hydraulic nc press used for sale

Single column hydraulic press SCHULZ type SES 250Masch.Nr. 04.86.3511/3 Year of manufacture 1986Compressive force 25 ton. Retraction force 10 toProjection 360 mmTable surface 600 x 720 mmPlunger area 500 x 500 mmFailure opening in table 100 mmPin hole 40 mmPlunger stroke 400 mmInstallation height max. 600 mmTable height above floor 935 / 775 mmTank capacity hydraulics 380 litresDrive power 7.5 kWNet connection 380 volts, 50 Hz- Fixed stop adjustment in the press cylinder 180 mm- Light barrier

2-column hydraulic press SELF-MADEBaucy approx. 1980Compressive force 6 ton. at 180 barCompressive force 5 ton. at 150 barCompressive force 4 ton. at 120 barCompressive force 3 ton. at 90 barTable top 400 x 340 x 30 mmPlunger plate 410 x 350 x 28.5 mmTable usable area between the guide columns 305 x 245 mmPlunger stroke 140 mmInstallation height max. 320 mmColumn diameter 35 mmTable height above floor 1050 mmHydraulic operating pressure max.180 barMotor power 4 kWNet connection 380 volts, 50 Hz- stepless

Key data: 5 t, 150 mm

Hydraulic Press Atsugi AP-5-KL Used Load Range: 20-50 (kN) Stroke (mm): 150 Lower Speed ​​(Approach Fast Speed: 350 (mm/s) Lower Speed ​​(Under Pressure Slow Speed: 36mm/s Rise Speed ​​250 (mm/s) Working Area Open Height: 250mm Open Depth: 180mm Table Size: 450x50mm Motor Specification 3 Phase AC200V 4P 1.5KW Two-Hand Operation . Mobile Worktable Fuel Oil / Quantity Daphni Hydraulic 46/9L Total Weight (kg) 270 Body Size ​ Height (mm) 986 Width (mm) 485 Depth (mm) 920

PRESS DESIGN   drive system: hydraulic   frame design: C-frame, single sided PRESS FORCES   total force (nominal): 12 to SLIDE   stroke: 200 mm ELECTRICAL SPECIFICATIONS   mains voltage: 380 V   mains frequency: 50 Hz DIMENSIONS / WEIGHTS   total weight approx.: 1000 kg Hour counter: 30'181 h last safety check: 27.07.2023, overrun time 38 ms, overrun distance 60 mm

Haco PPM 100 ton x 3100 mm CNC Capacity: 100 ton x 3100 mm Backgauge: CNC Control: 2D Touch Passage between uprights: 2600 mm Max stroke: 120 mm Max distance between table -- ram: 325 mm Depth of throat: 250 mm Table width: 180 mm Locking speed: 70 mm/sec Working speed: 7,2 mm/sec Returning speed: 60 mm/sec Electric motor (power): 6 kW Length: 3270 mm Depth: 1550 mm Height: 2240 mm Weight: 7 ton

Haco PPH 135 ton x 4100 mm CNC Capacity: 135 ton x 4100 mm Backgauge: CNC Control: Delem DA-41T Passage between uprights: 3600 mm Max stroke: 120 mm Max distance between table -- ram: 325 mm Depth of throat: 250 mm Table width: 180 mm Locking speed: 70 mm/sec Working speed: 7,2 mm/sec Returning speed: 62 mm/sec Electric motor (power): 11 kW Length: 4270 mm Depth: 1500 mm Height: 2470 mm Weight: 9,1 ton

CONTROLS   PC controller BECKHOFF PRESS DESIGN   drive system: servohydraulic   frame design: H-frame, tie rod   quick die change system: yes   feedstock transport direction: left to right SLIDE   total force (nominal): 1100 to   stroke: 130 mm   stroke rate (max.): 60 /min COUNTER RAM   nominal force: 330 to   stroke: 40 mm V-RING   nominal force: 500 to   stroke: 40 mm TOOL DIMENSIONS   lower table (left-right): 960 mm   lower table (front-back): 960 mm   upper table (left-right): 960 mm   upper table (front-back): 960 mm   shut height max.: 470 mm OVERALL SPECIFICATIONS (COIL LINES)   sheet width max.: 500 mm   sheet thickness max.: 16 mm   coil weight max.: 8 to   feedstock t ...

pressure: 80.0 t stroke: 250 mm table surface area: 1040 x 260 mm column travel between the guideways: 1040 mm ajustment speed: 8.0 mm/sec working feed: 5.0 mm/sec return speed: 10.0 mm/sec engine output: 5.5 kW weight of the machine ca.: 835 kg. dimensions of the machine ca.: 1810 x 700 x 2100 mm Furnishing: - Robust electro-hydraulic workshop press, with fixed cylinder - Ideal for aligning axles, shafts, etc., but also for pressing in and out of bolts, bearings, bushings and much more. - Robust welded steel construction for high demands - Table height adjustment via piston rod including round steel chain and 2x locking bolts Piston rod with metric socket - 1x set of V-block prism supports - Manometer for pressure display - simply constructed hand control with: 1x delivery speed 1x working speed 1x retreat speed - Piston can be stopped in any position - Hydraulic tank mounted on t ...

pressure: 20,0 t stroke: 185 mm table surface area: 170 mm Breite column travel between the guideways: 510 mm weight of the machine ca.: 112 kg dimensions of the machine ca.: 1630 x 560 x 730 mm Furnishing: - Standard with pressure cylinder that can be moved to the left and right - For aligning, pressing, bending, assembling gears, discs, etc. - Standard with foot pedal and hydraulic hand pump for piston delivery - Standard with support prism for aligning shafts - With automatic piston retraction by integrated return spring as standard - Height-adjustable press table with locking bolts - Large manometer for reading the compressive force - Including two-stage hydraulic pump - Robust construction with welded steel frame The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

pressure: 30 t stroke: 150 mm table surface area: 185 mm Breite column travel between the guideways: 530 mm weight of the machine ca.: 162 kg dimensions of the machine ca.: 800 x 700 x 1805 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

pressure: 50 t stroke: 200 mm table surface area: 730 x 205 mm dayligth: 1050 mm column travel between the guideways: 730 mm weight of the machine ca.: 288 kg. Description : - Standard with cable winch - for easy height adjustment of the support table - Piston delivery either manually or pneumatically - Powerful workshop presses for craft and repair businesses - Optimum price-performance ratio thanks to rational design - The standard foot pedal keeps your hands free for the workpiece - Increased range of application thanks to the optionally . available pressure mandrel set (10 pieces). - Pressure cylinder with integrated return spring for piston return - Welded steel frame for heavy use and high stability - Versatile in use thanks to the pressure cylinder that can . be moved to the left and right The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

pressure: 175 t chamfer lenght: 4100 mm distance between columns: 3600 mm column arm: 410 mm ram stroke speed: 180 mm/sec return speed: 135 mm/sec work speed: 10,0 mm/sec work stroke: 275 mm dayligth: 550 mm table height: 900 mm table width: 90,0 mm oil volume: 200 ltr. voltage: 400 Volt total power requirement: 15,0 kW weight: 11.950 kg range L-W-H: 5100 x 2150 x 2850 mm -------------------------------------------------- Press brake with special equipment increased installation height increased cylinder stroke as well as increased bending beam speeds -------------------------------------------------- Furnishing: - DELEM CNC control model DA-58T graphics / touchscreen 2D graphic programming 15 high definition color TFT screen Bending sequence calculation Product programming and display in real size USB interface - Motorized backgauge with R-axis, on recirculating ball spindles - ...

pressure: 100 t chamfer lenght: 2600 mm distance between columns: 2200 mm column arm: 410 mm ram stroke speed: 200 mm/sec work speed: 9.5 mm/sec return speed: 155 mm/sec work stroke: 275 mm dayligth: 530 mm table height: 900 mm table width: 90.0 mm oil volume: 150 ltr. voltage: 400 Volt total power requirement: 7.5 kW weight: 6850 kg range L-W-H: 3750 x 1950 x 2800 mm -------------------------------------------------- Press brake with special equipment increased installation height increased cylinder stroke as well as increased bending beam speeds -------------------------------------------------- Furnishing: - DELEM CNC control model DA 53T (touchscreen) - Motorized backgauge with R-axis, on recirculating ball spindles - X = 800 mm R = 250 mm with 2 stop fingers - controlled axes Y1 - Y2 - X - R - C (crowning) - electr. Crowning controlled by CNC - Upper deer foot tool with PS 135.8 ...

pressure: 220 t chamfer lenght: 3100 mm distance between columns: 2600 mm column arm: 410 mm ram stroke speed: 180 mm/sec work speed: 10.0 mm/sec return speed: 185 mm/sec work stroke: 275 mm dayligth: 550 mm table height: 930 mm table width: 200 mm oil volume: 300 ltr. voltage: 400 Volt total power requirement: 18.5 kW weight: 11286 kg Dimensions (HxWxD): 4550 x 2250 x 2850 mm -------------------------------------------------- HIGH-SPEED hydraulic press brake with increased installation height increased cylinder stroke enlarged projection -------------------------------------------------- Furnishing: - DELEM CNC control model DA 66T - swiveling touchscreen control unit - 7 controlled axes: Y1 - Y2 - X - R - Z1 and Z2, as well as CNC crowning - electr. controlled backgauge X-axis = 800 mm / R-axis = 250 mm - on ball screws - controlled electr. Stop fingers Z1 + Z2 - split upper deer foot ...

pressure: 220 t chamfer lenght: 4100 mm distance between columns: 3600 mm column arm: 410 mm ram stroke speed: 180 mm/sec work speed: 10.0 mm/sec return speed: 185 mm/sec work stroke: 275 mm dayligth: 550 mm table height: 900 mm table width: 160 mm back stop - adjustable: max. 800 mm oil volume: 300 ltr. voltage: 400 Volt total power requirement: 18.5 kW weight: 14000 kg range L-W-H: 5150 x 2250 x 3000 mm -------------------------------------------------- HIGH-SPEED hydraulic press brake with increased installation height increased cylinder stroke enlarged projection -------------------------------------------------- Furnishing: - DELEM CNC control model DA 66T - swiveling touchscreen control unit - 7 controlled axes: Y1 - Y2 - X - R - Z1 and Z2, as well as CNC crowning - electr. controlled backgauge X-axis = 800 mm / R-axis = 250 mm - on ball screws - controlled electr. Stop fingers Z1 ...

pressure: 220 t chamfer lenght: 3760 mm distance between columns: 3250 mm column arm: 410 mm ram stroke speed: 180 mm/sec work speed: 10.0 mm/sec return speed: 160 mm/sec work stroke: 275 mm dayligth: 550 mm table height: 900 mm table width: 160 mm oil volume: 300 ltr. voltage: 400 Volt total power requirement: 18.5 kW weight: 12906 kg range L-W-H: 5100 x 2250 x 2900 mm -------------------------------------------------- Press brake with special equipment increased installation height increased cylinder stroke as well as increased bending beam speeds -------------------------------------------------- Furnishing: - DELEM CNC control model DA 58T (TouchScreen) - Motorized backgauge with R-axis, on recirculating ball spindles - X = 800 mm R = 250 mm with 2 stop fingers - controlled axes Y1 - Y2 - X - R - C (crowning) - electr. Crowning controlled by CNC - Upper deer foot tool with PS 135 ...

pressure: 320 t chamfer lenght: 3100 mm distance between columns: 2600 mm column arm: 410 mm ram stroke speed: 140 mm/sec work speed: 10.5 mm/sec return speed: 150 mm/sec work stroke: 375 mm dayligth: 650 mm table height: 900 mm table width: 240 mm oil volume: 400 ltr. voltage: 400 Volt total power requirement: 30.0 kW weight: 17082 kg Dimensions (HxWxD): 4550 x 2450 x 3200 mm -------------------------------------------------- HIGH-SPEED hydraulic press brake with increased installation height increased cylinder stroke enlarged projection -------------------------------------------------- Furnishing: - DELEM CNC control model DA 66T - swiveling touchscreen control unit - 7 controlled axes: Y1 - Y2 - X - R - Z1 and Z2, as well as CNC crowning - electr. controlled backgauge X-axis = 800 mm / R-axis = 250 mm - on ball screws - controlled electr. Stop fingers Z1 + Z2 - split upper deer foot ...

pressure: 40.0 t chamfer lenght: 1270 mm distance between columns: 1050 mm column arm: 350 mm dayligth: 387 mm work stroke: 170 mm table height: 850 mm back stop - adjustable: 800 mm adjustment speed: 230 mm/min ajustment speed: 140 mm/sec working feed: 10.0 mm/sec return speed: 170 mm/sec total power requirement: 5.5 kW weight of the machine ca.: 3220 kg dimensions of the machine ca.: 2150 x 1650 x 2300 mm -------------------------------------------------- Press brake with special equipment increased installation height increased cylinder stroke as well as increased bending beam speeds -------------------------------------------------- Furnishing: - DELEM CNC control model DA 58T (TouchScreen) - Motorized backgauge with R-axis, on recirculating ball spindles - X = 800 mm R = 250 mm with 2 stop fingers - controlled axes Y1 - Y2 - X - R - C (crowning) - electr. Crowning controlled by C ...

pressure: 160 t chamfer lenght: 3100 mm distance between columns: 2600 mm column arm: 250 mm ram stroke speed: 90.0 mm/sec work speed: 7.5 mm/sec return speed: 80.0 mm/sec work stroke: 160 mm dayligth: 395 mm table height: 900 mm back stop - adjustable: max. 800 mm oil volume: 200 ltr. voltage: 400 Volt total power requirement: 11.0 kW weight: 7524 kg range L-W-H: 4250 x 1900 x 2550 mm Furnishing: - DELEM CNC control model DA-66T graphic/touch screen 2D graphical programming 17 TFT color screen with high resolution Bending sequence calculation Product programming and real size display USB interface intuitive, graphical entry of profiles Automatic calculation of features: tool safety zones, Press force, bending tolerance, crown setting, stretched Length, embossing force, flattening, automatic rounding calculation Radius programming Graphic tool and product library Collision mo ...

pressure: 80.0 t chamfer lenght: 2600 mm distance between columns: 2200 mm column arm: 250 mm ram stroke speed: 90.0 mm/sec work speed: 7.5 mm/min return speed: 60.0 mm/sec work stroke: 160 mm dayligth: 380 mm table height: 900 mm oil volume: 150 ltr. voltage: 400 Volt weight: 5227 kg range L-W-H: 3750 x 1950 x 2400 mm Furnishing: - DELEM - CNC control model DA-58T - controlled axes: Y1 - Y2 and X - AKAS laser in front of the machine - manual crowning - Upper tool, deer foot - Lower tool, die block with 4Vs - SICK light barrier behind the machine - 2 front support arms - SIEMENS - electrical system - BOSCH / HOERBIGER hydraulic system - CE mark / declaration of conformity - Operating manual: machine and control - Safety manual: press brakes The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

pressure: 160 t chamfer lenght: 3760 mm distance between columns: 3250 mm column arm: 250 mm ram stroke speed: 90.0 mm/sec work speed: 7.5 mm/min return speed: 80.0 mm/sec work stroke: 160 mm dayligth: 395 mm table height: 900 mm oil volume: 200 ltr. voltage: 400 Volt weight: 8514 kg range L-W-H: 4910 x 1900 x 2550 mm Furnishing: - DELEM - CNC control model DA-58T - controlled axes: Y1 - Y2 and X - SICK light barrier in front of the machine - Upper tool, deer foot - Lower tool, die block with 4Vs - manual table crowning - SICK light barrier behind the machine - 2 front support arms - SIEMENS - electrical system - BOSCH / HOERBIGER hydraulic system - CE mark / declaration of conformity - Operating manual: machine and control - Safety manual: press brakes The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

pressure: 175 t chamfer lenght: 3100 mm distance between columns: 2600 mm column arm: 410 mm ram stroke speed: 180 mm/sec work speed: 10.0 mm/sec return speed: 135 mm/sec work stroke: 275 mm dayligth: 550 mm table height: 900 mm table width: 90.0 mm oil volume: 200 ltr. voltage: 400 Volt total power requirement: 15.0 kW weight: 9450 kg range L-W-H: 4250 x 2150 x 2800 mm -------------------------------------------------- Press brake with special equipment increased installation height increased cylinder stroke as well as increased bending beam speeds -------------------------------------------------- Furnishing: - DELEM CNC control model DA-58T graphic/touch screen 2D graphical programming 15 TFT color screen with high resolution Bending sequence calculation Product programming and real size display USB interface - Motorized backgauge with R-axis, on ball screws - X = 800 mm R =  ...

pressure: 150 t stroke: 300 mm table surface area: 1070 x 290 mm column travel between the guideways: 1070 mm ajustment speed: 9.0 mm/sec working feed: 5.0 mm/sec return speed: 10.0 mm/sec engine output: 11.0 kW weight of the machine ca.: 1870 kg. range L-W-H: 2200 x 1300 x 2300 mm Exhibition machine from 2021 with only approximately 2 operating hours Condition as new Special price upon request Features: - Robust electro-hydraulic workshop press with fixed cylinder - Ideal for aligning axles, shafts, etc., but also for pressing in . and out bolts, bearings, bushings, and much more. - Robust welded steel construction for heavy-duty use - Table height adjustment via piston rod Includes round steel chain and 2 locking pins Piston rod with metric mount - 1 set of V-block prism supports - Pressure gauge for pressure display - Simple manual control with: 1 feed speed 1 working speed 1 ...

pressure: 60.0 t chamfer lenght: 2100 mm distance between columns: 1700 mm column arm: 410 mm ram stroke speed: 160 mm/sec work speed: 10.0 mm/sec return speed: 165 mm/sec work stroke: 275 mm dayligth: 530 mm table height: 900 mm table width: 90.0 mm oil volume: 150 ltr. voltage: 400 Volt total power requirement: 7.5 kW weight: 5640 kg range L-W-H: 3250 x 1960 x 2750 mm -------------------------------------------------- Press brake with special equipment increased installation height increased cylinder stroke as well as increased bending beam speeds -------------------------------------------------- Furnishing: - DELEM CNC control model DA 53T (touchscreen) - Motorized backgauge with R-axis, on recirculating ball spindles - X = 800 mm R = 250 mm with 2 stop fingers - controlled axes Y1 - Y2 - X - R - C (crowning) - electr. Crowning controlled by CNC - Upper deer foot tool with PS 135 ...

pressure: 220 t chamfer lenght: 4100 mm distance between columns: 3600 mm column arm: 410 mm ram stroke speed: 180 mm/sec work speed: 10.0 mm/sec return speed: 160 mm/sec work stroke: 275 mm dayligth: 550 mm table height: 900 mm table width: 160 mm oil volume: 300 ltr. voltage: 400 Volt total power requirement: 18.5 kW weight: 13800 kg range L-W-H: 5150 x 2250 x 3000 mm -------------------------------------------------- Press brake with special equipment increased installation height increased cylinder stroke as well as increased bending beam speeds -------------------------------------------------- Furnishing: - DELEM CNC control model DA-58T graphics / touchscreen 2D graphic programming 15 high definition color TFT screen Bending sequence calculation Product programming and display in real size USB interface - Motorized backgauge with R-axis, on recirculating ball spindles - X ...

pressure: 320 t chamfer lenght: 4100 mm distance between columns: 3600 mm column arm: 410 mm ram stroke speed: 140 mm/sec work speed: 10.5 mm/sec return speed: 150 mm/sec work stroke: 375 mm dayligth: 650 mm table height: 900 mm table width: 220 mm oil volume: 400 ltr. voltage: 400 Volt total power requirement: 30.0 kW weight: 22064 kg Dimensions (HxWxD): 5350 x 2450 x 3150 mm -------------------------------------------------- HIGH-SPEED hydraulic press brake with increased installation height increased cylinder stroke enlarged projection -------------------------------------------------- Furnishing: - DELEM CNC control model DA 66T - swiveling touchscreen control unit - 7 controlled axes: Y1 - Y2 - X - R - Z1 and Z2, as well as CNC crowning - electr. controlled backgauge X-axis = 800 mm / R-axis = 250 mm - on ball screws - controlled electr. Stop fingers Z1 + Z2 - split upper deer foot ...

Key data: 250 t

Inv. Num. : 8652 Type: ZHS 250 Producer: ŽDB Hydraulika Generated: 2000 Parameters: Compressive force: 250 t Table length: 3500 mm Table width: 1200 mm Stroke: 700 mm Ram dimensions: 3500 x 1200 mm Working speed: 13-60 mm/s Machine height: 6000 mm Machine length: 3000 mm Machine width: 5000 mm Machine weight: 60000 kg

LVD PPEB 100 ton x 2500 mm + 1000 mm CNC Capacity: 100 ton x 2500 mm + 1000 mm Backgauge: CNC Control: 2D touch Passage between uprights: 2050 mm Max stroke: 120 mm Max distance between table -- ram: 400 mm! Depth of throat: 200 mm Table width: 180 mm Locking speed: 100 mm/sec Working speed: 11 mm/sec Returning speed: 80 mm/sec Electric motor (power): 11 kW Length: 4100 mm Depth: 2320 mm Height: 2800 mm Weight: 8,5 ton

Pressing force: 4000kN, pressing pressure: 320bar, oil pressure: 250bar, blank holder force: 1600kN, blank holder stroke: 200mm, blank holder dimensions X/Y: 1000mm/800mm, blank holder ejector force: 160kN, ejector force: 63kN, ejector stroke: 100mm, overrun distance: 40mm, overrun time: 190ms. Documentation available. An on-site inspection is possible.

7 assen: Y1 /Y2 / X / Z1 / Z2 / R1 / R2 Amada-bombardement Capacity: 125 ton x 3100 mm Backgauge: CNC Control: Delem DA65R Passage between uprights: 2600 mm Max stroke: 100 mm Max distance between table -- ram: 300 mm Depth of throat: 400 mm Locking speed: 85 mm/sec Working speed: 10 mm/sec Returning speed: 80 mm/sec Length: 3245 mm Depth: 1940 mm Height: 2415 mm Weight: 7,7 ton

3 assen: Y1 / Y2 / X Capacity: 220 ton x 3100 mm Backgauge: CNC Control: 2D Touch Passage between uprights: 2600 mm Max stroke: 200 mm Max distance between table -- ram: 450 mm Depth of throat: 300 mm Locking speed: 100 mm/sec Working speed: 8 mm/sec Returning speed: 80 mm/sec Electric motor (power): 19 kW Length: 3500 mm Depth: 1900 mm Height: 2700 mm Weight: 10,5 ton

Key data: 630 t, 275 mm

For sale is a used lowering press, manufacturer Sack + Kiesselbach, type EP 630. The machine is in very good condition. The press worked in an engraving company as a test press. Technical data: Pressing force: max. 630 tons. Installation height: max. 325 mm Stroke: max. 275 mm Weight: 4,000 kg

SLIDE   total force (nominal): 880 to   stroke: 305 mm   cutting velocity min.: 5 mm/s   cutting velocity max.: 70 mm/s   closing velocity: 200 mm/s   returning velocity: 200 mm/s V-RING   nominal force: 400 to   stroke: 40 mm COUNTER RAM   nominal force: 200 to   stroke: 40 mm TOOL DIMENSIONS   lower table (left-right): 1010 mm   lower table (front-back): 1600 mm   upper table (left-right): 1000 mm   upper table (front-back): 1000 mm   shut height max.: 460 mm STRIP-FEEDER   feeder type: roll feeder   sheet width max.: 450 mm   sheet thickness max.: 16 mm   feeding step min.: 1 mm   feeding step max.: 999.9 mm   sheet length min: 3950 mm   speed max.: 48 m/min  &nbs ...

Durma HAP 200 ton x 3100 mm Capacity: 200 ton x 3100 mm Backgauge: elec Passage between uprights: 2550 mm Max stroke: 190 mm Depth of throat: 260 mm Locking speed: 100 mm/sec Working speed: 7 mm/sec Returning speed: 73 mm/sec Length: 4270 mm Depth: 1750 mm Height: 2850 mm Weight: 12 ton

Key data: 300 t, 800 mm

Hydraulic Press Emanuel 300 ton Year of construction: 1989 Dimension table: 1600 x 1300 mm Light max: 1130 mm Light min: 350 mm Slide stroke: 800 mm Cushion stroke: 400 mm Side upright clearance: 640 mm

Hydraulic Press Emanuel 500 ton press Year of construction: 1976 Dimension table: 2500 x 1900 mm Light max: 1490 mm Light min: 550 mm Slide stroke: 940 mm Cushion stroke: 400 mm Side upright clearance: 900 mm

Hydraulic Press MURARO 500 ton Year of construction: 2001 Dimension table: 2600 x 1600 mm Dimension lower table: 2700 x 1600 mm Light max: 1500 mm Light min: 700 mm Slide stroke: 900 mm Cushion stroke: 400 mm Side upright clearance: 770

Inv. Num. : 948 Type: LVH 2500 Producer: ŽĎAS Created: 1961 Parameters: Depth: 1800 mm Width: 3450 mm Height above ground: 4650 mm Weight: 85 000 kg Voltage: 220 / 380 V Mains frequency: 50 Hz Workforce: 2500 t Number of strokes: 20/min Height of the lifts: 500 mm Minimum plunger distance from the table: 900 mm Maximum plunger distance from the table: 1400 mm Table surface: 1050 x 1400 mm Plunger area: 1050 x 1200mm

Pressing force: 3150kN, table dimensions X/Y: 2500mm/1600mm, stroke (fixed): 280mm, stroke rate: 20-80strokes/min, weight: approx. 68000kg. Including Dreher transfer and feed line. The control system is defective. Documentation available. An on-site inspection is possible.

Capacity 50 tons Stroke 750 mm Table size 1500x1000 mm

upper amp; lower Wila tooling 5 axes: X / X´ / R / Z1 / Z2 Capacity: 50 ton x 2550 mm Backgauge: CNC Control: TS3 Passage between uprights: 2550 mm Max stroke: 265 mm Max distance between table -- ram: 515 mm Locking speed: 90 mm/sec Working speed: 20 mm/sec Returning speed: 90 mm/sec Electric motor (power): 9 kW Length: 3400 mm Depth: 1850 mm Height: 2820 mm Weight: 5 ton

Key data: 600 t

Max Tool length: 3000mm Max Tool Width: 2000mm Min Tool Height: 500mm Total Tool Weight: 20,000kg Max Closing Speed: 400 mm/sec

Haco PPM 175 ton x 3600 mm Capacity: 175 ton x 3600 mm Backgauge: electric Passage between uprights: 3150 mm Max stroke: 200 mm Max distance between table -- ram: 450 mm Depth of throat: 300 mm Locking speed: 80 mm/sec Working speed: 9 mm/sec Returning speed: 95 mm/sec Electric motor (power): 15 kW Length: 3880 mm Depth: 1750 mm Height: 2750 mm Weight: 13,4 ton

pressure: 25 t stroke: 145 mm daylight between the columns: 600 x 160 mm dayligth: mm : mm diameter of piston: mm weight of the machine ca.: 0,15 t dimensions of the machine ca.: 0,8 x 0,6 x 1,8 m Our frame presses are officially CE certified according to the latest rules. Almost all presses offered in this area are not CE certified. - with manual hydraulics - Move the cylinder sideways - Pressure gauge - 2 press documents The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
