lathe used for sale

Tip height: 107 mm top width: 350 mm circular diameter: bed 200 mm spindle bore: 25 mm taper tailstock: 2 MK spindle speed: 35 - 3500 rpm feeds: longitudinal and mm/U thread pitches plan: 0.2-3 mm electrical connection: 380 V, approx. 2.2 kW space: 600 x 1300 x 1230 mm weight: 850 kg

digital display swingdiameter over bed 800 mm swingdiameter over slide 600 mm distance between center 2000 mm spindle speed750 1 / min multifix tailstock

Working condition Complete electrics Yom: 1990 Technical details: Swing over bed: 2500 mm Turning length: 12 500 mm (The whole length of bed 15 700 mm) we can also make the extension of the needed workpiece weight: 120 tons bed width: 2 900 mm machine weight: 120 tons

Made in Italy Peak: 300 mm Rotary diameter over bed: 600 mm Rotary diameter via sled: 380 mm Peak: 1,500 mm Bed width: 400 mm Spindle bore: 82 mm Spindle nose: Camlock 8 " Spindle speeds: (12) 16-1200 U/min Engine power: 9.2 kW (special equipment/standard: 7.5 kW) Reprimor Z-axis: (93) 0.028-6.43 mm/U Feed X-axis: (93) 0.012-2.73 mm/U Thread, metric: (54) 0.5-224 mm Threads, Witworth: (55) 72-1/4 x8 TPI Thread, module: (54) 0.5-112 mm Threads, Diametral Pitch: (54) 64 -1/4 D.P. Crossleigh hub: 340 mm Oberslitten hub: 150 mm Riding stock pinol diameter: 85 mm Riding stove pinol stroke: 200 mm Ridstock cone: MK 5 Weight: About 3,200 kg Facilities: -3-axis digital display -Step-by-step speed adjustment -Automatic lubrication of the management railways -LED lighting -Micrometer bed strike -9.2 kW engine instead of 7.5 kW -Quick change holder system mul ...

Tip width: 700 mm Tip height: 150 mm Circulation diameter over bed: 300 mm Bed width: 180 mm Spindle bore: 38 mm Mounting in the spindle bore: MK 5 Speed range, infinitely variable: 30 - 450 / 150 - 3000 rpm Range of longitudinal feeds: (14) 0.07 - 0.65 mm/U Area of plan feeds: (11) 0.03 - 0.12 mm/U Metric threads: (18) 0.2 - 3.5 mm Inch Thread: (21) 8 - 56 Gg/1" Pinole path: 85 mm Pinole holder: MK 3 Engine power S1 100%: 1.5 kW / 400 V Motor recording power S6 40%: 2.2 kW / 400 V Machine dimensions (W x D x H): 1380 x 640 x 500 mm Weight approx.: 235 kg without base Delivery: - Digital display - 3-jaw chuck PO3-160 mm steel version - Feed flange 160 mm - Solid grain tips - Interchangeable wheels - Quick-release steel holder size 20-2 with 2 straight inserts - Slip clutch - Micrometer longitudinal stop - Plan sled with top support - Frequency inverter ...

Maximum diameter to turn on the bench 2,110 mm Maximum diameter to turn on trolley 1,600 mm Maximum distance between platforms 12,830 mm Spindle hole diameter 155 mm Cone on spindle no. 120 metric Cone on spindle (with reduction) no. 6 clamps Cone on the counterpoint (6-bit reduction) no. 120 metrics Maximum stroke of the counterpoint 400 mm DSeed from the tool support plane to the axis of the 80 mm centers Main engine power 100 HP Spindle speed from 0.9 to 90 rpm with continuous variation Longitudinal feed no. 36: 0.2 to 12.8 Transverse advances No. 36: 0.1 to 6.6 Metric fillets #26: 1 to 42 Whitwoth fillets #17: 0.5 to 11 Quick forwards Maximum permissible load on the tips 50-60 ton Refrigerant liquid system

Peak height 2,600 mm Point distance 10,000 mm Closed bench 2,000x6,000 mm To be completed with CNC

Height tips 220 mm Useful length 1,000 mm 42 mm bar pass

Equipped with no. 03 guides Overhauled with: guide grinding, CN conversion, new electrical and hydraulic system, hydraulic self-centering installation, shaving conveyor; CN Fagor 8055 Numerical Control – BT Maximum turnerable diameter 1800 mm 3-grife hydraulic self-centering with a diameter of 1450 mm with tightening force 30 Ton with 30 bar clamp L max turnerable 3000 mm Spindle engine power 110 Kw Maximum rotation speed 180 rpm Fast value axles 4000 mm/min M3/M4 Spindle Rotation Inversion Possibility 4 speed ranges Hydraulic counterpoint Maximum capacity of workpiece on counterpoint 12500 Kg It is currently possible to work details of up to 3000 mm length but the extension pallet is available to be able to work details up to 8 m in length. (un revised); Machine installed and working

Max length 8,000 mm Maximum turning diameter above wagon 1,250 mm Max vault over guides 1,650 mm Maximum turning diameter under spindle 2,000x700 mm Displayed – two axes

IN THE RETROFITTING PHASE Height tips 900 mm Point distance 7,000 mm Turnerable diameter on the bench 1,850 mm Turnerable diameter on trolley 1,350 mm Turnerable diameter on recess 2,150 mm Bench width 1,000 mm Bar passage diameter 206 mm ASA A1 15" spindle attachment Top speed 300 RPM Diameter of the tank counterpoint 220 mm Row stroke counterpoint 450 mm Withworth threads - metrics - diametrics - module Weight allowed between tips without lunettes 15 ton Weight allowed between tips with a 20-ton bezel

Height tips 300 mm Distance between tips 4,000 mm Spindle speed (16) 15-1,500 rpm Bar pass 105 mm Engine power 15 HP displayed with ELBO system

peak heights: 250 mm point distance: 1500 mm bar pass: 105 mm

Maximum turnerable diameter: 1040 mm Turning diameter above the wagon: 620 mm Maximum workable length: 5200 mm Spindle power: 40 kW CNC ECS Optical line measurement system Maximum flow between tips: 10 tons Machine complete with chip evacuator, 4-position hydraulic turret, safety shelters in compliance and spindle 3-jaw hydraulic self-centering AUTOBLOCK; Various accessories available (tool case, stretchers, lunettes...) EC 2018 remarking possibility

Code 0782 Description Centerlathe Make A.I. Hembrug Model DR - 133 Serial No. DR 133 / F 4018 Year 1970 Distance between centers 750 mm Swing over bed 270 mm Swing over gap xxx mm Swing over crossslide 150 mm Spindle bore 35 mm Number of spindle speeds 28 Spindle speeds 18 – 3550 rpm Feeds Longitude and cross Motor power 3 kW – 380 Volts Thread cutting Metric, W.W., Modul and D.P. Accessoiries 3 chuck 2 x RSF DRO Condition Machine is in normal condition.

Code 2841 Description Centerlathe Make Graziano Model SAG 12 Serial No. SAG 12 N 4475 Year 1976 Distance between centers 800 mm Swing over bed 320 mm Swing over gap 420 mm Swing over crossslide 176 mm Spindle bore 41 mm Number of spindle speeds 8 Spindle speeds 75-2000 rpm Feeds Longitude and cross Motor power 2 and 3 kW – 380 Volts Thread cutting Metric, W.W., Modul and D.P. Accessoiries 3 chuck Condition Machine is in normal condition.

Code 2876 Description Centerlathe Make Graziano Model SAG 12 Serial No. SAG 12 N 5150 Year 1980 Distance between centers 800 mm Swing over bed 320 mm Swing over gap 420 mm Swing over crossslide 176 mm Spindle bore 41 mm Number of spindle speeds 8 Spindle speeds 75-2000 rpm Feeds Longitude and cross Motor power 2 and 3 kW – 380 Volts Thread cutting Metric, W.W., Modul and D.P. Accessoiries 3 chuck Steadies Rapid toolpost Condition Machine is in normal condition.

Tip height: 250 mm Center width: 1500 mm Circulation Ø: over bed 500 mm Spindle bore: 63 mm Spindle holder: Size 8 Mounting cone tailstock: 5 MK Spindle speeds: 170 - 2240 rpm Feeds: longitudinal/flat 0.014-1/0.0063-0.45 mm/U Thread pitches: 0.1 - 112 mm electrical connection: 380 V, 7.5 kW Space requirement: 2300 x 1000 x 1400 mm Weight: 2360 kg

Beautiful hamlet intern 160. Centre distance 650 mm Center height 160 mm Turning diameter over bed 320 mm Spindle bore 40 mm Spindle speeds 24-2500 rpm Accessories: Digital display Heidenhain 3 axes 3-claw 160mm Multifix tool holder with 5 holders Collet Equipment Collets 27 pieces

Turning diameter over bed 490 mm Center width 1500 mm Spindle bore 63 mm Spindle speed 2240 min-1 Chuck diameter 250 mm 2 x Bezel Tailstock Multifix

Center height: 315 mm Center width: 1000 mm Circulating Ø: 630 mm Spindle bore: 74 mm Spindle holder: Size 8 Pick-up cone tailstock: 5 MK Spindle speeds: 7 - 710 rpm Feeds: longitudinal/flat 0.063-4/0.030-2 mm/rev Thread pitches: 1 - 14 mm electrical connection: 380 V kW Space requirement: 2750 x 1250 x 1380 mm Weight: approx. 4200 kg

WEILER DA 210 / 3-axis digital display Heidenhain Including CE marking - ORIGINAL CONDITION Center height 210mm Center width 1000mm Circumferential diameter over bed 435mm Circulation diameter via face slide 245mm Spindle bore 52mm Speed range 40-2000 rpm Automatic longitudinal / plan feeds Drive power 5.5 KW Cjr3wkhxxx Quick-release holder with 3 inserts Feed protection Work lamp 2x EMERGENCY/OFF Central lubrication Three-jaw chuck - 200mm Documentation Dimensions: LxWxH 2.3x1.2x1.6 meters weight 1400KG Errors / input errors excepted Chip back wall Coolant device

WEILER COMMODOR 230 2-axle Heidenhain digital display GS - Identifier Tip height 230mm Center width 1000mm Turning diameter over bed 475mm Circulation diameter via face slide 270mm Rod passage 56mm Speed range 25-2000rpm Automatic longitudinal/flat feeds Thread / Metric / Inch Tailstock MK4 Quick-change steel holder with insert Coolant device Chip back wall Work lamp 2xNOT/OFF Feed protection Three-jaw chuck 200mm Machine feet Documentation Cjr8l82mnl Dimensions: LxWxH 2.5x1.5x1.7 meters Weight 1800 kg

- Rotary Ø: 340 mm - Turning length: 1050 mm - Center height: 170 mm - Speed range: 20 - 2500 rpm - Quill stroke: 160 mm - Lining: Ø 250 mm - 4 -jaws - Spindle passage: 55 mm - Space requirements (W x D x H): approx. 3.1 x 1.1 x 1.5 m - Machine weight: 2,200 kg - Total power: 5.5 kW - Condition: good Accessories 3-jaw chuck Ø 250 mm, face plate Ø 510 mm, Multifix B steel holder with 4 inserts, bezel

FAM US 400 SW 1000 mm SH 200 mm. 31.3 to 2000 rpm Multifix B

Code 211321230614 Description Centerlathe Make ICOCA Model SJ – 410 x 1000 G Serial No. 8708004 Year 1987 Distance between centers 1000 mm Swing over bed 410 mm Swing over gap 650 mm Swing over cross slide 220 mm Spindle bore 51 mm Number of spindle speeds 12 Spindle speeds 40 – 2000 rpm Feeds Longitude and Cross Motor power 5 kW – 380 Volts Thread cutting Metric, W.W. Accessoiries 3 chuck Ø 230 mm Rapide toolpost Coolant Condition Machine is in very good condition

Center height: 123 mm Center width: 560 mm Circumferential Ø: above bed 280 mm Spindle bore: 27 mm Spindle speeds: 60 - 1250 rpm Feeds: longitudinal/flat 0.091-2.553/0.046-1.292 mm/rev Thread pitches: 0.25 - 11 mm Electrical connection: 380 V, 0.75 kW Dimensions: 1300 x 700 x 1270 mm Weight: approx. 300 kg

WEILER COMMODOR 230 AC / with CE marking / 3-axis digital display Gxadgeq -Built in 1999 -Tip height 230mm -Center width 1000mm - Turning diameter over bed 475mm -Circulation diameter via face slide 270mm -Rod passage 56mm -Speed range 25-2000rpm (infinitely variable via potentiometer) • Automatic longitudinal/plan feeds -Thread/Metric/Inch/Pitch/ -Tailstock MK4 -Quick-release bracket with insert -Coolant device -Chip back panel -Feed protection electric -Three-jaw chuck approx. 200mm -2xEMERGENCY/OFF -Documentation Dimensions: LxWxH 2.6x1.5x1.7 meters / Weight 1800Kg

Key data: 150 mm, 300 mm, -3500 U/min

Hamlet of Matador in obsolete condition SH 150 mm SW 600 mm tailstock MK 3 Guided tours Overlapping and post-processing New paint job New 3-axis digital display Emergency stop, feed protection with microswitch Miscellaneous Accessories

Swing over bed 840 mm Swing over support 530 mm Center distance 2000 mm Spindle bore 82 mm Spindle diameter in front bearing 160 mm Spindle taper - metric 100 Morse Tailstock 6 Maximum workpiece weight at the lowest speed of 6000 kg Largest blade profile 40 x 40 mm Electric motor for headstock drive 18.5 kW Machine dimensions L x W 3420 x 1880 mm Machine weight (according to the spike distance) 5700 kg

HAMLET COMMODOR incl. Three-axis digital display Turning length max. 1000mm Turning diameter max. 380mm Turning diameter over support 190mm Rod passage 56mm Speed range 25-2000 rpm Automatic longitudinal/face feeds Eeipidd Thread/Metric/Inch/etc Drive power 4 KW Tailstock MK4 Three-jaw chuck - Röhm 200mm Quick-change bracket incl. 3 inserts Bed stop Chip back wall Coolant system Feed protection 2 x EMERGENCY /OFF Machine Documentation Dimensions: LxWxH 2.7x1.5x1.8 meters Weight approx. 1.6 tons

Key data: 250 mm, 500 mm

Circulation diameter over bed 500 mm Max. turning length 1,600 mm Connected load 5.5 kW Machine weight 4.4 t

Key data: 180 mm, 360 mm, 14 U/min

Center height 180 mm Center width 750 mm Circulation diameter over bed 360 mm Spindle bore 41 mm Spindle speed range, stepped 14 – 2,800 rpm Machine weight 1.9 t Connected load 6.5 kW

HAMLET - E35 Control - CNC Center height: approx. 200mm Center width: approx. 950mm Max. circulation over bed: approx. 410mm Max. circulation over face cuts: approx. 200mm Max. circulation offset approx. 440mm Max. workpiece weight: approx. 900kg Speed range from approx. 1-3000 rpm Two speed gears Spindle head according to DIN: 55027 Spindle diameter: 90mm Spindle bore: 54mm Schunk/Rota lining: approx. 200mm Flat stroke: approx. 230mm Longitudinal stroke: approx. 950mm Multifix with inserts Chisel cross-section 25x25mm Tailstock quill taper: MK 4 D33lx09vs Coolant system Sliding door/feed guard Dimensions: LxWxH 2.3x1.4x1.7m Machine weight 2100 kg

Key data: 165 mm, 750 mm, 2800 U/min

Manufacturer: Gildemeister Model N.E.F. 320 K Year of construction 2004 Condition Used Siemens control system Specifications Circulation diameter 320 mm Turning length 750 mm Speed range - main spindle 3500 rpm Drive power - main spindle 9 kW Bar diameter 50 mm Tool holder Multifix size B Tailstock mount MK 4 Rapid traverse X / Z 8 / 10 m/min Machine weight approx. 2.5 t Space requirement approx. 2500 x 1800 x 1885 mm Accessories: 3 Jaw chuck Forkardt 200 Tool package Documentation

Center height: 285 mm Center width: 1500 mm Circumferential Ø: above bed 580 mm Spindle bore: 72 mm Spindle mount: Size 8 Pick-up cone tailstock: 5 MK Spindle speeds: 20 - 2000 rpm Feeds: longitudinal/flat 0.05-16.32/0.025-8.16 mm/rev Thread pitches: 0.5 - 120 mm Electrical connection: 400 V, approx. 10 kW Dimensions: 3000 x 1250 x 1550 mm Weight: 2860 kg

Offer 24009 Specifications: - Center height 200 mm - Center width 1500 mm - Maximum circulation – Ø above bed 400 mm - over face carriage 210 mm - Spindle bore 56 mm - Pick-up cone of the tailstock quill MK 5 - Tailstock quill travel 150 mm - Spindle speeds 11 - 2240 rpm - Feeds longitudinal + flat - Metric thread pitches -Thread - Module thread - Diametrically pitsch thread - Drive 400 V / 7.5 kW - 3 jaw chuck - Space requirement approx. W 3300 x H 1600 x D 1200 mm - Weight approx. 2800 kg

Key data: 160 mm

Year of construction: 2003 Top height: 160mm Center width: 650mm Spindle bore: Ø 40mm Circulation over bed 320 mm Spindle speed: 20-2500 Tailstock mount: MK3 Quill Stroke: 85mm Quill diameter 40 mm Longitudinal carriage feed range: 0.020 - 0.630 mm/rev Feed range face slide: 0.006 - 0.200mm/rev Possible thread types: Metric, Inch, Modulus, Diametrical Pitch Metric thread pitches: 0.25 - 8mm Spindle brake: switchable Main motor 3.5 kW Total connected load: 7.5 kvA Voltage: 400V Dimensions: approx. 1.58x0.9x1.5m (LxHxW) Weight: approx. 710kg Accessories as shown in the pictures: 3-axis digital display, coolant device, chuck protection, 4-jaw chuck, punch pliers and other collet equipment incl. Collets, Multifix with 2 inserts, manuals.

Slotting machine CABE 170 ST -Stroke adjustable up to max. 170mm -Projection to the middle of tool holder +- 275mm -Swivel butt head Right/Left -Rotary table - three-jaw chuck approx. 200mm -Tool cabinet with approx. 30 pieces - Push chisel Dimensions: LxWxH 1.1x0.7x1.7 meters Weight approx. 700Kg Blv0xavcuuo

max. turning length: approx. 750 mm, spindle bore 40 mm, max. 1800 rpm, with Multifix quick-release system, coolant device and 3-axis digital display, Fabr. ELESTA

max. turning length: approx. 2000 mm, centre height: approx. 300 mm, hollow spindle diameter: approx. 100 mm, with Multifix clamping system

Center height: approx. 250 mm, max. turning length: approx. 2000 mm, hollow spindle diameter: approx. 12 mm, with 3-axis digital display, Fabr. HEIDENHAIN, machine light, Multifix quick-release system

max. turning length: 3000 mm, center height: approx. 300 mm, hollow spindle diameter: 100 mm, with 3-axis digital angle, Fabr. SONY, 1 three-jaw chuck, Multifix quick-release system and coolant device

Article number: 04-03-111 Manufacturer: Weiler Very good general condition Machine partially overhauled Delivery time: on request - subject to prior sale Year of construction: ca.1991 L x W x H: approx. 2200x1200x1800mm Weight: approx. 1500kg Digital display: 3-axis digital display Sino New Dimensions: Max. turning diameter over bed: approx. Ø380mm Max. turning diameter via support: approx. Ø190mm Max.turning length: approx. 1000mm Rod passage: approx. Ø56mm Spindle: Speed range: approx. 25-2000 rpm Spindle nose: A 2-6 Drive power: approx. 4.0kW Automatic Longitudinal & Plan Feeds: Feed range: approx. 0.011–0.80 mm/rev Suitable for threads: Metric 0.30-10mm inches 80-2 3/4 g/'' Diametrical Pitch Thread 80-5.5 Dp Module 0.2-5 Tailstock: MK4 Accessories  3-axis digital display SINO New  3-jaw chuck 200mm New  Quick release holder size B + 1 insert  ...

Specifications: Center height: 220 mm Center width: 1000 mm Spindle bore: 55 mm Bed width: 430 mm Speeds, 2 stages: 18 - 1800 1/min Tailstock mount: MK 4 Quill stroke: 190 mm Feed rate: 0.30 - 3.26 mm/rev Dimensions (WxDxH), approx.: 2650 x 1100 x 1550 mm Equipment: - Quick-change holder System Multifix - Bed stop - Coolant device -Mudguard - Turning chuck protection with restart protection

Article number: 04-03-141 Manufacturer: Weiler Very good general condition Machine partially overhauled Delivery time: on request - subject to prior sale Year of construction: ca.1986 L x W x H: approx. 2000x1000x1700mm Weight: approx. 900kg Digital display: 3-axis digital display Sino New Dimensions: Max. turning diameter over bed: approx. Ø340mm Max. turning diameter via support: approx. Ø185mm Max.turning length: approx. 800mm Rod passage: approx. Ø42mm Spindle: Speed range: approx. 30-2800 rpm Spindle nose: A 2-5 Drive power: approx. 3.0kW Automatic Longitudinal & Plan Feeds: Feed range: approx. 0.016-0.50mm/rev Suitable for threads: metric 0.18 – 28 mm inches 80 – 1 gg/" Diametrical – Pitch Thread 200 – 2 3/4 Dp Module 0.1 – 9 Tailstock: MK3 Accessories  3-axis digital display SINO New  3-jaw chuck 160mm New  Quick Release Holder Size ...

Article number: 04-03-117 Manufacturer: Weiler Very good general condition Machine partially overhauled Delivery time: on request - subject to prior sale Year of construction: ca.1991 L x W x H: approx. 2200x1200x1800mm Weight: approx. 1500kg Digital display: 3-axis digital display Sino New Dimensions: Max. turning diameter over bed: approx. Ø380mm Max. turning diameter via support: approx. Ø190mm Max.turning length: approx. 1000mm Rod passage: approx. Ø56mm Spindle: Speed range: approx. 25-2000 rpm Spindle nose: A 2-6 Drive power: approx. 4.0kW Automatic Longitudinal & Plan Feeds: Feed range: approx. 0.011–0.80 mm/rev Suitable for threads: Metric 0.30-10mm inches 80-2 3/4 g/'' Diametrical Pitch Thread 80-5.5 Dp Module 0.2-5 Tailstock: MK4 Accessories  3-axis digital display SINO New  3-jaw chuck 200mm New  Quick release holder size B + 1 insert  ...

Article number: 04-03-224 Manufacturer: Weiler Very good general condition Machine partially overhauled Shipping time: All rights reserved. Year of construction: ca.1987 L x W x H: approx. 1500x1000x1700mm Weight: approx. 600kg Digital display: 3-axis digital display Sino New Dimensions: Max. turning diameter over bed: approx. Ø280mm Max. turning diameter via support: approx. Ø160mm Max.turning length: approx. 500mm Rod passage: approx. Ø36mm Spindle: Speed range: approx. 15-3550 rpm Spindle nose: A 2-5 Drive power: approx. 3.0kW Automatic Longitudinal & Plan Feeds: Feed range: approx. 0.05-0.80mm/rev Suitable for threads: metric 0.20 – 12 mm inches 80 – 2 gg/" Diametrical – Pitch Thread 160 – 6 Dp Module 0.1 – 4 Tailstock: MK3 Accessories  3-axis digital display SINO New  3-jaw chuck 160mm New  Quick Release Holder Size A + 1 Insert   ...

Article number: 04-03-218 Manufacturer: Weiler Very good general condition Machine partially overhauled Delivery time: on request - subject to prior sale Year of construction: ca.1993 L x W x H: approx. 1700x1000x1700mm Weight: approx. 650kg Digital display: 3-axis digital display Sino New Dimensions: Max. turning diameter over bed: approx. Ø320mm Max. turning diameter via support: approx. Ø198mm Max.turning length: approx. 650mm Rod passage: approx. Ø40mm Spindle: Speed range: approx. 96-2500 rpm Spindle nose: A 2-5 Drive power: approx. 2.2kW Automatic Longitudinal & Plan Feeds: Feed range: approx. 0.007-0.63mm/rev Suitable for threads: Metric 0.25 – 8 mm inches 80 – 2 Gg/" Diametrical – Pitch Thread 200 – 5 Dp Module 0.2 – 4 Tailstock: MK3 Accessories  3-axis digital display SINO New  3-jaw chuck 160mm New  Quick Release Holder Size A +  ...
