horizontal machining centres used for sale

Travel X-axis 19,000 mm Y-axis 3,500 mm Z-axis 1,000 mm W-axis 1,000 mm V-axis 2,500 mm B-axis 360°/ 0.001 Table size 4,000 x 3,500 mm Maximum permissible weight on the table 65 t Spindle diameter 160 mm Mounting cone in spindle 2079 DIN/ ISO 50 Spindle speed 2.5 - 1,000 rpm Spindle motor power 90 kW RAM cross section 400 x 400 mm Automatic tool changer 60 positions Feed in all axes 1 - 6,000 mm/min Rapid response in all axes 10,000 mm/min Automatic indexing 360,000° Plate field 12,750 x 6,000 mm CNC, electrical and mechanical overhaul by Siemens in 2003

Travel X-axis 9,500 mm Y-axis 4,100 mm Z-axis 950 mm W-axis 900 mm Main spindle speeds (infinitely adjustable): 3.15 - 1000 rpm Spindle motor power 58 kW Feed speed (infinitely adjustable): X-axis 0.1 - 9600 mm/min Y-axis 0.1 - 5600 mm/min Z-axis 0.1 - 5600 mm/min W-axis 0.1 - 5600 mm/min Accessories: Plate field: 6 x 4 m (CNC-controlled B- and V-axis) Table: 2 x 2 m (CNC-controlled B- and V-axis)

YEAR: 08/2004 LONGITUDINAL CORSA: X 800 MM TRANSVERSE COURSE: Y 700 MM VERTICAL COURSE: Z 700 MM ASSE B INDEXED 1st PALLET (2) 500X500 MM CNC MAPPS MSG-501 TOOL WAREHOUSES 60 LOCATIONS ATTACK MANDRINO BT40 MANDRINO MASSIMA VELOCITY 12000 RPM POWER OF MANDRINO'S POWER 26 KW

MANDRINO NASO: ASA A2-8 BAR PASS: 90 MM ROUND NUMBER: RPM 2500 COURSE AXIS X: 300 MM COURSE ASSE Z: 1250 MM TURNING DIAMETER: 500 MM TURNING LENGTH: 1200 MM IDRAULIC AUTOCENTRANTE TOOL COUNT: 12 CONTROL: FANUC Oi-TD YEAR: 2010

Capacity, ton 800 Movable die stroke, mm 180 Max. upsetting ram stroke, mm 380 Upsetting ram workstore, mm 250 Upsetting ram return stroke with closed dies, mm 130 Distance bentween upsetting ram and dies stroke forward, mm 140 Number of ram strokes per minute 35 Die dimensions, mm 590 x 220 x 660 Electric motor power, kW 40 Dimensions: mm 6300 x 3900 x 2850 Weight: kg app. 80800

pressure:6 t stroke:1020 mm total power requirement:3,5 kW Can only adjust between tips

Max. diameter of initial blank: 30 mm Blank length: -Min.: 120 mm -Max.: 300 mm Max. diameter of upset flange: 60 mm Upset slide nominal force: 2500 kN Max. force on clamping slide with dies closed: 2500 kN Stroke: -Movable die: 100 mm -Upset slide (full): 220 mm -Die closing: 140 mm Slide strokes per minute: 45 Machine overall dimensions: -Length: 6050 mm -Width: 4600 mm -Height: 2260 mm Machine weight: 24680 kg

- The largest diameter of the workpiece, mm 90 - The maximum diameter of the planted flange, mm 120 - Rated force of the landing slide, kN 6300 - The force perceived by the clamping slide with closed dies, kN 6300 - stroke of the landing slider, mm 350 - The stroke of the landing slide after closing the dies, mm 230 - The frequency of continuous idle slider per minute, not less than 42 - Power of the electric motor 45 - Dimensions, mm length 4835 width 3450 height 2880

CNC CONTROL: MSD 501 II, FANUC FEATURES: DIAMETER ADMITTED ON THE BED, MM 680 MAXIMUM TURNING DIAMETER 440 MM N1 MAXIMUM TREATMENT DIAMETER N2 322 MM MAXIMUM TURNING LENGTH, MM 471 THE STANDARD MACHINING DIAMETER MM170 MAIN SPINDLE: STEP PANEL 45 MM COUNTER SPINDLE: HOLE PITCH LINE 43 MM TURRET 1: POSITION N12 ALL MOTORIZED TOWER 2: POSITION N12 ALL MOTORIZED

control:siemens 1P 6SL 3054--0CE01-1AA0 Documents:vorhanden

with vertical matrix connector Max. work-piece diameter: 140 mm Max. diameter of upset flange: 180 mm Nominal force of upset slide: 12500 kN Force on clamping slide with dies closed: 12500 kN Stroke of: -Upset slide: 460 mm -Upset slide after closing of dies: 310 mm Number of continuous slide strokes per minute: at least 32 Electric motor power: 75 kW Machine dimensions: -Length: 8035 mm -Width: 4800 mm -Height: 3575 mm Machine weight: 140 tons

Table length: 10.800 mm Table width: 1.000 mm Table height: 200 mm Load capacity: 10 t/m Power motor spindle: 22 Kw Max. speed of turning: 1.700 rpm X Axis travel: 7.000 mm Vertical axis travel: 2.000 mm RAM travel: 1.000 mm Total installed power: 60 Kw Rapid feed rate: 15 mt/min CNC ECS 4801 Chip conveyor

Capacity ø 6-42mm. including bending jigs

Spacing : 2000 mm Permissible diameter on bench : 720 mm Diameter on straggler : 430 mm X stroke : 410 mm Z stroke : 2000 mm Spindle speed : 1 – 1800 rpm Spindle bore : 106 mm Spindle nose : DIN 55027 size 11 Installed power : 28 kW Power supply : 400 V Lots sold as is, unchecked, without tools or tool holders.

This 3-axis SPINNER TC800L 110 was manufactured in 2023. The machine is fully functional and includes a steady rest, tailstock, chip conveyor, and oil mist extraction system. It operates on a 3-phase power supply at 400 V. If you are looking to get high-quality turning capabilities, consider the SPINNER TC800L 110 horizontal turning machine we have for sale. Contact us for further details.

This 7-axis Index G300 L YB was manufactured in 1999. It features a maximum turning diameter of 270 mm and a maximum swing diameter of 590 mm. The machine includes a robust tool system with 12 stations and a milling spindle speed of up to 6000 rpm. If you are looking to get high-quality turning capabilities, consider the Index G300 L YB horizontal turning machine we have for sale. Contact us for further details.

This 3-axis MORI SEIKI SL-403BMC/800 was manufactured in 2002. It features a maximum turning diameter of 650 mm and a maximum turning length of 863 mm. The machine offers an X-axis travel of 345 mm and a Z-axis travel of 995 mm. If you are looking to get high-quality turning capabilities, consider the MORI SEIKI SL-403BMC/800 horizontal turning machine we have for sale. Contact us for further details.

This 3-axis DMG MORI CLX450 was manufactured in 2019. It features a 12-station tool turret and an integrated sub-spindle for enhanced productivity. The machine is equipped with a 3-jaw chuck on the main spindle. If you are looking to get high-quality turning capabilities, consider the DMG MORI CLX450 horizontal turning machine we have for sale. Contact us for further details.

Technical data: - Cutting range at 90° around 260 mm - flat 450 x 240 mm - Cutting range at 45° around 230 mm - flat 240 x 200 mm - Machine is mounted on original turnstile - Saw band dimension 3660 x 25 x 0.9 mm - Cutting speeds 20 / 35 / 50 / 70 m/min - Hydr. lifting + lowering the saw frame - Cutting pressure infinitely adjustable 0 - 10 m/min - Total drive power 400 V / 0.8 kW - Coolant device - Space requirement approx. W 2100 x H 1200 x D 1000 mm - Weight approx. 500 kg

This 10-axis Index C100 horizontal turning machine was manufactured in 2018. It features impressive axis travels of 70 mm in both X and Y directions, and 400 mm in Z. The machine includes three turrets with driven tools capable of 8000 rpm, and a counter spindle diameter of 42 mm. If you are looking to get high-quality turning capabilities, consider the Index C100 machine we have for sale. Contact us for further details.

This 3-axis SMEC SL2000M (B TYPE) was manufactured in 2023. It features a maximum turning diameter over bed of 510 mm and a turning length of 540 mm. The machine is equipped with a hydraulic 3-jaw chuck and a spindle speed of up to 4,500 rpm. If you are looking to get high-quality turning capabilities, consider the SMEC SL2000M (B TYPE) horizontal turning machine we have for sale. Contact us for further details.

Horizontal turning machine manufactured in 2018. This Mazak QUICK TURN 200MA L features a maximum workpiece diameter of Ø 360 mm and a maximum workpiece length of 535 mm. It is equipped with a spindle speed of 5,000 rpm and a turret with 12 VDI positions. If you are looking to get high-quality turning capabilities, consider the Mazak QUICK TURN 200MA L machine we have for sale. Contact us for further details.

Automatic horizontal packaging machines Model:NT-250 Voltage:AC 220/50 Film width:Max.250mm Power:2.4KW Bag length:65~190mm or 120~280mm Bag width:30~110mm Product height:Max.40mm Film diameter:Max.320mm Pack speed:60~120bags/min Machine size:37706701450mm Weight:480kg

Code 0776 Description Surface grinding machine Make ELB Type SWBD 030 MCNC82 Machine No. 18.346.0383 Manufacturing date 1983 Control MCNC / 82-PC Tablesize 3520 x 600 mm Table grinding size L x B x H 3000 x 600 x 600 mm Magnetical plate size L x B 3000 x 400 mm Speed table movement 0,2 – 6 m/min. Max. distance table – centre grinding wheel 850 mm Speeds vertical 3 – 375 mm/min. Speeds cross 1,2 m/min. Speeds grindingwheel stepless 750 – 1400 omw/min Grindingstone: Ø 600 x Wide:100 x Bore: 200 mm Weight 18.000 kg Motor power 37 kW – 380 Volt Accessoiries Electro table 3000 x 400 mm Grinding unit with water cooling Filtering unit with paperfilter Profile grinding unit Condition Machine is in very good condition

Packaging machine BVM Compacta Trend; good condition; is cleaned and checked before delivery; Welding0 width 500mm; Passage height 220mm; treadmill finger conveyor belt 1600mm; SC 4530 shrink tunnel with plastic link belt; Discharge belt 1000mm. Side sealing machine BVM Compacta Trend; good condition; will be cleaned and checked before shipping; sealing width 500mm; hight 220mm; infeed conveyor with fingers 160mm; shrink tunnel SC 4530 with plastic belt; outfeed conveyor 1000mm.

This SCHÜBEL MT 630 CNC was manufactured in 1999. It is a horizontal turning machine featuring a point width of 2,000 mm, a circulation diameter of 630 mm over the bed, and 290 mm over the cross slide. The speed range is 8 - 3,000 rpm with a drive power of 28 kW. Contact us for more information about this machine.

This 4-axis DMG MORI CLX 450 V4 was manufactured in 2021. It features a maximum turning diameter of 400 mm and a turning length of 800 mm. The machine is equipped with a Siemens Sinumerik 840D control and includes a turret with 12 stations, all with driven tools and a Y-axis. If you are looking for high-quality turning capabilities, consider the DMG MORI CLX 450 V4 CNC turning center we have for sale. Contact us for further details.

Horizontal turning machine manufactured in 2022. This Optimum OptiTurn TH 8030D features a maximum swing diameter of 800 mm and a turning length of 250 mm. It includes a robust spindle chuck and a rapid motion speed of 3800 mm/min. If you are looking to get high-quality turning capabilities, consider the Optimum OptiTurn TH 8030D machine we have for sale. Contact us for further details regarding this machine.

GER RS-12/50 surface grinding machine. Grinding area: 1200x550mm. Distance table-centre of spindle: 625mm. Table speed: 2 to 25m/min. Maximum table travel: 1250mm. Maximum work weight: 1200Kgs. Maximum cross travel: 500mm. Grinding wheel size: 400x80x127mm. Manual diamond grinder. Vertical orientable headstock. Vertical automatic feed. Power of grinding spindle: 12,5cv. Weight: 4500Kgs.

Horizontal turning machine manufactured in 2018. This DOOSAN Lynx 2100A features a maximum turning diameter of 350 mm and a turning length of 330 mm. It is equipped with a spindle speed of 5,000 rpm and a chuck size of 8” (210 mm). If you are looking to get high-quality turning capabilities, consider the DOOSAN Lynx 2100A machine we have for sale. Contact us for further details regarding this machine.

This 4-axis DMG CTX410 was manufactured in 2008. It features a maximum turning length of 600 mm and a turning diameter of 320 mm. The machine is equipped with a powerful spindle capable of reaching speeds up to 5,000 rpm and includes a turret with 12 positions for enhanced productivity. If you are looking to get high-quality turning capabilities, consider the DMG CTX410 horizontal turning machine we have for sale. Contact us for further details.

This 8-axis Citizen BNE-51MSY was manufactured in 2018. It features a maximum bar diameter of Ø 51 mm and a spindle speed of 5,000 min-1. The machine includes 12 turret stations and a slide stroke of 195 mm in the X1 direction. If you are looking to get high-quality turning capabilities, consider the Citizen BNE-51MSY horizontal turning machine we have for sale. Contact us for further details.

cutting diameter: 320 mm saw band length: 3660x27x0,9 mm cutting width: 400 mm cutting capacity - flat: 400 x 220 / 90° mm cutting capacity - round: 320 /90° mm speed: 20 - 100 m/min cutting capacity - flat: 280 x 200 / 45° mm cutting capacity - round: 280 / 45° mm sawing motor: 1,5 kW hydraulic motor: 0,37 kW coolant pump: 0,12 kW total power requirement: 2 kW weight of the machine ca.: 670 kg dimensions of the machine ca.: 1800 x 850 x 1200 mm Accessories: • Inverter • hydraulical vice • automatical movement to the top via hydraulical cylinder. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

This 3-axis Okuma LB15i-M was manufactured in 1997. It features a spindle speed of up to 6000 rpm and a spindle power of approximately 15 kW. The machine includes 5 motorized front tools and 2 radial tools, providing versatile machining capabilities. If you are looking to get high-quality turning capabilities, consider the Okuma LB15i-M horizontal turning machine we have for sale. Contact us for further details.

This Pinacho STH 400-105×3000 was manufactured in 2017. A robust horizontal turning machine with a swing over bed of 400 mm and a distance between centers of 3000 mm. Features a high-torque spindle and CNC-controlled feed for precise heavy-duty turning. Ideal for machining shafts, pipes, and flanges. Consider the opportunity to buy this Pinacho STH 400-105×3000 horizontal turning machine. Contact us for more information.

: 200 kN stroke length max.: 200 mm working feed: 10 mm/sec return speed: 20 mm/sec : 480x1060 mm work height max.: 900 mm toolpiece height max.: 200 mm total power requirement: 2,2 kW : 200x12 mm bending capacity max. - round: 48x4,0 mm weight: 500 kg Overall size: 1010x480x1120 mm Domestic equipments: - with semi-automatic control (99 programs with 16 steps each) - including bending bolt (without punch) - Tool holder for dies - Foot pedal Equipment: - Stamp, small U = 145 mm 85 °, H = 200 mm, R = 5 mm - Quick change monometer 85 °, H = 200 mm, V = 63 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

This 4-axis NAKAMURA-TOME AS-200L was manufactured in 2017. It features a maximum turning diameter of 320 mm and a turning length of 570 mm. The machine includes a 12-station turret and a main spindle speed of up to 4500 rpm. If you are looking to get high-quality turning capabilities, consider the NAKAMURA-TOME AS-200L horizontal turning machine we have for sale. Contact us for further details.

Horizontal turning machine manufactured in 2021. This DOOSAN Lynx 2100A features a maximum turning diameter of 350 mm and a turning length of 330 mm. It is equipped with a spindle speed of 6,000 rpm and a chuck size of 6” (160 mm). If you are looking to get high-quality turning capabilities, consider the DOOSAN Lynx 2100A machine we have for sale. Contact us for further details.

groove width: 16 mm x-travel: 16-200 mm table length: 1500 mm table width: 375 mm milling spindle: ISO 40 max. clampable toolpiece shaft diameter: 30 mm max. useable hobs, normal diameter: 40 mm distance between milling spindle and table: 150-250 mm axial move. of milling spindle (auto./manual): 120 mm vertical adjust. of milling slide (manual): 100 mm weight of the machine ca.: 3,1 t dimensions of the machine ca.: 2,00x1,40x2,40 m K4 - TECHDETAIL UK: 0,11 kW K4 - TECHDETAIL UK: 0,6/1,1 kW K4 - TECHDETAIL UK: 3 x 0,012-0,05 mm/U K4 - TECHDETAIL UK: 16x60 mm K4 - TECHDETAIL UK: 12 x 280 - 3550 U/min K4 - TECHDETAIL UK: 0,85 kW K4 - TECHDETAIL UK: 0-2,0 mm K4 - TECHDETAIL UK: 250 mm Condition: ready for production The machine is suitable for the manufacture of flutes and slots using undersize cutters with hydraulic adjustment. Roughing and finishing can be done in one single clamping.  ...

This 3-axis YCM GT-300LMB was manufactured in 2010. It features a maximum spindle speed of 3000 rpm and a chuck size of 12 inches. The machine offers an X-axis travel of 275 mm and a Z-axis travel of 1283 mm, making it suitable for various turning applications. If you are looking to get high-quality turning capabilities, consider the YCM GT-300LMB horizontal turning machine we have for sale. Contact us for further details.

This 4-axis SPINNER TC800 was manufactured in 2009. It features a radial turret and is equipped with Siemens control, ensuring reliable operation. With approximately 1,000 operating hours, this machine has been barely used. If you are looking to get high-quality turning capabilities, consider the SPINNER TC800 horizontal turning machine we have for sale. Contact us for further details.

This 3-axis Biglia B301 SM was manufactured in 2006. It features a robust Hainbuch collet chuck for both the main and counter spindle, ensuring precision in your turning operations. The machine has a weight of 3760 kg and operates at a spindle speed of 504 RPM. If you are looking to get high-quality turning capabilities, consider the Biglia B301 SM horizontal turning machine we have for sale. Contact us for further details.

This 3-axis SPINNER MT 500/1000 AT was manufactured in 2000. It features an X-axis travel of 210 mm, and Z-axis travel of 930 mm. The machine includes a robust table size of 520 x 900 mm with a load capacity of 400 kg. If you are looking to get high-quality machining capabilities, consider the SPINNER MT 500/1000 AT machine we have for sale. Contact us for further details.

This 5-axis Index C200 was manufactured in 2023, offering advanced capabilities for horizontal turning. Ideal for precision and efficiency in metalworking, this machine represents a significant asset for enhancing production quality. Consider the opportunity to buy this Index C200 horizontal turning machine. Contact us for more information.

This DMG MORI CLX 350 V3 was manufactured in 2023. A universal turning machine featuring driven tools and a C-axis. It includes a hydraulic 3-jaw chuck D210mm, a 12-slot servo tool turret holder VDI 30 with 12 driven tool stations, and a hollow clamping device with a max. bar capacity of D65mm. A great opportunity to buy this DMG MORI CLX 350 V3 universal turning machine. Contact us for further details regarding this machine.

cutting diameter: 325 mm saw band length: 4380x34x1,1 mm cutting width: 450 mm cutting capacity - flat: 450 x 325 / 90° mm cutting capacity - round: 325 /90° mm speed: 20 - 100 m/min sawing motor: 2,2 kW total power requirement: 3 kW weight of the machine ca.: 1010 kg dimensions of the machine ca.: 2100 x 860 x 1500 mm Accessories: • Inverter • hydraulical vice • automatical movement to the top via hydraulical cylinder. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

cutting diameter: 360 mm saw band length: 5200 x 34 x 1,1 mm cutting width: 700 mm cutting capacity - flat: 590 x 360 /30° mm cutting capacity - round: 360 / 30° mm cutting capacity - square: 360 x 360 / 30° mm cutting capacity - flat: 460 x 360 /45° mm cutting capacity - round: 360 /45° mm cutting capacity - square: 360 x 360 / 45° mm cutting capacity - flat: 305 x 360 /60° mm cutting capacity - round: 360 / 60° mm cutting capacity - square: 305 x 360 / 60° mm cutting capacity - flat: 700 x 360 / 90° mm cutting capacity - round: 360 / 90° mm cutting capacity - square: 360 x 360 / 90° mm speed: 20 - 100 m/min sawing motor: 3 kW hydraulic motor: 0,55 kW coolant pump: 0,12 kW voltage: 400 V / 50 Hz total power requirement: 3,7 kW weight of the machine ca.: 1460 kg dimensions of the machine ca.: 2850 x 1000 x 1850 mm Accessories: • Inverter • hydraulical vice • automatical ...

cutting diameter: 460 mm saw band length: 5200 x 41 x 1,3 mm cutting width: 460 mm cutting capacity - flat: 470 x 460 / 90° mm cutting capacity - round: 460 / 90° mm speed: 20 - 100 m/min voltage: 400 V / 50 Hz sawing motor: 4 kW total power requirement: 4,7 kW weight of the machine ca.: 1,665 t dimensions of the machine ca.: 2100 x 1300 x 850 m full-automatical band saw, Accessories: • Inverter for controllable speed, • automatical stop function after sawing and on breakage of the saw blade, • automatical saw arm lifting, • hydro-mechanical clamping of the saw blade, • material clamping to be effected from above, hydraulical vice, • switch for cutting pressure control, • coolant pump, • roller conveyor, length: 1.2 m. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
