m 520 used for sale

Minidose packing machine Made in Spain for small dose of sauces, olive oil, powder, hot caramel. The machine is new one and can be prepared for any kind of liquid, powder, granulate. PLC and screen. Electric photocell. coding machine. Further information please contact

Maja RVE 1500 S ice generator, performance aprox. 1500 kg / 24h, space-saving design, ice machine with silo ITS 1350-60, silo capacity approx. 612 kg, Maximum capacity including trollies 792 kg, simple handling, year of construction approx. 2002. The machine is currently in the refurbishment and can be tested in Koblenz, Germany.

Qty. 1 Second-hand skin pass mill Mfc.: Mannesmann Demag Sack Built: 1980’s Modernised in 1986 & 1993 Type: Duo Cold Rolling Mill – Non-Rev. Dia. 330 x 500 mm Material: Carbon steel, cold rolled and annealed Strip width: 80 - 470 mm Thickness entry: 4.0 mm Exit: 0.2 mm Decoiler Modernised in 1986 ID: 400 with segments 500 & 600 mm Spreading range: 370 – 420 mm Strip tension: 1300 – 65 daN Braking system: Generator Braking torque: max. 1300 daNm De-coiling speed: 2.5 m/sec. Coil cross section: 20 – 1880 mm² Coil weight per mm strip width max.: 10 kg Coil weight: 5.0 T Coil ID: 400 & 500 mm Coil OD: 600 – 1400 mm Roll dia.: 300 – 330 mm Roll length: 500 mm Roll force: 1850 – 2400 kN Min. roll force: 150 kN Hydraulic roll adjustment Adjustment stroke: 80 mm Adjustment speed: 1 – 3 mm/sec. Rolling speed: 2.5 m/sec. (150 m/min.) PLC system: ...

The injection blow molding machine VICTOR MACHINERY MSZ 30 for the production of bottles was built in 2015. Technical parameters : - screw diameter: 40 mm - screw L / D: 22: 1 - injection weight (HDPE): 190 g - maximum speed of the screw: 10-225 rpm. - heating power: 8.3 kW - injection clamping force: 292 kN - blow clamping force: 46.7 kN - maximum plate size (L x W): 400 × 270 mm - minimum mold thickness (H): 180 mm - mold heating capacity: 3 kW - opening: 220 mm - drying cycle: 3.5 sec. - engine power: 15 kW - hydraulic pressure: 15 MPa - suitable bottle range: 3-800 ml - maximum bottle height: ≤190 mm - maximum bottle diameter: ≤100 mm - minimum air pressure: 1MPa - compressed air discharge rate: ≥0.7 M3 / mm - water flow: 3 M3 / h - total rated power with mold heating: 26.3 kW - dimensions (L x W x H): 3.26 x 1.2 x 2.2 m - net weight: 4 tons

New machines: Chocolate tank, dissolving agitators, Temperature control machines, chocolate pumps. Various sizes and services, stainless steel, very good quality. We are a sales and service partner for MASSA in German-speaking countries.

1 piece NAUTA mixer MBX 40-R -Volume approx. 3.200 litre - bulk density CA. 0, 7 kg / l -Gearbox reconditioned vintage cameras -Swing arm mild steel Virgin -Container made of stainless steel V2A new products -Mixing screw stainless steel V2A new products -Spout pneumatically driven new product -Drive motors 5, 5kW & 0.55 of kW Virgin

1 piece NAUTA mixer MBX 50-R -Volume approx. 4.000 litre - bulk density CA. 0, 6 kg / l -Gearbox reconditioned vintage cameras -Swing arm mild steel Virgin -Container made of stainless steel V2A new products -Mixing screw stainless steel V2A new products -Spout pneumatically driven new product -Drive motors 5, 5kW & 0.55 of kW Virgin

MADO MEW 620 Automatic Grinder, performance 1400kg/h, bowl capacity 35kg, stainless steel construction, Unger Cutting System reduces handling and minimizes heat rise. You are very welcome to inspect and test the machine in our facility in Koblenz, Germany.

MAZAK laser cutting machine STX510 MKIII 4kW TOP CONDITION - LIKE NEW - ONLY 700 RUNNING HOURS year: 2012 refurbished, MAZAK lasercutting machine with 2500W table size: 3000mm x 1500mm machine dimension 2,9m x 7,3m chip conveyor LAN / USB connection automatic nozzle change fast piercing in heavy materials piercing sensor plasma sensor for stainless steel cutting burning sensor for mild stelle cutting full covered machine table FE: 22mm VA: 15mm ALMG: 10mm plastics possible to cut incl. software incl. exhauster option: warranty, setup, training option: fully automatic loading/unloading CELL system

Multivac double sided labelling machine: Type: MR425 Year of production: 2005 Serial number: 23932/05 2 label dispensers type MR411 attached. One dispensers labels from the top down and the other dispenser labels from the side. It can put labels on up to 200 mm in height. Dimensions: 2.900mm x 1.600mm & 2.100mm (LxWxH) Very high capacity. Condition: good

TOP STATE - OVERHAUL IN 2016! Year of construction: 2001 2D table format: 2500 x 1250 3D Max processing size: 900 mm x 2150 mm x 300 mm Power: 2000W Control: FANUC incl. cooler incl. 2D programming software + chamfer module + tube/profile module incl. training incl. commissioning incl. quick penetration incl. ball roller table with 3D cutting head incl. CNC tube axle tube and profile up to 160 mm diameter plates, chamfering 3D molded parts, tubes and profiles FE: up to 15mm Oxide-free VA: up to 8mm designed for high pressure cutting up to 20 bar no foundation required! Optional automatic loading and unloading by Mazak FMS48 is available always regularly serviced with warranty / commissioning / training

Table length: 0 mm Table width: 0 mm Longitudinal X: 0 mm Cross Y: 0 mm Vertical Z: 0 mm Positions ATC: 0   Positions APC: 0   CNC Brand: 0 CNC Model: 0 Control: HEIDENHAIN TNC 426/430 Technical data Number of axis total: 3 Table length: 900 mm Table width: 600 mm Longitudinal travel (X-axis): 710 mm Transversal travel (y-axis): 550 mm Vertical travel (z axis): 500 mm Table load max.: 1600 kg Tool changer: Number of tools: 30 Tool diameter: 90 mm Diameter with free adjacent pockets: 140 mm Tool lenght: 300 mm Max. tool-weight: 8 kg Time of tool changing: 5 sec Spindle nose: ISO: B40 Spindle speeds: from: 100 rpm up to: 12000 rpm Feeds: stepless longitudinal from: 1 mm/min up to: 15000 mm/min transversal from: 1 mm/min up to: 15000 mm/min vertical from: 1 mm/min up to: 1 mm/min Feed range: 10000 mm/min Rapid traverse: long.: 30 m/min Rapid traverse: transversal: 30 m/min Rapid traver ...

Pallet length: 0 mm Pallet width: 0 mm Longitudinal X: 0 mm Cross Y: 0 mm Vertical Z: 0 mm Number of pallets: 0   Positions ATC: 0   CNC Brand: 0 CNC Model: 0 Control: HEIDENHAIN TNC 640 Technical data Number of axis simultaneous: 5 Rotary table:diameter: 150 mm Table load max.: 25 kg Longitudinal travel (X-axis): 400 mm Transversal travel (y-axis): 200 mm Vertical travel (z axis): 385 mm B axis swivelling range: -110 / +30 ° Table speeds: stepless up to: 4000 rpm Holding torque of the table: 400 Nm Tool changer: Number of tools: 96 Tool diameter max.: 50 mm Tool lenght: 130 mm Max. tool-weight: 1 kg Time of tool changing: 0.8 sec Average chip-to-chip time: 3 sec Spindle nose: HSK: E40 Spindle speeds: stepless up to: 42000 rpm Rapid traverse:: 60 m/min Acceleration: 10 m/s Air connect: 6 bar Voltage 50 Hz 3x: 400 Volt Spindle power: 10 / 15 kW Torque max.: 8 / 12 Nm Machine´s w ...

Table length: 0 mm Table width: 0 mm Longitudinal X: 0 mm Cross Y: 0 mm Vertical Z: 0 mm Positions ATC: 0   Positions APC: 0   CNC Brand: 0 CNC Model: 0 Control: HEIDENHAIN iTNC 426 / 430 Operating hours: 24453 Technical data Number of axis total: 3 Number of spindles: 1 Table length: 1050 mm Table width: 590 mm Number of T-channels: 8 Distance of the T-slots: 63 mm T-channel width: 14H7 mm Table load max.: 400 kg Longitudinal travel (X-axis): 800 mm Transversal travel (y-axis): 450 mm Vertical travel (z axis): 450 mm Tool changer:: TC 30 Tool diameter: 90 mm Diameter with free adjacent pockets: 110 mm Tool lenght: 250 mm Max. tool-weight: 6 kg Time of tool changing: 5 sec Average chip-to-chip time: 7 sec Spindle nose: HSK-A: 63 DIN 69893 Spindle speeds: stepless from: 100 rpm up to: 20000 rpm Feed range: 1500 mm/min Rapid traverse:: 22 m/min Air connect: 6 - 7 bar Voltage 50 Hz  ...

Turning diameter: 0 mm Turning length: 0 mm Turret positions: 0 Positions ATC: 0   Number controlled axis: 0   CNC Brand: 0 CNC Model: 0 Control: FANUC Series 16 Operating hours: 5859 Technical data Distance between centres: 610 mm Swing over cross-slide: 300 mm Swing over bed: 450 mm Max. turning diameter: 525 mm Spindle hole: 52 mm Turning diameter: 210 mm Turning length: 525 mm Carriage: Longitudinal travel (Z-axis): 560 mm Transversal strocke (X axis): 135 mm Turret slide: number: 1 Number of positions turret 1: 12 Driven tools turret 1: 6 Inner cone diameter: 32 mm Indexing time: 0.7 sec Taper in spindle:: JIS A2-5" Spindle speeds: stepless from: 60 rpm up to: 6000 rpm Taper in tailstock: Morse taper: 4 MT Spindle stroke: 80 mm Spindle diameter: 75 mm Feeds: stepless longitudinal from: 1 mm/min up to: 15000 mm/min transversal from: 1 mm/min up to: 12000 mm/min Spindle motor: 11  ...

Table length: 0 mm Table width: 0 mm Longitudinal X: 0 mm Cross Y: 0 mm Vertical Z: 0 mm Positions ATC: 0   Positions APC: 0   CNC Brand: 0 CNC Model: 0 Control: HEIDENHAIN iTNC 530 Operating hours: 0 Technical data Table length: 700 mm Table width: 500 mm Number of T-channels: 5 Distance of the T-slots: 100 mm T-channel width: 18H7 mm Longitudinal travel (X-axis): 600 mm Transversal travel (y-axis): 500 mm Vertical travel (z axis): 540 mm Tool changer: Number of tools: 24 Tool diameter max.: 77 mm Diameter with free adjacent pockets: 115 mm Tool lenght: 305 mm Max. tool-weight: 6 kg Time of tool changing: 6 sec Average chip-to-chip time: 8 sec Spindle nose: ISO: B40 Vertical spindle speeds: stepless from: 100 rpm up to: 10000 rpm Rapid traverse: long.: 24 m/min Rapid traverse: transversal: 24 m/min Rapid traverse: vertical: 20 m/min Voltage 50 Hz 3x: 400 Volt Spindle power: 12  ...

Table length: 0 mm Table width: 0 mm Longitudinal X: 0 mm Cross Y: 0 mm Vertical Z: 0 mm Positions ATC: 0   Positions APC: 0   CNC Brand: 0 CNC Model: 0 Control: FANUC Series 31i Technical data Table length: 750 mm Table width: 450 mm Table load max.: 300 kg Longitudinal travel (X-axis): 650 mm Transversal travel (y-axis): 450 mm Vertical travel (z axis): 350 mm Dimension of the workpice: Length: 750 mm Width: 635 mm Height: 250 mm Tool magazine number of tools: 60 Tool diameter max.: 80 mm Tool lenght: 250 mm Max. tool-weight: 7 kg Time of tool changing: 4.8 sec Spindle nose: HSK: E50 Distance spindle nose to table: 150 - 500 mm Spindle speeds: stepless from: 300 rpm up to: 30000 rpm Feed range: 1 - 20000 mm/min Rapid traverse:: 20 m/min Air connect: 4 - 8 bar Voltage 50 Hz 3x: 400 Volt Spindle power: 17/13 kW Total power required: 50 kVA Machine´s weight about: 7700 kg Overall ...

Table length: 0 mm Table width: 0 mm Longitudinal X: 0 mm Cross Y: 0 mm Vertical Z: 0 mm Positions ATC: 0   Positions APC: 0   CNC Brand: 0 CNC Model: 0 Control: HEIDENHAIN iTNC 530 Operating hours: 12463 Technical data Number of axis simultaneous: 3 Table length: 700 mm Table width: 630 mm Table load max.: 800 kg Longitudinal travel (X-axis): 600 mm Transversal travel (y-axis): 600 mm Vertical travel (z axis): 500 mm Tool magazine number of tools: 30 Tool diameter max.: 75 mm Tool lenght: 210 mm Max. tool-weight: 2.5 kg Spindle nose: HSK-A: 63 Spindle speeds: stepless from: 100 rpm up to: 24000 rpm Rapid traverse:: 30 m/min Voltage 50 Hz 3x: 400 Volt Spindle motor: 12.5 / 22 kW Total power required: 26 kW Time under power: 43869 Hour Operating time: 12463 Hour Working time: 26214 Hour Spindle run time: 8612 Hour Noise level: 75 dB (A) Machine´s weight about: 8300 kg Overall dim ...

Table length: 0 mm Table width: 0 mm Longitudinal X: 0 mm Cross Y: 0 mm Vertical Z: 0 mm Positions ATC: 0   Positions APC: 0   CNC Brand: 0 CNC Model: 0 Control: HEIDENHAIN iTNC 530 Operating hours: 34729 Technical data Number of axis simultaneous: 4 Table length: 900 mm Table width: 600 mm Table load max.: 800 kg Longitudinal travel (X-axis): 800 mm Transversal travel (y-axis): 600 mm Vertical travel (z axis): 500 mm Tool magazine number of tools: 50 Tool diameter max.: 75 mm Tool lenght: 210 mm Max. tool-weight: 2.5 kg Spindle nose: HSK-A: 63 Spindle speeds: stepless from: 100 rpm up to: 24000 rpm Voltage 50 Hz 3x: 400 Volt Spindle motor: 12.5 / 22 kW Total power required: 26 kW Noise level: 75 dB (A) Machine´s weight about: 8300 kg Overall dimensions machine: Length: 4000 mm Width: 3700 mm Height: 2500 mm Various accessories: Paper filter facility Chip conveyor Dividing attac ...

Table length: 0 mm Table width: 0 mm Longitudinal X: 0 mm Cross Y: 0 mm Vertical Z: 0 mm Positions ATC: 0   Positions APC: 0   CNC Brand: 0 CNC Model: 0 Control: HEIDENHAIN iTNC 530 Operating hours: 3200 Technical data Number of axis total: 5 5-sided machining Rotary table:diameter: 400 mm Longitudinal travel (X-axis): 600 mm Transversal travel (y-axis): 450 mm Vertical travel (z axis): 450 mm Table load max.: 400 kg B axis swivelling range: -115/+30 ° C axis: 360 ° Tool changer:: TC 30 Spindle speeds: stepless from: 50 rpm up to: 20000 rpm Feed range: 22 mm/min Rapid traverse:: 22 m/min Voltage 50 Hz 3x: 400 Volt Spindle motor: 5.5 kW Total power required: 18 kW Noise level: 75 dB (A) Machine´s weight about: 7500 kg Length: 2500 mm Width: 1600 mm Height: 2650 mm Various accessories: Coolant system Touch Probe Renishaw Electronic hand held control Handwheel electroinic Spindle ...

Pallet length: 0 mm Pallet width: 0 mm Longitudinal X: 0 mm Cross Y: 0 mm Vertical Z: 0 mm Number of pallets: 0   Positions ATC: 0   CNC Brand: 0 CNC Model: 0 Control: SIEMENS SINUMERIK 840 D Technical data Number of machines: 2 Number of axis total: 5 Longitudinal travel (X-axis): 750 mm Transversal travel (y-axis): 860 mm Vertical travel (z axis): 850 mm Table divisions (B): 0.001 ° Pallets: number: 12 Length: 630 mm Width: 630 mm Tool changer: Tool magazine number of tools: 334 Spindle nose: HSK-A: 100 Spindle speeds: stepless up to: 11000 rpm Feeds: X axis: 32 m/min Y axis: 32 m/min Z axis: 32 m/min Spindle motor: 25 kW Various accessories: FMS system (flexible manufacturing system) Coolant system Chip conveyor

Pallet length: 0 mm Pallet width: 0 mm Longitudinal X: 0 mm Cross Y: 0 mm Vertical Z: 0 mm Number of pallets: 0   Positions ATC: 0   CNC Brand: 0 CNC Model: 0 Control: SIEMENS SINUMERIK 840 D Operating hours: 0 Technical data Number of axis total: 5 Longitudinal travel (X-axis): 3000 mm Transversal travel (y-axis): 2000 mm Vertical travel (z axis): 2000 mm vertical travel (Y-axis): 1720 mm Table divisions (B): 0.001 ° Swivel angle (a-axis): 175 ° Pallets: number: 8 Length: 1250 mm Width: 1250 mm Transport weight: 3000 kg Tool changer: Tool magazine number of tools: 640 Spindle nose: HSK-A: 100 Spindle speeds: stepless up to: 3000 rpm Feeds: X axis: 40 m/min Y axis: 40 m/min Z axis: 30 m/min Spindle motor: 50 kW Various accessories: FMS system (flexible manufacturing system) Coolant system Chip conveyor

Turning diameter: 0 mm Turning length: 0 mm Turret positions: 0 Positions ATC: 0   Number controlled axis: 0   CNC Brand: 0 CNC Model: 0 Control: MONFORTS CONTROL SYSTEM MTC Technical data Centre height: 250 mm Distance between centres: 1500 mm Swing over cross-slide: 290 mm Swing over bed: 500 mm Taper in spindle: DIN 55027 Carriage: Transversal strocke (X axis): 265 mm Spindle speeds: number (steps): 3 from: 3 rpm up to: 2800 rpm Taper in tailstock: Morse taper: 5 MT Spindle stroke: 160 mm Spindle diameter: 80 mm Rapid traverse X: 5 m/min Rapid traverse Z: 10 m/min Spindle motor: 16.5 kW Voltage 50 Hz 3x: 400 Volt Total power required: 16 kVA Machine´s weight about: 3000 kg Various accessories: 3-jaw chuck diameter: ROTA-S 250 mm 4-jaw chuck diameter: 250 mm Set of jaws Set of jaws hard Travelling steady Lamp Tailstock Coolant system Interface serial port RS 232 Chip conveyor  ...

Table length: 0 mm Table width: 0 mm Longitudinal X: 0 mm Cross Y: 0 mm Vertical Z: 0 mm Positions ATC: 0   Positions APC: 0   CNC Brand: 0 CNC Model: 0 Control: HEIDENHAIN TNC 426 Operating hours: 1800 Technical data Number of axis total: 4 Table length: 1150 mm Table width: 700 mm Turret stations:: 60 Longitudinal travel (X-axis): 1000 mm Transversal travel (y-axis): 750 mm Vertical travel (z axis): 750 mm Tool changer:: TC 30 Number of tools: 30 Tool diameter: 77 mm Diameter with free adjacent pockets: 115 mm Tool lenght: 305 mm Spindle nose: HSK: A63 Distance from vertical spindle to table: 115 mm Spindle speeds: stepless up to: 24000 rpm Feed range: 1500 mm/min Rapid traverse:: 22 m/min Voltage 50 Hz 3x: 400 Volt Total power required: 40 kW Time under power: 21859 Hour Operating time: 7308 Hour Spindle run time: 1564 Hour Machine´s weight about: 10500 kg Overall dimensions  ...

Turning diameter: 0 mm Turning length: 0 mm Turret positions: 0 Positions ATC: 0   Number controlled axis: 0   CNC Brand: 0 CNC Model: 0 Control: MAZATROL PC Fusion 640M Operating hours: 77200 Technical data Number of axis total: 9 Number of spindles: 2 Spindle hole: 88 mm Turning diameter: 610 mm Turning length: 1105 mm Carriage: Longitudinal travel (X-axis): 1137 mm Transversal strocke (X axis): 580 mm Transversal travel (y-axis): 210 mm Tool magazine stationary, number of tools: 80 KM 63 C axis (spindle,resolution): 0 - 360 ° / 0.001 ° Spindle speeds: stepless from: 35 rpm up to: 3500 rpm Milling cutter speeds: 10000 rpm Rapid traverse X: 30 m/min Rapid traverse Z: 20 m/min Rapid traverse Y: 15 m/min Total power required: 26 kW Machine´s weight about: 12000 kg Overall dimensions machine: Length: 5300 mm Width: 3000 mm Height: 2800 mm Various accessories: 3-jaw chuck diameter: 2 ...

Table length: 0 mm Table width: 0 mm Longitudinal X: 0 mm Cross Y: 0 mm Vertical Z: 0 mm Positions ATC: 0   Positions APC: 0   CNC Brand: 0 CNC Model: 0 Control: HEIDENHAIN iTNC 530 Operating hours: 64731 Technical data 5-sided machining Number of axis simultaneous: 5 Table length: 320 mm Table width: 320 mm Longitudinal travel (X-axis): 600 mm Transversal travel (y-axis): 450 mm Vertical travel (z axis): 450 mm Length Table load max.: 75 kg Table divisions (B): -115 / +30 ° Table divisions (C): 360 ° Pallets:: 3R GPS Pallets chanching device: Automatic pallet change-unit (number of paletts) number: 6 Length: 320 mm Width: 320 mm Transport weight: 200 kg Tool changer: Addet tool-holder magazine Number of tools: 170 Spindle nose:: HSK-A 63 Spindle speeds: stepless up to: 20000 rpm Feeds: Voltage 50 Hz 3x: 400 Volt Machine´s weight about: 7700 kg Overall dimensions machine: Leng ...

Table length: 0 mm Table width: 0 mm Longitudinal X: 0 mm Cross Y: 0 mm Vertical Z: 0 mm Positions ATC: 0   Positions APC: 0   CNC Brand: 0 CNC Model: 0 Control: NUM 1060 Technical data Number of axis total: 5 Number of spindles: 11 Longitudinal travel (X-axis): 740 mm Transversal travel (y-axis): 185 mm Vertical travel (z axis): 220 mm Swivel angle (a-axis): 110 ° C axis: 360 ° Spindle positioning increment: 0.001 ° Bar diameter: 32 mm Spindle nose: ISO: 25 Spindle speeds:: (11x) stepless from: 50 rpm up to: 12000 rpm Rapid traverse: long.: 10 m/min Rapid traverse: transversal: 20 m/min Rapid traverse: vertical: 20 m/min Air connect: 6 bar Voltage 50 Hz 3x: 400 Volt Total power required: 10 kVA Machine´s weight about: 3500 kg Overall dimensions machine: Length: 2215 mm Width: 2500 mm Height: 2650 mm Various accessories: Set of toolholders (without tools) Set of collets

FMS SYSTEM: Machining Cell consisting of: Two 5-Axis machining Centres 8-Pool Pallet System(1250 x 1250mm x 3.000kg) Pallet Storage System X= 3.000 mm, Y= 2.000H/1.720V, Z= 2.000mm; A= 175°, B=0,001°; 640 Pos. ATC ; Spindle Taper HSK-A100; Spindle n= 3.000; Motor 50kW; Feeds: X,Y= 40m/min, Z= 30m/min Siemens 840D, Chip-conveyor; Serial No. 1450-03 and 1451-3, both from 2003 FR: À VENDRE MAINTENANTFMS SYSTEME ; 8 Pos. Piscine à palettes (1250 x 1250mm x3.000kg). 2x MCM Jet Five Mirror 5 axes CENTRE D'USINAGE/BEARBEITUNGSZENTREN/MACHINE CENTERS, X= 3.000, Y= 2.000H/1.720V, Z= 2.000mm ; A= 175°, B=0,001° ; 640 Pos. ATC ; Cône de broche HSK-A100 ; Broche n= 3.000 ; Moteur 50kW ; Alimentation : X,Y= 40m/min, Z= 30m/minSiemens 840D, convoyeur à copeaux ; numéros de série 1450-03 et 1451-3, à partir de 2003

Key data: 1435

Turning diameter: 1435 mm Turning length: 0 mm Spindle bore: 0 mm Motor power: 0 HP/kW Fields of application machining of two wheel sets at the same time turning of wheel tyre profiles on wheel sets in situ machining of brake discs on wheel sets in situ machining of single wheel sets machining of coupled wheel sets machining of wheel sets of different gauges on all mainline railway, metro and tram vehicles Rail track gauge:  1.435mm Max. wheel tread Ø:1.400mm Min. wheel tread Ø:500mm Number of slides:  2 + 2  Power:             2 x 30 kW Length:            7.000 mm  Width:             8.000 mm  Height:            2.600 mm  Weight:            32.000 kg  The tandem a ...

Key data: 670 Mazatrol, 1380 640 M

Turning diameter: 670 mm Turning length: 1380 mm Turret positions: 0 Positions ATC: 0   Number controlled axis: 4   CNC Brand: Mazatrol CNC Model: 640 M Max. turning Ø:  670mm X-Axis:          740mm Y-Axis:          410mm Z-Axis:          1.380mm B Axis:          270° Speedrange:      4000Rpm Spindle power:   30kW Subspindle speeds:4000Rpm ATC / revolver:  40 Capto C6  Speed live tools:4000Rpm Length:          7.000 mm  Width:           3.000 mm  Height:          3.000 mm  Weight:          15.000 kg

Key data: 630 Siemens, 630 840 D, 800

Pallet length: 630 mm Pallet width: 630 mm Longitudinal X: 800 mm Cross Y: 800 mm Vertical Z: 800 mm Number of pallets: 2   Positions ATC: 120   CNC Brand: Siemens CNC Model: 840 D X – Travel:               800mm Y – Travel:               800mm Z – Travel:               800mm B-Axis indexing:          360° Table Length:             630mm Table Width:              630mm Table load:               1.200Kg Number of pallets:        2 Feed rate X-Axis:         60.000mm/min. Feed rate Y-Axis:         60.000mm/min. Feed rate Z-Axis:      &n ...

Key data: 1100 _Unknown / Other, 600 Celos, 800

Table length: 1100 mm Table width: 600 mm Longitudinal X: 800 mm Cross Y: 530 mm Vertical Z: 510 mm Positions ATC: 40   Positions APC: 0   CNC Brand: _Unknown / Other CNC Model: Celos X – Travel:               800mm Y – Travel:               530mm Z – Travel:               510mm Table Length:             1.100mm Table Width:              600mm Table load:               1.000Kg Feed rate X-Axis:         30.000mm/min. Feed rate Y-Axis:         30.000mm/min. Feed rate Z-Axis:         30.000mm/min. Spindle Taper:            40ISO/Bt/Mk Power o ...

Key data: 850 Heidenhain, 600 iTNC 530, 640

Table length: 850 mm Table width: 600 mm Longitudinal X: 640 mm Cross Y: 600 mm Vertical Z: 500 mm Positions ATC: 30   Positions APC: 0   CNC Brand: Heidenhain CNC Model: iTNC 530 X – Travel:              640mm Y – Travel:              600mm Z – Travel:              500mm Table Length:            850mm Table Width:             600mm Table load:              600Kg Feed rate X-Axis:        40.000mm/min. Feed rate Y-Axis:        40.000mm/min. Feed rate Z-Axis:        40.000mm/min. Spindle Taper:           Sk40 ISO/Bt/Mk Power on spindle:        19kW Speeds / ra ...

Key data: 2000 Mazatrol, 760 640 M, 1740

Table length: 2000 mm Table width: 760 mm Longitudinal X: 1740 mm Cross Y: 760 mm Vertical Z: 660 mm Positions ATC: 30   Positions APC: 0   CNC Brand: Mazatrol CNC Model: 640 M X – Travel:              1.740mm Y – Travel:              760mm Z – Travel:              660mm Table Length:            2.000mm Table Width:             760mm Table load:              1.400Kg Feed rate X-Axis:        36.000mm/min. Feed rate Y-Axis:        36.000mm/min. Feed rate Z-Axis:        36.000mm/min. Spindle Taper:           40ISO/Bt/Mk Power on spindle:        18,5 kW Speeds / ...

Key data: 350 Mazatrol, 365 T Plus, 12

Turning diameter: 350 mm Turning length: 365 mm Turret positions: 12 Positions ATC: 0   Number controlled axis: 0   CNC Brand: Mazatrol CNC Model: T Plus Make: MAZAK Type: Multiplex 610 + Flex GL50N Control: Mazatrol T Plus YOP: 1995 Gantry loader Flex GN50L Power 58 kW Double spindel Double turret Live / Driven tools Milling and Turning ! Max. turning Ø:350mm X-Axis:        200mm Z-Axis:        365mm Spindle bore:  52mm Speedrange:    5000Rpm Spindle power: 11kW ATC / revolver:12 Length:        7.000 mm  Width:         3.500 mm  Height:        3.000 mm  Weight:        7.000 kg

Table length: 0 mm Table width: 0 mm Longitudinal X: 700 mm Cross Y: 500 mm Vertical Z: 450 mm CNC Brand: _Unknown / Other Make: MAHO Type: MH700C Control: 432 YOP: 1989 NC Rotary table (B-Axis) 630 mm CNC 432 with handwheel Pinole 100 mm X – Travel:              700mm Y – Travel:              500mm Z – Travel:              450mm Table  Ø:                630mm Feed rate X-Axis:        6.000mm/min. Feed rate Y-Axis:        3.000mm/min. Feed rate Z-Axis:        11.400mm/min. Spindle Taper:           40ISO/Bt/Mk Speeds / ranges:         3150Rpm Number of controlled axis:3 + 1  Length:  &n ...

Key data: 700 Heidenhain, 500 TNC 124, 500

Table length: 700 mm Table width: 500 mm Longitudinal X: 500 mm Cross Y: 400 mm Vertical Z: 400 mm Positions ATC: 0   Positions APC: 0   CNC Brand: Heidenhain CNC Model: TNC 124 Make: DMG MORI Type: DMU 50 M Control: HeidenHain TNC 124 YOP: 1998 Optical Digital read out B & C Axis 5 Axis on screen X – Travel:              500mm Y – Travel:              400mm Z – Travel:              400mm Table Length:            700mm Table Width:             500mm Table load:              200Kg Feed rate X-Axis:        5.000mm/min. Feed rate Y-Axis:        5.000mm/min. Feed rate Z-Axis:        5.000mm/min.  ...

Key data: 500 Mazatrol, 500 640 M, 730

Pallet length: 500 mm Pallet width: 500 mm Longitudinal X: 730 mm Cross Y: 730 mm Vertical Z: 740 mm Number of pallets: 20   Positions ATC: 325   CNC Brand: Mazatrol CNC Model: 640 M Make: MAZAK Type: PFH 5800 Control: MAZATROl 640M YOP: 2005 20 x Pallet stations ATC with 325 positions Tooling package ca 150 pieces Granit clamping towers 18 x X – Travel:               730mm Y – Travel:               730mm Z – Travel:               740mm B-Axis indexing:          360000° Table Length:             500mm Table Width:              500mm Table load:               500Kg Number of pallets:      &n ...

Key data: 2000 Mazatrol, 760 , 1740

Table length: 2000 mm Table width: 760 mm Longitudinal X: 1740 mm Cross Y: 760 mm Vertical Z: 660 mm Positions ATC: 48   Positions APC: 0   CNC Brand: Mazatrol 3D measuring probe Visiport windows Chip conveyor with IKZ 3275 Hours X – Travel:     1.740mm Y – Travel:     760mm Z – Travel:     660mm Table Length:   2.000mm Table Width:    760mm Table load:     1.400Kg Feed rate X-Axis:36.000mm/min. Feed rate Y-Axis:36.000mm/min. Feed rate Z-Axis:36.000mm/min. Spindle Taper:  40ISO/Bt/Mk Power on spindle:18,5 kW Speeds / ranges:12000Rpm ATC / revolver: 48 Chip conveyor:  yes  Coolantsystem:  yes  Length:         4.450 mm  Width:          3.460 mm  Height:         3.100 ...

Table length: 790 mm Table width: 560 mm Longitudinal X: 635 mm Cross Y: 510 mm Vertical Z: 460 mm Positions ATC: 30   Positions APC: 0   CNC Brand: Siemens CNC Model: 840 D X – Travel:              635mm Y – Travel:              510mm Z – Travel:              460mm Table Length:            790mm Table Width:             560mm Table load:              600Kg Feed rate X-Axis:        30.000mm/min. Feed rate Y-Axis:        30.000mm/min. Feed rate Z-Axis:        30.000mm/min. Spindle Taper:           SK40 ISO/Bt/Mk Speeds / ranges:         8000Rpm ATC / revo ...

Table length: 630 mm Table width: 500 mm Longitudinal X: 500 mm Cross Y: 450 mm Vertical Z: 400 mm Positions ATC: 30   Positions APC: 0   CNC Brand: Heidenhain CNC Model: iTNC 530 X – Travel:              500mm Y – Travel:              450mm Z – Travel:              400mm A – Axis:                - 5 to + 115 ° Table Length:            630mm Table Width:             500mm Table load:              400Kg Feed rate X-Axis:        30.000mm/min. Feed rate Y-Axis:        30.000mm/min. Feed rate Z-Axis:        30.000mm/min. Spindle Taper:          & ...

Table length: 1200 mm Table width: 228 mm Longitudinal X: 800 mm Cross Y: 400 mm Vertical Z: 500 mm CNC Brand: _Unknown / Other CNC Model: Teach in ProtoTRAK - SMX Teach in Teach in Milling 800 x 400 x 500 mm MACH - ID 6333 Make: ProtoTRAK Type: SMX Teach in Control: ProtoTRAK SMX X-Axis    800 mm Y-Axis    400 mm Z-Axis    500 mm Table Length     1.200 mm Table Width        228 mm Table load           600 kg Power on spindle     3 kW Spindle speeds       3600 Rpm Spindle Taper        40 ISO/Bt/Mk Control      SMX Dimensions Length     3.200 mm Width      2.800 mm Height     2.300 mm Weight     2.000 ...

Table length: 0 mm Table width: 0 mm Longitudinal X: 600 mm Cross Y: 700 mm Vertical Z: 550 mm Positions ATC: 0   Positions APC: 0   CNC Brand: Heidenhain MACH - ID 6309 Make: DECKEL MAHO Type: DMU 60 P Control: Heidenhain Mill Plus YOP: 1998 X – Travel    600 mm Y – Trave     l700 mm Z – Travel    550 mm A – Axis      120 ° B – Axis       360 ° Table load     350 kg Table Ø        630 mm Feed rate X-Axis      10.000 mm Feed rate Y-Axis      10.000 mm Feed rate Z-Axis      10.000 mm Spindle Taper            40 ISO/Bt/Mk Speeds / ranges          12000 Rpm ATC / revolver      &nbs ...

Table length: 700 mm Table width: 500 mm Longitudinal X: 500 mm Cross Y: 400 mm Vertical Z: 400 mm Positions ATC: 16   Positions APC: 0   CNC Brand: Siemens CNC Model: 840 D MACH - ID 6278 Make: DECKEL MAHO Type: DMU 50 Control: SIEMENS 840D YOP: 2005 Hours: 4836 X – Travel    500 mm Y – Travel    400 mm Z – Travel    400 mm Table Length    700 mm Table Width     500 mm Table load       200 kg Feed rate X-Axis     12,000 mm Feed rate Y-Axis     12,000 mm Feed rate Z-Axis     12,000 mm Spindle Taper          40 ISO/Bt/Mk Power on spindle     13 kW Speeds / ranges        10.000 Rpm ATC / revolver        &n ...

Table length: 2000 mm Table width: 510 mm Longitudinal X: 1660 mm Cross Y: 510 mm Vertical Z: 510 mm Positions ATC: 30   Positions APC: 0   CNC Brand: Mazatrol CNC Model: M Plus MACH - ID 6107 Make:MAZAK Type:VTC 200 C Control:Mazatrol M Plus YOP:1998 X – Travel     1.660 mm Y – Travel      510 mm Z – Travel      510 mm Table Length      2.000 mm Table Width        510 mm Table load           1.000 kg Feed rate X-Axis        36,000 mm Feed rate Y-Axis         36,000 mm Feed rate Z-Axis          36,000 mm Spindle Taper               40 ISO/Bt/Mk Power on spindle          &n ...

Drilling capacity: 13 mm Throat: 180 mm Spindle taper: 2   MACH - ID 6106 Make:MAXION IXION Type:BT 13 P YOP:2003 Max. drill Ø stee    l13 mm Max. drill Ø cast     15 mm Stroke pinole           70 mm Throat        180 mm Column sleeve        65 mm Spindle TaperMk    2 ISO/Bt/Mk Speeds / ranges        240 - 4000 Rpm Table Length            230 mm Table Width              170 mm Power                        0,75 kW Max. distance spindle – table        275 mm Dimensions Length    400 mm Width      500 mm Height  &nb ...

Drilling capacity: 15 mm Throat: 180 mm Spindle taper: 2   MACH - ID 6105 Make:MAXION IXION Type:Unimax 1 Frequenz YOP:2014 Max. drill Ø steel    15 mm Max. drill Ø cast     18 mm Max. tap ØM           12 M Stroke pinole           80 mm Throat        180 mm Column sleeve       65 mm Spindle Taper         2 ISO/Bt/Mk Speeds / ranges       4000 Rpm Table Length           250 mm Table Width             220 mm Power                       1.1 kW Max. distance spindle – table        380 mm Length&nbs ...

Pallet length: 400 mm Pallet width: 400 mm Longitudinal X: 560 mm Cross Y: 460 mm Vertical Z: 510 mm Number of pallets: 0   Positions ATC: 60   CNC Brand: Mazatrol MACH-id    6026 MAKE         Mazak Japan TYPE          H 400 YOP           1990 SPECIFICATIONS X - Travel        560 mm Y - Travel        460 mm Z - Travel         510 mm B-Axis indexing         360.000 ° Table Length             400 mm Table Width               400 mm Table load                   400 Kg Number of pallets       2 Feed rate X-Axis        &nbs ...

Technische Daten: - Doppelte Gehrung    45C - Einzelne Gehrung bis 90C - Arbeitsbreite, max.    70 mm - Arbeitshöhe, max.    115 mm - Nettogewicht    35 kg Beschreibung: Manuel handbediente Gehrungsstanze - ohne Staub - kein Lärm - kein Kompressor - sauber Schnitt. Morsö B ist ein kleines handliches Tischmodell, das für Glasleisten u. dgl. gut geeignet ist. Leisten bis zu einer geeigneten Breite können mit einem Schnitt geschnitten werden.

Technische Daten: - Doppelte Gehrung    45C - Einfache Gehrung bis    90C - Arbeitsbreite, max.    70 mm - Arbeitshöhe, max.    115 mm - Maßskala bis    650 mm - Nettogewicht    35 kg Beschreibung: Manuel handbediente Gehrungsstanze - ohne Staub - kein Lärm - kein Kompressor - sauber Schnitt. Morsø BA ist ein kleines handliches Tischmodell, das für schmale Leisten mit Falz sehr gut geeignet ist. Die Messerkopf kann in zwei Positionen eingestellt werden, so daß man einen glatten und sauberen Schnitt erreicht. Die Maßskala sichert die genaue Längseinstellung
