horizontal used for sale

Control uni-Pro CNC 90 Travel X/Y/Z 800/800/710 mm Speed 4500 1/min Tool magazine for 52+120 tools SK 50 Indexing table 1° 4-fold pallet changer 500x630 mm Conveyor

MCM Clock 600 MP14 FMS consisting of 2 machines CNC FANUC 16i-M, 14 pallets 500mm x 500mm Spindle 15000RPM full 4th axis (360.000 pos) Tool Changer: 200 pos. X=600mm, Y=600mm, Z=700mm JFMX supervisor 2001 Under power in our warehouse in Gussago Mimu Machine Tools (Italy), X: 600, Pallets: 14, Pallet size: 500x500, Spindle: 15000 rpm

Longitudinal X: 400 mm Cross Y: 240 mm Vertical Z: 350 mm Positions ATC: 40   CNC Brand: Heidenhain X - Travel:     400mm Y - Travel:     240mm Z - Travel:     350mm A - Axis:       110° B - Axis:       360° Table load:     25 Table  Ø:       250mm Feed rate X-Axis:40000mm/min. Feed rate Y-Axis:40000mm/min. Feed rate Z-Axis:40000mm/min. Spindle Taper:  40ISO/Bt/Mk Speeds / ranges:42000Rpm Length:         2900mm Width:          2400mm Height:         2700mm Weight:         5500kg

Capacity round maximum diameter: 300 mm Angle degrees maximum: 300 Capacity square: 3660 mm Workpiece height: 9 mm Workpiece width: 27 mm Capacity rectangle: 100 mm Band sawPegas - 300 x 320 SHI - LR MACH-ID 7631 Make: Pegas Type: 300 x 320 SHI - LR Control: PEHU Year: 2018 Capacity 90°:       300° Cutting flat 90°:   320 x 300mm Capacity L 45°:     300° Capacity R 45°:     270° Feed single stroke: 10mm Feed multiple stroke:5000mm Cutting speed Vario:20 - 100 Circle blade size:  3660 x 27 x 0,9mm Power:              2,4kW Length:             2050mm Width:              6000mm Height:             2040mm Weight:             120 ...

: neu : ca. 4 Monate ab Auftragse : Türkei : 44300 € : 8200x41x1,3 mm : 20-100 m/min : 810 mm : 750 mm : 910x750 mm : rund 600 mm, quadrat 600 : rund 360 mm, quadrat 360 : 725 mm : 0.12 kW : 4 kW : 4020 mm : 1600 mm : 2450 mm : 3970 kg hydraulic vice digital readout for scale of bending angle hydraulic clamping of sawing arm turning of sawing arm by hand continuously variable down speed of sawing arm automatic sawing frame lifting after cutting sensitive cutting pressure adjustment subject to material condition hydromechanic tape tension readout by manometer mobile control panel angular geared conical heavy duty gear unit driven chip brush tape guiding by hard metal sheet plates and rolls automatic tape break lock coolant equipment HYDRAULIC UPLIFT OF SAWING FRAME user manual in GERMAN or ENGLISH The data for this ad was created with ModulMWS - the software solution of LogoTech oHG ...

: neu : ca. 14 - 16 Wochen ab Auf : Türkei : 28200 € : 5400x41x1,3 mm : 20-100 m/min : 450 mm : 425 mm : 695 x 425 mm : rund 430 mm, quadrat 425 : rund 320 mm, quadrat 290 : 690 mm : 0.12 kW : 0.55 kW : 4 kW : 3090 mm : 1200 mm : 1940 mm : 1630 kg double linear guides hydraulic-mechanical bandtension saw bandbrush infinitely variable cutting speed sensitive cut regulation bi-metal saw band 41 coolant device thermal overload protection heavy duty gear optical height adjustment 3 ° inclined band hydraulic clamping of the vice user manual in GERMAN or ENGLISH OPTIONS: hydraulic vertical clamping € 1.280,- micro cooling unit € 890,- chip conveyer € 1.090,- laser cutting line € 560,- The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Grinding surface 600 mm x 250 mm Table surface 600 mm x 200 mm Distance between the table surface and the grinding spindle max. 550 mm Max. table load 200 kg Grinding spindle speed at 50 Hz 2,800 rpm Drive power of the grinding wheel 2.2 kW

cutting diameter: 540 mm saw band length: 6700 mm cutting width: 610 mm Stroke: 1000 mm Control: NC band speed: 20-116 m/min column diameter: 150 mm total power requirement: 11 kW weight of the machine ca.: 3,6 t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

SKODA WD 160 A Floor type boring machine - new in 1963 - refurbished 2011 - HEIDENHAIN measuring system - axis: X-axis 9100 mm Y-axis 2500 mm Z-axis 1200 mm W-axis 800 mm

Table size 300 x 300 mm Longitudinal travel 450 mm Cross travel 400 mm Vertical travel 400 mm Max. load on table 200 Kg Spindle speeds 50 - 15.000 rpm Tool change 60 pcs Spindle taper ISA 40 Control FANUC18 i - M Timer, machine on 82.300 Timer Cycle hours 17.200 Timer Main motor power 7,5 Kw Equipped with: Pallets 5 PCS. Internal cooling Hand wheel for axes travel Short arbors Interface RS-232 C Turn table Chip conveyor Coolant Service tools etc.

: neu : ca. 4-6 Monate ab Auftrag : Türkei : 26300 € : 6000x41x1,3 mm : 20-100 m/min : 560 mm : 560 mm : 750x560 mm : rund 410 mm, quadrat 410 : 590 mm : 0.12 kW : 1.1 kW : 4 kW : 3400 mm : 1000 mm : 2050 mm : 2045 kg 2° inclined band linear guides control panel material limit shaft coolant pump 1200 mm roller table hydraulic vice hydromechanic band tensioning inverter presser adjustment band brush optical height adjustment security switch operating manual in Englisch OPTION: turn table for mitre cuts€ 3.700,-- hydraulic top clamping from above € 1.280,-- micro cooling unit € 890,-- laser cutting line € 560,-- The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

capacity 90 degrees: round: 305 mm capacity 90 degrees: square: 260 mm : 350x200 saw band length: 3375x27x0,9 mm band speed: 18 - 100 m/min table height: 880 mm total power requirement: 1,5/1,8 kW weight of the machine ca.: 0,84 t dimensions of the machine ca.: 1,85 x 1,9 x 2,0 m Demonstration system for a SPECIAL PRICE Fully automatic miter band saw • miter left 45° automatic operation • miter left 60° semi-automatic operation (cuts without programming) • Material height sensor (automatic cut start recognition) • Frame and gear made from one piece, very quiet cut and very low vibration • Removable chip tray (disinfection) • Shockproof and ergonomic control panel with oil-resistant EPDM cover • Top access to the saw, material and feed unit • Hinged safety cover • Fine feed adjustment • Semi-auto. Cut! • Optimize work processes with CNC control Possibility to ente ...

cutting diameter: 105 mm saw band length: 1140 x 13 x 0,65 mm cutting width: 100/100x105 mm capacity 60 degrees: round: mm capacity 45 degrees: flat: 55 x 55 mm capacity 45 degrees: round: 60 mm total power requirement: 0,18 kW weight of the machine ca.: 18 kg dimensions of the machine ca.: ca.400 x 300 x 350 mm We must ask you to request machines from us on a daily basis in the near future. Please notice: We would be happy to make you a free offer. However, please understand that we only process inquiries with complete address details. Gear drive, automatic belt tension, electronically adjustable Belt speed from 20 to 100 m / min Due to the light aluminum housing, the machine is very light and therefore good mobile use. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

cutting diameter: 185 mm saw band length: 2.080 x 20 x 0,90 mm cutting width: 100x185 mm connected load frequency: 230 V band speed: 35 und 70 stufenlos m/min mitre joint 90° (angle-iron till): 60 ° total power requirement: 2,35 KW weight of the machine ca.: 195 kg dimensions of the machine ca.: 1280 x 550 x 1480 mm We must ask you to request machines from us on a daily basis in the near future. Please notice: We would be happy to make you a free offer. However, please understand that we only process inquiries with complete address details. An inexpensive and powerful band saw for sporadic workshop use The Zimmer Z185 / R is a self-lowering saw for miter cuts from 0 ° - 60 ° left. After the cut, the machine stops due to a safety limit switch. The lowering is continuously adjustable via a hydraulic system. The manual lifting of the saw arm after the cut can - on any Position. The saw ...

- Grinding width: 200 mm - Magnetic table: 500 x 200 mm - Dressing device: yes - Coolant device: yes - Automatic infeed: no - Machine weight: 1850 kg - Dimensions (W x D x H): 1.8 x 1.5 x 2.2 m m - Condition: good, immediately ready for use Accessories without documentation, machine feet

cutting diameter: 225 mm saw band length: 2480 mm cutting width: 160 mm dimensions of saw-band: 2480 x 27 x 0,9 mm mitter cutting: 60 ° cutting speed: 20 - 90 m/min power capacity: 1,5 kW voltage: 230 V coolant: total power requirement: 1,6 kW weight of the machine ca.: 200 kg dimensions of the machine ca.: 0,70 x 1,40 x 1,40 m - stepless speed - stepless feed - miter cut - Bi-metal saw band - Material stop - Machine base - Coolant device The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

capacity 90 degrees: round: 305 mm capacity 90 degrees: square: 260 mm : 350 x 200 saw band length: 3375 x 27 x 0,9 mm band speed: 18 - 110 m/min table height: 940 mm total power requirement: 1,5/1,8 kW weight of the machine ca.: 0,61 t dimensions of the machine ca.: 1,5 x 1,75 x 1,9 m Double miter metal band saw with AutoCut function - Miter cuts up to 60° left and 45° right - Ball bearing turntable - Vice can be moved sideways - Massive, large material support - Automatic cooling Figure is semi-automatic. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Pallet length: 0 mm Pallet width: 0 mm Longitudinal X: 1000 mm Cross Y: 800 mm Vertical Z: 850 mm Number of pallets: 2   Positions ATC: 60   CNC Brand: Fanuc X - Travel:               1000mm Y - Travel:               800mm Z - Travel:               850mm B-Axis indexing:          360000° Table Length:             630mm Table Width:              630mm Table load:               1600 Number of pallets:        2 Feed rate X-Axis:         12000mm/min. Feed rate Y-Axis:         12000mm/min. Feed rate Z-Axis:         12000mm/min. Spindl ...

Hydraulic Press Brake BEYELER PR6 100/2550 Year of construction: 1998 Command: CYBELEC DNC 804 PS/K 6 axes Capacity: 100 T x 2550 mm Maxi travel: 215 mm Throat depth: 405 mm Distance between uprights: 2050 mm Maxi closing speed: 200 mm/s Working speed: from 1 to 10 mm/s Motor: 7,5 kW sBack Rear Gauge R1 - R2 - Z1 - Z2 Dual pedal footswitch Voltage: 380 V Dimensions (L x W x H): 3000 x 2000 x 2550 mm Weight: 6,5 T

Motorized lathe Hwacheon 300 ML :::SPECIFICATIONS::: CNC Model: Fanuc - CNC Version: 18i - Main Spindle Nose: ASA 8 - Main spindle power: 22Kw Main spindle self-centering diameter: 250mm - Main spindle bar passage: 78mm - Turning diameter: 380mm - Turning length: 1200mm Number of Main Spindle Revolutions: 3200 Number of Tool Turrets: 1 Number of tool places before turret: 12 Number of motorized first turret: 12 X axis travel first turret: 280mm Z axis travel first turret: 1270mm High cooling pressure: yes Tailstock: yes Dinghy stroke: 120mm Chip evacuator: carpet Number of motorized tool holders supplied: 4 Self-centering bezel: yes Make and model of self-centering bezel: Morari SLZ 151 Min diameter - Max diameter: 15 - 170mm Other technical data: Tailstock in cycle with coupling to the wagon Machine equipment: STD tool holder kit

Capacity: 1 200 T, Total stroke: 500 mm, Stroke of main crank shaft: 318 mm, Stroke of mobile die: 215 mm, Stroke/min: 27, Bar diameter: 50-90 (150) mm, Max diameter of peace: 152mm, Max weight of piece: 5 kg, Main motor power: 75 KW, Area of machine : 6400 x 4420 mm, Hight of machine: 3830 mm, Weight: 128.0 T

GENERAL Project No.: 905610 Quantity: 1 pcs. Manufacturer: MÄGERLE Type: MGC Grinding Centre Control: Siemens 840 D solutionline Year of construction: 2020 Conservation status: Used machine Machine on approx. (hrs): 2.124 Program run approx. (hours): 155 Spindle on approx. (hrs): 214 DESCRIPTION GRINDING Travel in X 1300 mm Travel in Y 450 mm Travel in Z 350 mm Max. rapid traverse speed in X/Y/Z 20/10/10 m/min Max. distance table spindle center 850 mm Automatic balancing device Motor spindle Max. diameter x width x bore grinding wheel 500x160x203.2 mm Max. circumferential speed 63 m/s2 Max. speed 5000 1/min Max. power at ED 10-40/100% 50 kW Workpiece table with T-slots and 16-fold oil feed-through (shuttle table) 2x 760×325 mm Clamping hydraulics Hydrostatic guidance Forming roll dresser MT 200 D200 B167 OTHER EQUIPMENT Splash guard cladding wit ...

Motorized lathe BIGLIA B 1200Y :::SPECIFICATIONS::: CNC Model: Fanuc CNC version: 18i - TB Main spindle nose: ASA 8 Main spindle power: 26Kw Main spindle self-centering diameter: 315mm Main spindle bar clearance: 94mm Turning diameter: 400mm Turning length: 1200mm Number of Main Spindle Revolutions: 2800 Number of Tool Turrets: 1 Number of tool places before turret: 12 Number of motorized first turret: 12 X axis travel first turret: 255mm Y axis travel first turret: +60 -50mm Z axis travel first turret: 1315mm Rapid feeds linear axes X Y Z: 24m/min Tailstock: yes Chip evacuator: carpet Presetting: yes Self-centering bezel: yes Self-centering bezel make and model: Bezel wagon :::D IMENSIONS AND WEIGHT::: Length: 5100mm Width: 2130mm Height: 2100mm Weight: 6800Kg

Index G200 bar lathe :::SPECIFICATIONS::: CNC Model: Siemens CNC version: Index C 200 - 4 Main spindle nose: ASA 6 Main spindle bar clearance: 60mm Turning diameter: 150mm Turning length: 400mm Main spindle revolutions: 5000 Number of Tool Turrets: 1 Number of tool places before turret: 14 Number of motorized first turret: 14 First turret tool attachment type: VDI 25 X axis travel first turret: 155mm Y axis travel first turret: +-60mm Z axis travel first turret: 400mm Model and brand bar magazine: LNS Hydrobar L 3000 mm Tailstock: yes Positioning: automatic Chip evacuator: carpet Other technical data: The tailstock has a programmable axis Machine equipment: Rich equipment: Motorized and fixed tool holder sets Hainbuch pliers Self-centering forkardt :::D IMENSIONS AND WEIGHT::: Weight: 4800Kg

Inv. Num. : 6982 Type: OPTIMA Producer: TOS Created: 2005 Parameters: Working table length: 2500 mm Working table width: 1800 mm X-axis travel: 3000 mm Y-axis travel: 1800 mm Z-axis travel: 1600 mm

Ref. -No.: 10357 Manufacturer: STARRAG HECKERT Year of construction: 2007 Type of control: CNC Steuerung Control: Sinumerik 840D Country of origin: Schweiz X-Travel: 1200 mm Y-Travel: 950 mm Z-Travel: 1200 mm Work spindle drive power (25% ED): 67 kW Work spindle torque (25% ED): 1508 Nm Tool Taper: HSK-A100 Workpiece interference circle diameter: 1250 mm Tool Piece Magazine With: 80 Pcs./pcs. Tool changer: Werkzeugkettenmagazin Max. Workpiece height: 1200 mm Feed Speeds X/Y/Z Axis: 60000 mm / min Feed Capacities X/Y/Z: 22/18/22 N Speed range - main spindle: 20 - 6000 RPM Numbers Of Pallets: 2 Max pallet load: 1500 kg Size Of Pallet: 800 x 630 mm pallet change time: 14 s Pallet clamping area (lxw): 800 x 630 mm Weight Of The Machine Ca.: 25 t

Ref. -No.: 10342 Manufacturer: STARRAG HECKERT Year of construction: 2015 Type of control: CNC Control: Fanuc Series 16i Storage location: Halberstadt Country of origin: Schweiz Serial no.: 12217 X-Travel: 1000 mm Y-Travel: 910 mm Z-Travel: 835 mm Distance spindle center - table: 100 mm Table Dimensions (Lengthxwidth): 630 x 800 mm Table Load: 1250 kg Max. Tool Length: 600 mm Max. Tool Diameter: 500 mm Tool Taper: HSK-A 100 Numbers Of Tools In Magazin: 240 Spindle Speed: 20 - 6000 RPM Feed Capacities X/Y/Z: 20.000 N Rapid Traverse: 40 m / min Internal cooling: 30/40/50 bar External cooling: 2 bar

Ref. -No.: 10335 Manufacturer: HÜLLER HILLE Year of construction: 2008 Type of control: CNC Control: Sinumerik 840D pl Storage location: Halberstadt Country of origin: Germany X-Travel: 1000 mm Y-Travel: 800 mm Z-Travel: 800 mm B-Axis: 360 ° Machine length: 9500 mm Machine width: 4500 mm Machine Height: 3500 mm Distance spindle center - table: 150 mm Table Dimensions (Lengthxwidth): 500 x 630 mm Table Load: 800 kg Max. Workpiece Weight: 40 kg Max. Tool Length: 650 mm Max. Tool Diameter: 325 mm Workpiece Diameter At Full Load: 100 mm Tool Taper: HSK - 100 Spindle Speed: 0 - 12000 RPM Rapid Traverse: 60 m / min Further information: Coolant system = 1250 l

Ref. -No.: 10022 Manufacturer: UNION Year of construction: 2001 Type of control: CNC Control: Heidenhain-Steuerung TNC 310 Storage location: Halberstadt Country of origin: Deutschland X-Travel: 2000 mm Y-Travel: 1600 mm Z-Travel: 2000 mm Machine length: 6950 mm Machine width: 4685 mm Machine Height: 3885 mm Table Height: 1050 mm Spindle Diameter: 110 mm Spindle Taper: ISO 50 Table Dimensions (Lengthxwidth): 1400 x 1600 mm Faceplate speed: 5,6 - 224 RPM Spindle Speed: 5,6 - 1120 RPM Metric thread feeds: 1,25 - 56 mm Drive Capacity - Spindle Motor: 40 kW Weight Of The Machine Ca.: 25 t Bore Depth: W 800 mm Further information: with facing slide 13 inch thread feeds 1 1/8 - 28 Gg / 1 “ YOM: 1990/ Retrofit: 2001

Hydraulic Press Brake FAVRIN type P4HS Capacity: 2500 x 3 mm Year of construction: 1990 Motor power: 5,5 CV Clamping pressure: 165 bars Clamping travel: 200 mm Bending angle: 45° Voltage: 380 V Dimensions (L x W x H): 3700 x 1700 x 2200 mm Weight: approx 3,2 T

x-travel: 450 mm y-travel: 400 mm z-travel: 400 mm : control: Heidenhain 355 cooling: total power requirement: 4 kW weight of the machine ca.: 2,4 t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Key data: 3000 mm, 1800 mm, 1600 mm

Inv. Num. : 7037 Type: OPTIMA Producer: TOS Created: 2005 Parameters: Duty cycle: 83171 h Hours: 36486 h Work table length: 2500 mm Work table width: 1800 mm X-axis travel: 3000 mm Y-axis travel: 1800 mm Z-axis travel: 1600 mm

Key data: 560 mm, 510 mm, 560 mm

Inv. Num. : 5374 Type: H 40 TREND Producer: ZPS Created: 2004 Parameters: Control system: Siemens 840 D Work table length: 400 mm Work table width: 400 mm Tool magazine: 45 pieces Maximum spindle speed: 10000 1/min X-axis travel: 560 mm Y-axis travel: 510 mm Z-axis travel: 560 mm Cone: SK 40 Machine height: 2616 mm Machine length: 4730 mm Machine width: 2540 mm Machine weight: 9 t 2020: new spindle and new table (the parts) 2022: new table clamp

Key data: 400 mm, 700 mm, 400 mm

Inv. Num. : 6723 Type: BA400-2 Producer: SW Created: 2004 Parameters: Control system: Siemens - Sinumerik 840D Maximum spindle speed: 17500 1/min Tool magazine: 120 pieces X-axis travel: 400 mm Y-axis travel: 700 mm Z-axis travel: 400 mm Cone: HSK63 Equipment: IKZ High Pressure Pump Filtration Knoll Preparation for 5 axis

cutting diameter: 280 mm saw band length: 3660 x 27 mm cutting width: 0,9 mm capacity 90 degrees: square: 270 x 270 mm capacity 90 degrees: flat: 210 x 330 mm total power requirement: 1,5 kW weight of the machine ca.: 1200 kg dimensions of the machine ca.: 1350 x 2250 x 1860 mm The GERD WOLFF KMS 280 is a precision servo-driven bandsaw designed for consistently accurate cutting. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Key data: 1000 mm, 800 mm, 850 mm

Inv. Num. : 6941 Type: MCFH63 Producer: ZPS Created: 2001 Parameters: Control system: Siemens X-axis travel: 1000 mm Y-axis travel: 800 mm Z-axis travel: 850 mm

Yunnan MY7120A 450 x 200 mm Worklength with magnetic table: 460 mm Grindingwidth: 200 mm Longitudinal travel X-axis (autom.): 480 mm Cross-travel Y-axis (autom.): 240 mm Travel Z-axis (autom.): 300 mm Dimensions of the table: 450 x 200 mm Distance between table -- spindlecentre: 65 > 448 mm Max dia grindingstone: dia 200 x 16 x 32 mm Spindlespeeds: 2800 rpm Motorpower: 1,5 kW Length: 1520 mm Depth: 1100 mm Height: 1640 mm Weight: 950 kg

Key data: 1010 mm, 800 mm, 1010 mm

Inv. Num. : 6942 Type: H63 Producer: ZPS Created: 2005 Parameters: Control system: Siemens Work table length: 800 mm Work table width: 630 mm X-axis travel: 1010 mm Y-axis travel: 800 mm Z-axis travel: 1010 mm

BAR LATHE MIYANO BNJ 42S :::SPECIFICATIONS::: CNC Model: Fanuc - CNC Version: 18iT - Main Spindle Power: 11Kw - Main Spindle Bar Clearance: 42mm Number of main spindle revolutions: 5000 - Number of tool holders: 2 - Number of first turret tool positions: 8 - Number of first turret motorized units: 8 First Turret X-Axis Travel: 142mm First Turret Z-Axis Travel: 250mm Number of second turret tool slots: 3 Number of fixed tool positions for the second turret: 3 Sub-spindle: yes Sub-spindle speed: 5000 Power against spindle: 5.5Kw Bar clearance: 42mm Z stroke counter spindle : 250mm Bar feeder model and brand: LNS Hydrobar Mini Sprint Chip conveyor: belt conveyor Number of live tool holders supplied: 2 :::D DIMENSIONS AND WEIGHT::: Length: 2700mm Width: 1450mm Height: 1720mm Weight: 4600Kg

Packaging machine BVM Compacta 5022 EMS Servo; good condition; cleaned and tested; Welding width 500mm; Passage height 220mm; with 2.Sonber welding stamp for plastic bag handle; optionally with shrink tunnel SC 4030 SD. Side sealing machine BVM Compacta 5022 EMS Servo; good condition; cleaned and checked; sealing width 500mm; hight 220mm; with secound stamp for plastic bag handle; for option with shrink tunnel SC 4030 SD.

Key data: 400 mm, 700 mm, 400 mm

Inv. Num. : 7008 Type: BA400-2 Producer: SW Created: 2011 Parameters: Control system: Siemens - Sinumerik 840D Number of stacking positions: 120 Maximum spindle speed: 17500 1/min X-axis travel: 400 mm Y-axis travel: 700 mm Z-axis travel: 400 mm Cone: HSK63 Equipment: IKZ Conveyor High Pressure Pump Filtration Knoll 1x two-seater 5th axle W1W2 on U-side (manufacturer SW) Laser Inspection of Broken Tools

Motorized lathe CMZ TD 45 Y 1350 :::SPECIFICATIONS::: CNC Model: Fanuc - CNC Version: 32 iTB - Main Spindle Nose: ASA 11 - Main Spindle Power: 51Kw Main chuck diameter: 400mm - Main spindle bar clearance: 127mm - Turning diameter: 550mm Turning length: 1300mm Main spindle speed: 2200 Number of Tool Turrets: 1 Number of first turret tool slots: 16 Number of First Turret Motors: 16 First Turret X-Axis Travel: 380mm Y-axis travel first turret: +80 - 60mm First Turret Z-Axis Travel: 1350mm Tailstock: Yes Chip conveyor: belt conveyor Presetting: yes Self-centering bezel: yes Make and model centering steady rest: Autoblock SLU-X-3.2-ZS Min diameter - Max diameter: 50 - 200mm Other technical data: Mnadrini turret at 12000 rpm and power 13.7 Kw Machine equipment: set of fixed and motorized tool holders

Condition: well-kept, fully functional Availability: as of now Voltage: 380+N+T Phases: 3 Frequency: 50 Hz Power:2500 W

Effort 2000t moving matrix 280 mm landing pad 570 mm landing slider after closing the matrices 390 mm Number of moves of the ram, stroke / min 25 Electric motor power 160 kW Dimensions, mm: LWH = 856053604850, the level above the floor is 3200. Weight of the car without electricity: 239.8 tons. Weight of the bed: Front part: 82 tons. Rear part: 55t. Weight 270 ton

Centre d’usinage de profils alu acier pvc : Marque: Ciman Mack 7 lg8000 ou en 2x4000 alternatif +CN sur pupitre filaire 3 axes avec chargeur d’outils (axe Z à revoir) Section 220/120 Bande d’évacuation copeau avec cuve mobile Barrière de cellule en façade et paroir acoustique 3 côtes Poids 3t + 1t Dimensions machine 8000/1200h1500

Table size: 1500x1500mm Shank: 130mm B axis with positioning 0.001 CNC: Fanuc 12M Travels X=1800mm Y=1500mm Z=1200mm BT50 60 tool charger Chip conveyor Internal cooling Renishaw probe Maximum load on table: 8000 kg Total weight of the machine: 35000 kg.

Machining capacity -Maximum swing diameter above the guide ways: 2500 mm (98.42 in); -Maximum swing diameter above the saddle: 2100 mm (82.67 in); -Distance between centers: 7600 mm (299.21 in); -Maximum weight between centers: 20 tons. Faceplate -Faceplate diameter: Ø2200 mm (86.61 in); -Turning speed range: 150 rpm ; -Main motor power: 60/75 kW ( 80/100 HP); C axis -C axis: continue 360°; -Milling spindle motor power: 11/15 kW (14/20 HP); Standard Accessories: -FANUC 0i CNC; -Heidenhain linear scales; -Faceplate, 1 piece; -Tool turret with 12 posts for milling tools, 1 piece; -Partial enclosure with chip conveyor; -Centralized hydraulic and lubrication unit; -Electrical devices: 380V, 3 phases, 50 Hz; -Levelling devices for foundation, 1 set.

Inv. Num. : 7007 Type: BA400-2 Producer: SW Created: 2010 Parameters: Control system: Siemens - Sinumerik 840D Number of stacking positions: 120 Maximum spindle speed: 17500 1/min X-axis travel: 400 mm Y-axis travel: 700 mm Z-axis travel: 400 mm Cone: HSK63 Equipment: IKZ Conveyor High Pressure Pump Filtration Knoll 1x two-seater 5th axle W1W2 on U-side (manufacturer SW) Laser Inspection of Broken Tools

Chassis number: 416-87 Weight: 1,5 tons Length mm: 4000 Width mm: 2000 Height mm: 1300 Transport size L x W x H: 4,0 x 2,0 x 1,3 Min.-max glass size: min 100mm / max. 1250mm Condition machine : Working - For more information, please mail us: salestecfort.nl

Key data: 710 mm, 610 mm, 660 mm

Control Mazatrol Fusion 640M Travel X/Y/Z 710/610/660 mm Spindle speed 12,000 min-1 Tool magazine for 80 tools SK40 2-fold pallet changer (500x500 mm) Max. workpiece D 730 mm, H 710 mm, 500 kg Conveyor
