lathe and milling used for sale

Incl. pallet Auction-ID: A7-48215-25

A CNC PCB drilling and milling machine for PCB manufacturing is available. Stations: 2, Speed: 125000rpm, Collet: 3.175mm, Tool diameter range: 0.1mm-6.35mm, Working dimensions X/Y: 630mm/765mm, Positioning accuracy: 5µm, Repeatability: 4µm, Rapid traverse: 25m/min. Documentation available. An on-site inspection is possible.

DMG MORI CTX beta 1250 TC 4AYear of manuf. : 2014 Control : Siemens 840 Dsl - Operate Turning diam. : 340 mmTurning length : 1185 mm____________Description:In General:Year of manufacture:2014Control system:Siemens 840 Dsl - OperateSwivel diameter:540 mmTurning length:1,185 mmBar capacity:67 mmMain spindle:Technology:Direct drive spindleSpeed:5,000 rpmPower:32 kWTorque:360 NmBar capacity:67 mmC-axis:0.001°Chuck:Hainbuch Spanntop Axfix 65Hydraulic clamping:Differential pressure clampingClamping cylinder:Hollow clamping cylinderCoolant supply:External (chuck flushing)Sub spindde:Technology:Direct drive spindleSpeed:5,000 rpmPower:32 kWTorque:360 NmC-axis:0.001°Chuck:Hainbuch Spanntop AxfixHydraulic clamping:Differential pressure clampingCoolant supply:External and internalTailstock function:Mechatronic control of the sub spindleTool carrier I (X/Y/Z/B):Technology:Milling spindle on  ...

x-travel: 1200 mm y-travel: 400 mm z-travel: 460 mm table-size: 1500 x 400 mm control: konventionell tool adaptor: SK40 turning speed range: 45 - 2000 U/min quill stroke: ja mm total power requirement: kW weight of the machine ca.: 3,2 t dimensions: 2,8 x 2,5 x 2,1 m Equipment: - ELESTA digital display - Infinitely variable feed - Coolant system - Horizontal milling attachment - Chip guard - Chip trays - Hydraulic machine vice - Machine light - Documentation The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

CONTROLS   CNC controls SIEMENS BASIC FUNCTIONS   number of spindles: 4   number of turrets: 2   live positions: yes   number of c-axes: 4 WORKING RANGE TURNING   turning diameter (max): 100 mm   bar diameter (max): 20 mm MAIN SPINDLE   spindle revolutions (max): 5000 /min COUNTER SPINDLE   spindle revolutions (max): 5000 /min TOOL MAGAZINE   number of positions: 48 ELECTRICAL SPECIFICATIONS   mains voltage: 400 V   mains frequency: 50 Hz DIMENSIONS / WEIGHTS   space requirements -left/right-: 9600 mm   space requirements -front/back-: 1500 mm   total height: 2200 mm   total weight approx.: 2600 kg ATTACHMENTS (TURNING)   bar magazine: optional   - bar length (max): 3000 mm   chip conveyor: yes   coolant unit: yes   hydraulic system: yes Features: - various tool holders - various collets in every millimeter increment - bar feeder (dual channe ...

3x various Bruckner centering tips - Type SD25 cyl. 25-252 - Type F06884 EZ-040730.3 - Type F06884 EZ-040730.3 • Application: For use conventional turning. CNC turning. Roughing and Finish. • Execution: for all turning operations (roughing. finishing and fine turning)Fine to roughing of medium components hardened and ground with high precision • Advantage: long service lifeMaintenance free guaranteed by test report thanks to permanent lubricationreinforced and robust precision bearings for mounting Radial and axial forces. Auction-ID: A1-48483-123

An unused Traub CNC twin-spindle turning and milling center with peripheral equipment is available. Spindle types 1/2: D76/D76, max. turning length: 900mm, max. workpiece diameter: 76mm, number of tool carriers: 3, control system: Traub TX8i-s V8. Main spindle bore: 76mm, taper size: 6, hollow clamping cylinder: D76/20, indexing: 2.5°, clamping pressure range: 8bar-75bar. Counter spindle bore: 76mm, taper size: 6, hollow clamping cylinder: D76/20, indexing: 2.5°, clamping pressure range: 8bar-75bar. Upper tool carrier: axes: X/Y/Z, stations: 12. Lower left tool carrier: axes: X/Y/Z, stations: 12. Lower right tool carrier: axes: X/Y/Z, stations: 12. Including Isi Elbaron RON4DHEC mist extraction and filtration system, custom-built circulation conveyor, Bürener hinged belt chip conveyor, Bürener Eco-Fluid coolant system (600l), cooling unit, coolant chiller, Traub WH workpiece handling ...

x-travel: 290/300 mm y-travel: 330/340 mm z-travel: 150/160 mm total power requirement: kW weight of the machine ca.: 675 kg dimensions of the machine ca.: 2700 x 2500 mm The machine was overhauled by the company Harich in 2017. Machine number: 57330/08 Technical data: Table longitudinal movement (motorized/manual): 290/300 mm Spindle head transverse movement (motorized/manual): 150/160 mm Support vertical movement (motorized/manual): 330/340 mm Angle table clamping surface: 600 x 210 mm Spindle speeds: 40 – 2000 rpm Tool holder: Standard taper 40 Motor power: 1.5/1.9 kW Feed rate range (infinitely variable): 5 – 500 mm/min Rapid traverse: 1200 mm Equipment: 3-axis digital readout (Heidenhain) Vertical milling spindle with quill adjustment Additional horizontal spindle REPAR 2 safety device (www.repar2.com) Operating manual The machine will be loaded onto a Euro-pallet, total height: ...

New and used milling cutters and drills. Various manufacturers Approx. 300-350 pieces The table is not part of the auction. Auction-ID: A7-48592-3

A Mori Seiki CNC turning and milling center with counter spindle including automation is available. Tool turrets: 3, tool stations: 3×16, live tools: all stations, X-axis travel: 210mm, Z1/Z2/Z3-axis travel: 300mm/810mm/300mm, main spindle bore: 55mm, spindle speed: 6000rpm, automation robot: LR Mate 200iC 5L, payload: 5kg, reach: 892mm, repeatability: 0.03mm. Machine dimensions X/Y/Z: approx. 3800mm/2700mm/2500mm, weight: approx. 8900kg, control: Fanuc 31i-A, power-on hours: 101035h, operating hours: 68322h, process hours: 34697h. Including an automated CO2 fire detection system, transformer, machine extraction system, 4× workpiece carriers and an automatic diameter detection system. Documentation available. An on-site inspection is possible.

A Mori Seiki CNC turning and milling center with counter spindle including automation is available. Tool turrets: 3, tool stations: 3×16, live tools: all stations, X-axis travel: 210mm, Z1/Z2/Z3-axis travel: 300mm/810mm/300mm, main spindle bore: 55mm, spindle speed: 6000rpm, automation robot: LR Mate 200iC 5L, payload: 5kg, reach: 892mm, repeatability: 0.03mm. Machine dimensions X/Y/Z: approx. 3800mm/2700mm/2500mm, weight: approx. 8900kg, control: Fanuc 31i-A, power-on hours: 101035h, operating hours: 68322h, process hours: 34697h. Including an automated CO2 fire detection system, transformer, machine extraction system, 4× workpiece carriers and an automatic diameter detection system. Documentation available. An on-site inspection is possible.

CONTROLS   CNC controls FANUC 31I MODEL A BASIC FUNCTIONS   number of spindles: 2   number of turrets: 2   live positions: yes   number of c-axes: 2   number of y-axes: 1 WORKING RANGE TURNING   turning diameter (max): 230 mm   worpiece length max.: 700 mm MAIN SPINDLE   spindle revolutions (min): 50 /min   spindle revolutions (max): 5000 /min   c-axis: yes COUNTER SPINDLE   spindle revolutions (min): 50 /min   spindle revolutions (max): 6000 /min   c-axis: yes X/Z SLIDE   tool fixture: Turret ELECTRICAL SPECIFICATIONS   mains voltage: 400 V   mains frequency: 50 Hz DIMENSIONS / WEIGHTS   space requirements -left/right-: 2800 mm   space requirements -front/back-: 1630 mm   total height: 2200 mm   total weight approx.: 9000 kg ATTACHMENTS (TURNING)   chip conveyor: yes   coolant unit: yes   band filtration unit: yes   coolant through  ...

A Takamatsu CNC twin-spindle turning and milling center is available. 1) Turning diameter: 190mm, turning length: 150mm, max. one-sided machining length: 440mm, max. bar diameter main spindle/counter spindle: 51mm/42mm, spindle nose 1/2: A2-6/A2-5, spindle bearing 1/2: 100mm/85mm, main spindle bore 1/2: 52mm/43mm, spindle speed: 5000rpm, tool stations: 2×12, travel X1/X2: 162.5mm/170mm, travel Z1/Z2: 500mm/500mm, travel Y: +/-35mm, travel A: 550mm, machine dimensions X/Y/Z: approx. 3000mm/2250mm/2100mm, weight: approx. 7400kg, control: Fanuc 32i-B. 2) TOP Automazioni FU350SX bar feeder, max. bar capacity: 52mm, max. bar length: 3200mm, max. remnant length: 300mm, max. feed rate: 30m/min, max. bundle weight: 2000kg, machine dimensions X/Y/Z: approx. 4300mm/1400mm/1200mm, weight: approx. 1200kg. 3) LTA E 120-X-2-H filtration system, year of manufacture: 2022, filter stages: 2, extraction  ...

Two Index CNC turning and milling centers are available. 1) Index G250, year of manufacture: 2008, swing diameter: 560mm, turning length: 800mm, bar capacity: 90mm, spindle diameter: 140mm, spindle speed: 3500rpm, spindle power: 43kW/57kW, torque: 275Nm/363Nm, indexing: 2.5°, tool speed: 6000rpm, tool drive power: 11kW, X/Z travel: 300mm/800mm, rapid traverse X: 30m/min, rapid traverse Z: 22.5m/min, feed force X/Z: 7200N/9000N, quill diameter: 65mm, machine dimensions X/Y/Z: approx. 7300mm/4000mm/2600mm, weight: approx. 14000kg, control: Siemens 840D C200-4D. 2) Index G300, year of manufacture: 1998, retrofit: 2022, turning diameter: 270mm, turning length: 710mm, max. swing diameter: 590mm, main spindle bore: 65mm, spindle diameter: 110mm, spindle speed: 5000rpm, torque: 275Nm, power: 43kW, tailstock center distance: 740mm, max. thrust force: 10kN, short slide travel X/Y: 215mm/180mm, s ...

turning diameter:120 mm turning length:100 mm control:Fanuc Spindle 1 power:7,5 kW Spindle 1 RPM:4500 1/min Spindle 2 power:7,5 kW Spindle 2 RPM:4500 1/min Distance between spindle noses:600 mm Turret No.1 stations / rotary tools:15/15 Power rotary tools turret 1:2,7 kW RPM of rotary tools turret 1:4000 1/min Turret No.2 stations / rotary tools:15/15 Power rotary tools turret 2:2,7 kW RPM of rotary tools turret 2:4000 1/min Travel x/z turret 1:250 / 300 mm Travel x/z turret 2:250 / 920 mm Bar capacity spindle 1:51 mm Bar capacity spindle 2:51 mm power chuck:165 mm Spindle bore sp. 1:62 mm Spindle bore sp. 2:62 mm dimensions of the machine ca.:3700 x 2300 x 3000 mm weight of the machine ca.:5600 kg Used CNC-2-spindle CNC turning and milling center with gantry loader - 2x 15 station turret -automatic gantry loader with turnaround station. 14 station-magazin right side Max. Parts size Ø 12 ...

turning diameter:370 mm turning length:200 mm Spindle 1 RPM:4000 1/min control:Siemens 840 D Spindle 2 RPM:4000 1/min power capacity:L / R 18/24 kW max. torque on the spindle:630 nM C-Axis:0,001° Turret No.1 stations / rotary tools:12/12 VDI 40 Turret No.2 stations / rotary tools:12/12 VDI 40 turning speed range - milling:3000 1/min power capacity - milling spindle:8,8 kW torque rotary tools:28 Nm Bar capacity spindle 1:85 mm total power requirement:65 kVA weight of the machine ca.:13 t dimensions of the machine ca.:5,7x2,4x2,1 m Travel x1:260 mm Travel x2:260 mm Travel Y1:600 mm Travel y2:600 mm Power Chuck:2 x 250 mm manual tool eye:l & r High performance 6-axis subspindle CNC-Lathe with twin turren and rotating tools.

standard turning dia.:200 turning length:max. 810 mm control:MSX-701 MAPPS IV greates pass round over bed:800 mm Max. distance between centres:1130 mm max. turning diameter:320 mm max. workpiecediameter:300 mm bar material dia.:65 mm Traverse X-Axis 1:210 Traverse X-Axis 2:210 mm Traverse X-Axis 3:210 mm Traverse Y-Axis 1:110 (+65/-45) mm Traverse Y-Axis 2:110 (+45,/-65) mm Traverse Z-Axis 1:300 mm Traverse Z-Axis 3:300 mm Traverse Z-Axis 2:810 mm Traverse B-Axis:870 mm turning speed range - spindle:5.000 1/min Number of spindle speed ranges:2 . spindle nose:JIS A2-6 spindle bore:73 mm spindle bearing diameter:120 mm C-Axis:0,001 ° turning speed range - spindle:5.000 1/min spindle nose:JIS A2-6 spindle bore:73 mm bar material dia. max:65/52 mm spindle bearing diameter:120 mm C-Axis:0,001 ° Number of Turrets:3 . Number of tool stations:16 x 3=48 pos Schank height for square tool:20 mm D ...

turning diameter:65 mm turning length:120 mm control:Index C200-4D SL z-axis main spindle travel:390 mm z-axis subspindle travel:390 mm x-axis subspindle travel:600 mm Travel Y1:± 80 mm Travel y2:± 80 mm x-axis rapids:45 m/min y-axis rapids:15 m/min z-axis rapid travel:45 m/min Spindle 1 RPM:5000 1/min Spindle 1 Power:35,5/27,5 kW Spindle 1 Torque:170 /125 Nm Spindle 2 RPM:5000 1/min Spindle 2 power:35,5/27,5 kW Spindle 2 torque:170/125 Nm c-axis:0,00014 ° bar material dia.:65 mm spindle nose:AD 140 spindle bore:85 mm Milling spindle 1 RPM:18000 1/min Milling spindle 1 power:11 kW Milling Spindle1 torque:19 Nm Milling spindle 2 RPM:18000 1/min Milling Spindle 2 power:11 kW Milling spindle 2 torque:19 Nm B-axes swivel angle:230 ° B-axes torque:440 Nm B-axes angle resolution:0,001 ° Milling spindle 1 & 2 tool magazine:80 HSK A40 Milling spindle 2 tool magazine static tools :6 x VDI 25 ...

turning diameter:640 / 400 mm turning length:1500 mm control:Siemens 840 D Powerline Travel turret No.1 (milling spindle) x/y/z:550 / 180 (±90) / 1585 mm Swivle angle milling spindle (B-axis):±120° interpol. ° Rapid traverse feeds turret 1 (milling head) x/y/z:40/24/60 m/min RPM milling spindle:12000 1/min power capacity - milling spindle:12 / 23 kW Torque of milling spindle:100 Nm Tool magazine for milling spindle (turret 1):120 HSK-A 63 Tool change time tool/tool, milling spindle:1,6 s Spindle 1 RPM:4000 1/min Spindle 1 power:36/ 45 kW Spindle 1 Torque:730 Nm Spindle 1 max. bar diameter:90 Spindle 2 RPM:4000 1/min Spindle 2 power:36 / 45 kW Spindle 2 torque:730 Nm Spindle 2 max. bar diameter:90 c-axis:0,001 ° Travel turret 2 x:225 mm Travel Turret 2 z:1595 mm RPM of rotary tools turret 2:4000 1/min no. of tools in turret 2:12 VDI 40 high-pressure pump:20 bar total power requiremen ...

turning diameter:500 mm turning length:1000 mm control:Siemens 840 D spindle:42 / 28 kW spindle turning speed - stepless:31 - 4000 1/min max. torque on the spindle:345 Nm c-axis:360000 x 0,001° feeds -stepless-:0 - 10000 mm/min rapid traverse:10000 mm/min turret stations / rotary tool stations:12/12 VDI 40 RPM of rotary tools:2000 1/min diameter of quill:90 mm quill stroke:80 mm tailstock quill taper ISO:SK 30 Tailstock Travel:600 mm Power rotary tools:3,5 kW :22,5 Nm Rotary tool holders:4 ax./ 4 rad. spindle passage:66 mm total power requirement:30 kW weight of the machine ca.:7,5 t dimensions of the machine ca.:8x 3 x 4 m

standard turning dia.:200 turning length:max. 810 mm control:MSX-701 MAPPS III greates pass round over bed:800 mm Max. distance between centres:1130 mm max. turning diameter:320 mm max. workpiecediameter:300 mm bar material dia.:65 mm Traverse X-Axis 1:210 Traverse X-Axis 2:210 mm Traverse X-Axis 3:210 mm Traverse Y-Axis 1:110 (+65/-45) mm Traverse Y-Axis 2:110 (+45,/-65) mm Traverse Z-Axis 1:300 mm Traverse Z-Axis 3:300 mm Traverse Z-Axis 2:810 mm Traverse B-Axis:870 mm turning speed range - spindle:5.000 1/min Number of spindle speed ranges:2 . spindle nose:JIS A2-6 spindle bore:73 mm spindle bearing diameter:120 mm C-Axis:0,001 ° turning speed range - spindle:5.000 1/min spindle nose:JIS A2-6 spindle bore:73 mm bar material dia. max:65/52 mm spindle bearing diameter:120 mm C-Axis:0,001 ° Number of Turrets:3 . Number of tool stations:16 x 3=48 pos Schank height for square tool:20 mm  ...

turning diameter:160 mm turning length:300 mm control:Siemens 840D Spindle 1 Power:22 kW Spindle 1 RPM:5000 1/min Spindle 1 max. bar diameter:65 Spindle 1 Torque:150 Nm Spindle 2 power:16,8 kW Spindle 2 RPM:5000 1/min Spindle 2 torque:100 Nm Travel for pick up of 2nd Spindle:W2=690 mm dimensions of the machine ca.:´4,5x2,0x2,3 m weight of the machine ca.:9 t CNC turning center with 3 turrets with rotary tool drives and 2 spindles. There is an internal coolant system for the turrets with individual pumps

turning diameter:190 mm turning length:503 mm control: Fanuc 31i - TA Travel x/z turret 1:135 / 503 mm Travel x/z turret 2:135 /503 mm c-axis:Sp. 1 / 2 Spindle 1 RPM:6000 1/min Spindle 1 Power:11/7,5 kW Spindle 1 max. bar diameter:42 mm Spindle 2 RPM:6000 1/min Spindle 2 power:11/7,5 kW Turret No.1 stations / rotary tools:12/12 Turret 1 tool RPM:6000 1/min Turret 1 power rotary tools:7,1 / 2,2 kW Turret No.2 stations / rotary tools:12/12 Turret 2 tool RPM:6000 1/min Turret 2 power rotary tools:7,1 / 2,2 kW total power requirement:53 kVA weight of the machine ca.:5700 t dimensions of the machine ca.:2,3 x 1,6 x 1,94 m High precision cnc turning center, rotary tools and y-axis on upper turret, Robot loader for shafts.

turning diameter:410 mm turning length:500 mm control:Fanuc 21i TB standard turning diameter:275 mm travel -x axis:277 mm travel -y axis:82 (±41) mm travel -z axis:500 mm Spindle 1 RPM:4500 1/min Spindle 1 Power:18,5/18,5/15 kW Spindle 1 max. bar diameter:65 mm turret stations / rotary tool stations:12/12 Power rotary tools:5,5 kW RPM of rotary tools:6000 1/min total power requirement:39,2 kVA weight of the machine ca.:6,2 t dimensions of the machine ca.:3,1 x 2,0 x 2,2 m collet chuck:Hainbuch High precision Turning and Milling Centre with Y-axis and robot loading. Stäubli Robot for shaft loading.

turning diameter:270 mm turning length:710 mm weight of the machine ca.:6,5 t max. swing diameter:590 mm with automatic loading and unloading system G300 with "spindle bore clamping capacity 90mm" in tailstock version The machine has no driven tools. The information in the circuit diagram refers to the rotary drive for indexing the turret, not to driven tools.

turning diameter:270 mm turning length:710 mm weight of the machine ca.:6,5 t max. swing diameter:590 mm with live tools:VDI40 Live tooling VDI40 with automatic loading and unloading system G300 with "spindle bore clamping capacity 90mm" in tailstock version Chip conveyor, belt filter press, hydraulic unit, as well as infeed and outfeed chain conveyor EWAP, with 33 pallets. The machine has no driven tools. The information in the circuit diagram refers to the rotary drive for indexing the turret, not to driven tools.

turning diameter:270 mm turning length:710 mm weight of the machine ca.:6,5 t max. swing diameter:590 mm with automatic loading and unloading system, chip conveyor G300 with "spindle bore clamping capacity 90mm" in tailstock version The machine has no driven tools. The information in the circuit diagram refers to the rotary drive for indexing the turret, not to driven tools.

turning diameter:120 mm turning length:650 mm weight of the machine ca.:11 t dimensions of the machine ca.:5,032 x 3,048 x 2,445 m Gildemeister MF Twin 65-II lathe with loading automation. This machine is suitable as a counter spindle machine for 4-axis machining on the main and counter spindles, complete machining (turning, drilling, milling, Y-axis, B-axis) of bar and shaft parts.

turning diameter:120 mm turning length:650 mm weight of the machine ca.:11 t dimensions of the machine ca.:5,032 x 3,048 x 2,445 m max. swing diameter:250 mm Gildemeister MF Twin 65-II lathe with loading automation. This machine is suitable as a counter spindle machine for 4-axis machining on the main and counter spindles, complete machining (turning, drilling, milling, Y-axis, B-axis) of bar and shaft parts.

turning diameter:33 mm turning length:330 mm control: 840 total power requirement:20 kW weight of the machine ca.:6 t dimensions of the machine ca.:3850,2000,2100 m 17 axes 3 revolvers with the powered tools 1 gantry with the driven tools Main and counter spindle with C axes Barfeeder Machine On-time 58,133 hours

spindle diameter:130 mm spindle diameter:130 mm x-travel:2190 mm y-travel:1520 mm z-travel:1000 mm w-axis:1075 mm table surface area:2000 x 1800 mm workpiece weight max.:8000 kg spindle turning speed range:4,5 x 900 U/min spindle taper: ISO:50 faceplate turning speed range:4,5 x 180 U/min faceplate diameter:785 mm rapid traverse::5000 mm/min total power requirement:40 kW weight of the machine ca.:35 t dimensions of the machine ca.:5,5 x 6,9 x 5,2 m Machine retrofit and overhould with TNC 360 Heidenhain in 2023 and stepless spindle speeds - table indexing 4 x 90° - facing head 785 mm - exhauster - various arbors and tooling

spindle diameter:150 mm x-travel:10000 mm y-travel:2500 mm bore spindle stroke:700 mm Speed of boring spindles:1,25 - 1250 U/min. ram stroke:700 mm dimension of the ram:340 x 340 mm mm spindle taper ISO:50 rapid traverse:5 m/min total power requirement:120 kW weight of the machine ca.:115 t dimensions of the machine ca.:15,1 x 10 x 6,4 m CNC control Siemens 840 Dsl completely modernized 2010 FIBRO CNC drilling work table 2500 x 2500 mm 50 to. workpiece weight Longitudinal travel 2500 mm Angular milling head 4 x 90° Universal angular milling head Panel area approx. 10000 x 5000 mm Chip conveyor and coolant device Aerostatic guides

bore capacity in steel (diameter):- mm throat:- mm bore stroke:- mm x-axis:1.800 mm y-axis:1.600 mm z-axis:1.250 mm w-axis:630 mm max. table load:5.000 kg table length:1.400 mm table width:1.600 mm spindle diameter:105 mm spindle turning speed range:3.300 U/min numbers of positions in the tool changer:40 internal coolant system feed:40 bar Splash guard around rotary table Chip Conveyor Oil cooling unit (chiller) Touch probe Renishaw RMP60 Upgrades in 2024 and 2025 Retrofit of X and Z axis ball screws at producer ? KSK Kurim CZ New linear scales Heidenhain in X and Z axis including cabling retrofit of Z axis - new Biplast V lining on guideways, hand scraped Biplast lining on Z axis new TOS Varnsdorf parts for tool clamping and automatic tool changer arm Overhaul of X, Z and Y axis feed motors at authorized Siemens service (new bearings and sensor) New Siemens hand wheel

turning diameter:220 mm turning length:- mm control:- distance between milling spindels:800 mm spindle speed max.:12.000 U/min daylight:66 mm machine weight ab.:11 t total power requirement:90 kVA Fanuc control Two turrets Two spindles Spindle bore 66 mm on both spindles Two Y-axes Parts gripper Hainbuch chuck on both spindles Tailstock function Chip conveyor Tool eye Short bar loader Tool holder package

spindle diameter:100 mm x-travel:1250 mm y-travel:1100 mm z-travel:950 mm spindle turning speed range:2500 U/min Rotary-table:1100 x 1000 mm table surface area:1000 x 1100 mm tool clamping:69871 DIN spindle stroke:630 mm spindle taper:SK50 total power requirement:22/34 kW max. workpiece weight:3000 kg weight of the machine ca.:13000 kg

x-travel:3500 mm y-travel:2500 mm z-travel:1250 mm w-axis:800 mm bore spindle speeds:2500 U/min table load:12 t dia. of rotary table:1800 x 2200 mm numbers of positions in the tool changer:60 ? Overhauled in 2025 and 2026 ? The spindle was relubricated and new spindle bearings fitted in 2025 by technicians from TOS Varnsdorf ? 12-month warranty and guarantee on geometric accuracy Scope of repairs to the X, Z and B axes 1. Complete dismantling and cleaning of the machine bed for the X and Z axes as well as the B axis 2. Regrinding of X and Z axis guide ways at Czech manufacturer of CNC horizontal boring machines 3. Removal of the old lining from the X- and Z-axis slides and the B-axis 4. Anchoring of re-grinded X and Z axis machine bed 5. New, hand-scraped lining made from Biplast-V on the X- and Z-axis slides, and from new Biplast-V on the B-axis 6. Installation of ball screws, lin ...

spindle diameter:150 mm x-travel:3.000 mm y-travel:2.000 mm spindle stroke:700 mm dimension of the ram:340 x 340 mm ram stroke:700 mm column travel:1.500 mm high speed spindle taper ISO:50 bore spindle turning speed range:3,2 - 1.600 U/min table surface area:2.000 x 2.500 mm max. table load:25.000 kg rapid traverse speed:5/10 m/min feed speeds:1 - 1.500 mm/min faceplate speeds from - to:3,2 - 140 U/min dimensions of the machine ca.:8,4 x 6,8 x 5,9 m weight of the machine ca.:57 t total power requirement:100 kW Full B-axis Aerostatic guides Coolant system with IKZ

bore capacity in steel (diameter):5 - 30 mm x-travel:450 mm y-travel:380 mm total power requirement:1,4 / 2,2 kW weight of the machine ca.:1.100 kg dimensions of the machine ca.:1.000 x 1.400 x 2.900 mm gear box:85 - 2.000 U/min spindle diameter:72 mm bore depth:700 mm throat:300 mm spindle taper MT:3 T-slots:3 x 16/25 mm table-size:700 x 300 mm spindle turning speed range:85/170/250/355/475/710/1000/2000 U/min motor speeds::705/1425 Year:ca. 1975

x-travel:1190 mm total power requirement:25 kW feeds::3 - 2000 mm/min weight of the machine ca.:4,3 t table-size:1600 x 400, 5 Spannbacken mm dimensions of the machine ca.:4000 x 3600 x 2200 mm speeds:45 - 1800 U/min y-travel:530 mm z-travel:540 mm tool taper:ISO 50 control cabinet:940 kg

x-travel:850 mm y-travel:280 mm z-travel:355 mm total power requirement:8 kW weight of the machine ca.:4 t dimensions of the machine ca.:2 x 2 x2.40 m revolutions per minute: 28-1.400 U/min table-size:1.200 x 370 mm surface area:1.060 x 260 mm spindle taper:SK 50

spindle diameter:150 mm x-travel:10000 mm y-travel:2500 mm bore spindle stroke:700 mm ram stroke:700 dimension of the ram:340 x 340 mm spindle taper ISO:50 Speed of boring spindles:1,25 - 1250 U/min. feed speeds infinitely variable:1 - 5000 mm/min rapid traverse:5 m/min total power requirement:120 kW weight of the machine ca.:115 t dimensions of the machine ca.:15,1 x 10 x 6,4 m with CNC SIEMENS 840 Dsl complete retrofit in 2010 FIBRO CNC rotary table 2500 x 2500 mm, 50 to. loading capacity, longitudinal movement 2500 mm, angular milling head 4 x 90° universal milling head floor plate area ca. 12000 x 6000 mm ( 72 m²) chip conveyor and coolant attachment aerostatic guideways

turning diameter:275 mm turning length:900 mm spindle passage:65 mm power capacity at 100 % load:25/20 kW spindle turning speed range:1 - 5000 U/min spindle diameter in front bearing:110 mm c-axis:1 - 500 U/min. number of workpiece supports:4 tool turret:1 x-axis:290 mm y-axis:165 mm z-axis:360 mm b-axis:360 ° rapid speed:18/30 m/min number of tools:2x2 + 2x2 number of driven tools:2x2 + 2x2 mm toolpiece turning speed range:8000 / 2000 U/min power capacity:25% ED 5,8 kW tool taper:TRAUB 60 tool turret:2/3/4 x-axis:170 mm z-axis:600/950 mm y-axis:+/- 60 mm rapid speed:18/15/30 m/min number of driven tools:10 mm toolpiece turning speed range:1 - 6000 U/min power capacity:25% ED 5,8 kW tool taper:DIN 69880 40 x 63 total power requirement:95 kW weight of the machine ca.:16 t dimensions of the machine ca.:10,0 x 3,5 x 3,0 m with CNC TRAUB TX 8i, Barloader TRAUB Stamag DNH61 / 3000, Main and  ...

spindle diameter:150 mm x-travel:3000 mm y-travel:2000 mm spindle stroke:700 mm dimension of the ram:340 x 340 mm ram stroke:700 column travel:1500 mm spindle taper ISO:50 bore spindle turning speed range:3,2 - 1600 U/min table surface area:2000 x 2500 mm max. table load:25000 kg rapid speed:5 / 10 m/min feed speeds:1 - 5000 mm/min total power requirement:100 kW weight of the machine ca.:57 t dimensions of the machine ca.:8,4 x 6,8 x 5,9 m with CNC SIEMENS 840 D full B-axis aerostatic guideways facing head ( 3,2 - 140 rpm ) angular milling head 1000 Nm coolant attahcmnet with internal cooling supply

spindle diameter:130 mm x-travel:2190 mm y-travel:1520 mm z-axis:1520 mm w-axis:1000 mm table surface area:2000 x 1800 mm workpiece weight:8 t spindle motor:18 kW spindle taper ISO:50 spindle turning speed range:4,5 - 900 U/min faceplate diameter:785 mm rapid traverse:5 m/min total power requirement:40 kW dimensions of the machine ca.:5,5 x 6,9 x 5,2 m weight of the machine ca.:35 t Machine was retrofitted in 2023 with HEIDENHAIN TNC 360 CNC control - inf. variable spindle spped - 4 x 90° table positioning - diverse toolholders - dDust exhauster

spindle diameter:120 mm x-travel:1250 mm y-travel:1250 mm z-travel:800 mm W-axis (spindle longitudinal):600 mm Speed of boring spindles:1- 2000 U/min. spindle taper ISO:50 table surface area:1000 x 1000 mm total power requirement:55 kW weight of the machine ca.:18 t with CNC HEIDENHAIN TNC 426 autom. toolchnager 40-pockets coolant attachment

spindle diameter:200 mm x-travel:10000 mm y-travel:4000 mm z-axis:1500 mm W-axis (spindle longitudinal):1000 mm bore spindle turning speed range:1 - 2000 U/min dimension of the ram:600 x 530 mm high speed spindle taper ISO:60/50 rapid motion - x-axis:8000 mm/min rapid motion - y-axis:8000 mm/min rapid traverse Z-axis:5 m/min total power requirement:120 kW weight of the machine ca.:135 t dimensions of the machine ca.:16,0 x 5,0 x 10,0 m with CNC Steuerung HEIDENHAIN iTNC 530 hydrostatic guideways x and Y- axis autom. toolchanger 40-pockets autom. Pickup Station for angular milling head, universal milling head and facing head rotary table 3000 x 3000 mm , max load 60 to. v-axis 2500 mm chip conveyor and coolant attachment

Auction-ID: A1-48962-243

Max. turning length 1050 mm, max. turning diameter 300 mm, left turning spindle DIN 55026 Form A size 8 with spindle bore 100 mm, right turning spindle DIN 55026 Form A size 6 with spindle bore 77 mm, drive power left main drive 37 kW with speed range 12.5-4000 1/min, drive power right main drive 15 kW with speed range 10-5000 1/min, rapid traverse upper cross slide longitudinal and flat each 25 m/min with longitudinal stroke Z-axis 1120 mm and plane stroke X-axis 420 mm, Rapid traverse of lower cross slide longitudinal and flat 25 m/min each with longitudinal stroke Z-axis 940 mm and axial stroke X-axis 185 mm, milling spindle output 9 kW with speed range 80-4000 1/min and rapid traverse 10 m/min, tool magazine with 96 tool positions. Automatic operator door. Chip conveyor. Coolant tank 700+155L with high-pressure pump up to 80Bar. Main spindle with ZF gearbox up to 4000 rpm, 37kw  ...

x-travel: 400 mm y-travel: 390 mm z-travel: 350 mm Control: DIALOG4/CONTOUR 3 tool taper: SK 40 spindle turning speed range: 31 - 3150 U/min feed range: 10 - 2000 mm/min total power requirement: kW weight of the machine ca.: 1,7 t dimensions of the machine ca.: 1.600 x 2.500 x 2.000 mm CNC control DIALOG4/CONTOUR 3 Table: 700 x 480 mm rigid angle table Swivel-type vertical milling head Coolant tank The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

turning diameter over bed: 460 mm turning diameter over slide rest: 274 mm turning length: 1000 mm spindle bore: 58 mm spindle turning speed range: 25 - 2000 U/min turning dia. in gap: 690 mm metric threading: 41 / 0,1 - 14 mm thread - inch: 60 / 2 - 112 inch. thread - module: 34 / 0,1 - 7 mm Whitworth-thread: 60 / 2 - 112 TPI adjustment of the upper slide: 140 mm dia. of quill: 60 mm quill stroke: 120 mm total power requirement: 5,5 kW weight of the machine ca.: 1,7 / 2,0 t dimensions of the machine ca.: 2,2 x 1,0 x 1,3 m A comprehensive range of quality centre lathes characterised by wide versatility,high accuracy and extremely rigid construction. The machines are well equipped with a multi-fix quick change tool post and 2-axis Newall digital readout fitted as standard and a variable speed option is available. Huvema lathes fully conform to CE regulations. Also available in: 1,5m 3 ja ...
