injection used for sale

Clamping/injection matrix Maximum opening width [mm] 1300 Injection unit Screw diameter [mm] 80 Injection volume [cm3] 1433 Shot weight [g] 1304 Injection pressure [bar] 1829 Electro-hydraulic equipment Power rating of the pump motor [kW] 75 Power rating of barrel heating [kW] 36 Dimensions and weight (approximately) Net weight with control cabinet [t] 15.3 Dimensions (L x W x H) [m] 6,91 m x 2,20 m x 2,41 m

Battenfeld HM 500/3400 S injection molding machine Year of production - 2006 Control: Unilog B6 Injection unit… / 3400 S Screw diameter: 65 mm Specific injection pressure: 2500 bar Injection volume: 1244 ccm Shot weight: 1070 g Crimping 500 / ... Strength: 500 t Board dimensions: 1590 x 1470 mm Clearance between columns: 1000 x 800 mm Tool height: 450… 1600 mm Opening for a path of 1150 mm Distance plates: 1600 mm - 1 x pneumatic valve - 1 x NW6 hydraulic core movable plate - Connection via robot. Euromap 67

Clamping force [kN] 5500 Dimensions of mounting plates (hxv) [mm] 1345 x 1280 Clearance between columns (hxv) [mm] 915 x 860 Maximum opening width [mm] 850 injection unit Screw diameter [mm] 80 Injection volume [cm3] 1960 Injection weight [g] 1765 Injection pressure [bar] 1730

Closing unit Clamping force [kN] 2000 Dimensions of mounting plates (hxv) [mm] 795 x 795 Clearance between columns (hxv) [mm] 570 x 570 Min./max. mold height [mm] min300 Maximum opening width [mm] 950 Injection unit Screw diameter [mm] 50 Injection volume [cm3] 392 Injection weight [g] 359 Injection pressure [bar] 2000 Electrical and hydraulic equipment Rated power of the pump motor [kW] 30 Heater power [kW] 14.9 Dimensions and weight Net weight with control cabinet [t] 7.9 Dimensions (length x width x height) [m] 5.53m x 1.79m x 2.2m Additional equipment: Conveyor belt Single-phase plastic feeder Picker

Closing unit Clamping force [kN] 2000 Dimensions of mounting plates (hxv) [mm] 795 x 795 Clearance between columns (hxv) [mm] 570 x 570 Min./max. mold height [mm] min 300 Maximum opening width [mm] 950 Injection unit Screw diameter [mm] 50 Injection volume [cm3] 392 Injection weight [g] 359 Injection pressure [bar] 2000 Electrical and hydraulic equipment Rated power of the pump motor [kW] 30 Heater power [kW] 14.9 Dimensions and weight Net weight with control cabinet [t] 7.9 Dimensions (length x width x height) [m] 5.53m x 1.79m x 2.2m Additional equipment: Conveyor belt Single-phase plastic feeder Dryer Picker

Dimensions and weight Net weight with control cabinet [t] 7.69 Dimensions (length x width x height) [m] 4.48 x 1.5 x 2.2 Closing unit Clamping force [kN] 1250 Dimensions of mounting plates (hxv) [mm] 805 x 770 Clearance between columns (hxv) [mm] 530 x 470 Min./max. mold height [mm] min. 300mm Injection unit Screw diameter [mm] 45 Injection volume [cm3] 275 Injection weight [g] 250 Injection pressure [bar] 1878

Clamping force [kN] 2000 Dimensions of mounting plates (hxv) [mm] 685 x 685 Clearance between columns (hxv) [mm] 520 x 520 injection unit Screw diameter [mm] 45 Injection volume [cm3] 286 Injection weight [g] 240 Injection pressure [bar] 2500 Electric-hydraulic equipment Pump motor rated power [kW] 30 Heater power [kW] 14.9 Dimensions and weight Net weight with control cabinet [t] 6.63 Dimensions (L x W x H) [m] 5.35x1.93x2.20

Clamping force [kN] 1600 Dimensions of mounting plates (hxv) [mm] 1200 min./ max. mold height [mm] min 450 Maximum opening width [mm] 750 injection unit Screw diameter [mm] 45 Injection volume [cm3] 427 Injection weight [g] 360 Injection pressure [bar] 1720 Electric-hydraulic equipment Pump motor rated power [kW] 30 Heater power [kW] 15.8 Dimensions and weight Net weight with control cabinet [t] 9.5

Clamping force [kN] 5500 Dimensions of mounting plates (hxv) [mm] 1280 X 1280 Clearance between columns (hxv) [mm] 900 X 900 min./ max. mold height [mm] min 450 max 800 Maximum opening width [mm] 900 injection unit Screw diameter [mm] 85 Injection volume [cm3] 2128 Injection weight [g] 1936 Injection pressure [bar] 1354

Clamping force [kN] 3000 Dimensions of mounting plates (hxv) [mm] 1060 x 1120 Clearance between columns (hxv) [mm] 720 x 720 min./ max. mold height [mm] 400 - 750 Maximum opening width [mm] 1100 injection unit Screw diameter [mm] 62 Injection volume [cm3] 749 Injection weight [g] 680 Injection pressure [bar] 2100

Closing unit Clamping force [kN] 2000 Dimensions of mounting plates (hxv) [mm] 795 x 795 Clearance between columns (hxv) [mm] 570 x 570 injection unit Screw diameter [mm] 55 Injection volume [cm3] 474 Injection weight [g] 434 Injection pressure [bar] 1650 Electric-hydraulic equipment Pump motor rated power [kW] 30 Heater power [kW] 14.9 Dimensions and weight Net weight with control cabinet [t] 7.9 Dimensions (L x W x H) [m] 5.53 x 1.79 x 2.20

Engel ES 1350/400 HL injection molding machine Year of production - 2000 Screw diameter - 55 mm Injection volume - 618 ccm Injection weight - 556g Closing force - 4000 kN Min.form height - 250 mm Max. mold height - 900 mm Tie-bar-less machine Injection pressure - 2183 bar machine with a robot, a cage, two conveyor belts Weight - 30,000 kg Dimensions in: 7.8m x 2.25m x 2.33m

Closing unit Clamping force [kN] 6500 Dimensions of mounting plates (hxv) [mm] 1530 x 1450 Clearance between columns (hxv) [mm] 1000 x 930 min./ max. mold height [mm] 400 / - Maximum opening width [mm] 1550 injection unit Screw diameter [mm] 80 Injection volume [cm3] 1543 Injection weight [g] 1404 Injection pressure [bar] 2205 Electric-hydraulic equipment Pump motor rated power [kW] 110 Heater power [kW] 59 Dimensions and weight Net weight with control cabinet [t] approx. 45.7 Dimensions (L x W x H) [m] approx. 9.98 x 2.78 x 2.43

Closing unit Clamping force [kN] 500 Dimensions of mounting plates (hxv) [mm] 600 x 600 Clearance between columns (hxv) [mm] 370 x 370 min./ max. mold height [mm] 200 / - Maximum opening width [mm] 600 injection unit Screw diameter [mm] 22 Injection volume [cm3] 38 Injection weight [g] 35 Injection pressure [bar] 2500 Electric-hydraulic equipment Nominal power of the pump motor [kW] 11 Heater power [kW] 6.3 Dimensions and weight Net weight with control cabinet [t] approx. 2.7 Dimensions (L x W x H) [m] approx. 3.53 x 1.41 x 1.96

Demag Ergotech Extra 80-430 Year of production - 2002 Technical data of the closure Closing force: 800 kN Clearance between columns vertical: 400 mm Clearance between columns pos: 400 mm Size of table plates pos: 540 mm Dimension of the table plates vertical: 540 mm Mold height min: 250 mm The distance between the plates: 700 mm Opening distance: 450 mm ejector: 150 mm throwing: 41 kN Centering D of the movable plate: 125 mm Centering D of a fixed plate: 125 mm tool weight: 700 kg Injection technical data screw diameter: 40 mm Injection volume: 231 ccm Injection pressure: 2025 bar Screw path: 150 mm plasticization rate: 160 g / s PS Air injection rate: 33 g / s PS Mouthpiece path: 200 mm Dimensions and weight Dimensions in: 4.2m x 1.32m x 2m Total weight in: 3,900 kg

Closing unit Clamping force [kN] 2750 Dimensions of mounting plates (hxv) [mm] 970 x 970 Clearance between columns (hxv) [mm] 630 x 630 injection unit Screw diameter [mm] 60 Injection volume [cm3] 763 Injection weight [g] 694 Injection pressure [bar] 2144 Dimensions and weight Net weight with control cabinet [t] 15.5 Dimensions (L x W x H) [m] 7.5 x 2.2 x 2.7 m

Demag Extra 150-430 Clamping/injection matrix Clamping force [kN] 1650 Mounting plate dimensions (hxv) [mm] 705 x 700 Clearance between columns (hxv) [mm] 475 x 475 Min./max. mold height [mm] 250-480 Maximum opening width [mm] 930 Injection unit Screw diameter [mm] 40 Injection volume [cm3] 231 Shot weight [g] 205 Injection pressure [bar] 2020 Electro-hydraulic equipment Power rating of the pump motor [kW] 18,5 Power rating of barrel heating [kW] 11,1 Dimensions and weight (approximately) Net weight with control cabinet [t] 5,3 Dimensions (L x W x H) [m] 4,9 x 1,5 x 2,0

Clamping/injection matrix Clamping force [kN] 2750 Mounting plate dimensions (hxv) [mm] 970 x 970 Clearance between columns (hxv) [mm] 630 x 630 Injection unit Screw diameter [mm] 60 Injection volume [cm3] 763 Shot weight [g] 694 Injection pressure [bar] 2144 Dimensions and weight (approximately) Net weight with control cabinet [t] 15,5 Dimensions (L x W x H) [m] 7,5 x 2,2 x 2,7 m

Clamping force [kN] 4200 Dimensions of mounting plates (hxv) [mm] 1310 x 1200 Clearance between columns (hxv) [mm] 800 x 800 min./ max. mold height [mm] 580 - 1600 Maximum opening width [mm] 1020 injection unit Screw diameter [mm] 70 mm Injection volume [cm3] 1047 Injection weight [g] 953 Injection pressure [bar] 1778 Electric-hydraulic equipment Pump motor rated power [kW] 75 Heater power [kW] 30 Dimensions and weight Net weight with control cabinet [t] 22 Dimensions (L x W x H) [m] 6.38 m x 2.33 m x 2.48 m

Closing unit Clamping force [kN] 1300 Dimensions of mounting plates (hxv) [mm] 615 x 615 Clearance between columns (hxv) [mm] 420 x 420 Min./max. mold height [mm] min 250 Injection unit Screw diameter [mm] 45 Injection volume [cm3] 286 Injection weight [g] 240 Injection pressure [bar] 2500 Electrical and hydraulic equipment Rated power of the pump motor [kW] 30 Heater power [kW] 13.8 Dimensions and weight Net weight with control cabinet [t] 4.33

Closing unit Clamping force [kN] 2000 Dimensions of mounting plates (hxv) [mm] 830 x 830 Clearance between columns (hxv) [mm] 560 x 560 Min./max. mold height [mm] min 310 Maximum opening width [mm] 1335 Injection unit Screw diameter [mm] 50 Injection volume [cm3] 451 Injection weight [g] 410 Injection pressure [bar] 1946 Electrical and hydraulic equipment Rated power of the pump motor [kW] 30 Heater power [kW] 15 Dimensions and weight Net weight with control cabinet [t] 9 Dimensions (length x width x height) [m] 5.7 x 1.7 x 2.1

Closing unit Maximum opening width [mm] 1300 injection unit Screw diameter [mm] 80 Injection volume [cm3] 1433 Injection weight [g] 1304 Injection pressure [bar] 1829 Electric-hydraulic equipment Pump motor rated power [kW] 75 Heater power [kW] 36 Dimensions and weight Net weight with control cabinet [t] 15.3 Dimensions (L x W x H) [m] 6.91 m x 2.20 m x 2.41 m Closing unit Clamping force [kN] 3500 Dimensions of mounting plates (hxv) [mm] 1060 x 1095 Clearance between columns (hxv) [mm] 710 x 710 min./ max. mold height [mm] min 380

Engel ES 1350 275 HS Closing unit Clamping force [kN] 2750 Dimensions of mounting plates (hxv) [mm] 1050 x 900 Min./max. mold height [mm] min 350 Maximum opening width [mm] 1200 Injection unit Screw diameter [mm] 55 Injection volume [cm3] 556 Injection weight [g] 130 Injection pressure [bar] 1763 Electrical and hydraulic equipment Rated power of the pump motor [kW] 37 Heater power [kW] 19.8 Dimensions and weight Net weight with control cabinet [t] 19

Clamping force [kN] 20000 Dimensions of mounting plates (hxv) [mm] 2650 x 2400 Clearance between columns (hxv) [mm] 1870 x 1620 min./ max. mold height [mm] 800-1700 Maximum opening width [mm] 3600 injection unit Screw diameter [mm] 150 Injection volume [cm3] 11928 Injection weight [g] 8469 Injection pressure [bar] 1445 Electric-hydraulic equipment Pump motor rated power [kW] 160 Heater power [kW] 109 Dimensions and weight Net weight with control cabinet [t] 111 Dimensions (L x W x H) [m] 14.75 x 4.10 x 3.41

Closing unit Clamping force [kN] 5000 Dimensions of mounting plates (hxv) [mm] 1270 x 1310 Clearance between columns (hxv) [mm] 900 x 800 min./ max. mold height [mm] min 480 Maximum opening width [mm] 1650 injection unit Screw diameter [mm] 80 Injection volume [cm3] 1543 Injection weight [g] 1404 Injection pressure [bar] 2205 Electric-hydraulic equipment Pump motor rated power [kW] 90 Heater power [kW] 44 Dimensions and weight Net weight with control cabinet [t] 7.9 Dimensions (L x W x H) [m] 7.65 m x 2.55 m x 2.55 m

Short circuit force [kN] 800 Dimensions of fastening plates (hxv) [mm] 630 x 630 Clearance between columns (hxv) [mm] 420 x 370 Min./ max. mold height [mm] min 250 Maximum opening width [mm] 475 Injection unit Screw diameter [mm] 35 Injection volume [cm3] 169 Injection size [g] 153.8 Injection pressure [bar] 2083 Dimensions and weight Net weight with control cabinet [t] 4.1 Dimensions (L x W x H) [m] 3.86 x 1.89 x 1.33

Clamping force [kN] 1100 Dimensions of mounting plates (hxv) [mm] 630 x 680 Clearance between columns (hxv) [mm] 470 x 420 min./ max. mold height [mm] 275 - 775 Maximum opening width [mm] 1275 injection unit Screw diameter [mm] 35 Injection volume [cm3] 169 Injection weight [g] 153 Injection pressure [bar] 2083 Dimensions and weight Net weight with control cabinet [t] 4.5 Dimensions (L x W x H) [m] 4.0 x 1.5 x 2.1

Closing unit Clamping force [kN] 500 Dimensions of mounting plates (hxv) [mm] 498 x 498 Clearance between columns (hxv) [mm] 320 x 320 Injection unit Screw diameter [mm] 25 Injection volume [cm3] 54 Injection weight [g] 45 Injection pressure [bar] 2500 Dimensions and weight Net weight with control cabinet [t] 2.15 Dimensions (length x width x height) [m] 3.5 x 1 x 1.7

Closing unit Clamping force [kN] 350 Dimensions of mounting plates (hxv) [mm] 324 x 250 Clearance between columns (hxv) [mm] 221 x 221 Min./max. mold height [mm] 150-300 Maximum opening width [mm] 500 Injection unit Screw diameter [mm] 20 Injection volume [cm3] 31 Injection weight [g] 26 Injection pressure [bar] 2500 Electrical and hydraulic equipment Rated power of the pump motor [kW] 7.5 Heater power [kW] 4.5 Dimensions and weight Net weight with control cabinet [t] 1.06 Dimensions (length x width x height) [m] 2.7 m x 1.4 m x 2.2 m

Arburg 320S 500-150 Closing unit Clamping force [kN] 500 Dimensions of mounting plates (hxv) [mm] 472 x 472 Clearance between columns (hxv) [mm] 320 x 320 Min./max. mold height [mm] min 225 Maximum opening width [mm] 575 Injection unit Screw diameter [mm] 30 Injection volume [cm3] 78 Injection weight [g] 71 Injection pressure [bar] 2210 Electrical and hydraulic equipment Rated power of the pump motor [kW] 15 Heater power [kW] 8.4 Dimensions and weight Net weight with control cabinet [t] 2.25

Krauss Maffei KM 420-3000 CX Clamping/injection matrix Clamping force [kN] 4200 Mounting plate dimensions (hxv) [mm] 1270 x 1230 Clearance between columns (hxv) [mm] 800 x 800 Min./max. mold height [mm] min 580mm Maximum opening width [mm] 1600 Injection unit Screw diameter [mm] 70 Injection volume [cm3] 1232 Shot weight [g] 1121 Injection pressure [bar] 2389 Electro-hydraulic equipment Power rating of the pump motor [kW] 75 Power rating of barrel heating [kW] 29 Dimensions and weight (approximately) Net weight with control cabinet [t] 22,3 Dimensions (L x W x H) [m] 7,32 x 2,49 x 2,38

Clamping force [kN] 350 Dimensions of mounting plates (hxv) [mm] 410 X 410 Clearance between columns (hxv) [mm] 280 x 280 injection unit Screw diameter [mm] 25 Injection volume [cm3] 48 Injection weight [g] 43 Injection pressure [bar] 2441 Electric-hydraulic equipment Nominal power of the pump motor [kW] 11 Heater power [kW] 5 Dimensions and weight Net weight with control cabinet [t] 1.8 Dimensions (L x W x H) [m] 3.20x1.30x1.80 m

Krauss Maffei KM 150-520 C2 with the LR 100 robot Clamping force [kN] 1500 Dimensions of mounting plates (hxv) [mm] 780 x 790 Clearance between columns (hxv) [mm] 500 x 500 Maximum opening width [mm] 900 injection unit Screw diameter [mm] 45 Injection volume [cm3] 275 Injection weight [g] 250 Injection pressure [bar] 1878 Electric-hydraulic equipment Pump motor rated power [kW] 30 Heater power [kW] 16 Dimensions and weight Net weight with control cabinet [t] 7.1 Dimensions (L x W x H) [m] 4.66 x 1.51 x 2.19

Clamping force [kN] 1000 Dimensions of mounting plates (hxv) [mm] 570 x 570 Clearance between columns (hxv) [mm] 420 x 420 injection unit Screw diameter [mm] 40 Injection volume [cm3] 182 Injection weight [g] 153 Injection pressure [bar] 2120 Dimensions and weight Net weight with control cabinet [t] 3430 Dimensions (L x W x H) [m] 4.35 x 1.64 x 2.08

Clamping force [kN] 800 Dimensions of mounting plates (hxv) [mm] 610 X 610 Clearance between columns (hxv) [mm] 405 x 405 Maximum opening width [mm] 500 injection unit Screw diameter [mm] 25 Injection volume [cm3] 52 Injection weight [g] 47 Injection pressure [bar] 2500 Dimensions and weight Net weight with control cabinet [t] 2.2 Dimensions (L x W x H) [m] 3.3 x 1.2 x 1.9

Clamping force [kN] 600 Dimensions of mounting plates (hxv) [mm] 550 x 530 Clearance between columns (hxv) [mm] 320 x 370 min./ max. mold height [mm] 200 - 450 Maximum opening width [mm] 450 injection unit Screw diameter [mm] 30 Injection volume [cm3] 88.4 Injection weight [g] 80.4 Injection pressure [bar] 1100 Electric-hydraulic equipment Nominal power of the pump motor [kW] 11 Heater power [kW] 3.3 Dimensions and weight Net weight with control cabinet [t] 3100 Dimensions (length x width x height) [m] 3600× 1300× 1900

Clamping force [kN] 3500 Dimensions of mounting plates (hxv) [mm] 1060 x 1095 Clearance between columns (hxv) [mm] 710 x 710 min./ max. mold height [mm] min 380 Maximum opening width [mm] 1300 injection unit Screw diameter [mm] 50 Injection volume [cm3] 432 Injection weight [g] 393 Injection pressure [bar] 2304 Electric-hydraulic equipment Pump motor rated power [kW] 75 Dimensions and weight Net weight with control cabinet [t] 15.5 Dimensions (L x W x H) [m] 6.79 x 2.17 x 2.25

Clamping force [kN] 1100 Dimensions of mounting plates (hxv) [mm] 745 x 770 Clearance between columns (hxv) [mm] 470 x 470 min./ max. mold height [mm] min 300 Maximum opening width [mm] 900 Injection unit Screw diameter [mm] 45 Injection volume [cm3] 275 Injection weight [g] 250 Injection pressure [bar] 1878 Electric-hydraulic equipment Rated power of the pump motor [kW] 18.5 Heater power [kW] 13 Dimensions and weight Net weight with control cabinet [t] 6 Dimensions (length x width x height) [m] 4.48 x 1.51 x 2.19

Krauss Maffei KM 160-750 CX Clamping/injection matrix Clamping force [kN] 1600 Mounting plate dimensions (hxv) [mm] 820 x 845 Clearance between columns (hxv) [mm] 520 x 520 Min./max. mold height [mm] min 300 mm Maximum opening width [mm] 950 Injection unit Screw diameter [mm] 50 Injection volume [cm3] 393 Shot weight [g] 357 Injection pressure [bar] 1892 Electro-hydraulic equipment Power rating of the pump motor [kW] 22 Power rating of barrel heating [kW] 10,97 Dimensions and weight (approximately) Net weight with control cabinet [t] 6 Dimensions (L x W x H) [m] 4,6 x 1,6 x 2,1

Demag Extra 160-600 Clamping/injection matrix Clamping force [kN] 1600 Mounting plate dimensions (hxv) [mm] 770 X 770 Clearance between columns (hxv) [mm] 520 x 520 Min./max. mold height [mm] 275 Maximum opening width [mm] 1085 Injection unit Screw diameter [mm] 45 Injection volume [cm3] 291 Shot weight [g] 291 Injection pressure [bar] 1910 Electro-hydraulic equipment Power rating of the pump motor [kW] 22 Power rating of barrel heating [kW] 11,3 Dimensions and weight (approximately) Net weight with control cabinet [t] 6,4 Dimensions (L x W x H) [m] 5,3 x 1,5 x 2,0

Closing unit Clamping force [kN] 1100 Dimensions of mounting plates (hxv) [mm] 745 x 770 Clearance between columns (hxv) [mm] 470 x 470 Min./max. mold height [mm] min 300 Injection unit Screw diameter [mm] 50 Injection volume [cm3] 393 Injection weight [g] 358 Injection pressure [bar] 358 Dimensions and weight Net weight with control cabinet [t] 7.8 Dimensions (length x width x height) [m] 5.0 x 1.6 x 2.0

Closing unit Clamping force [kN] 2000 Dimensions of mounting plates (hxv) [mm] 685 x 685 Clearance between columns (hxv) [mm] 520 x 520 Injection unit Screw diameter [mm] 50 Injection volume [cm3] 353 Injection weight [g] 297 Injection pressure [bar] 2080 Electrical and hydraulic equipment Rated power of the pump motor [kW] 30 Heater power [kW] 14.9 Dimensions and weight Net weight with control cabinet [t] 6.63 Dimensions (length x width x height) [m] 5.35x1.93x2.20

Closing unit Clamping force [kN] 500 Dimensions of mounting plates (hxv) [mm] 472 x 472 Clearance between columns (hxv) [mm] 320 x 320 Min./max. mold height [mm] min 225 Maximum opening width [mm] 575 Injection unit Screw diameter [mm] 30 Injection volume [cm3] 78 Injection weight [g] 71 Injection pressure [bar] 2210 Electrical and hydraulic equipment Rated power of the pump motor [kW] 15 Heater power [kW] 8.4 Dimensions and weight Net weight with control cabinet [t] 2.25 t

Closing unit Clamping force [kN] 1100 Dimensions of mounting plates (hxv) [mm] 745 x 770 Clearance between columns (hxv) [mm] 470 x 470 Min./max. mold height [mm] min 300 Maximum opening width [mm] 900 Injection unit Screw diameter [mm] 45 Injection volume [cm3] 275 Injection weight [g] 250 Injection pressure [bar] 1878 Electrical and hydraulic equipment Rated power of the pump motor [kW] 18.5 Heater power [kW] 13 Dimensions and weight Net weight with control cabinet [t] 6 Dimensions (length x width x height) [m] 4.48 x 1.51 x 2.19 Additional equipment: Single-phase plastic feeder Picker

Closing unit Clamping force [kN] 800 Dimensions of mounting plates (hxv) [mm] 570 x 570 Clearance between columns (hxv) [mm] 420 x 420 Min./max. mold height [mm] min 250 Maximum opening width [mm] 750 Injection unit Screw diameter [mm] 35 Injection volume [cm3] 144 Injection weight [g] 132 Injection pressure [bar] 1820 Electrical and hydraulic equipment Rated power of the pump motor [kW] 15 Heater power [kW] 8.6 Dimensions and weight Net weight with control cabinet [t] 3.18 Dimensions (length x width x height) [m] 4.2 x 1.7 x 1.8 Additional equipment: Single-phase plastic feeder Picker

Closing unit Clamping force [kN] 1300 Dimensions of mounting plates (hxv) [mm] 745 x 770 Clearance between columns (hxv) [mm] 470 x 470 Min./max. mold height [mm] min 300 Injection unit Screw diameter [mm] 55 Injection volume [cm3] 475 Injection weight [g] 432 Injection pressure [bar] 1564 Dimensions and weight Net weight with control cabinet [t] 7.8 Dimensions (length x width x height) [m] 5.0 x 1.6 x 2.0

Clamping force [kN] 4500 Dimensions of mounting plates (hxv) [mm] 1200 x 1200 Clearance between columns (hxv) [mm] 830 x 830 injection unit Screw diameter [mm] 70 Injection volume [cm3] 1480 Injection weight [g] 1360 Injection pressure [bar] 1820 Electric-hydraulic equipment Pump motor rated power [kW] 55 Heater power [kW] 23.7 Dimensions and weight Net weight with control cabinet [t] 20 Dimensions (L x W x H) [m] 6.9 X 2.3 X 2.2

Clamping/injection matrix Clamping force [kN] 3500 Mounting plate dimensions (hxv) [mm] 1060 x 1095 Clearance between columns (hxv) [mm] 710 x 710 Min./max. mold height [mm] min 380 Maximum opening width [mm] 1300 Injection unit Screw diameter [mm] 50 Injection volume [cm3] 432 Shot weight [g] 393 Injection pressure [bar] 2304 Electro-hydraulic equipment Power rating of the pump motor [kW] 75 Dimensions and weight (approximately) Net weight with control cabinet [t] 15,5 Dimensions (L x W x H) [m] 6,79 x 2,17 x 2,25

Demag Ergotech Concept 110/470-600 Clamping/injection matrix Clamping force [kN] 1100 Mounting plate dimensions (hxv) [mm] 670 x 660 Clearance between columns (hxv) [mm] 470 x 470 Min./max. mold height [mm] min 250 Maximum opening width [mm] 850 Injection unit Screw diameter [mm] 50 Injection volume [cm3] 398 Shot weight [g] 359 Injection pressure [bar] 1550 Electro-hydraulic equipment Power rating of the pump motor [kW] 33,3 Power rating of barrel heating [kW] 15,7 Dimensions and weight (approximately) Net weight with control cabinet [t] 5,6 Dimensions (L x W x H) [m] 4,9 x 1,5 x 2,0

Demag Ergotech 2000-840 Clamping/injection matrix Clamping force [kN] 2000 Mounting plate dimensions (hxv) [mm] 830 x 830 Clearance between columns (hxv) [mm] 560 x 560 Injection unit Screw diameter [mm] 60 Injection volume [cm3] 636 Shot weight [g] 570 Injection pressure [bar] 1351 Dimensions and weight (approximately) Net weight with control cabinet [t] 10 Dimensions (L x W x H) [m] 5.70x1.70x2.10
