121,929 used machines on RESALE, but how to find them? Machine Search
maximum number of results exceeded > 1000
please refine your search
used
The horizontal CNC machining center with a magazine for 60 tools, model CW-1000, is designed for complex boring and milling. It can handle parts (including fixtures) with maximum dimensions (length x width x height) 1200x1000x1000. Contents of delivery: - bed, column, frame - protection along the X, Y, Z axes - tool magazine manipulator type for 60 tools - rotary table - workpiece changer (2 pallets) - ball screws and rolling guides on the X, Y, Z axes - guides protection - spindle 4200 rpm, power 30 kW, SK50 - coolant supply through the spindle, pressure up to 50 bar, replaceable filters up to 25 microns - reducer - motors on the X, Y, Z, B axes, manufactured by Siemens (Germany) - main drive and feed drive: digital drives of the âSINAMICS S120â series - automatic lubrication system - hydraulic system - belt chip conveyor with coolant pump - lighting of the c ...
used
- CNC control: HEIDENHAIN 530 - table dimensions: 1200 x 450 mm - travel in the X axis: 1020 mm - travel in the Y axis: 510 mm - travel in the Z axis: 510 mm - maximum table load: 600 kg - T-slots: 5 x 18 x 75 mm Spindle of the DUGARD EAGLE 1000 CNC milling machine: - distance from the spindle face to the table: 150-660 mm - overhang (distance from the center of the spindle to the body): 550 mm - spindle taper: 7/24 (BT-40) - spindle speed: 80-8000 rpm feeds : - X, Y, Z axis accelerated feeds: 30/30/18 m/min. - working feeds: 1-7600 mm / min. Tool magazine: - tool magazine: 20 (carousel type) - tool holder: BT-40 - maximum tool diameter: 89 mm - maximum tool weight: 7 kg Engine : - spindle motor (30 min.): 10 HP (7.5 kW) - drive motor (X, Y, Z): 1.4 HP (1.0 kW) - coolant pump: 0.38 kW General : - required power of the DUGARD EAGLE 1000 machine: 15 kVA ...
used
Schaudt PS51 Cnc external grinding machine with Knoll vacuum filter, Promot Cnc Cartesian robot, Donaldson vacuum filter and Marposs unit. à 360 max workable x 600 mm, max weight 300 kg With Promot CNC magazine Length 375 mm, weight 5 + 5 kg Grinding wheel à 762 mm, grinding wheel pack weight 500 kg, max width 125 mm, grinding wheel pack up to 300 mm with crankcase modification, programmable rotation speed 45 - 60 m/sec - Grinding wheel motor power 22 kW Dressing system for shaped rollers Workpiece rotation 1 - 1000 rpm Complete with Promot ELP A0029904 magazine - 2000 Cnc Siemens Weight 10 t grinding only. Accessories: Knoll 2000/MW475 Belt Filter Series No. 214472 Ref. 384014 from 2003 Donaldson DMG D1 57171684 vacuum cleaner from 2007 Two Marposs units Fully functional machine, both Shaudt and Promot can do installation, language change, staff training
used
OTT Tornado - TOP Control - via a 15-inch colour touch monitor for full automation and maximum ease of use CM-CombiMelt gluing system Suitable for the processing of EVA and PUR hot melt adhesives as well as all common cleaning granules Joining machining part for attaching chipboard Automatic Roller Magazine Automatic Edge Magazine Double cross-cuter, automatic swivel 0° / 3° Flush milling machine - for flush milling - 12mm Fine milling machine RADIUS - Radius milling - Profile knife R2 - R5 Automated Copy Milling - Corner Rounds Scraper Device - Radius Surface Scraper Device Lubricant Spray Device - PU Cleaning set with fine buffing device very stable workpiece support with roller conveyors - FRONT with scissor pull-out Complete tooling included First delivery 2012 Machine is WORKSHOP OVERHAULED in TOP CONDITION
used
Key data: 650 mm, 600 mm, 500 mm
Manufacturer : Hermle Model: C 30 U Number of machines : 2 Control : Heidenhain i TNC 530 Year of construction : 2008 / 2009 Switch-on hours : approx. 115000 h Spindle running time : 24400 h Location : Germany until week 49 / 2023 then from warehouse Sweden Specifications Max. spindle speed: 28000 rpm Spindle mount : HSK A 63 Number of synchronously controlled axes : 5 Travel X-axis : 650 mm Y-axis : 600 mm Z-axis: 500 mm A-axis : +/- 115 º MM B-axis : 360° NC serving table diam. 280 mm Tool Locations Pick Up: 32 Positions Additional magazine: 157 lots Total tool slots : 189 lots Loading and unloading area: 8 lots Tool length max.: 300 mm Tool diameter max. 125 mm Tool weight max.: 8 kg Dimensions Length : 3154 MM Width : 2354 MM Height 2892 MM Machine weight : 10500 KG Other equipment features - max. coolant pressure 80 bar possible ( IKZ ...
used
Manufacturer ZAYER Model TEBAS-5000 Year 2013 CNC HEIDENHAIN iTNC-530 HSCI Table Table Surface 5.200 x 2.200 mm. Max. weight allowed on table 25.000 kg. Max distance from 45º head nose to table in vertical position 1.410 mm. Max distance from 45º head nose to table in horizontal position 1.465 mm. Max distance from direct exit head nose to table in vertical position 1.420 mm. Travels and feeds Longitudinal Traverse (X Axis) 5.000 mm. Transversal Traverse (Y Axis) 3.750 mm. Vertical Traverse (Z Axis) 1.250 mm. Distance between columns 3.000 mm. Rapid Traverse 50.000 mm/min Max. Working Feed 30.000 mm/min Headstocks Universal Auto Indexing Head 45º 0.001º/0.001º Taper DIN 69871 AD 50 Spud ISO 7388-2 B 50 Spindle speed 6.000 rpm Speed ranges 3 Main spindle power 43 kW Direct output head reduction 1-2,29 INCLUDED Taper DIN 69871 AD 50 Spud ISO 7388-2 B 50 S ...
used
DUGARD EAGLE 660 VMC CNC machining centre built in 2007 in Taiwan, is used for precision milling, drilling, threading, boring and reaming of workpieces with rotary tools. The machine, with its extensive machining capabilities, is distinguished by its extremely stable base, which provides rigidity and support for the guideways on which the X,Y,Z axes are guided. To ensure a high level of safety, specially designed sliding guards protect the operator from moving parts, coolant and workpiece fragments. All the processes, from tool selection to the machining cycle, are performed fully automatically by the milling centre. The implemented SIEMENS SINUMERIK 810 D CNC control minimises the operator’s handling of the machine, while the capacious 24-position magazine selects the shortest possible access path to the tool. This solution increases production efficiency while significantly reduci ...
used
Wood Her Tria 120 Full car. Edge magazine Full car. Roller magazine - cross-cut shears Banding - 20 mm CARTRIDGE PU GLUING STATION Flush caps Flush - Chamfer - Radius Milling/Digital - 20 mm Soundproof booth from retirement Machine is WORKSHOP OVERHAULED
used
Key data: 4140 mm, 1570 mm, 200 mm
Features of the mechanical engineering method: Structure - The machine bed is made of an electro-welded steel structure, which is appropriately reinforced at the most stressed points. - The mobile gantry structure is realized with an electro-welded steel structure to minimize deformations due to the bending and torque generated during the use of the work center. Axis Movement - The boom is driven along the X-axis and the Y-axis by means of rack and pinion drive (hardened rack and a precision reduction gearbox with 2 pinions) - Movement of the machining unit in the vertical direction (Z-axis), carried out by means of ball screws with preloaded spindle nut. Guides of the axes - All axes travel on linear guides with recirculating ball sliding shoes. (Protection by sealing lip against dust and dirt) Auxiliary vacuum system - Enables the clamping of workpieces by means of va ...
used
Tool changer chain, chain magazine, tool changing system, tool magazine -Manufacturer: Tool changer from CNC machining center MAHO -for: max. 24 shots -Recording: SK -Dimensions: 1200/410/H480 mm -Town weight: 106 kg
used
HAAS MINI MILL HE CNC machining center built in the USA in 2001 is distinguished by its incredible milling precision and accuracy, making it ideal for a wide range of applications in any production facility. Made from the highest quality raw materials, the stable, compact design with sliding doors effectively dampens the vibrations generated during machining and provides easy access to the work space. The work space is equipped with a T-slot table, a reliable high-speed spindle and a 10-position tool magazine. To minimise the need for the operator to operate the machine, all machining parameters are programmed in the intuitive HAAS CNC control, which fully automatically executes the machining cycles. The HAAS CNC vertical machining center weighs 2200 kg. Technical data of the HAAS MINI MILL HE CNC milling machine - CNC control: HAAS - work table surface area (L x W): 914 x 305 mm ...
used
HAAS MINI MILL HE CNC vertical milling center was built in 2006 in the United States. This compact machine, with its emphasis on high productivity and precision milling, is ideal for any production facility, even during the most intensive challenges. Behind the sliding doors there is a large work space equipped with a T-slot table, a 10-position tool magazine and a reliable high-speed spindle. Machining programmes are created in just a few steps in the intuitive HAAS CNC controller, which performs cycles fully automatically and minimises the operator’s need to operate the machine. The HAAS CNC vertical machining center weighs 2200 kg. Technical data of the HAAS MINI MILL HE CNC milling machine - CNC controller: HAAS - feed rates in the X/Y/Z axis: 406/305/254 mm - work table surface (L x W): 914 x 305 mm - maximum workpiece weight: 227 kg - maximum spindle rotational speed: 600 ...
new
Key data: 500 mm, 400 mm, 300 mm
High Speed Cutting - Special machining center with FANUC® nano-contour technology for the fashion accessories and jewelry industry and similar industrial processes where the greatest possible precision is required, such as dental technology – medical technology – mold making. For the processing of precious metal alloys, as well as aluminium – copper – brass – bronze and similar non-ferrous metals. The raw material to be processed is forged – cast or rolled flat bars up to 150 mm wide and maximum 500 mm long, which are stored in a blank magazine. Automatic loading of flat bars (raw or raw material), material thickness from 1 mm to 15 mm – automatic unloading of finished flat bars. Milling spindle drive power 8 kW Milling spindle speeds up to 36,000 rpm Tool holder HSK40 Tool magazine for 24 pieces of tools - Automatic pneumatic flat bar clamping - Automatic ...
new
High Speed Cutting - Special machining center with FANUC® nano-contour technology for the fashion accessories and jewelry industry and similar industrial processes where the greatest possible precision is required, such as dental technology – medical technology – mold making. For the processing of precious metal alloys, as well as aluminium – copper – brass – bronze and similar non-ferrous metals. The raw material to be processed is forged – cast or rolled flat bars up to 150 mm wide and maximum 500 mm long, which are stored in a blank magazine. Automatic loading of flat bars (raw or raw material), material thickness from 1 mm to 15 mm – automatic unloading of finished flat bars. Milling spindle drive power 8 kW Milling spindle speeds up to 36,000 rpm Tool holder HSK40 Tool magazine for 24 pieces of tools - Automatic pneumatic flat bar clamping - Automatic ...
new
High Speed Cutting - Special machining center with FANUC® nano-contour technology for the fashion accessories and jewelry industry and similar industrial processes where the greatest possible precision is required, such as dental technology – medical technology – mold making. For the processing of precious metal alloys, as well as aluminium – copper – brass – bronze and similar non-ferrous metals. The raw material to be processed is forged – cast or rolled flat bars up to 150 mm wide and maximum 500 mm long, which are stored in a blank magazine. Automatic loading of flat bars (raw or raw material), material thickness from 1 mm to 15 mm – automatic unloading of finished flat bars. Milling spindle drive power 8 kW Milling spindle speeds up to 36,000 rpm Tool holder HSK40 Tool magazine for 24 pieces of tools - Automatic pneumatic flat bar clamping - Automatic ...
GeneralUniversal milling machine, with compound Guideway construction; Control: CELOS with Siemens 840D sl Operate Working area 1Cross450 mmLongitudinal500 mmVertical400 mmTechnical DataType of main driveAC Drive power (100% DC)25 kWDrive power (40% DC)35 kWSpeed range20-18000 rpmSpindle taperHSK-A 63 Clamping SystemHSK-A 63 Feed rate longitudinal/transverse/vertical-30000/-30000/-30000 mm/minRapid traverse longitudinal/transverse/vertical30/30/30 m/minFloor space/WeightDimensions (L x W x H)4,15 x 3,98 x 2,75 mWeight approx.4500 KgSwivel Rotary Table, simultaneousSwivel Rotary Table for simultaneous machining swivel range -5 to +110°, rotary axis 360° including direct measuring system for B- and C-axis and working plane transformation Not available with NC-Divider EA 410!Table surface 630 x 500 mmDistance between T-Slots 63 mmNumber of Slots 7Slot width 14 mmMaximum load (table centre ...
used
DECKEL MAHO DMC 50 V CNC machining center was built in Germany in 1995. The machine distinguished by its robust, stable construction is used in precision face and hole machining using rotary tools. The machine is ideal for use in any production facility thanks to its reliable components, such as the high-performance FRANZ KESSLER DMS100.AL.4.FOM spindle and the 20-position tool magazine with automatic tool changing, which guarantee perfect milling precision and accuracy. The DECKEL MAHO CNC vertical machining center weighs 7000 kg. Technical specifications of the DECKEL MAHO DMC 50 V CNC milling machine - work table dimensions (L x W): 700 x 400 mm - feed rates in the X/Y/Z axis: 500/420/500 mm - speed of feeds in the X/Y/Z axis: 1-2000 mm/min - feed motor power in the X/Y/Z axis: 3.5 kW - maximum workpiece weight: 800 kg - maximum spindle rotational speed: 15000 rpm - maximum ...
used
Tool changer chain, chain magazine, tool changing system, tool magazine -Manufacturer: Mikron, tool changer from CNC machining center Mikron UME 600 -for: max. 22 shots -Intake: SK40 -Dimensions: 1200/1150/H860 mm -Transport weight: 294 kg
used
2006 Mazak FH-6800 Palletech CNC Horizontal Machining Center Pallet Size.. 24.8" x 24.8" TRAVELS X-Axis Travels... 41.3" Y-Axis Travels... 31.5" Z-Axis Travels... 34.7" Distance from Spindle Center to Top of Pallet. 3.9" - 35.4" Distance from Spindle Nose to Pallet Center. 5.9" - 40.6" WORKPIECE SIZE Maximum Table Load... 3,315 lbs. Maximum Workpiece Height. 39.4" Maximum Workpiece Diameter... 41.3" 7,000 RPM Spindle Spindle Horsepower (15 Min/Cont). 40/30 HP Spindle Torque... 868 ft/lbs Obtains Full HP 243 RPM Constant Torque Range 35 - 243 RPM Spindle RPM.. 7,000 Spindle Speed Increment.. 1 RPM Number of Ranges. 4 (2 electric, 2 mechanical - automatically shifted) Tool Clamping Force.. 4,630 ft./lbs. Spindle Cooling System... Spindle Chiller AUTOMATIC TOOL CHANGER Magazine Capacity 120 Tool-to-Tool Time 1.8 seconds Chip-to-Chip Time (Approx.).. 5 seconds ...
used
Overview The palletizer was manufactured by the German company Krones in 2008 and was until recently part of a PET bottling line at a large German soft drinks manufacturer. The palletizer is now being released as the owner is investing in a completely new line. Technical details/ scope Output: approx. 170 layers/h (line output: 36,000 bottles/h for 0.5 l and 26,000 bottles/h for 1.5 l) Pallet loader With shutter head Incl. protective fences, pallet transport, Container transport, tray turner, formation table, layer pad inserter, layer pad magazine, empty pallet magazine
used
Used fully overhauled Depalletizer 40 000 bph We have a used fully overhauled depalletizer available for purchase manufactured by Krones This depalletizer was fully overhauled by Siemens PLC in 2020 including the installation of new PLCs and sensors ensuring that the machine is up to date and efficient The depalletizer is capable of operating at high speeds of up to 40 000 bottles per hour making it ideal for high volume production lines Features and Specifications In addition this Used Full Overhauled Depalletizer is equipped with a bottle mass table sheet removing arm and magazine as well as a pallet magazine The machine operates automatically with a new PLC in 2020 Siemens ensuring that your production line runs smoothly and efficiently Additional Details With its high speed capability and reliable operation this depalletizer is an excellent investment for any production line in need ...
used
New Palletizer ROBOT ARM PALLETIZER Automatic palletizing group specially designed for high speed applications with Fast Pack Formation Table at High Elevation Speed suitable for 72 000 cans hour line for 250 ml slim cans with 6 4 configuration on 1200 1000 mm pallets Package infeed height H 2000 mm Designed for pallet dimensions 1000x1200mm Max standard pallet height 1900mm Pallet transfer height H 500mm Machine is composed of Fast Pack Formation Table at High Elevation Mechanism to turn packs automatically at inlet of the palletizer according to the predetermined configuration of each layer It is controlled by the PLC and The device is equipped with a turner which turns the product of 90 if required Intermediate Table Consists of conveyor table a product pushing device to pallet lifter Driven by a geared motor The translation of the layer from the performer to the palletiser is carried ...
used
CNC 5-axis gantry milling machine Jobs JomaX 265 W Year of construction 2016 Siemens 840D SL CNC controller Panel size 25,000 x 5,000 mm (10 panel panels) Plate field load per panel field max. 10,000 kg Rapid traverses X,Y,Z/W 28,000/8,000 mm/min. C/A axis 30°/s Distance spindle nose ~ table max. 3,900 mm Distance between uprights 6,000 mm Travel X 28,000 mm Y 6,500 mm Z 1,500 mm 2-axis NC swivel milling head. C 400 (+/- 200°). A 220° +/- 110° Spindle holder HSK-A100 Spindle drive power 42/53 kW Spindle torque max. 1,337/1,687 Nm Spindle speeds up to 3,000 rpm. 1-axis angle milling head 90° BUSS With C-axis +/-200° Spindle holder HSK-A100 Spindle drive power 30/37 kW Spindle torque max. 955/1,178 Nm Spindle speeds up to 2,800 rpm. Vertical milling head BUSS Spindle holder HSK-A100 Spindle drive power 45/56 kW Spindle torque max.1,433/ ...
used
Year of construction 2008 Control system Siemens 840 D Rotational diameter. [mm] 2400 Turning length [mm] 2145 General: Year of construction 2008 Control system Siemens 840 D Turning diameter 2,400 mm Rotation height 2,145 mm (stand elevation 900 mm) Machine Table: Technology gear table, 2 stages Drive power 100 kW Torque 39,700 Nm Holding torque milling operation 44,800 Nm Speed 250 rpm Face plate diameter 2,200 mm Table load max. 17,000 kg C-axis 0.001° Drilling and milling equipment: Technology Gear Spindle Speed max. 3,000 rpm Power 37 kW Torque 1,230 Nm Tool holder Capto C8 Crossbar: Vertical travel 1,000 mm Grid spacing 100 mm Distance between milling spindle and table 2,350 mm Support: Travel X-axis +/- 1,350 mm Z-axis travel 1,500 mm Chisel slide cross-section 250 x 250 mm Immersion diameter 340 mm Rotate tool holder Capto C6 Tool Hold ...
used
Disposable PET bottle line consisting of SIPA stretch blow molder with cooling system, APV Intermix mixing system, Hinke buffer tank, Hal PET bottle filler and capper, P.E. Futura labeller, Variopack tray packer with shrink tunnel, Twin Pack handle applicator, Profipak palletiser, pallet turner, pallet wrapper, pallet discharge, blank hopper and transport system, lid hopper and transport system, air transport system for empty PET bottles, Bottle transport system, tray transport system, pallet transport, layer magazine, CIP set, 2 citric acid tanks with dosing system, 2 mixing tanks for syrup, flash pasteuriser and control and regulating systems., Filling capacity: 8000 bph 1,5 L PET bottles, Formats: 0,5 L and 1,5 L disposable PET, Operation / Control: The plant is completely equipped with Siemens S7 control system., Features: Stretch blow molder with cooling system; mixing system; buffe ...
used
MazaK M Plus X Axis Strokes: 1150 Y Axis Strokes: 1000 Z Axis Strokes: 1000 Board length: 630 Deck Board Width: 630 Max Piece Dimensions Length X Width X Height Table: D.1050XH.1100 Spindle Table Surface: Tapped holes Max Spindle Piece Weight: 1500 Spindle Spindle: 8000 Spindle holder: ISO 50 Torque Cont 10 Min Spindle: 600 Nm Rapid Displacement X Axis Rapid Displacement: 30000 Rapid Move Y Axis Rapid Move: 30000 Rapid Displacement Z Axis Rapid Displacement: 30000 Number of Atc Warehouse Tools: 120 Max Atc Magazine Tool Diameter: 225 Max Tool Length from the Atc Warehouse Reference Line: 630 ATC magazine tool selection method: fixed Max Tool Weight Atc Warehouse: 30 Kg Atc Warehouse Tool Change Time: 5 SEC. Refrigerant pressure: 50 BAR Machine Dimensions Height: 21350 Machine Dimensions Width: 3480 Depth Machine Dimensions: 6750 Machine Dimensions Weight: 20900 ...
used
Palletiser The following components are included: - Interim storage gripper - 2 layer slides - centering - turning station in the infeed - empty pallet magazine for 12 pallets - control cabinet - safety fence, Additional title: pallet packer, Capacity: 10 pallets/h, Power: 9,0 kW, Voltage: 3 x 400/230 VAC, Frequency: 50 Hz, Formats: currently: trays for milk drinks, formerly: beverage crates, Operation / Control: Siemens S7 315 2 DP, Features: Interim storage gripper, 2 layer slides, centering, turning station in the infeed, empty pallet magazine for 12 pallets, control cabinet, safety fence
used
- Horizontal 4-axis Cnc Machining Center In Continuous Control Fanuc 31i-model B -apc 2 Stations -corse X800 X Y800 X Z750 (Voltage : D.850x1000) -60 Random Tool Places -iso 50 Electrospindle With Double Contact Flange, Oil Cooled, 10000 Rpm -pallet Capacity: 700 Kg - External 4-way Hydraulic Locking System 70 Bar With Lock/release Switch -internal/external Air Blow Adjustable M Function - Internal Refrigerant Duct At 70 Bar - Additional Calpeda Shower Cleaning Pump 15 Bar - Robot Electric Attachment Arrangement (Fanuc) -internal System To Reset Length And Tool Radius Renishaw Ts27r, Available New One Equal In Case Of Breakage In The Magazine. - Piece Reset Measurement Probe With Renishaw Rmp60 Cycles (Radio Transmission) -data Server 2gb, Fanuc Aicc 2 Software (High Speed For 3d Molds And Figures, 1ooo Blocks Ahead) -communication With Ports And Usb + Ethernet - Scraping ...
used
Gildemeister GMX 250 Linear The GMX 250 Linear is a turning-milling centre for producing rotational parts, type flange. It machines the complete part in one run without the operator interfering from a semi-finished part, for instance a cast part. In fact, from both sides using two clampers. The machine is able to turn, mill, drill, produce threads etc. Operating system – Heidenhain plus it with turnplus Working range Maximum turnable diameter 640 mm Maximum turnable diameter of the counter spindle 400 mm Distance between the spindles 1,500 mm Turntable length 1,185 mm Main drive Maximum output 28 kW Maximum speed 5,000 min-1 Maximum torque 320 Nm Tool magazine Number of tools in the magazine 46 Number of tools in the turret 12 Tool interface HSK 63, VDI 40 Main drive Maximum output 28 kW Maximum speed 5,000 min-1 Maximum torque 320 Nm
used
Used SCM ERGON 240 Wood CNC machining centre double bench for pendulum or electric axis operation, maximum size 4 x 2.20 m Suitable for working on wooden, plastic and aluminum plates. Double spindle, double tool magazine. It has a double bench, double spindle, double tool magazine. Two Z axes, two Y axes, one common X axis (calling it five axes would be misleading)
used
Planer for round bars solver with magazine Type: VF 120 Year of construction: 1987 max. workpiece thickness 120 mm with 2 planer heads and 2 knives each (4 knives in total) in the machine and 2 spare planer heads and 2 knives each (4 knives in total) for round bars in 8 mm Feed speed 5-25 m/min. incl. slide-in magazine solver suitable for the production of dowel rods, round and profile rods
used
turning diameter: 575 mm turning length: 1500 mm control: Mazatrol PC Fusion 640MT total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m Mazatrol PC Fusion 640 MT control milling spindle C-axis Y-axis 40-fold magazine 3-jaw chuck Kitagawa Steady rest tail stock Tool Eye coolant device chip conveyor Technische Daten / technical details: Drehdurchmesser / turning diameter 575 mm Drehdurchmesser über Schlitten / turning diameter over sledge 470 mm max. Drehlänge / max. turning length 1500 mm X-Achsenverfahrweg / travel x-axis 450 mm Z-Achsenverfahrweg / travel z-axis 1527 mm Y-Achsenverfahrweg / travel y-axis +-90 mm max. Drehzahl Hauptspindel / max. spindle speed main spindle 35-3000 UpM / rpm Drehzahl Frässpindel / speed of milling spindle 15-6000 UpM / rpm Anzahl der Magazinplätze / number of places in magazine 40 fach /fold Gewi ...
Key data: 1250 mm, 1250 mm, 1000 mm
Year of construction 2015 Control Heidenhain iTNC 530 Speed [rpm] 18000 Travel X/Y/Z [mm] 1250/1250/1000 Tools & Tools. HSK 63 General: Year of construction 2015 Control Heidenhain iTNC 530 Travel X/Y/Z 1,250/1,250/1,000 mm Spindle speed 18,000 rpm Tool holder HSK-63 Spindle: Motor Spindle Technology Speed 18,000 rpm Power max. 35 kW Torque max. 130 Nm Tool holder HSK 63 NC swivel head: B-axis 210° (-30°/+180°) Resolution 0.001° NC Rotary Table: C-axis 360° Clamping surface 1,000 x 800 mm Table load max. 1,500 kg Tool magazine: Technology Chain Magazine Tool changer double gripper Number of stations 120 Equipment / Accessories: Automation 2-fold pallet changer Displacement measuring systems directly in all axes (glass scales) Chip Disposal Chip Conveyor Coolant supply IKZ system, 40 bar Tool Measurement BLUM Laser Workpiece Measurement I ...
used
Control : Siemens SINUMERIK 840C • Spindle Taper: SK 40 • Magazine: 32 sets • Atc: UMBRELLA TYPE • Table Size: 400 mm x 400 mm • Pallet Changer: Available: Double Pallet • Travel X: 500 mm • Travel H: 500 mm • Travel Z: 500 mm • Table: B Axis: 0.001 Degree (Precision Rotating) • Power Shaft Motor: 35 KW • Spindle speed: 18000 rpm • Cooling through Shaft: Available • Chip conveyor: Available this extra information is standard for this model. Please always double-check the details during a visit The Deckel Maho 50 H is a precision machining center renowned for its exceptional performance and versatility. Manufactured in 2004, this horizontal machining center is equipped with advanced features and capabilities to meet the demanding requirements of modern machining operations. Controlled by the Siemens SINUMERIK 840C system, the Deckel Maho ...
used
Machine is in good working condition • Control unit: FANUC 18-T • Year : 1998 • Double Mirror: 8 and 6 inch available • C Axis: Available • Magazine: 12 sets • Machining Diameter Max. : Ø350x640mm • Spindle Diameter: Ø60mm • Conveyor: Available this extra information is standard for this model. Please always double-check the details during a visit The Doosan DOOTURN 310TML CNC lathe, manufactured in 1998, continues to stand as a reliable and efficient machine for precision turning operations. Equipped with a FANUC 18-T control unit, this lathe offers advanced control capabilities for precise and versatile machining tasks. Featuring a double mirror configuration with 8 and 6 inch options, the DOOTURN 310TML provides flexibility in accommodating a wide range of workpiece sizes and configurations. The availability of a C-axis further enhances its machining ...
used
Description: Vertical machining center Serial number 910209110 Working table: 1150 x 410 mm Maximum worktable load: 500 kg Travels: - X-axis (longitudinal): 760 mm - Y-axis (transversal): 440 mm - Z-axis (vertical): 485 mm Distance from the table to the spindle: 150-635 mm Distance from the center to the column: 250-690 mm Distance from the center of the spindle to the column: 470 mm Spindle diameter: 80 mm Taper: ISO 40 Spindle speed: 25-4500 Rpm Rapid feeds: , - X/Y-axis: 15000 mm/min - Z-axis: 12000 mm/min Cutting feedrate X-/Y-/Z-axis: 1-5000 mm/min 30-position tool magazine Bi-directional magazine rotation Maximum tool diameter: 175 mm Maximum tool weight: 10 kg Maximum tool length: 350 mm Tool change time: 1.9 sec. YASNAC MX3 Control Controlled axes: 3 Simultaneously controlled axes: , - 3 positioning, linear interpolation - 2 Circular interpolation Power 25 KVA z-motion: 4 ...
used
Description: Vertical machining center Serial number 890907849 Working table: 1150 x 410 mm Maximum worktable load: 500 kg Travels: - X-axis (longitudinal): 760 mm - Y-axis (transversal): 440 mm - Z-axis (vertical): 485 mm Distance from the table to the spindle: 150-635 mm Distance from the center to the column: 250-690 mm Distance from the center of the spindle to the column: 470 mm Spindle diameter: 80 mm Taper: ISO 40 Spindle speed: 25-4500 Rpm Rapid feeds: - X/Y-axis: 15000 mm/min - Z-axis: 12000 mm/min Cutting feedrate X-/Y-/Z-axis: 1-5000 mm/min 20-position tool magazine Bi-directional magazine rotation Maximum tool diameter: 175 mm Maximum tool weight: 10 kg Maximum tool length: 350 mm Tool change time: 1.9 sec. YASNAC MX3 Control Controlled axes: 3 Simultaneously controlled axes: - 3 positioning, linear interpolation - 2 Circular interpolation Power 25 KVA PARTIALLY DISASSEMBLE ...
used
Description: Vertical machining center Serial number 890707694 Working table: 1150 x 410 mm Maximum load on worktable: 500 kg Travels: - X-axis (longitudinal): 760 mm - Y-axis (transversal): 440 mm - Z-axis (vertical): 485 mm Distance from the table to the spindle: 150-635 mm Distance from the center to the column: 250-690 mm Distance from the center of the spindle to the column: 470 mm Spindle diameter: 80 mm Taper: ISO 40 Spindle speed: 25-4500 Rpm Rapid feeds: , - X/Y-axis: 15000 mm/min - Z-axis: 12000 mm/min Cutting feedrate X-/Y-/Z-axis: 1-5000 mm/min 30-position tool magazine Bi-directional magazine rotation Tooling included Maximum tool diameter: 175 mm Maximum tool weight: 10 Kg Maximum tool length: 350 mm Tool change time: 1.9 sec. YASNAC MX3 Control Controlled axes: 3 Simultaneously controlled axes: , - 3 positioning, linear interpolation - 2 Circular interpolation Powe ...
used
Description: The machine intended for precise processing of details has a high-quality steel construction, equipped with the best components. The metalworking process takes place on the 500 mm long and 380 mm wide work table of the milling center using a powerful 15 kW spindle, which guarantees excellent precision and significantly reduces milling time. The CNC milling machine has 5 axes (X,Y,Z,C,B) with displacements of 500 mm (X axis), 420 mm (Y axis), 380 mm (Z axis), 180° (C axis) and 360 ° (axis B). Along with the vertical machining center, a wide range of equipment is offered, consisting of, for example: a control panel with an installed HEIDENHAIN TNC 430 CNC control system, a spacious tool magazine and a detail probe. The total weight of the machine is 6000 kg. Technical data of the CNC milling center DECKEL MAHO DMU 50 EVOLUTION number of axles: 5 displacements in X/Y/Z ax ...
used
Machine in good technical condition, possibility of testing after agreement. In 2015, GO spindles took place. In October 2023, the tool magazine motor was replaced. In 2011, a license for the DXF software option was purchased - import for iTNC. Motorcycle watches. power on time : 57676. Heidenhain iTNC53O control system. Technical data: Longitudinal clearance (X): 2 x 750 mm Cross travel (Y): 500 mm Vertical travel (Z): 600 mm Table-spindle face distance: 180 - 780 mm Machine table: Table clamping surface: 1000 x 500 mm T grooves 3 pieces (middle groove H7): 14 H9 mm Table load. 800 kg/m2 (with uniform surface load of the table) Feeds: Max. sliding force: 9000N Rapid traverse in X/Y/Z: 25/25/20 m/min Feed in all axes: 1 – 9999 mm/min Main drive-spindle: Main drive AC motor with hollow shaft 40% ED: 40 kW Speed range - stepless: 30-6000 rpm. Spindle torque 4 ...
used
The machine is in good technical condition. Table clamping area 1500x670 X-axis travel - 1270 mm Y-axis travel - 610 mm Z-axis travel - 720 mm Hedennain TNC 430 control system Spindle speed 10-8000 / min Number of controlled axes: 3 Central cooling Central cooling pressure 10 bar Spindle taper ISO 50 Tool magazine Number of positions in the tool magazine 30 Dimensions lxwxh - 5000x3600x3330 m Machine weight 11000 kg The accessories of the purchase item consist of: -workpiece probe: m & h inprocess messtechnik -clamps SK50 - 25 pcs. Year of production / SO / GO: - / - / 2001
used
Description: Basic Machine Universal machining centre DMU 60eVo New DMG MORI Design traverse path X/Y/Z 600/500/500 mm / X/Y/Z 23.6/19.6/19.6 in motorspindle speedMASTER® SK 40/BBT speed range 20 - 18.000 min-1 SK40 speed range 18.000 - 20.000 min-1 SK40-BIG PLUS® 35 kW (40% ED), 25 kW (100% ED) 46.9 hp (40% DC), 33.5 hp (100% DC) tool taper SK40 (DIN ISO 7388-1-A, AD) for Pull-Studs DIN ISO 7388-3-A, AD NC swivel rotary table chain type tool changer with 30 positions and double gripper active cooling direct measuring system full cabin Swarf conveyor (scraper type), spray gun MPC (Machine Protection Control) 3D-Control, ERGOline® control Dynamic package for DMU 60 eVo linear linear drive X/Y-axis with 80 m/min // 262.48 ft/min rapid feed X/Y/Z 80 m/min // 262.48 ft/min, Acceleration X/Y/Z 10 m/s² // 32.8 ft/s² Control CELOS with Siemens 840D sl Operate includes 21,5 ERGOline® ...
used
Description: Operating hours 37559 (read off), spindle hours 12690 (read off), universal milling machine, with traverse paths 750 x 650 x 560 mm, motor spindle 24000 rpm, 13 kW, tool holder HSK63A, chain magazine, 30 magazine positions SK40, 3D belt control, Coolant tank 500 l, HEIDENHAIN ITNC 530 HSCI control, NC rotary table (C-axis), diameter 650 mm (800 x 650 mm), table load 600 kg, C-axis swivels 360°, swivel range A-axis 120° +/-, 3D measuring probe, type TS649, scraper belt chip conveyor, machine has DMG Smartkey (V2) and MPC (Machine Protection Control), Quickset, a new spindle was installed by the manufacturer approx. 2000 operating hours ago Approx. Onsite Dimension. (l x w x h): 5,000 x 2,800 x 2,900 mm, weight approx.: 10,000 kg
used
Description: IMA NOVIMAT/CONTOUR/I/G80/790/R3 edge banding machine with PUR gluing unit and diode laser LDM - Stop ruler with automatic adjustment - Joining milling unit 2 x 4.0 kW - Blow nozzle for removing loose particles on the workpiece side - 300 mm radiator for preheating the workpiece edge up to 60 mm high - Gluing unit VTG with pre-melter for PUR Quickmelt - Edge magazine with 2-fold roll - Diode laser system LDM approx. 4 KW with laser rack - Pre-milling unit above 1850 W - Trimming unit for longitudinal and transverse processing 2 x 200 W with pneumatic swivel - Multiple profile milling unit 2 x 1000 W  , Stepper motor adjustment horizontally and vertically  , 3-way feeler roller - Copy milling machine KFA x20, motor 500 W - Multiple profile scraper unit  , Stepper motor adjustment horizontally and vertically  , 3-way feeler roller - Scraper  , with electr ...
used
Equipment/technical data: - e-Motion control with 21" smartouch instead of 10" tempora F 800 Ser - Upper pressure beam motor-controlled, adjustable workpiece height 8-60 mm - Chain feed 12 m/min, 1.5 kW, Minimum workpiece length 140 mm - Turntable edge magazine for roll edge material 0.4 - 3 mm and strip magazine for 12 pieces 10 mm edges - Edge feeding for roll and strip material - pneum. Controlled gluing unit, Teflon-coated, for 1.5 kg EVA granules, with synchronized glue roll and quick-change system. (for PUR adhesive processing, taking into account the Adhesive processing guidelines) - Pneumatically operation-controlled pressure unit e-motion (one driven, two conical contact rollers) tempora 60.12/2: 0-12mm - Impact shears for roll material - Cross-cut saw with 2 motors - Joining milling unit 2 x 1.5 kW - Upper and lower combination milling unit, 0.75 kW each, flush a ...
used
Table dimensions ( x-y/mm) 1500 X 650 Stroke ( X/mm) 1400 Stroke ( Y/mm) 650 Stroke ( Z/mm) 650 Type of controll Selca S4040dh Number of spindle per minute 8000 Tool magazine Yes Number of inserts in the tool magazine 24 Weight ( ton) 11 Height ( mm) 3000 Profondità ( x/mm) 4000 Chuck connection Iso 50 Location Novara Italy Ce Marked
used
Description: Y-axis (with electrode change): 675 mm Carrying capacity: 1000 kg Integrated C-axis 1/min: 10/20 Working head: Max. Head load: 100 kg Max. Distance between tool carrier plate and worktable: 575 mm Electrode changing system: Pickup plate magazine Magazine slots: 20 Drive and measuring system: Drive type: digital AC servo motors Travel speed X/Y/Z: 2000 mm/min Digital display: 0.001 or 0.0001 selectable Total amount of dielectric: 400 liters x-motion: 525 mm, y-motion: 400 mm, z-motion: 375 mm, control: Multipulse, table surface area l x w : 730 x 630 mm, weight approx.: 4,800 kg, Approx. Onsite Dimension. (l x w x h): 2,200 x 2,150 x 2,550 mm
used
Overview The Kettner Linapac crater was manufactured in 1998 and installed in a mineral water company in Germany. It was used in a combined line producing PET in shrink film and pet cycle. As the line was mainly producing on the shrink packer, this machine is in excellent condition. The documentation and program backup are also available. The crater comes with a magazine to store format parts. Tech Specs: Capacity: up to 18,000 bph Number of crating heads: 5 Formats: 4x3 3x2 Control: Siemens S7 Additional Equipment: Crating heads Magazine for storage of crating heads Technical documentation Conveyor
used
Overview The loader was manufactured in 2000 by the German company Kettner. It is located at a German mineral fountain and is part of a plant that has been shut down because the operator will be bottling in glass in the future and no longer in PET. The loader is still mounted and electrically connected. Techn. data 3-axis loader Capacity: up to 68 pallets/hour Control Siemens S5 With automatic central lubrication Accessories Pack transport Pallet transport Grouping table Layer pad inserter Intermediate layer magazine Empty pallet magazine
used
Stroke ( X/mm) 500 Stroke ( Y/mm) 450 Stroke ( Z/mm) 400 Type of controll Heidenhain Itnc 530 Fs Number of spindle per minute 20000 Tool magazine Yes Number of inserts in the tool magazine 60 Max Tool Diameter 150 Mm Weight ( ton) 6 Type 5 Continuous Axes Tilting Rotary Table 500 Mm Location Milan Italy
