mechanical press used for sale

CONTROLS   PLC SCHNEIDER PRESS DESIGN   drive system: eccentric / crank   number of slide actions: 11   feedstock transport direction: left to right PRESS FORCES   total force (nominal): 66 to SLIDE   slide force: 6 to   stroke: 114 mm SLIDE (MECHAN. PRESS)   variable speed: yes   stroke rate (min.): 40 /min   stroke rate (max.): 130 /min   main drive power: 7.5 kW STRIP-FEEDER   feeder type: roll feeder TRANSFER SYSTEM   distance between tools, stroke X fixed: 82 mm DIMENSIONS / WEIGHTS   space requirements -left/right-: 2875 mm   space requirements -front/back-: 1500 mm   total height: 2900 mm   total weight approx.: 7500 kg ATTACHMENTS (PRESSES)   safety guard / safety door: yes   2-hand engagement: yes   noise protection cabin: yes   acc. to actual accident protection regulation: yes Specifications: Number of stations: 12 (11+1) Capacity  ...

The Dorst TPA 70 is a used powder compaction press, known for its precise and reliable performance. It delivers a maximum pressing force of 700 kN with a withdrawal force of 400 kN, making it suitable for diverse compaction needs. The machine features a pressing travel of up to 30 mm, with a maximum filling height of 70 mm and operates at speeds between 14 to 40 strokes per minute. This ensures efficient throughput, ideal for high-demand production environments. With an upper punch stroke of 120 mm and adjustable travel of 200 mm, the Dorst TPA 70S offers flexibility in application. It requires a compressed air supply with an intake of approximately 200 liters per minute, and operates on a total connected load of about 20 kW. To enhance functionality, the machine is constructed robustly, maintaining a workplace-related sound level of 78 dB(A), and features a press housing capacity of 190 ...

Crimping pliers, crimping pliers, cable lug pliers, mechanical crimping pliers, pressing jaws, pressing tool for cable end sleeves, wire end sleeves, cable lugs, hand crimping pliers, sleeve pliers, clamp sleeve pliers -Manufacturer: WMW, hand crimping pliers type PH 2.5C -Crimping: of cable lugs and cable connectors -Pressing force: 25.0 N -Pressing stroke: 15 mm -Transport case: incl. accessories, see photo -Quantity: 1x crimping pliers available -Price: per piece -Dimensions of pliers: 600/180/H25 mm -Total weight: 3.2 kg

The Dorst TPA 350 is a robust used powder compaction press, offering a maximum pressing force of 3500 kN. It is designed to handle demanding applications with efficiency, providing a maximum withdrawal force of 2500 kN and supporting force in pressing position up to 2000 kN. The die return force reaches a maximum of 80 kN. It features an upper punch stroke of 220 mm, with an adjusting travel of 200 mm, ensuring precision in operations. This press operates at a rate of 5-18 strokes per minute, catering to various production speeds. It accommodates a maximum filling height of 180 mm and allows a pressing travel and withdrawal travel both up to 90 mm. The top pressing travel is capped at 18 mm, with an upper punch pneumatic preload maximum of 60 mm, demonstrating versatility in its functioning. It operates with a compressed air supply consuming approximately 140 l/min, backed by a total con ...

CONTROLS   conventional PRESS FORCES   total force (nominal): 75 to PRESS TABLE   table surface (left-right): 1250 mm   table surface (front-back): 1110 mm SLIDE   table surface (left-right): 960 mm   table surface (front-back): 750 mm SLIDE (MECHAN. PRESS)   slide adjustment: 80 mm   stroke adjustment: yes   stroke min.: 10 mm   stroke max.: 50 mm   stroke rate (min.): 120 /min   stroke rate (max.): 600 /min STRIP-FEEDER   feeder type: roll feeder   sheet width max.: 300 mm ELECTRICAL SPECIFICATIONS   total power consumption: 15.5 kW DIMENSIONS / WEIGHTS   total weight approx.: 13500 kg ATTACHMENTS (PRESSES)   strip feeder: yes   feeder type: roll feeder

Table dimensions ( x-y/mm) 2150 x 1200 Slide Dimensions X-Y (mm) 2000 x 1200 Stroke (mm) 300 Slide Adjustment (mm) 200 Stroke per minute 5 - 50 Lateral window dimensions ( x-y/mm) 800

Press force: 1,200 t Ram stroke: 600 mm Ram adjustment: 500 mm Stroke rate: approx. 10 – 16 strokes/min Shut height: approx. 1,250 mm Drawing equipment: Drawing cushion force: approx. 240 t Drawing cushion stroke: approx. 250 mm Pneumatic ejector in ram: Force: approx. 95 t Stroke: approx. 150 mm Table size: approx. 3,500 x 1,900 mm Heavy-duty mechanical eccentric press in robust double-column design from Schuler, suitable for industrial applications as well as classical forming and deep drawing processes. The machine features a press force of 1,200 t with a fixed ram stroke of 600 mm and a ram adjustment of 500 mm. The stroke rate ranges from approx. 10 to 16 strokes per minute, allowing flexible use depending on the application. The working area is designed with a table size of approx. 3,500 x 1,900 mm, offering sufficient space for medium to large tooling. A key feature is the ...

The Dorst TPA 20/3 is a reliable used powder compaction press known for its robust construction and precise operations. It offers a maximum pressing force of 200 kN and a withdrawal force of up to 100 kN. With a maximum filling height of 140 mm and pressing travel extending to 70 mm, it accommodates a range of powder compaction tasks efficiently. The press is capable of operating at speeds ranging from 5 to 22 strokes per minute, supporting a variety of production needs. It features an upper punch stroke of 200 mm, with an adjustable travel of 160 mm for flexibility across different applications. The machines air supply intake is approximately 160 liters per minute, and it has a connected load of about 15 kW. Constructed with dimensions of around 2000 mm in width, 1700 mm in depth, and 3250 mm in height, the Dorst TPA 20/3 weighs approximately 4,900 kg. It maintains a workplace sound lev ...

Mechanical stamping press manufactured in 2016. This AIDA 315/2MR/LD/TE3 features a press capacity of 315 tons and a stroke length of 250 mm. It includes a maximum die size of 2,250 × 750 mm and a maximum die weight on slide of 10,200 kg. If you are looking to get high-quality stamping capabilities, consider the AIDA 315/2MR/LD/TE3 machine we have for sale. Contact us for further details.

Mechanical stamping press manufactured in 2018. This AIDA 315/2MR/LD/TE 3 features a press capacity of 315 tons and a stroke length of 250 mm. It has a maximum die size of 2,250 × 750 mm and can accommodate a maximum die weight of 10,200 kg. If you are looking to get high-quality stamping capabilities, consider the AIDA 315/2MR/LD/TE 3 machine we have for sale. Contact us for further details regarding this machine.

Mechanical stamping press manufactured in 2013. This AIDA 315/2MR/LD/TE 3 features a press capacity of 315 tons and a stroke length of 250 mm. It is designed for high-precision stamping operations with a robust double-upright frame and integrated drawing cushion. If you are looking to get high-quality stamping capabilities, consider the AIDA 315/2MR/LD/TE 3 machine we have for sale. Contact us for further details regarding this machine.

Mechanical stamping press manufactured in 2012. This Colombo Agostino T231A315 features a nominal press capacity of 315 tons and a slide stroke of 250 mm. It includes a motorized slide adjustment of 315 mm and a bed dimension of 1120 mm x 960 mm. If you are looking to get high-quality stamping capabilities, consider the Colombo Agostino T231A315 machine we have for sale. Contact us for further details.

The used DORST DK 100 is a robust sizing and powder compaction press designed for high-performance industrial applications. Capable of a maximum pressing force of 1000 Kn and a withdrawal force of 500 Kn, this machine provides powerful and reliable operation. It accommodates a filling height of up to 110 mm with a pressing travel of 50 mm, ensuring versatility for various compaction tasks. The upper punch stroke is 140 mm, with adjustable travel up to 75 mm, allowing for precise control over pressing operations. This model offers between 5 and 22 strokes per minute, giving you flexibility in production rates. The die return force is 100 Kn, while the supporting force in the pressing position reaches 300 Kn. Pneumatic operations are supported with an upper punch preload of up to 30 mm and compressed air consumption of approximately 80 liters per minute. It requires a total connected load  ...

The Dorst TPA 15/3 is a used mechanical powder compaction press designed for precision and efficiency in industrial applications. It provides a maximum pressing force of 150 kN and a withdrawal force of 100 kN, supporting a variety of compaction tasks. With an upper punch stroke of 100 mm and a range of 70 mm for adjusting the travel, this machine offers flexibility for different requirements. Operating at speeds of 7 to 32 strokes per minute, it ensures a reliable production throughput. This press allows for a maximum filling height of 70 mm and pressing travel up to 35 mm, suitable for a range of powder compaction needs. The machine is fitted with a compressed air system that has an intake of around 70 liters per minute and a total connected load of approximately 6 kW. It is compact yet robust, with dimensions of about 1400 mm in width, 1300 mm in depth, and 2650 mm in height, weighing ...

pressure: 1000 t distance between columns: . mm stroke: . mm total power requirement: . kW weight of the machine ca.: t dimensions of the machine ca.: m The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

SLIDE   total force (nominal): 40 to   stroke rate (max.): 110 /min TOOL DIMENSIONS   lower table (left-right): 300 mm   lower table (front-back): 280 mm   shut height max.: 180 mm DIMENSIONS / WEIGHTS   space requirements -left/right-: 1835 mm   space requirements -front/back-: 1500 mm   total height: 1800 mm   total weight approx.: 2500 kg

The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

SCHMIDT EP345 ist eine Elektropresse, ausgelegt für präzise Bearbeitung mit hoher Genauigkeit und Zuverlässigkeit. Hub maximal 150 mm, Geschwindigkeit 200 mm/s, Presskraft 10 kN; Eigengewicht 59 kg. Technische Eckdaten: Geschwindigkeit 200 mm/s, Hub 150 mm, Presskraft 10 kN, Gewicht 59 kg. Ermöglicht das Erreichen enger Toleranzen und eignet sich für Automobilindustrie, Uhrenindustrie, Werkzeugmaschinenbau, Luft- und Raumfahrt sowie Medizintechnik. Technische Daten ohne Gewähr

CONTROLS   PC controller BECKHOFF PRESS DESIGN   drive system: knuckle-joint SLIDE   total force (nominal): 160 to   stroke: 60 mm   stroke rate (max.): 70 /min COUNTER RAM   nominal force: 40 to   stroke: 14 mm V-RING   nominal force: 50 to   stroke: 10 mm TOOL DIMENSIONS   lower table (left-right): 480 mm   lower table (front-back): 520 mm   upper table (left-right): 480 mm   upper table (front-back): 520 mm   shut height max.: 314 mm   ram adjustment: 80 mm   distance between columns (H-frame): 500 mm   passline opening (free passage in side columns): 220 mm STRIP-FEEDER   feeder type: roll feeder   sheet width max.: 210 mm   sheet thickness max.: 6 mm   feeding step max.: 999.9 mm   sheet length min: 2000 mm   pilot release system: yes   band lubrication system: yes Complete refurbished fineblanking press: disassembly into individua ...

CONTROLS   PLC SIEMENS SIMATIC OP 47-12 PRESS FORCES   total force (nominal): 200 to PRESS TABLE   table surface (left-right): 2440 mm   table surface (front-back): 1500 mm SLIDE   table surface (left-right): 1500 mm   table surface (front-back): 1100 mm   stroke: 180 mm SLIDE (MECHAN. PRESS)   slide adjustment: 150 mm   stroke rate (min.): 20 /min   stroke rate (max.): 120 /min   main drive power: 45 kW OVERALL SPECIFICATIONS (COIL LINES)   sheet thickness max.: 2.5 mm DECOILER   sheet width max.: 300 mm   sheet width (min): 30 mm   coil weight max.: 3 to   max. diameter of coil: 1500 mm   mandrel expansion range from: 460 mm   mandrel expansion range up to: 530 mm LEVELLER UNIT   sheet width max.: 30 mm   sheet width (min): 300 mm   number of leveller rolls: 9   diameter of leveller rolls: 30 mm   number of intermediate rolls: 11   feed  ...

machine ready for transport and to be assessed on viewing day. machine has been repaired, see photos Auction-ID: A1-48648-7

PRESS DESIGN   drive system: hydraulic SLIDE   total force (nominal): 40 to   stroke: 45 mm   stroke rate (max.): 110 /min TOOL DIMENSIONS   lower table (left-right): 300 mm   lower table (front-back): 280 mm   shut height max.: 90 mm DIMENSIONS / WEIGHTS   space requirements -left/right-: 1835 mm   space requirements -front/back-: 1500 mm   total height: 1800 mm   total weight approx.: 2500 kg

SLIDE   total force (nominal): 80 to   stroke rate (max.): 120 /min V-RING   stroke: 90 mm TOOL DIMENSIONS   lower table (left-right): 420 mm   lower table (front-back): 420 mm   upper table (left-right): 420 mm   upper table (front-back): 420 mm DIMENSIONS / WEIGHTS   space requirements -left/right-: 2970 mm   space requirements -front/back-: 1665 mm   total height: 242 mm   total weight approx.: 6000 kg

Max plate thickness: 2.5mm. Max working width: 1020mm. In working order. Auction-ID: A3-46156-6141

Raskin mechanical press manufactured in Angleur (Belgium). Estimated capacity of 35 tons. Heavy cast iron machine equipped with flywheel, grooved table and mechanical clutch. Sold in the condition visible in photos. Ideal for punching, light cutting, stamping or workshop work. Auction-ID: A3-46126-35825

pressure:800 t distance between columns:2900 mm stroke:350 mm Controls:SIEMENS PRESS DESIGN:. - frame design : H-frame :. - Drive type : mechnical :. - openings in uprights : yes :. - number of cushions:0 - opening in table : yes :. - moving bolster : yes :. PRESS FORCES:. - total force (nominal):800 to PRESS TABLE:. - clamping surface (left-right):2800 mm - clamping surface (front-back):2800 mm - rectangular breakthrough (width):2000 mm - rectangular breakthrough (front-back):1800 mm - height above floor level:850 mm RAM:. - clamping surface (left-right):2800 mm - clamping surface (front-back):2800 mm - stroke:350 mm - number of strokes max:55 /min RAM (MECHAN. PRESS):. - ram adjustment:350 mm TOOL ASSEMBLY DIMENSIONS:. - shut height (stroke down, adjustment up):1100 mm - distance between columns (H-frame):2900 mm - Free passage between side columns (width):2560 mm ...

pressure:400 t distance between columns:1250 mm stroke:250 fix mm no. of strokes:45 /min distance table/ram, max. stroke up, adjustment up:825 mm table surface area:1000 x 900 mm column travel -side:400 x 700 mm ram surface:1000 x 900 mm ram adjustment:100 mm capacity of ejector in table:40 t ejector stroke:160 mm power capacity:270,0 kW weight:44,0 t Dimensions (WxDxH):2,4 x 3,6 x 7,2 m height over floor:6,4 m

pressure:125 t stroke:25 fix mm no. of strokes:70 - 700 /min distance between columns:1150 mm distance table/ram, max. stroke up, adjustment up:400 mm table surface area:1150 x 1000 mm hole in the table:900 x 220 mm side window:650 mm ram surface:990 x 850 mm ram adjustment:60 mm material width:250 mm material thickness:2,5 mm power requirement:46,5 kW weight:29,5 t roll feed:mechanical, Schuler, WK 8-250

pressure:063 t stroke:70 fix mm no. of strokes:15 - 60 /min distance between columns:1340 mm width between oil collecting pans:1180 mm distance table/ram, max. stroke up, adjustment up:328 mm table surface area:1260 x 700 mm hole in the table:1000 x 100 mm table height over floor:1000 mm column travel -side:470 mm ram surface:1300 x 650 mm ram adjustment:100 mm power requirement:27,5 kW weight:13,7 t Dimensions (WxDxH):3,4 x 2,1 x 3,4 m clutch:pneumatic overload protection in ram:hydraulic ram counterbalance:pneumatic ram adjustment:motoric

pressure:100 t distance between columns:1230 mm stroke:20 - 200 mm no. of strokes:20 - 60 /min distance table/ram, max. stroke up, adjustment up:650 mm table surface area:1050 x 750 mm table height over floor:760 mm side window:540 mm ram surface:1000 x 750 mm ram adjustment:100 mm power requirement:18,0 kW weight:20,5 t Dimensions (WxDxH):2,8 x 1,9 x 4,3 m infinitely variable drive:PIV clutch:pneumatic overload protection in ram:hydraulic ram counterbalance:pneumatic ram adjustment:motoric

pressure:500 t distance between columns:2400 mm stroke:400 fix mm no. of strokes:13 - 23 /min Distance table/ram, max. stroke up, adjustment up:1600 mm table surface area:2300 x 1800 mm column travel -side:1600 mm ram surface:2170 x 1800 mm ram adjustment:300 mm total power requirement:110,0 kW Weight:135,0 t Dimensions (WxDxH):3,35 x 4,85 x 7,0 m clutch:pneumatic overload protection in ram:hydraulic ram adjustment:motoric

pressure:030 t stroke:8 - 40 mm no. of strokes:100 - 600 /min distance between columns:325 mm distance table/ram, max. stroke up, adjustment up:250 mm table surface area:540 x 300 / 325 x 395 mm hole in the table:315 x 110 mm table height over floor:1000 mm column travel -side:290 mm ram surface:250 mm material width of feeder:120 mm material thickness of feeder:3,0 mm feed length:60 mm power requirement:5,5 kW weight:2,6 t Dimensions (WxDxH):1,5 x 1,2 x 2,2 m clutch:pneumatic roll feed:mechanical, Bruderer BBV 120/60

pressure:160 t distance between columns:2050/1900 mm stroke:15 - 170 mm no. of strokes:15 - 40 /min distance table/ram, max. stroke up, adjustment up:690 mm table surface area:1600 x 800 mm side window:800 mm ram surface:1620 x 700 mm ram adjustment:140 mm power requirement:15,0 kW weight:24,0 t Dimensions (WxDxH):3,3 x 2,3 x 5,3 m height over floor:4,8 m height beneath floor:0,5 m clutch:pneumatic ram adjustment:motoric ram counterbalance:pneumatic

pressure:500 t stroke:40 - 160 mm no. of strokes:32 / 48 /min distance between columns:1620 mm distance table/ram, max. stroke up, adjustment up:660 mm table surface area:1600 x 1300 mm table height over floor:750 mm column travel -side:400 x 430 mm ram surface:1400 x 1200 mm ram adjustment:120 mm pressure of drawing cushion in table:60 t stroke of drawing cushion in table:100 mm drawing cushion surface in table:1300 x 810 mm material width of feeder:1000 mm material thickness of feeder:- 6,0 mm feed length:350 mm height beneath floor:0,3 m power requirement:44,0 / 66,0 kW weight:56,0 t Dimensions (WxDxH):3,55 x 2,55 x 5,1/5,8 m height beneath floor without drawing cushion:0,3 m height beneath floor with drawing cushion:1,0 m clutch-/ brake combination:pneumatic; Desch overload protection in ram:mechanical ram counterbalance:pneumatic ram adjustment:motoric drawing cushion in table:pneum ...

pressure:500 t stroke:40 - 160 mm no. of strokes:32 / 48 /min distance between columns:1620 mm distance table/ram, max. stroke up, adjustment up:660 mm table surface area:1600 x 1300 mm table height over floor:750 mm column travel -side:400 x 430 mm ram surface:1400 x 1200 mm ram adjustment:120 mm material width of feeder:1000 mm material thickness of feeder:- 6,0 mm feed length:350 mm power requirement:44,0 / 66,0 kW weight:56,0 t Dimensions (WxDxH):3,55 x 2,55 x 5,1/5,8 m height beneath floor:0,3 m pneumatic clutch-brake combination:Desch Mechanical pincers feed:Obru, BVK 3.10.3

pressure:500 t stroke:40 - 160 mm no. of strokes:32 / 48 /min distance between columns:1620 mm distance table/ram, max. stroke up, adjustment up:660 mm table surface area:1600 x 1300 mm table height over floor:750 mm column travel -side:400 x 430 mm ram surface:1400 x 1200 mm ram adjustment:120 mm pressure of drawing cushion in table:60 t stroke of drawing cushion in table:100 mm drawing cushion surface in table:1300 x 810 mm material width of feeder:1000 mm material thickness of feeder:- 6,0 mm feed length:350 mm power requirement:44,0 / 66,0 kW weight:56,0 t Dimensions (WxDxH):3,55 x 2,55 x 5,1/5,8 m height beneath floor without drawing cushion:0,3 m height beneath floor with drawing cushion:1,0 m pneumatic clutch-brake combination:Desch drawing cushion in table:pneumatic Mechanical pincers feed:Obru, BVK 3.10.3

pressure:040 t stroke:8 - 50 mm no. of strokes:50 - 300 /min distance between columns:600 mm distance table/ram, max. stroke up, adjustment up:285 mm table surface area:590 x 500 mm hole in the table:590 x 40 - 100 mm table height over floor:860 mm column travel -side:280 mm ram surface:590 x 380 mm ram adjustment:80 mm material width of feeder:150 mm power requirement:7,5 kW clutch:pneumatic ram adjustment:motoric pincer feed:mechanical

pressure:160 t stroke:160 fix mm no. of strokes:30 - 120 /min distance between columns:1190 mm distance table/ram, max. stroke up, adjustment up:735 mm table surface area:1200 x 1000 mm hole in the table:500 x 300 mm table height over floor:900 mm side window:600 mm ram surface:1000 x 800 mm ram adjustment:125 mm material width of feeder:550 mm material thickness of feeder:0 - 6,0 mm feed length:350 mm material cross-cut:1100 mm² Feed speed:50 m/min power requirement:45,0 kW weight:25,0 t dimensions (WxDxH):2,3 x 2,1 x 4,7 m infinitely variable drive:PIV overload protection in ram:hydraulic ram adjustment:motoric ram counterbalance:pneumatic pincer feed:mechanisch, RS 350/550 SL 90

Pressure:630 t distance between columns:1600 mm stroke:fix 250 mm no. of strokes:20 /min distance table/ram, max. stroke up, adjustment up:900 mm table surface area:1550 x 1200 mm table height over floor:800 mm side window:620 mm ram surface:1360 x 1200 mm ram adjustment:160 mm height over floor:5,9 m height beneath floor:0,6 m power requirement:32,0 kW weight:59,0 t dimensions (WxDxH):3,0 x 2,2 x 6,5 m clutch:pneumatisch overload protection in ram:hydraulisch ram adjustment:motorisch ram counterbalance:pneumatisch

pressure:500 t distance between columns:3400 mm stroke:850 mm no. of strokes:9 - 18 /min distance table/ram, max. stroke up, adjustment up:2050 mm table surface area:3100 x 1900 mm table height over floor:400 mm side window:1550 mm ram surface:3100 x 1900 mm ram adjustment:350 mm pressure of drawing cushion in ram:70 t pressure of drawing cushion in table:140 t stroke of drawing cushion in table:0 - 250 mm stroke of drawing cushion in ram:150 mm height beneath floor:6,0 m height over floor:8,3 m weight:155,0 t dimensions (WxDxH):5,1 x 4,5 x 12,3 m Kind of drive:link drive tool changing unit:2 x

pressure:500 t distance between columns:3400 mm stroke:850 mm no. of strokes:9 - 18 /min distance table/ram, max. stroke up, adjustment up:2050 mm table surface area:3100 x 1900 mm table height over floor:400 mm side window:1550 mm ram surface:3100 x 1900 mm ram adjustment:350 mm pressure of drawing cushion in ram:70 t pressure of drawing cushion in table:140 t stroke of drawing cushion in table:0 - 250 mm stroke of drawing cushion in ram:150 mm height beneath floor:6,0 m height over floor:8,3 m weight:155,0 t dimensions (WxDxH):5,1 x 4,5 x 12,3 m Kind of drive:link drive tool changing unit:2 x

pressure:500 t distance between columns:3400 mm stroke:850 mm no. of strokes:9 - 18 /min distance table/ram, max. stroke up, adjustment up:2050 mm table surface area:3100 x 1900 mm table height over floor:400 mm side window:1550 mm ram surface:3100 x 1900 mm ram adjustment:350 mm pressure of drawing cushion in ram:70 t pressure of drawing cushion in table:140 t stroke of drawing cushion in table:0 - 250 mm stroke of drawing cushion in ram:150 mm height beneath floor:6,0 m height over floor:8,3 m weight:155,0 t dimensions (WxDxH):5,1 x 4,5 x 12,3 m Kind of drive:link drive tool changing unit:2 x

pressure:500 t distance between columns:3400 mm stroke:850 mm no. of strokes:9 - 18 /min distance table/ram, max. stroke up, adjustment up:2050 mm table surface area:3100 x 1900 mm table height over floor:400 mm side window:1550 mm ram surface:3100 x 1900 mm ram adjustment:350 mm pressure of drawing cushion in ram:70 t pressure of drawing cushion in table:140 t stroke of drawing cushion in table:0 - 250 mm stroke of drawing cushion in ram:150 mm height beneath floor:6,0 m height over floor:8,3 m weight:155,0 t dimensions (WxDxH):5,1 x 4,5 x 12,3 m Kind of drive:link drive overload protection in ram:hydraulic ram adjustment:motoric tool changing unit:2 x

pressure:200 t stroke:30 - 160 mm no. of strokes:40 - 120 /min distance between columns:1500 mm distance between oil collecting pans:1300 mm distance table/ram, max. stroke up, adjustment up:860 mm hole in the table:550 x 300 mm table surface area:1250 x 1250 mm table height over floor:1000 mm column travel -side:600 x 530 mm ram surface:1250 x 1000 mm ram adjustment:125 mm Material width of feeder:30 - 500 mm Material thickness feeder:0,5 - 3,0 mm feeding length:0 - 999,9 mm power requirement:50,0 kW weight:34,0 t dimensions (WxDxH):4,0 x 1,7 x 5,2 m clutch-/ brake combination:pneumatisch, Ortlinghaus overload protection in ram:hydraulisch ram adjustment:automatisch stroke adjustment:automatisch ram counterbalance:pneumatisch roll feed:Weingarten, WE 60 Option: NEW electrical controls:Siemens S7-1500 F

Pressure:150 t stroke:fix 80 mm no. of strokes:30 - 150 /min distance between columns:930 mm distance table/ram, max. stroke up, adjustment up:400 mm table surface area:880x1300/1500x600 mm hole in the table:760 x 180 mm table height over floor:1270 mm column travel -side:650 mm ram surface:920x1000/1300x600 mm weight:27,5 t Dimensions (WxDxH):3,1 x 1,8 x 4,3 m WITHOUT feeder:can be offered optionally

Pressure:250 t stroke:30 mm no. of strokes:60 - 500 /min Distance between columns:1500 mm distance table/ram, max. stroke up, adjustment up:390 mm table surface area:1580 x 1100 mm hole in the table:1270 x 300 mm table height over floor:1470 mm side window:600 mm ram surface:1500 x 900 mm ram adjustment:100 mm material width:500 mm material thickness:0,5 - 1,5 mm coil weight:6,5 t coil internal diameter:420 - 560 mm coil external diameter:1500 mm power capacity:45,0 kW Weight:44,0 t Dimensions (WxDxH):3,3 x 1,8 x 4,5 m clutch:pneumatisch ram adjustment:motorisch double decoiler:LH 2-1,5-500 straightening machine:R 500 roll feed:mechanisch; Schuler, WK 8-500

pressure:500 t stroke:fix 300 mm no. of strokes:20 - 70 Hub/min distance between columns:3100 mm side window:1400 mm distance table/ram, max. stroke up, adjustment up:1000 mm Table area:2800 x 1600 mm ram surface:2800 x 1450 mm ram adjustment:100 mm power requirement:90,0 kW weight:100,0 t Dimensions (WxDxH):5,75 x 3,2 x 7,8 m height above floor:6,4 m height beneath floor:1,4 m clutch:pneumatic; Ortlinghaus ram adjustment:motoric overload protection in ram:hydraulic ram counterbalance:pneumatic

pressure:600 t distance between columns:3640 mm stroke:350 mm no. of strokes:11 - 44 /min Distance table/ram, max. stroke up, adjustment up:1550 mm table surface area:3600 x 2500 mm sliding table:3600 x 2500 mm ram surface:3600 x 2500 mm Side window:2200 mm ram adjustment:400 mm material width coil line:500 - 1950 mm Material thickness at 1200 mm material width:0,6 - 2,5 mm Material thickness at 1850 mm material width:0,6 - 2,0 mm Material thickness at 1950 mm material width:0,6 - 1,75 mm Coil weight:35,0 t coil internal diameter:610 mm coil external diameter:900 - 1900 mm no. of straightening rolls:13 straightening roll diameter:50 mm Stack height:400 mm stacking dimensions - station 1+2 (L x W):150-2000 x 250-2000 mm stations:2 power requirement:112,0 + 35,0 kW Weight:390,0 t Dimensions (WxDxH):7,3 x 5,1 x 15,0 m Height above floor:9,1 m Height below floor:5,9 m clutch-/ brake combinat ...

CONTROLS   electronic controls BECKHOFF PRESS DESIGN   drive system: servomechanic   number of slide actions: 1 PRESS FORCES   total force (nominal): 100 to PRESS TABLE   table surface (left-right): 950 mm   table surface (front-back): 660 mm SLIDE   slide force: 100 to   table surface (left-right): 550 mm   table surface (front-back): 460 mm   spigot hole diameter: 50 mm   stroke rate (max.): 130 /min SLIDE (MECHAN. PRESS)   slide adjustment: 80 mm   stroke min.: 20 mm   stroke max.: 160 mm   stroke rate (min.): 70 /min   stroke rate (max.): 130 /min   main drive power: 25 kW TOOL ASSEMBLY DIMENSIONS   shut height (stroke down, adjustment up), BDC: 370 mm DECOILER   design: single reel   sheet width max.: 400 mm   coil weight max.: 1.25 to   max. diameter of coil: 1250 mm   mandrel expansion range from: 375 mm   mandrel expansion range u ...

Year of construction 2009 like new condition, has worked only sporadically 1 year, Looks machine like new inside The machine is CNC controlled, for the mechanical structuring of thin-film solar cells. The processing heads move over that with a layer of molybdenum metal or other sputtered Glass, with a format 125 x 65 cm, and create an insulating track by material removal. The CNC control controls the movement of the X-, Y-, Z-, A-, and U-axis. all documents, Control Panel, and control are available Original price: 847.000,00 € The complete unit to build a 75MW of production are available. (1 x laser, 2 x mechanical structuring and setting device for needles) Geamt-new value 2.1 mill euro net
