control: HEIDENHAIN ITNC 530 - Working area (X x Y x Z): 650 x 650 x 550 mm - C-axis: 360 ? - Max. tool weight: 10 kg - Operating hours: 51.651 - Axes: 5 - Power: installed max: 16 kW - Weight: 13.000 - Dimensions (long x wide x high): 2.345 x 4.250 x 2.600 mm

fixed center, fixed punch center, fixed Morse taper, fixed center point, center points -Fixed centering point: MK3 with Morse taper sleeve Ø 40 mm -Morse taper sleeve: Type BL 340 -Dimensions: Ø 44 x 152 mm -Weight: 1.1 kg

- Tool measuring probe RENISHAW TS-23R - Rapid Traverse (X x Y x Z): 36 / 36 / 36 mm/min - Spindle taper: BBT40 - Travel (X x Y x Z): 1.000 x 560 x 600 mm - Number of tool stations: 30 (automatic) - Control: HW F i Series - Max. spindle speed: 12

- Auto power-off - Air blower - Chip conveyor - Spindle cooling (oil cooler) - 30 ATCs - Travel (X x Y x Z): 1.020 x 540 x 530 mm - Control: Fanuc 18iMB - Max. spindle speed: 12.000 rpm - Spindle type: BT 40

- Dataserver - AICC2 (200 blocks of read only) - S pindle cooling (oil cooler) - 30 ATCs - Chip conveyor - Travel (X x Y x Z): 1.000 x 550 x 500 mm - Number of tool stations: 30 - Working area (X x Y x Z): 1.100 x 500 mm - Max. spindle speed:

Used machine in good condition. Available for immediate delivery. - Travel (X x Y x Z): 800 x 510 x 630 mm - Working area (X x Y x Z): 950 x 510 mm - Max. workpiece weight: 500 kg - Axes: 3 - Weight: 5.800

live center, live center, live morse taper, live center, live lathe center, live center, centering cone -Manufacturer: Henninger, rotating centering point centering cone -Type: unfortunately without type designation -Recording: MK5 -Dimensions: Ø 116 x 300 mm -Weight: 8.2 kg

live center, live center, live morse taper, live center, live lathe center, live center, centering cone -Revolving center: Mounting MK6 -Type: unfortunately without type designation -Centering tip: Ø 150 mm -Dimensions: Ø 150 x 300 mm -Weight: 10.5 kg

Used machine in good condition. Available for immediate delivery. - Travel (X x Y x Z): 1.060 x 510 x 635 mm - Control: SIEMENS 828D - Working area (X x Y x Z): 1.200 x 500 mm - Max. workpiece weight: 800 kg - Max. spindle speed: 8.000 rpm - Spindle type: BT 40 - Dimensions (long x wide x high): 2.910 x 2.690 x 2.815 mm - Weight: 7.500

Key data: 750 mm, 750 mm, 725 mm

GENERAL Project No.: 905674 Quantity: 1 pcs. Manufacturer: HECKERT (STARRAG) Type: HEC 500 D Control: Siemens 840 D solutionline Year of Make: 2011 Condition: Used machine Layers approx.: 2-3 layers DESCRIPTION MILL Travel in X 750 mm Travel in Y 750 mm Travel in Z 725 mm Max. rapid traverse speed in X/Y/Z 100/100/100 m/min Max. acceleration in X/Y/Z 11/14/11 m/s2 Tool holder HSK 63 Max. speed milling spindle 15000 1/min Max. power at ED 10-40/100% 31/– kW Max. torque at ED 10-40/100% 200/– Nm Spindle diameter in the front bearing 75 mm 1 pc. horizontally arranged milling spindle/s Torque support for multi-spindle drill heads Tool magazine 60 stations Max. tool diameter 160 mm Max. tool length 400 mm Max. tool weight 10 kg Chip to chip time 2.7 s Rotary pallet changer 2-fold Pallet size 500×630 mm Max. workpiece weight per pallet 600 kg Rotary  ...

- Totally overhauled machine, with a NEW Control + New Crystal Rules - Travel (X x Y x Z): 380 x 380 x 255 mm - Number of tool stations: 6 - Working area (X x Y x Z): 700 x 350 x 2 mm - Max. workpiece weight: 75 kg - Max. spindle speed: 5.000 - 3.

Used machine in good condition. Available for immediate delivery. - Number of tool stations: 30 - Control: CNC - Max. workpiece weight: 17.600 kg - Max. tool weight: 66 kg - Axes: 4 - Weight: 77.175 - Dimensions (long x wide x high): 1.501 x 1.300 x 1.000 mm

live center, live center, live morse taper, live center, live lathe center, live center, centering cone, centering ball, centering mandrel, centering chuck, pipe centering chuck -Manufacturer: Kondamat, centering chuck pipe centering chuck -Recording: MK4 -Dimensions: see photos -Dimensions: Ø 100 x 225 mm -Weight: 2 kg

Including: - Coolant Tray - Chip conveyor - Number of tool stations: 20 - Spindle power : 15 kW - Backgauge speed (X x Y x Z ): 24 x 24 x 20 mm/s - Travel (X x Y x Z): 762 x 435 x 510 mm - Working area (X x Y x Z): 920 x 436 mm - Max. workpiece weight: 600 kg - Max. spindle speed: 8.000 rpm - Operating hours: 6.700 - Axes: 3 - Weight: 500 - Dimensions (long x wide x high): 2.093 ? 1.962 ? 2.509 mm

fixed center, fixed punch center, fixed Morse taper, fixed center point, center points -Fixed center point: Morse taper MK4 -Number: 2x centering tips available -Price: per piece -Dimensions: Ø 32 x 160 mm -Weight: 0.8 kg/piece

live center, live center, live morse taper, live center, live lathe center, live center, centering cone -Revolving center: Mounting: MK4 -Type: unfortunately without type designation -Centering tip: Ø 100 mm -Dimensions: Ø 100 x 230 mm -Weight: 5.2 kg

Used machine in good condition. Available for immediate delivery. - Travel (X x Y x Z): 500 x 380 x 300 mm - Number of tool stations: 14 - Spindle taper: BT 30 - Spindle power : 2.2 kW - Control: CNC FANUC SERIE 16iM - Working area (X x Y x Z): 550 x 380 mm - Max. workpiece weight: 250 kg - Max. rapid traverse (X, Y, Z): 48 mm / min - Max. spindle speed: 1.000 rpm - Weight: 1.700 - Dimensions (long x wide x high): 1.565 x 1.907 x 2.216 mm

fixed center, fixed punch center, fixed Morse taper, fixed centering center, centering centers -Fixed center point: Morse taper MK6 -Number: 4x centering tips available -Price: per piece -Dimensions: approx. Ø 63/243 mm -Weight: 4.5 kg/piece

Used machine in good condition. Available for immediate delivery. - Travel (X x Y x Z): 500 x 400 x 330 mm - Number of tool stations: 14 - Spindle taper: BT 30 - Spindle power : 5.5 kW - Control: FANUC 16i-M - Working area (X x Y x Z): 600 x 400 mm - Max. workpiece weight: 250 kg - Max. spindle speed: 8.000 rpm - Dimensions (long x wide x high): 3.000 ? 2.000 ? 2.400 mm - Weight: 2.000

fixed center, fixed punch center, fixed Morse taper, fixed centering center, centering centers -Fixed centering tip: 3 pieces -Mounting: Met. cone 80 mm see photos -Shipping/Price: complete -Transport dimensions: 400/250/H80 mm -Total weight: 33.5 kg

Used machine in good condition. Available for immediate delivery. - Number of tool stations: 24 - Travel (X x Y x Z): 760 x 410 x 510 mm - Control: FANUC Oi-MC - Working area (X x Y x Z): 920 x 430 mm - Max. spindle speed: 8.000 rpm - Axes: 3 - Dimensions (long x wide x high): 3.350 x 2.700 x 2.800 mm - Weight: 5.000

Used machine in good condition. Available for immediate delivery. - Rapid Traverse (X x Y x Z): 30.000 mm/min - Rapid Traverse (X x Y x Z): 650 x 400 x 305 mm/min - Number of tool stations: 22 - Spindle taper: BT-30 - Spindle power : 7,4 kW - Max. spindle speed: 16.000 rpm - Max. tool diameter: 80 mm - Max. tool weight: 3 kg - Coolant tank capacity: 200 l - Dimensions (long x wide x high): 3.248 x 1.837 x 2.696 mm - Weight: 3.500

Used machine in good condition. Available for immediate delivery. - Number of tool stations: 24 - Control: FANUC - Working area (X x Y x Z): 1.300 x 600 x 600 mm - Max. workpiece weight: 1.000 kg - Max. spindle speed: 9.000 rpm - Axes: 3 - Dimensions (long x wide x high): 3.550 x 2.568 x 2.171 mm

Used machine in good condition. Available for immediate delivery. - Spindle taper: BBT40 - Max. tool length: 300 - Number of tool stations: 30 - Spindle power : 18.5/11 kW - Rapid Traverse (X x Y x Z): 36 x 36 x 36 mm/min - Travel (X x Y x Z): 900 x 460 x 520 mm - Control: FANUC - Max. workpiece weight: 600 kg - Max. spindle speed: 12.000 rpm - Max. tool diameter: 80 mm - Chip extractor: YES - Internal cooling: YES - High pressure pump: 20 Bar - Axes: 3 - Dimensions (long x wide x high): 2.805 x 2.180 x 3.026 mm - Weight: 5.500

live center, live center point, live Morse taper, live center point, live lathe center, center point, centering taper -Traversing centering tip: MK5 mount, 2 pieces -Type: 1x without type designation / 1x IAMU-BLAJ-CM5-STAS-7628-74 -Price/Fee: complete -Transport dimensions: 267/180/H90 mm -Total weight: 7.6 kg

live center, live center point, live Morse taper, live center point, live lathe center, center point, centering taper -Manufacturer: Lenze ABW, live centering tip -Type: ZN 204 -Recording: MK4 -Dimensions: Ø 69 x 210 mm -Weight: 2.1 kg

Number of axes: 5 Feed speeds in the X/Y/Z axis: 500/420/380 mm Feed rates in the C/B axes: 180°/360° Dimensions of the work table (L x W): 500 x 380 mm Maximum workpiece weight: 350 kg Spindle power: 15 kW Maximum spindle speed: 18000 rpm Tool magazine capacity: 30 pcs. Overall dimensions (L x W x H): 3360 x 2550 x 2600 mm Total weight of the DMU 50 eVolution machine: 6000 kg

fixed point, fixed center point, fixed Morse taper, fixed center point, center points -Fixed centering tip: 2 pieces -Type: IAMU-5A STAS-2294-74 -Recording: Morse cone MK5 -Price/Fee: complete -Transport dimensions: 200/90/H44 mm -Weight: 3.7 kg/pc.

x-travel: 350 mm y-travel: 240 mm Ucblcnl2H9 z-travel: 340 mm Speed: 20 - 4,500 1/min Table: D 400 x 280 Control: 810 D Shop mill SIEMENS Tool holder: SK 40 Rapid traverse: 5 m/min Spindle: 6.3 / 10 kW Total connected load: 15 kVA Approx. space requirement: 1.7 x 1.55 x 2.1 m Universal CNC Milling Machine, Rotary swivel table manual with angle display on the screen, El. Handwheel

Key data: 1120 mm, 510 mm, 510 mm

For sale. Mazak vertical machining center type VTC-20B with Kitagwa integrated rotary axis. X-, Y- and Z-axis travels are 1,120 x 510 x 510 mm. Table size: 1410 x 510mm. Table capacity: 800Kg. Maximum speed is 6,000 rpm. SK-40 spindle holder. The number of tool positions is 24 pieces ATC, max. tool Ø / max. tool Ø 80 mm ditto for free places / max. tool Ø with free places besides 110 mm max. tool length 350 mm max. tool weight 8 kg Feed range xy / feed range xy 1-8000 mm/min. Vorschubbereich z / feed range z 1-8000 Mm/min. Rapid traverse X/Y / rapid feed X/Y 30 m/min. Drive power / drive capacity 15 kW Weight of the machine approx. / weight 6500 kg

Inv. Num. : 7814 Type: CWK 800 Producer: Starrag Heckert Created: 2004 Parameters: Control system: Siemens Sinumeric Switch-on hours: 60035 h Hours: 31689 h Work table length: 800 mm Work table width: 800 mm Maximum workpiece weight: 1500 kg Spindle power: 28 kW Machine length: 6330 mm Machine width: 5760 mm Machine weight: 18100 kg In 2021 repairs: Replacement of linear guides and ball screws on the X, Y and Z axes Spindle replacement and ATC cabling Machine geometry ATC Function Test

Inv. Num. : 7815 Type: HEC 800 Producer: Starrag Heckert Created: 2008 Parameters: Switch-on hours: 46529 h Hours: 19542 h Work table length: 800 mm Work table width: 800 mm Maximum workpiece weight: 2000 kg Spindle drive power: 28 kW X-axis travel: 1450 mm Y-axis travel: 1100 mm Travel distances Z-axis: 1300 mm Cone: SK 50 Machine length: 8300 mm Machine width: 5500 mm Machine weight: 27000 kg

Key data: 65 mm, 510 mm

12-8 position driven turrets - Y axis +/- 40 mm - with Lns Quick Load short barfeed - well tooled - fanuc 18i-TA Control

Mazak VTC 200 B moving column machining center ::TECHNICAL SPECIFICATIONS::: CNC Model: Mazatrol - CNC Version: Fusion 640M - Tool Mount: ISO 40 - Spindle Power: 18.5Kw Number of spindle speeds: 12000 - Number of tools: 24 - X-axis travel: 1120mm - Y-axis travel: 510mm - Z-axis travel: 510mm Table dimensions: 1460 x 510mm Guides: roller CNC divider: yes Rotation: Continuous High refrigerant pressure: yes Chip conveyor: belt Presetting: yes :::D DIMENSIONS AND WEIGHT::: Length: 3312mm Width: 2850mm Height: 2651mm Weight: 6100Kg

Vertical machining center TC-32BN QT :::TECHNICAL SPECIFICATIONS::: CNC Model: Brother - CNC Version: B00 - Tool Holder: BT 30 - Spindle Power: 11Kw - Number of Spindle Revolutions: 12000 Number of tools: 26 - X-axis travel: 550mm - Y-axis travel: 400mm - Z-axis travel: 415mm - Rapid feeds for linear axes X Y Z: 70m/min Guides: roller CNC divider: yes Divider brand and model: No. 2 NIKKEN Rotation: Continuous Pallet change: yes Pallet size: 600 x 425mm Maximum allowable load: 200Kg Round pallet: yes High refrigerant pressure: yes Chip conveyor: belt Machine equipment: Renishaw probe ready :::D DIMENSIONS AND WEIGHT::: Length: 1890mm Width: 3669mm Height: 2360mm Weight: 4600Kg
