horizontal machining centers used for sale

Key data: 750 mm, 750 mm, 725 mm

GENERAL Project No.: 905674 Quantity: 1 pcs. Manufacturer: HECKERT (STARRAG) Type: HEC 500 D Control: Siemens 840 D solutionline Year of Make: 2011 Condition: Used machine Layers approx.: 2-3 layers DESCRIPTION MILL Travel in X 750 mm Travel in Y 750 mm Travel in Z 725 mm Max. rapid traverse speed in X/Y/Z 100/100/100 m/min Max. acceleration in X/Y/Z 11/14/11 m/s2 Tool holder HSK 63 Max. speed milling spindle 15000 1/min Max. power at ED 10-40/100% 31/– kW Max. torque at ED 10-40/100% 200/– Nm Spindle diameter in the front bearing 75 mm 1 pc. horizontally arranged milling spindle/s Torque support for multi-spindle drill heads Tool magazine 60 stations Max. tool diameter 160 mm Max. tool length 400 mm Max. tool weight 10 kg Chip to chip time 2.7 s Rotary pallet changer 2-fold Pallet size 500×630 mm Max. workpiece weight per pallet 600 kg Rotary  ...

Number of axes: 5 Feed speeds in the X/Y/Z axis: 500/420/380 mm Feed rates in the C/B axes: 180°/360° Dimensions of the work table (L x W): 500 x 380 mm Maximum workpiece weight: 350 kg Spindle power: 15 kW Maximum spindle speed: 18000 rpm Tool magazine capacity: 30 pcs. Overall dimensions (L x W x H): 3360 x 2550 x 2600 mm Total weight of the DMU 50 eVolution machine: 6000 kg

x-travel: 350 mm y-travel: 240 mm Ucblcnl2H9 z-travel: 340 mm Speed: 20 - 4,500 1/min Table: D 400 x 280 Control: 810 D Shop mill SIEMENS Tool holder: SK 40 Rapid traverse: 5 m/min Spindle: 6.3 / 10 kW Total connected load: 15 kVA Approx. space requirement: 1.7 x 1.55 x 2.1 m Universal CNC Milling Machine, Rotary swivel table manual with angle display on the screen, El. Handwheel

Key data: 1120 mm, 510 mm, 510 mm

For sale. Mazak vertical machining center type VTC-20B with Kitagwa integrated rotary axis. X-, Y- and Z-axis travels are 1,120 x 510 x 510 mm. Table size: 1410 x 510mm. Table capacity: 800Kg. Maximum speed is 6,000 rpm. SK-40 spindle holder. The number of tool positions is 24 pieces ATC, max. tool Ø / max. tool Ø 80 mm ditto for free places / max. tool Ø with free places besides 110 mm max. tool length 350 mm max. tool weight 8 kg Feed range xy / feed range xy 1-8000 mm/min. Vorschubbereich z / feed range z 1-8000 Mm/min. Rapid traverse X/Y / rapid feed X/Y 30 m/min. Drive power / drive capacity 15 kW Weight of the machine approx. / weight 6500 kg

Key data: 65 mm, 510 mm

12-8 position driven turrets - Y axis +/- 40 mm - with Lns Quick Load short barfeed - well tooled - fanuc 18i-TA Control

Technical data and equipment: Travel X/Z - X2/Z2: 270/750 // 205/750 mm Travel Y: 100 (+-50) mm Max. rod diameter: 65 mm Main spindle drive: 0 - 5000 rpm Sub-spindle drive: 0 - 7000 rpm Tool holder: VDI 30 Control: Siemens Sinumerik 840 PL Revolver: 2 pcs. for applied Tools (12 slots each) Turret: Upper turret is equipped with Y-axis Spindle: 2 pcs main and counter spindle with C-axis Accessories for the machine: - Bar feeder Irco Profimat 70.6/270.6 - Internal cooling - Driven tools (straight and angled) - Chuck for main and counter spindle -Suction -Conveyor - Pick-up device with outfeed conveyor - KSS system Knoll SF 1000/Turbo-1 - Various holders approx. 80 pcs VDI 30 - Drill rod holder - Muzzle holder Machine space requirements: 3400 x 2600 x 2300 mm // 7600 kg

DMG MORI CMX 1100 V CNC machining center was built in 2019 in Japan by DMG MORI CO.,LTD. The machine, designed for machining workpieces with a maximum weight of 1000 kg, is distinguished by the use of state-of-the-art components and technical solutions which guarantee excellent machining results for many years of continuous operation. The machining process is performed inside a fully illuminated workspace by means of reliable components in the form of cutting tools and a high-speed spindle. The ‘C’ shaped cast iron bed perfectly dampens any vibrations and oscillations generated during machining, while ensuring the highest possible process stability. The CMX 1100 V CNC vertical machining center on offer also has a wide range of optional equipment, consisting of, among others, measuring probes from the renowned RENISHAW brand, a divider and the advanced MAPPS FANUC CNC control. Over ...

Key data: 2 mm, 810 mm, 700 mm

General Manufacturer: Spinner Type: MVC1600-B Year of Make: 2006 Switch-on hours: 30,240 h Control: Siemens 810D ShopMill Travels: X 1,600 mm Y 810 mm Z 700 mm Spindle Speed: 6,000 rpm Power: 25 kW Tool holder: SK50 Tool Changer Number of stations: 24-fold with double arm Condition Condition: Used Functional: Tested and fully functional Other equipment and accessories included: Conveyor Blow-out device for spindle High-pressure system IKZ 26 bar Preparation 4th axis Preparation of workpiece probes

DAEWOO PUMA 300 LB (Doosan), 2-axis CNC lathe, CNC Fanuc 18T, Hydraulic tailstock, Condition: very good. This machine can be inspected in our warehouse, under power., Mimu machine tools Italy

CNC Lathe - twin turret - subspindle Y axis NAKAMURA WT 250 CNC Fanuc, Series 16i-T, Spindle - sub spindle 1 turret live tools + Y axis 1 turret live tools (lower), 2x C-Axis, Swarf conveyor, IEMCA TS560P Bar loader Under power in our in our warehouse in Gussago BS. Mimu machine tools Italy

Inv. Num. : 8135 Type: MCV 750 A speed Producer: MAS Created: 2020 Parameters: Control system: Heidenhain 640 Number of axes: 4 pieces Minimum vertical spindle speed: 12000 1/min X-axis travel: 750 mm Y-axis travel: 500 mm Travel Z axis: 500 mm Number of all tools: 24 pieces Rapid traverse X/Y/Z: 40000/40000/40000 mm/min Total power: 50 kW Machine height: 2500 mm Machine length: 3400 mm Machine width: 3110 mm Machine weight: 5250 kg Equipment: Chuck TOS UIS 200/4-1-M2; TOS UIS 250/4-2-M1

Bridge type Machining Centre NICOLAS CORREA EURO 2000 - 18.000 rpm - capacity 2000x1250x650 mm, CNC SELCA 4045, Information about technical data are not binding., Machine available subject to prior sale., Working table size: 2300x1000 mm, Longitudinal travel x axis: 2000 mm, Cross travel y axis: 1250 mm, Vertical travel z axis: 650 mm, Measurement system: HEIDENHAIN optical scales, Working feed x-y-z axes: 0 - 30.000 mm/1, Rapid feed x-y-z axes: 30.000 mm/1, Spindle taper type: HSK 63, Automatic tools change nr.: 40, Spindle speed: 0- 18.000 rpm, Spindle motor power: 20 Kw, Cnc: SELCA 4045, Approx net weight: 20.000 Kg, Accessories: through-spindle coolant, chip conveyor

Siemens Sinumerik 828D control system with ShopMill Travel X/Y/Z: 1020 x 635 x 610 mm Spindle speed: 10,000 min-1 Tool magazine for 24 Wkz. SK 40 IKZ Conveyor Measuring Sensors

bar material dia.: 75 mm max. max. swing dia.: 540 mm turning length: 650 mm control: FANUC Oi-TB machine weight ab.: 6.200 kg CNC Turning- and Milling Center | JOHNFORD - SL-50-CF-Y equipped with chip conveyor. Additional equipment: + C axis + Y axis + driven tools The machine is in good condition. - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - #Tags: SL 50 | SL50 | SL-50 CF Y | SL50 CF Y The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

turning diameter: max. 420 mm turning length: 1250 mm control: INDEX, C 200-4 D swing diameter: 630 mm travel x1: 320 mm travel z1: 1250 mm travel x2: 170 mm travel z2: 1250 mm travel x3: 320 mm travel z3: 1250 mm main spindle speed: max. 3000 U/min main spindle drive: 53 kW spindle passage: 102 mm spindle head: DIN 55026 Gr. 11 max. torque on the spindle: 675 Nm sub spindle - spindle speed range: max. 3000 U/min sub spindle drive: 53 kW sub spindle - spindle passage: 102 sub spindle - spindle head: DIN 55026 Gr. 11 sub spindle - spindle torque: 675 Nm travel sub spindle: 1250 mm feed power: X1 14000/Z1 14000 N rapid traverse: X1 20/Z1 40 m/min feed power: X2 8600/Z2 14000 N rapid traverse: X2 20/Z2 40 m/min feed power: X3 14000/Z3 14000 N rapid traverse: X3 20/Z3 40 m/min numbers of turret head positions: Rev. 1 = 12 numbers of turret head positions: Rev. 2 = 10 numbers of turret head p ...

x-travel: 1500 mm y-travel: 800 mm z-travel: 700 mm table surface area: 1760 x 700 mm spindle taper: SK 40 spindle turning speed - stepless: 8000 U/min spindle drive: 15 kW feeds: 1 - 8000 mm/min rapid traverse X/Y/Z axis: 15 / 15 / 12 m/min table load: max. 2500 kg spindle throat: 760 mm ATC: 40 Pos control: HEIDENHAIN, TNC 530 total power requirement: kW weight of the machine ca.: 12,5 t dimensions of machine L x W x H: 4,23 x 2,98 x 2,74 m - with coolant through spindle Accessories: NC-dividing unit (=4th Axis) with tailstock, center height 250 mm, 2 hydr. vices make HILMA, model NC 160, width of jaws 160 mm, various tool holders, chip conveyor, coolant - geometrical overhauled in 2022 - - new ball bearing spindle installed on Y-axis in NOV. 2022 - - the magnetic plates shown on the photo are not included - The data for this ad was created with ModulMWS - the software so ...

Sell our old vertical milling machining center as a spare parts dispenser, unfortunately I can not say what the machine has exactly, I only know that the control unit is defective

Inv. Num. : 8246 Type: XR 1000 Producer: Hardinge Generated: Parameters: Control system: iTNC530 Work table length: 1200 mm Work table width: 600 mm Speed: 12000 1/min X-axis travel: 1020 mm Y-axis travel: 610 mm Travel travel Z-axis: 610 mm Machine weight: 7000 kg

Manufacturer JOHNFORD Model SV-41 + APC – pallet changer Year of manufacture 2007 CNC FANUC 18i MC.2 Table dimensions 1,200 x 600 mm Maximum weight allowed on table 1,200 kg Travel (X / Y / Z) 1,050 / 610 / 610 mm Distance from nose spindle to table 100-700 mm. Distance from spindle center to column 640 mm. Fast feed (X,Y axes) 30,000 mm./min. Fast forward (Z-axis) 20,000 mm./min. Work progress 12,000 mm/min. BT-40 Spindle Cone Maximum spindle speed 60-10,000 rpm Spindle power 7.5 / 11 kW Automatic tool loader Charger type Bidirectional RANDOM Tool loader positions 20 Maximum tool diameter 100 mm Maximum tool length 320 mm Maximum tool weight 10 kg Equipment Internal cooling 20 Bar INCLUDED 2 longitudinal chip evacuators INCLUDED 1 x Cross Chip Evacuator INCLUDED Air conditioning in electrical cabinet INCLUDED Portable steering wheel INCLUDED Automatic pall ...

Key data: 190 mm

Stock No: 3764 CNC LATHE Manufacturer: Mori Seiki, Type: ZT 1000Y Machine NO.: ZT101CB0056, Year of manufacture: 2003 Specifications: Max. circumferential diameter 190 mm dia. Max. turn. About BED 250 mm DIA. Main motor power 22/18.5 kw Main spindle speed range 6000 rpm Hole through drawing tube 46 mm dia. C axles 0.001 Y axis 40+/- mm Z Aksen Rapid Traverse 1/2 - 24 m/min Tool turret 1 with 16 stations Motor power driven tools 5.5 / 3.7 / 2.2 kW Kw Tool turret 2 with 16 stations Powered tools. 6000 rpm Sub-spindle Sub-spindle speeds 6000 rpm Control MSX-501 Fabr. Power on 15088 hours Operating hours spindle 5080 hours Controlled in 5+2 axes Accessories: Load and Unload device Hydr. Chuck main spindle 169 mm dia Hydr. Chuck Subspindle 169 mm dia Tool setter Weight: 5000 kg

Stock number: 3912 PROCESSING Manufacturer: EXCELL, Type: 810 Machine NO.: ES 8031, Year of manufacture: 0 Specifications: Table size 900 x 480 mm Large table load 400 kg Longitudinal movement (X) 810 mm Transverse movement (Y) 510 mm Vertical movement (Z) 560 mm Size distance spindle/table 700 mm Spindle Taper 40 Iso Spindle motor 9 Kw Tool changer 25 places Control Fanuc OM Fabr. Accessories: Cooling water system. Operating instructions Length: 2200 mm, Height: 2600 mm, Width: 3500 mm, Weight: 5400 kg

The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Control Heidenhain TNC 620 V2 Travel X/Y/Z 760/480/480 mm Speed 12000 rpm. Tool magazine for 24 tools SK40 Table size 900x410 mm Conveyor

YOM: 2003 CNC controller: MSX-501 Axes X-axis travel mm: 630 Y-axis travel mm: 600 Z-axis travel mm: 670 Rapid traverse m/min: 50 B-axis degrees: 360º (0.001º index) Rapid traverse m/min: 50 Worktable Number of pallets: 2 Table dimensions mm: 500x500 Maximum workpiece size (D x H) mm: ø800x1.000 Max. workpiece weight kg: 500 Spindle Spindle speed rpm: 14000 Spindle drive power kW: 18.5/22 Tool system Tool holder: ISO-40 Tool magazine slots: 60 Equipment Chip conveyor Signal lamp High pressure pump Internal coolant supply

Inv. Num. : 8267 Type: S56 Producer: Makino Created: 2009 Parameters: Control system: FANUC 310is Work table length: 1000 mm Work table width: 500 mm Maximum table load (uniform): 650 kg Maximum vertical spindle speed: 20000 1/min X-axis travel: 900 mm Y-axis travel: 500 mm Travel Z axis: 450 mm Cone: HSK-A63 Number of all tools: 30 pieces Machine height: 3063 mm Machine length: 3302 mm Machine width: 2570 mm Machine weight: 7500 kg

EMCO HYPERTURN 665MCPLUS Turning center with C/Y axis Gantry loading system and bar loading magazine Turning-milling machining completely in one clamping Year of construction 2003 Control SIEMENS SINUMERIK 840D Equipment: Gantry loading system with 20 basic pallets automatic bar loading magazine make IEMCA type MASTER 880 MP 2 tool turrets each approx. 12 stations Main spindle with C-axis Sub-spindle with C-axis Chip conveyor make KNOLL Refrigeration unit make KELVIO Included in delivery: VDI Recordings Powered tools Tool cabinet Drawer cabinet Operating Instructions/Documentation Machine parameters on storage medium Technical data and equipment – see PDF. All technical information, illustrations and content are non-binding and without guarantee. Subject to changes and errors. All other accessories visible in the photos and video are not included in the ...

BIGLIA B658 CNC turning center was built in 2008 in Italy by OFFICINE E. BIGLIA & C. S.p.A. The machine, designed for precision machining of workpieces with a maximum diameter of 380 mm, has, among others, a 12-position turret, a reliable spindle and an automatic tailstock. All process parameters, in turn, are programmed in an intuitive FANUC CNC control with many useful functions that facilitate the daily operation of the machine. The BIGLIA B 658 CNC lathe weighs 6000 kg. Technical specifications of the BIGLIA B658 lathe - maximum turning diameter: 380 mm - maximum bar diameter: 80 mm - maximum passage: 620 mm - maximum turning length: 650 mm - feed in the X/Z/B axis: 220/650/660 mm - rapid traverse in the X/Z/B axis: 20/24/12 m/min - spindle rotational speed: 30-3000 rpm - spindle bore diameter: 90 mm - spindle centre height: 1055 mm - front bearing inner diameter: 130 mm ...

BIGLIA B658/B CNC turning center was built in 2009 in Italy by OFFICINE E. BIGLIA & C. S.p.A. The machine, designed for machining workpieces with a maximum diameter of 380 mm, offers excellent precision and repeatability of the produced parts. The machining process is performed inside a large workspace which includes, among others, a powerful spindle, a 12-position turret and an automatic tailstock. All parameters are, in turn, entered in an intuitive FANUC CNC control with many useful functions. The BIGLIA B 658/B CNC lathe weighs 5700 kg. Technical specifications of the BIGLIA B658/B lathe - CNC controller: FANUC Series 21i-TB - maximum turning diameter: 380 mm - maximum bar diameter: 80 mm - maximum passage: 620 mm - maximum turning length: 650 mm - feed in the X/Z/B axis: 220/650/660 mm - rapid traverse in the X/Z/B axis: 20/24/12 m/min - spindle rotational speed: 30-3000  ...

MAZAK QUICK TURN NEXUS 100MS CNC lathe was built in 2005 in Japan by YAMAZAKI MAZAK CORP. The machine, designed for precision machining of workpieces with a maximum diameter of 280 mm, is distinguished by the use of reliable components with excellent technical parameters, such as two spindles (main spindle and sub-spindle) and a 12-position turret. The machining process is performed inside a large, fully illuminated workspace by means of a powerful spindle with an integrated motor design that minimises vibrations at high speeds. This is all complemented by an intelligent CNC control that simplifies daily work by allowing even the most advanced machining programmes to be created in just a few steps. The MAZAK QTN-100MS CNC turning center weighs 4100 kg. Technical specifications of the MAZAK QUICK TURN NEXUS 100MS metal lathe - CNC control: MAZATROL 640T NEXUS - maximum turning diamet ...

Specifications: Manufacturer: 3M ESPE Type: Lava CNC 500 Control: Beckhoff Year of Make: 2008 Compressed air: 6.5 bar Rated power: 1 kW Rated mains frequency: 50/60 Hz Weight Weight: 620 kg Condition Condition: Used Functional: Tested and fully functional

KOVOSVIT MAS S80i CNC turning center was built by KOVOSVIT MAS a.s. in the Czech Republic. This extremely powerful machine is used for precision hole drilling, threading and turning of cylindrical, conical and spherical surfaces. The offer also includes a wide range of equipment in the form of components from renowned brands, which guarantee excellent repeatability of the manufactured parts over many years of intensive operation. These include, among others, a new tool measuring probe, a hydraulic tailstock and a HEIDENHAIN intelligent CNC control. All this makes the S80i CNC CNC lathe the perfect choice for both unit and small batch production. The total weight of the machine is 6700 kg. Technical specifications of the KOVOSVIT MAS S80i universal lathe - maximum turning diameter above the bed: 680 mm - maximum turning diameter over the slide: 430 mm - maximum bar diameter: 80 mm  ...

DUGARD EAGLE 1000 VMC CNC vertical machining center was built in 2000 in Taiwan by C Dugard Ltd. The machine is used for precision machining of workpieces with a maximum weight of 600 kg. The machining process is performed by means of reliable components that offer the highest quality of manufactured parts for many years of use. Inside the large workspace there is among others a large work table with a length of 1200 mm and a width of 450 mm, a powerful spindle and a 20-position tool magazine. The DUGARD EAGLE 1000 CNC machining center weighs 5800 kg. Technical specifications of the DUGARD EAGLE 1000 VMC CNC milling machine - CNC control: SIEMENS - feed in the X/Y/Z axis: 1020/510/510 mm - feed rate in the X,Y,Z axis: 1-7600 mm/min - rapid traverse in the X/Y/Z axis: 30/30/18 m/min - work table dimensions (L x W): 1200 x 450 mm - maximum workpiece weight: 600 kg - maximum spind ...

bar capacity 90 mm - 2x12 driven positions turrets - Y axis in upper turret - tail stock - very very well equipped ( 36 driven + 39 fixed tool holders - 30 collets etc.etc.) - Lns Sprint S2 barfeed with front magazine - Siemens 840D Power Line Control - IN PERFECT CONDITION

swing diameter: 640 mm max. turning passage: 640 mm control: Simens 840 D Powerline - - - - - Main spindle - - - - -: - - - - - - bar material dia.: 65 mm chuck diameter: 200 - 315 mm spindle bore diameter: 80 mm diam. of main spindle in forward position: 120 mm --- Subspindle ---: - - - - - - bar material dia.: 65 mm chuck diameter: 315 mm spindle bore diameter: 80 mm forward bearing diameter: 120 mm - - - - - General data - - - - -: - - - - - - spindle distance: 1.500 mm turning length: 1.185 mm Main-/Counter -spindle turning speeds: 5.000 U/min driven tools turning speeds: 12.000 U/min Slide cross: X1, Y1: 550 / 180 mm Slide cross: Z1: 1.185 mm Slide cross: B1: 240 ° Slide cross: X2: 180 mm Slide cross: Z2: 1.050 mm Slide cross: Z3: 1.150 mm CNC Turning- and Milling Center | DMG GILDEMEISTER - GMX 250 linear equipped with main/counter spindle, chip conveyor, tool changer, a turret fo ...

x-travel: 450 mm y-travel: 400 mm z-travel: 400 mm control: Heidenhain Mill Plus V600 total power requirement: kW weight of the machine ca.: 7000 kg dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

MATEC 30 HV CNC machining center was built in 2001 in Germany by Matec Maschinenbau GmbH. The machine, designed for precision machining of oversized workpieces, is equipped with a number of reliable components with excellent specifications. This includes a tilting work head, a 24-position tool magazine and a chip extraction unit. All this is complemented by the intelligent BOSCH CNC control, in which advanced machining programmes are created in just a few steps. The MATEC CNC vertical machining center weighs approximately 15000 kg. Technical specifications of the MATEC 30 HV CNC milling machine - CNC controller: BOSCH TYP 3 OSA - feed in the X/Y/Z axis: 3000/600/800 mm - maximum spindle rotational speed: 9000 rpm - minimum spindle rotational speed: 20 rpm - spindle drive power: 16 kW - tilting work head - rotation angle of work head: ± 90° every 1° - 24-position tool magazi ...

KITAMURA MYCENTER HX630G CNC machining center was built in 2017 by the Japanese brand Kitamura Machinery Co., Ltd. The machine, designed for precision machining of workpieces with a maximum weight of 1500 kg, was created as a response to the needs of modern business. In order to meet all production requirements, state-of-the-art technical solutions, combined with extensive equipment, guarantee excellent repeatability of the manufactured parts over many years of intensive operation. The machining process is performed fully automatically inside a large working area, which includes a capacious tool magazine and a reliable spindle with a special DCS (Dual Contact Spindle) system. This system ensures optimum spindle rigidity through simultaneous contact between the taper and the flange. Furthermore, the automatic pallet exchange system allows workpieces to be loaded and unloaded simultaneo ...

OKUMA MA-600HII CNC machining center was built in 2012 by the Japanese brand OKUMA Corporation. This highly efficient machine is used for advanced workpiece machining in 4 axes. The machining process is performed fully automatically inside a large working area by means of precision cutting tools and a reliable high-speed spindle. The automatic pallet changing system allows workpieces to be loaded and unloaded simultaneously during machining, reducing machine downtime to a minimum. The extensive equipment also includes, among others, a capacious tool magazine and an intelligent CNC controller with an intuitive interface. The MA-600HII CNC horizontal machining center weighs 24500 kg. Technical specifications of the OKUMA MA-600HII CNC milling machine - CNC controller: OSP-P300MA - number of axes: 4 (X,Y,Z,B) - feed in the X/Y/Z axis: 1000/900/1000 mm - rapid traverse in the X,Y,Z ax ...

12 position upper turret (6 are driven) -10 positionlower turret (5 are driven) - sub spindle - 2 x C axis - equipped with Lns Sprint S2 bar loader with front magazine, fixed and driven tool holders, manuals - Fanuc 18T Control

Control Ultimax 3-4 2 color screens (text + graphics) Travel X/Y/Z 1020/510/610 mm Speed 8000 1/min Tool magazine for 24 Wkz. SK 40 DCF Software

CINCINNATI ARROW 1250 CNC vertical machining center was built in 2001 in the United Kingdom by CINCINNATI MACHINE U.K. LIMITED. The machine, distinguished by its high reliability, productivity and precision, is used for the economic machining of workpieces. The machining process is performed inside a large work space, equipped with, among others, a 21-position tool magazine and a high-speed spindle. Its high-quality design eliminates any vibrations generated during milling, guaranteeing the highest possible stability during even the most intensive challenges. The offered CINCINNATI ARROW 2 1250 CNC machining center has undergone regular maintenance and servicing. The machine is after an spindle overhaul and the replacement of guides and screws in the X and Y axes. The total weight of the machine is 6000 kg. Technical specifications of the CINCINNATI ARROW 1250 CNC milling machine - C ...

3 slides 3 revolvers with 12 positions each driven main and subspindle 2 C-axis Y axis, workpiece unloading device, high pressure coolant system with paper filter chip conveyor, Control: Fanuc 310i, Country of origin: Italy, Operating hours: 34.000 | 22.900, Number of spindles: 2, Number of linear axis + C axis: 8+2, Max bar diameter [mm]: 65, Spindle speed [rpm]: 5.000, Spindle motor [kW]: 20, Auto bar loader: Iemca Master 880 P/R, Machine weight approx. [kg]: 9.000

control: MAZAK Mazatrol 640T Nexus swing over bed: 610 mm swing diameter over bed slide: 350 mm turning length: 982 mm c-axis: indexing: 0.001 ° turning speeds: 4000 U/min tool taper: ASA A2-8 tailstock quill taper MT: 5 rapid traverse X-axis: 30 m/min rapid traverse Z-axis: 33 m/min Overall size: 4500 x 2000 x 1600 mm weight of the machine ca.: 6.5 t The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Control: Manufacture: SIEMENS 840D x-travel: 600 mm y-travel: 560 mm z-travel: 510 mm table-size: 900 x 560 mm spindle turning speed range: 12000 U/min tool magazin:: 30 weight of the machine ca.: 5 t HEIDENHAIN TNC-426 Prepared for the 4th axis www.marcels-maschinen.ch The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

control: FANUC TXP-200 FA turning diameter: 360 mm swing over bed: 600 mm swing diameter over bed slide: 450 mm turning length: 683 mm c-axis: indexing: 0.001 ° turning speeds: -3000 U/min tool taper: VDI 40 Top turret tool hodler:: 12 tailstock quill taper MT: 5 quill travel: 100 mm feed: 1-10 m/min rapid traverse X-axis: 20 m/min rapid traverse Z-axis: 24 m/min Overall size: 4450x2100x2350 mm weight of the machine ca.: 7200 t The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Control: Manufacture: FANUC 0iM x-travel: 620 mm y-travel: 470 mm z-travel: 400 mm table-size: 700 x 450 mm spindle turning speed range: 10000 U/min tool magazin:: 20 weight of the machine ca.: 4.5 t HEIDENHAIN TNC-426 Prepared for the 4th axis www.marcels-maschinen.ch The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

turning diameter: 16 mm workpiece length - max.: 145 mm main spindle speeds:: 15000 rpm control: SIEMENS 840 DSL weight of the machine ca.: 2.6 t dimensions of the machine ca.: 2.2 x 1.5 x2.0 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Control: Manufacture: FANUC 18i-MB x-travel: 510 mm y-travel: 360 mm z-travel: 300 mm table surface area: 600 x 360 mm spindle turning speed - stepless: 12000 U/min dimensions of the machine ca.: 1400 x 2300 x 2300 mmxmmxmm weight of the machine ca.: 2.6 t tool piece magazine with: 24 Plätzen tool piece magazine with: 20 Plätzen The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 6000 mm y-travel: 1000 mm z-travel: 1200 mm table-size: 6400x1000 mm tool change unit: 80x spindle taper: HSK A100 spindle turning speed range: 45-9000 U/min total power requirement: kW weight of the machine ca.: 48 t dimensions of the machine ca.: 12x4.3x4.5 m SIEMENS 840D 4th axis B-Axis +/-90° Spindle coolant through spindle Tool measuring device www.marcels-maschinen.ch The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

HAAS VF-1 CNC machining center was built in 2015 in the United States by HAAS AUTOMATION, INC. The machine, designed for unit and small batch production, is the ideal choice for any tool workshop. All this is due to the use of a number of modern components with excellent technical parameters, which guarantee high reliability and precise machining. Workpieces weighing a maximum of 1361 kg are machined inside a large, fully illuminated work area by means of a high-speed spindle and tools taken from a 20-position magazine. The machining process is free of vibration or oscillation, thanks to an extremely stable design made from top-quality steel. All this is complemented by an intelligent CNC control with an intuitive interface. The HAAS VF1 milling center weighs 3539 kg. It is also possible to purchase additional tooling shown in the photos (tool holders, vices, TSCHORN 3D tester, measur ...
