horizontal milling center used for sale

Key data: 1120 mm, 510 mm, 510 mm

For sale. Mazak vertical machining center type VTC-20B with Kitagwa integrated rotary axis. X-, Y- and Z-axis travels are 1,120 x 510 x 510 mm. Table size: 1410 x 510mm. Table capacity: 800Kg. Maximum speed is 6,000 rpm. SK-40 spindle holder. The number of tool positions is 24 pieces ATC, max. tool Ø / max. tool Ø 80 mm ditto for free places / max. tool Ø with free places besides 110 mm max. tool length 350 mm max. tool weight 8 kg Feed range xy / feed range xy 1-8000 mm/min. Vorschubbereich z / feed range z 1-8000 Mm/min. Rapid traverse X/Y / rapid feed X/Y 30 m/min. Drive power / drive capacity 15 kW Weight of the machine approx. / weight 6500 kg

Number of axes: 5 Feed speeds in the X/Y/Z axis: 500/420/380 mm Feed rates in the C/B axes: 180°/360° Dimensions of the work table (L x W): 500 x 380 mm Maximum workpiece weight: 350 kg Spindle power: 15 kW Maximum spindle speed: 18000 rpm Tool magazine capacity: 30 pcs. Overall dimensions (L x W x H): 3360 x 2550 x 2600 mm Total weight of the DMU 50 eVolution machine: 6000 kg

x-travel: 350 mm y-travel: 240 mm Ucblcnl2H9 z-travel: 340 mm Speed: 20 - 4,500 1/min Table: D 400 x 280 Control: 810 D Shop mill SIEMENS Tool holder: SK 40 Rapid traverse: 5 m/min Spindle: 6.3 / 10 kW Total connected load: 15 kVA Approx. space requirement: 1.7 x 1.55 x 2.1 m Universal CNC Milling Machine, Rotary swivel table manual with angle display on the screen, El. Handwheel

CNC machining center WILLEMIN 508MT TECHNICAL FEATURES: Year: 2016 NC Type: FANUC series 31i-B5 Number of continuous axes: 5 X-axis travel: 450 [mm] Y-axis travel: 200 [mm] Z-axis travel: 425 [mm] Fast travel speed X, Y and Z: 40000 [mm/min] Acceleration of axis displacement: 10 [m/s²] Maximum diameter in bar turning spindle: 42 [mm] Maximum speed Turning spindle: 6000 [rpm] Maximum power turning spindle: 7.5 [kW] A-axis angular travel: 360 [°] A-axis resolution: 0.001 [°] A-axis drive: Torque-motor A-axis spindle nose: A4 B-axis angular travel: -15 [°] / +100 [°] B-axis resolution: 0.001 [°] B-axis drive: Torque-motor Pin Attachment: HSK-E40 Maximum speed Spindle: 42000 [rpm] Number of tool magazine stations: 72 Maximum length Tool Size: 150 [mm] Maximum diameter Tool Size: 80 [mm] Tool Change Time: 1 [sec] Time between cuts: 3 [sec] Irrigation tray  ...

Auction-ID: A7-45992-212

Key data: 65 mm, 510 mm

12-8 position driven turrets - Y axis +/- 40 mm - with Lns Quick Load short barfeed - well tooled - fanuc 18i-TA Control

CNC processing center manufactured in 1997. This WEINIG / DIMTER Unicontrol 10 features a maximum workpiece length of 3,600 mm and a maximum workpiece height of 100 mm. It includes a powerful cross-cut saw with a spindle speed of up to 3,000 rpm and a tenoning spindle motor power of 15 kW. If you are looking to get high-quality CNC processing capabilities, consider the WEINIG / DIMTER Unicontrol 10 machine we have for sale. Contact us for further details.

Mazak VTC 200 B moving column machining center ::TECHNICAL SPECIFICATIONS::: CNC Model: Mazatrol - CNC Version: Fusion 640M - Tool Mount: ISO 40 - Spindle Power: 18.5Kw Number of spindle speeds: 12000 - Number of tools: 24 - X-axis travel: 1120mm - Y-axis travel: 510mm - Z-axis travel: 510mm Table dimensions: 1460 x 510mm Guides: roller CNC divider: yes Rotation: Continuous High refrigerant pressure: yes Chip conveyor: belt Presetting: yes :::D DIMENSIONS AND WEIGHT::: Length: 3312mm Width: 2850mm Height: 2651mm Weight: 6100Kg

Vertical machining center TC-32BN QT :::TECHNICAL SPECIFICATIONS::: CNC Model: Brother - CNC Version: B00 - Tool Holder: BT 30 - Spindle Power: 11Kw - Number of Spindle Revolutions: 12000 Number of tools: 26 - X-axis travel: 550mm - Y-axis travel: 400mm - Z-axis travel: 415mm - Rapid feeds for linear axes X Y Z: 70m/min Guides: roller CNC divider: yes Divider brand and model: No. 2 NIKKEN Rotation: Continuous Pallet change: yes Pallet size: 600 x 425mm Maximum allowable load: 200Kg Round pallet: yes High refrigerant pressure: yes Chip conveyor: belt Machine equipment: Renishaw probe ready :::D DIMENSIONS AND WEIGHT::: Length: 1890mm Width: 3669mm Height: 2360mm Weight: 4600Kg

Technical data and equipment: Travel X/Z - X2/Z2: 270/750 // 205/750 mm Travel Y: 100 (+-50) mm Max. rod diameter: 65 mm Main spindle drive: 0 - 5000 rpm Sub-spindle drive: 0 - 7000 rpm Tool holder: VDI 30 Control: Siemens Sinumerik 840 PL Revolver: 2 pcs. for applied Tools (12 slots each) Turret: Upper turret is equipped with Y-axis Spindle: 2 pcs main and counter spindle with C-axis Accessories for the machine: - Bar feeder Irco Profimat 70.6/270.6 - Internal cooling - Driven tools (straight and angled) - Chuck for main and counter spindle -Suction -Conveyor - Pick-up device with outfeed conveyor - KSS system Knoll SF 1000/Turbo-1 - Various holders approx. 80 pcs VDI 30 - Drill rod holder - Muzzle holder Machine space requirements: 3400 x 2600 x 2300 mm // 7600 kg

Key data: 2 mm, 810 mm, 700 mm

General Manufacturer: Spinner Type: MVC1600-B Year of Make: 2006 Switch-on hours: 30,240 h Control: Siemens 810D ShopMill Travels: X 1,600 mm Y 810 mm Z 700 mm Spindle Speed: 6,000 rpm Power: 25 kW Tool holder: SK50 Tool Changer Number of stations: 24-fold with double arm Condition Condition: Used Functional: Tested and fully functional Other equipment and accessories included: Conveyor Blow-out device for spindle High-pressure system IKZ 26 bar Preparation 4th axis Preparation of workpiece probes

Manufacturer: Hermle Model: C 800 U Year of Manufacture: 1997 Configuration: 5-axis with rotary table, C-axis and A-axis Control System: Heidenhain 426 Find more here - / Contact us at -

Manufacturer: Edel Model: CP 3020 Year of Manufacture: 2009 Configuration: 5-axis with C-axis and A-axis Control System: Heidenhain 530 Find more here - / Contact us at -

Manufacturer: POSMILL Model: E1100 Configuration: 3-axis CNC Control System: Heidenhain 530 Year of Manufacture: 2010 Find more here - / Contact us at -

Manufacturer: POSMILL Model: POSMill E1100 Configuration: 3-axis CNC Control System: Heidenhain 530 Year of Manufacture: 2012 Find more here - / Contact us at -

Manufacturer: POSMILL Model: POSMill E2050 Configuration: 3-axis CNC Control System: Heidenhain 530 Year of Manufacture: 2011 Find more here - / Contact us at -

Manufacturer: Deckel Maho Model: DMU 60 E Configuration: 3-axis CNC Control System: Mill Plus Year of Manufacture: 1999 Find more here - / Contact us at -

Auction-ID: A1-45845-86

Auction-ID: A1-45845-61

DAEWOO PUMA 300 LB (Doosan), 2-axis CNC lathe, CNC Fanuc 18T, Hydraulic tailstock, Condition: very good. This machine can be inspected in our warehouse, under power., Mimu machine tools Italy

Auction-ID: A1-45845-57

CNC Lathe - twin turret - subspindle Y axis NAKAMURA WT 250 CNC Fanuc, Series 16i-T, Spindle - sub spindle 1 turret live tools + Y axis 1 turret live tools (lower), 2x C-Axis, Swarf conveyor, IEMCA TS560P Bar loader Under power in our in our warehouse in Gussago BS. Mimu machine tools Italy

Auction-ID: A1-45845-85

Inv. Num. : 8135 Type: MCV 750 A speed Producer: MAS Created: 2020 Parameters: Control system: Heidenhain 640 Number of axes: 4 pieces Minimum vertical spindle speed: 12000 1/min X-axis travel: 750 mm Y-axis travel: 500 mm Travel Z axis: 500 mm Number of all tools: 24 pieces Rapid traverse X/Y/Z: 40000/40000/40000 mm/min Total power: 50 kW Machine height: 2500 mm Machine length: 3400 mm Machine width: 3110 mm Machine weight: 5250 kg Equipment: Chuck TOS UIS 200/4-1-M2; TOS UIS 250/4-2-M1

Auction-ID: A1-45845-60

x-travel: 700 mm y-travel: 600 mm z-travel: 600 mm table surface area: 630 mm : 360 Grad angle of table min./max.: 45/20 Grad turning speeds: 6300 U/min control: Pfilips type: CNC 432 Tool changer: spindle taper ISO: 40 chip conveyor: total power requirement: 27 KVA weight of the machine ca.: 5,8 t dimensions of the machine ca.: 4,1x2,3x2,4 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

control: Siemens Sinumerik 840D table load: 0,7 t work piece spindle speed: 200 - 2300 U/min total power requirement: 12 kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Manufacturer: TRIMILL Model: VC 2314 Configuration: 3-axis CNC Control System: Heidenhain TNC 640 Year of Manufacture: 2024 Find more here - / Contact us at -

Sheet metal centering pull-down unit GENUSTECH PM4I2V395MEMB50C-287 flange diameter: Ø 56 / 72 mm Sensor unit: SENSTRONIC A1202R6K700111 10 - 55 V DC approx. 0.2 m Connection cable New ! Dimensions: 210 x 80 x 90 mm

Auction-ID: A1-45502-148

turning diameter:1390 mm turning length:14000 mm weight of the machine ca.:13 t More information can be found in the Appendix.

Centering vise PAGUS jaw height: 50 mm span: 0...95 mm on table with graduation 360° rotatable Dimensions: 330 x 255 x 160 mm

Centering disc, tube clamp PAGUS Ø 300 - 340 mm used, tested ! Dimensions: 340 x 340 x 50 mm

Spindle with centering tip, clamping device PAGUS clamping range: 145 mm base plate 215 x 100 mm shaft diameter: Ø 40 mm Handwheel diameter: Ø 250 mm Dimensions: 600 x 250 x 250 mm

x-travel:800 mm y-travel:460 mm z-travel:510 mm total power requirement:20 kW weight of the machine ca.:8 t Vertical Processing Centre 20kW is the nominal value. The spindle only needs 7.5kW. It looks like 15kW will be enough.

x-travel:560 mm y-travel:450 mm z-travel:450 mm table surface area:760 x 410 mm turning speed range:8.000 U/min total power requirement:20 kW Vertical Processing Centre
