machining center vertical used for sale

An old Stama machining center is available. Tool positions: 10, travel path X/Y/Z: 500mm/380mm/400mm, table dimensions X/Y: 700mm/380mm, tool holder: SK30, speed: 7500rpm, drilling capacity in steel: 30mm, machine dimensions X/Y/Z: approx. 2350mm/2550mm/2750mm, weight: approx. 2500kg, control: Fanuc 6MB. An on-site inspection is possible.

Working field: axis x: 3200 mm, axis y: 944 mm, axis z: 110mm Max programmable speed: axis x: 100 m/min, axis y: 75 m/min, axis z: 15 m/min Drill holder: diameter 10 mm Spindle speeds: 4000 rpm Grooving saw: diameter 120 mm Drill spindles: 24 horizontal spindles in X, 10 vertical spindles in X line Working pressure air pressure: 6 bar Installed power: max 25 kW Capacity of vacuum tools: 40 m?/h CNC: screen: monochromatic 9? Floppy disk unit

x-travel:850 mm y-travel:500 mm z-travel:610 mm rotary table::400 mm spindle turning speed range:12.000 1/min drive capacity - spindle motor:17/10 kW control:HEIDENHAIN iTNC 530 Tool changer:40- fach spindle taper ISO:SK 40 weight of the machine ca.:7,7 t total power requirement:28,5 kW dimensions of the machine ca.:3 x 2.70 x 3,2 m 5-axis simultaneously universal-machining center, NC-rotary-swivelling table dia. 400mm, 3D infrared touchprobe, el. handwheel, chipconveyor, airblast through spindle, internal coolant supply 40bar, flushgun, direct measuring system, approx. 38.000h "machine on", approx. 14.500h "spindle on"

Working area: X 5200 x Y 1260 mm Heading of main spindle: X 5709 mm, Y 1650 mm 8 workpiece consoles Equipment: Drilling unit with 18 spindles, 12 vertical sp?ndles, 6 horizontal spindles (4 in direction X , 2 in direction Y ) Grooving saw Milling motor 11 kW, 20000 rpm max, HSK-F 63 take-up, liquid-cooled, 5-axis controlled Tool changer with 16 positions Laterally positioned changer with 8 positions PC control

x-travel:1250 mm y-travel:880 mm z-travel:800 mm control: Heidenhain TNC 430 tool change unit:60 Pos. Tool bore:SK 50 turning speeds:8000 1/min size of pallet:1000 x 800 mm total power requirement:56 kVA weight of the machine ca.:14,3 t dimensions of the machine ca.:5,5 x 3 x 3,1 m 5-axis machine with controlled universal milling head (B-axis), 2-palett changer incl. 2 palets, 1000 x 800 mm Production package: - internal coolant supply 40 bar with 900l coolant box (2,25 x 1.3 x 2,2m / 950kg), - chipconveyor (4,85 x 1,2 x 1,75m / 600kg), - ROTOCLEAR, - 3D touchprobe RENISHAW MP 10 - 60 pos. ATC SK 50 - el. handwheel - mech. tool-breakage control, accessories (SK 50 toolholders approx. 100.200 h "machine on", approx. 52.200 h "spindle on", last spindle change in 2020

x-travel:700 mm y-travel:700 mm z-travel:700 mm turning speeds:18.000 1/min max. torque on the spindle:110 / 84 Nm tool taper:SK 40 control:HEIDENHAIN iTNC 530 tool change unit:180 fach size of pallet:500 x 500 mm mm max. workpiece weight:600 kg spindle:34 / 28 kW rapid traverse:60 m/min total power requirement:68 kVA weight of the machine ca.:10,5 t dimensions of the machine ca.:9,5 x 7,5 x 3,4 m dimensions for transport:4,3 x 2,4 x 2,6 m horizontal machining center with linear drives,, NC-roundtable, pallet pool RS 10 for totally 12 pallets, monitor for workpiece setting-up device, high pressure coolant through spindle 40bar, internal air blast supply, mode 4, hydraulic clamping 2/4 for workpiece setting-up device and working table, BLUM laser, oilmist suction, 3D touch probe TS 649, tool-breackage control, mechanical, SDS spindle diagnosis system, flush gun, el. handwheel, chipconveyo ...

x-travel:800 mm y-travel:800 mm z-travel:800 mm turning speeds:12.000 1/min tool taper:SK 50 control:SIEMENS 840D shopmill tool change unit:240 fach size of pallet:630 x 630mm mm spindle:52 kW / 430Nm total power requirement:87 kVA weight of the machine ca.:15 t dimensions for transport:4,6 x 2,95 x 2,7 m horizontal machining center, NC-round-table pallet-changer (2 pallets), Internal Coolant Supply 40 bar, prepared for Infrared Touch Probe Renishaw MP 10 without probe, tool-breakage control (mech.), MQL, airblast through spindle, oilmist suction, TRANSMIT funbction, accuracy package, mode 4, glass window right door, incl. FASTEMS FPC 1000 pallet pool for 14 pallets, incl. setting up station, control, and 10 pallets approx. 98.500 h main switch on apprax. 45.500 Spindle hours

x-travel:800 mm y-travel:950 mm z-travel:1020 mm control:HEIDENHAIN iTNC 530 table load capacity:800 kg tool taper:HSK 63 turning speeds:16.000 1/min spindle:35 / 25 kW table-size:770 mm max. torque on the spindle:160 / 223 Nm tool change unit:120 (2x60) Pos. weight of the machine ca.:20 t dimensions of the machine ca.:3,3 x 6,15 x 3,2 m 5-axis simultaneously machining center with controlled swivel-rotary table (A/B-axis), milling head horizontal, internal coolant device (10-80bar), oilmist-suction, electromech. tool-length measuring device GROB, chipconveyor, 3D touch probe, KINEMATICOPT, BLUM laser, el. handwheel, hour meter: approx. 82.000 h "machine on", approx. 48.800 h "spindle on"

x-travel:1.250 mm y-travel:710 mm z-travel:710 mm table surface area:1500 x 800 mm table load capacity:800 kg turning speeds:12000 1/min spindle drive:15 / 10 kW control:MILLPLUS iT HEIDENHAIN spindle taper:SK 40 tool change unit:60 Pos. capacity:44 kVA weight of the machine ca.:10,5 t dimensions of the machine ca.:3,5 x 2,65 x 2,65 m 5 axis simultaneously machining center, B-axis (-120° / +30°), NC-rotary-table integrated in rigid table, direct measuring system, 3D probe infrared, HEIDENHAIN TS 640, internal coolant supply 40 bar, 600l, flushgun, chipconveyor, mode 4, 3D quickset software (no hardware), Higher noise in rush on X-axis and roundtable approx. 48.500 hours "machine on" / approx. 18.000 hours "spindle on"

x-travel:800 mm y-travel:800 mm z-travel:800 mm turning speeds:35-10.000 1/min spindle:37 / 30 kW max. torque on the spindle:525 / 206 Nm Tool bore:BT 50 rapid traverse:60 m/min tool change unit:160 Pos. size of pallet:500 X 500 mm control:MAZATROL 640M Nexus c-axis:0,001° x 360.000 workpiece weight:1.000 kg workpiece height max.:1.000 mm interference area:900 mm 2 pcs. horizontal machining centers (HCN 6000 + HCN 6000-II, 2008), interlinked with pallet pool (16 pallets) MAZAK FMS, 2 pallet changer, chipconveyor, coolant device with internal coolant supply, accessories for both machines: 18 pallets, approx. 300pcs. toolholders, miscellaneous devices for workpiece-clamping...

x-travel:800 mm y-travel:800 mm z-travel:800 mm turning speeds:35-10.000 1/min spindle:37 / 30 kW max. torque on the spindle:525 / 206 Nm Tool bore:BT 50 rapid traverse:60 m/min tool change unit:160 Pos. size of pallet:500 X 500 mm control:MAZATROL 640M Nexus c-axis:0,001° x 360.000 workpiece weight:1.000 kg workpiece height max.:1.000 mm interference area:900 mm 2 pcs. horizontal machining centers (HCN 6000-II + HCN 6000, 2005), interlinked with pallet pool (16 pallets) MAZAK FMS, 2 pallet changer, chipconveyor, coolant device with internal coolant supply,

x-travel:410 mm y-travel:610 mm z-travel:500 mm turning speeds:15000 1/min tool adaptor:SK 40 control:iTNC 530 HEIDENHAIN smart NC table::320 x 320 mm table load:100 kg tool change unit:48 Pos. total power requirement:35 kVA weight of the machine ca.:7,4 t dimensions of the machine ca.:4,15 x 3,8 x 3,28 m 5-axis simultaneously machining center, NC-round-swivelling table, C-axis 360°, B-axis +30/-120°, chipconveyor, 3D touchprobe, internal coolant supply 20bar, el. handwheel, kinematicsopt, meter readings: approx. 9.600h "machine on", approx.3.500h "spindle on"

x-travel:2300 mm y-travel:1200 mm z-travel:600 mm turning speeds:30-10.000 1/min max. torque on the spindle:254 / 159 Nm control:HEIDENHAIN TNC 430 tool taper:SK 40 tool change unit:60 Pos. spindle:40 / 25 kW fixed working table:surface area:1.100 x 1.100 mm rotary table:1.100 x 1.100 mm rapid traverse:30 m/min total power requirement:69 kVA weight of the machine ca.:20 t universal machining center with indexing head (2,5°), NC-rotary table, max. table load 1.500kg, internal coolant supply 30 bar, paper filter, el. handwheel, chipconveyor, automatic doors, flush gun, no touch probe available, approx. 81.400 h main swich on approx. 72.200 h control on approx. 26.700 h program running on machine under power , for functional testing

x-travel:800 mm y-travel:700 mm z-travel:600 mm table load capacity:800 kg control:SIEMENS 840D shopmill turning speeds:12.000 1/min tool adaptor:HSK 63 rapid traverse:50 m/min tool change unit:30 Pos. electr. connected load with add. coolant:56 kVA weight of the machine ca.:9,5 t transport measurements machine:4 x 2,5 x 2,75 m 5 Axis simultaneously machining center, Baxis (NC-head) and NC- rotary-swivelling-table dia 900/630mm, internal cooling device 40 bar, 600l prepared for 3D-touchprobe HEIDENHAIN TS 641 (without touchprobe), prepared for el. handwheel (without handwheel), mode 4, approx. 85.000 h mainswich ON , approx. 55.000 h Spindle ON (last spindle change in nJuly 2021 at approx. 50.000h)

x-travel:8500 mm y-travel:2000 mm z-travel:1500 mm rapid travel x/y/z:25 m/min table-size:10.000 x 1.350 mm table load:max. 5 t/qm universal head:orthogonal 1° x 1° tool taper:SK 50 milling head speed:4.000 1/min power capacity:37 kW max. torque on the spindle:900 Nm internal coolant system feed:15 bar control:HEIDENHAIN iTNC 530 Tool changer:60 Pos. total power requirement:75 KW dimensions of the machine ca.:12,7 x 5,2 x 4,6 m weight of the machine ca.:35 t universal travelling column - universal machining center, orthogonal milling head, water-cooled, with 1° indexing in 2 axis (360 pos. in rear layer, 270 pos. in front layer) 3D touch probe M&H 20.41, dividing wall for 2 table machining, internal air blast, 15bar high pressure pump, prepared for HSC milling heads incl. torque support, moveable operator-cabin/panel, chipconveyor, handwheel HR 410, controlled security fence, miscella ...

x-travel:750 mm y-travel:600 mm z-travel:520 mm table surface area:D 700 x 500 mm turning speeds:30000 1/min tool taper:HSK E50 control:HEIDENHAIN iTNC 530 tool change unit:60 pos. rapid traverse:50 m/min table load capacity - central/maximum:350 kg total power requirement:50 kVA weight of the machine ca.:9 t dimensions of the machine ca.:3,2 x 2,65 x 2,8 m 5-axis simultaneously HSC-machining center, NC-round-swivelling table B-axis 180°, C-axis 360°, chip conveyor, prepared for 3D touchprobe HEIDENHAIN TS 641 (without touchprobe), mode 4, spindle chiller, no internal coolant supply, approx. 124.200 hours "machine on", approx. 60.600 hours "spindle on" in total

x-travel:600 mm y-travel:580 mm z-travel:580 mm numbers of pallets:2 pallet size::400 x 400 mm max. workpiece weight:400 kg spindle taper ISO:40 spindle speeds::35 - 12000 feed speeds:1 - 50000 mm/min rapid speed:50 m/min total power requirement:25 kW weight of the machine ca.:12 t dimensions of the machine ca.:3,6 x 3,6 x 2,9 m with CNC SEICOS 16 M ( FANUC base ) autom. toolchanger 61-pockets pallet indexing 1° chip conveyor and coolant attachment exhauster clamping cube and diverse toolholders

x-travel:2200 mm y-travel:2200 mm z-travel:1400 mm spindle taper ISO:50 spindle diameter in front bearing:110 mm spindle turning speed range:45 - 6000 U/min pallet table size:1000 x 1250 mm pallet worktable capacity:6000 kg feed range:1 - 60000 rapid traverse:60 m/min spindle drive motor:27 kW dimensions of the machine ca.:15 x 8,5 x 5,7 m total power requirement:133 kVA weight of the machine ca.:50 t Machine with SIEMENS 840 D control - full B-axis - palette changer for 3 palettes - tool changer for 244 tools - coolant through spindle - max. workpiece swing 2200 mm

x-travel:1800 mm y-travel:1600 mm z-travel:1400 mm B-axis (table):360° size of pallet:1000 x 1250 mm workpiece swing dia.:2100 mm workpiece weight:3500 kg spindle taper ISO:50 spindle drive motor:37 kW spindle turning speed range:25 - 10000 U/min feed range:40/50 m/min rapid power traverse circular:10 U/min total power requirement:90 kVA weight of the machine ca.:43 t dimensions of the machine ca.:11 x 9 x 4,5 m Machine with SIemens 840 D control for 4 axis - full B-axis - palette changer - tool changer for 150 tools - coolant device with coolant through spindle - chip conveyor

x-travel:630 mm y-travel:630 mm z-travel:630 mm pallet size::400 x 500 mm spindle taper::HSK 63 spindle turning speed - stepless:10 - 16000 U/min total power requirement:55 kW weight of the machine ca.:11 t Machine with SIEMENS 840 D control for 4 axis - digital drives - palette changer 4-fold - tool changer 160-fold - coolant device with coolant through spindle - full B-axis - chip conveyor - hydr. workpiece clamping

x-travel:1100 mm y-travel:900 mm z-travel:1250 mm b-axis:360 000 x 0,001 ° milling head speed:1 - 10000 U/min spindle taper: ISO:50 rapid traverse:60 m/min pallet size::630 x 630 total power requirement:37 kW weight of the machine ca.:25 t with CNC control SIEMENS 840 D autom. toolchanger 165 pockets twin pallets 630 x 630 mm max. pallet load 1500 kg through spindle coolant chip conveyor and coolant attachment make KNOLL

Technical data Note: There was no original machine documentation. To the best of our knowledge, all the following technical data were partially read from the nameplate and taken from publicly accessible online sources. Manufacturer: SW (Swabian Machine Tools) / EMAG Type: BAS 03-12 Year of Make: 2008 Serial Number: 1820031 Machine Type: CNC Universal Machining Center Control: Siemens Sinumerik 840D Powerline Operating voltage: 3/PE 400 V, 50 Hz Rated current: 85 A Fuse: 125 A Pneumatic pressure: 6.0 bar Air consumption: approx. 0.3 Nm³ Machine weight: approx. 8,000 kg Configuration Siemens CNC control Double station / multi-sided machining Automatic tool changer Chip conveyor (KNOLL) Cooling lubricant and filter system (KNOLL) Full fairing Suitable for series production

Technical data Note: There was no original machine documentation. To the best of our knowledge, all the following technical data were partially read from the nameplate and taken from publicly accessible online sources. Manufacturer: SW (Swabian Machine Tools) / EMAG Type: BAS 03-12 Year of Make: 2003 Serial number: 182.012 Machine Type: CNC Universal Machining Center Operating voltage: 3/PE AC 400 V / 50 Hz Spindle power: 14.5 kW Rated current: 85 A Connected load: 60 kVA Configuration Double station / multi-sided machining Automatic tool changer Chip conveyor / filter system Full fairing Integrated control cabinet

Sold with various tools and documentation. Technical Information Main training Maximum speed: 9,000 rpm Motor: AC Servo Motor 100% ED engine power: 4.96 kW Engine power at 40% ED: 6.94 kW Continuously programmable speed: 20 – 9,000 rpm Torque/power diagram Speed range: 20 – 9,000 rpm Axis drive AC servo motors for X, Y, Z axes Programmable feed rate: up to 10,000 mm/min Input Unit: 0.01 mm Fast (fast) speed: 12 m/min Measurement system X, Y, Z axis resolution: 0.001 mm Position Tolerance (Direct Measurement): 0.010 mm Work Area X-axis travel: 500 mm Y-axis travel: 400 mm Z-axis travel: 400 mm Work table Round table with swivel axis Clamping surface: Ø 700 x 500 mm T-slot spacing: 63 mm T-Slot Width: 14 H7 Centering bore: Ø 30 H7 Rotation range: 360° Table lock ...

Technical data Manufacturer: Hurco Model: VMX 24 t Type: CNC Vertical Machining Center X/Y/Z: 610 / 510 / 610 mm Table size: 760 x 510 mm Table load: 1000 kg Spindle holder: SK 40 Speed: 10 – 12,000 rpm⁻¹ Power: 7.5 kW Torque: 95 Nm Feed: up to 11,400 mm/min Rapid traverse: 35/35/30 m/min Tool Positions: 24 Max. tool weight: 7 kg Max. tool length: 300 mm Positioning Accuracy: ±0.01mm Repeatability: ±0.005 mm Coolant tank: 265 l Dimensions: 3940 x 4000 x 2715 mm Weight: approx. 4900 kg Configuration Machine bed: Cast iron Guided tours: Ball Linear Guides Tool Changer: Drum magazine Measuring system: Photoelectric Electrical connection: 400 V / 23 kVA Compressed air: 6 bar

Technical data Note: There was no original machine documentation. To the best of our knowledge, all the following technical data were partially read from the nameplate and taken from publicly accessible online sources. Manufacturer: SW (Swabian Machine Tools) / EMAG Type: BAS 03-12 SC3 Year of Make: 2007 Serial Number: 1820027 Machine Type: CNC Universal Machining Center Control: Siemens Sinumerik 840D Powerline Operating voltage: 3/PE 400 V, 50 Hz Rated current: 85 A Fuse: 125 A Pneumatic pressure: 6.0 bar Air consumption: approx. 0.3 Nm³ Configuration Siemens CNC control Automatic tool changer Double station / multi-sided machining Chip conveyor Cooling lubricant system Full fairing Control cabinet

CNC control: Heidenhain TNC 530 Machine 5 simultaneous axes Strokes: X = 730 mm, Y = 560 mm, Z = 560 mm Spindle speed: up to 12,000 rpm Cone: SK40 Feeds: 20 – 20,000 mm/min Fast feeds: 30 m/min Table: 1000 x 600 mm Max load table: 800 kg Tool changer: 24 / 30 positions Machine hours≈ 31,481 h Spindle hours≈ 25,087 h Lots sold as is, unchecked, without tools or tool holders.

CNC Bar Machining Center for Aluminum, Machine No. 6100013187, control Beckhoff C6140 renewed in 2020, infeed of extrusion profile magazine length max. approx. 6000 mm, machining units (drilling / milling: vertical top 1 piece / vertical bottom 4 pieces / horizontal front 1 piece / horizontal rear 1 piece) and (sawing 3 pieces: 45 / 90 / 45 degrees), outfeed belt max. approx. 2700 mm, chip conveyor belt (The article is in condition as existing and unchecked. The article is sold from the foundation and without content/material! For the dismantling and loading of the item, there are no pallets, other packaging material available on site and the buyer must rent a forklift, tank rollers, machine jacks, etc. at his own expense if necessary! Mediation of dismantling and loading possible. Contact: Dejan Ducic / dejan.ducic@surplex.com Auction-ID: A7-45878-14

CNC Bar Machining Center for Aluminum, Machine No. 1310031121, machining length max. approx. 7200 mm, tool turret 8-fold, spindle power max. approx. 5.5 KW, angle head saw unit, angle head drilling/milling horizontal 2 pieces, drilling/milling vertical 5 pieces, brackets 8 pieces, material tensioner 8 pieces, control Ferrocontrol (The article is in its condition as existing and unchecked. The article is sold from the foundation and without content/material! For the dismantling and loading of the item, there are no pallets, other packaging material available on site and the buyer must rent a forklift, tank rollers, machine jacks, etc. at his own expense if necessary! Attention: The Elumatec CNC bar machining center stands on a pedestal with a mesh floor. This area was the former ramp area. The mesh floor must not be driven on with a forklift. Important, bring drivable plates and tank roll ...

Travel X/Y/Z: 1600mm/400mm/350mm, quill stroke: 350mm, max. workpiece weight: 2100kg, table dimensions X/Y: 2100mm/430mm, table height: 908mm, tool positions: 78, tool holder: SK40, max. torque: 70Nm, rapid traverse: 30m/min, feed force: 7kN. Machine dimensions X/Y/Z: approx. 4700mm/2950mm/2700mm, weight: approx. 9300kg, control: Siemens 840C. The spindle of the machine must be overhauled and was removed as well. Documentation available. An on-site inspection is possible.

Technical data Note: There was no original machine documentation. To the best of our knowledge, all the following technical data were partially read from the nameplate and taken from publicly accessible online sources. Manufacturer: CHIRON Type: FZ 08 B/W Year of Make: 2000 Machine Type: CNC Vertical Machining Center Control: Siemens Sinumerik Operating voltage: 3/N/PE 400 V Frequency: 50/60 Hz Control voltage: 230/24 V Connected load: approx. 21 kVA Rated current: approx. 35 A Configuration Double clamping system / pendulum operation 2 clamping stations NC sub-unit Peiseler AWUP 100 Automatic tool changer Cooling lubricant system Extraction system Full fairing Compact design for series production Auction-ID: A7-46048-9

Technical data Note: There was no original machine documentation. To the best of our knowledge, all the following technical data were partially read from the nameplate and taken from publicly accessible online sources. Manufacturer: SW (Swabian Machine Tools) / EMAG Type: BAS 03-12 Year of Make: 2003 Serial number: 182.012 Machine Type: CNC Universal Machining Center Operating voltage: 3/PE AC 400 V / 50 Hz Spindle power: 14.5 kW Rated current: 85 A Connected load: 60 kVA Configuration Double station / multi-sided machining Automatic tool changer Chip conveyor / filter system Full fairing Integrated control cabinet Auction-ID: A7-46048-7

Technical data Note: There was no original machine documentation. To the best of our knowledge, all the following technical data were partially read from the nameplate and taken from publicly accessible online sources. Manufacturer: SW (Swabian Machine Tools) / EMAG Type: BAS 03-12 Year of Make: 2008 Serial Number: 1820031 Machine Type: CNC Universal Machining Center Control: Siemens Sinumerik 840D Powerline Operating voltage: 3/PE 400 V, 50 Hz Rated current: 85 A Fuse: 125 A Pneumatic pressure: 6.0 bar Air consumption: approx. 0.3 Nm³ Machine weight: approx. 8,000 kg Configuration Siemens CNC control Double station / multi-sided machining Automatic tool changer Chip conveyor (KNOLL) Cooling lubricant and filter system (KNOLL) Full fairing Suitable for series production Auction-ID: A7-46048-6

Weinig Unicontrol 10 – CNC window production system incl. tool package For sale is a professional Weinig Unicontrol 10 CNC window production machine, designed for the complete machining of window scantlings – including cross-cut saws, tenon milling, profile unit and automatic feed system. The machine is equipped with several milling spindles, a sawing unit and a wide range of accessories, including high-quality tool sets. (including slitting and milling tools, complete set is suitable for 68 mm large pieces of wood and a Euro fold) The condition is good for its age, the machine was in use until the end. Ideal for timber construction companies or carpenters with their own window production. Auction-ID: 03A-BWU-3

LID MAHO DMU 125 T hi-dyn 3-axis CNC universal machining center Control: Heidenhain MillPlus Year of Make: 2002 Powerful and robust 3-axis machining center from DECKEL MAHO. Ideal for complex milling operations in tool, mould and machine construction. Travels • X-travel: 1,250 mm • Y-travel: 880 mm • Z-travel: 800 mm Main spindle • Speed range up to 18,000 rpm⁻¹ • Drive power: 15 / 10 kW • Max. torque: 500 Nm • Tool holder: SK 40 Work table • Table clamping surface: 1,500 × 1,050 mm • Max. table load: 2,500 kg • Number of T-slots: 10 • T-slot width: 18 H7 mm • T-slot spacing: 100 mm Tool Changer • 30 tool positions • Max. tool diameter: 80 mm • 160 mm with free adjacent position • Max. tool length: 315 mm • Max. tool weight: 8 kg • Max. total weight in the magazine: 100 kg Feeds • Rapid traverse  ...

Technical data Note: There was no original machine documentation. To the best of our knowledge, all the following technical data were partially read from the nameplate and taken from publicly accessible online sources. Manufacturer: SW (Swabian Machine Tools) / EMAG Type: BAS 03-12 SC3 Year of Make: 2007 Serial Number: 1820027 Machine Type: CNC Universal Machining Center Control: Siemens Sinumerik 840D Powerline Operating voltage: 3/PE 400 V, 50 Hz Rated current: 85 A Fuse: 125 A Pneumatic pressure: 6.0 bar Air consumption: approx. 0.3 Nm³ Configuration Siemens CNC control Automatic tool changer Double station / multi-sided machining Chip conveyor Cooling lubricant system Full fairing Control cabinet Auction-ID: A7-46048-2

Table clamping surface: 2 x 350 x 300 mm traverse path x/y/z: 700/300/250 mm spindle retainer: BT 30 ISA kl. / gr. Table/spindle distance: 450 mm spindle speeds: 6-6000 rpm number of tool stations: 10 pieces feeds: 5-10000 mm / min rapid traverse: x & y/z 25/20 m / min spindle drive: 3,1/4,1 kW Electr. Supply: 400 V kW weight: 2600 kg

The vertical milling center FADAL VMC 2216 FX was manufactured in 2007 by the FADAL concern in the USA. The machine is equipped with FANUC Oi-MC numerical control. The milling machine can process workpieces weighing up to 450 kilograms. Machine travels in the X, Y, Z axes are 550 mm, 400 mm and 500 mm, respectively. The spindle revolutions of the CNC milling machine reach 8000 rpm. The center has a warehouse for 21 tools. Perfect for working with single details as well as for larger-scale processing. Technical data of the FADAL VMC 2216 FX machining center - CNC control: FANUC Oi-MC - table length: 406 mm - table width: 990 mm - maximum weight of the workpiece: 450 kg - X axis travel: 550 mm - Y axis travel: 400 mm - Z axis travel: 500 mm - maximum spindle speed: 8000 rpm - tool magazine: 21 - handle: SK 40 - spindle motor power: 11.2 kW - power demand: 35 kVA - power o ...

The vertical milling center FADAL VMC 15XTL was manufactured in 2007 in the United States by the FADAL brand. The machining center is digitally controlled by Fadal. It has a table size of 870 x 400 mm. The milling machine is designed for processing materials weighing up to 340 kg. It is equipped with a magazine for 21 tools. The spindle speed of the machining center, on the other hand, reaches 7500 rpm. Technical parameters of the FADAL VMC 15XTL CNC milling machine - CNC control: Fadal - working table length: 400 mm - working table width: 870 mm - maximum table load (evenly distributed): 340 kg - number of tools in the magazine: 21 pcs. - spindle drive power: 5.6 kW - maximum rotary speed of the vertical spindle: 7500 1 / min. - minimum distance between the spindle and the table: 101.6 mm - maximum distance between the spindle and the table: 609.6 mm - travel length in th ...

MODEL: VERSAMATIC 400 TYPE: TV-MO SERIAL NUMBER: VS4 166 YEAR OF BUILD: 1995 CNC: HEIDENHAIN

FZ15KS HIGH SPEED 4 axis vertical machining center X: 550mm Y: 400mm Z: 360mm 4th axis original Peiseler CNC Siemens 840D Table surface 1050 x 450mm Toolchanger 48 posts ISO 40 Spindle speeds up to 12000 1/min with 4th axis Renishaw broken tool detector Coolant through spindle swarf conveyor Can be inspected under power in our warehouse. Mimu machine tools (Italy)

Table size: 1000 x 490 mm traverse path x/y/z: 800/510/500 mm spindle retainer: ISO 40 ISA kl. / gr. Table/spindle distance: 120/620 mm spindle speeds: 40-6000 rpm number of tool stations: 22 pieces feeds: x/y 1-3200 / z 1-2000 mm / min rapid traverse: x/y 1-3.2, z 1-2 m / min. Supply: 380 V, 19 kW space: 2850 x 2150 x 2600 mm weight: 3800 kg

Control Siemens 828 D Travel X/Y/Z 850/550/550 mm Speed 8000 rpm Tool magazine for 24 tools BT40 Table size 950x550 mm

Table clamping area: 300 x 500 mm Travel x/y/z: 420/300/250 mm Spindle holder: BT 30 ISA small/gr. distance table/spindle: Spindle speeds: approx. 10 - 10000 rpm Feeds: approx. 5 - 10000 mm/min Rapid speed: x u. y/z 25/20 m/min Spindle drive: 7 kW electr. Connection: 400 V, approx. 9 kVA kW Space requirement: 2650 x 1400 x 2450 mm Weight: approx. 2800 kg

OKUMA MX 45 VAE TECHNICAL SPECIFICATIONS CNC model Okuma OSP Cnc version OSP 700 M Tool mount BT 40 Spindle power 11Kw Kw Number of Spindle Revolutions 7000 Tool number 30 X-axis travel 762 mm Y-axis travel 460 mm Z-axis travel 450 mm Rapid advances linear axes X Y Z 30 30 24 m/min Table dimensions 1000x460 mm Roller guides High cooling pressure Pressure value 15 bar System with external tank with filter yes Dredging chip evacuator

Vertical machining center Chiron FZ08W :::SPECIFICATIONS::: CNC Model: Fanuc CNC version: 21M Tool connection: HSK 32 Spindle power: 3,7Kw Number of spindle revolutions: 15000 Number of tools: 12 X Axis Stroke: 300mm Y Axis Stroke: 250mm Z Axis Stroke: 250mm Rapid feeds linear axes X Y Z: 40 40 60m/min Guides: roller Pallet change: yes Pallet size: 550 x 300mm Maximum load allowed: 200Kg Rotopallet: yes Chip evacuator: carpet :::D IMENSIONS AND WEIGHT::: Length: 2600mm Width: 1400mm Height: 2100mm Weight: 2200Kg

Ref. -No.: 10359 Manufacturer: BRINKMANN Year of construction: 2005 Type of control: CNC Storage location: Halberstadt Country of origin: Deutschland Tool holder type: Sauter Werkzeugrevolver Operating hours: 45000 Hours Further information: Hinged chip conveyor Coolant cleaning with 2 pumps Cooling system 1x jaw chuck without cooling mist exhaust system

Key data: 1000 mm, 500 mm, 500 mm

Inv. Num. : 5515 Type: VOC 1000 Produzent: INTOS Erzeugt: 2003 Parametern: Steuerungssystem: Siemens 810D Arbeitstischlänge: 1100 mm Arbeitstischbreite: 500 mm Anzahl der Stapelpositionen: 20 Drehzahl: 8000 1/min Verfahrwege X-Achse: 1000 mm Verfahrwege Y-Achse: 500 mm Verfahrwege Z-Achse: 500 cm Spindelleistung: 25 kVA Kegel: SK 40 Maschinengewicht: 4619 kg Ausstattung: Späneförderer Verfügbarkeit: April 2022 2022: GO Spindel

Key data: 1000 mm, 500 mm, 500 mm

Inv. Num. : 6776 Type: VOC 1000 Produzent: INTOS Erzeugt: 2003 Parametern: Steuerungssystem: SIEMENS Sinumerik Arbeitstischlänge: 1100 mm Arbeitstischbreite: 500 mm Maximale Drehzahl der Spindel: 8000 1/min Verfahrwege X-Achse: 1000 mm Verfahrwege Y-Achse: 500 mm Verfahrwege Z-Achse: 500 mm Spindelleistung: 25 kVA Kegel: SK 40 Anzahl der Stapelpositionen: 20 Stücke Maschinengewicht: 4619 kg

Key data: 1020 mm, 510 mm, 610 mm

Inv. Num. : 6222 Type: BMC 4020 Producer: HURCO Created: 2000 Parameters: Control system: UNIMAX Operating hours: 59,600 h Work table length: 1220 mm Work table width: 510 mm Minimum vertical spindle speed: 80 1/min Maximum vertical spindle speed: 8000 1/min X-axis travel: 1020 mm Y-axis travel: 510 mm Z-axis travel: 610 mm Spindle power: 15 kW Maximum tool weight: 682 kg Max. tool weight: 7 kg Machine height: 2670 mm Machine length: 3350 mm Machine width: 2320 mm Machine weight: 5600 kg Equipment: Tool clamping 2015: Spindle change
