horizontal milling center used for sale

Tool changer: 32 places IKZ 22 bar + belt filter system Chip conveyor Auction-ID: A1-46607-10

Table size: 800x400 mm Tool changer 12-speed Electric handwheel Auction-ID: A1-46607-98

Fully populated tool changer, 30 position tool changer, with dividing head - 4 axis, Vise ALLMATIC LC125, Handwheel Auction-ID: A1-46607-33

Technical data Manufacturer: CHEVALIER Model: FALCON-2033VMC Machine Type: Vertical CNC Machining Center Table size: 1000 × 450 mm Max. table load: 500 kg Travel (X/Y/Z): 650 / 500 / 500 mm Spindle mount: #40 Speed range: 60 – 6000 rpm⁻¹ Spindle motor: 7.5 kW Rapid traverse: 15 / 15 / 12 m/min Positioning accuracy: ±0.005 mm Repeatability: ±0.003 mm Tool changer: 20 places Max. tool weight: 7 kg Dimensions set-up: 2740 × 2508 × 2755 mm Machine weight: approx. 4500 kg Configuration Tool magazine: 20-fold carousel Coolant pump: integrated Compressed air requirement: 5 kg/cm², 200 l/min Power requirement: 15 kVA (optional 20 kVA) Auction-ID: A7-46432-10

- Tool changer: 16-speed - Chip tray available and chip conveyor purchased at a later date Auction-ID: A1-46607-1

Table size: 1000 x 560 mm Probe: Heidenhain Tool changer: 30 places Auction-ID: A1-46607-51

BROTHER TC-R2A – CNC Vertical Machining Center General data: Manufacturer: Brother Model: TC-R2A Machine number: 111291 Year of manufacture: 2002 Machine type: CNC vertical machining center Technical details: Axis travel (X / Y / Z): 420 / 320 / 450 mm Tool changer: 14-position automatic tool changer Pallet changer: yes Rotary table: CNC rotary table included Control system: CNC control: Brother Electronic handwheel: included Description: Compact CNC vertical machining center BROTHER TC-R2A designed for high-speed and precise machining operations. Equipped with automatic tool changer, pallet changer, and rotary table, the machine is suitable for efficient production and multi-axis processing in industrial environments. Auction-ID: A7-46498-40

BROTHER TC-215 – CNC Vertical Machining Center General data: Manufacturer: Brother Model: TC-215 Machine type: CNC vertical machining center Technical details: Spindle speed: 6000 – 10000 rpm Control system: CNC-400 Description: CNC vertical machining center BROTHER TC-215 designed for precision milling and machining operations. The machine provides reliable performance and a versatile spindle speed range, making it suitable for various industrial and workshop applications. Auction-ID: A7-46498-58

4-axis dividing head Auction-ID: A1-46607-111

Tool changer: 18 places Auction-ID: A1-46607-95

Accuway UM130 with 4th axis: Tool changer: 32-speed Spindle nose to table: 150 - 700 mm Table size: 1500 x 650 mm T-slots: 5 x 18 x 100 mm Max. workpiece weight: 1500 kg Feed speed: X/Y/Z: 30 m/min Max. tool length: 300 Auction-ID: A1-46607-18

Rotary table diameter: 700 mm Table surface: 1250 x 700 mm B-axis: +30 / -120 C-axis: 360 Tool changer: 32 times 2019: X/Y/Z guides and KGT renewed Auction-ID: A1-46607-120

Table dimensions: 1500 x 1000 Table load: 2,500 kg Distance between table and spindle: 200-800 mm Tool Changer: 30 Tool Measurement: Blum Laser Chip conveyor electr. Handwheel Maximum height: 3550 mm Auction-ID: A1-46607-42

Tool positions: 16-fold NC rotary table: 630 mm B-axis: -5/+95 without vice Auction-ID: A1-46607-29

Equipped with digital counter, fixed seat, quick-change tool holder with 12 adapters, self-centering 4-jaw chuck, ø 250 mm. Auction-ID: A1-45502-158

Equipped with Newall digital readout type B 60, quick-change tool holder + 4 adapters, four-jaw chuck 200 mm, change wheels, two fixed and two pedestrian glasses, various turning tools, centers, Wooden storage cabinet. Auction-ID: A1-45502-161

CNC Machining Center JOHNFORD VMC-850 | Year of construction 2023 | FANUC | 60-fold tool changer Manufacturer: JOHNFORD Model No.: VMC-850 Machine Type: CNC Machining Center Year of manufacture: 2023 Operating hours: approx. 667 h ⸻ CNC control • FANUC 0i-MF Plus • Manual Guide i • Dual Check Safety (safety software) ⸻ Spindle & Tool Changer • Tool changer with double-arm gripper • 60 tool positions • Tool holder: SK40 • Milling spindle: 5.5 / 7.5 kW • Speed: up to 12,000 1/min ⸻ Measuring & Cooling Systems • Glass scales in X, Y and Z axes • IKZ 30 bar through the spindle • Programmable air/water switching • Oil mist extraction, programmable • Renishaw OMP40-2 touch probe (wireless) • Renishaw OTS tool measuring tool setter (wireless) ⸻ Workspace • X-axis travel: 800 mm • Y-axis  ...

Clamping System: SK40 30-position tool changer Minimum and maximum tool diameter: 76/125 mm Maximum tool length: 280 mm Maximum tool weight: 7 kg Including tool holders and related drills/cutters. With the possibility of converting clamping system to the desired type, subject to a quote from the product representative. Assorted quantities and types, as shown in the photo. The total availability of individual visible elements is not guaranteed. Auction-ID: A7-46538-10

Grinding wheel gap: 1.5 / 50 mm, Max.width of wheel in feed grinding: 125 mm, Working wheel dimensions (od x id x width): 325x175x125 mm, Øext.min. working wheel: 220mm, Max. profile depth of the working wheel: 8 mm, Regulating wheel speed nº: infinite, Infeed (auto / manual): Automatic / Automatic, Driving wheel dimensions (od x id x width): 220 x 125 x 125 mm, Øext.min. driving wheel: 165 mm, Working wheel motor power: 7,5 Kw, Driving wheel motor power: 0.75 Kw, Angle of inclination of the working grinding head: +/- 5º, Angle of inclination of the drive wheel head: -2/+5º, Long: 1.520 mm, Width: 1.020 mm, High: 1.260 mm, Weight: 1.550 Kg

Max. machining length: 2,600 mm Y-axis travel: 315 mm Travel Z-axis: 230 mm Speed of milling spindle infinitely adjustable between 2,800 and 12,000 rpm Rotatable support table between 0° and 180°, thus 3-sided machining in one clamping X and Y-axis CNC controlled, Z-axis infinitely adjustable motorized 4 pneumatic material tensioners Manual tool change Minimum quantity spraying device USB port Instruction manual

Key data: 762 mm, 630 mm, 610 mm

Inv. Num. : 9118 Type: XT 630 5AX Producer: Bridgeport Created: 2018 Parameters: Control system: Heidenhain TNC 640 Switch-on hours: 26283 h Hours: 13817 h Table diameter: 630 mm Number of axles: 5 pieces Maximum vertical spindle speed: 15000 1/min X-axis travel: 762 mm Y-axis travel: 630 mm Travel travel Z-axis: 610 mm Cone: BT40 Machine weight: 14600 kg

Performance data Drilling performance in ST 60 with carbide drill up to 42 mm Threading up to M30 Milling capacity in ST 60 to 600 cm³/min Tool magazine with 20 tool positions Maximum tool diameter 75 mm For free secondary seats, a maximum of 125 mm Maximum tool length 280 mm Maximum tool weight 8 kg Spindle drive 22 kW Stepless speed range 20 – 9,000 rpm⁻¹ Maximum torque 140 Nm Rapid traverse speed 40 m/min Feed force X- / Y-axis 5,000 N Feed force Z-axis 10,000 N Media and connection values Coolant device with 200 litre tank capacity Total connected load approx. 20 kVA Air connection 6 bar including collets 23 pieces, plus sleeves for bar feeders Auction-ID: A7-46729-5

Reading hours: approx. 67,741 h (machine) / approx. 21,617 h (spindle) Equipped with: 60-fold tool change magazine, (1x) chip conveyor (2017), (1x) cooling/filter unit with pumps and control cabinet, oil mist separator. Auction-ID: A1-45979-2

Maximum tool weight: 7kg, Maximum tool length: 300mm. Equipped with: (1x) 16-way tool changer, (1x) chip conveyor, (1x) cooling/filter unit, (1x) spindle cooler, (1x) external cooling unit. Auction-ID: A1-45979-4

Reading hours: approx. 66.283 h (machine) / approx. 21.312 h (spindle) Equipped with: 60-fold tool change magazine, (1x) chip conveyor (2017), (1x) cooling/filter unit with pumps and control cabinet, oil mist separator. Auction-ID: A1-45979-3

Spare parts (spindles) for Starrag machine ZT 800 / ZT 1000 2x Ø310x800mm (150mm x Ø128.5mm) 1x Ø310x1000mm (340mm x Ø128.5mm) Various ball screws to Starrag - partly new ground - partly new (unused)

CONTROLS   CNC controls MORI SEIKI MSG-501 WORKING RANGE -CUBIC-   number of processing axes (excl parallel axes): 4   X-axis travel: 1300 mm   Y-axis travel: 1200 mm   Z-axis travel: 1100 mm TABLE   table surface (left-right): 800 mm   table surface (front-back): 800 mm   workpiece load (max): 2000 kg SPINDLE / HEAD   spindle revolutions (max): 0 /min   spindle revolutions (max): 6000 /min   tool fixture: ISO BT 50 AXIS DRIVES   rapid traverse: 42000 mm/min TOOL MAGAZINE   number of positions: 60 ELECTRICAL SPECIFICATIONS   mains voltage: 400 V   mains frequency: 50 Hz DIMENSIONS / WEIGHTS   space requirements -left/right-: 7400 mm   space requirements -front/back-: 4300 mm   total height: 3750 mm   total weight approx.: 23500 kg ATTACHMENTS   chip conveyor: yes   coolant unit: yes   band filtration unit: yes   through spindle coolant at ...

A Mazak CNC 5-axis machining center with a dual pallet changer is available. Spindle power: 22kW, speed: 10000rpm, rapid traverse: 42m/min, tool positions: 80, tool holder: SK50, coolant pressure: 70bar, control system: Mazatrol Matrix. Including CNC option package Performance, preparation for Monitoring System B, Mayfran Consep 2000 chip conveyor and tool length measuring device. Documentation available. An on-site inspection is possible.

SPINNER TC110L-MCY Powerful, used CNC turning-milling center with C-/Y-axis for complex machining with driven tools. Year of manufacture 2007 Control SIEMENS 840DE sl ShopTurn X – 350 mm Y – 230mm -115+115mm Z – 1,840 mm C-axis Swing diameter up to 690 mm Spindle 26 kW with 2 gears Speeds up to 3,200 rpm. Spindle bore 110 mm Equipment: Revolver BARUFFALDI type TBMR250-12 with 12 seats, Refurbished in 2024 Driven tools up to 4,000 rpm. VDI 50 Mounts hydraulic bezel make SMW Hydraulic three-jaw chuck make SMW diameter 315 mm Oil Mist Extraction System Make IFS Model M1600 Year 2012 Hinged belt chip conveyor make KNOLL Model S -1/50 Paper belt filter system make KNOLL model KF150/700 Coolant High Pressure Pump electronic handwheel Footswitch Included in delivery: Operating Instructions/Documentation More photos and PDF with technical data & transport ...

Manufacturer: KAO FONG MACHINERY CO., LTD. (KAFO) Year: 1990 Type: CNC Vertical Machining Center CNC Numerical Control: FANUC Series 15-M Axes: 3-axis (X, Y, Z) Strokes: X 1030 mm / Y 210 mm / Z 610 mm Spindle: BT40 – up to 6000 rpm – power approx. 11 kW Tool magazine: 20 positions BT40 Weight: approx. 6000 kg Origin: Taiwan Notes: Heavy-duty CNC vertical milling and boring machine for general machining. Auction-ID: A1-46647-228

Spindle speed: 18,000 rpm Tool magazine: 50 tools Tool holder: SK25 Working area (X × Y × Z): 400 × 250 × 350 mm Auction-ID: A7-46789-1

Machine: MASTERWOOD PROJECT DOORS Machining Center Year: 2001 Machining Range: X 2500 mm, Y 1360 mm, Z 100 mm (120 mm pass-through) Front Position: 2.2 kW horizontal unit, 8 kW ISO30 solenoid spindle, 8 pos. ISO30 Rear Position: 2.2 kW horizontal group, 14 inch rotating magazine. ISO30, manual tilting X/Y index head Table: belt-driven, vacuum pump 100 m³/h Belt: chip evacuation Order: Windows PC + SINCRO software Standards: EC Auction-ID: A1-46801-40

Center height: approx. 150 mm Center length: approx. 800 mm Reference: Hercegfi - Lot 112 Auction-ID: A7-46763-243

Machine number: KMM526 1506 Operating voltage: 400 V Frequency: 50 Hz Rated current: 45 A Control: FANUC SERIES 18i-MB 5 Table dimensions: 1500 x 470 m with three grooves Attention: without the clamping devices shown in the photos incl. 4th axis Travel X-axis: 1000 mm Travel Y-axis: 400 mm Travel Z-axis: 360 mm Projection: 350 mm Working spindle Spindle bearing diameter: 65 mm Tool holder: SK 40 Spindle speed: from 36 to 12000 rpm incl. 42-fold tool changer Max. tool diameter: 125 mm Max. tool length: 250 mm Feed in X/Y/Z axis: 1 - 10000 mm/min Rapid traverse in X/Y/Z axis: 45 m/min incl. chip conveyor and coolant system Reference: Elos - Lot 1 Auction-ID: A7-46763-320

Machine: MASTERWOOD PROJECT DOORS Machining Center Year: 2001 Machining Range: X 2500 mm, Y 1360 mm, Z 100 mm (120 mm pass-through) Front Position: 2.2 kW horizontal unit, 8 kW ISO30 solenoid spindle, 8 pos. ISO30 Rear Position: 2.2 kW horizontal group, 14 inch rotating magazine. ISO30, manual tilting X/Y index head Table: belt with vacuum pump 100 m³/h Belt: chip evacuation Order: Windows PC + SINCRO software Standards: EC Auction-ID: A1-46801-39

CNC vertical machining center for machining metal parts. Numerical control: Siemens 810D Strokes: X 630 mm / Y 500 mm / Z 500 mm Table: 800 × 500 mm Maximum table load: 500 kg Spindle cone: ISO 40 Spindle speed: 10,000 rpm Auction-ID: A1-46647-248

Atlas machining center tubeless version X-axis stroke = 6000 mm Power supply 400V 50Hz Europower supply Anuba Group in CA Anuba Diam.13 sheet Vertical support for milling unit 0/90pn Upright position n.2 Milling unit 15HP Index HSK F63 Fixed head with 2 outlets blade holder D=220 + cutter holder - HSK 63 F Tool Holder 14 pos.side trolley HSK63 Front upright position Drill head Saw for longitudinal incisions 11 kW frequency inverter 8 suction cups 114X140MM - H 100 (to be confirmed) 12 suction cups 125x75MM - H 100 longitudinal (to be confirmed) 2 suction cups 114x140mm - H 75 for blocking. Template (to be confirmed) 3 additional vacuum devices for workpiece blocking 2 pneumatic vertical pressers supp. - 1 MVT. - 100 hours (to be confirmed) 2 horizontal pneumatic vices (to be confirmed) Positioning 10 bars + suction cups on display CE safety standards for atlas bati xl Atlas  ...

Manufacturer: DMG (Deckel Maho Gildemeister) Year: 2006 Type: CNC Vertical Machining Center Numerical Control: Heidenhain TNC 530 Strokes: X 635 mm / Y 510 mm / Z 460 mm Spindle: 12,000 rpm Tool magazine: 32 positions Spindle center coolant: 20 bar Filtration: Cartridge filtration Tooling: No tooling supplied with the machine Weight (kg): approx. 6000 Notes: Multi-purpose CNC vertical machining center. Serial number included in the description. Auction-ID: A1-46647-216

Manufacturer: SIGMA Year: 2002 Type: CNC Vertical Machining Center Numerical Control: FANUC 18M Axes: 3-Axis (X, Y, Z) Strokes: X 750 mm / Y 400 mm / Z 450 mm Table: 900 x 400 mm – max. load 600 kg Spindle: SK40 (DIN 69871-A) – 6,000 rpm – 15 kW – max. torque 191 Nm Tool magazine: random carousel – 21 tools Guides: Linear guides Weight: 6,000 kg Remarks: Italian-made CNC vertical machining center, functional machine. Auction-ID: A1-46647-223

Machine number: 71401453 Operating voltage: 400 V Frequency: 50 Hz Rated current: 80 A Connection: 44 kVA Spindle hours read: 26350 Control: MILLPLUS Spindle speed: up to 12000 rpm Feed X/Y/Z axis: 20 - 15000 mm/min Rapid traverse X/Y/Z axis: 40 m/min Displacement measuring system Resolution X/Y/Z axis: 0.001 mm Input gauge X/Y/Z axis: 0.001 mm Position tolerance in X/Y/Z axis: 0.010 mm Travel X-axis: 600 mm Travel Y-axis: 700 mm Travel Z-axis: 600 mm Tool holder: SK 40 incl. 60-fold tool changer Max. tool diameter: 100 mm Max. tool length from spindle nose without tool breakage monitoring: 350 mm NC rotary table Clamping surface: 630 mm Diameter Distance between T-slots: 63 mm Number: 9 Centering bore: 50 mm Diameter Max. rotation of table top: 10.7 rpm Feed: 3600°/min Resolution of the measuring system: 0.001° incl. chip conveyor and cooling system Attention: the machine can be trans ...

Machine sold without tools Vise not included Included only probe Auction-ID: A1-46647-1

CNC vertical machining center for machining metal parts. Numerical control: Siemens Sinumerik 810D Powerline Strokes: X 640 mm / Y 600 mm / Z 500 mm Table: 850 × 600 mm Maximum table load: 600 kg Spindle taper: SK 40 (DIN 69871) Spindle speed: 1 – 8,000 rpm Fast feeds: X 70 m/min / Y 40 m/min / Z 40 m/min Tool changer: 30 positions Spindle motor power: 12 / 17 kW Energized hours: 43,000 h Operating hours: 15,000 h Note: Without tool holder Auction-ID: A1-46647-242

Year: 1995 Serial No.: 488-11 Type / Function: 4-axis vertical CNC machining center Configuration: 2 pallets, 2 × 4th axis Peiseler RT 160 Numerical control: SIEMENS Spindle: New spindle replaced in 2021 Included equipment: KNOLL filter unit, chip conveyor Weight: 4000 kg Auction-ID: A1-46647-271

Serial number: 1537001259A Operating voltage: 400 V Frequency: 50 Hz Connection: 17 kVA Rated current: 35 A Control: HEIDENHAIN TNC 620 Spindle speed: up to 12,000 rpm Max. spindle torque: 83 Nm Feed speed in X/YZ: up to 20,000 mm/min Rapid traverse in X/Y/Z: 30 m/min Setup operation in X/Y/Z: 20 - 2000 mm/min Travel X-axis: 635 mm Travel Y-axis: 510 mm travel distance Z-axis: 460 mm Displacement measuring system X/Y/Z: 1 μ Positioning uncertainty X/Y/Z: 6 μ Tool holder: SK 40 Table dimensions: 790 x 560 mm Spindle hours read with 5 grooves: approx. 5000 incl. 20-fold tool changer Attention: all tool holders located in the tool changer are included in the scope of delivery! Reference: Schönichen - Lot 47 Auction-ID: A7-46763-284

Manufacturer: FAMUP Year: 1994 Type: CNC vertical machining center Numerical control: FANUC Series O-M Strokes: X 600 mm / Y 400 mm / Z 400 mm Table: 400 × 400 mm – max. load 300 kg Spindle: ISO / SK 40 – 6,000 rpm – 11 kW Tool magazine: 18 positions – Max. tool Ø 75 mm – changeover time 2 s Chip conveyor: Yes Dimensions (mm): 3200 × 2900 × 2600 Weight (kg): approx. 3500 Notes: Italian-made CNC vertical machining center, suitable for general milling. Lots sold as is, unchecked, without tools or tool holders. Auction-ID: A1-46647-219

Serial number: CAI843289 Operating voltage: 3 x 400 V Frequency: 50 Hz Nominal current: 11.5 A Connection: 5.5 kW Container: 200 l Temperature: 3 - 40 °C Delivery quantity: 600 l/min Max. pressure: 10 bar Reference: Veatec - Lot 4 Auction-ID: A7-46763-254

Manufacturer: HEAD / KENT Model: CUV-10 (KMV 10) Year: 1999 Robust CNC vertical machining center, Meehanite cast iron construction, suitable for machining single parts and small to medium series. Numerical control: FANUC OMD Structure: Meehanite cast iron Turcite B-coated slides Rigid thread Portable electronic crank Full protective guard Sprinkler system Work light and end-of-cycle lamp Toolbox Races: X: 1,020 mm Y: 510 mm Z: 510 mm Distance between spindle nose and table: 105 to 740 mm Table: Dimensions: 1,200 × 600 mm T-slots: 18 mm – 3 grooves Max. permissible load: 1,000 kg Spindle: Speed: 30 – 7,500 rpm Transmission: ZF gearbox – 2 ranges Cone: BT 40 Engine power: 11 kW Feeds: Fast feed (X,Y,Z): 24 m/min Working feed: 1 – 10,000 mm/min Tool changer: Capacity: 20 tools Max. tool weight: 6 kg Bidirectional selection Machine dimensions: 2,880 × 2,420 × 2,980 mm Floor space  ...

Useful working area: X: 3200 mm Y: 1360 mm Z: 175 mm Configuration: 16-core drill head 14 kW electro-chuck – HSK 63 F C-axis – gear rotation Rotating tool magazine 8 front positions HSK 63 8-position tool magazine at carriage edge Fixed head with 1 blade holder outlet Ø 250 – HSK 63 F \"K\" head with 1 outlet -10° / 90° blade Ø 180 + milling cutter – HSK 63 F Fixed head with 2 milling cutter outlets – HSK 63 F Equipment: 14 kW frequency inverter Cooling unit for 19 kW unit Table with 2 suction cups per support 6-bar / 12-suction cup 2 suction cups 114 × 140 mm – h 100 mm per support 2 stops per bar 6-bar table pre-arranged for locking with vices (plus set) 2 horizontal pneumatic vices Vacuum pump 250 m³/h Chip belt Remote control (hold-start override) CNC on external PC (PC included) 17\" TFT displayPC and instructions in English Mastercabinet level 1 Power supply:  ...

Machine number: 711194 Operating voltage: 400 V Frequency: 50/60 Hz Connection: 40 kVA Control: FANUC SERIES 18-M Spindle speed: 45 to 4500 rpm Spindle holder: BT 50 Front bearing diameter: 100 mm Travel X-axis: 1100 mm Travel Y-axis: 600 mm Travel Z-axis: 630 mm Distance between spindle nose and table center: 218 - 848 mm Distance between spindle center and stand: 650 mm Table dimensions: 1200 x 600 mm Table load: max. 1200 kg Grooves: 5 Groove size: 18 mm Distance: 100 mm Rapid traverse X/Y/Z: 16/16/15 m/min Feed speed: 1 - 5000 mm/min Tool magazine: 24 places Max. tool dimensions: Diameter 125 x 350 mm Max. tool weight: 15 kg Tool holder: SK 50 incl. dividing head (4th and 5th axis) from the manufacturer NIKKEN, with a three-jaw chuck, Diameter: 250 mm Reference: Hercegfi - Lot 29 Auction-ID: A7-46763-211

Tool changer with 30 tool positions Auction-ID: A1-46781-9
