maho graziano used for sale

Table length: 1000 mm Table width: 600 mm Longitudinal X: 630 mm Cross Y: 560 mm Vertical Z: 560 mm Positions ATC: 20   Positions APC: 0   CNC Brand: Heidenhain CNC Model: 3D Mill Plus MACH-id     5023 MAKE          Deckel Maho TYPE            DMU 60 T YOP              2000 SPECIFICATIONS Controll      HeidenHain 3D Mill Plus Spindle Taper         Sk 40 kW power on spindle       13 kW CNC Automatic milling head / Gr.-91 to + 12 Grad X - Travel        630 mm Y - Travel        560 mm Z - Travel        560 mm Table Length x Width        1000 x 600 mm Table load in kG       500 Kg Number off controll ...

Table length: 800 mm Table width: 480 mm Longitudinal X: 500 mm Cross Y: 420 mm Vertical Z: 380 mm Positions ATC: 32   Positions APC: 0   CNC Brand: Heidenhain CNC Model: 3D Mill Plus MACH-id   5024 MAKE        Deckel Maho TYPE          DMU 50 eVolution YOP            2000 SPECIFICATIONS Controll        HeidenHain 3D Mill Plus Spindle Taper       Sk 40 kW power on spindle       13 kW X - Travel        500 mm Y - Travel        420 mm Z - Travel         380 mm Table Length x Width      800 x 480 mm Table load in kG       180 Kg Number off controlled axis        3 ATC tool changer      ...

Code 0739 DESCRIPTION CNC Universal toolroom milling machine Make Maho Model MH 700 C S/N 75915 Year 1984 Control Philips CNC 432 Table 900 x 500 mm Longitude ( X – axis ) table 700 mm Vertical ( Y – axis ) table 450 mm Cross ( Z – axis ) spindle 500 mm Spindle out ( H/V ) 100 mm Max. distance table / spindle horizontal 700 mm Max. distance spindle / table vertical 500 mm Spindle taper 40 ISO Speeds 20 – 3150 rpm Feeds X-Y-Z 1 – 3000 mm/min Rapides 6 m/min Spindle motor 8 kW - 380 Volts Accessories Table 900 x 500mm Condition Machine is in good condition

x-travel: 600 mm y-travel: 560 mm z-travel: 560 mm Control: SIEMENS 840 C total power requirement: 12 kW weight of the machine ca.: 10000 kg dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 750 mm y-travel: 560 mm z-travel: 600 mm Control: HEIDENHAIN iTNC 530 total power requirement: 70 kW weight of the machine ca.: 11.000 kg dimensions of the machine ca.: m D E C K E L M A H O (Germany) Vertical CNC Machining Centre with high speed linear drives in 3 Axis and in double column design for high precision work Model DMC 75 V LINEAR Year 2005 _______________________________________________________ Working range: Longitudinal stroke X Axis 750 mm Vertical stroke Z Axis 600 mm Cross stroke Y Axis 560 mm Table clamping size 950 x 650 mm Max. Table load 1.000 kg Max. height of workpiece 600 mm Tool holder Cone HSK 63 Spindle (KESSLER) speeds 18,000 rpm Torque, max. 86/1 ...

Table length: 0 mm Table width: 0 mm Longitudinal X: 600 mm Cross Y: 700 mm Vertical Z: 600 mm Positions ATC: 120   Positions APC: 0   CNC Brand: Heidenhain CNC Model: TNC 430 MACH-id     4103 MAKE         DMG Deckel Maho TYPE           DMU 60 P Hi Dyn YEAR          2000 SPECIFICATIONS X - Travel    600 mm Y - Travel    700 mm Z - Travel     600 mm bed / plano / portal / moving column     5 Axis Controll      Heidenhain TNC 430 Table Length x Width       630 mm Table load in kG        600 Kg Spindle Taper      HSK 63 kW power on spindle     16 kW Spindle speeds / ranges       18000 Rpm ATC tool changer   ...

x-travel: 1000 mm y-travel: 500 mm z-travel: 700 mm table surface area: 1250 x 700 mm spindle taper ISO: 50 spindle turning speed range: 20 - 3200 U/min quill stroke: 100 mm semi-automatic operated: Phillips 432 Number of working hours: 62.340 h main drive motor: 22 kW total power requirement: 27 KVA weight of the machine ca.: 7,7 t base area: 3,8 x 4,1 x 2,4 mm accessories:: hydr. Schraubstock X axis, longitudinal 1,000 mm Y axis, vertical 500 mm Z axis, cross 700 mm Min./max. distance from vertical spindle to table top 138 / 600 mm Overhang max. approx. 800 mm Spindle taper SK 50 with inner cooling Spindle speeds (infinitely variable in 2 steps) 20 - 3,200 rpm Feed motion YXZ 1 - 3,000 mm/min Rapid traverse XZ 6,000 mm/min, Y = 5,000 mm/min. Divider as 4th axis with housing of the working area The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 600 mm y-travel: 525 mm z-travel: 500 mm table surface area: 1000 x 543 mm spindle taper: SK 40 spindle taper: DIN 69871 spindle turning speed - stepless: 20 - 12.000 U/min feed X/Y/Z-axis: 20 - 10.000 mm/min rapid traverse X/Y/Z axis: 18 / 18 / 15 m/min table load: max. 350 kg control: HEIDENHAIN MillPlus milling-head swivable +/-: 90 ° total power requirement: 26 kVA weight of the machine ca.: 4,2 t dimensions of machine L x W x H: 2,95 x 2,1 x 2,26 m Accessories: various tool fixtures, coolant The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 660 mm y-travel: 500 mm z-travel: 600 mm table surface area: 630 x 500 mm spindle taper: SK 40 spindle turning speed range: 20 - 6.300 U/min feeds: 30 m/min control: PHILIPS CNC 532 internal coolant system feed: 40 bar total power requirement: 50 kW weight of the machine ca.: 13,3 t dimensions of machine: 4,98 x 2,78 x 2,93 m with rotary pallet changer and hydr. swivelling head (horiz./vert.) Accessories: chip conveyor, coolant The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 700 mm y-travel: 500 mm z-travel: 600 mm size of pallet: 630 x 500 mm spindle taper ISO: 40 turning speed range: 20 - 6300 U/min feeds longditudinal/cross/vertical: 1 - 4000 mm/min rapid travel x/y/z: 10 / 8 / 10 m/min control: PHILIPS CNC 432 spindle motor: 15 kW total power requirement: kW weight of the machine ca.: 6,0 t dimensions of machine: 4,10 x 2,17 x 2,55 m acc.: hydr. swivelling head with hydr. tool clamping, chip conveyor, coolant, entire protection cabin with pallet changer (two pallets) and 60-pos. tool changer The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Table length: 1250 mm Table width: 600 mm Longitudinal X: 1040 mm Cross Y: 600 mm Vertical Z: 500 mm Positions ATC: 30   Distance between uprights: 0 mm CNC Brand: Heidenhain CNC Model: iTnc 530 MACH-id   3989 MAKE       Deckel Maho TYPE         DMC 104 V Linear YEAR        2007 SPECIFICATIONS X - Travel    1040 mm Y - Travel      600 mm Z - Travel      500 mm bed / plano / portal / moving column    Portal Controll     iTNC 530 Table Length x Width   1250 x 600 mm Table load in kG   800 Kg Spindle Taper    Sk 40 kW power on spindle   30 kW Spindle speeds / ranges    12000 Rpm ATC tool changer   30 Coolant true spindle / Bar    10 Bar Number off  ...

Table length: 3100 mm Table width: 900 mm Longitudinal X: 2500 mm Cross Y: 900 mm Vertical Z: 800 mm Positions ATC: 30   Positions APC: 0   CNC Brand: Heidenhain CNC Model: iTNC 530 MAKE   DMG TYPE    250 linear YEAR   2004 SPECIFICATIONS X - Travel   2500 mm Y - Travel   900 mm Z - Travel    800 mm Controll   ITNC 530 Table Length x Width   3100 x 900 mm Table load in kG    3000 Kg Spindle Taper    HSK 63    kW power on spindle   35 kW Spindle speeds / ranges   18.000 Rpm ATC tool changer    30 Coolant true spindle / Bar   17 Bar Number off controlled axis 5 CNC Automatic milling head / Gr.0.001 Gr DIMENSIONS Length   6500 mm Width    3000 mm Height   3000 mm   ...

x-travel: 880 mm y-travel: 630 mm z-travel: 630 mm Control: Heidemhain type: 426/430 spindle speed:: 18000 spindle taper: HSK 63 surface area: 1250x700 mm Rotary table: 700 mm Table load: 1000 kg b-axis: Schwenkopf 0,001 ° c-axis: 0-360° Rundtisch 0 total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 800 mm y-travel: 650 mm z-travel: 550 mm control: Heidenhain Millplus tool taper: SK40 total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 700 mm y-travel: 600 mm z-travel: 600 mm table surface area: 630 mm : 360 Grad angle of table min./max.: 45/20 Grad turning speeds: 6300 U/min control: Pfilips type: CNC 432 Tool changer: spindle taper ISO: 40 chip conveyor: total power requirement: 27 KVA weight of the machine ca.: 5,8 t dimensions of the machine ca.: 4,1x2,3x2,4 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 1250 mm y-travel: 1000 mm z-travel: 1000 mm taper ISO: 50 Table dimensions: 650 x 1000 mm spindle speeds: 32-1600 voltage: 380 V total power requirement: 7,5 kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Table length: 1250 mm Table width: 800 mm Longitudinal X: 1000 mm Cross Y: 800 mm Vertical Z: 700 mm Positions ATC: 30   Distance between uprights: 1300 mm CNC Brand: _Unknown / Other CNC Model: Dialog 112 MAKE  Deckel Maho TYPE   DMC 100 V YEAR   1998 SPECIFICATIONS X - Travel  1000 mm Y - Travel   800 mm Z - Travel   700 mm bed / plano / portal / moving column   Portal milling Controll    Dialog 112 Table Length x Width   1250 x 800 mm Table load in kG   1250 Kg Spindle Taper    Sk 40 kW power on spindle   10 kW Spindle speeds / ranges   8000 Rpm ATC tool changer   30 Number off controlled axis   3 Distance between columns    1300 mm DIMENSIONS Length   4500 mm Width    3200 mm  ...

turning diameter: 500 mm turning length: 1100 mm control: Pfillips 432 turning diameter over slide rest: 420 mm spindle turning speed range: 3000 U/min spindle passage: 82 mm Tool changer: 12 tool taper: VDI 40 total power requirement: kW weight of the machine ca.: 5,7 t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 600 mm y-travel: 400 mm z-travel: 400 mm spindle taper ISO: 40 spindle turning speed range: 80 - 4000 U/min transmission ratio: 18 feed range: 0,1 - 2000 mm/min rapid traverse: x = 4 / y = 3 / z = 5 m/min table load capacity: 250 kp voltage: 380 V / 50 Hz spindle drive: 5,5 kW total power requirement: 16 kVA weight of the machine ca.: 2,6 t dimensions of the machine ca.: 3,8 x 4,3 x 2,0 m • CNC-control system 432 E • Operating hours: 37719 The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

: DMC 60 U Hi-Dyn control: Heidenhain TNC 430 x-travel: 600 mm y-travel: 700 mm z-travel: 600 mm : Form AD turning speeds: 0 - 18.000 U/min : : 630x500mit Palettenträger mm pallet changing: 2-fach pallet size:: 2 x 630 x 500 mm : SK40 tool change unit: 60 Plätze : Heidenhain TT 130 : : coolant: : 40 bar chip conveyor: kW : The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 630 mm y-travel: 560 mm z-travel: 560 mm Control: Heidenhain TNC 430 total power requirement: 26 kW weight of the machine ca.: 6500 t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 880 mm y-travel: 630 mm z-travel: 630 mm control: TNC 426/430 Heidenhain Main spindle:: turning speed range - main spindle: 20 - 18.000 min/-1 power capacity - main spindel: 15 / 10 kW max. Torque: 130 Nm tool taper: SK 40 swivellable: work table:: table surface area: 1.250 x 700 mm max. table load: ca. 1.000 kg tool magazin:: number of toolpositions: 32 (2x 16) pos. tool taper: SK 40 max. tool diameter: 80 / 130 mm max. tool-dia with free toolbox: 160 mm max. tool length: 315 mm max. tool weight: 8,0 kg feeds:: feed speeds: 1 - 15.000 mm/min rapid traverse: 30 m/min total power requirement: 60 kW weight of the machine ca.: 8,0 t dimensions of the machine ca.: 4,0 x 4,0 x 2,7 m Documents: swarf management system: Coolantsystem: elektr. hand wheel: spindle oil cooler: tool monitoring: CNC - MachiningCenter Universal DECKEL MAHO - DMU 80 T - Swivel-Milling-Head The  ...

Table length: 700 mm Table width: 500 mm Longitudinal X: 500 mm Cross Y: 400 mm Vertical Z: 400 mm Positions ATC: 0   Positions APC: 0   CNC Brand: Heidenhain CNC Model: TNC 124 MACH-id   3609 MAKE    Deckel Maho TYPE  DMU 50 M YEAR   1998 SPECIFICATIONS    X - Travel   500 mm Y - Travel   400 mm Z - Trave    l400 mm Controll     HedienHain TNC 124 Table Length x Width   700 x 500 mm Table load in kG    200 Kg Spindle Taper    Sk 40 kW power on spindle   9 kW Spindle speeds / ranges   4500 Rpm DIMENSIONS Length   2610 mm Width     2700 mm Height   2500 mm

x-travel: 1.250 mm y-travel: 880 mm z-travel: 800 mm control: TNC 430 Heidenhain Main spindle:: turning speed range - main spindle: max. 12.000 min/-1 power capacity - main spindel: 15 / 10 kW max. Torque: 500 Nm tool taper: SK 40 work table:: table surface area: 1.500 x 1.050 mm max. table load: 2.500 kg number of T-slots: 10 T-slot - width: 18 H7 mm T-slot - distance: 100 mm Tool-Presetter:: number of toolpositions: 60 pos. max. tool diameter: 80 mm max. tool-dia with free toolbox: 160 mm max. tool length: 315 mm max. tool weight: 8 kg max. total weight: 100 kg feeds:: rapid traverse ( X / Y / Z ): 15 m/min feed speeds: 10.000 mm/min total power requirement: 29 kW weight of the machine ca.: 16,0 t dimensions of the machine ca.: 7,0 x 5,0 x 3,3 m Documents: Chip conveyor: Coolantsystem: Automatic Tool Changer: elektr. hand wheel: CNC - Machining Center Vertical DECKEL MAHO - DM ...

x-travel: 500 mm y-travel: 350 mm z-travel: 380 mm table-size: 790x360 mm spindle turning speed range: 63-4000 U/min weight of the machine ca.: 1.8 t Active Digital read out Misc.accessories www.marcels-maschinen.ch The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Table length: 700 mm Table width: 500 mm Longitudinal X: 500 mm Cross Y: 400 mm Vertical Z: 400 mm Positions ATC: 0   Positions APC: 0   CNC Brand: Heidenhain CNC Model: TNC 124 SPECIFICATIONS X - Travel    500 mm Y - Travel    400 mm Z - Travel    400 mm bed / plano / portal / moving column   3 + 2 Axis Universal CNC Milling machine Controll   HeidenHain TNC 124 Table Length x Width   700 x 500 mm Table load in kG   200 Kg Spindle Taper   Sk 40 kW power on spindle  9 kW Spindle speeds / ranges  4500 Rpm Number off controlled axis  3 + 2

Table length: 800 mm Table width: 800 mm Longitudinal X: 800 mm Cross Y: 700 mm Vertical Z: 600 mm Positions ATC: 5   Positions APC: 0   CNC Brand: Heidenhain CNC Model: iTNC 530 SPECIFICATIONS X - Travel   800 mm Y - Travel  700 mm Z - Travel  600 mm bed / plano / portal / moving column 5 Axis with auto Head & C Axis   ControlliTNC 530 Table Length x Width  800 mm Table load in kG   800 Kg Spindle Taper  Hsk 63 Spindle speeds / ranges   12.000 Rpm ATC tool changer   30Coolant true spindle / Bar   18 Bar Number off controlled axis  5  CNC Automatic milling head / Gr.B axis 0 - 190 Gr & A Axis 0 - 130 Gr

x-travel: 1200 mm y-travel: 600 mm z-travel: 600 mm total power requirement: 25 kW weight of the machine ca.: 11,5 t M A H O (Germany) CNC Controlled Bed Type Universal Machining Centre Model MH 1200 S (120012) Year 1991 Partially reconditioned in Year 2007 by MMD Company _____________________________________________________________ Table travel: X axis, longitudinal 1,200 mm Y axis, vertical 600 mm Spindle head Z axis, cross 600 mm Rotary Table size 1,000 x 800 mm Distance between spindle and column, max. 900 mm Spindle taper SK 40 Spindle speeds (infinitely variable in 2 steps) 20 – 6,300 rpm Max. weight of workpiece 1,000 kg Feeds / quick feeds, X, Y and Z Axes 1 – 4,000 / 12,000 mm/min Feeds / quick feeds, B Axi ...

x-travel: 1000 mm y-travel: 500 mm z-travel: 650 mm tool taper: SK 40 quill stroke: 100 mm turning speed range - power take off spindle: 40-2000 U/min Feed: 5-2000 mm/min Rapid movement: 4000 mm/min Control: Heidenhain total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Table length: 800 mm Table width: 500 mm Longitudinal X: 630 mm Cross Y: 500 mm Vertical Z: 500 mm Positions ATC: 25   Positions APC: 0   CNC Brand: Heidenhain CNC Model: TNC 426 SPECIFICATIES Verplaatsing X - as  630 mm Verplaatsing Y - as  500 mm Verplaatsing Z - as  500 mm Type bed freezer - bed / vloer / portaal VMC Besturing  HeidenHain TNC 426 Tafel afmeting lengte x breedte  800 x 500 mm Spindel opname Iso  Bt 40 Vermogen aan spil kW  10 kW Toeren - Snelheden - Stappen   8000 Rpm Gereedschap wisselaar   25 Koeling door spil in Bar   15 Bar Aantal gestuurde assen 3 + 1

Milling machine DECKEL MAHO DMG 125

Type: DMU 60T Max longitudinal travel X-axe: 630 mm Max cross-travel Y-axe: 560 mm Max travel Z-axe: 560 mm Power on spindle: 40 kW Admission in millinghead: SK40 Spindlespeeds: 20 > 12 000 rpm Table size: 1000 x 600 mm Control: Heidenhain Length: 2800 mm Depth : 3490 mm Height: 2220 mm Weight: 7 ton

Table length: 900 mm Table width: 630 mm Longitudinal X: 800 mm Cross Y: 600 mm Vertical Z: 700 mm Positions ATC: 60   Positions APC: 0   CNC Brand: Heidenhain CNC Model: TNC 426 SPECIFICATIONS X - Travel 800 mm Y - Travel  600 mm Z - Travel  700 mm bed / plano / portal / moving column 5 AXIS VMC Controll  TNC 426 Table Length x Width   900 x 630 mm Table load in kG  800 Kg Spindle Taper  Sk 40 Spindle speeds / ranges  12000 Rpm ATC tool changer   60 Coolant true spindle / Bar  15 Bar Number off controlled axis   5 CNC Automatic milling head / Gr.0.001 Gr

Deckel Maho DMU50e DMU 50 Evolution Max longitudinal travel X-axe: 500 mm Max cross-travel Y-axe: 420 mm Max travel Z-axe: 380 mm Power on spindle: 25/35 kW Type of millinghead: SK 40 Spindlespeeds: 20 > 18 000 rpm Table size: Ø 500 x 380 mm Control: Heidenhain Power needed: 38 kVa Length: 4000 mm Depth : 2500 mm Height: 2700 mm Weight: 5 ton Toolholder: yes Number of tools: 32 tools

Table length: 700 mm Table width: 500 mm Longitudinal X: 500 mm Cross Y: 400 mm Vertical Z: 400 mm Positions ATC: 0   Positions APC: 0   CNC Brand: Heidenhain CNC Model: TNC 124 SPECIFICATIES Verplaatsing  X - as   500 mm Verplaatsing Y - as  400 mm Verplaatsing  Z - as  400 mm Type bed freezer - bed / vloer / portaal VMC Besturing  Heidenhain TNC 124 Tafel afmeting lengte x breedte700 x 500 mm Tafel belasting in Kg 200 Kg Spindel opname Iso   Sk40 Vermogen aan spil kW  9 kW Toeren - Snelheden - Stappen  4500 Rpm Gereedschap wisselaarno ATC   Aantal gestuurde assen  3 + 2 AFMETINGEN Lengte 2600 mm Breedte 2700 mm Hoogte 2500 mm

serial number: 82586 Control: Heidenhain 234 x-travel: 800 mm y-travel: 500 mm z-travel: 550 mm table size: 900 x 600 mm : max. 3.000 U/min tool adaptor: SK40 weight of the machine ca.: 2,2 t The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

MAschinen Details Warehouse number 1105-03470 Machine Type Machining Center - Vertical Make DMG DECKEL MAHO Type DMF 180 linear Year of construction 2012 Control type CNC Control SIEMENS 840 D Storage location FRANCE Country of origin Germany Delivery time 1 month after order Freight base from location Technical details x-path 1800 mm y-way 700 mm z-way 700 mm Control SIEMENS 840 D 840 D Table clamping surface 2600 x 600 mm Table load 2 t Speed 18000 rpm Recording ISO SK 40 Tool changing device 30-fold Rapid speed 50 m/min Operating hours 53000 h Spindle hours 13500 h Total power requirement 36 kVA Machine weight approx. 11 t Space requirement approx. 4.40 x 2.45 x 2.65 m Information LID MAHO DMG DMF 180 Linear Equipment direct path measuring system RIGID TABLE WITH INTEGRATED RUNNING TABLE D.750 MM CENTRALLY ARRANGED NICT WITH IKZ 600 liters 40 bar PAPER ...

Table length: 700 mm Table width: 500 mm Longitudinal X: 500 mm Cross Y: 400 mm Vertical Z: 400 mm Positions ATC: 0   Positions APC: 0   CNC Brand: Siemens CNC Model: Sinumerik Shopmill SPECIFICATIES Verplaatsing X - as 500 mm Verplaatsing Y - as 400 mm Verplaatsing  Z - as 400 mm Type bed freezer - bed / vloer / portaal VMC Besturing     Siemens Sinumrik SHOPMILL Tafel afmeting lengte x breedte 700 x 500 mm Tafel belasting in Kg  200 Kg Spindel opname Iso  Sk 40 Vermogen aan spil kW 9 kW Toeren - Snelheden - Stappen 8000 Rpm Gereedschap wisselaar 18Aantal gestuurde assen 3 + 2 AFMETINGEN Lengte 2610 mm Breedte 2700 mm Hoogte 2500 mm

DMG Deckel Maho DMU 60T X: 630 - Y: 560 - Z: 560 mm Max longitudinal travel X-axe: 630 mm Max cross-travel Y-axe: 560 mm Max travel Z-axe: 560 mm Power on spindle: 10/15 kW Admission in millinghead: SK 40 Spindlespeeds: 20 > 12 000 rpm Table size: 1000 x 600 mm Control: Heidenhain Length: 2800 mm Depth : 3490 mm Height: 2220 mm Weight: 7 ton Toolholder: yes Number of tools: 24 tools

CNC milling machine make MAHO type MH 600 ESerial -No: 63770, year of construction 1986Working area X: 600 mmWorking area Y: 400 mmWorking area Z: 400 mmTable size / rigid angle table: 1000 x 400 mmTool holder: ISA 40Quill stroke: 80 mmSpeed range: 80 - 4000 rpm.Feed range X, Y, Z: 1 - 2000 mm / min.Rapid traverse X: 4 m / min.Rapid traverse Y: 3 m / minRapid traverse Z: 5 m / minResolution: 0.001 mmDrive power / total connection value: 4.0 kW / 16 kVAFootprint: 2300 x 2160 x 1900 mmWeight: 2.25 tWith- CNC track control type 432 Eused in good conditionPrice on request.Delivery: ex warehouse or location free loading truck.Payment: net at takeover or by appointment.Technical data are not binding. Errors excepted.We would be pleased, if you like our offer and are always available for your queries.Best regardsM. WaldeckWAHO Machine Tools

Technical data Table length: 590 mm Table width: 270 mm Longitudinal travel (X-axis): 400 mm Transversal travel (y axis): 250 mm Vertical travel (z axis): 737 mm Distance from vertical spindle to table: 400 mm Distance from horizontal spindle to table: 470 mm Table load max.: 60 kg Spindle speeds: stepless from: 50 rpm up to: 3450 rpm Taper in spindle: 40 ISO Feeds stepless: longitudinal from: 5 mm/min up to: 1000 mm/min transversal from: 5 mm/min up to: 5000 mm/min Rapid traverse: longitudinal: 0.67 m/min transversal: 2.4 m/min vertical: 1.6 m/min Voltage 50 Hz 3x: 380 Volt Spindle motor: 2.2 kW Total power required: 5.1 kVA Machine´s weight about: 900 kg Overall dimensions machine: Length: 1500 mm Width: 1300 mm Height: 2000 mm Various accessories: Dividing attachment Rotary table:diameter: 340 mm Digital readout number of axis:: 3 Coolant system Steady Rigide table Universal ta ...

Technical data Table length: 690 mm Table width: 270 mm Longitudinal travel (X-axis): 400 mm Transversal travel (y axis): 250 mm Vertical travel (z axis): 375 mm Distance from vertical spindle to table: 400 mm Distance from horizontal spindle to table: 470 mm Table load max.: 60 kg Spindle speeds: stepless from: 50 rpm up to: 3150 rpm Taper in spindle: 40 ISO Feeds stepless: longitudinal from: 5 mm/min up to: 1000 mm/min transversal from: 5 mm/min up to: 1000 mm/min vertical from: 5 mm/min up to: 670 mm/min longitudinal: 2.4 m/min transversal: 2.4 m/min vertical: 1.6 m/min Voltage 50 Hz 3x: 380 Volt Spindle motor: 2.2 kW Total power required: 5.1 kVA Machine´s weight about: 900 kg Overall dimensions machine: Length: 1500 mm Width: 1300 mm Height: 2000 mm Various accessories: Dividing attachment Coolant system Rigide table Universal table Vertical milling head Automatic central lub ...

Table length: 700 mm Table width: 500 mm Longitudinal X: 500 mm Cross Y: 400 mm Vertical Z: 400 mm Positions ATC: 0   Positions APC: 0   CNC Brand: Heidenhain CNC Model: SK 40 SPECIFICATIONS X - Travel  500 mm Y - Travel  400 mm Z - Travel  400 mm bed / plano / portal / moving columnVMC Controll  TNC 124 Table Length x Width  700 x 500 mm Table load in kG  200 Kg Spindle Taper   Sk 40kW power on spindle   9 kW Spindle speeds / ranges  4500 Rpm

CNC tool milling machine make MAHO type MH 700 CMachine -No: 76845 Year 1986Clamping surface CNC rotary table: 630 mmTable movement along X: 600 mmTable movement vertical Y: 450 mmHorizontal movement of the spindle head Z: 500 mmSpindle mount: ISO 40Quill stroke of the work spindle by hand: 80 mmSpindle speeds via DC power:infinitely variable: 20-3135 rpm.Feedrate for all 3 axesvia DC drive stepless adjustable: 1-3000 mm / minRapid traverse for all 3 axes: 4 m / minCorrection of the feed and rapid traversespeeds for all 3 axes: 0-140%elec. Connection: 380 V, 14 kWWeight: 3400 kgWith- 52800 hours of operation- CNC Phillips control 432- CNC rotary table as 4th axis- electr. Control panel with screenxa0xa0 attached to the swivel arm- full cabin !- electronic handwheel- Coolant device- chip trayused, in good conditionPrice on request.Delivery: ex warehouse or location free loading truck.Paym ...

Table length: 1000 mm Table width: 600 mm Longitudinal X: 630 mm Cross Y: 560 mm Vertical Z: 560 mm Positions ATC: 24   CNC Brand: Heidenhain CNC Model: TNC 430 SPECIFICATIONS X - Travel  630 mm Y - Travel  560 mm Z - Travel  560 mm Controll  HeidenHain TNC 430 Table Length x Width  1000 x 600 mm Table load in kG  500 Kg Spindle Taper   Sk40 / HSK 63kW power on spindle    9 / 13 kW Spindle speeds / ranges   18.000 Rpm ATC tool changer  12 + 12 = 24 x Coolant true spindle / Bar   17 Bar Bar Number off controlled axis   3 + 1 B Axis

Table length: 0 mm Table width: 0 mm Longitudinal X: 630 mm Cross Y: 560 mm Vertical Z: 560 mm Positions ATC: 0   Positions APC: 0   CNC Brand: Heidenhain CNC Model: TNC 430 SPECIFICATIONS X - Travel  630 mm Y - Travel  560 mm Z - Travel  560 mm Controll  TNC 430 Spindle Taper  Bt 40 Spindle speeds / ranges  20 - 18000 Rpm ATC tool changer  Bt 40 & Hsk 63

Tool milling machine make MAHO type MH 700Machine -No: 71139Technical specifications:Working area X 500 mm Y 465 mm Z 400 mmSpindle mount ISA 4018 spindle speeds 32 - 1600 rpm.Quill stroke 100 mmCross feed aut.:10 - 500 mm / min.Longitudinal feed 10 - 500 mm / min.Vertical feed 5 - 250 mm / min.Rapid traverse : 1.4 / 1.4 / 0.7 mUniversal table / clamping surface 820 x 480 mmTable lateral adjustment 200 mmTable can be swiveled by + - 30 °Can be tilted by + - 30 °Table rotatable around 360 °Drive power 3.0 kWFeed motor 1.1 kWWeight approx 2020 kgExternal dimensions approx . 1800 x 1500 x 1800 mmWith- Point-to-point control Heidenhain TNC 121- Universal milling table- automatic tool clamping- various tool holdersused, in good conditionPrice on request.Delivery: ex warehouse or location free loading truck.Payment: net at takeover or by appointment.Technical data are not binding. Errors ex ...

Table length: 2600 mm Table width: 600 mm Longitudinal X: 2200 mm Cross Y: 560 mm Vertical Z: 720 mm Positions ATC: 30   CNC Brand: Siemens CNC Model: 840 D Power Line SPECIFICATIES Verplaatsing   X - as  2200 mm Verplaatsing   Y - as   560 mm Verplaatsing Z - as  720 mm Type bed freezer - bed / vloer / portaal  5 Axis VMC Besturing   Siemens 840D Power Line Tafel afmeting lengte x breedte   2600x 600 mm Tafel belasting in Kg   3500 Kg Spindel opname Iso   iso 40 Toeren - Snelheden - Stappen   8500 Rpm Gereedschap wisselaar   30 Koeling door spil in Bar  17 Bar Aantal gestuurde assen   3 + 2 Axis Kop indexeerbaar B en of C en hoeveel ˚graden  A + B Axis rotary table

CNC Universal milling machine make MAHO type MH 400 PFabr. -No: 41837 Year 1983vertical clamping surface: 800 x 200 mmWorking area along X: 400 mmWorking area vertical Y: 375 mmWorking area transverse Z: 250 mmTool holder: ISO 40Tool clamping: automaticQuill stroke vertical: 50 mmstepless speed adjustmenthorizontal and vertical: 40-3150 rpm.Feed range X and Y: 5 - 750 mm / minFeed range Z: 5 - 500 mm / minRapid traverse X and Y: 1.2 m / minRapid traverse Z: 0.8 m / minMain drive: 2.2 kWOutside dimensions approx: 1000 x 1300 x 1750 mmWeight approx: 850 kgWith- Point and distance control HEIDENHAIN TNC 135- rigid angle table- Horizontal milling deviceused, in good conditionPrice on request.Delivery: ex warehouse or location free loading truck.Payment: net at takeover or by appointment.Technical data are not binding. Errors excepted.We would be pleased, if you like our offer and are always  ...

Power: 100 kW X - axis: 300 mm Y - axis: 400 mm Number laser heads: 0   CNC Brand: _Unknown / Other CNC Model: Lasersoft 3 D Make Deckel Maho Type DML 40 S Year 2001 LASERSOFT 3D - 6 Axis Table length (mm)L = 400 Table width (mm)W = 300 Longitudinal X (mm)X = 300 Cross Y (mm)Y = 400 Vertical Z (mm)Z = 500 Laser 100 W3 Mechanical axis 3 Optical Axis- Automatic repositioning - DECKEL MAHO LASERSOFT 3 D - Direct 3 D Autocad import - Filigran Kavitaeten 0.04 mm - Keramik machining possible - Vertical machining possible - Dimensions - Length : 3.500 - Width : 3.000 - Height : 2.000 - Weight : 2.200
