119,280 used machines on RESALE, but how to find them? Machine Search
maximum number of results exceeded > 1000
please refine your search
used
sheet width: 2500 mm plate thickness: 5 mm distance between columns: 2600 mm total power requirement: 5 kW The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
used
Overview The winder was manufactured in 2002 by the swiss company Strapex. It is located at a German mineral fountain and is part of a plant that has been shut down because the operator will be bottling in glass in the future and no longer in PET. The storage depalletizer is still mounted and electrically connected. Technical Data Power: 5,4 kW Air consumption: 100 l/ min Max. Air pressure: 6 bar Weight: 1500 kg Accessories Pallet transport Protective fence Logopak labeler Empty pallet magazine
used
Description: Serial number: 48179 Operating voltage: 220 V Rated current: 3 A Frequency: 50 Hz Connection: 370 W Speed: 3000 rpm Table dimensions: 140 x 120 mm Approx. Onsite Dimension. (l x w x h): 400 x 300 x 300 mm, weight approx.: 40 kg
used
sheet width: 3050 mm plate thickness: 6,00 mm distance between columns: mm cutting angle: 0,5 - 3,0 ° drive motor: 11 kW down holder: 18 Stück total power requirement: kW weight of the machine ca.: 6,00 t dimensions of the machine ca.: m • Automatic cutting angle adjustment • Automatic cutting gap adjustment • Cutting line lighting • Support arms • Knife with 4 cutting edges • Cutting length limitation • CNC back gauge 705mm adjustment range 705 mm • Angle stop • Operation manual The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
used
Gebr. CNC Long Short Turning/Milling Center with B-Axis Hours: 7200 Control: Fanuc 31i-A Machining length: max. 250 mm Number of controlled axes: 7 axes and max. 5 axes simultaneously B-axis: 0°-130° freely programmable Rod passage: Ø 3 mm to max. Ø 20 mm Drive power main spindle: 3.7 kW Drive power counter spindle: 2.2 kW Main spindle speed: 10,000 rpm Counter spindle speed: 10,000 rpm C-axis: main and counter spindle Number of linear beams: 2 pieces Total number of tools: 35 pieces Dimensions (LxWxH) in mm: 2.110x1.200x1.885 Weight: 3,300 kg Conversion from long to short turning Deep Hole Drilling Stations NAKANISHI high-speed spindle Rear slide with Y-axis Cross Drilling Rear Conveyor Fire extinguishing system FMB bar feeder Minimag 20, YOC 2012 The machine can be viewed under power by arrangement. Subject to changes and errors in the technical data and ...
used
Hydr. Swing cut guillotine shears HERA type HSS III Fabr. No. 598 Year of manufacture 1986 Cutting length 3100 mm Cutting thickness 3 mm Column projection 200 mm Knife strokes 25 strokes/min. Mains connection 380 volts, 50 Hz motor power 3 kW - motorized adjustable back gauge 1070 mm - actual value digital display for the back gauge - cutting gap adjustment - cutting length adjustment - front side gauge left 1000 mm - 4 sheet metal support arms 1000 mm - el. Foot switch Space requirement without sheet metal support arms L x W x H 3630 x 2200 x 1600 mm Weight approx. 4000 kg good condition; used
used
travel -x axis: 1.050 mm travel -y axis: 875 mm travel -z axis: 875 mm control: FANUC 18i-M NC rotary table: 630 x 630 numbers of positions in the tool changer: 60 Dimensions (L x W x H): 3.525 x 5.650 x 3.526 mm weight of the machine: 20.000 kg Milling machining centers - horizontal | HYUNDAI KIA - HS630 equipped with ITC (30bar), chip conveyor & RENISHAW tool changer. The machine is in a well-maintained condition. - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - #Tags: HYUNDAI WIA - HS630 | HS 630 | HS-630 The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
used
5 Axis X,Y,Z Travels 450,580,400 mm Spindle speed 28.000 rpm Controller Siemens 840D SL
used
Description: mounted mandrels, Thermo grip veldoni HSK 63, 150 pieces weight approx.: 120 kg, Approx. Onsite Dimension. (l x w x h): 1,200 x 800 x 300 mm
used
Description: amount 33 pieces weight approx.: 50 kg, Approx. Onsite Dimension. (l x w x h): 1,200 x 800 x 500 mm
used
Description: amount 5 pieces weight approx.: 10 kg, Approx. Onsite Dimension. (l x w x h): 1,200 x 800 x 500 mm
used
Description: amount 22 pieces weight approx.: 25 kg, Approx. Onsite Dimension. (l x w x h): 1,200 x 800 x 500 mm
used
Description: amount 31 pieces Approx. Onsite Dimension. (l x w x h): 1,200 x 800 x 500 mm, weight approx.: 105 kg
used
Tool holder, tool holder, milling holder, milling tool, chuck, milling cutter holder -Manufacturer: Eroglu, cutter holder with coolant channel in original packaging -Type: HSK 63-12-80-K -Art.No.: A63.04.12.K -Transport dimensions. 470/100/H95mm -Weight: 1.2 kg
used
Key data: 3000 mm, 13 mm
Machine Type: Guillotine Shears Manufacturer: HACO Type: HSLX3013 Year of construction: 1996 Condition: used / good Offer will only be sent if a complete imprint is provided! Location Warstein , Germany Reference MV-KÖL-0424-2 DESCRIPTION We offer you a used guillotine shears from the manufacturer HACO. Cutting capacity 3m x 13mm Haco's control system renewed. further data on request. Availability: by arrangement Our offer is aimed at tradespeople who are registered within the meaning of the Trade Regulation Act according to §14 GewO. The offer is subject to change, subject to prior sale. Please provide your full contact details to receive a quote with our terms and conditions and payment terms. Errors in the descriptions and offers are excepted
used
This DMG Mori HSC 55 linear Universal Machining Center was manufactured in the year 2011 and has 61913 control hours, 59275 machines on hours, 10986 program run hours, and 10631 Spindle running time (spindle exchange at approx.7300 hours). The machine has a spindle speed of 20 - 28000 rpm. It is equipped with a Heidenhain iTNC 530 control unit and has 5 axis.
used
This AGIE CHARMILLES MIKRON HSM 400 LP Vertical Machining center was manufactured in the year 2013 in Switzerland and has 18727 production hours, of which 18377 are spindle hours. It is equipped with a HEIDENHAIN 530 control unit and has 3 axis. The machine has a spindle speed of 42000 rpm.
used
This POSMILL E 2050 L HSCI Vertical Machining center machine was manufactured in the year 2015 in Germany and has 2750 spindle hours (since spindle renewal in April 2021). It is equipped with a HEIDENHAIN iTNC 530 control unit and HSK 63. The machine has new inline spindle, new spindle motor and new rotary union (April 2021). It comes with inner cooling through spindle 20Bar with belt filter, tool changer 60 compartment, 3D probe Blum, tool measurement Blum laser, Heidenhain handwheel, blowing air spindle center and operation mode 4. Upon request and for additional cost approx. 250 HSK holders and drill chucks are available (partly new / partly used).
used
This EXERON Digma HSC 300/P 3-axis Vertical Machining Centre was manufactured in 2006 in Germany. It is equipped with a Heidenhain iTNC530 control unit and a 42000 rpm spindle. In addition to its 3 axes (X = 480 mm, Y = 340 mm, Z = 355 mm) it has a table size of 470 x 400 mm and 40 tool slots. In 2018 a new spindle has been installed. Furthermore it stands out to be used for graphite machining.
used
Briquette diameter: mm 180, Briquette diameter large mm 195, Force main cylinder kN 8,500, Briquette density steel, cast iron Kg/dm 5,5, Briquette density aluminium Kg/dm3 2,4, Briquette density brass, copper Kg/dm3 7.0, Capacity steel/cast iron t/h 7.5, Capacity aluminium t/h 3.5, Capacity brass/copper t/h 8.0, Drive power standard kW 180, Footprint m x m 6.5 x 8.5, Machine weight t 45, Year: 1999, Immediately available, Briquette diameter: mm 180, Year: 1999
used
Description: No.1 'HS 12 H Serial No.2337' - Automatic machine for straightening and cutting round metal wires smooth and ribbed from mm. 4 to 12, with hydraulic and flying shear cutting: with straightening system with 3-speed rotating body, obtainable by selecting the stepped pulley: with electric motor of 22KW, with soft starter for smooth starting, with 6 pairs of conveyor rollers, pressure pneumatic, for a forward speed of 30/150 mt./min., with hydraulic power unit with oil accumulation with 5.5 KW motor for fast and precise cutting. Complete with 2 sets of straightening units for quick change of cast iron jaws, set of conveyor rollers from mm. 4 to 12 and pre-selection piece counter. Mt. 4 pallet Nr. 1 FS-type decoiler, bell carrier with pneumatic and hand brake Nr. 1 Bell for rolls of int. diam. Of cm. 44/78 Nr. 2 straightening units each complete with 3 cast iron j ...
used
Used vertical packaging machine made by Velteko model HSV 101S1. New 2002. The machine is equipped with auger dispenser and a date dispenser + receiving conveyor + PRISMA 08D3 checkweigher. TECHNICAL PARAMETERS: The HSV 101S machine is designed for packing loose and small goods into bags, which the machine forms from a roll of packing material. The machine is designed for normal working environment protected from the influence of atmospheric agents with temperature regulation (-5 to +40°C) -AB5, AC1, AD1, AE1, BA4, BOI, BE1, CA1, CD1 - according to HD CENELEC 384.3 S 1 The parts of the machine coming into contact with foodstuffs are made of stainless steel (17 240 Cr-Ni) suitable for contact with foodstuffs. The capacity of the machine depends on the grade of packaging material, the goods being packed, and the capacity of the dispenser. - Performance of the machine (layered ...
used
sheet width: 2050 mm plate thickness: 1,50 mm distance between columns: mm rear stop: 500 mm total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: 2,40 x 1,30 x 1,30 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
used
length in total: 400 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
new
: neu : ca. 12 Wochen ab Auftrags : Türkei : 82900 € : 1666.29 € : 2050 mm : 20 mm : 20 mm : 16 mm : 16 mm : 12 mm : 280 mm : 280 mm : 220 mm : 1,5 / 5 m/min : 16,5 kW : 4350 mm : 1700 mm : 1850 mm : 8550 kg 4 rolls fullhydraulic drive of upper roll and lower roll hydraulic infeed of lower and side roll digital read-out of lower and side rolls position hardened rolls conical bending device hydraulic load relieving of upper roll hydraulic drop-end bearing 2 working speeds central lubrication system protectionagainst overload moveable control pane according to CE rules OPTIONAL EQUIPMENT (PRICES ON REQUEST): infinitely adustable speed of rolls hydraulic side support hydraulic top support IMPORTANT ISSUES AT CONICAL BENDING: the max. sheet metal thickness isequivalent to 50 % of nominal capacity the cone length can be max. 30 % oremust be more than 60 % of roll length hardened rolls ar ...
used
CONTROLS CNC controls HEIDENHAIN TNC 640 WORKING RANGE -CUBIC- number of processing axes (excl parallel axes): 5 X-axis travel: 640 mm Y-axis travel: 250 mm Z-axis travel: 400 mm rotating range B-axis from: 105 ° rotating range B-axis up to: -105 ° rotating range C-axis from: 0 ° rotating range C-axis up to: 360 ° distance spindle nose - table surface (max.): 450 mm TABLE workpiece load (max): 60 kg SPINDLE / HEAD spindle revolutions (max): 42000 /min TOOL MAGAZINE number of positions: 90 ELECTRICAL SPECIFICATIONS mains voltage: 400 V mains frequency: 50 Hz DIMENSIONS / WEIGHTS space requirements -left/right-: 2400 mm space requirements -front/back-: 2370 mm ...
used
CONTROLS PLC SIEMENS S7 SLIDE total force (nominal): 250 to SLIDE (HYDR. PRESS) approximation velocity max.: 200 mm/s working velocity min.: 10 mm/s working velocity max.: 44 mm/s return velocity max.: 200 mm/s COUNTER RAM nominal force: 63 to V-RING nominal force: 100 to TOOL DIMENSIONS lower table (left-right): 500 mm lower table (front-back): 500 mm upper table (left-right): 695 mm upper table (front-back): 730 mm shut height max.: 360 mm ATTACHMENTS -FINEBLANKING PRESS- light barrier: yes closed cabin: yes decoiler: optional leveller unit: optional waste cutter: yes slug separator: yes
used
A window and door production line with 7 machines is available. 1) 1.1) HT line: Horizontal four-head welding machine (HSM) Stürtz, year of construction: 2019. 1.2) 2 MC - 1 head cleaner Stürtz with tool carrier top and bottom, year of construction: 2009. Add-ons for frames and sashes, profile type: Veka, installation depths: 70mm/76mm/82mm/116mm, max. size: approx. 2600mm/4000mm. 2) HFL Kruba milling machine: 3-axis milling machine, year of manufacture: 2011. 3) Rotox GZS glazing bead saw, year of manufacture: 2011. 2000 pieces in 8 hours. With 10-pair loading magazine (corresponds to 20 glazing beads) and 20-pair automatic removal table (corresponds to 40 cut glazing beads). 4) Series line: 4.1) & 4.2) Vertical four-head welding machine Stürtz VSM-20/VSM26-Turbo with handling system, year of manufacture: 2019. 4.3) Horizontal four-head plastering machine Stürtz MC-H4K-30/26, year o ...
used
Description: machine number: 5.82.97.011 control: HEIDENHAIN Atek HS-Plus  , travels: X-axis: 700 mm Y-axis: 550 mm Z-axis: 450 mm table dimensions: 900 x 550 mm max. table load: 700 kg tool holder: HSK 40 number of tool positions: 12 rapid traverse: 40 m/min. feed rate: 40000 mm/min.  , machine is in good technical condition, can be tested by prior arrangement z-motion: 450 mm, max. workpiece weight between centers: 700 kg, x-motion: 700 mm, y-motion: 550 mm, control: HEIDENHAIN Atek HS-Plus, table surface area l x w : 900 x 550 mm, taper: HSK 40, toolchanger positions: 12, feed range: 40,000 mm/min, rapid motion: 40 m/min, weight approx.: 6,500 kg, Approx. Onsite Dimension. (l x w x h): 2,850 x 2,850 x 3,030 mm
used
Description: No.: 8204 Output: 30,000 kcal/h , (approx 35 kw) Air output: 2,400 m³ Approx. Onsite Dimension. (l x w x h): 1,700 x 1,200 x 1,700 mm, weight approx.: 700 kg
used
x-travel:800 mm y-travel:600 mm z-travel:500 mm pallet size::320 x 320 mm table load:150 kg spindle turning speed range:24.000 1/min drive capacity - spindle motor:22 kW control:HEIDENHAIN iTNC 530 feed speeds infinitely variable:20 / 20 / 40 m/min Torque:46 Nm rapid traverse:50 m/min Tool changer:220 Pos. spindle taper ISO:HSK A-63 weight of the machine ca.:8,5 t dimensions of the machine ca.:6,5 x 5,5 x 3 m dimensions for transport:2 m 5-axis simultaneously universal-machining center, with NC-rotary-swivelling-table A-axis +30/-110°, C-axis 360°, internal coolant supply 18-70bar, paper-filter, infrared touchprobe M&H PS 32.00, oilmist suction, MQL (minimal quantity lubrication), APS, ITC, el. handwheel, chipconveyor, EROWA pallet-pool for 24 pallets, approx. 131.000h "machine on", approx. 20.700h "spindle on"
used
Pouch Form Fill & Sealingmachine manufacturer: Nagema, Germany Typ: HS1 capacity: max. 50 bags/min, infinitely adjustable closing: sealing dosage: volumetric doser like rice, candies, spicery etc. bag width: 120 mm bag length: from 50 200 mm adjustable dimension: 2,0 x 1,1 x 2,1 m weight: 900 kg Techn. State: used, very good state
new
NEW MACHINE With format sliding table 2.60m Saw blade 250-315mm swivel: 90-45 Planing width of 410mm 4 knife shaft reversible knife (no more adjustment) Dressing table length of 1800mm Pass-through height from 4-225mm Mill: 90-45 swiveltove to the rear Milling rpm: 3000/4000/5000/ 6000/8000 and 10000 rpm Altitude stroke 160mm Engine power: 3 motors 3 KW400 V (4.0 hp)S1 100% continuous operation SPECIAL PRICE: net Options: Scoring unit with motor Miter stop 900mm Integral safety rails 500mm Westcott Drill Chuck 0-16mm Long hole drilling device Eccentric tensioner Right and left running (milling) Engine 4.0 KW (5.5 hp)S1 100% Planing knife 410 HSS G&WJ-BA-410-HSS
new
NEW MACHINE With Formatschiebetisch 2, 60m Saw blade 250-315 mm Swivel: 90 °-45 ° Planing width 410 mm 4 cutter Blade (no setting more) Dressing table length of 1800 mm Clearance height of 4-225 mm Milling cutter: 90 °-45 ° swivel to the rear Blower rpm: 3000/4000/5000/6000 / 8000 and 10000 RPM Vertical lift 160 mm Engine power: 3 engines 3 KW400 V (4,0 PS) S1 100% continuous operation WJ-500300 Special price: NET Options: Before scoring unit with motor Guide fence 900 mm Integral safety rail 500 mm Westcott Chuck 0-16mm Milling Eccentric clamp Right - and left-hand rotation (BUR) Engine 4.0 KW (5.5 HP) S1 100% Planer blade 410 HSS G & WJ-BA-410-HSS
new
NEW MACHINE With format sliding table 2.60m Saw blade 250-315mm swivel: 90-45 Planing width of 320mm 3 Knife shaft reversible knife (no more adjustment) Pass-through height from 4-225mm Mill: 90-45 swiveltove to the rear Milling rpm: 3000/4000/5000/ 6000/8000 and 10000 rpm Altitude stroke 160mm Engine power: 3 motors 3 KW400 V (4.0 hp)S1 100% continuous operation WJ-500200 SPECIAL PRICE: net Options: Scoring unit with motor Miter stop 900mm Integral safety rails 500mm Westcott Drill Chuck 0-16mm Long hole drilling device Eccentric tensioner Right and left running (milling) Planing knife 320 HSS G&WJ-BA-410-HSS
new
Engine power: 1,1 kW, 230V / 1PH motor coolant pump: 50 W Feeding: manual Blade speed: 20-65 m / min Number of steps: infinitely variable Band saw blade dimensions: 1,735 x 12.7 x 0.9 mm length Vice open/closed: 1,120 / 930 mm width without / with material stop: 510 / 720 mm Height lower / upper final position saw bracket: 1240 / 1,590 mm Net weight: 100 kg G & pieces 3300150SE Option: 3 Piece bi-metal band saw blades HSS
new
- Arbeitsbereich X - Achse 1300 mm - Arbeitsbereich Y - Achse 2500 mm - Arbeitsbereich Z - Achse 300 mm - Frässpindel luftgekühlt HITECO / Italy 9.5 kw, HSK 63F - Spindel Drehzahl stufenlos 24.000 rpm - Werkzeugwechsler 8-fach, seitlich - Verfahrsystem (X & Y Achse) Zahnstangen-Ritzelantrieb - Verfahrsystem (Z Achse) Kugelrollspindel - Verfahrmotoren AC Servo Motoren Delta / YASKAWA - SHIMPO Getriebe Antrieb - max. Verfahrgeschwindigkeit 40 m/min - max. Arbeitsgeschwindigkeit 20 m/min - Arbeitsgenauigkeit 0.05 mm - Vakuum - Rastertisch mit 4 Sektionen und T-Nuten - BECKER Vakuumpumpe trockenlaufend, luftgekühlt, Leistung 129 m3/h - Werkstückpositionierung, pneumatisch absenkbare Anschläge je 2 Stück in X und Y - Werkzeuglängen Sensor - CAD/CAM Software VECTRIC CUT 2D PRO (NESTING Inclusive) - Steuerung OSAI/ Italy - Schnittstelle Ethernet/USB/CompactFlash Card - Elektroanschluss 3 ...
new
- Arbeitsbereich X - Achse 2100 mm - Arbeitsbereich Y - Achse 3000 mm - Arbeitsbereich Z - Achse 300 mm - Frässpindel luftgekühlt HITECO/ Italy 9.5 kw, HSK 63 F - Spindel Drehzahl stufenlos 24.000 rpm - Werkzeugwechsler,Karusell 8-fach, mitfahrend - Verfahrsystem (X & Y Achse) Zahnstangen-Ritzelantrieb - Verfahrsystem (Z Achse) Kugelrollspindel - Verfahrmotoren AC Servo Motoren Delta / YASKAWA - SHIMPO Getriebe Antrieb - max. Verfahrgeschwindigkeit 40 m/min - max. Arbeitsgeschwindigkeit 20 m/min - Arbeitsgenauigkeit 0.05 mm - Vakuum - Rastertisch mit 4 Sektionen - BECKER Vakuumpumpe trockenlaufend, luftgekühlt, Leistung 2 x 129 m3/h = 258 m3/h - Werkstückpositionierung, pneumatisch absenkbare Anschläge je 2 Stück in X und Y - Werkzeuglängen Sensor - CAD/CAM Software VECTRIC CUT 2D PRO (NESTING Inclusive) - Steuerung OSAI / Italy - Schnittstelle Ethernet/USB/CompactFlash Card - Ele ...
used
Cat.-No. 14-00218 PET line for still and carbonated beverages Format: 1.5 L, production capacity: 20,000 bottles / h in a very good condition Year of construction: 2001 working hours: 42.389 the plant built up yet, but is currently out of operation Machine manufacturer year details Blow moulding machine SIG BLOMAX 16 2001 including molding water inlet, elevator and hopper, cooler (Rahim) Molding m Tanner VZT 3000 dosing system 2001 air transporters 2001 buffer tank 14 m³ Alfa Laval 2001 short time pasteurisation KHS Innopro KZE 2001 330 HL / h Triblock (Rinser, filler, Capper) KHS Innoclean/Innofill 120/10 2001 volume filler Capsule conveyors with supply tank Filling height control HEUFT basic 2001 labeller KHS Anker 2001 label control HEUFT HBF 150000 ST 2001 laser encoder video Jet 3430 2001 shrink film Packer SMI SK 800 T 2001 tray Packer in 6 Pack film (50 ppm) ...
new
Technische Daten: - Verfahrbereich X - Achse 3700 mm - Verfahrbereich Y - Achse 1600 mm - Verfahrbereich Z - Achse 200 mm - Arbeitsbereich X - Achse 3685 mm - Arbeitsbereich Y - Achse 1550 mm - Arbeitsbereich Z - Achse 70 mm - Lade- Entladegeschindigkeit 15 m/min - Frässpindel luftgekühlt HSD / Italy 9.6 kw, HSK 63 (Option 11 kW HSK 63F) - Spindel Drehzahl stufenlos 24.000 rpm - Werkzeugwechsler,Karusell 8-fach, mitfahrend - Bohraggragat VERTIKAL 5 + 4 FAM / Italian 5 Spindeln in Y-Richtung, Bohrabstand 32 mm 5 Spindeln in X-Richtung, Bohrabstand 32 mm - Verfahrsystem (X & Y Achse) Zahnstangen-Ritzelantrieb - Verfahrsystem (Z Achse) Kugelrollspindel - Verfahrmotoren AC Servo Motoren YASKAWA - hochgenaue THK Linearführungen mit Langzeitschmiereinheit in X, Y, Z Achse - SHIMPO Getriebe Antrieb - max. Verfahrgeschwindigkeit 80 m/min - max. Arbeitsgeschwindigkeit 25 m/min - Arbeitsgenaui ...
used
We give our wheel bearing. Vitrified bonded grinding wheels for metal processing. From 100 mm to 600 mm in diameter. We carry also diamond and CBN wheels for tool grinding machines new and used. Strausak Fleximat 91 we have yet complete disc sets for all common diameters for the machining of solid carbide and HSS milling and drilling tools. Price and info. on request.
new
- Arbeitsbereich X - Achse 1500 mm - Arbeitsbereich Y - Achse 3000 mm - Arbeitsbereich Z - Achse 300 mm - Frässpindel luftgekühlt HITECO / Italy 9.5 kw, HSK 63F - Spindel Drehzahl stufenlos 24.000 rpm - Werkzeugwechsler 8-fach, seitlich - Verfahrsystem (X & Y Achse) Zahnstangen-Ritzelantrieb - Verfahrsystem (Z Achse) Kugelrollspindel - Verfahrmotoren AC Servo Motoren Delta / YASKAWA - SHIMPO Getriebe Antrieb - max. Verfahrgeschwindigkeit 40 m/min - max. Arbeitsgeschwindigkeit 20 m/min - Arbeitsgenauigkeit 0.05 mm - Vakuum - Rastertisch mit 4 Sektionen und T-Nuten - BECKER Vakuumpumpe trockenlaufend, luftgekühlt, Leistung 129 m3/h - Werkstückpositionierung, pneumatisch absenkbare Anschläge je 2 Stück in X und Y - Werkzeuglängen Sensor - CAD/CAM Software VECTRIC 2D PRO (NESTING Inclusive) - Sicherheitslichtschranke Vorschrift nach EN 848-3 (Optional einseitig, zweiseitig oder dreise ...
new
Technische Daten: - Verfahrbereich X - Achse 2900 mm - Verfahrbereich Y - Achse 2160 mm - Verfahrbereich Z - Achse 200 mm - Arbeitsbereich X - Achse 2850 mm - Arbeitsbereich Y - Achse 2130 mm - Arbeitsbereich Z - Achse 70 mm - Lade- Entladegeschindigkeit 15 m/min - Frässpindel luftgekühlt HSD / Italy 9.6 Kw HSK 63 (Option 11 kW HSK 63F) - Spindel Drehzahl stufenlos 24.000 rpm - Werkzeugwechsler,Karusell 8-fach, mitfahrend - Bohraggragat VERTIKAL 5 + 4 FAM / Italian 5 Spindeln in Y-Richtung, Bohrabstand 32 mm 5 Spindeln in X-Richtung, Bohrabstand 32 mm - Verfahrsystem (X & Y Achse) Zahnstangen-Ritzelantrieb - Verfahrsystem (Z Achse) Kugelrollspindel - Verfahrmotoren AC Servo Motoren YASKAWA - hochgenaue THK Linearführungen mit Langzeitschmiereinheit in X, Y, Z Achse - SHIMPO Getriebe Antrieb - max. Verfahrgeschwindigkeit 80 m/min - max. Arbeitsgeschwindigkeit 25 m/min - Arbeitsgenauig ...
used
Complete wheel sets for the production and subsequent sharpening of HSS and carbide tools. Single diamond and CBN discs. for the manufacturing and Resharpening. Grinding wheel shots short and long run. Spacer discs for grinding wheel flanges.
used
5 axis machininng center (milling/turning from bar) multitasking Under power in our warehouse MAKE CHIRON MODEL MILL 800 5 axis CNC Fanuc 18iMBS (5 simoultaneous axis 1) X, Y, Z (mm) 800 ? 500 - 550 Rapids (Highspeed) 60 m/min Swivelling head CNC controlled (B axis) +/- 100° Turning spindle Peiseler Milling spindle 12.000 giri / 140 Nm (v nota 2) Tools 65 Tool type HSK-A 63 DIN 69893 Tool-change time 1,5 sec (v nota 3) Table 1400x500 Max table load 1200 kgs Coolant through spindle 70 bar (see note 4) CNC controlled clamping/rotating unit for 6th face machining (v. nota 5) Pressurised linear encoders Swarf conveyor Renishaw-ready Y.O.M. 2006 Weight 7500 kgs Turning package Max dia 65mm RPM: 15 / 4500 Max 42,5 KW / 90 Nm. Hydraulic clamping 800 Nm. Bar loader ILS-RBK- 10012 65 Diameters min ...
new
- Arbeitbreite 250 mm - max. Hobelhöhe 180 mm - Tischlänge 1085 mm - 3-Messerwelle inklusive 3 HSS Wendehobelmesser - Drehzahl 4800 U/min. - Motor 2,8 PS / 400 V - Abrichtanschlag 0C-45C schwenkbar - Absaugstutzen Durchmesser 100 mm - Abmessungen L=1500, B=500, H=900 mm - Gewicht 190 kg - Aluminiumanschlaglineal, neigbar und ordentlich feststellbar - Aluminiumschutz über der Messerwelle (Arbeitsschutz) - seitlich aufklappbare massive Graugusstische - stabiler Unterbau für hohe Standsicherheit - Vorschub wahlweise abstellbar - komfortable Schalter-Stecker Kombination - Stahlblech-Spänehaube für Dickenhobelbetrieb umklappbar - Absaugschlauchanschluss FI 100mm - optimal gelagerte Ein- und Auszugswalzen für optimalen Anpressdruck - Dickentischsäule selbstreinigend - einfaches Einstellen der Dickentischhöhe mit Handrad
used
Artec mini table lathe C2x300 tips size 300 mm + 8 PCs chisel set Mini table lathe C 2 and 8 PCs. HSS cutters set now in the Westfalia savings Kit. C-2 the spindle speed variable from 200-2500 RPM via a potentiometer is adjustable at the mini lathe. About a 80 mm three-jaw chucks can be clamped workpieces easily. The workpieces can be supported with a tailstock with MK 2-recording. By a quad-steel holder the cutters can be secured, designed for 8 mm cutters. Also thread can be cut with this mini lathe 1.5 mm pitch. All materials with normal strength can be edited. (Aluminium brass steel). Technical data: centre height 90 mm centre distance 300 mm spindle bore 19 mm tailstock intake MK-2 thread cutting range 0.2 1.5 mm speed range 200-2500 U / min variable power 250 Watt/230 V Plan route 65 mm Oberweg sled 55 mm Quill trail 50 mm Dimensions Lxwxh approx. 700 ...
new
Technische Daten: Verfahrwege: - Arbeitsbereich X - Achse 1640 mm - Arbeitsbereich Y - Achse 3400 mm - Arbeitsbereich Z - Achse 250 mm Arbeitsbereich: - Arbeitsbereich X - Achse 1260 mm - Arbeitsbereich Y - Achse 3060 mm - Arbeitsbereich Z - Achse 100 mm - Spindel Italian HITECO 9.0 kw / HSK 63 F - Spindel Drehzahl stufenlos 0-24.000 rpm - Verfahrgeschwindigkeit 80 m/min. - Arbeitsgeschwindigkeit 20 m/min. - Karusell Werkzeugwechseler 8-fach - Bohraggergat mit 9 Spindeln vertikal + 6 Spindeln horizontal + Nutsägeaggregat - Verfahrsystem (X & Y Achse) Zahnstangen-Ritzelantrieb - Verfahrsystem (Z Achse) Kugelrollspindel - Verfahrmotoren AC Servo Motoren YASKAWA - CAD/CAM Software EXICAM (Englisch) - Steuerung / Controller OSAI / Italy - Arbeitsgenauigkeit 0.05 mm - Konsolentisch mit einfach zu positionierenden Vakuumsaugern (SCHMALZ) und absenkbaren Werkstückseitenanschlägen - Werkst ...
used
Tool and Cutter Grinder of HELLER SA 315, to the automatic sharpening new dovetail and bevelling of HSS circular saw blade, saw diameter of 350 mm -Grinding wheel Ø 125 and 150 mm -Wheel up to 6 mm -Wheel bore 32 mm -Saw blade diameter 80-350 mm -Blade cutting width up to 5 mm -Blade hole 22-60 mm -Central lubrication -Change gears available
new
Technische Daten: - Verfahrbereich X - Achse 900 mm - Verfahrbereich Y - Achse 1300 mm - Verfahrbereich Z - Achse 180 mm - max. Werkstückabmessungen 2500 x 900 x 60 mm - min. Werkstückabmessungen 280 x 75 x 10 mm - Verfahrsystem (X & Y Achse) Zahnstangen-Ritzelantrieb - Verfahrsystem (Z Achse) Kugelrollspindel - Verfahrmotoren AC Servo Motoren Delta / YASKAWA - Luftkissentisch für leichte Bewegung und Schonung der Werkstückoberfläche - Frässpindel luftgekühlt HITECO / Italy 9.0 kw, HSK 63F - Spindel Drehzahl stufenlos 24.000 Upm - Bohraggregat - Bohraggregat mit 9 Spindeln vertikal + 6 Spindeln horizontal + Nutsägeaggregat - Verfahrgeschwindigkeit X - Achse 25 m/min - Verfahrgeschwindigkeit Y - Achse 45 m/min - Verfahrgeschwindigkeit Z - Achse 25 m/min - Steuerung OSAY / Italy - Schnittstelle Ethernet/USB/CompactFlash Card - Werkstückpositionierung, pneumatisch absenkbare Ansch ...
