pressure: 200 t stroke: 150 mm table surface area: 850x650 mm ram surface: 730x560 mm weight of the machine ca.: 8 t dimensions of the machine ca.: BxTxH 2000x2500x3600mm m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
pressure: 100 t throat: 380 mm stroke: 300 mm arm length: 380 mm table surface area: 1700x700 mm ram surface: 1400x700 mm dayligth: 650 mm total power requirement: 30 kW weight of the machine ca.: 10 t dimensions of the machine ca.: 2400x3600x3400 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
Key data: 2200 t
Qty. 1 Second-hand extrusion press – 2200 MT Mfc.: Breda Danieli Built: 2016 Status: still in production Max. Extrusion Force: 21,9 MN at 300 bar Max. working pressure: 310 bar Type of press: back loading with 2 containers Billet size 8” - length: 300 – 1,200 mm Scope of supply: complete extrusion press in working order with hydraulic and electric system Overhead pinch billet manipulator Material: AL 6000 Series Out of the scope of supply: floor frame mounted in the concrete floor all dies and tooling bolsters
Qty. 1 Second-hand 160 MN Horizontal Direct Single Action Extrusion Press Mfc.: SMS Force: 16 000 MT Built: 2015/2016 Billet dim.: Dia. 610/720 x 750 – 2500 mm Scope of supply: Induction Billet Furnace Extrusion Press Quenching System Puller Run-Out Table Stretcher Finishing Saw Profile Stacker Die Oven Billet Peeling Machine
Nominal force 1250 ton - first stage : 260 tons, - second stage : 800 tons, - third stage : 1250 tons, Slide stroke 1250 mm Distance between table and slide 2650 mm Main cylinder dia Ø 500mm Return cylinder dia. ( two) 2xØ400mm Distance between column 1800mm Table size width / length 1250 / 3150 mm Main motor power 150 kW Machine dimensions L x W x H 16950 x 12100 x 11410 mm Weight 265000 kg Forging manipulator FS2ЕТС -2T also available 1T and 700t
HYDRASAN 350 T hydraulic press was built in 2007. There are 2 such machines available for sale. A price included in the offer applies to one machine. Technical specifications of the HYDRASAN 350 T press - maximum press force: 350 t - lower work table surface area (L x W): 1300 x 420 mm - movable table stroke: 300 mm - distance between tables: 400 mm - approach speed: 4.8 mm/s - return speed: 5.1 mm/s - piston diameter (cylinder internal diameter): 230 mm - directional control valve: REXROTH 4WE 10 G33/CG24N9K4 - pump flow rate: 40 l/min - oil tank capacity: 120 l - hydraulic oil gauge: PAKKENS - working pressure: 230 bar - manostat: REXROTH HED 80A 20/350 - electric motor power: 5.5/11 kW - electric motor rotational speed: 1450 rpm - power supply: 380 V; 50 Hz - dimensions of the HYDRASAN machine (L x H): 1800 x 2200 mm
pressure: 100 t throat: 380 mm stroke: 400 mm power capacity: 22 kW dayligth: 600 mm ram surface: 600x500 mm table surface area: 720x600 mm weight of the machine ca.: 9 t The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
pressure: 200 t distance between columns: 500 mm stroke: 150 mm ram surface: 320 mm table surface area: 470x400 mm weight of the machine ca.: 12 t dimensions of the machine ca.: 2000x2000x2700 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
Inv. Num. : 8131 Type: HPD-S 63 Producer: Hydrap Created: 1997 Parameters: Compressive force: 63 t Stroke: 1000 mm Maximum lifting speed: 410 mm/s Machine height: 2200 mm Machine length: 1200 mm Machine width: 500 mm Machine weight: 13000 kg
pressure: 160 t distance between columns: 850 mm stroke: 400 mm ram surface: 800x700 mm : 300 mm pressure of ejector: 20 t table surface area: 800x700 mm total power requirement: kW weight of the machine ca.: 12 t dimensions of the machine ca.: 1800x1800x4200 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
pressure: 40 t throat: 320 mm stroke: 250 mm arm length: 320 mm table surface area: 1400x600 mm ram surface: 1200x600 mm dayligth: 650 mm total power requirement: 22 kW weight of the machine ca.: 8 t dimensions of the machine ca.: 3200x3300x3300 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
pressure: 25 t stroke: 100 mm table surface area: 440x320 mm ram surface: 360x220 mm hole in the table: 160x100 mm table height: 900 mm tool hole in ram: Ø 40 mm dayligth: 280 mm weight of the machine ca.: 1,5 t dimensions of the machine ca.: BxTxH 1500x1500x2100 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
pressure: 25 t throat: 250 mm stroke: 100 mm ram surface: 500x400 mm hole in the table: Ø 110 mm table height: 850 mm tool hole in ram: Ø 40 mm ram surface: Ø 150 mm weight of the machine ca.: 2,5 t dimensions of the machine ca.: 1500x2000x2200 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
pressure: 25 t distance between columns: 580 mm stroke: 150 mm dayligth: 370 mm table surface area: 560x400 mm ram surface: 400x350 mm hole in the table: 80 mm weight of the machine ca.: 2,5 t dimensions of the machine ca.: 1500x500x2500 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
pressure: 100 t passage width: 810 mm stroke: 400 mm table surface area: 1140x740 mm ram surface: 1140x740 mm dayligth: 670 mm weight of the machine ca.: 8 t dimensions of the machine ca.: 1800x1800x3000 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
pressure:6,3 t throat:170/180 mm stroke:310 mm power capacity:3 kW dayligth:775 mm weight of the machine ca.:1,5 t clamping table:470 x 330 mm table height over floor:800 mm C-Type 1 Station
press capacity:950 kN control:Siemens S7 Required air-pressure:6 bar loading area:1200 x 600 mm Pressure power:1000 kN total power requirement:18 kW weight of the machine ca.:6200 kg dimensions of the machine ca.:2600 x 1300 x 3100 mm
pressure:10 t stroke:400 mm total power requirement:1,6 kW weight of the machine ca.:1,1 t dimensions of the machine ca.:1100 x650 x 2050 mm dayligth:500 mm table-size:400 x 450 mm Documents:vorhanden
pressure:160 t throat:360 mm stroke:500 mm total power requirement:17 kW weight of the machine ca.:7,2 t dimensions of the machine ca.:2,0 x 0,95 x 3,70 m table-size:900 x 630 mm Documents:vorhanden
pressure:160 t throat:360 mm stroke:500 mm Documents:vorhanden
pressure:60 t distance between columns:650 mm stroke:220 mm distance table/ram, max. stroke up, adjustment up:410 mm table surface area:600 x 525 mm hole in the table:110 mm table height over floor:900 mm side window:200 mm ram surface:560 x 490 mm power requirement:15,0 kW dimensions (WxDxH):1,9 x 1,3 x 2,7 m foundation pit:not necessary
pressure:250 t distance between columns:1110 mm stroke:250 mm Distance table/ram, max. stroke up, adjustment up:500 mm Table surface area:1100 x 900 mm Table height above floor:950 mm Side window:690 mm Ram surface:1100 x 900 mm Oil volume:730 l Power capacity:56,0 kW Dimensions (WxDxH):2,3 x 1,55 x 3,96 m
pressure:300 t distance between columns:1800 mm stroke:1000 mm Distance table/ram, max. stroke up, adjustment up:1300 mm Table surface area:1600 x 1200 mm Table height above floor:1080 mm Ram surface:1600 x 1200 mm Weight:24,0 t Dimensions (WxDxH):2,8 x 2,1 x 6,0 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2
Unused, crimping range 15-63mm, maximum aperture 75mm, 53.5 mpa, force 500 T, 3000W
Equipped with shrinkage of 6-45 mm; Manual pump; Shrink force 1000Kn; 7 Sets of molds; Completion indicator light; Maximum opening diameter without mold: 50mm; Maximum opening diameter with mold: 40mm; Hydraulic tank capacity: 1L; Hydraulic oil capacity: 0.5L; Unused
Equipped with shrinkage of 6-45 mm; Manual pump; Shrink force 1000Kn; 7 Sets of molds; Completion indicator light; Maximum opening diameter without mold: 50mm; Maximum opening diameter with mold: 40mm; Hydraulic tank capacity: 1L; Hydraulic oil capacity: 0.5L; Unused
Hydraulic Hose Press; Crimping range: 15-63mm, Max aperture: 75mm, Voltage: 380V, Wattage: 3000W, Pressure: 53.5 Mpa Packing size: 780x540x1350 Weight incl. packaging: 280 kg Unused.
Equipped with shrinkage of 6-45 mm; Manual pump; Shrink force 1000Kn; 7 Sets of molds; Completion indicator light; Maximum opening diameter without mold: 50mm; Maximum opening diameter with mold: 40mm; Hydraulic tank capacity: 1L; Hydraulic oil capacity: 0.5L; Unused
C-Frame construction Die height 850 mm Thickness bolster plate 100 mm Throath C Side 360 mm Ram stroke 500 mm Power 22.5 kW Accrete speed 100 mm/min. Working speed 10 mm/min. Return speed 125 mm/min. Machine ready for transport to be assessed on viewing day
Hydraulic press manufactured in 2003. This Darley EHP-LS 230.31/25 features a press force of 230 tons and a maximum bending length of 3100 mm. It includes a throat depth of 400 mm and a stroke of 275 mm. The machine is equipped with CNC control and independent hydraulic axes for enhanced precision. If you are looking to get high-quality bending capabilities, consider the Darley EHP-LS 230.31/25 hydraulic press we have for sale. Contact us for further details.
This 3-axis SXKH HMG-300JM hydraulic press was manufactured in 2014. It features a substantial table dimension of 2200 x 1800 mm and a weight capacity of 36000 kg. The machine operates with a forward speed of up to 4200 mm/min and has a power rating of 30 kW. If you are looking to get high-quality pressing capabilities, consider the SXKH HMG-300JM machine we have for sale. Contact us for further details.
Press capacity: 50 ton Throat depth: 265 mm Stroke: 250 mm Daylight: 400 mm Table surface area : 700 x 450 mm Slide area: 550 x 300 mm Table height over floor: 850 mm Approach speed: 32 mm / sec Working speed: 6,3 mm / sec Return speed: 42 mm / sec Required power: 4 kW Dimensions L x W x H: 1290 x 1160 x 2085 mm Weight of machine approx.: 1,75 ton
Pressure switches REXROTH HED 8 0H 20/50 K14 S ( HED80H20/50K14S ) R901102712 Pv = 5...50 bar Pmax = 350 bar Dimensions: 90 x 90 x 40 mm
Pressure switches REXROTH HED 8 0H 20/50 K14 ( HED80H20/50K14 ) R901102349 Pv = 5...50 bar Pmax = 350 bar Dimensions: 90 x 90 x 40 mm
Pressure switch REXROTH HED 4 0A 15/100 Z14 ( HED40A15/100Z14 ) Pv = 10...100 bar Pmax = 350 bar lockable ! Dimensions: 160 x 90 x 40 mm
Pressure Switches REXROTH HED 8 0A 12/100 K14 536027 Pv = 10...100 bar Pmax = 350 bar Dimensions: 120 x 80 x 40 mm
Hydraulic Testing Press WALTER + BAI AG 200 kN D-200-D / CSRG-5501 pressure max: 200 kN stroke: max approx. 200 mm (at the moment limited by measuring probe and limit switch) largest height: 400 mm table: 340 x 340 mm 380 V Dimensions: 1300 x 840 x 2050 mm
