136,867 used machines on RESALE, but how to find them? Machine Search
Key data: 330 mm, 635 mm, 210 mm
brand new, toolmaker accuracy DIN 8605 Center height 167 mm Center width 635 mm Circulation diameter. over bed 330 mm Circulation diameter. over cross slides 210 mm Circulation diameter. in the offset 480 mm Main spindle bore 40 mm Speed range 40 - 2500 rpm Cone in tailstock MK 3 Drive power 2.2 kW Standard equipment: - 2-axis digital display ACU-RITE® DRO 203 - Precision spindle bearing thanks to NSK® tapered roller bearings - Quick-change steel holder MULTIFIX® size MA - Chip collection tray with opening flap at the front - Movable steel holder protection - Rear splash and chip protection wall - Feed protection - Spindle cover - Removable bridge - Coolant system - Work area lighting - Thread clock - Large matt chrome-plated scales - Foot brake with brake pedal over the entire length -Operating instructions - CE declaration of conformity
Center height 660 mm Distance between the centers length 12000 mm Turning diameter 1320 mm Turning max. via support 950 mm Clamping max. 1200 Power 55 KW Torque 35000 Nm Bezel I 200-630 mm Workpiece weight 21 to Accessories: Conveyor
Self-centering 4 jaw lining NEW Bearings: 315 mm type 3704 400 mm type 3704 400 mm type 3744-11
Key data: 600 mm, 2000 mm, 400 mm
brand new, good handling due to feed switch via joystick and rapid traverse, full-fledged manual transmission with large speed range Technical data: Swing over bed 600 mm over support 400 mm Center height 300 mm Bed width 400 mm Center width 2000 mm Spindle bore 80 mm Speed range (21) 20-2000 rpm quill cone MK 5 incl. accessories: - Rear chip splash protection wall - Electr. Locked face plate/chuck protection - Guide and pull spindle cover - Coolant system - Machine light - Rapid traverse longitudinal and transverse/joy-stick - Feed longitudinal and transverse/joy-stick - Interchangeable wheels - 4-fold steel holder -Operating instructions additionally included in the price: - Fixed bezel 20 - 200 mm - Fixed bezel 180 - 340 mm - Mitlauf. Bezel 20 - 200 mm - Main motor 11 kW instead of 7.5 kW - Cross support machined with T-slots - Reduction gear for t ...
MANDRINO NASO: ASA A2-8 BAR PASS: 90 MM ROUND NUMBER: RPM 2500 COURSE AXIS X: 300 MM COURSE ASSE Z: 1250 MM TURNING DIAMETER: 500 MM TURNING LENGTH: 1200 MM IDRAULIC AUTOCENTRANTE TOOL COUNT: 12 CONTROL: FANUC Oi-TD YEAR: 2010
Parallel lathe Geminis GE650S to be rebuilt. Distance between points: 1000mm. Flip on bench: 680mm. Flip on cart: 410mm. Flip over neckline: 850mm. Main hole: 84mm. Motorized trolley and charriot. Speeds: 18 (13-1000rpm). Main engine: 15hp. Plate and trolley protections and CE RD1215/97 certificate. Quick-change plate and turret.
CNC CONTROL: MSD 501 II, FANUC FEATURES: DIAMETER ADMITTED ON THE BED, MM 680 MAXIMUM TURNING DIAMETER 440 MM N1 MAXIMUM TREATMENT DIAMETER N2 322 MM MAXIMUM TURNING LENGTH, MM 471 THE STANDARD MACHINING DIAMETER MM170 MAIN SPINDLE: STEP PANEL 45 MM COUNTER SPINDLE: HOLE PITCH LINE 43 MM TURRET 1: POSITION N12 ALL MOTORIZED TOWER 2: POSITION N12 ALL MOTORIZED
Key data: 4000 mm, 5000 mm
Specifications Control SIEMENS SINUMERIK 840 Dsl Main dimensions and travels Face plate diameter 4,000 mm Circumferential diameter (max.) 5,000 mm Workpiece height (max.) 5,000 mm Total height of the machine 9,250 mm Maximum workpiece weight 80,000 kg Table base Y Horizontal table displacement 2,500 mm Crossbar Vertical adjustment of the crossbeam 3,200 mm in 50 steps Crossbeam Support (Right) Horizontal adjustment support - 2740 + 2740 mm Vertical displacement of the chisel slider 1,800 mm Cross-section of the chisel slider 250x210 mm Side Support (Right) Vertical adjustment support -25 + 2170 mm Horizontal displacement of the chisel slider 1,000 mm Cross-section of the chisel slider 250x210 mm Turning diameter max./min. 4,500/2,500 mm Main Drive: Main motor power 100 kW Face plate speed range 0.63 – 63 rpm. Maximum torque at the ...
Machine weight: 39,000 kg Faceplate diameter 2000 mm number of supports: 2 pcs. Dimensions : Height 6280 mm width 6600 mm length 4800 mm Extras: Right support with turret head, left and side - sliders. Digital indication of NS 114. Technical condition at the time of sale: Defective rotary amplifier main drive-replacement is required. Require replacement of cables and wires external piping:-machine control cabinets. Repair and adjustment of electrical parts. Not operated since 1994 The maximum dimensions of a workpiece Height 1300 mm Diameter of 2000 mm Weight 15 000 kg
Key data: 2 mm, 10 mm
Description KRAMATORSK CNC heavy lathe 1 K 671 320 F3 Details Type 1 K 671 320 F3 Year of construction 1988 (first commissioned in 1998) Turning length 10,000 mm Turning diameter over bed 2,000 mm (modified) Face plate diameter 1,950 mm Face plate clamping range 400 - 1,350 mm Speeds 1.00 - 140 rpm. Torque 125,000 Nm Main cutting force 130 kN max. Tailstock can be automatically swivelled in max. workpiece weight 70 to max. workpiece weight with steady rest 100 to Drive power 100 kW Number of bed tracks 4 Dimensions 22,000 x 6,200 x 2,900 mm CNC control SIEMENS 840D (2010 for 220,000.00 €) Support feed X-Z 0.3 - 4,000 mm/min. Support rapid traverse X-Z 4,000 mm/min. Dimensions inner cone 140 x 1:7 The machine is up to date with the CE directives incl. 2 steady rests, 1 roller block, 4 jaws, boring device very good c ...
Table diameter 1450mm Max working diameter 1600mm Max height under crosstravel 1000mm Nr. 02 RAM Visualization by DRO 4 axes Good working conditions Machine weight18 ton
Vertical lathe KOLOMNA 1540 T CONVENTIONAL MACHINE READY TO INSTALL Spindle diameter 4.000 mm Working diameter 4.140 mm Max working height 2.060 mm Ram travel 1.250 mm Weight over spindle 100 ton Motor power spindle 100 kW Boring/milling unit included Nr.02 RAM with visualization by DRO Excellent conditions, mechanical really like a new.
Bridgeport EZ Path S Used machine (very good) Control type Cnc Built 2001 Hours K.a. Price 12,500 € net plus VAT Dimensions 3100x1850x1500 Weight 2500 kg Location Haiger Description Universal CNC cycle deer of the brand Bridgeport suitable for tooling, fixture construction, training as well as mold making • Circulation diameter: 430mm • Control: Fanuc 20T Technical data • Circulation diameter 430mm • Peak width 1000mm • Control Siemens Fanuc 20 T • Reitstock MK 4 • Multifix tool station • Speed 1-4000rpm • Connection 380V - 7.5 KW
Machine is equipped wit h HEIDENHEIN DIGITALS 2 TURNING HEADS TURNING LENGHT 1800mm HOLE TROUGH SPINDLE 76mm WITH LINETS AND ACCESORRIESS, READY TO WORK. BEFORE LOADING MACHINE WILL BE CLEANED FOR THE CUSTOMER.
Specifications: Manufacturer: Weisser Type: Univertor AM-1L Year of Make: 2020 Control: CNC control Siemens SINUMERIK 840D sl Travels: X 1,700 mm Z 500 mm Spindle unit left side of the machine Speed Limit| 3,500 rpm Rated speed: 780 rpm Torque: 430/610 Nm (100/40% ED) Spindle bearing Ø: 120 mm Spindle flange: A8 according to DIN 55026 Dressing unit Max. speed: 16,000 rpm Dressing disc holder Ø: 40 x 10 mm Revolver Target turret: 12-speed Drive: electric swivel drive Internal grinding spindle with grinding software Tool holder: D28/43 (thread M28x2) Spindle bearing Ø: 45 mm in hybrid version Speed limit: 45,000 rpm. Rated speed: 30,000 rpm Drive power: 15/18 kw (100/60 % ED) Torque| 4.7/5.7 Nm (100/60% DC) External grinding spindle with grinding software Tool holder taper: 1:10; Ø 73 mm Spindle bearing Ø: 80 mm in hybrid version Speed limit: 6,00 ...
Demoor 825-320 oil country lathe. Distance between centers: 3000mm. Swing: 970mm. Swing in carriage: 700mm. Bore: 320mm. New electrical box. Carriage with cone copier. Equipped with chuck.
Merli Clovis 70 heavy lathe. Distance between centers: 8000mm. Swing: 1650mm. Swing in carriage: 1170mm. Bore: 206mm. Bed width: 1000mm. Speeds: 16.(3-300). Maximun weight without steady rest: 15.000Kgs. Maximun weight with 1 steady rest: 20.000Kgs. Equipped with chuck of 1400mm. Equipped with DRO. Equipped with 2 steady rest. Equipped with CE protections and CE certificate for second hand machines.
Technical data: Turning diameter over bed: 520 mm Turning diameter via support: 310 mm Turning length: 1000 mm Circulation diameter in recess: 580 mm Peak height: 250 mm Bed width: 410 mm Spindle bore: 62 mm Spindle flange: Camlock Gr. 8 Spindle speeds: 24: 9 - 1800 rpm Machine weight approx.: 2.75 t Space requirements approx.: 2.8 x 1.3 x 1.3 m Electrics 380 Volt: 32A Three-jaw lining: 315 mm Forkart Coolant device Measuring system: Glasstab 0.005mm resolution on all 3 axes Quick-release steel holder " Multifix ": C
Perfect, used short time. Lead Screw and Feed Shaft Lathe 3-axis position indicator Workpiece length (max.) 1.928 mm Turning diameter over bed 560 mm Turning-Ø over support 355 mm Turning diameter over gap bridge 785 mm Gap bridge length 170 mm Bed width 350 mm Travel X-axis 316 mm Travel Z1-axis 130 mm Swing range of top slide ± 52° Spindle speeds L 25-200 / H 200-1600 1/min Spindle bore 80 mm Spindle mount Camlock D1-8 Spindle taper MT 7 Feed X-axis 0,02 - 0,573 mm/R Feed Z-axis 0,059 - 1,646 mm/R Tapping, metric (47) 0,2 - 14 mm Tapping, diametric (50) 4-112 DP Tapping, module (39) 0,1 - 7 mm Tapping, whithworth (60) 2-112 TPI Tailstock quill diameter 75 mm Tailstock taper MT 5 Tailstock quill stroke 180 mm Tailstock traverse adjustment ± 12 mm Motor rating main drive 7,5 kW Overall dimensions 3,34x1,15x1,46 m Weight 2.720 kg 3-jaw chuck Ø 315 mm 4- ...
Cazeneuve HB575 rebuilt lathe. Swing over bed: 575mm. Swing over carriage: 300mm. Distance between centers: 4000mm. Spindle nose: 51mm. Motor power: 12,5cv. Equipped with universal chuck of 250mm and steady rest. CE protections in chuck and carriage and CE european certificate for second hand machines. Optional: DRO Fagor or Heidenhain. Optional: CE back guard.
Cazeneuve HB500 rebuilt lathe. Distance between centers: 2000mm. Swing over bed: 500mm. Swing over carriage: 220mm. Motor power: 10cv. Spindle nose: 40,5mm. CE protections in chuck and carriage and CE european certificate for second hand machines. Equipped with universal chuck of 250mm and steady rest. Optional: DRO Fagor or Heidenhain. Optional: CE back guard.
Cazeneuve HB575 rebuilt lathe. Swing over bed: 575mm. Swing over carriage: 300mm. Distance between centers: 750mm. Motor power: 12,5cv. Spindle nose: 51mm. Equipped with universal chuck of 250mm. CE protections in chuck and carriage and CE european certificate for second hand machines. Optional: DRO Fagor or Heidenhain. Optional: Steady rest. Optional: CE back guard
Description Seiger lathe SLZ 800E x 4000 Details Machine no. 4443 Year of construction 2008 Siemens Cycle Control Spindle holder according to DIN 55027 size 11 Spindle bore Ø 130 mm Spindle diameter in the front bearing 170 mm Spindle taper 1:20 Drive power 20/28 kW Main spindle speed switching stage "I" 9-1,800 min-1 Main spindle speed switching stage "II" 9-400 min-1 Maximum torque: 3,200 Nm Center width 4,000 mm Circulation Ø above the bed 810 mm Circulation Ø above the face slide 540 mm Bed width 480 mm Machine dimensions 2,000+center width x 2,750 x 2,000 mm Permissible workpiece masses between points without setting stick 2,000 kg Permissible workpiece masses between points with a setting stick 2,200 kg Permissible workpiece masses between tips with two setting sticks 2,500 kg Permissible workpiece masses flying i ...
Description Heyligenstaedt Lathe NDb-630 Details Year of manufacture 1980 Tip height above bed 630 mm Turning length 3,000 mm Turning diameter over bed 1,240 mm Turning diameter over bed slide 960 mm Max. workpiece weight without support 10,000 kg Bed width over guideways 850 mm Number of guideways 2 Bed height 650 mm Slide path 3,000 mm Face plate diameter 1,100 mm Main spindle diameter in the front bearing 280 mm Max. torque at the face plate 25,000 Nm max. workpiece weight clamped on the fly at center of gravity distance 250 mm in front of face plate 4,000 kg Main spindle speed range 2.24 - 450 rpm. Number of main spindle speeds 4 mech. Levels Power main motor 50 kW Main motor speed 100-1,000-2,500 rpm. Number of supports: 1 Cutting force support 4,000 kg Guide length front bed track 1,300 mm Quill diameter 250 mm ...
Code 93024 Description Chucking lathe Make Warner & Swaswy Model 0 - AC Serial No. 2083651 Year 1972 Swing over bed 200 mm Swing over gap 200 mm Swing over crossslide 200 mm Spindle bore --- mm Longitude: 140 mm Cross: 100 mm Chuck : 160 mm Bore: 20 mm Number of spindle speeds 32 Spindle speeds 58 - 2507 rpm Feeds Longitude and cross Motor power 5,5 kW – 380 Volts Accessoiries hydraulic 3 chuck coolant Condition Machine is in good condition.
used
TSUGAMI B0385L Swiss-Type CNC Sliding Headstock Lathe Year: 2014 Condition: Tooling included (as shown in photos) Specifications subject to buyer verification Machining Capacity • Max barstock diameter: 32 mm • Max machining length: 100 mm • Max main spindle drilling diameter: 13 mm • Max main spindle tapping: M12 • Max back spindle chucking diameter: 38 mm • Max back spindle drilling diameter: 12 mm • Max back spindle tapping: M12 • Max cross drilling diameter: 10 mm • Max cross tapping: M8 • Max tool spindle slotting cutter diameter: 45 mm Spindle Speeds • Main spindle speed: 200 – 6,000 RPM • Back spindle speed: 200 – 7,000 RPM • Tool spindle speed: 200 – 5,000 RPM Tooling & Axes • Total tool capacity (standard): 20 tools • Tool size: 20 × 20 × 125 mm • Controlled linear axes: 5-axis Ra ...
turning diameter over bed: 460 mm turning diameter over slide rest: 274 mm turning length: 1000 mm spindle bore: 58 mm spindle turning speed range: 25 - 2000 U/min turning dia. in gap: 690 mm metric threading: 41 / 0,1 - 14 mm thread - inch: 60 / 2 - 112 inch. thread - module: 34 / 0,1 - 7 mm Whitworth-thread: 60 / 2 - 112 TPI adjustment of the upper slide: 140 mm dia. of quill: 60 mm quill stroke: 120 mm total power requirement: 5,5 kW weight of the machine ca.: 1,7 / 2,0 t dimensions of the machine ca.: 2,2 x 1,0 x 1,3 m A comprehensive range of quality centre lathes characterised by wide versatility,high accuracy and extremely rigid construction. The machines are well equipped with a multi-fix quick change tool post and 2-axis Newall digital readout fitted as standard and a variable speed option is available. Huvema lathes fully conform to CE regulations. Also available in: 1,5m 3 ja ...
turning diameter over bed: 460 mm turning diameter over slide rest: 274 mm turning length: 1000 mm turning dia. in gap: 690 mm spindle bore: 58 mm spindle turning speed range: 25-2000 U/min feeds - longitudinal: 0,031-1,7 mm/U voltage: 400 V / 50 Hz total power requirement: 5,5 kW weight of the machine ca.: 1,8 t dimensions of the machine ca.: 2,3 x 1,0 x 1,5 m • with 3- and 4- jaw chuck, • 2 axis-digital display NEWALL, • fixed and live steady, • Machine light. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
turning diameter over bed: 460 mm turning diameter over slide rest: 274 mm turning length: 1500 mm spindle bore: 58 mm spindle turning speed range: 25 - 2000 U/min turning dia. in gap: 690 mm metric threading: 41 / 0,1 - 14 mm thread - inch: 60 / 2 - 112 inch. thread - module: 34 / 0,1 - 7 mm Whitworth-thread: 60 / 2 - 112 TPI adjustment of the upper slide: 140 mm dia. of quill: 60 mm quill stroke: 120 mm total power requirement: 5,5 kW weight of the machine ca.: 1,7 / 2,0 t dimensions of the machine ca.: 2,2 x 1,0 x 1,3 m A comprehensive range of quality centre lathes characterised by wide versatility,high accuracy and extremely rigid construction. The machines are well equipped with a multi-fix quick change tool post and 2-axis Newall digital readout fitted as standard and a variable speed option is available. Huvema lathes fully conform to CE regulations. Also available in: 1,5m 3 ja ...
turning diameter over bed: 360 mm turning diameter over slide rest: 220 mm turning length: 1000 mm turning dia. in gap: 515 mm spindle bore: 38 mm spindle turning speed range: 30 - 2200 U/min feeds - longitudinal: 0,067 - 1,485 mm/U feeds - cross: 0,033 - 0,742 mm/U voltage: 400 V / 50 Hz total power requirement: 2,5 kW weight of the machine ca.: 0,75 t dimensions of the machine ca.: 2,3 x 1,0 x 1,5 m • with 3- and 4- jaw chuck, • 2 axis-digital display NEWALL, • fixed and live steady, • Machine light. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
turning diameter over bed: 460 mm turning diameter over slide rest: 274 mm turning length: 2000 mm spindle bore: 58 mm spindle turning speed range: 25 - 2000 U/min turning dia. in gap: 690 mm metric threading: 41 / 0,1 - 14 mm thread - inch: 60 / 2 - 112 inch. thread - module: 34 / 0,1 - 7 mm Whitworth-thread: 60 / 2 - 112 TPI adjustment of the upper slide: 140 mm dia. of quill: 60 mm quill stroke: 120 mm total power requirement: 5,5 kW weight of the machine ca.: 1,7 / 2,0 t dimensions of the machine ca.: 2,2 x 1,0 x 1,3 m A comprehensive range of quality centre lathes characterised by wide versatility,high accuracy and extremely rigid construction. The machines are well equipped with a multi-fix quick change tool post and 2-axis Newall digital readout fitted as standard and a variable speed option is available. Huvema lathes fully conform to CE regulations. Also available in: 1,5m 3 ja ...
turning diameter over bed: 460 mm turning diameter over slide rest: 274 mm turning length: 1000 mm spindle bore: 58 mm turning dia. in gap: 690 mm spindle taper: Größe 6, DIN 55029 spindle turning speed - stepless: 30 - 2000 U/min feeds - longitudinal: 0,031 - 1,7 mm/U thread - mm pitch: 0,1 - 14 mm thread - inch: 2 - 112 Gang / inch. tailstock quill diameter: 60 mm tailstock quill taper metric: MT 4 tailstock quill stroke: 120 mm max. workpiece weight between centres: 500 kg voltage: 400 V / 50 Hz spindle motor: 5,5 kW total power requirement: 6 kW weight of the machine ca.: 1,8 t dimensions of the machine ca.: 2,9 x 1,2 x 1,5 m • stepless adjustable turning speed via frequency converter, digital display, 2-axe-DRO, Made:NEWALL The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
turning diameter over bed: 400 mm turning diameter over slide rest: 235 mm turning length: 1000 mm turning dia. in gap: 560 mm spindle bore: 52 mm spindle taper: Größe 6, DIN 55029 spindle turning speed - stepless: 18 - 2120 U/min feeds - longitudinal: 0,015 - 0,6 mm/U face feeds: 0,0075 - 0,3 thread - mm pitch: 0.25 - 7,5 mm thread - inch: 4 - 120 Gang / inch. tailstock quill diameter: 50 mm tailstock quill taper metric: MT 4 tailstock quill stroke: 120 mm max. workpiece weight between centres: 500 kg voltage: 400 V / 50 Hz spindle motor: 5,5 kW total power requirement: 7,5 kW weight of the machine ca.: 1,85 t dimensions of the machine ca.: 2,9 x 1,2 x 1,5 m • stepless adjustable turning speed via frequency converter, digital display, 2-axe-DRO, Made:NEWALL The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
turning diameter over bed: 250 mm turning diameter over slide rest: 130 mm turning length: 700 mm turning speeds: 115 - 1620 U/min centre height: 125 mm spindle bore: 27 mm tailstock quill taper MT: 2 tailstock quill stroke: 40 mm metric threading: 0,2 - 3,5 mm thread - inch: 8 - 56 inch. thread - module: 0,2 - 12,5 mm swival range +/-: Oberschlitten 45 ° connected load frequency: 400 V total power requirement: 0,75 kW weight of the machine ca.: 0,15 t dimensions of the machine ca.: 1,41 x 0,61 x 0,41 m Equipped with - 2-axis digital measuring system with position indicator - manufactured according to DIN 8606 - 27 mm spindle passage - adjustable guideways by adjustable strips - Strong engine with 0.75 kW - High resolution of the axis spindles for exact positioning Delivery: 3-jaw chuck 100 mm, change gear set, splash guard 3-axis digital measuring system fully assembled. The data for ...
Key data: 3200 mm, 2500 mm, 14000 mm
The lathe model 1682A is designed for roughing and finishing work on cast iron or steel parts weighing up to 170 tons. Production year 60’ and complete retrofited in 2011 The largest workpiece dimension above the support is 2500 mm. Parts can be machined using both high-speed steel and carbide-tipped cutters. The machine can be used for turning external surfaces, boring, facing and parting, and turning various cones, radii, and chamfers. The machine is equipped with a Balt-System NC-310/3 CNC system and separate drives for the Z, R, X, U, W, and Q coordinates, enabling the machining of complex surfaces (fill Based on the technical documentation provided, here is a translation and summary of the 1682A Heavy-Duty Lathespecifications, organized by category for better clarity: 1. General Machine Dimensions & Capacity This is a massive industrial lathe designed for exceptionally la ...
turning diameter over bed: 250 mm turning diameter over slide rest: 130 mm turning length: 700 mm turning speeds: 115 - 1620 U/min centre height: 125 mm spindle bore: 27 mm tailstock quill taper MT: 2 tailstock quill stroke: 40 mm metric threading: 0,2 - 3,5 mm thread - inch: 8 - 56 inch. thread - module: 0,2 - 12,5 mm swival range +/-: Oberschlitten 45 ° connected load frequency: 400 V total power requirement: 0,75 kW weight of the machine ca.: 0,15 t dimensions of the machine ca.: 1,41 x 0,61 x 0,41 m Equipped with - 2-axis digital measuring system with position indicator - manufactured according to DIN 8606 - 27 mm spindle passage - adjustable guideways by adjustable strips - Strong engine with 0.75 kW - High resolution of the axis spindles for exact positioning Delivery: 3-jaw chuck 100 mm, change gear set, splash guard 3-axis digital measuring system fully assembled. The data for ...
turning diameter over bed: 320 mm turning diameter over slide rest: 220 mm turning length: 600 mm turning diameter in the gap: 320 mm turning speeds: 60 - 1650 U/min centre height: 160 mm spindle bore: 38 mm tailstock quill taper MT: 3 MK connected load frequency: 400 V total power requirement: 1,1 kW weight of the machine ca.: 340 Kg dimensions of the machine ca.: 1,4 x 0,75 x 0,7 m Center lathe with: 3-jaw chuck 160 mm. 4-jaw chuck 200 mm. Faceplate 200mm Fixed bezel Continuous bezel 4-way steel holder. Halogen machine light Chip tray, chip protection wall Hardened and ground bed tracks Longitudinal and cross feed Complete coolant system Forage protection Set of change gears Machine tools The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
turning diameter: 720 mm turning length: 2000 mm control: Siemens 805 greates pass round over bed: 720 mm bed width: 480 mm spindle diameter in front bearing: 150 mm spindle bore: 106 mm swing diameter over face slide: 430 mm total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
faceplate diameter: 3100 mm swing diameter: 3600 mm turning height: 3600 mm control: Fagor 8035 table load: 35 t turning speeds: 0,32 - 40 U/min max. ram stroke: 3000 mm table load: 35 t turning speeds: 0,32-40 U/min total power requirement: 70 kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
Key data: 1600 mm, 3500 mm, 800 mm
For sale is: 1 Piece Used Face and Lace Lathe Manufacturer: Werkzeugmaschinenfabrik Zerbst GmbH Type: DP1 / S3 x 3500 Year of manufacture: 1994 Technical data: Largest turning diameter over bed: 1,600mm Center width: 3,500mm Spindle bore: 100mm Face plate diameter: 1,250mm Total mass of the machine: approx. 24.8t incl. documentation Further pictures and videos can be sent on request. The following things have been renewed/repaired on the machine in the last four years: At the end of 2022, the tailstock was completely overhauled. New bearing and new tip and lubrication. 2024 Cross Support regenerated. Refurbishment of the wedge strips with new sliding coating, snatchers on the guideways smoothed by scraping, Bearing seats of the spindles made smooth, wedge strips in the contact surface and covering surface scraped. Lubrication pump cle ...
faceplate diameter: 3.000 mm swing diameter: 7.000 mm turning height: 3.000 mm Control: FANUC 18i-TB total power requirement: 60/75 kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
turning diameter over bed: 560 mm turning diameter over slide rest: 355 mm turning length: 1500 mm spindle bore: 80 mm spindle turning speed range: 25 - 1600 U/min turning dia. in gap: 785 mm metric threading: 0,2 - 14 mm thread - inch: 2 - 112 inch. thread - module: 34 / 0,1 - 7 mm Whitworth-thread: 60 / 2 - 112 TPI adjustment of the upper slide: 140 mm dia. of quill: 130 mm quill stroke: 120 mm total power requirement: 7,5 kW weight of the machine ca.: 2,3 t dimensions of the machine ca.: 2,8 x 1,20 x 1,5 m A comprehensive range of quality centre lathes characterised by wide versatility,high accuracy and extremely rigid construction. The machines are well equipped with a multi-fix quick change tool post and 2-axis Newall digital readout fitted as standard and a variable speed option is available. Huvema lathes fully conform to CE regulations. Also available in: 1,5m 3 jaw chuck 4 jaw ...
Change gear, change gears, gear -for: heavy-duty lathe Braun Zerbst -Number: 23 pieces change gears -Module: mm -Dimensions: 530/530/H735 mm -Weight: 144 kg
Lacfer CR2-E250 rebuilt lathe. Distance between centers: 1.500mm. Swing: 530mm. Swing over carriage: 320mm. Swing in gap: 740mm. 16 speeds. (18-1.600rpm). Main motor power: 10hp. Spindle bore: 60mm. Equipped with universal chuck. Equipped with steady rest. CE certificate for european used machines.
turning diameter: 1120 mm turning length: 6000 mm swing diameter over bed slide: 760 mm total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m Brand: Colombo Type: VUP 2S Year of make: 1978 Distance between centers: 6.000 mm Centre height: 560 mm Swing over bed: 1.120 mm ø Swing over support: 760 mm ø 4-Jaw chuck: 1.000 mm ø Digital read-out: Sony Including: 1 x steady rest 520 mm ø 1 x steady rest 950 mm ø 1 x open steady rest Chisel holder Chisel support automatic feed Rapid traverse chisel support Electrically movable counter center Drilling bar: length 2046 mm x 170 mm ø The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
