Vertical lathe KOLOMNA 1540 T CONVENTIONAL MACHINE READY TO INSTALL Spindle diameter 4.000 mm Working diameter 4.140 mm Max working height 2.060 mm Ram travel 1.250 mm Weight over spindle 100 ton Motor power spindle 100 kW Boring/milling unit included Nr.02 RAM with visualization by DRO Excellent conditions, mechanical really like a new.
Bridgeport EZ Path S Used machine (very good) Control type Cnc Built 2001 Hours K.a. Price 12,500 € net plus VAT Dimensions 3100x1850x1500 Weight 2500 kg Location Haiger Description Universal CNC cycle deer of the brand Bridgeport suitable for tooling, fixture construction, training as well as mold making • Circulation diameter: 430mm • Control: Fanuc 20T Technical data • Circulation diameter 430mm • Peak width 1000mm • Control Siemens Fanuc 20 T • Reitstock MK 4 • Multifix tool station • Speed 1-4000rpm • Connection 380V - 7.5 KW
Description Seiger lathe SLZ 800E x 4000 Details Machine no. 4443 Year of construction 2008 Siemens Cycle Control Spindle holder according to DIN 55027 size 11 Spindle bore Ø 130 mm Spindle diameter in the front bearing 170 mm Spindle taper 1:20 Drive power 20/28 kW Main spindle speed switching stage "I" 9-1,800 min-1 Main spindle speed switching stage "II" 9-400 min-1 Maximum torque: 3,200 Nm Center width 4,000 mm Circulation Ø above the bed 810 mm Circulation Ø above the face slide 540 mm Bed width 480 mm Machine dimensions 2,000+center width x 2,750 x 2,000 mm Permissible workpiece masses between points without setting stick 2,000 kg Permissible workpiece masses between points with a setting stick 2,200 kg Permissible workpiece masses between tips with two setting sticks 2,500 kg Permissible workpiece masses flying i ...
Description Heyligenstaedt Lathe NDb-630 Details Year of manufacture 1980 Tip height above bed 630 mm Turning length 3,000 mm Turning diameter over bed 1,240 mm Turning diameter over bed slide 960 mm Max. workpiece weight without support 10,000 kg Bed width over guideways 850 mm Number of guideways 2 Bed height 650 mm Slide path 3,000 mm Face plate diameter 1,100 mm Main spindle diameter in the front bearing 280 mm Max. torque at the face plate 25,000 Nm max. workpiece weight clamped on the fly at center of gravity distance 250 mm in front of face plate 4,000 kg Main spindle speed range 2.24 - 450 rpm. Number of main spindle speeds 4 mech. Levels Power main motor 50 kW Main motor speed 100-1,000-2,500 rpm. Number of supports: 1 Cutting force support 4,000 kg Guide length front bed track 1,300 mm Quill diameter 250 mm ...
Demoor 825-320 oil country lathe. Distance between centers: 3000mm. Swing: 970mm. Swing in carriage: 700mm. Bore: 320mm. New electrical box. Carriage with cone copier. Equipped with chuck.
Merli Clovis 70 heavy lathe. Distance between centers: 8000mm. Swing: 1650mm. Swing in carriage: 1170mm. Bore: 206mm. Bed width: 1000mm. Speeds: 16.(3-300). Maximun weight without steady rest: 15.000Kgs. Maximun weight with 1 steady rest: 20.000Kgs. Equipped with chuck of 1400mm. Equipped with DRO. Equipped with 2 steady rest. Equipped with CE protections and CE certificate for second hand machines.
Leit & Pull Spindle Lathe "DREHMA - D410x1500mm -Demonstration machine - year 2025 -CE - Identifier -Digital display -Turning diameter over bed 410mm -Turning length 1500mm -Turning diameter over support 255mm -Turning diameter in the offset 580mm -Spindle Passage 52mm -Speed range 45-1800 rpm -Automatic longitudinal/plane feeds -Thread/Inch/Metric etc. -Tailstock Mk4 -Central lubrication -Drive power 3.5 KW -Fixed / Rotating bezel -Multifix holder with 4x inserts -Three-jaw chuck 200mm Hsbknowatv Ss Au S Tel -Four-jaw chuck 250mm -Face Plate -Lining protection -Front safety device -Coolant device -Work light -Running tip -Machine feet
Control Fanuc 32i-TB Main spindle: Motor spindle technology Speed (max.) 6,500 rpm Power (max.) 7.5 kW Bar passage 38 mm Travel in Z (longitudinal turning operation) 320 mm Workpiece Clamping Collet Chuck (Type F48) Guide Bush Synchronous Running Sub-spindle: Motor spindle technology Speed (max.) 6,500 rpm Power (max.) 5.5 kW Workpiece Clamping Collet Chuck (Type F48) Pneumatic ejector Linear slides: Number of lathe chisel stations 5 Tool holder 16 x 16 mm/ 20 x 20 mm Number of stations cross drilling rig 5 Tool holder ER16/ER20 Tool drive 6,000 rpm, 2.2 kW Cross slide: Number of stations 2 Tool holder ER16 Milling operations tool drive Residual apparatus: Number of stations 8 Tool holder Ø32 mm Number of driven stations 4 Tool holder ER16 Tool drive 6,000 rpm, 1 kW Equipment/accessories: Chip Management Chip Conveyor Coolant system IKZ syste ...
Key data: 1600 mm, 3500 mm, 800 mm
For sale is: 1 Piece Used Face and Lace Lathe Manufacturer: Werkzeugmaschinenfabrik Zerbst GmbH Type: DP1 / S3 x 3500 Year of manufacture: 1994 Technical data: Largest turning diameter over bed: 1,600mm Center width: 3,500mm Spindle bore: 100mm Face plate diameter: 1,250mm Total mass of the machine: approx. 24.8t incl. documentation Further pictures and videos can be sent on request. The following things have been renewed/repaired on the machine in the last four years: At the end of 2022, the tailstock was completely overhauled. New bearing and new tip and lubrication. 2024 Cross Support regenerated. Refurbishment of the wedge strips with new sliding coating, snatchers on the guideways smoothed by scraping, Bearing seats of the spindles made smooth, wedge strips in the contact surface and covering surface scraped. Lubrication pump cle ...
Cazeneuve HB575 rebuilt lathe. Swing over bed: 575mm. Swing over carriage: 300mm. Distance between centers: 4000mm. Spindle nose: 51mm. Motor power: 12,5cv. Equipped with universal chuck of 250mm and steady rest. CE protections in chuck and carriage and CE european certificate for second hand machines. Optional: DRO Fagor or Heidenhain. Optional: CE back guard.
Cazeneuve HB500 rebuilt lathe. Distance between centers: 2000mm. Swing over bed: 500mm. Swing over carriage: 220mm. Motor power: 10cv. Spindle nose: 40,5mm. CE protections in chuck and carriage and CE european certificate for second hand machines. Equipped with universal chuck of 250mm and steady rest. Optional: DRO Fagor or Heidenhain. Optional: CE back guard.
Cazeneuve HB575 rebuilt lathe. Swing over bed: 575mm. Swing over carriage: 300mm. Distance between centers: 750mm. Motor power: 12,5cv. Spindle nose: 51mm. Equipped with universal chuck of 250mm. CE protections in chuck and carriage and CE european certificate for second hand machines. Optional: DRO Fagor or Heidenhain. Optional: Steady rest. Optional: CE back guard
Control Other GDW Spindle Passage [mm] 43 Rotary diameter. [mm] 300 Turning length [mm] 650 Main spindle: Belt spindle technology Speed 4,500 rpm Power (max.) 7.5 kW Torque (max.) 80 Nm Spindle Passage 43 mm Workpiece clamping 3-jaw chuck, Röhm ZS ø160 mm Tool carrier (X/Z): Technology slide with 4-cavity turret Tool holder ready size 1 Travel in X/Z 170/650 mm Rapid traverse in X/Z 6 m/min Tailstock: Technology Manual tailstock with handwheel Quill stroke 110 mm Quill ø 50 mm Quill Cone MK3 Equipment/accessories: Chip disposal chip tray Coolant Management KSS Pump Tool holder Div. gebr. Parat Holder Further accessories 4-jaw chuck ø160 mm, various used Baking
Lacfer CR2-E250 rebuilt lathe. Distance between centers: 1.500mm. Swing: 530mm. Swing over carriage: 320mm. Swing in gap: 740mm. 16 speeds. (18-1.600rpm). Main motor power: 10hp. Spindle bore: 60mm. Equipped with universal chuck. Equipped with steady rest. CE certificate for european used machines.
- 3-cheek lining - 4-cheek lining - fixed bezel - running bezel - 3-axis position display Sino SDS6-3V - Multifix Type E incl. 4 holders - Splash guard - Oil pan - Lighting system - Foot spindle brake - Coolant sealing - Steel stand with 3 drawers and cabinet door - Reduction sleeve - Spare gears Technical data: - Circulating Ø over bed: 360 mm - Circulation Ø over slide: 212 mm Ø without bridge: 490 mm - Center width: 1000 mm - Bed width: 187 mm - Spindle bore: 51 mm - Metric threads: 0.2 - 5 mm (28 steps) - Inch thread: 8 - 112 tpi (36 steps) - Module thread: 0.2 - 3 mm (22 steps) - Thread with diametrical slope: 8 - 112 dp (36 steps) - Longitudinal feed: 0.050 - 0.696 MM (36 steps) - Transverse feed: 0.013 - 0.188 mm (36 steps) - Tailstock Pinoleenaufnahme: MK3 - Tailstock Pinoleenhub: 100 mm - Motor power: 1.5 kW - Dimensions WxHxD: 1925 x 1510 x 75 ...
- Sino SDS6-3V 3-axis position display - magnetic and manual spindle brake - 3 jaw chucks ø 250 mm - 4 jaw linings ø 320 mm - Stop Z-axis - fixed & running bezels - Multifix Type C incl. 4 holders - Flat disc ø 430 mm - Lighting system - Coolant sealing Specification - Tip width: 2000 mm - Circulating Ø over bed: 600 mm - Circulation Ø over slide: 360 mm - Circulating Ø in eruption: 730 mm - Bed width: 330 mm - Spindle bore Ø: 80 mm - Spindle cone: Metric 80 C8 / D1 - D8 - Speed range: 24 - 1600 rpm - Speed levels: 15 - Metric threads: 0.5 - 28 mm (66 steps) - Inch thread: 1 - 56 tpi (66 steps) - Module thread: 0.5 - 3.5 mm (33 steps) - Thread with diametrical slope: 8 - 56 dp (33 steps) - Longitudinal feed: 0.072 - 4.038 mm/U (66 steps) - Transverse feed: 0.036 - 2.019 mm/U (66 steps) - Tool holder: 25 x 25 mm - Tailstock Pinole Ø: 65 mm - Tailstock ...
- Sino SDS6-3V 3-axis position display - magnetic and manual spindle brake - 3 jaw chucks ø 250 mm - 4 jaw linings ø 320 mm - Stop Z-axis - fixed & running bezels - Multifix Type C incl. 4 holders - Face disc - Lighting system - Coolant sealing Specification - Center width: 1000 mm - Circulating Ø over bed: 500 mm - Circulation Ø over slide: 325 mm - Orbital Ø in eruption: 630 mm - Bed width: 330 mm - Spindle bore Ø: 80 mm - Spindle cone: Metric 80 C8 / D1 - D8 - Speed range: 24 - 1600 rpm - Speed levels: 15 - Metric threads: 0.5 - 28 mm (66 steps) - Inch thread: 1 - 56 tpi (66 steps) - Module thread: 0.5 - 3.5 mm (33 steps) - Thread with diametrical slope: 8 - 56 dp (33 steps) - Longitudinal feed: 0.072 - 4.038 mm/rev (66 steps) - Transverse feed: 0.036 - 2.019 mm/rev (66 steps) - Tool holder: 25 x 25 mm - Tailstock Pinole Ø: 65 mm - Tailstock pinole ...
Gurutzpe Super A lathe. Distance between centers: 6.000mm. Swing: 1020mm. Swing in carriage: 745mm. Swing on gap: 1440mm. Spindle bore: 140mm. Speeds: 16 (9-500rpm). Equipped with 4 independent chuck and steady rest. Equipped with new universal chuck of 500mm. Equipped with new DRO Fagor. Equipped with new Multifix turret. Motorized carriage. CE protections and european certificate for second hand machines.
COLOMBO lathe, H points 800x1500, hydraulic tailstock, displayed.
Key data: 660 mm, 3000 mm, 440 mm
Sine 330/3000 D Well-maintained conventional lathe without mounted lathe chuck but with standard accessories The construction follows the classic design however, is based on a heavy, one-piece cast machine bed. How in the case of heavy lathes here, too, the adhesion between the engine and spindle via a manual Multi-plate clutch. With integrated Features such as the removable bed bridge, rapid traverse and a Taper turning device. WORKSPACE Workpiece length 3000 mm Turning diameter over bed 660 mm Circumferential Ø over support 440 mm Turning diameter without bridge 900 mm Bridge length 320 mm Bed width 400 mm TRAVELS X-axis travel 368 mm Travel Z1 axis 230 mm Swivel range upper slide 45° MAIN SPINDLE Spindle speed 25 1/min - 1600 1/min Spindle bore 105 mm Spindle holder D1-8 RUSH COURSE Rapid traverse X-axis 2000 mm/min Rapid traverse Z-axis 4000 mm/min ...
Parallel Lathe WEISSER HEILBRONN Between points: 1100 mm Maxi Ø on bench: 440 mm Maxi Ø over saddle: 230 mm Cone: CM4 Spindle diameter: Ø 45 mm Spindle speed: from 45 to 2000 RPM TRIPAN Turret 3-jaws chuck Ø 200 mm Threadings: Metric + Whitworth Auto feeds longitudinal + transversal Lubricant pump Voltage: 380 V Dimensions (L x W x H): 2500 x 1300 x 1500 mm Weight: approx 2 T
SMT Lathe 80001350 The machine was designed and manufactured to produce rotor shafts for power tools. The machine is designed and manufactured to perform the following operations automatically. - Load/unload parts automatically from/to tool carrier line with a pick-up & placement unit between the shaft ends. - Rotate ring seat + flat rotate commutator + rotate commutator. - Ring mounting - Commutator side - Ring mounting - Drive wheel side The machine has several production programs to produce different parts. Each program uniquely corresponds to a wave type Specifications Anchor wavelength from up to 92.5 - 163.1 mm Bearing pin diameter commutator side 8; 10; 12.5 mm Drive side 12; 8 mm Min. Available length bearing position 3.6 mm Package diameter 52; 55; 59 mm Ring dimensions Outer diameter 40 - 57.4 mm Inner diameter 37.4 - 56 mm Ring width 4 - 8 mm R ...
GENERAL Project No.: 905398 Quantity: 1 pcs. Manufacturer: EMAG Type: VL 3 Control: Fanuc 18i TB Year of construction: 2001/2022 State of condition: Refurbished machine Layers approx.: 2-3 layers DESCRIPTION TURN circulation diameter over bed cover 210 mm chuck diameter 170 mm speed main spindle 7500 1/min power main spindle at ED 10-40/100% 25/16 kW torque main spindle at ED 10-40/100% 134/85 Nm Spindle diameter in the front bearing Main spindle 80 mm Spindle flange size main spindle size 5 (DIN 55026) Axes on the main spindle unit X/Z Travel in X/Y/Z main spindle unit 400/-/200 mm rapid traverse speed in X/Y/Z main spindle unit 60/-/30 m/min Feed force in X/Y/Z main spindle unit 5000/-/5000 N Direct displacement measuring system main spindle unit X/Z Full clamping cylinder on the main spindle Revolver bottom Number of stations/driven by 12/12 Tool ho ...
Inv. Num. : 6305 Type: SKJ 20 Produzent: TOS Erzeugt: 1982 Parametern: Tischdurchmesser: 2000 mm Maximales Werkstückgewicht: 15000 kg Max. Werkstückhöhe: 1200 mm Maximale Tischdrehzahl: 170 1/min Gewicht: 35000 kg
Turning length 650 mm Z-axis 650 mm X-axis 170 mm
Lathe Manufacturer: Meusser & Co. - Frankfurt am Main
Lathe Manufacturer: Meusser & Co. Frankfurt am Main
Description SHOOTING FRORIEP 40Dv Carousel Lathe. Modernized in 1998, among other things, a driven tool system (C-axis) was installed and the control was modernized to 840 C. Details Serial number 11330051 Year of construction 1980 Control SIEMENS electrical connection 400 V Face plate diameter 3,500 mm Workpiece height 3,000 mm Face plate over corridor 160 mm Total power requirement 71 kW Space requirement approx. 13 x 6 m Reconstruction 1998
Parallel Lathe SOCOMO type STAR 305 Between points: 700 mm Maxi Ø on bench: Ø 320 mm Maxi Ø over saddle: Ø 175 mm Spindle diameter: Ø 36 mm Rotation: from 70 to 2000 RPM 3-jaws chuck Ø 200 mm Threadings: Metric + Whitworth Tailstock: CM3 Auto feeds longitudinal + transversal Length: 1800 mm Depth: 800 mm Total height: 1200 mm Weight: approx 1 T
Inv. Num. : 6598 Type: SK 12 Producer: ZPS Created: 1964, GO 1994 Parameters: Table diameter: 1180 mm Clamping plate speed: 5.3-225 1/min Max. turning diameter: 1350 mm Max. workpiece height: 900 mm Max. workpiece weight: 5000 kg Length: 2360 mm Width: 3860 mm Height: 4260 mm Weight: 18300 kg
Gurutzpe Super BT lathe. Distance between centers: 8.000mm. Swing: 2.000mm. Swing in carriage: 1.680mm. Swing on gap: 2.360mm. Spindle bore: 102mm. Equipped with chuck and steady rest. DRO Fagor. CE protections and european certificate for second hand machines.
MAKE CHIRON MODEL MILL 800 5 axis 5 axis machininng center (milling/turning from bar) Under power in our warehouse in Gussago BS Italy Mimu Machine tools CNC Fanuc 18iMBS (5 simoultaneous axis 1) X, Y, Z (mm) 800 â 500 - 550 Rapids (Highspeed) 60 m/min Swivelling head CNC controlled (B axis) +/- 100° Turning spindle Peiseler Milling spindle 12.000 giri / 140 Nm (v nota 2) Tools 65 Tool type HSK-A 63 DIN 69893 Tool-change time 1,5 sec (v nota 3) Table 1400x500 Max table load 1200 kgs 90fjsieew Coolant through spindle 70 bar (see note 4) CNC controlled clamping/rotating unit for 6th face machining (v. nota 5) Pressurised linear encoders Swarf conveyor Renishaw-ready Y.O.M. 2006 Weight 7500 kgs Turning package Max dia 65mm RPM: 15 / 4500 Max 42,5 KW / 90 Nm. Hydraulic clamping 800 Nm. Bar loader ILS-RBK- 10012 65 Diameters min/max 5/65 mm L= 600-1200 mm Highspeed (2) 60m/min. Spindl ...
Lathe Manufacturer: Schaerer Model: UN 200 Center distance: 1600mm
Lathe Speeds: 40 - 2000 rpm Tension - lead screw Distance between centers 1 m Center height 230 mm Length 2.50 m Width 1.20 m Height 1.60 m Multifix B recording Accessories Machine unchecked
Clamping claw box made of solid steel GR 9 (new) 4 pieces
Göltebodt quick-change holder 21 x 300107 € 100,-- 3 x 300114 € 100,-- 1 x 300125 € 150,-- 1 x 300105 € 75,--
Parallel Lathe GEMA LZ 160 Between points: 1000 mm Maxi Ø on bench: 310 mm Maxi Ø over saddle: 180 mm Maxi diameter in brocken bed: Ø 420 mm x Length 200 mm Spindle diameterØ 44 mm Spindle speed: from 48 to 1500 RPM TRIPAN Turret Supplied with 2 tool holders 3-jaws chuck Ø 200 mm Threadings: Metric + Whitworth Tailstock: CM3 Auto feeds longitudinal + transversal Lubricant pump Voltage: 380 V Dimensions (L x W x H): 2100 x 800 x 1300 mm Weight: approx 1,3 T
Lathe TOS SUI 40-50 Center width 1500 mm Circulation over machine bed 500 mm Circulation over support 320 mm Spindle speed 14 to 2240 rpm Quick Release - Steel Bracket § Jaw wedge bar chuck Machine is ready for operation and in good condition
Ref. -No.: 10314 Manufacturer: PINACHO Year of construction: 2005 Type of control: Konventionell Storage location: Halberstadt Country of origin: Spain Travel quill: 180 mm Turning Diameter: 630 mm Turning Length: 3000 mm Turning Diameter Over Bed: 620 mm Cross Movement. (X-Axis): 365 mm Tailstock Quill Diameter: 72 mm Turning diameter over cross slide: 880 mm
Control Rexroth System 200 BTV30 Circulation diameter over bed: 160 mm Circulation diameter over face carriage 250 mm Chuck diameter 160 mm Turning length 300 mm Spindle speed 8000 min-1 12-speed revolver with attached Competition. Workpiece conveyor belt Conveyor Various tool holders
Parallel Lathe WMW NILES type DLZ 500 IV L 1000 Between points: 1000 mm Maxi Ø on bench: 500 mm Maxi Ø over saddle: 300 mm Spindle diameter: Ø 50 mm Spindle speed: from 28 to 1400 RPM 3-jaws chuck Ø 200 mm Threadings: Metric + Whitworth Tailstock CM4 Auto Feeds transverse + longitudinal + rapid Lubricant pump Voltage: 380 V Dimensions (L x W x H): 3000 x 1400 x 1500 mm Weight: approx 2,5 T
Parallel Lathe MULLER & PESANT Between points: 2500 mm Maxi Ø on bench: 520 mm Maxi Ø over saddle: 280 mm Maxi diameter in brocken bed: 700 mm Spindle diameter: Ø 56 mm Spindle speed: from 12,5 to 1000 RPM TRIPAN Turret 3-jaws chuck Ø 250 mm Tailstock CM4 Auto feeds longitudinal + transversal Lubricant pump Voltage: 380 V Dimensions (L x W x H): 4000 x 1500 x 1600 mm Weight: approx 3,5 T
Gurutzpe Super AT lathe. Distance between centers: 4000mm. Swing: 1020mm. Swing over carriage: 710mm. Swing in gap: 1320mm. Bore: 76,5mm. Motorized carriage. 4 independent jaws chuck. DRO Heidenhain.
Mobile milling machine for attachment, e.g. a lathe. As good as new, almost unused condition More data according to photos
Key data: 280 mm
Year of construction 2015 Center height: 165 mm Center width: 650 mm Turning diameter over bed: 280 mm Face slide: 180 mm Spindle speed: 30 - 4000 rpm (infinitely variable) Spindle bore: 43 mm Feeds: 0.025 - 0.9 mm/rev Thread pitch: 0.2 - 7 mm Spindle head DIN 55027: Size 5 Bed sledge travel: 610 mm Sledge travel: 165 mm Upper slide travel: 115 mm Inner cone tailstock quill DIN 228: MK3 Quill stroke: 82 mm Dimensions: 1600 x 860 x 1450 mm Weight: 1000 kg Total power requirement: 18kVA Accessories: 3-jaw chuck, Multifix quick-change steel bracket with cassettes, bezel, coolant device, lighting, chip protection
Key data: 560 mm, 1200 mm, 380 mm
Lathe Core Three-jaw chuck Multifix B 2 Holder Spindle bore 52 mm Speeds 38 - 1900 rpm Steels Chuck Sharpen 380 V 25 A Length 2.80 m Width 1.00 m Height 1.60 m
Control: Siemens 840 C Max. turning diameter: 1300 mm Max: Circulation diameter: 1400 mm Axle stroke: Z-1000 mm X-1500 mm Dimensions to top edge of spindle: 940 mm Bearing Ø in front bearing: 710 mm Max. speed: 500 rpm Max. torque: 30 000 Nm Main spindle motor AC max.: 100/40% ED 76/115 kW Chip diameter: 1600 mm Feed intake/centeringØ: 790 mm Max. feed force Z/X axis: 25000 N Axis speed Z-X-axis: 0.01 – 14000 mm/min Z-X-Axis Displacement Measuring System: Angle Position Sensor/Linear Measuring System Tool carrier: Disc turret with B-axis Tool holders: Modular system UTS 50 Machine weight: 30 000 kg The machine is still energized. Viewing possible at any time by arrangement.
Key data: 178 mm, 485 mm, 100 mm
Turning length: 485 mm Rotation diameter: 178 mm above bed / 100 mm over cross slide Spindle Passage: 15.5 mm Spindle speeds: 25 - 2,150 rpm. Tool Container: Tripan Container Equipped with: - Rohm 3-jaw chuck with different jaws - Zahrade Set - Collet set -Operating instructions Country of origin: UK Machine LxWxH: 1180 x 700 x 1200 mm Machine weight: 170 kg
Technical data approx.: - Largest turning diameter - over bed 560 mm - via flat slide 315 mm - Center width 1500 mm - Traverse transverse slide approx. 300 mm - Spindle bore 80 mm - Mounting cone of the tailstock quill MK 4 - Travel of the tailstock quill 150 mm - Spindle speeds 1 - 2500 rpm - Rapid traverses X / Y -with: - NC – FANUC control - 2 E. handwheels for manual turning -Tailstock - Coolant device - Drive 400 V / 7.5 kW - Space requirement approx. W 3250 x H 1750 x D 1500 mm - Weight approx. 3800 kg
Key data: 500 mm
804337 Spindle and nut X-axis TOS TRENS SN50 series
