magazine used for sale

CNC Lathe Gildemeister CTX 200 Series 2 Immediately free from location: CNC Lathe Gildemeister Type CTX 200 Series 2 Built in 2001 Operating hours 39,000 CNC Control Heidenhain 4290 TP Turning diameter 210 mm Turning length 305 mm Reiststock revolver 12 driven tools Conveyor Bar loading magazine Max travel plan 160 mm Max travel length 350 mm Spindle speeds up to 5000 rpm 2 simultaneous axes with C axis 1 controlled spindle 12 driven tools Collet pliers with hydr. Hollow clamping device up to 43 mm Workpiece pick-up device up to 56 mm very many tools

TECHNICAL DATA: Working width mm: 230 Planing height mm: 120 Infeed table length mm: 3500 Number of spindles: 6 Spindle configuration: 1 B: 5,5 KW 2 R: 7,5 KW 3 L: 7,5 KW 4 T: 7,5 KW 5 B: 5,5 KW 6 T: 5,5 KW Spindle diameter mm: 40 Feedrate m/min: 6-36 Rotation speed max rpm: 6.000 Soundproofing cabin: Yes Feeding magazine Weinig - PHV - 2004

CNC 5 Axis Machining Center Manufacturer Lid Maho Type DMU50 Built in 2008 Control Siemens 840D solutionline Shop Mill Speed 10000 umin Rapid xyZ 24m/min Swing round table with digital drives - A and B axis Tool magazine: 16 places Switch-on hours: 17920 Spindle hours: 7857 Machine is in a used very good condition New spindle 2 years ago.

PA 21/3 High-performance brochure inserts for pre-folded brochures/package inserts Technical features: -Drive on the right -Solid construction -Low-noise drive - without gears -Modular system - Highest performance through the use of double curve, crank drive and electronically controlled stepper -Compulsory handover Sizes: -Inlet width max. 210 mm min. 60 mm -Inlet length max. 105 mm min. 15 mm Paper weight: -Recommended paper thickness 45 - 100 g/sqm Achievement: -Depending on paper quality and fold up to 400 rpm. Drive: -via chain Mass and weight at PA21/3: 1600 x 640 x 500 mm (length x width x height) Weight: 84 kg Compressed air connection for solenoid valve vacuum control 6 bar, vacuum connection: 0.6 bar, compressed air connection (Festo valve) for pneumat. Swivel actuator 6 bar The PA 21/3 are similar in principle to the PA 21/2, but hav ...

Tube filling and closing machine for metal tubes incl. - Empty tube magazine - Automatic tube orientation - Closing stations for single or double folds - 1 pc. format parts for Tube D.40 - mechanical capacity up to max. 80 tubes / min. Machine has to be refurbished self-directed.

Machine details Bearing number 1105-03199 Machine type Milling machine - Universal Make DECKEL MAHO DMG Type DMU 70eVolution Built in 2001 Control type CNC Warehouse FRANCE Country of origin Germany Delivery time by arrangement Freight base from location Price Technical details x-path 750 mm y-path 600 mm z-way 520 mm Control HEIDENHAIN iTNC 530 Information Milling machine - Universal DECKEL MAHO DMG DMU 70eVolution NC Swivel Round Table (700X500) Spindle -------------------- Spindle speed: 18,000rpm Tool holder: SK40 Tool changer -------------------- Magazine places: 32 Pick up Facilities -------------------- Measuring probe Conveyor 2. Processor card electronic handwheel HR410 Blowing air M25 Rinsing gun

Punching machine Trumpf TruMatic TC3000-1300 FMC Year of construction 2004 87500 hours (03.2021) In this case, the configuration : TruMatic TC3000-1300 FMC Year of construction 2004 Working range : 2550 x 1280 mm Standard: • Sturdy C-frame • Coordinate guidance with integrated linear magazine, 21 seats for tools and clamps • 2 clamps • Drives: Maintenance-free digital three-phase servo motors • Punching head: hydraulic system with closed control loop, hydraulic mono tool holder, 360° rotation for all Tools, automatic tool length compensation, programmable scraper movement • Programmable hold-down • Tool spray lubrication • Punch butt suction • Partial slide 500 x 500 mm • Control Bosch PNC-P, activity-oriented user interface, Online Help, Diagnostics, 3.5" Floppy Drive, RJ45 Network Connection • Graphics programming ToPs 2000 • ToP ...

Mikron VCP 800 2007 Built in 2007 Control Heidenhain iTNC 530 Travel X-800mm , Y-650mm , Z-500mm Working spindle: Spindle speed max. 12000rpm. Tool magazine: Number of tool slots 36 Machine table: Clamping area 800 x 650mm Accessories: Inner coolant supply - Belt filter system 20Bar Conveyor

Control Siemens 840 D Travel X/Y/Z 1800/425/400 mm Tool magazine for 36 Wkz. SK40 Speed 5,000 rpm Clamping area 2560x450 mm Conveyor

1 aseptically filling Elo-Pak line suitable for ESL milk and fruit juice Int. Designation: new hall composed of: a.) 1 aseptically filling Elo-Pak filling machine Int. No. II 103 built by Fa: Shikoku Type: U-980 A Serial No. 455 Year of construction 2007 with 3 format options, 0.33, 0.5 and 1.0 l Output: 11,000 U/h for fruit juice in use in operation until the end of January 2019. The following annexes to the Elopak line are: 3 rows of individual packaging transport lanes from polycetting, length to Meuerer carton packing system approx. 23 m with curves 3 Elopak ceiling stackers Year of construction 2004; with screw cap magazine with Yet stream transport railways into the 3 lid storage containers 1 carton pack vending machine for 6 units in the box, partially open at the top Type: Ba-6-30; Serial No. 50325-210 Manufacturer: Meurer Year of construc ...

TECHNICAL DATA: Working width mm: 230 Planing height mm: 150 Infeed table length mm: 2000 Feedrate m/min: 6-24 Rotation speed max rpm: 6000 Number of spindles: 5 Spindle configuration: 01 - Planer wave - 7,5 HP 01 - Right spindles - 10 HP 01 - Spindles left 01 - Spindles top - 10 HP 01 - Bottom spindles - 10 HP Total connection HP: 42,75 Weight Kg: 2400 Feeding magazine

DECKEL MAHO DMU 100 T YEAR OF CONSTRUCTION: 2001 - Number of axes: 5 ( simultaneous) milling spindle - Tool holder: SK40 - Spindle drive power: 15 [kW] - Spindle speed: 20 - 12,000 [up] LINEAR ACHSEN - Travel X/Y/Z axes: 1,060 x 710 x 710 [mm] - Rapid speed (X/Y/Z) : 30,000 [mm/min] - Feed speed (X/Y/Z) : 20 - 15,000 [mm/min] SCHWENKACHSE A : SCHWENKKOPF - Travel: 90 [degrees](+/-) - Minimum resolution: 0.001 [degree] SCHWENKACHSE B : NC ROUND TABLE x 800 [mm] - Travel: 360 [degrees](+/-) - Minimum resolution: 0.001 [degree] WERKZEUGWECHSLER - Number of tools in the magazine: 32 ( 2x 16 places) table - Table size: 1500 x 795 [mm] - Loading table max. : 500 [kg]

955LE CNC tube bending machine The machine was never working – only a few samples at the beginning. The year of production is 2015. Price +/ - 200.000,-- EUR (EXW). (Price of this NEW machine is now more than 300.000,-- EUR) alternative: another Type BMR 65 The package includes the bending machine, a KUKA robot, a pipe magazine, a material chute and a safety fence. Attached I am sending you some photos, including some from the last inspections, which describe the current status. You are welcome to visit the equipment on site.

Circular automatic saw make FORTE type FKA 45Built in 1970Saw blade dimensions: 225 x 32 x 2 mmCutting performance in non-ferrous metal: 60 mmCutting performance in steel: 45 mmSection length automatically up to: 200 mmCutting speeds: 35 - 900 m / minFeed rate hydraulic: 300/600 mm / sDrive power: 4/5 kWDimensions L x W x H: 2700 x 700 x 1250 mmWeight approx: 1033 kgWith- Bar magazine for steel and non-ferrous metalsExclusively non-ferrous metal has been produced on the machine!used, from an operating resolution, despite the year of constructionin very good conditionPrice on request.Delivery: ex warehouse or location free loading truck.Payment: net at takeover or by appointment.Technical data are not binding. Errors excepted.We would be pleased, if you like our offer and are always available for your queries.Best regardsM. WaldeckWAHO Machine Tools

Description On the accumulation cycle conveyor with 4 stations, parcels, newspaper, magazine and similar stacked print products are dammed up if required and clocked in with a time delay after release. Advantage: The recessed grip between the belts allows manual removal of stacks. – Transport speed infinitely variable via frequency converter – unpackaged products 30m/min and packaged products 50m/min. – Length 4x 50cm – Nominal diameter 400 mm – Recessed grip 85mm wide and 25 mm deep – Working height 850mm +/- 50 mm – with cycle control Year of construction 2003 (OVP unused)

Manufacturer KEKEISEN Type UBF-D 7000 / 23 Year of construction 2013 Control iTNC 530 Heidenhain - 2 pallets, can be used individually or coupled. - Universal milling head automatically swivelling A: +/-90° / B: +/-90° - 6 axes - incl. NC rotary table 1,250 x 1,250 mm (fibro) - Operating hours: approx. 17,800 h - Current on / approx. 5,700 h program run x-travel 7,000 mm y-travel 1,200 mm z-travel 2,300 mm Speed range - main spindle 20 - 6,000 min/-1 Drive power - main spindle 30 kW Gear stages 2 Transmission stage 1 20 - 1.250 min/-1 Gearbox stage 2 1,250 - 6,000 min/-1 Tool holder SK 50 Swivel A+B: +/-90° Division 1 ° Workbench: Table clamping surface 7,000 x 840 mm Pallet 1: 2,500 x 840 mm Pallet 2: 3,300 x 840 mm table load 7,000 kg Number of T-slots 9 Tool magazine: Number of tool positions 60 ...

Inv. Num: 5407 Type: 8000 Series Producer: MultiCam Generated: 2013 Parameters: Working table length: 4293 mm Working table width: 2200 mm Number of synchronized axes: 5 pieces Tool magazine: 12 pieces Maximum distance between the spindle and the table: 24000 mm Max workpiece dimensions: 2600x2050x800 mm 2020: GO at the spindle Vacuum table with grid Electric HSD spindle head

Technical data: CNC Heidenhain 530 TABLE: Table dimensions: mm 1.600 x 1.250 Table rotation: continuous Capacity: kg 6.000 WORKING CAPACITY: Longitudinal travel/X-axis: mm 3.000 Transverse stroke/Y axis: mm 1.250 Vertical travel/Z axis: mm 1.600 Luge stroke/W axis: mm 650 MANDREL: Spindle connection: ISO 50 Barrel diameter: mm 130 Rotation speed: 2,000 rpm Motor power: kW 22 TOOL MAGAZINE: Tool stations: Nr. 60 GENERAL: Overall dimensions: mm 7.700 x 5.500 x 4.600 Machine weight: kg 33.000 Machine complete with: High pressure through the spindle Blowing air through the spindle Remote electronic handwheel Heidenhain optical lines Instruction manuals NB: The aforementioned technical data, collected from the technical data sheet of the manufacturer, are to be considered non-binding and subject to change without notice.

One-sided edge gluing machine in right version for hot melt adhesive gluing. equipment: - Glued part for hot melt adhesive granules - Autom. Edge magazine with roller plate - Pre-cap scissors - Pressure zone with hooded pressure roller and 2 trailing rollers - centrally adjustable upper pressure - Cap unit 2 x 0.27 kW - Büdig milling unit 2 x 0.35 kW - Drawing blade unit for PVC edges (chamfers/rounds of pre-milled PVC edges) - Swib ledunit 2 x 0.18 kW specifications: Edge thickness 0.4 - 5 mm Roller separation max. 3 x 30 mm (PVC) or 0.8 x 60 mm Workpiece thickness 10 - 50 mm Workpiece width min. 70 mm Workpiece length min. 160 mm Feed 11 m/min. Electric400 Volt - 3 Ph. - 50 Hz Connection value approx. 5 kW Pneumatic connection 6 bar Total length 4000 mm Weight approx. 1050 kg

Machine details Bearing number 1105-03282 Machine type Machining Center - Vertical Make FAMUP Type MCX 450 Built in 1997 Control type CNC Control FANUC OMC Warehouse FRANCE Country of origin Italy Delivery time immediately Freight base EX WORK Technical details x-path 450 mm y-path 300 mm z-way 400 mm Control FANUC OMC Spindle speed 8000 rpm Spindle motor 5 kW Rapids x/y/z 30 mm/min Table size 600 x 300 mm Tool change time 0.9 sec Tool magazine: 16 FACH SK 30 Information WITH CONTROL FANUC OMC 8000 RPM 5 KW 2.5 TONS MASSE 2 X 2.25 X 2.3 16 FACH MAGAZIN SK 30

- Cutting speed: 6 - 30 m/min - Saw blade dimensions: 400 (425) x 50 x 5 mm - Cutting range 45° flat: 180 x 40 mm - Cutting range 90° flat: 240 x 70 mm - Cutting range 90° round: 140 mm - Cutting range 90° square: 130 mm - Miter cut: infinitely variable 60 -/+ degrees - Saw blade feed speed: 0 - 1,200 mm/min - Minimum quantity lubricating system: PPS 401 115326 - Autom. Flat magazine FMA for rods: 1500 - 7000 mm - Control: Kaltenbach MULTI-COM - Chip conveyor - Total power: 5.5 kW - Machine weight: 4500 kg - Dimensions (W x D x H): 9.45 x 2.59 x 2.1 m - Power-on hours: 17290 h - Condition: very good details fully automatic universal saw, workpiece stop for inclined cuts to the left and right, work space lighting, section gripper with autom. Adjustment of the front gripper jaw, sorting device with drive, sorting of good parts, very well maintained system acce ...

5 axis CNC – portal profile machining center for all materials - aluminum - steel - stainless steel - plastics - non-ferrous metals. Drilling + tapping, flow drilling, milling + thread milling, as well as sawing at free angles – for example, steel profile saws up to 6 mm wall thickness Largest saw blade diameter 500 mm Largest machining length 7,000 mm Largest workpiece cross-section 650 x H 300 mm Working range in five-axis operation 6,400 mm x 480 x H 300 mm Spindle drive power 17 kW at 100% ED Milling spindle speeds up to 24,000 rpm Moving tool magazine for 12 tools Tool holder HSK 63 Rapid speeds up to 100 m/min / acceleration 2.5 G Space requirement (including control cabinet and control panel) approx. 9 m x 2.5 m x H 2.6 m Weight approx. 5,000 kg. equipment: - OSAI® CNC control - YASKAWA® feed drives and feed controllers - HITECO® milling spindle w ...

This palletising system processes with container transport, turning station, grouping station, automatic liner magazine, Motoman robot EPL, 250KG Lifting power Designation: Palletizer Manufacturer: Profipack, Robopack, Logopack. Year of Construction: 2007 very few operating hours Capacity: about 160-200 layers/h Availability: from now on

Labeler / Labeling Machine Wet glue labelling machine Langguth E 32 / R-315 Container size 2 - 30 l Year of construction 2008 incl. glue pump swing magazine with single-stroke and handle guide very good ready-to-use condition, directly from production!

5 axis CNC – portal profile machining center for all materials - aluminum - steel - stainless steel - plastics - non-ferrous metals. Drilling + tapping, flow drilling, milling + thread milling, as well as sawing at free angles – for example, steel profile saws up to 6 mm wall thickness Largest saw blade diameter 500 mm Largest machining length 7,000 mm Largest workpiece cross-section 650 x H 300 mm Working range in five-axis operation 6,400 mm x 480 x H 300 mm Spindle drive power 17 kW at 100% ED Milling spindle speeds up to 24,000 rpm Moving tool magazine for 12 tools Tool holder HSK 63 Rapid speeds up to 100 m/min / acceleration 2.5 G Space requirement (including control cabinet and control panel) approx. 9 m x 2.5 m x H 2.6 m Weight approx. 5,000 kg. equipment: - OSAI® CNC control - YASKAWA® feed drives and feed controllers - HITECO® milling spindle wit ...

HARTFORD LG1000 LG1000 F1 series TABLE Working area mm 1150x510 Table with T-slots mm 18x3x160 Table capacity kg 700 SHIFTS AXIS X mm 1000 Y AXIS mm 510 AXIS Z mm 630 Spindle axis distance to table surface mm 100 ~ 730 Distance of the table axis tip from the column mm 562.5 POSITIONING ACCURACY Positioning accuracy (JIS B6338) mm ± 0.008 Repeatability (JIS B6338) mm ± 0.002 FEEDS Working feed m / min 12 Rapid traverse X / Y / Z m / min 30/30/24 (optional 40/40/32) SPINDLE # 40BT Spindle Nose Spindle speed (belt gear) rpm 8000 (opt. 10000/12000) Spindle speed (DDS) rpm 10000 (opt. 12000/15000) Spindle drive (30 min) 11 kW, belt drive AUTOMATIC TOOL CHANGER Tool magazine capacity A: 24 (opt S: 20) Max. tool weight kg 7 Max. tool dimensions (diameter x length) mm ø75 x 300L (option S: ø90 x 250L) Type of hand ...

Capsule feeder,stainless steel,elevator with out sorting and capsule magazine.

Capsule feeder,stainless steel,elevator with out sorting and capsule magazine.

max. workpiece length: 5150 mm profile spindle: 1 Stück main drive: 16 kW Control: Beckhoff CNC Number of axles: 5 St. CNC machining center Masterwood Project 385 WL, NEUMASCHINE The all-rounder for Windows, round arches and doors interior Post and beam 5-axis machining of all kinds Detailed description in the adjacent PDF file! HIGHLIGHTS: - Working range: X = 5150 mm, Y = 1500 mm, Z = 200 mm - 1 pc. 5-axis high-performance spindle, 16 kW, double bearing with HSK 63 F recording - fixed drill head with 19 spindles with 7 individually retrievable vertical spindles X-direction with 6 individually retrievable vertical spindles Y-direction with 2 double horizontal spindles X-direction and 1 double horizontal boring spindle in the Y direction Saw unit integrated in drill head - Carousel tool changer with 22 places and 102 mm grid spacing - Carousel tool changer with 16 places and 102 mm grid ...

:::SPECIFICATIONS::: CNC Model: Okuma OSP CNC version: U100 - L Spindle nose: ASA 6 Spindle power: 22Kw Main spindle revolutions: 5000 Turning diameter: 630mm Bar clearance: 51mm Turning length: 1170mm Number of tools: 44 Tool connection: HSK 63 Spindle power: 7,7Kw Number of spindle revolutions: 6000 X Axis Stroke: 475mm Y axis stroke: + - 80mm Z Axis Stroke: 1155mm Swivel B-axis travel: 0.001degree Rapid feeds linear axes X Y Z: 40m/min High cooling pressure: yes Pressure value: 120bar System with external tank with filter: yes Number of Tool Turrets: 1 Number of tool places before turret: 12 First turret tool attachment type: VDI Counter-spindle: yes Number of counter-spindle revolutions: 6000 Counterspindle power: 22Kw Bar clearance: 32mm Z stroke counterspindle : 1180mm Model and brand bar magazin ...

x-travel: 750 mm y-travel: 560 mm z-travel: 600 mm Control: HEIDENHAIN iTNC 530 total power requirement: 70 kW weight of the machine ca.: 11.000 kg dimensions of the machine ca.: m D E C K E L M A H O (Germany) Vertical CNC Machining Centre with high speed linear drives in 3 Axis and in double column design for high precision work Model DMC 75 V LINEAR Year 2005 _______________________________________________________ Working range: Longitudinal stroke X Axis 750 mm Vertical stroke Z Axis 600 mm Cross stroke Y Axis 560 mm Table clamping size 950 x 650 mm Max. Table load 1.000 kg Max. height of workpiece 600 mm Tool holder Cone HSK 63 Spindle (KESSLER) speeds 18,000 rpm Torque, max. 86/1 ...

x-travel: 11200 mm y-travel: 3130 mm z-travel: 1000 mm Control: NUM 1060 W A-axis: +- 120 ° c-axis: +215/-210 ° spindle motor: 15 kW spindle taper: HSK-F63 turning speeds: 24000 U/min table width: 1500 mm table length: 9400 oder 2x3000 mm total power requirement: kW weight of the machine ca.: 20 t dimensions of the machine ca.: 14,6x5,0x4,225 m Use: e.g. for processing aluminum panels, drilling profiles, advertising (signs milling, etc.), mold construction (prototypes) and processing of light steel frames / -beams using HSC milling The vertically arranged high-frequency milling spindle for automatic Tool change is mounted in a fork head on the Z-axis plate. The Spindle can be moved with the fork head in 2 NC axes, in the A axis and the C-axis. The vertical movement is carried out via the Z-axis. Liquid cooling via a cooling unit. Tool magazine: moving plate changer in the potal, outsid ...

x-travel: 2600 mm y-travel: 1600 mm z-travel: 1700 mm Control: Fanuc 16 MB total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: 42 x 18 m The system requires a space of approx. 42 x 18 m It is designed for fully automatic operation in 3 shifts. Components with tolerances of

No. 5011: 1 gebr. Set of magazine pockets / tool holders SK 40 Fabr. UNISIGN, type suitable for Univers 4, with 7 base holders + 10 storage pockets

internal diameter: 2 - 40 mm grinding depth: - mm swing diameter: 285 mm total power requirement: 5,5 kW weight of the machine ca.: 1,5 t dimensions of the machine ca.: m Max. Distance chuck flange - wheelhead 390 mm Accessories: Grinding spindle, make PRECISE 20.000 - 66.000 rpm, power 1.3 kW Grinding spindle, make PRECISE 60.000 - 120.000 rpm, power 0.23 kW magazine The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

TOP CONDITION - OVERHAULED IN 2022 ! Year of construction: 2013 Panel format: 3000 x 1500 x 100mm Power: 2500W Control: Mazatrol Preview 2 with LAN / USB / Touch incl. cooler incl. programming software incl. training incl. commissioning Hbfbummie incl. quick puncture incl. changing table + ball roller table incl. 2-fold cutting head change magazine incl. 2 cutting heads incl. automatic shower changer incl. plasma detection incl. piercing sensor FE: up to 20mm VA: up to 12mm oxide-free Wood + acrylic cuttable designed for high-pressure cutting up to 20bar no foundation needed! Always regularly serviced The machine can be viewed and tested completely overhauled under power in our hall. Optional automatic loading and unloading by Mazak CELL510 INCLUDING delivery / warranty / commissioning / training (within EU)

diameter: 15 mm length: 800 mm = bar loading and de-loading magazine for bars up to 15 mmø, bar length 800 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 630 mm y-travel: 700 mm z-travel: 630 mm Control: Meldas M650 tool adaptor: HSK-A63 Table dimensions: 450x450 mm Table load: 400 kg number of spindle speeds: 300 - 20.000 min-1 total power requirement: 30 kW weight of the machine ca.: t dimensions of the machine ca.: m FEED RATE Rapid feed rate X,Y 120 m/min Rapid feed rate Z 60 m/min Rapid feed rate B 120 m/min Cutting feed rate X,Y,Z 0,1 – 60 m/min SPINDLE RPM spindle 300 – 20.000 min-1 Spindle taper HSK-A63 Coolant Through spindle ATC Tool holder Special HSK-A63 2 Face contact tool Tool magazine storage 40 pcs Tool change time 2,5 sec. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Inv. Num. : 5552 Type: BMC 24 SSM Producer: HURCO Created: 2004 Parameters: Control system: ULTIMAX Work table length: 760 mm Work table width: 400 mm Spindle drive power: 7.5 kW Tool magazine: 24 pieces Speed: 80-8000 1/min Travel X-axis: 610 mm Travel Y-axis: 405 mm Travel Z-axis: 505 mm Cone: SK40 Machine height: 2650 mm Machine length: 2140 mm Machine width: 2100 mm Machine weight: 4200 kg

CNC,5 Axis JOBS,Linx Compact + Heidenhain TNC 530 HSCI Year of construction: 2013 X-2000 Speed up to 60m/min , Force (N) 9000 Acceleration 4,5 m/sec2 Y-3000 Speed up to 60m/min , Force (N) 9000 Acceleration 6.0 m/sec2 Z-1250 Speed up to 60m/min , Force (N) 9000 acceleration 7,2 m/sec2 C - +/- 200 straight , torque 1200Nm ,max. torque with clamped axle 5000 Nm A - -120/+95 Torque 1200Nm ,Maximum torque with clamped axis 5000NM Speed: 15,000 rpm Cone according to HSK-A-100 Weight : 70000 kg Tool magazine type chain 32 tool positions, Max tool weight 15kg for more info, please call or write e-mail. Machine is immediately available and if you are seriously interested, you can inspect it under power An invoice with VAT will be issued

Used curd production line from OBRAM Olsztyn. Year of manufacture 2005. Line capacity 1400 kg/h. Packing machine: Multivac R 240 with BIZERBA CWM 6000 checkweigher. 2-track CIP washing station. Line composition: - UFO - Column forming device UF21 - Curd multiforms - 42 nests - Curd presses - 3 pieces - Pressing covers for curd presses - 3 pieces - Multiform swivels - 2 pieces - Multiform emptier - Multiform washer - Multiform magazine for 30 pieces - Multiform transport system - Tray filler - Trays for transporting cottage cheese - Trolleys for transporting trays - Multivac R 240 packaging machine - hard bottom film, soft top film, packaging with the possibility of multiple opening - Automatic constant weight control device BIZERBA CWM 6000 - 2-track CIP station WAB-30/2, OBRAM, 3 tanks with a capacity of 3,000 L

- X: 420 mm - Y: 330 mm - Z: 400 mm - Table size: 850 x 325 mm - Speed range: 0 - 5000 rpm - Spindle mount: SK 40 - Rapid traverse: 12 m/min - WZ changer: 12-speed - Tool holder: 40 SK - Tool weight max.: 5 kg - Tool length max.: 220 mm - Tool Ø max.: 63 mm - Control: Sinumerik 810 M - Switch-on hours: 40484 h - Total power: 15 kW - Machine weight: 3200 kg - Dimensions (W x D x H): 2.4 x 2.3 x 2.45 m - Condition: good, ready for immediate use Details one tool station is currently defective, nice compact machine, can be used immediately Accessories HILMA SM 125 machine vice, various recordings in the magazine, documentation, machine feet

x-travel: 600 mm y-travel: 500 mm z-travel: 500 mm total power requirement: 7,5 kW weight of the machine ca.: 5,5 t Working range: Longitudinal stroke X axis 600 mm Vertical stroke Y axis 500 mm Cross stroke Z axis 500 mm Clamping size of angle table 530 x 900 mm Max. weight of workpiece on table 450 kg Distance from table to vertical spindle, min./max. 120 / 620 mm Distance from table to horizontal spindle, min./max. 156 / 656 mm Tool taper SK 40 Spindle speeds 0 - 6,300 rpm Feeds X, Y and Z Axes, max. 2 - 10,000 mm/min Quick feed X, Y and Z Axes 10,000 mm/min Spindle drive 8 kW Total electrical load, approx. 15 kW - 400 V - 50 Hz Weight, approx. 5,500 kg Accessories / Special Features DIALOG 11 CNC Control in 4 axes with all the usual options, cycles, and subprograms. Graphic display and electronic hand wheel. Vertical milling head can be pushed up manually so that the  ...

x-travel: 710 mm y-travel: 500 mm z-travel: 500 mm total power requirement: 24 kW weight of the machine ca.: 7 t dimensions of the machine ca.: m M I K R O N (Switzerland) CNC Controlled Universal Milling Machine with Tool Changer Model WF 54 VH CNC Year 1991 Serial No. 5110302 ________________________________________________________ Table travel, X axis, longitudinal 710 mm Table travel, Z axis, vertical 500 mm Milling head travel, Y axis, cross 500 mm Mounting height below vertical spindle, approx. 600 mm NC rotary table 800 mm Resolution of rotary table, C axis 0.001 ° Spindle taper SK 40 Spindle speeds, 3 steps, infinitely variable 10 - 6,300 rpm Feeds, XYZ 2 - 4,000 mm/min Quickfeed, XY 10,000 mm/min Quickfeed, Z 8,000 mm/min Spindle drive, approx. 15 kW Total electrical load, approx. 24 kW - 380 V - 50 Hz Weight, approx. 7,000 kg Accessories / Special Feat ...

x-travel: 800 mm y-travel: 630 mm z-travel: 560 mm total power requirement: 60 kW weight of the machine ca.: 12.5 t dimensions of the machine ca.: m H E L L E R (Germany) 5 Axis - CNC Controlled Horizontal Machining Centre Model FST- MC 160 / 800 / E Year 1998 Only approx. 500 hours in operation _______________________________________________________ Working range: Longitudinal stroke X axis 800 mm Vertical stroke Y axis 630 mm Cross stroke Z axis 560 mm NC rotary table Tilting A axis 180 ° Turning B axis 360 ° Size of pallet, approx. 250 x 620 mm Tool holder HSK 63A Spindle speeds, infinitely variable 63 - 20,000 rpm Feeds / quick feeds XYZ 1 - 70,000 mm/min Spindle drive 24 kW Total electrical load, approx. 60 kW - 400 V - 50 Hz Weight, approx. 12,500 kg Accessories / Special Features 5-Axis SIEMENS CNC Path Control, Mode ...

KENYO VS80160 5-axis Machining center with CE Producer: Nanjing Kenyo Precision Machine Manufacture Co., Ltd YOM 2015 Simultaneously 5 axes Total Installed Capacity 22.4 kW 5-Axis vertical Milling machine for blanks up to 1000-1500kg Stroke X/Y/Z- 1600/800/800 mm Working table size 800x1800 mm Diameter of NC swivel table axle C 630 mm Rotating mass clamping force 4000 Nm Spindle clamping force: ≥ 2000 Nm Maximum mass load 2000 kg Spindle diameter 170 mm Spindle rotation angle- ± 110 Degree Tool Store Type BT40 ISO Tool magazine 24 pcs Maximum spindle rotation speed 10.000 rpm Spindle power 15 kW Ball-Screw pair HIWIN Spindle Hesheng Ball Bearings NSK Positioning accuracy ≤ X/Y/Z: 0.015 mm, C: 0.002 degree, B: 0.002 degree Repeat accuracy ≤ X/Y/Z- 0.01 mm, C:0.0015 Degree, B:0.0015 Degree Quick move: ≥ 10000 mm/min Milling speed: ≥ 1 to 8000 mm/min OC ...

diameter: 0 mm workpiece length: 1000 mm work piece width: 875 mm total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m CNC deburring/brushing cell, tool magazine, SIEMENS 510, 5 axes CNC Controlled Flexible Brushing and Deburring Cell The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Table length: 0 mm Table width: 0 mm Longitudinal X: 0 mm Cross Y: 0 mm Vertical Z: 0 mm Positions ATC: 0   Positions APC: 0   CNC Brand: 0 CNC Model: 0 Control: MAZATROL M32 Technical data Number of axis total: 3 Table length: 1740 mm Table width: 750 mm Table load max.: 2500 kg Longitudinal travel (X-axis): 1500 mm Transversal travel (y axis): 800 mm Vertical travel (z axis): 508 mm Tool magazine number of tools: 30 Tool diameter max.: 125 mm Diameter with free adjacent pockets: 190 mm Tool lenght: 300 mm Max. tool-weight: 15 kg Spindle nose: ISO: 50 Distance spindle nose to table: 200 - 708 mm Spindle speeds: stepless from: 22 rpm up to: 3150 rpm Rapid traverse: long.: 24 m/min Rapid traverse: transversal: 24 m/min Rapid traverse: vertical: 18 m/min Voltage 50 Hz 3x: 380 Volt Spindle motor: 26 / 22 kW Total power required: 52.3 kVA Machine´s weight about: 11000 kg Overall di ...

Compressor Bitzer Type: S6H-20.2Y Volume: 73.6 m3/h Cooling capacity for R404A: 32 kW at -25°C/40°C, 20 kW at -40°C/40°C, 13 kW at -50°C/40°C Bottle capacity: 73 l Dimensions: 1330x1150x1300 mm Items in magazine: 1 Condition: Used in good condition In set with: Cool Gea Cuba Type: SGKE 50-F61 (x2) Cooling capacity for one: 9,3 kW at DT8, 7,5 kW at DT7 Surface: 39 m2 Air flow: 6300 m3/h Fin spinning: 10 mm Electric heaters Fans: 1x500 mm Dimensions: 1680x800x750 mm Refrigerant: Freon Volume: 13 l Quantity in stock: 2 Condition: Used in good condition Price on request, We have many other equipment : Bitzer, Copeland, Frascold, Lunite, Kueba, Guentner, Eco, Alfa-Laval, Goedhart, Helpman

Table length: 0 mm Table width: 0 mm Longitudinal X: 0 mm Cross Y: 0 mm Vertical Z: 0 mm Positions ATC: 0   Number of pallets: 0   CNC Brand: 0 CNC Model: 0 Control: FANUC Series 18i-MB Technical data Number of axis total: 3 Table length: 1700 mm Table width: 810 mm Number of T-channels: 5 T-channel width: 22 mm Distance of the T-slots: 160 mm Longitudinal travel (X-axis): 1600 mm Transversal travel (y axis): 815 mm Vertical travel (z axis): 815 mm Distance from vertical spindle to table: 1035 mm Spindle speeds: number (steps) from: 30 rpm up to: 4500 rpm Tool magazine number of tools: 32 Spindle nose: ISO: 50 Tool diameter: 110 mm Tool lenght: 350 mm Max. tool-weight: 15 kg Feeds (X, Y, Z): 1 - 10000 mm/min Rapid traverse:: 15 m/min Milling spindle motor: 18.5 kW Machine´s weight about: 13300 kg Overall dimensions machine: Length: 4488 mm Width: 3448 mm Height: 3250 mm Various acce ...
