machining center used for sale

KOVOSVIT MAS S80i CNC turning center was built by KOVOSVIT MAS a.s. in the Czech Republic. This extremely powerful machine is used for precision hole drilling, threading and turning of cylindrical, conical and spherical surfaces. The offer also includes a wide range of equipment in the form of components from renowned brands, which guarantee excellent repeatability of the manufactured parts over many years of intensive operation. These include, among others, a new tool measuring probe, a hydraulic tailstock and a HEIDENHAIN intelligent CNC control. All this makes the S80i CNC CNC lathe the perfect choice for both unit and small batch production. The total weight of the machine is 6700 kg. Technical specifications of the KOVOSVIT MAS S80i universal lathe - maximum turning diameter above the bed: 680 mm - maximum turning diameter over the slide: 430 mm - maximum bar diameter: 80 mm  ...

DUGARD EAGLE 1000 VMC CNC vertical machining center was built in 2000 in Taiwan by C Dugard Ltd. The machine is used for precision machining of workpieces with a maximum weight of 600 kg. The machining process is performed by means of reliable components that offer the highest quality of manufactured parts for many years of use. Inside the large workspace there is among others a large work table with a length of 1200 mm and a width of 450 mm, a powerful spindle and a 20-position tool magazine. The DUGARD EAGLE 1000 CNC machining center weighs 5800 kg. Technical specifications of the DUGARD EAGLE 1000 VMC CNC milling machine - CNC control: SIEMENS - feed in the X/Y/Z axis: 1020/510/510 mm - feed rate in the X,Y,Z axis: 1-7600 mm/min - rapid traverse in the X/Y/Z axis: 30/30/18 m/min - work table dimensions (L x W): 1200 x 450 mm - maximum workpiece weight: 600 kg - maximum spind ...

- invoersysteem voor vlak- en hoekstaal - met toevoerwagen en materiaalklem - Vacon 110 software CNC-besturing Platstaal gt; maximale lengte: 15 200 mm gt; maximale breedte: 50-500 mm gt; maximale dikte: 5-25 mm Hoekstaal gt; maximale lengte: 15 200 mm gt; maximale breedte/hoogte: 50 x 50 - 200 x 200 mm gt; maximale dikte: 16 mm gt; maximaal gewicht: 750 kg Hydraulisch ponsen VPO 1000 gt; cap: 100 ton gt; perforatiediameter/dikte: 57/15 mm of 32/25 mm gt; 4 ponsunits voor vlak staal gt; 1 ponseenheid voor hoekstaal gt; incl. gereedschap Hydraulische schaar voor vlak staal VPS 2200 gt; cap: 220 ton gt; breedte/dikte: 500/25 mm gt; hoek: +/- 45° Hydraulische hoekschaar voor staal VHS 2400 gt; cap: 240 ton gt; 200 x 200 mm / 16 mm Hydraulische coderingseenheid VNI 1/36 gt; 1 codeerschijf gt; 36 tekens gt; tekenhoogte x diepte: 10 x 1 mm Hydraulisch aggregaat VHA 37 gt; 37 kW - 250 bar

bar capacity 90 mm - 2x12 driven positions turrets - Y axis in upper turret - tail stock - very very well equipped ( 36 driven + 39 fixed tool holders - 30 collets etc.etc.) - Lns Sprint S2 barfeed with front magazine - Siemens 840D Power Line Control - IN PERFECT CONDITION

Key data: 1000 mm, 3000 mm

achine details Stock-No. 1105-04069 Type of machine CNC Turning- and Milling Center Make DOOSAN DAEWOO Type PUMA 700 LM b Year of manufacture 2006 Type of control CNC Storage location FRANCE Country of origin KORREA Delivery time IMMEDIATELY Freight basis EX WORK Price Technical details turning diameter 900 mm turning length 3050 mm control FANUC 21 i TB swing dia. 1030 mm Standard Turning Diameter 750 mm Bar Material Dia. 165 mm Spindle bore 110 mm Travel -X Axis 471 mm Travel -Z AXIS 2100 mm Rapid Travel - Longitudinal/Face 15/ 20 m/min Spindle RPM 3000 1/min spindle drive 45 kW turret stations / rotary tool stations 12 / 6 BMT 85 speed of driven tools 3000 1/min total power requirement 62.2 kVA Weight of the machine approx. 22.2 t dimensions of the machine approx. 6.1 x 2.2 x 2.2 m Accessories Chip conveyor YES Parts and total counter Tool holders  ...

MATEC 30 HV CNC machining center was built in 2001 in Germany by Matec Maschinenbau GmbH. The machine, designed for precision machining of oversized workpieces, is equipped with a number of reliable components with excellent specifications. This includes a tilting work head, a 24-position tool magazine and a chip extraction unit. All this is complemented by the intelligent BOSCH CNC control, in which advanced machining programmes are created in just a few steps. The MATEC CNC vertical machining center weighs approximately 15000 kg. Technical specifications of the MATEC 30 HV CNC milling machine - CNC controller: BOSCH TYP 3 OSA - feed in the X/Y/Z axis: 3000/600/800 mm - maximum spindle rotational speed: 9000 rpm - minimum spindle rotational speed: 20 rpm - spindle drive power: 16 kW - tilting work head - rotation angle of work head: ± 90° every 1° - 24-position tool magazi ...

KITAMURA MYCENTER HX630G CNC machining center was built in 2017 by the Japanese brand Kitamura Machinery Co., Ltd. The machine, designed for precision machining of workpieces with a maximum weight of 1500 kg, was created as a response to the needs of modern business. In order to meet all production requirements, state-of-the-art technical solutions, combined with extensive equipment, guarantee excellent repeatability of the manufactured parts over many years of intensive operation. The machining process is performed fully automatically inside a large working area, which includes a capacious tool magazine and a reliable spindle with a special DCS (Dual Contact Spindle) system. This system ensures optimum spindle rigidity through simultaneous contact between the taper and the flange. Furthermore, the automatic pallet exchange system allows workpieces to be loaded and unloaded simultaneo ...

OKUMA MA-600HII CNC machining center was built in 2012 by the Japanese brand OKUMA Corporation. This highly efficient machine is used for advanced workpiece machining in 4 axes. The machining process is performed fully automatically inside a large working area by means of precision cutting tools and a reliable high-speed spindle. The automatic pallet changing system allows workpieces to be loaded and unloaded simultaneously during machining, reducing machine downtime to a minimum. The extensive equipment also includes, among others, a capacious tool magazine and an intelligent CNC controller with an intuitive interface. The MA-600HII CNC horizontal machining center weighs 24500 kg. Technical specifications of the OKUMA MA-600HII CNC milling machine - CNC controller: OSP-P300MA - number of axes: 4 (X,Y,Z,B) - feed in the X/Y/Z axis: 1000/900/1000 mm - rapid traverse in the X,Y,Z ax ...

12 position upper turret (6 are driven) -10 positionlower turret (5 are driven) - sub spindle - 2 x C axis - equipped with Lns Sprint S2 bar loader with front magazine, fixed and driven tool holders, manuals - Fanuc 18T Control

Control Ultimax 3-4 2 color screens (text + graphics) Travel X/Y/Z 1020/510/610 mm Speed 8000 1/min Tool magazine for 24 Wkz. SK 40 DCF Software

CINCINNATI ARROW 1250 CNC vertical machining center was built in 2001 in the United Kingdom by CINCINNATI MACHINE U.K. LIMITED. The machine, distinguished by its high reliability, productivity and precision, is used for the economic machining of workpieces. The machining process is performed inside a large work space, equipped with, among others, a 21-position tool magazine and a high-speed spindle. Its high-quality design eliminates any vibrations generated during milling, guaranteeing the highest possible stability during even the most intensive challenges. The offered CINCINNATI ARROW 2 1250 CNC machining center has undergone regular maintenance and servicing. The machine is after an spindle overhaul and the replacement of guides and screws in the X and Y axes. The total weight of the machine is 6000 kg. Technical specifications of the CINCINNATI ARROW 1250 CNC milling machine - C ...

Control: OSP-P 300S X-axis: 690 mm Y-axis with stroke: 230 mm Z-axis: 2,045 mm B-axis: up to 225°, positioning in 0.001° Turning length: 2,000 mm Turning diameter: 710 mm Spindle bore: 110 mm Tool holder: HSK 63 Tool magazine: 80-fold Equipment: - Collision avoidance system - Tool monitoring system - Tool measuring device - Tool calibration - Sub-spindle with tailstock function - Renishaw touch probe - Door automation - NC bezel support with bezel SMW SLU-Z 3.2 - ONE touch IGF - Hinged belt conveyor - Main spindle replaced in 2022

:::TECHNICAL SPECIFICATIONS::: CNC Model: Selca CNC Version: S3045 Tool Attachment: ISO 40 Spindle power: 7.5Kw Number of spindle speeds: 8000 Number of tools: 21 X-axis travel: 1000mm Y-axis travel: 400mm Z-axis travel: 450mm Fast feeds for linear axes X Y Z: 24m/min Table dimensions: 1150 x 400mm Table capacity: 700Kg Guides: flat :::D DIMENSIONS AND WEIGHT::: Length: 2320mm Width: 1960mm Height: 2660mm Weight: 7500Kg

Travel X/Y/Z: 5500mm/1200mm/1800mm, milling head indexing: 2.5°, drive power: 28kW, spindle speed: 4000rpm, feed X/Y/Z: 25m/min, table diameter: 1600mm, table speed: 250rpm, max. workpiece weight: 8000kg, panel field dimensions X/Y/Z: 6000mm/2000mm/300mm, machine weight: approx. 16500kg, control: Heidenhain iTNC 530. Workpiece weight: 8000kg, panel field dimensions X/Y/Z: 6000mm/2000mm/300mm, machine weight: approx. 16500kg, control: Heidenhain iTNC 530. Including internal coolant supply and chip conveyor. Documentation available. On-site inspection is possible.

A WMW lead and feed spindle lathe that was overhauled in 1993 and has not been used since then is available. Center width: 1600mm, turning length: 1600mm, turning diameter: 250mm, turning diameter over bed/cross slide: 450mm/250mm, steel holder surface X/Y: 140mm/140mm, steel cross-section: 25mm/25mm. Speed: 2240rpm, spindle bore: 45mm, faceplate diameter: 450mm, quill stroke: 160mm, max. workpiece weight: 800kg/1250kg, max. journal diameter: 60mm. Including taper turning device, coolant device and quadruple steel holder. Documentation available. On-site inspection is possible. The machine was not used after its overhaul in 1993.

A simultaneous turning center Spinner with three turrets and extensive accessories, spare parts and tools is available. Travel X1/X2/X3: 180mm, travel Y1/Y2: +/-45mm, travel Z1/Z3: 704mm, travel Z2/E2: 620mm/720mm, rapid traverse X/Y/Z: 30m/min, acceleration: 0.5g. Spindle 1: Speed: 5000rpm, nose: A6, bore: 65mm, chuck diameter: 210mm, power: 18kW, torque: 115Nm. Spindle 2: Speed: 700rpm, nose diameter: 110mm, bore: 42mm, max. chuck diameter: 140mm, max. chuck jaw weight: 1.25kg, power: 16.6kW, torque: 100Nm. Turret 1/2/3: Turret stations: 3x12, speed: 8000rpm, tool holder: BMT 45, power: 4.3kW, torque: 13.6Nm. Machine dimensions X/Y/Z: approx. 2880mm/2130mm/1990mm, weight: approx. 7500kg, operating hours: 27102h, control: Fanuc 31i. Including loading magazine Top Automazioni, cooling/high pressure system with 80bar, chip conveyor, fire extinguishing system, a comprehensive tool package  ...

Swing diameter over bed/bed slide: 480mm/340mm, turning length: 800mm, center distance: 1000mm, swing diameter in the recess: 540mm, spindle bore: 52mm, speed: 1400rpm. Quill taper: MK4, manual quill adjustment: 160mm, upper part displacement: 10mm. Machine dimensions X/Y/Z: approx. 2600mm/1100mm/1350mm, weight: approx. 2300kg. On-site inspection is possible.

Turning diameter: 200mm, turning length: 400mm, turning diameter: 420mm, bar diameter: 60mm, max. spindle chuck diameter: 160mm, speed: 5000rpm, turret: 2, positions: 2x14, rapid traverse X/Z: 20m/min/30m/min. Machine dimensions X/Y/Z: approx. 7500mm/2100mm/2100mm, weight: approx. 4500kg. Documentation available. On-site inspection is possible.

A complete sheet metal processing center for bending and cutting including automation is available. Documentation available. On-site inspection is possible.

Turning diameter: 420mm, turning length: 820mm, spindle bore: 105mm, speed: 3000rpm, spindle power: 22kW, travel X/Z: 280mm/820mm, tool positions: 10, drive tool speed: 6000rpm. Machine dimensions X/Y/Z: approx. 4400mm/2100mm/2300mm, weight: approx. 6000kg, control: Mitsubishi M-720BM (MAPPS 2), operating hours: 10000h. Including various accessories. The driven tools have never been used, only the Y-axis has run. Measuring arm and ball screw of the Y-axis are as good as new. Documentation available. On-site inspection is possible.

Center height: 180mm, center width: 800mm, turning diameter over bed/face slide: 380mm/200mm, spindle bore: 52mm, speed: 1500rpm, bed width: 330mm, quill stroke: 180mm, quill holder: MK4, machine dimensions X/Y/Z: approx. 2000mm/850mm/1450mm, weight: approx. 1050kg. On-site inspection is possible.

A Gildemeister CNC double-spindle turning and milling center including coolant system and chip conveyor is available. Turning diameter over bed: 640mm, machining diameter: 400mm, center distance: 1930mm, travel X/Z: 550mm/1585mm, travel Y: +/-110mm, B-axis: +/-120° (interpolating), C-axis: 360°. Main spindle: power: 36kW/45kW, speed: 4000rpm, torque: 600Nm-730Nm, bore: 107mm. Milling spindle: Speed: 12000rpm, power: 13.2kW/22kW, torque: 100Nm. Tool places: 60, carrier: turret 12-fold star SW 380, machine dimensions X/Y/Z: approx. 9300mm/4600mm/3100mm, weight: approx. 20000kg, control: Siemens Sinumerik 840D powerline. Documentation available. On-site inspection is possible.

With two machining modules, X-axis: -50 to 725mm, Y-axis: -200 to 300 / -250 to 250mm, rapid traverse X-, Y-, Z-axis: 18/12/30m/min, control: Siemens Sinumerik, temperature range: 5–40°C, power type/frequency: 3 PEN / 50Hz, rated voltage: AC 400V, control voltage: DC 24V, auxiliary voltage: AC 230V, connected load: 102kVA, rated current: 148A, rated current (fast): 148A, fuse (slow): 160A, length: 8000mm, width: 3000mm, height: 4000mm, weight: approx. 17t, operating hours: approx. 80,000h. The machine is fully functional, the ball screw drive (recirculating spindle) of the Z-axis was renewed in 2024 and it has been regularly maintained. Comes with documentation, control cabinet, hydraulic unit, filter elements, and chip conveyor. An on-site inspection is possible.

A Trima CNC gantry machining center is available. Workpiece dimensions X/Y/Z: 2500mm/1100mm/80mm, spindle power: 7.5kW, speed: 24000rpm, tool positions: 10, traversing speed X/Y/Z: 55m/35m/15m/min. Machine dimensions X/Y: approx. 4400mm/2500mm, weight: approx. 3200kg, control: Siemens Sinumerik. The machine has a control defect. The reference run is aborted. Documentation available. On-site inspection is possible.

: M01.43870 frequency: 50 Hz voltage: 400 V : 24 V connected load: 48 kW rated current: 63 A control: Siemens 840 D turning diameter: 250 mm turning length: 100 mm weight of the machine ca.: 7,5 t turning length external: / innen 100 mm workpiece length - min.: 29 mm workpiece length - max.: 100 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

grinding diameter max.: 30 mm regulating wheel width: 12 mm max. width of grinding wheel: mm total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

workpiece diameter: 8-125 mm grinding depth: 130 mm clamping length: 50-1100 mm max. workpiece diameter: 0 mm min. workpiece diameter: 0 mm workpiece length: mm total power requirement: 1 kW weight of the machine ca.: 500 kg dimensions of the machine ca.: m T E C H N I C A (Switzerland) Centre Hole Grinding Machine Model ZSM 1000 Year approx. 1975 Serial No. J 1400 _______________________________________________________ Distance between centres 50 – 1,100 mm Height of centres 145 mm Workpiece Ø 8 – 125 mm Max. centre hole taper Ø 2 – 50 mm Max. centre hole taper angle 60 ° Clamping range of vice 4 – 150 mm Stroke of grinding head 130 mm Stroke of grinding tool on workpiece 0.75 – 5 mm Grinding tool Ø  ...

3 slides 3 revolvers with 12 positions each driven main and subspindle 2 C-axis Y axis, workpiece unloading device, high pressure coolant system with paper filter chip conveyor, Control: Fanuc 310i, Country of origin: Italy, Operating hours: 34.000 | 22.900, Number of spindles: 2, Number of linear axis + C axis: 8+2, Max bar diameter [mm]: 65, Spindle speed [rpm]: 5.000, Spindle motor [kW]: 20, Auto bar loader: Iemca Master 880 P/R, Machine weight approx. [kg]: 9.000

grinding diameter max.: 100 mm regulating wheel width: 200 mm max. width of grinding wheel: 200 mm grinding diameter: 100 mm grinding length: 250 mm feed in: mm working area: mm speed: m/min Bar length: mm total power requirement: 25 kW weight of the machine ca.: 4.500 t dimensions of the machine ca.: m K O E N I G & B A U E R (Germany) Centreless Grinder with Plunge-in Grinding Device Model Multimat 150 - 5 Year approx. 1978 S/Nr. 73 918 _______________________________________________________ Grinding Ø regular/maximal 2 – 50/100 mm Max. length of workpiece for Thru-Feed-grinding 250 mm Max. length of workpiece for plunge-cut grinding 200 mm Grinding wheel size, Ø x width 600 x 200 mm Regulating wheel size, Ø x width 300 x 200 mm Grinding wheel speed, max. 1.450 rpm/35 m/sec. Regulating wh ...

5 axis X-Axis 800 mm Y-Axis 800 mm Z-Axis 600 mm Interference circle diameter 1070 mm Distance Spindle Up to 823,5 mm Machine-Table Load 1000 Kg Maximum rapid travel X/Y/Z at TCP max 75 m/min Cutting-Tool Interface HSK-A63 Motor Spindle Power at CDF 25% max 50kW Engine Spindle Torque at CDF 25% max 187 Nm Machine weight 13000 kgs Wiring diagram: 2526-95-64934955 Resy Filtration system Model : 14-P00449-3 Serial : KBF- 452/500 Erowa pallet changer Model RobotEasy Serial number ERE1364 Year 2014 Weight 1300kgs Hyfra Pedia chillers Model sigma 7-s

We are selling a Haas ST-20 turning center on behalf of a customer. The machine was installed and never used productively., - Control Options, - options package, - high-pressure coolant flow, - accessory package

HAAS VF-1 CNC machining center was built in 2015 in the United States by HAAS AUTOMATION, INC. The machine, designed for unit and small batch production, is the ideal choice for any tool workshop. All this is due to the use of a number of modern components with excellent technical parameters, which guarantee high reliability and precise machining. Workpieces weighing a maximum of 1361 kg are machined inside a large, fully illuminated work area by means of a high-speed spindle and tools taken from a 20-position magazine. The machining process is free of vibration or oscillation, thanks to an extremely stable design made from top-quality steel. All this is complemented by an intelligent CNC control with an intuitive interface. The HAAS VF1 milling center weighs 3539 kg. It is also possible to purchase additional tooling shown in the photos (tool holders, vices, TSCHORN 3D tester, measur ...

Key data: 750 mm, 1524 mm

Control Mazatrol Matrix Max. Rotary Diameter 760 mm Max. turning length 1,524 mm Travel X-axis: 630 mm Y-axis: 230 mm Z-axis: 1,585 mm W-axis: 1,530 mm B-axis -30 to 210° Rapid traverse X/Y/Z/W 50/40/50/30 m/min Main spindle Drive power: 30 kW Max. spindle speed 3,300 rpm C-axis Max. bar passage: 102 mm Sub-spindle Drive power: 26kW Max. spindle speed 4,000 rpm C-axis Milling spindle Drive power: 18.5 kW Max. spindle speed: 12,000 rpm B-axis: 0.0001° Capto C6 Tool magazine / ATC 80 tool positions Max. tool diameter: 90/125 mm Max. tool length: 400 mm Max. tool weight: 10 kg Special equipment Cooling by the spindle High pressure pump 70 bar 20 l/min . PLC with 7 pressure levels Chip conveyor MAYFRAN CONSEP 2000 II 70 bar 20 l/min . PLC with 7 pressure levels Interface for bar feeder Automatic Parts Catcher Synchronized Threading ...

Key data: 660 mm, 1495 mm

Mazatrol Matrix Max. Rotary Diameter 660 mm Max. turning length 1,495 mm Travel X-axis: 580 mm Y-axis: 150 mm Z-axis: 1,545 mm W-axis: 1,490 mm B-axis -30 to 210° Rapid traverse X/Y/Z/W 50/40/50/30 m/min Main spindle Drive power: 22 kW Max. spindle speed 4,600 rpm C-axis Max. bar passage: 65 mm Sub-spindle Drive power: 18.5 kW Max. spindle speed 5,000 rpm C-axis Milling spindle Drive power: 18.5 kW Max. spindle speed: 12,000 rpm B-axis: 0.0001° Capto C6 Tool magazine / ATC 120 tool positions Max. tool diameter: 90/125 mm Max. tool length: 300 mm Max. tool weight: 10 kg lower turret Drum turret 9 tool stations 6 powered tool stations Max. speed: 6,000 rpm Special equipment Mayfran Consep 2000 II Chip Conveyor, Double Switching Filter Preparation IKZ 70 bar 70 bar high pressure pump Milling spindle synchronized threading Cyl ...

Year of construction 2019 Control Celos with Siemens 840D sl Operate including 21.5 ERGOline Control Travel X-axis: 490 mm Y-axis: 250 mm Z-axis: 1,300 mm B-axis: +120° to -120° Max. turning diameter 500 mm Max. turning length 1,200 mm Main spindle ISM102 Drive power: 37/28 kW Max. torque: 700/800 Nm Max. spindle speed: 4,000 rpm Max. bar passage: 104 mm Sub-spindle ISM52 Drive power: 14.5 kW Max. spindle speed: 6,000 rpm Milling spindle Drive power: 22 kW Max. spindle speed 12,000 rpm HSK-63A DIN69893 Tool magazine 80 tool positions Other equipment Interface for robots Glass scales in X, Y and Z axes MP 1.0 – Machine Protection Control Tool probes Workpiece probe, BLUM TC60 Sorting the tools in the magazine Technology cycle for the application of an alternating speed for vibration-critical voltages Chuck rinsing device on the ...

Inv. Num. : 8429 Type: Bluestar 6 Producer: HÜLLER-HILLE Created: 2006 Parameters: Work table length: 630 mm Work table width: 630 mm X-axis travel: 700 mm Y-axis travel: 630 mm Travel Z axis: 700 mm Max. tool diameter: 150 mm Max. tool weight: 10 kg

Control Winmax Travel X/Y/Z 2135 x 865 x 762 mm Spindle speed 12,000 min-1 Tool magazine for 40 Wkz., SK 40 Handwheel Ultimotion IKZ 40bar Probes Renishaw Conveyor

Ergomat TNG 32 + LNS Sprint 552 - Turning Center + Bar Feeder - FANUC 0i-TF CNC control - 60° inclined bed - Cross slides with linear guides - Parts separators - Coolant device -Conveyor - Switch-on time: 645 hours - Processing time: 390 hours - Year of construction 2022 LNS Sprint 552 - Bar Feeder - Rod Ø: 5 - 52 mm - Bar length: 3200 mm - Loading capacity: 11, 9, 8 bars Specifications Main spindle: - Bar passage Ø: 32 mm - Spindle speed max.: 5000 rpm - Collets DIN6343: 171-E A36 - Collets DIN6343: 161-E A25 Workspace: - Workpiece Ø/length: 32 / 75 mm - Travel in X: 300 mm - Travel in Y: 175 mm Cross slide "Gang Type": - Rapid traverse X: 12 m/min - Rapid traverse Z: 20 m/min - Number of tools: 7 - Tool shank Ø: 20 mm - Tool holder 4-point: 12 x 12 mm Coolant system: - Coolant pressure: 6 bar - Tank capacity: 100 l Performance data: - Po ...

Machine Type: Turning Machine Model: Sprint 50 2T Manufacturer: DMG MORI Year of Manufacture: 2017 Specifications: - Spindle Speed (Max): - 1st Spindle: 7000 rpm - 2nd Spindle: 7000 rpm - Machine Weight: 9200 kg Electrical Specifications: - Power: 54 kVA - Current (Max): 135 A - Fuse Rating: 160 A - Voltage: - Main: 400 V ±10% - Auxiliary AC: 230 V - Auxiliary DC: 24 V - Frequency: 50 Hz Accessories/extras: CT-20D Hinge Belt chip extractor 2 pcs Sauter turret head Typ. Grip main spindle SPANNTOP mini 65 Grip counter spindle SPANNTOP mini 52 Unloading system Marposs TT30 tool setting system Artis CTM V6 tool wear and breakage monitoring system LNS Alpha 552 - 4 meter bar feeder Find more here - / Contact us at -

GILDEMEISTER MF twin 65 CNC lathe was built in 2000 in Germany by GILDEMEISTER Drehmaschinen GmbH. This extremely efficient machine is used for precision machining of workpieces with a maximum diameter of 200 mm. The machining process is performed inside a large work space, by means of two spindles and tools taken from two 12-position turrets. This solution maximises production efficiency by enabling simultaneous workpiece machining on both spindles. What’s more, any vibration or oscillation is eliminated by a rigid bed, guaranteeing high process stability even during the most intense challenges. The MF twin 65 CNC turning center, including the control cabinet, weighs approximately 6500 kg. Technical specifications of the GILDEMEISTER MF twin 65 CNC dual-spindle lathe General data - number of axes: 4 (X1,X2,Z1,Z2) - swing over bed: 240 mm - maximum turning diameter: 200 mm - ma ...

ISEL SM Alpha Omega – 5-axis CNC machining center with 2 spindles For sale is a precise and versatile ISEL SM Alpha Omega 5-axis CNC milling machine, built in 05/2015, equipped with two high-frequency spindles. This machine is ideal for applications in medical technology, precision engineering, micromachining, and mold and prototype construction. Specifications: Model: ISEL SM Alpha Omega Year of manufacture: 05/2015 Item number: 274507 SSZ6000 Axes: 5 (X, Y, Z, A, B) Travel: X-axis: 1800 mm Y-axis: 1700 mm Z-axis: 800 mm Spindles: Quantity: 2 high-frequency spindles Speed: up to 60,000 rpm Power: up to 6 kW Tool holder: HSK25 / HSK32 Dimensions (WxDxH): approx. 2800 x 2550 x 2950 mm Weight: approx. 1400 kg Solid steel/granite sandwich construction for high rigidity and vibration damping Highly dynamic linear motors in X and Y axes Turn/swivel  ...

Travel (X / Y / Z) 762 mm / 508 mm / 610 mm Table size 1,020 mm × 510 mm Table load max. 1,000 kg Spindle holder SK 40 (DIN 69871) Spindle speed max. 10,000 min⁻¹ Spindle power 11 kW Tool Stations 24 Stations, Automatic Tool Changer (ATC) Iobjwt Rfwstfb Tpmjic Max. tool weight 7 kg Max. tool length 300 mm Max. tool diameter 80 mm Rapid traverse (X / Y / Z) 24 m/min / 24 m/min / 20 m/min Feeds programmable up to approx. 7,600 mm/min Control HURCO Ultimax 4 Machine weight approx. 4,700 kg Machine dimensions (L × W × H) approx. 3.9 m × 2.4 m × 2.7 m

Center width: 1000mm, turning diameter over bed/crank/trolley: 360mm/510mm/205mm, spindle bore: 42mm, speed: 2100rpm, machine dimensions X/Y/Z: approx. 1950mm/900mm/1350mm, weight: approx. 750kg. On-site inspection is possible.

Year of manufacture 2007 Travel X 1270 mm Travel Y 660 mm Travel Z 610 mm Table size 1500 mm × 660 mm Table load 1300 kg Spindle speed up to 12,000 min⁻¹ Spindle drive approx. 18 kW Tool holder SK 40 Tool Stations 24-Fold Tool Changer Rapid traverse (X/Y) 30 m/min Rapid traverse (Z) 20 m/min Machine weight approx. 9000 kg to 9500 kg Machine dimensions (L×D×H) approx. 3.25 m × 2.35 m × 2.95 m

The machine is in good technical condition, a test run is possible by prior arrangement.

Grinding wheel dimensions (h x w x d x w): Ø 508 x Ø 305 x width 655 mm, Ø min/max to be ground: 5/240 mm, Min/max speed of regulating wheel (rpm): 0/115 rpm, Type of control (cnc/manual): manual, In feed Grinding (auto/manual): manual, Dimensions of the regulating grinding wheel (h x w x d x w): Ø 330 x Ø 203 x width 655 mm, Maximum length to grind in feed grinding: 655 mm, Grinding wheel head motor power: 45 hp, Total power: 60 HP, Length 3.000 mm, Width 1.400 mm, Height 1.600 mm, Weight 11.500 Kg

Ø grinding wheel dimensions (od x id x width): Ø 650 x Ø 304,8 x 500mm, Ø min / max to grinding: 3/200 mm, Regulating wheel width: 500 mm, Regulating wheel speed nº: Infinite, Min / max regulating wheel speed (r.p.m.): 10/255 r.p.m., Dressing (auto / manual): Longitudinal auto, manual penetration of both grinding wheels, Cnc axes nº: 1, Diamond dressing speed: 255 r.p.m., Regulating wheel dimensions (od x id x width): Ø 350 x Ø 203,2 x 500mm, Grinding wheel width: 500 mm, Maximum infeed grinding length: 500 mm, Motor power grinding wheelhead: 55 Kw, Power hydraulic motor: 3 Kw, Total power: 60 Kw, Voltage: 220 / 380V, Long: 2.300 mm, Width: 2.800 mm, Accessories included: Grinding wheel balancer, plongeé rule holders / Grinding wheel balancer, plongeé rule holders., High: 2.100 mm, Weight: 15.000 Kg

Dimensions: 1520x1020x1260mm, Weight: 1550 kg, Grinding wheel gap: 1.5/50mm, Max.width of wheel in feed grinding: 125mm, Working wheel dimensions (od x id x width): 325x175x125mm, Øext.min. working wheel: 220mm, Max. profile depth of the working wheel: 8mm, Driving wheel dimensions (od x id x width): 220x125x125mm, Øext.min. driving wheel: 165mm, Working wheel motor power: 7,5Kw, Driving wheel motor power: 0,75Kw, Angle of inclination of the working grinding head: +/- 5º, Angle of inclination of the drive wheel head: -2/+5º

Ø max working wheel: 508, Ø min. working wheel: 380, Ø inside working wheel: 254 (305), Working wheel width: 205, Ø max. drive grinding wheel: 305, Ø min. drive grinding wheel: 230, Ø inside grinding wheel: 152.4, width of feed wheel: 205, Cutting speed: 30-45-60 m/s, R.p.m. of the driving wheel: 0-300, Diamond speed: 300, working wheel motor: 15 Kw (18Kw), Driving wheel motor: 10.4 Nm, Dimensions WxLxDxH: 2250x3380x2385, Weight: 9000Kg, CNC Brand: SIEMENS, CNC Model: 840 D, Number of CNC axes: 11
