used
Mobile Articulated Measuring Arm Measuring Machine Gauge Manufacturer: Zett Mess Type: AMPG 2400 Precision Year of Make: 2010 Measuring Ø: 2,400 mm
used
amplification -fold: 10x B / 22 x-axis: - mmy-axis: - mmThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
used
IntNr231045 Gebr. Profile projector Mitutoyo PV 500 with screen 500 mm and digital display Specifications: Profile Projector Make MITUTOYO Type PV-500 Screen diameter 508 mm Screen can be rotated 360° (Vernier 1 ́) Magnification possible 5 x , 10 x , 20 x ,50x , 100 x Installation is carried out by insert system with adapter Magnification accuracy for transmitted light / incident light +- 0.1% / +- 0.15% Mains 220 V, 50 Hz Power consumption 340 VA Basic unit dimensions 900 x 700 x 1700 mm Weight 180 kg with – 2-axis digital display Mitutoyo Accessories The machine can be viewed by appointment electricity. Changes and errors in the technical data and specifications as well as prior sale reserved! Used Profile projector Mitutoyo PV 500 with 500 mm screen and digital display Technical data: Profile projector make MITUTOYO type PV-500 Screen diameter 508 mm ...
new
Suitable for measuring and presetting all types of cutting tools as well as for measuring grinding wheel packages. The Zoller image processing saturn set incl. Camera system allows a fast and operator-independent measurement of any tool cutting edge. Accessories: Pilot 2.0 software, High-precision SK 50 spindle/vacuum (concentricity 0.002 mm, vacuum clamping device,, spindle brake), Pilot 2.0 electronics, Pilot 2 operating dialog German, Base cabinet., Z-axis travel: 420 mm, Traverse X-axis: 200 mm, Workpiece diameter: Max. 420 mm, Workpiece length: Max. 400 mm, Max. Snap gauge diameter: d = 100mm, Workpiece holder: SK 50, Tool weight: Max. 10 kg, Repeatability: +/- 0.002 mm,, Display accuracy: 0.001 mm, Concentricity: 0,005 mm, Connected load: 230 V / 50 Hz, Compressed air connection: approx. 6 bar, Dimensions W x D x H: 1300 x 625 x 1600 mm, Weight: approx. 200 kg, colour: silver gra ...
used
Gebr. KEYENCE_Modellreihe XM_(T2000- still to be examined) Bj.2018 Gauge Measuring range: 300 mm × 250 mm × 150 mm Smallest display unit: Distance 1 μm / Angle 0.0001 degrees Measurement accuracy: Repeatability: ±3 μm Measurement deviation: ±8 μm Stage Maximum weight load: 25 kg Probes: 2 Built-in display: 15-inch LCD monitor (1024 × 768) Interfaces: USB 2.0 Series A: 3 ports Environmental resistance: +10 to +35°C With reference to ISO 10360-2 (within a range of 200 × 200 × 150 mm at an ambient temperature in operation of 23 ±1°C) Control Unit XM-1600 Probe: XM-P2000 Functions: Setting Mode, Image-Guided Measurement, Statistics & Analysis, Single Measurement 500 (without comment elements) Basic measurement: distance, angle, calculation, CAD distance Plane, Straight, Point, Circle, Cylinder, Cone, Sphere Point – No Correction, Ellipse, Point Circle ...
used
Suitable for measuring all types of milling and drilling tools, profiles, punching tools, drive and cardan shafts, profile rollers, etc. Accessories: Measuring table adjustment with digital display, Screen diameter: 500 mm, Enlargement: 50 and 100 times, Swivel range of the upper table: +/- 2 mm, Connected load approx.: 230 V / 50 Hz, Dimensions W x D x H approx.: 1200 x 700 x 1800 mm, Weight approx.: 400 kg, colour: Light grey
used
We offer 2 Heidenhain touch probes for sale. -Manufacturer: Heidenhain -Type: TS120 to € 560.- Mounting SK40 - TS520 at € 850.- Mounting SK40 Please specify the desired button when purchasing. Shipping available on request. Costs are borne by buyers! To make an appointment for the purchase or testing of our machines, please contact us at the following number: 0043 3467 - 21270 or by email at officevie-systems.com. All machines have been tested and maintained. We sell our machines without warranty and do not take any responsibility after purchase.
used
: SPANNFIX : 5 height: 350 mmthroat: 250 mmweight: 8 kg: : Please note:The machine is dismantled and ready for loading. It is not possible to show it under power or make a video.Our offer includes already the best pictures. So we don’t have and won’t send additional pictures.The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
used
3D Probe See pictures
used
quality grade: 1 The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
used
Linear rail with folding cam Height-adjustable for mounting on hole punches
used
height & diameter measuring device
used
Cone gauges Morse Taper 2 Cone gauges Morse Taper 3 Cone gauges Morse taper 4 Cone gauges steep cone 30 Taper gauges steep cone 40 Test Mandrels Morse Taper 2 Test Mandrels Morse Taper 3 Test Mandrels Morse Taper 4 Test mandrels steep cone 30 Test Mandrels Steep Cone 40 Cone cleaner Morse taper 2 Cone cleaner Morse taper 3 Cone cleaner Morse taper 4 Cone cleaner steep cone 30 Cone cleaner steep cone 40
new
Suitable for measuring and presetting all types of cutting tools as well as for measuring grinding wheel packages. The extensive and comprehensive software solution with intuitive graphical user guidance guides users quickly and safely to precise measurement results., Accessories:, Upgrade to ZOLLER measuring device control »pilot 4.0« with 17” monitor,, Autofocus/venturion 800,, Rotary encoder (ROD=) for high-precision position determination,, Tool inspection (incident image processing with centered LED lighting),, High-precision spindle ACE” concentricity 0.002 mm,, Tool management standard,, FORED manual measuring programs,, 3 used attachment holders., Z-axis travel: 800 mm, Traverse X-axis: 200 mm, X axis travel: 200 mm, Workpiece diameter: Max. 1000 mm, workpiece length: Max. 800 mm, Workpiece length: Max. 400 mm, Max. snap gauge diameter: d = 200mm, Max. Snap gauge diameter: ...
used
Zeiss Prismo VAST Gold with rotary table Year of manufacture 1999 Retrofit Measuring range: X= 900 mm, Y= 1200 mm, Z= 700 mm Control C98 with control panel BP26_SE Roundtable VAST Gold probe Stylus Changing Magazine 13-Fold Stylus changer plate Pushbutton Accessories Calibration ball Technical documentation Other accessories Workstation with monitor Software Calypso Basic other options of your choice
used
Suitable for fully automatic and touch-less measuring of cutting tools of all kinds. By means of 2 CCD matrix cameras, reflected-light and transmitted light measurements are performed. For example diameter, length, angles, spiral angle, spiral length, clearance angle, cutting angle etc. can be measured. Accessories:, Pneumatic workpiece clamping,, Windows 7 PC + QCM 8.0, software VIALOGIC TIM Teach-In-Mode,, software package 1 (cylindrical tools sharp edge, corner and full radius),, software package 2 ( conical-spiral tools sharp edge, corner and full radius),, Software VIALOGIC Viascan,, QCM Network,, LightControlDevice,, Glass scales on the linear axes., Traverse X-axis: 200 mm, Y-axis travel: 350 mm, Z-axis travel: 250 mm, A-axis speed: 60 rpm, Workpiece holder: ISO 50, Workpiece diameter: 3 - 200 mm, Workpiece length: Max. 300 mm, Workpiece weight: max. 40 kg, Connected load: approx. ...
used
Zeiss Prismo 7 MPS VAST Gold with rotary table Year of manufacture 1999 Retrofit Last calibration 6/2021 Measuring range: X= 900 mm, Y= 1200 mm, Z= 700 mm Control C98 with control panel Roundtable VAST Gold probe Stylus changing magazine 7-fold Stylus changer plate Pushbutton Accessories Calibration ball Technical documentation Other accessories Workstation with monitor Software Calypso Basic other options of your choice
used
x-travel: 1500 mmy-travel: 1000 mmz-travel: 900 mmweight: 1,2 kgdimensions: 260 x 168 x 80 mmFunction: ready for operation: electric 230 volt: Machine manual: Used 3-axis digital display from Mitutoyo with three scales. The digital oneMeasuring device was dismantled because the machine - a table boring machine - was disposed of.Display area. 0.005, 0.001mm. Hole circle display, distance processing,Conversion to lathe operation possible, programmable parameters.The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
used
Zeiss Prismo VAST XT Year of manufacture 2003 Retrofit Measuring range: X= 900 mm, Y= 1200 mm, Z= 700 mm Control C99 with control panel VAST XT probe Stylus Changing Magazine 13-Fold Stylus changer plate Pushbutton Accessories Calibration ball Technical documentation Other accessories HP Workstation with Monitor Software Calypso Basic other options of your choice
used
Measuring range: 1000 mmmeasuring system resolution capability: 0,01 /0,0005 mmrepeatability: 10 umadjustment speed: 1,5 m/secweight - pallet system: ca. 1,8 kgDigital workshop caliper in lightweight construction with wooden box. Large digital display. With measuring tips and prism guide. Easy, precise running thanks to prism guidance. Aluminum rail and slider. 50% weight advantage.The caliper was hardly used and is in new condition.The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
used
Zeiss UMC 850 Measuring range: X= 800 mm, Y= 1800 mm, Z= 600 mm Control panel BP26 Accuracy E0, MPE = 2.5+L/250 Stylus changing magazine 5-fold Calibration ball Other stylus accessories Technically and visually in very good condition
used
x-travel: 500 mmy-travel: 400 mmz-travel: 400 mmMITUTOYO Euro-M 544 Coordinate measuring machine Measuring machineSize of the base plate: 850x850mmInformation on the scope of deliveryThe package contains only the ordered product. Additional decorative items or other items shown in the product images are not part of the delivery.The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
used
Zeiss MC 850 VAST XT Gold Measuring range: X= 850 mm, Y= 1800 mm, Z= 600 mm Complete Retrofit 2018 Control C99 with control panel BP26_SE VAST XT Gold probe Stylus Changing Magazine MSR 13-Fold Software Calypso 2018 Basic CNC Option QS-Stat interface Calibration ball Other stylus accessories Technically and visually in excellent condition
used
diameter: / mmworkpiece length: / mmlength: / mmMITUTOYO SURFTEST SV-500 Roughness tester with OLZE measuring plateSize: 600 x 600 x 80mmTarget µm: 16Actual µm: 10,00Own weight: 85kgInformation on the scope of deliveryThe package contains only the ordered product. Additional decorative items or other items shown in the product images are not included in the delivery.The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
used
Zeiss CNC Coordinate Measuring Machine Prismo MP5 Year of manufacture: 8/1999 Last calibration 9/2023 Measuring range: X= 900 mm, Y= 1200 mm, Z= 700 mm Device features, equipment: Control C98 with control panel Sensors RDS with RST Pushbutton Changer Magazine 5-fold RST 5x probing system Dpp7Jl Pushbutton Accessories Measuring ball Calculator with monitor Software Calypso Basic 5.4 Loading system Other accessories Complete retrofit C99 and Calypso possible
new
min. dia.: 0,1 mmmax. diameter: 150 mmdimensions: 300 x 150 x 200 mmweight: 4,0 kgThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
used
Machine Type: SK50 Mandrel Manufacturer: KYUSHUKOGU Type: SK50 Condition: used / very good Offer will only be sent if a complete imprint is provided! Price 178,50 Euro incl. VAT and shipping within Germany. Location Warstein , Germany Reference MZ-WER-1223-1 DESCRIPTION We offer you a used alignment mandrel, see pictures. Technical data will follow. Availability: immediately Our offer is aimed at tradespeople who are registered within the meaning of the Trade Regulation Act according to §14 GewO. The offer is subject to change, subject to prior sale. Please provide your full contact details to receive a quote with our terms and conditions and payment terms. Errors in the descriptions and offers are excepted!
used
Tool pressetter Needs new computer and software Estimated price 2022 from producer € 4500,--
used
Machine type: Test mandrel Manafacture: System 3R Type: 3R-606 Year of construction: unbek. Condition: Used Offer will only be sent if a complete imprint is provided! Price 800 Euro incl. 19 % VAT and shipping within Germany Location Warstein , Germany Reference M-HIR-0623-1 DESCRIPTION We offer you to buy a used mandrel from the manufacturer System 3R, as shown in the pictures. Availability: Immediately Our offer is aimed at traders who are registered within the meaning of the trade regulations according to §14 GewO. The offer is subject to change, subject to prior sale. Please provide your full contact details to receive a quote with our terms and conditions of payment. Errors in the descriptions and offers are excepted!
used
Heidenhain ROD 800.0000 - 36000 Id.Nr. 298 466 06 Incremental angle encoders with self-bearing Series: ROD 800 System accuracy ± 1" Mechanically zul. Speed 1000 min–1 Interface: » 1 VSS Scope of supply: 1 piece Item condition: NEW More items - new and used - can be found in our shop! International shipping costs on request!
used
roughness meter, Contour measuring device Manufacturer: Hommel Type: T 8000 Year of construction: 2005 Specification: DIN EN ISO 4287 Ra, Rz, RmaxRSm
used
For sale are two touch probes from Renishaw. -Manufacturer: Renishaw -Type: MP11 & MP3 -Recording: SK50
used
For sale are several touch probes from Heidenhain. -Manufacturer: Heidenhain -Type: TS110 / TS111 = each 850 € TS220 / TS230 = 950 € each ! Since several touch probes are for sale, please use the specify the desired type! -Recording: SK50
used
2 point indoor measuring device diameter range of
used
Tool adjuster, adjustment and measuring instrument used Manufacturer E. Zoller V420magnum Type: V425D Built: 1997 Dimensions: approx. 1600 x 1000 x 2000 mm
used
full drawer cabinet cca 350 pcs various pinball, thread edging, etc.
used
Various threaded rings, border raven gauges, measuring rings Etc in the item
used
Coordinate Measuring Machine 6-Axis Zett Measuring AMPG 3600 Precision Zett Mess Coordinate measurement technology Type AMPG 3600 Precision 6-axis measuring joint arm Magent foot and tripartite Laptop with software
used
Tool presetting device Brand: Zoller Type: Venturion 400 Without computer,software. Mechanics only This item is only sold to traders.
