Krauss Maffei KM 300 – 1900 C2 injection molding machine Year of manufacture -2000 Control : MC4 Closing unit Clamping force: 3000 kN Mold opening force, max.: 160 kN Sliding force of the moving plate Opening: 86 kN Sliding force of the moving plate Closing: 68 kN Mold plate size (h x v): 995 mm x 1050 mm Distance between columns (h x v): 630 mm x 630 mm Mold opening stroke: 820 mm Min. mold height: 330 mm mold height: 1150 mm Hydraulic ejector - stroke: 200 mm Forward/reverse ejection force: 58/28 kN injection unit Screw diameter: 70mm Ls/D ratio: 20 Injection pressure: 1778 bar Displacement: 1047 cc Shot weight, PS: 953 g Injection speed: 400cc/sec Screw speed: 218 1/min Plasticizing capacity max.: 75 g/s Nozzle pressure: 110 kN Electrical and hydraulic equipment Pump motor nominal capacity: 55 kW Installed heating power: 30 kW Adjustable barrel heating zo ...

-KM 110-380 CX PVC - Mold clamping force: 1100 kN - Mold opening force: 70 kN - Mounting plate dimensions (H x W): 745 x 770 mm - Clearance between columns (H x W): 470 x 470 mm - Mold opening stroke: 600 mm - Minimum mold height: 300 mm - Opening width: 900 mm - Ejector stroke: mm 150 - Ejector force forward / backward: 22.6 / 9.8 kN Injection unit - Screw diameter: 35 mm - Ls / D ratio: - 22.9 - Injection pressure: 2429 bar - Injection volume: cm3 154 - Injection weight 1): 140 g - Injection capacity: cm3 / s - Screw rotation speed, standard speed 390 - Plasticizing capacity 1): - with standard screw speed: g / s 22.1 Electrical and hydraulic equipment - Pump motor rated power: kW 19 - Installed heater power: kW 10.9 - Number of cylinder heating zones: - 5 - Dry cycle time / stroke according to Euromap 6 2): s / mm 2.1 / 329 - Oil tank capacity: dm3 489 Dimensi ...

Supplied with magnetic plates for assembly of molds Krauss Maffei KM 3200-17200 MX Injection molding machine Year of production - 2006 Clamping force - 32,000 kN The dimensions of the boards - 2270 X 1820 mm Clearance between columns - 1100 X 2000 mm Screw diameter - 135 mm Specific injection pressure - 1784 bar Injection weight - 6860 g Injection volume - 9662 ccm The machine is to be picked up in December 2022 Machine without robot Worked - 62,000 man-hours The amount of oil - 2400 liters Dimensions: 16.04 X 5.21 X 4.07 m Weight - 240 tons

Krauss Maffei KM 320 – 2700 C3 injection molding machine Year of manufacture -2003 Control : MC4 Technical data Closing unit Clamping force: 3200 kN Size of mold plates: 1240 mm x 1240 mm Distance between columns (h x v): 710 mm x 710 mm Mold opening stroke: 769 mm Mold height min.: 120 mm Hydraulic ejector - stroke: 251 mm injection unit – Screw diameter: mm 70 – Ls/D ratio: – 23 – Injection pressure: bar 2389 – Injection volume: cm3 1097 – Injection weight: g 998 – Injection efficiency: cm3/s 393 – Number of screw revolutions: 1/min 272 – Plasticizing efficiency 1): g/s 83/108option – Nozzle pressure force: kN 129 Electrical and hydraulic equipment Adjustable hot runner zones: 20 Hydraulic cores: 2 pcs Euromap connector 12 Hydraulic cylinder tip valve Electric scooping motor Air valves 2 pcs

Krauss Maffei KM 250-1400 C2 Injection molding machine Year of production - 2006 Fully hydraulic locking system. MC 4 control system with color monitor, integrated control panel and built-in disk drive. Plasticizing system 1 complete plasticizing system for thermoplastics with a screw diameter of 60 mm, with back-lock and open nozzle Nozzle radius 15mm, nozzle opening 6mm. TECHNICAL DATA OF THE MACHINE IN STANDARD EXECUTION Closing unit - Mold clamping force: 2500 kN - Mold opening force: 160 kN - Movement force of the movable plate clamping the mold - - - opening: kN 86 - closing: 68 kN - Mounting plate dimensions (h x v): mm 995 x 1050 - Clearance between columns (h x v): mm 630 x 630 - Mold opening stroke: mm 820 - Minimum mold height: mm 330 - Opening width: mm 1150 - Ejector stroke: mm 200 - Ejector force: 58/28 kN Injection unit - Screw diameter: mm 60 - Injec ...

Two twin machines available Fully hydraulic closing system. MC 4 control system with color monitor, integrated control panel and built-in disk drive. Plasticizing system 1 complete plasticizing system for thermoplastics with a screw diameter of 90 mm, with a return lock and an open nozzle. Closing system: Clamping force: 5000 kN Mold opening force, max.: 280 kN Movable pressure plate Sliding force Opening: 137 kN Movable pressure plate Sliding force Closing: 116 kN Mold plate size (hxv): 1270mm x 1200mm Distance between columns (hxv): 900 mm x 800 mm Mold opening stroke: 1170 mm Min. mold height: 480 mm Maximum opening path: 1650 mm Hydraulic ejector - stroke: 250 mm Forward/reverse ejection force: 92548 kN injection unit Screw diameter: 90 mm Injection pressure: 1742 bar Injection volume : 1953 cm³ Injection weight, PS: 1777 gr Injection rate: 649cc/sec Screw spee ...

Clamping force [kN] 8000 Dimensions of mounting plates (hxv) [mm] 1610 x 1250 Clearance between columns (hxv) [mm] 1120 x 1000 min./ max. mold height [mm] 600 - 2000 Maximum opening width [mm] 2000 injection unit Screw diameter [mm] 130 Injection volume [cm3] 6172 Injection weight [g] 5617 Injection pressure [bar] 1296 Dimensions and weight Net weight with control cabinet [t] 55 Dimensions (L x W x H) [m] 10.50 m x 2.65 m x 2.40 m

Krauss Maffei KM 125-390 C2+ injection molding machine Year of production - 1999 Fully hydraulic closing system. MC 4 control system with color monitor, integrated control panel and built-in disk drive. Plasticizing system complete plasticizing system for thermoplastics with a screw diameter of 40 mm Nozzle radius 10mm, nozzle opening 4mm TECHNICAL DATA OF THE MACHINE IN STANDARD VERSION Closing unit – Mold clamping force: kN 1250 – Mold opening force: kN 70 – Dimensions of the mounting plate (h x v): mm 745 x 770 – Clearance between columns (h x v): mm 470 x 470 – Mold opening stroke: mm 600 – Minimum mold height: mm 300 – Opening width: mm 900 – Ejector stroke: mm 150 – Ejector force forward/reverse: kN 22 / 10 injection unit – Screw diameter: mm 40 – Ls/D ratio: – 20 – Injection pressure: 1860 bar – Injection volume: cm3 204 – Inject ...

Clamping/injection matrix Maximum opening width [mm] 1300 Injection unit Screw diameter [mm] 80 Injection volume [cm3] 1433 Shot weight [g] 1304 Injection pressure [bar] 1829 Electro-hydraulic equipment Power rating of the pump motor [kW] 75 Power rating of barrel heating [kW] 36 Dimensions and weight (approximately) Net weight with control cabinet [t] 15.3 Dimensions (L x W x H) [m] 6,91 m x 2,20 m x 2,41 m

Dimensions and weight Net weight with control cabinet [t] 7.69 Dimensions (length x width x height) [m] 4.48 x 1.5 x 2.2 Closing unit Clamping force [kN] 1250 Dimensions of mounting plates (hxv) [mm] 805 x 770 Clearance between columns (hxv) [mm] 530 x 470 Min./max. mold height [mm] min. 300mm Injection unit Screw diameter [mm] 45 Injection volume [cm3] 275 Injection weight [g] 250 Injection pressure [bar] 1878

Krauss Maffei KM 300-1000 CX injection molding machine Year of production - 2010 Fully hydraulic closing system. MC 5 control system with color monitor, integrated control panel and built-in disk drive. SP 1000 plasticizing system complete plasticizing system for thermoplastics with a screw diameter of 50 mm, with a return lock and an open nozzle Nozzle radius 15 mm, nozzle opening 3 mm. Closing unit – Mold clamping force: kN 3000 – Mold opening force: kN 169 – Dimensions of the mounting plate (h x v): mm 995 x 1050 – Clearance between columns (h x v): mm 630 x 630 – Mold opening stroke: mm 820 – Minimum mold height: mm 330 – Opening width: mm 1150 – Ejector stroke: mm 200 – Ejector force forward/reverse: kN 58/28 injection unit – Screw diameter: mm 50 – Ls/D ratio: – 22.0 – Injection pressure: bar 2304 – Injection volume: cm3 432 – Inje ...

Krauss Maffei KM 200-1000 CX Year of production - 2021 Fully hydraulic locking system. MC 6 control system based on an industrial computer in real-time Ethernet technology, equipped with an integrated 21.5 ″ control panel with a color touch screen. Plasticizing system 1 complete plasticizing system for thermoplastics with a screw diameter of 55 mm, with back-lock and open nozzle Nozzle radius 10mm, nozzle opening 4mm TECHNICAL DATA OF THE MACHINE IN STANDARD EXECUTION Closing unit - Mold clamping force: 2000 kN - Mold opening force: 101 kN - Mounting plate dimensions (h x v): mm 915 x 915 - Clearance between columns (h x v): mm 560 x 560 - Mold opening stroke: mm 700 - Minimum mold height: mm 350 - Opening width: mm 1050 - Ejector stroke: mm 200 - Ejector force forward / reverse: 58/28 kN Injection unit - Screw diameter: mm 55 - Ls / D ratio: - 20.0 - Injection pres ...

Closing unit Clamping force [kN] 6500 Dimensions of mounting plates (hxv) [mm] 1530 x 1450 Clearance between columns (hxv) [mm] 1000 x 930 min./ max. mold height [mm] 400 / - Maximum opening width [mm] 1550 injection unit Screw diameter [mm] 80 Injection volume [cm3] 1543 Injection weight [g] 1404 Injection pressure [bar] 2205 Electric-hydraulic equipment Pump motor rated power [kW] 110 Heater power [kW] 59 Dimensions and weight Net weight with control cabinet [t] approx. 45.7 Dimensions (L x W x H) [m] approx. 9.98 x 2.78 x 2.43

Closing unit Clamping force [kN] 500 Dimensions of mounting plates (hxv) [mm] 600 x 600 Clearance between columns (hxv) [mm] 370 x 370 min./ max. mold height [mm] 200 / - Maximum opening width [mm] 600 injection unit Screw diameter [mm] 22 Injection volume [cm3] 38 Injection weight [g] 35 Injection pressure [bar] 2500 Electric-hydraulic equipment Nominal power of the pump motor [kW] 11 Heater power [kW] 6.3 Dimensions and weight Net weight with control cabinet [t] approx. 2.7 Dimensions (L x W x H) [m] approx. 3.53 x 1.41 x 1.96

Krauss Maffei KM 110-520 C1 injection molding machine Year of production - 2004 Fully hydraulic locking system. MC4 control system with color monitor, integrated control panel and built-in disk drive Plasticizing system 1 complete plasticizing system for thermoplastics, abrasive version, 45 mm screw diameter, with backlatch and open nozzle TECHNICAL DATA OF THE MACHINE IN STANDARD EXECUTION Closing unit: - Mold closing force: 1100 kN - Mold opening force: 70 kN - Movement force of the movable plate clamping the mold - - - opening: 35 kN - closing: kN 28 - Mounting plate dimensions (h x v): mm 745 x 770 - Clearance between columns (h x v): mm 470 x 470 - Way of opening the mold: mm 600 - Mold development height: mm 300 - Opening width: mm 900 - Ejector stroke: mm 150 - Ejector force: 22/10 kN Injection unit: - Screw diameter: mm 45 - Injection pressure: 1878 bar - In ...

MC5 control system with color monitor, integrated control panel and built-in disk drive. Plasticizing system 1 complete plasticizing system for thermoplastics with a screw diameter of 50 mm TECHNICAL DATA Closing unit - Mold clamping force: 1760 kN - Mounting plate dimensions (h x v): mm 790 x 740 - Clearance between columns (h x v): mm 560 x 510 - Way of opening the mold max: mm 450 - Height of the mold development min./max: mm 200/600 - Plate opening stroke: mm 1050 - Ejector stroke: mm 130 - Ejector force: 49 kN Injection unit - Screw diameter: mm 50 - Ls / D ratio: 20.2 - Injection pressure: 1892 bar - Injection volume: cm3 393 - Injection weight for PS: 357 g - Injection capacity: cm3 / s 314 - Number of screw revolutions, max: rpm 320 - Nozzle clamping force: 29.4 kN Electrical parameters - Connection value: kW 38 - Heaters power: kW 15.6 - Number of cylind ...

Krauss Maffei KM 650 - 3500 C2 Injection molding machine Year of production - 1999 Location - Poland MC control type 4 Unit crimping Crimping force 6500 kN Tool opening force, max. 346 kN The size of the plates (height x height) 1620 x 1470 mm clearance between columns (height x height) 1000 x 930 mm mold opening path 1150 mm mold mounting height min. Opening width 540 mm 1690 mm Ejector stroke 250 mm Ejector force forward / reverse 226 kN Injection unit Screw diameter 90 mm Ls / D ratio 20 Injection pressure 1742 bar shot weight 1742 g Plasticizing flow max. 83 g / sec nozzle pressure 173 kN Electro-hydraulic devices Rated power of the pump motor 90 kW Installed heating power of 36 kW Cylinder heating control zones 7 Oil filling 1240 ltr. Dimensions and weights Space requirement approx. 9.06 x 2.85 x 2.60 m Gross weight is 30,870 kg Tool weight 11400 kg

Clamping force [kN] 4200 Dimensions of mounting plates (hxv) [mm] 1310 x 1200 Clearance between columns (hxv) [mm] 800 x 800 min./ max. mold height [mm] 580 - 1600 Maximum opening width [mm] 1020 injection unit Screw diameter [mm] 70 mm Injection volume [cm3] 1047 Injection weight [g] 953 Injection pressure [bar] 1778 Electric-hydraulic equipment Pump motor rated power [kW] 75 Heater power [kW] 30 Dimensions and weight Net weight with control cabinet [t] 22 Dimensions (L x W x H) [m] 6.38 m x 2.33 m x 2.48 m

KRAUSS MAFFEI KM 650-3500 C1 injection molding machine Year of production - 2003 Robot name-WITTMANN W 632 Closing force. [tons] - 650 Min. Height of the form [mm] -600 Max. mold height [mm] -1150 Column spacing (hxv) in the light (mm) - 1000 x 930 Mounting plates size - 1490 × 1440 Ejector stroke (max) [mm] -250 Screw diameter [mm] -90 Injection weight [g] -2500 Oil quantity [liter] -1000 Injection sequence in mold -2 Number of hydraulic cores S / R- 0/2 The maximum distance between the plates [mm] -1500

Closing unit Maximum opening width [mm] 1300 injection unit Screw diameter [mm] 80 Injection volume [cm3] 1433 Injection weight [g] 1304 Injection pressure [bar] 1829 Electric-hydraulic equipment Pump motor rated power [kW] 75 Heater power [kW] 36 Dimensions and weight Net weight with control cabinet [t] 15.3 Dimensions (L x W x H) [m] 6.91 m x 2.20 m x 2.41 m Closing unit Clamping force [kN] 3500 Dimensions of mounting plates (hxv) [mm] 1060 x 1095 Clearance between columns (hxv) [mm] 710 x 710 min./ max. mold height [mm] min 380

Clamping force [kN] 20000 Dimensions of mounting plates (hxv) [mm] 2650 x 2400 Clearance between columns (hxv) [mm] 1870 x 1620 min./ max. mold height [mm] 800-1700 Maximum opening width [mm] 3600 injection unit Screw diameter [mm] 150 Injection volume [cm3] 11928 Injection weight [g] 8469 Injection pressure [bar] 1445 Electric-hydraulic equipment Pump motor rated power [kW] 160 Heater power [kW] 109 Dimensions and weight Net weight with control cabinet [t] 111 Dimensions (L x W x H) [m] 14.75 x 4.10 x 3.41

Closing unit Clamping force [kN] 5000 Dimensions of mounting plates (hxv) [mm] 1270 x 1310 Clearance between columns (hxv) [mm] 900 x 800 min./ max. mold height [mm] min 480 Maximum opening width [mm] 1650 injection unit Screw diameter [mm] 80 Injection volume [cm3] 1543 Injection weight [g] 1404 Injection pressure [bar] 2205 Electric-hydraulic equipment Pump motor rated power [kW] 90 Heater power [kW] 44 Dimensions and weight Net weight with control cabinet [t] 7.9 Dimensions (L x W x H) [m] 7.65 m x 2.55 m x 2.55 m

Clamping force [kN] 800 Mounting plate dimensions (hxv) [mm] 610 X 610 Clearance between columns (hxv) [mm] 405 x 405 Min./max. mold height [mm] min 250 Maximum opening width [mm] 750 Injection unit Screw diameter [mm] 35 Injection volume [cm3] 156 Shot weight [g] 142 Injection pressure [bar] 2429 Dimensions and weight (approximately) Net weight with control cabinet [t] 3,5 Dimensions (L x W x H) [m] 4,01 x 1,39 x 2,02

Net weight with control cabinet [t] 3,5 Dimensions (L x W x H) [m] 4,01 x 1,39 x 2,02 Clamping/injection matrix Clamping force [kN] 800 Mounting plate dimensions (hxv) [mm] 610 x 610 Clearance between columns (hxv) [mm] 405 x 405 Min./max. mold height [mm] min 250 Maximum opening width [mm] 750 Injection unit Screw diameter [mm] 35 Injection volume [cm3] 156

Krauss Maffei KM 420-3000 CX Clamping/injection matrix Clamping force [kN] 4200 Mounting plate dimensions (hxv) [mm] 1270 x 1230 Clearance between columns (hxv) [mm] 800 x 800 Min./max. mold height [mm] min 580mm Maximum opening width [mm] 1600 Injection unit Screw diameter [mm] 70 Injection volume [cm3] 1232 Shot weight [g] 1121 Injection pressure [bar] 2389 Electro-hydraulic equipment Power rating of the pump motor [kW] 75 Power rating of barrel heating [kW] 29 Dimensions and weight (approximately) Net weight with control cabinet [t] 22,3 Dimensions (L x W x H) [m] 7,32 x 2,49 x 2,38

Krauss Maffei KM 150-520 C2 with the LR 100 robot Clamping force [kN] 1500 Dimensions of mounting plates (hxv) [mm] 780 x 790 Clearance between columns (hxv) [mm] 500 x 500 Maximum opening width [mm] 900 injection unit Screw diameter [mm] 45 Injection volume [cm3] 275 Injection weight [g] 250 Injection pressure [bar] 1878 Electric-hydraulic equipment Pump motor rated power [kW] 30 Heater power [kW] 16 Dimensions and weight Net weight with control cabinet [t] 7.1 Dimensions (L x W x H) [m] 4.66 x 1.51 x 2.19

Clamping force [kN] 800 Dimensions of mounting plates (hxv) [mm] 610 X 610 Clearance between columns (hxv) [mm] 405 x 405 Maximum opening width [mm] 500 injection unit Screw diameter [mm] 25 Injection volume [cm3] 52 Injection weight [g] 47 Injection pressure [bar] 2500 Dimensions and weight Net weight with control cabinet [t] 2.2 Dimensions (L x W x H) [m] 3.3 x 1.2 x 1.9

Clamping force [kN] 3500 Dimensions of mounting plates (hxv) [mm] 1060 x 1095 Clearance between columns (hxv) [mm] 710 x 710 min./ max. mold height [mm] min 380 Maximum opening width [mm] 1300 injection unit Screw diameter [mm] 50 Injection volume [cm3] 432 Injection weight [g] 393 Injection pressure [bar] 2304 Electric-hydraulic equipment Pump motor rated power [kW] 75 Dimensions and weight Net weight with control cabinet [t] 15.5 Dimensions (L x W x H) [m] 6.79 x 2.17 x 2.25

Clamping force [kN] 1100 Dimensions of mounting plates (hxv) [mm] 745 x 770 Clearance between columns (hxv) [mm] 470 x 470 min./ max. mold height [mm] min 300 Maximum opening width [mm] 900 Injection unit Screw diameter [mm] 45 Injection volume [cm3] 275 Injection weight [g] 250 Injection pressure [bar] 1878 Electric-hydraulic equipment Rated power of the pump motor [kW] 18.5 Heater power [kW] 13 Dimensions and weight Net weight with control cabinet [t] 6 Dimensions (length x width x height) [m] 4.48 x 1.51 x 2.19

Krauss Maffei KM 160-750 CX Clamping/injection matrix Clamping force [kN] 1600 Mounting plate dimensions (hxv) [mm] 820 x 845 Clearance between columns (hxv) [mm] 520 x 520 Min./max. mold height [mm] min 300 mm Maximum opening width [mm] 950 Injection unit Screw diameter [mm] 50 Injection volume [cm3] 393 Shot weight [g] 357 Injection pressure [bar] 1892 Electro-hydraulic equipment Power rating of the pump motor [kW] 22 Power rating of barrel heating [kW] 10,97 Dimensions and weight (approximately) Net weight with control cabinet [t] 6 Dimensions (L x W x H) [m] 4,6 x 1,6 x 2,1

Closing unit Clamping force [kN] 1100 Dimensions of mounting plates (hxv) [mm] 745 x 770 Clearance between columns (hxv) [mm] 470 x 470 Min./max. mold height [mm] min 300 Injection unit Screw diameter [mm] 50 Injection volume [cm3] 393 Injection weight [g] 358 Injection pressure [bar] 358 Dimensions and weight Net weight with control cabinet [t] 7.8 Dimensions (length x width x height) [m] 5.0 x 1.6 x 2.0

Closing unit Clamping force [kN] 1100 Dimensions of mounting plates (hxv) [mm] 745 x 770 Clearance between columns (hxv) [mm] 470 x 470 Min./max. mold height [mm] min 300 Maximum opening width [mm] 900 Injection unit Screw diameter [mm] 45 Injection volume [cm3] 275 Injection weight [g] 250 Injection pressure [bar] 1878 Electrical and hydraulic equipment Rated power of the pump motor [kW] 18.5 Heater power [kW] 13 Dimensions and weight Net weight with control cabinet [t] 6 Dimensions (length x width x height) [m] 4.48 x 1.51 x 2.19 Additional equipment: Single-phase plastic feeder Picker

Closing unit Clamping force [kN] 1300 Dimensions of mounting plates (hxv) [mm] 745 x 770 Clearance between columns (hxv) [mm] 470 x 470 Min./max. mold height [mm] min 300 Injection unit Screw diameter [mm] 55 Injection volume [cm3] 475 Injection weight [g] 432 Injection pressure [bar] 1564 Dimensions and weight Net weight with control cabinet [t] 7.8 Dimensions (length x width x height) [m] 5.0 x 1.6 x 2.0

Clamping/injection matrix Clamping force [kN] 3500 Mounting plate dimensions (hxv) [mm] 1060 x 1095 Clearance between columns (hxv) [mm] 710 x 710 Min./max. mold height [mm] min 380 Maximum opening width [mm] 1300 Injection unit Screw diameter [mm] 50 Injection volume [cm3] 432 Shot weight [g] 393 Injection pressure [bar] 2304 Electro-hydraulic equipment Power rating of the pump motor [kW] 75 Dimensions and weight (approximately) Net weight with control cabinet [t] 15,5 Dimensions (L x W x H) [m] 6,79 x 2,17 x 2,25

Krauss Maffei KM 160-380 CX Clamping/injection matrix Clamping force [kN] 1600 Mounting plate dimensions (hxv) [mm] 820 x 845 Clearance between columns (hxv) [mm] 520 x 520 Min./max. mold height [mm] min 300 mm Maximum opening width [mm] 1250 Injection unit Screw diameter [mm] 40 Injection volume [cm3] 201 Shot weight [g] 183 Injection pressure [bar] 1860 Electro-hydraulic equipment Power rating of the pump motor [kW] 22 Power rating of barrel heating [kW] 10,97 Dimensions and weight (approximately) Net weight with control cabinet [t] 6 Dimensions (L x W x H) [m] m 4,6 x 1,6 x 2,1

Closing unit Clamping force [kN] 8000 Dimensions of mounting plates (hxv) [mm] 1610 x 1530 Clearance between columns (hxv) [mm] 1120 x 1000 Min./max. mold height [mm] min 600 Maximum opening width [mm] 2000 Injection unit Screw diameter [mm] 95 Injection volume [cm3] 3367 Injection weight [g] 3064 Injection pressure [bar] 1795 Electrical and hydraulic equipment Rated power of the pump motor [kW] 90 Heater power [kW] 61 Dimensions and weight Net weight with control cabinet [t] 55 Dimensions (length x width x height) [m] 10.5 x 2.65 x 2.4 Hydraulic auger drive with permanent motor (with torque limitation in the upper speed range). The screw drive is adjustable on the monitor screen. For independent and parallel plasticization when opening and closing the mold, a screw drive with an electric motor or a second pump unit is used Single pneumatic valve on movable mold mou ...

Closing unit Clamping force [kN] 1100 Dimensions of mounting plates (hxv) [mm] 745 x 770 Clearance between columns (hxv) [mm] 470 x 470 Min./max. mold height [mm] min 300 Injection unit Screw diameter [mm] 50 Injection volume [cm3] 393 Injection weight [g] 358 Injection pressure [bar] 1892 Dimensions and weight Net weight with control cabinet [t] 7.8 Dimensions (length x width x height) [m] 5.0 x 1.6 x 2.0

Closing unit Clamping force [kN] 1300 Dimensions of mounting plates (hxv) [mm] 745 x 770 Clearance between columns (hxv) [mm] 470 x 470 Min./max. mold height [mm] min 300 Injection unit Screw diameter [mm] 55 Injection volume [cm3] 475 Injection weight [g] 432 Injection pressure [bar] 1564 Dimensions and weight Net weight with control cabinet [t] 7.8 Dimensions (length x width x height) [m] 5.0 x 1.6 x 2.0

Krauss Maffei KM 450-3500 C3 Closing unit Clamping force [kN] 4500 Dimensions of mounting plates (hxv) [mm] 1270 x 1200 Clearance between columns (hxv) [mm] 900 x 800 Min./max. mold height [mm] min 480 Maximum opening width [mm] 1650 Injection unit Screw diameter [mm] 90 Injection volume [cm3] 1953 Injection weight [g] 1777 Injection pressure [bar] 1742 Electrical and hydraulic equipment Rated power of the pump motor [kW] 90 Heater power [kW] 59 Dimensions and weight Net weight with control cabinet [t] 26.3 Dimensions (length x width x height) [m] 7.98 x 2.35 x 2.51m Pressure tank for increased injection power. The screw is driven by an electric motor Air core Hydraulic core 10 x rotameters Euromap 67

Krauss Maffei KM650-5700CM Closing unit Clamping force [kN] 6500 Dimensions of mounting plates (hxv) [mm] 1550 X 1440 Clearance between columns (hxv) [mm] 1000 X 930 Min./max. mold height [mm] min 600 Maximum opening width [mm] 1750 Injection unit Screw diameter [mm] 95 Injection volume [cm3] 2956 Injection weight [g] 2111 Injection pressure [bar] 1795 Electrical and hydraulic equipment Rated power of the pump motor [kW] 110 Heater power [kW] 59 Dimensions and weight Net weight with control cabinet [t] 39.5 Dimensions (L x W x H) [m] 9.36 x 2.65 x 2.43

Clamping/injection matrix Clamping force [kN] 5000 Mounting plate dimensions (hxv) [mm] 1270 x 1310 Clearance between columns (hxv) [mm] 900 x 800 Min./max. mold height [mm] min 480 Maximum opening width [mm] 1650 Injection unit Screw diameter [mm] 80 Injection volume [cm3] 1543 Shot weight [g] 1404 Injection pressure [bar] 2205 Electro-hydraulic equipment Power rating of the pump motor [kW] 90 Power rating of barrel heating [kW] 44 Dimensions and weight (approximately) Net weight with control cabinet [t] 7.9 Dimensions (L x W x H) [m] 7,65 m x 2,55 m x 2,55 m

Clamping force [kN] 3000 Dimensions of mounting plates (hxv) [mm] 995x1050 Clearance between columns (hxv) [mm] 630x630 Min./max. mold height [mm] min 330 Maximum opening width [mm] 1150 Injection unit Screw diameter [mm] 55 Injection volume [cm3] 523 Injection weight [g] 476 Injection pressure [bar] 1904 Dimensions and weight Net weight with control cabinet [t] 12.5 Dimensions (length x width x height) [m] 5.97 x 2.04 x 2.36

Closing unit Clamping force [kN] 500 Dimensions of mounting plates (hxv) [mm] 490 x 440 Clearance between columns (hxv) [mm] 370 x 320 Min./max. mold height [mm] 150 - 450 Maximum opening width [mm] 750 Injection unit Screw diameter [mm] 22 Injection volume [cm3] 38 Injection weight [g] 35 Injection pressure [bar] 2500 Electrical and hydraulic equipment Rated power of the pump motor [kW] 6.1 Heater power [kW] 6.3 Dimensions and weight Net weight with control cabinet [t] 4 Dimensions (length x width x height) [m] 4.2 x 1.44 x 1.85

Closing unit Clamping force [kN] 1200 Dimensions of mounting plates (hxv) [mm] 640 x 590 Clearance between columns (hxv) [mm] 470 x 420 Min./max. mold height [mm] 180 - 550 Maximum opening width [mm] 950 Injection unit Screw diameter [mm] 40 Injection volume [cm3] 201 Injection weight [g] 183 Injection pressure [bar] 1860 Electrical and hydraulic equipment Rated power of the pump motor [kW] 13.8 Heater power [kW] 11.5 Dimensions and weight Net weight with control cabinet [t] 6.9 Dimensions (length x width x height) [m] 5.3 x 1.6 x 1.88

Producer KRAUSS MAFFEI Type KM 250/1400 CX Year 2010 Clamping unit Clamping force 250 ton Opening stroke 820 mm Distance between tie bars 710 x 630 mm Mould height min. 480 mm Opening width 1300 mm Injection unit Screw diameter 55 mm Injection volume 570 cm³ Shot weight 519 g Injection pressure 2387 bar Measurements and weight Dimensions 6.1 x 2.2 x 2.3 m Machine weight 15000 kg

Inv. Num. : 5875 Type: KM 300-1400 C1 Producer: Krauss Maffei Created: 2001 Parameters: Laser ON: 70,000 h Clamping force: 300 t Screw diameter: 60 mm Injection capacity: 679 cm³ Injection mass: 618 g Min. height of clamping plate: 995 mm Min. width of clamping plate: 1050 mm Distance between uprights (horizontal): 630 mm Distance between uprights (vertical): 630 mm Ejector stroke length: 200 mm Maximum spraying pressure: 2000 bar Pump power: 45 kW Opening the mold: 820 mm Machine length: 6000 mm Machine width: 2100 mm Machine height: 2400 mm Injection weight: 12,500 kg Equipment: Robot Getecha Aschaffenburg GL 5 (built in 2001)

Inv. Num. : 7218 Type: 80-380 CX Producer: Krauss Maffei Created: 2008 Parameters: Clamping force: 800 kN Screw diameter: 40 mm Injection capacity: 201 cm³ Injection mass: 183 g Height of the clamping plate: 670 mm Width of clamping plate: 670 mm Distance between uprights (horizontal): 420 mm Distance between uprights (vertical): 420 mm Opening the mold: 500 mm Injection weight: 3,900 kg

Screw diameter; 105 mm Injectable volume: 3611 cm3 Injection pressure: 1580 bar Column width: 1000 x 930 mm Minimum mould thickness: 600 mm Opening stroke: 1150 mm Cores: 6 Robot Interface: Yes Options: Robot Interface 20 mold heating zones Sequential Injection

Description: Machine number: 44314 Operating voltage: 400 V Frequency: 50 Hz Rated current: 50 A Closing force: 50 to Approx. Onsite Dimension. (l x w x h): 3,500 x 1,200 x 2,000 mm, weight approx.: 3,000 kg

Key data: 550 mm, 1200 mm

BERSTORFF GmbH Mixing mill for all types of rubber compounds Roll width 120 cm Roll diameter 55 cm Machine in very good condition !
