machining center used for sale

Unit 1 - Geiss CNC FZ 2800 x 1000 - Year of Manufacture: 2013 - Total Weight: 42.05 kN - Voltage: 400V, 3-phase + N, 50Hz - Connected Load: 25.62 kW - Rated Current: 37 Amp - Certification: CE Unit 2 - Geiss CNC FZ 2000 x 1000 - Year of Manufacture: 2012 - Total Weight: 30.22 kN - Voltage: 400V, 3-phase + N, 50Hz - Connected Load: 24.72 kW - Rated Current: 36 Amp - Certification: CE Find more here - / Contact us at -

Two Geiss CNC machining centers are available. 1) Geiss FZ 2000x1000, year of manufacture: 2012, travel path X/Y/Z: 2450mm/1400mm/800mm, B-axis: 285°, C-axis: 520°, speed: 30000rpm, table dimensions X/Y: 2000mm/1000mm, machine dimensions Y/Z: 2500mm/2450mm, weight: approx. 30500kg. 2) Geiss FZ 2800x1000, year of manufacture: 2013, table dimensions X/Y: 2800mm/2000mm, weight: approx. 42000kg. The Geiss machine with the year of manufacture 2013 has spindle problems. A cost estimate is available for this. The repair can be carried out before the sale or by the buyer. Documentation available. An on-site inspection is possible. Individual sale possible.

JUPITER JC-1000 DATA SHEET Control: Fagor CNC8055 MC Strokes (X, Y, Z): 1000 x 500 x 500 mm Table: 1200 x 500 mm Spindle: BT 40 - 8,000 RPM Tool magazine: 24 positions Rapid: 30 m/min Overall dimensions: 2900 x 2200 x 2600 mm Machine weight: 5000 kg Scope of delivery: remote handwheel, chip tank Chip Conveyor Complete with manual CE Certificate Auction-ID: A7-47195-8

Serial number H30163, complete with chip conveyor and manuals Auction-ID: A7-47195-36

Inv. Num. : 9068 Type: VHC 3 XTS Producer: AXA Created: 2016 Parameters: Control system: HEIDENHAIN iTNC 530 Maximum vertical spindle speed: 10000 1/min X-axis travel: 3000 mm Y-axis travel: 900 mm Z-axis travel: 950 mm Cone: HSK – A 63 Number of all tools: 36 pieces Equipment: Chip conveyor NC rotary table AXA RTA 2-300 (diameter 300 mm) 3D Measuring Probe RMP60 Handwheel Hand Dishwashing Gun

hogedrukkoeling via de spindel spanentransporteur X-axis: 1660 mm Y-axis: 510 mm Z-axis: 510 mm Table dimensions: 2000 x 510 mm Max weight on the table: 1000 kg Admission in spindle (ISO): BT-40 Power on the spindle: 18,5 kW Control : Mazatrol 640M Toolchanger: yes Number of toolholders: 30 positions Number of rotations: 12 000 rpm Weight: 8250 kg

With 4 and 5 axles, chip conveyor VICES and TOOLS NOT INCLUDED Auction-ID: A7-47195-37

Maximale afmetingen van het werkstuk: 800 x 1000 mm tabelindexering elke 0,001° afstand van palletcentrum tot spindelneus: 70 gt; 810 mm afstand van palletoppervlak tot spindelcentrum: 100 gt; 830 mm Hogedrukkoeling via de spindel (70 bar) Uitgerust met Palletech High Rise System = uitbreidbare palletopslag met 2 niveaus voor 12 pallets. spanentransporteur X-axes: 730 mm Y-axes: 730 mm Z-axes: 740 mm Table dimensions: 500 x 500 mm (2x) Max weight on the table: 700 kg Admission in spindle (ISO): BT40 Power on the spindle: 30 kW Toolstore: yes Tools: 160 positions Frequency : 18000 rpm Number of pallets : 12 pallets Length: 9000 mm Depth: 8000 mm Height: 2850 mm Weight: 12,4 ton

Equipped with: lathe with driven tools, possibility of milling, Max. turning diameter: 180 mm, Max. turning length 300 mm, Main spindle speed: 5,000 rpm, Spindle power 22 kW, Bar passage: 60 mm, Spindle nose: A2-6, Equipped with Filtermist S400 extraction, conveyor belt, Fedek DH 65L S2 rod loader, Habor oil cooler, various loose holders, tubes and parts, documentation available. Auction-ID: A1-41998-3

Connected load: 16kVA, control: FANUC Series 0-M, with carousel tool magazine, coolant system with external chiller HABOR Unit, spindle cooling, enclosed working area (full enclosure), handwheel (MPG) vorhanden, manual clamping devices on table and transformer separately in the control cabinet. On-site inspection is possible.

TOOLS PROVIDED Auction-ID: A1-46801-403

An old Stama machining center is available. Tool positions: 10, travel path X/Y/Z: 500mm/380mm/400mm, table dimensions X/Y: 700mm/380mm, tool holder: SK30, speed: 7500rpm, drilling capacity in steel: 30mm, machine dimensions X/Y/Z: approx. 2350mm/2550mm/2750mm, weight: approx. 2500kg, control: Fanuc 6MB. An on-site inspection is possible.

TECHNICAL DATA SHEET WINTEC MV 45 Control: Fanuc Series 18-M X-axis travel: 800 mm Y-axis travel: 450 mm Z-axis travel: 500 mm Table dimensions: 900 x 450 mm Spindle Attachment: BT 40 Spindle speed: 8,000 RPM Tool Change: ATC 20/24 Position Rapid: 24 - 30 m/min Overall dimensions: 2400 x 2200 x 2550 mm Machine weight: 4500 kg Auction-ID: A7-47195-14

Auction-ID: A1-41998-10

Number of axes: 3, max. speed: 6000rpm, compressed air connection: 6-8bar, main motor power: 20HP, control system: Fanuc Series 18-M, weight: 12t, without documentation. An on-site inspection is possible.

X-axis stroke 520 mm Y-axis stroke 360 mm Z-axis travel 465 mm Table size 650 x 375 mm Table load capacity 500 kg Spindle speed 12,000 rpm Spindle power 5.5/7.5 kW Tool holder BT 40 Tool magazine 20 positions Accessories Connection with boring head D'Andrea TRM/50 Gerardi vice 345x120 mm Machine equipped with manuals and CE declaration of conformity. All technical data shown are indicative and may be changed without notice and therefore should not be considered binding Auction-ID: A1-47207-2

X-axis travel 560 mm Y-axis travel 560 mm Z axis travel 630 mm Continuous B-axis Table load capacity 400 kg Spindle speed 14,000 rpm BT 40 tool holder Tool magazine 60 positions Accessories Pallet cubes 250x250x600 Pallet cubes 400x150x600 Miscellaneous tooling D'Andrea boring head attachment Machine equipped with manuals All technical data shown are indicative and may be changed without notice and therefore should not be considered binding Auction-ID: A1-47207-1

CONTROLS   CNC controls MORI SEIKI MSC 500 WORKING RANGE -CUBIC-   number of processing axes (excl parallel axes): 3   X-axis travel: 560 mm   Y-axis travel: 410 mm   Z-axis travel: 460 mm TABLE   table surface (left-right): 900 mm   table surface (front-back): 450 mm   workpiece load (max): 300 kg SPINDLE / HEAD   spindle revolutions (min): 80 /min   spindle revolutions (max): 8000 /min   tool fixture: ISO BT 40 TOOL MAGAZINE   number of positions: 20 ELECTRICAL SPECIFICATIONS   mains power supply: 15.5 kVA DIMENSIONS / WEIGHTS   space requirements -left/right-: 2210 mm   space requirements -front/back-: 2242 mm   total height: 2723 mm   total weight approx.: 4200 kg

Max. spindle speed: 18,000/min, controls: iTNC 530, operating hours: 94,807h. An on-site inspection is possible.

X-axis: 620mm, y-axis: 520mm, z-axis: 460mm, B-axis: -50° to +110°, C-axis smallest increment: 0.001°, distance from spindle nose to table surface B/C-axes: 140-600mm, B/C-axis rotary table diameter: 650mm, centering bore: Ø55H7x12, T-slots quantity/width/pitch: 5x18x100, max. workpiece dimensions: Ø520x330mm, max. table load (90°/horizontal): 200/300kg, max. spindle speed (standard) direct drive: 12,000/min, spindle bearing inner diameter: 70mm, rapid traverse X/Y/Z: 36m/min, working feed rate: 1-10m/min, rapid traverse B/C-axis: 25rpm, tool holder: MAS BT-40, number of tool positions: 40, max. tool length: 250mm, max. tool weight: 7kg, compressed air requirement: 0.6MPa / 500l/min, coolant tank capacity: 420l, connected load: 45kVA, control: Heidenhain iTNC 640 HSCI, length: 2325mm, width: 4210mm, height: 3108mm, weight: 9.5t, operating hours control on: 9,380h, machine on: 9,501 ...

DMG MORI DMU 210 P Universal Machining Center in heavy-duty duoBLOCK design for 5-axis positioning and simultaneous machining. The machine features a Heidenhain TNC 640 3D control system and a large working area of X 2,100 mm / Y 2,100 mm / Z 1,250 mm. The machining center is equipped with a continuously positioning universal milling head with a controlled B-axis and an integrated motor spindle. The swivel range extends from the horizontal position to a maximum of 250°. Additionally, the machine is equipped with an NC rotary table Ø 1,700 mm with direct path measurement system and 360° positioning. The permissible table load is approximately 8,000 kg. The SK50 motor spindle reaches speeds from 20 – 12,000 rpm with a power output of 52 kW / 42 kW and a torque of up to 430 Nm. Tool magazine as a wheel magazine with 63 tool positions and double gripper. Equipment includes, among othe ...

DMG MORI DMU 160 P Universal Machining Center in heavy-duty portal / duoBLOCK design for 5-axis positioning and simultaneous machining. Equipped with Heidenhain TNC640 control and designed for high-precision heavy-duty machining in tool, mold, and mechanical engineering. Large working area with integrated NC rotary table and controlled B-axis milling head for complex 5-axis machining. The machine concept is designed for maximum rigidity, thermal stability, and high long-term accuracy. The machine features SK50 spindle technology, a wheel magazine with 63 tool positions, and a double gripper system. Through-spindle coolant supply and extensive measurement and process optimization systems are available. Equipment includes, among others: Oil and emulsion mist separator with mechanical filter Blow air through the spindle center Blum Laser NT Hybrid tool measurement M&H infrared mea ...

5-Axis Machining Center GF Machining Solutions MIKRON UCP 800 Duro CNC: Heidenhain iTNC 530 Axis Travels X-axis: 800 mm Y-axis: 650 mm Z-axis: 500 mm Rotary Axes C-axis 360° continuous swivel range Spindle / Adapter Types NCD 150 PL – NCD 200 PL Tool Interface HSK-E63 Operating Hours Control ON: 30,064 h Machine ON: 10,322 h Program Execution: 4,159 h Drives ON: 7,331 h Spindle ON: 4,231 h Equipment Chip conveyor Coolant system with filtration unit Documentation available

Driller project 323 Power supply 400v 50hz Europower supply frequency inverter 11 kW CE safety standards for std frame saw for longitudinal incisions belts waste disposal std frame booklet instructions in Italian special execution Posiz.1-c.u. Hsk 8 posizioni indexato Special execution Posiz.2-c.u. Hsk 8 posizioni Special execution Piano di lavoro tipo schmalz in sostituzione del piano std. Auction-ID: A1-46801-94

x-travel:800 mm y-travel:410 mm z-travel:510 mm control:Fanuc 10 MA rapid travel x/y/z:20/20/15 mm/min table surface area:1100 x 450 mm tool taper:BT 40 tool magazin::30 BT 40 max. tool length:250 mm max. tool weight:8 kg power requirement:7,5/5,5 kW turning speed range:6000 1/min weight of the machine ca.:6,3 t Under offer is a complete CNC tool shop, which will be given up due to old age of owner. The Mori Seiki is still highly accurate. All existing tool holders, tools, drills, vices etc. come with the machine. All measuring devices also come with the machine. Upon request orders for parts to be made can be passed on to new owner. This is a low cost all inclusive opportunity for a "Startup"

x-travel:1400 mm y-travel:1200 mm z-travel:1350 mm control:MSX- 701 Mapps III table surface area:800 x 800 mm rapid traverse:50 m/min table rotating:360.000 x 0,001 B-Achse ° table load:2,0 t numbers of pallets:2 turning speed range:8000 1/min power capacity - milling spindle:37 kW no. of tools in the magazine:60 Stück tool taper:HSK-A 100 weight:31 t dimensions:5,9 x 3,48 x 3,68 m Equipment: - Thru-the-spindel coolant system Mayfran Consep 2000 70 bar with chipconveyor - Helical cutting + Synchronized tapping - Parts program memory 1 MB - Knoll 70 bar high pressure and filter system - Electrostatic oil dust collector LTA - elect. hand wheel - renishaw probe - abso- scale i X/Y/Z- axis - 5 free m- funktions - 48 extra off sets - dual ballscrews on X/Y/Z- axis

x-travel:560 mm y-travel:560 mm z-travel:660 mm control:Celos Siemens 840D SL Operate ERGOline Multitouch turning speeds:20 - 20.000 1/min spindle drive:25/ 35 kW max. torque on the spindle:86 / 130 tool taper:HSK-A63 Number of tool station:60 diameter of tools max.:70 mm Tool diameter with no neighbouring tools:170 mm tool length - max.:450 mm weight of tools max.:12 kg numbers of pallets:2 Pallet dimension:400 x 400 mm max. workpiece diameter:630 mm workpiece height max.:900 mm table load:400 kg rapid travel x/y/z:60 m/min Feed x/y/z:60 m/min internal coolant system feed:70 bar weight of the machine ca.:8,5 t dimensions:3200 x 4800 x 2900 mm Renishaw probe (spindle):Vorbereitung / preparation only Horizontal machining center with Siemens - Celos control, full b-axis, tool magazine with 123 pos. HSK-A 63, coolant through spindle 40 bar. The machine has just received a new milling spind ...

x-travel:630 mm y-travel:600 mm z-travel:650 mm control:MSC 502 (Fanuc 16) Spindle RPM:12000 1/min spindle drive:22 / 18,5 kW rapid travel x/y/z:32 m/min Pallet dimension:500x500 mm numbers of pallets:2 table load:0,5 t working diameter:max. 610 mm Number of tool station:60 BT40 max. tool length:360 mm max. tool weight:12 kg tool changing time:1,3 sec B-axis positioning (non continuous):1 total power requirement:50 kVA weight of the machine ca.:14 t dimensions of the machine ca.:3,3 x 5,8 x 3,2 m spindle load monitor:Typ C This horizontal machining center comes with a pallet changer with 2 pallets, and has the following options: ATC 60 tool stations, High pressure coolant trough spindle interface,

x-travel:630 mm y-travel:630 mm z-travel:630 mm control:Unipro 90 Pallet changer 2x:400 x 500 workpiece - installed height:800 mm max. clampable workpiece diameter:720 - 850 mm spindle taper::SK 40 spindle turning speed - stepless:10 - 8000 1/min Spindle power:20 / 30 kW Spindle Torque:95/143 Nm tool magazin::80 SK 40 total power requirement:55 kW weight of the machine ca.:11 t Machine with Unipro 90 control for 5 axis - twin palette changer - tool magazine 80 HSK-A 63 - coolant device with coolant through spindle 7 pressure levels - full A & B-axis - chip conveyor

x-travel:1530 mm y-travel:530 mm z-travel:465 mm side by side, right side fixed table X =:925 mm side by side left side 2 axis table X =:780 mm control:Heidenhain TNC 640 tool magazin::122 SK 40 spindle turning speed - stepless:12.000 1/min Spindle Torque:120 Nm power capacity:22 kW Fixed Table Dimensions:920 x 540 mm Table load fixed table:2000 kg Max. parts size on fixed table:900 x 500 x 400 mm Diameter of integrated 2-axis rotary table:650 mm Table load rotary table:500 kg B-axis swivel angle:-90°/+110° ° / deg Max. parts size on rotary table:600 x 500 x 400 mm Max. Parts size over both tables:1500 x 500 x 400 mm internal coolant system feed:70 bar bar weight of the machine ca.:10,5 t dimensions of the machine ca.:3,65 x 2,53 x 2,81 m pendant hand wheel:HR 510 FS Measuring probe for work piece:Blum TC 52 The SpinnerU5 1530 5-axis machine with Heidenhain iTNC 640 control is as new ...

x-travel:800 mm y-travel:950 mm z-travel:1020 mm control:Sinumerik 840D sl MDynamics Operate turning speeds:10.000 1/min Spindle power:26/20 kW max. torque on the spindle:340/262 Nm tool taper:HSK-A 100 tool change unit:120 (2x60) Pos. Pallet changer 2x:630 x 630 mm table load capacity:800 kg weight of the machine ca.:20 t dimensions of the machine ca.:3,3 x 6,15 x 3,2 m 6-axis simultaneous horizontal machining center with controlled swivel-rotary table (A/B-axis), Swivel table can swing overhead (180°), that means the part is hanging down overhead and chips don?t accumulate on pallet, they can fall free into the chip conveyor CNC controlled U-axis enables radial movement of tool for variable spindling diamenter. twin pallet changer 630 x 630 mm 6 hydraulic couplings for pallet fixture clamping with rotary joint in A and B-axis special hydraulic pump for fixture coolant through spindle  ...

x-travel:600 mm y-travel:580 mm z-travel:530 mm distance spindle center to column:630 mm distance spindle center to table:100-600 mm milling feed range:1-10.000 mm/min max. table load:200/100 kg max. tool weight:8 kg positioning accuracy:+/- 0,01 mm :8000/15000 1/min spindle drive:7,5/11,5 /5,5 kW repeating accuracy:+/- 0,008 mm weight of the machine ca.:7,4 / 7,65 t Brand-new CNC vertical machining center with CNC control FANUC or HEIDENHAIN Warranty: 12 months More information can be found in the Appendix.

x-travel:1000 mm y-travel:1150 mm z-travel:700 mm table-size:900 mm table load:1500 kg spindle speeds:10.000 1/min spindle drive:Motorspindel von Cytec CS34-180-A 34&42KW/160&200 Nm spindle taper:A100 HSK T-slots:18mm/7/100 mm milling feed range:20.000 mm/min rapid traverse feeds:X/Y/Z: 24 m/min diameter of tools max.:150 mm workpiece length:300 mm weight of tools max.:20 kg weight of the machine ca.:15 t dimensions of the machine ca.:s. Katalog m CNC controller:Heidenhain iTNC-640 HSCI-Steuerung cnc rotary table:von Cytec; mit Ø900mm; 800 1/min Drehmomenttisch (AS3347) + HSK-T63/100 Spindel & ATC + TNC-640 Fräsdrehzahlregelung B-axis:Fräskopf, 0-180° c-axis:0,001° automatic tool changer:HSK-A/T100; 60 fach Scales:in X/Y/Z von Heidenhain mit Druckluft inner coolant:20

x-travel:630 mm y-travel:560 mm z-travel:560 mm weight of the machine ca.:6,5 t Number of axles:5 St. spindle turning speed range:18.000 U/min numbers of tools in magazin:24 tool taper:SK 40 Round Table B-Axis

x-travel:800 mm y-travel:400 mm z-travel:350 mm total power requirement:44 kW weight of the machine ca.:8,8 t dimensions of the machine ca.:6,1 x 4,1 x 3,3 m tool taper:HSK63 number of spindle speeds:36-12.000 Number of tools:2 x 21 St. rotary table diameter:1340 mm Texte, Bilder, Grafiken, Layout, Strukturen und Algorithmen etc. unterliegen weltweitem Urheberrecht. Unerlaubte Verwendung der Daten, werden sowohl strafrechtlich als auch zivilrechtlich verfolgt. Das ausschließliche Urheber- / Nutzungsrecht dieser Daten wurde nachfolgender Person eingeräumt. Copyright © 2005-2026, Josef Weber. All rights reserved.

x-travel:630 mm y-travel:630 mm z-travel:500 mm number of spindle speeds:0 - 15000 spindle motor:32 kW size of pallet:500 x 500 mm b-axis:36000 x 0,001 ° no. of workpieces in the magazine:61 Stück tool taper:HSK 63 weight of the machine ca.:15 t Single-Spindle Mechanical processing cylinder head VR6

x-travel:1000 mm y-travel:800 mm z-travel:1100 mm weight of the machine ca.:20 t dimensions of the machine ca.:6,80 x 3,0 x 3,20 m Tool bore:SK50 Tool taper:HSK-A 100 turning speed range:45-6.000 U/min size of pallet:630x800 mm change time of pallets:21 sec Mechanical processing of cylinder heads and cylinder crankcases Machines have been in single-shift operation since 2013 Service and maintenance intervals were adhered to

x-travel:1000 mm y-travel:800 mm z-travel:1100 mm weight of the machine ca.:15,2 t Tool bore:SK50 Tool taper:HSK-A 100 turning speed range:45-6.000 U/min size of pallet:630x800 mm change time of pallets:21 sec Mechanical processing of cylinder heads and cylinder crankcases Machines have been in single-shift operation since 2013 Service and maintenance intervals were adhered to

spindle speed::max. 12000 tool taper:HSK 80 . b-axis:360 x 0,001 ° worktool support (A-axis):+40 / -95 ° weight of the machine ca.:25 500 Kgs. x-travel:800 mm y-travel:700 mm z-travel:630 mm dimensions of the machine ca.:6200 x 3000 x 3200 mm pallet size::500 x 500 mm no. of tools in the magazine:61 Nos. Weight approx.:23,5 t Horizontal Machining Center with CNC Control System SIEMENS 840 C in well maintained condition. Single spindle

x-travel:800 mm y-travel:950 mm z-travel:1020 mm weight of the machine ca.:17 t dimensions of the machine ca.:6 x 3 x 3,2 m Diameter of the table:770 mm max. table load:800 kg tool taper:HSK-A63 max. tool length:465 mm no. of tools in magazin:60 spindle turning speed range:12.000 U/min feed power:8 kN kp power capacity:25/35 kW 5 axis G550-1024 HSK A-63 Grob (Bezeichnung G550-1024) 1 spindle Texte, Bilder, Grafiken, Layout, Strukturen und Algorithmen etc. unterliegen weltweitem Urheberrecht. Unerlaubte Verwendung der Daten, werden sowohl strafrechtlich als auch zivilrechtlich verfolgt. Das ausschließliche Urheber- / Nutzungsrecht dieser Daten wurde nachfolgender Person eingeräumt. Copyright © 2005-2026, Josef Weber. All rights reserved.

x-travel:780 mm y-travel:560 mm z-travel:560 mm weight of the machine ca.:10 t Number of axles:5 St. spindle turning speed range:20-12.000 U/min numbers of tools in magazin:30 tool taper:SK 40 surface area:500 x 630 mm Round Table B-Axis Texte, Bilder, Grafiken, Layout, Strukturen und Algorithmen etc. unterliegen weltweitem Urheberrecht. Unerlaubte Verwendung der Daten, werden sowohl strafrechtlich als auch zivilrechtlich verfolgt. Das ausschließliche Urheber- / Nutzungsrecht dieser Daten wurde nachfolgender Person eingeräumt. Copyright © 2005-2026, Josef Weber. All rights reserved.

x-travel:700 mm y-travel:630 mm z-travel:700 mm weight of the machine ca.:15 t dimensions of the machine ca.:4,20 x 2,90 x 2,90 m pallet size::500 x 500 mm tool taper:SK 40 Tool taper:HSK-A 63 turning speed range:10.000 U/min

x-travel:2000 mm y-travel:1600 mm z-travel:1140 mm b-axis:0.0001° x 360° ° number of pallets:4 table surface area:1000 x 1450 mm max. table load:6.000 kg turning speed range:4 - 10000 U/min power capacity at 100 % load:40 kW kW tool taper:HSK100 DIN69893A machine weight ab.:63.000 kg space required L x W X H:12320 x 11000 x 4700 mm incl. 50 x HSK100 tool tapers

x-travel:450 mm y-travel:450 mm z-travel:450 mm weight of the machine ca.:14 t size of pallet:320 x 320 mm number of spindles:2 Double spindle 4-axis machining center Horizontal 4 machine plates Renishaw probe Control Siemens Sinumerik 840D Working space (X / Y / Z): 450x450x450 mm Load pallet / table max .: 300 kg Acceleration: 10 m / s² Rapid traverse: 60 m / min Pallet size: 320 x 320 mm Chip-to-chip time: 2.6 s Workpiece height max .: 700 mm Tool holder: HSK 63 Tool places: 2x 60 Tool spindle: 10,000 rpm, 95 Nm Speed increase to 18,000 rpm Infrared receiver for probe, Make Renishaw Vaf72a0p Tool magazine with 60 places Control panel on the workstation Control panel on the tool installation site Workpiece positioning stations can be rotated manually with hydraulic workpiece clamping 60 bar Pneumatic support control on the workstation Automatic swing gate Extended coolant layer 70 ba ...

x-travel:800/945 mm y-travel:800 mm z-travel:600 mm spindle motor:27 kW spindle turning speed range:10 - 8000 U/min spindle taper ISO:40 c-axis:360.000 x 0,001 table load capacity:600 kg table clamping surface::800 630 mm total power requirement:55 kW weight of the machine ca.:16 t Machine with Heidenhain iTNC 530 CNC control for 5 axis - pendulum operation with turn- swivil table left and fixed table right - tool changer for 30 tools - coolant device, chip conveyor - complete splash housing

x-travel:1660 mm y-travel:760 mm z-travel:660 mm weight of the machine ca.:8700 t dimensions of the machine ca.:4.320 x 3.380 mm distance spindlenose - table min./max.:808 mm distance work spindle /surface of the table:155 - 815 mm Machine height:2850 mm floor space required (w/o switchgear cabinet):4.320 x 3.380 mm spindle motor:11 (10 Minuten) /7,5 (30 Minuten)/ 5,5 (Dauerbetrieb) kW tool taper:SK 40 Spindle RPM:40 - 7.000 (Standard ) / 40 - 10.000 ( Option ) 1/min surface area:2.000 x 760 mm max. table load:1.000 kg feeds X-axis:1 - 5.000 mm/min rapid traverse X-axis:24.000 m/min rapid traverse Y-axis:24.000 feeds Y-axis:1 - 5.000 mm/min feeds Z-axis:1 - 5.000 mm/min rapid traverse Z-axis:20.000 m/min

x-travel:635 mm y-travel:510 mm z-travel:460 mm turning speed range:20 - 10.000 U/min tool taper:SK 40 table clamping surface LxW:790 x 560 mm Machine with glass scales Full safety cabin with sliding doors + interior lighting Height-adjustable machine shoes 3 pcs.

x-travel:1.100 mm y-travel:900 mm z-travel:1.250 mm tool length:750 mm rapid traverse in x-y-z axis:60 feeding capacity X Axis:17.000 daN feed capacity Z - max.:17.000 N spindle taper:SK50 max. workpiece weight:1500 kg revolutions per minute:10.000 U/min pallet table size:630 x 630 mm tool magazin::165x (bis D=125mm), 21x (bis D=225mm), 8x (bis D=350mm total power requirement:37 kW

x-travel:1.250 mm y-travel:880 mm z-travel:800 mm spindle turning speed range:1 - 10.000 U/min high speed spindle taper ISO:50 table-size:1.250 x 1.000 mm max. workpiece weight: 2.000 kg feed speeds infinitely variable:1 - 30.000 mm/min rapid traverse speed:40 m/min weight of the machine ca.:16 t dimensions of the machine ca.:7,2 x 4,4 x 2,9 m

distance spindle /table:min /max 190 / 570 mm distance spindle /table:190 - 570 mm surface area:650 x 300 mm Boring power:in GG 20 40 mm bore capacity in steel:ST 60 32 mm turning speed range::50 - 5000 UpM total power requirement:2,2 kW threading:GG 20 M30 threading::ST 60 M 24 weight of the machine ca.:1400 kg table load:max. 150 kg table height:770 mm traversing speed:max X-, Y- u. W-Achse 5 m/min max. traversing speed:Z-Achse 3 m/min w-axis:380 mm workpiece height max.:495 mm tool changing time:ca. 3 sec x-travel:450 mm y-travel:300 mm z-travel:180 mm workpiece weight:1,5 kg
