horizontal machining centers used for sale

Key data: 560 mm, 510 mm, 510 mm

Inv. Num. : 9279 Type: HTC 400 Producer: MAZAK Created: 1998 Parameters: Control System: Mazatrol Work table length: 400 mm Work table width: 400 mm Maximum table load (even): 300 kg Spindle drive power: 5.5 kW Maximum spindle speed: 10000 1/min X-axis travel: 560 mm Y-axis travel: 510 mm Travel Z-axis: 510 mm Number of stacking positions: 24 pieces

Boring power:10 mm weight:590 kg connected load:2 kW dimensions::1500 x 1300 x 2300 mm

Manufacturer: Biesse Model: C6.50 WMS Year of Manufacture: 2009 Type of Machine: Machining center with automatic loading Working Field: - X-axis: 6400 mm - Y-axis: 1650 mm - Z-axis: 350 mm Drilling Head: - Vertical spindles: 16 - Horizontal spindles: 6 (X and Y directions) - Integrated grooving saw on X-axis Electrospindle: - 1x HSK F63, 13.2 kW, air-cooled - 0–24,000 RPM Tool Changer: - Rotary 16-position tool changer Worktable: - ATS (Advanced Table Setting) with manual positioning pods and rails Control System: - NC 500 / XP600 with BiesseWorks software Safety: - Full perimeter safety bumpers with sensors Vacuum System: - High-capacity vacuum pump for strong hold-down Find more here - / Contact us at -

Mazak VTC-41 L X: 1660 - Y: 410 - Z: 510 mm CNC X-axis: 1660 mm Y-axis: 410 mm Z-axis: 510 mm Table dimensions: 2000 x 410 mm Max weight on the table: 800 kg Depth of throat (uprights-spindlecenter): 460 mm Admission in spindle (ISO): ISO 40 Power on the spindle: 11/7,5/5,5 kW Drilling-capacity: max dia 25 mm Tapping-capacity: max M24 Control : Mazatrol Number of axes: 3 axes Toolchanger: yes Number of rotations: 7000 rpm Length: 3900 mm Depth: 3050 mm Height: 2700 mm Weight: 6 ton

Chevalier X: 850 - Y: 510 - Z: 510 mm CNC X-axis: 850 mm Y-axis: 510 mm Z-axis: 510 mm Table dimensions: 1000 x 450 mm Admission in spindle (ISO): ISO 40 Power on the spindle: 7,5 kW Control : Siemens 810 Number of axes: 3 axes Toolchanger: yes Number of toolholders: 20 positions Number of rotations: 8000 rpm

Manufacturer: WEEKE Model: OPTIMAT BHT 500 Year of Manufacture: 2009 Technical Specifications: - Voltage: 400 V - Frequency: 50/60 Hz - Phases: 3 + N (three-phase with neutral) - Power Consumption: 45 kW - Current Rating: 100 A - Control Voltage: 24 V Find more here - / Contact us at -

Type: XCEEDER 900/RT Een hoogwaardig multitasking bewerkingscentrum met 5 geïnterpoleerde assen. Ontworpen voor de hoogste prestaties bij het bewerken van 3D-vormen die draaien, frezen, boren en slijpen vereisen. Speciaal afgestemd op toepassingen variërend van complexe tandwielen en waaiers tot mallen, matrijzen en gereedschappen, voor projecten in de lucht- en ruimtevaart, automotive en energieopwekking. maximale werkstukdiameter: 900 mm A-as: -30° / 110° C-as: continu: 100 RPM maximale afstand tussen spindel en tafel: 700 mm Opties gemonteerd op de machine: 1 - hogesnelheidsspindel van 40.000 tpm 2 - tafel met diameter 700 mm 3 - gereedschapswisselaar met 150 posities 4 - spaantransportband 5 - koelsysteem met recuperatie 6 - temperatuurregeling voor koelmiddel 7 - hoge druk koeling (40 tot 70 bar) door spindel 8 - rookafzuigsysteem 9 - chipverzamelbox 10 - Voorinstelling syste ...

Freesrobot Staubli RX170HM Deze robot is voorzien van gaten om te frezen in mallen van banden, maar ook in andere zaken is dit mogelijk. Koeling door de spindel en de koelmelk is luchtgekoeld. Smering Gebeurde met vet. spindelopname: HSK E 32 Werd gebruikt in Tire Mold fabriek Mecamold Herstal. Max weight on the table: 300 kg Admission in spindle (ISO): HSK E 32 Power on the spindle: 8 kW Drilling-capacity: 80 mm Tapping-capacity: 80 mm Control : Fanuc Number of axes: 6 Toolchanger: nee Number of toolholders: nee Number of rotations: 500 - 20 000 rpm Power principal motor : 5 kW

Paletchanger 2 tafels Hoge druk koeling 15 bar Schroottransportband Maximale werkstukafmetingen: 3240 x 880 x 640 mm X-axis: 3000 mm Y-axis: 800 mm Z-axis: 585 mm Table dimensions: 3240 x 750 mm Max weight on the table: 3 ton Passage between uprights: 860 mm Admission in spindle (ISO): ISO 50 Power on the spindle: 30 kW Control : Mazatrol 640 Toolchanger: yes Number of toolholders: 40 positions Number of rotations: max 6000 rpm Number of pallets: (2x) 750 x 3240 mm Length: 3274 mm Depth: 8100 mm Height: 3546 mm Weight: 19 ton

Manufacturer: Chiron Model: FZ 08K S Magnum SK Year of Manufacture : 2007 Type of Machine : Vertical Machining Center Factory overhaul: 2017 (Chiron CMS) Operating hours: approximately 22,500 h CNC control: Siemens 840D (PCU 20 / NCU 572.4) Spindle: water-cooled motor spindle, 15,000 rpm Spindle last replaced: September 2025 Last major service: October 2025 (Chiron, 4,000 h interval) NC swivel head swivel range: -20 degrees / +115 degrees Travel X / Y / Z: 450 mm / 270 mm / 310 mm Rapid traverse X / Y / Z: 75 m/min Acceleration X / Y / Z: 1g / 1.5g / 2g Tool positions: 40 x HSK-A 40 Chip-to-chip time: 2.6 seconds vertical (DIN) --------------------------------------------------------------- Equipment and Accessories Included Rotary table package AWU 160 with D105 mm (positioning axis) Hainbuch Spanntop collet chuck D100 6th side machining attachment Part removal hand ...

A complete machining line consisting of four Toyoda machining centers, Palltec transport and automation system, filter systems, chip conveyors and coolant supply systems is available. 1) 4x CNC horizontal machining center Toyoda FH 630 SX, year of manufacture 3/1: 2007/2008, control: Fanuc 31i, pallet dimensions X/Y: 630mm/630mm, travel X/Y/Z: approx. 1050mm/900mm/1050mm, max. workpiece diameter: 1170mm, max. workpiece height: 1250mm, max. pallet load: 1500kg, spindle taper: BT50, speed: 6000rpm, tool magazine: Fanuc FTS 330, tool positions: 330, operating hours range: approx. 65000h-76000h. All machining centers have the same tool management, but different operating hours within the above-mentioned range. 2) Rail-guided-vehicle system RGV Palltec FPA 630, year of manufacture: 2006. 3) Master computer system with Windows 7 Professional, interfaces: CNC/RGV/peripherals. The production lin ...

Manufacturer: Weeke Model: Optimat BHC Venture 1 Year of Manufacture: 2006 Operating Hours: 20000h Electrical: - Power Supply: 400V / 50 Hz / 3-phase + N - Total Power: 18 kW - Current: 35 A - Control Voltage: 24V Find more here - / Contact us at -

hogedrukkoeling via de spindel spanentransporteur X-axis: 1660 mm Y-axis: 510 mm Z-axis: 510 mm Table dimensions: 2000 x 510 mm Max weight on the table: 1000 kg Admission in spindle (ISO): BT-40 Power on the spindle: 18,5 kW Control : Mazatrol 640M Toolchanger: yes Number of toolholders: 30 positions Number of rotations: 12 000 rpm Weight: 8250 kg

Current 35 A Including tool magazine 40 positions with tools Auction-ID: A7-48410-865

Without tools and clamping devices Pick-up date: 10.08 - 12.08 Auction-ID: A1-48584-3

Incl. various clamping devices, without trolley Auction-ID: A7-48588-1

WITHOUT tools and clamping devices incl. FEHLMANN EROWA Robot Multi Automation, FEHLMANN ATS 160 CNC dividing head Pick-up date: 17.08 - 18.08 Auction-ID: A1-48584-2

Without tools and clamping devices, machine has spindle damage! Pick-up date: 10.08 - 11.08 mandatory! Auction-ID: A1-48584-4

strong>Serial Number: VMC-6680 CNC Control: GE Fanuc Series 0-M Power: 16 kW Voltage: 380 V Frequency: 50 Hz Additional information: Integrated rotary tool changer Status: Used machine Additional information: : Disassembly and loading at the expense of the buyers Auction-ID: A1-48609-3

UNIT 1 - Weeke Profiline ABL 210 - Manufacturer: Weeke - Model/Type: Profiline ABL 210 - Year of manufacture: 2007 - Made in Germany - Power: 17 KW - Voltage: 400 V - Frequency: 50 Hz, 3 phase + N - Current: 35 A - Control voltage: 24 V UNIT 2 - Ligmatech MDE 110 loading system - Manufacturer: Ligmatech - Model/Type: MDE 110/28/08 - Year of manufacture: 2007 - Made in Germany - Voltage: 400 V - Frequency: 50 Hz, 3 phase + N - Current: 12 A - Fuse: 25 A - Control voltage: 24 V - Max pressure: 10 bar - Air consumption: 8 Nm3/h - Weight: 6500 kg UNIT 3 - Ligmatech control system - Manufacturer: Ligmatech - Model/Type: Steuerung - Year of manufacture: 2007 - Made in Germany - Voltage: 400 V - Frequency: 50 Hz, 3 phase + N - Current: 8 A - Fuse: 16 A - Control voltage: 24 V Find more here - / Contact us at -

Brother TC-225 CNC Machining Center Manufacturer: Brother Industries Ltd., Japan Type: TC-225 Control: Brother CNC-400 Vertical CNC Machining Center 3-axis version Automatic tool changer with 10 tool positions Electrical connection: 380 V / 50 Hz Rated power: 9.0 kVA Machine weight approx. 2,000 kg Compact design for milling, drilling and threading Tool magazine and control available According to the previous owner, the machine was functional before storage Current functional status unchecked Loading possible for an extra charge and by prior appointment Auction-ID: A1-48287-1039

Fadal CNC Machining Center Manufacturer: Fadal Engineering Co. Inc., USA Type: VMC 15RT (Model 914-15) Year of Make: 1995 Serial Number: 95111170 Control: Fadal CNC 88HS Vertical CNC Machining Center 3-axis version Tool changer available Tool holder partly included Machine room equipped with vice Electrical connection: 400 V / 50 Hz Robust industrial design Machine was in production until it was relocated Current functional status unchecked Traces of use according to age and use present Loading possible for an extra charge and by prior appointment Auction-ID: A1-48287-1052

x-travel:600 mm y-travel:580 mm z-travel:530 mm distance spindle center to column:630 mm distance spindle center to table:100-600 mm milling feed range:1-10.000 mm/min max. table load:200/100 kg max. tool weight:8 kg positioning accuracy:+/- 0,01 mm :8000/15000 1/min spindle drive:7,5/11,5 /5,5 kW repeating accuracy:+/- 0,008 mm weight of the machine ca.:7,4 / 7,65 t Brand-new CNC vertical machining center with CNC control FANUC or HEIDENHAIN Warranty: 12 months More information can be found in the Appendix.

x-travel:1000 mm y-travel:1150 mm z-travel:700 mm table-size:900 mm table load:1500 kg spindle speeds:10.000 1/min spindle drive:Motorspindel von Cytec CS34-180-A 34&42KW/160&200 Nm spindle taper:A100 HSK T-slots:18mm/7/100 mm milling feed range:20.000 mm/min rapid traverse feeds:X/Y/Z: 24 m/min diameter of tools max.:150 mm workpiece length:300 mm weight of tools max.:20 kg weight of the machine ca.:15 t dimensions of the machine ca.:s. Katalog m CNC controller:Heidenhain iTNC-640 HSCI-Steuerung cnc rotary table:von Cytec; mit Ø900mm; 800 1/min Drehmomenttisch (AS3347) + HSK-T63/100 Spindel & ATC + TNC-640 Fräsdrehzahlregelung B-axis:Fräskopf, 0-180° c-axis:0,001° automatic tool changer:HSK-A/T100; 60 fach Scales:in X/Y/Z von Heidenhain mit Druckluft inner coolant:20

x-travel:1660 mm y-travel:760 mm z-travel:660 mm weight of the machine ca.:8700 t dimensions of the machine ca.:4.320 x 3.380 mm distance spindlenose - table min./max.:808 mm distance work spindle /surface of the table:155 - 815 mm Machine height:2850 mm floor space required (w/o switchgear cabinet):4.320 x 3.380 mm spindle motor:11 (10 Minuten) /7,5 (30 Minuten)/ 5,5 (Dauerbetrieb) kW tool taper:SK 40 Spindle RPM:40 - 7.000 (Standard ) / 40 - 10.000 ( Option ) 1/min surface area:2.000 x 760 mm max. table load:1.000 kg feeds X-axis:1 - 5.000 mm/min rapid traverse X-axis:24.000 m/min rapid traverse Y-axis:24.000 feeds Y-axis:1 - 5.000 mm/min feeds Z-axis:1 - 5.000 mm/min rapid traverse Z-axis:20.000 m/min

The DECKEL-MAHO machining centers are suitable for manual and manual Automatic operation. --> area of application <-- --> MILLING: --> Drilling: --> Face Milling --> Countersinking --> Circular Milling --> Circular Drilling --> Screw Milling --> Screw Drilling --> Hobbing --> Profile drilling --> Profile Milling --> Shape Drilling --> Shape Milling --> incl. vertical tool changer with double gripper --> Tool Magazine, Variable Place Coding (VPC): --> Number of tools: 20 pieces --> Standard tool - Ø max.: 90 mm --> Special tool - Ø for free neighboring spaces max.: 140 mm --> Tool length from spindle nose max.: 300 mm --> Tool weight max. 12 kg Auction-ID: A1-48483-117

CNC Control: Mazatrol 640M Equipment: Tool magazine with tool holder Accessories: Numerous tool holders and tools included Status: Used machine Additional information: Vise and clamping equipment present and the batch only includes the machine Additional information: : Disassembly and loading at the expense of the buyers Auction-ID: A1-48609-1

Weight: approx.4500 KG mash. No.: 6517991 General/technical data: Vertical CNC machining center in a very good, almost new condition, first-hand with very little operating hours. Travel: X= 670 Y=450 Z=470 mm Rapid response: in X and Y = 24m/min, in Z =20m/min Spindle motor: 10 KW Spindle speed: from 50 to 4,500 rpm Spindle cone: SK 40 Control: Siemens 810 M GA 2 Dimensions clamping table: 900 x 420mm max table load: 300 kg Distance spindle head to top of the table: 630mm spindle center to stand face: 470mm Tool slots in the magazine: 24 pieces DIN ISO 40 max. tool diameter: 110mm to 125mm tool length 100mm to 280mm tool length Beuvvquh2i Dimensions of the machine approx.: 2200 x 3000 x 2950 mm (without operator, service and chip conveyor environment) Accessories/ Optional equipment: â?¢ external coolant system with 2 pumps â?¢ Chip conveyor with ...

ertikal machining center, used, from location vertical machining center, used, Model/ model: VS 500 SPEED Fabr./ make: NORTE Year built/ year: 1999 Control/ control: SIEMENS 840D x-Way /x-travel 2000 mm y-way / y-travel 500 mm z-way / z-travel 500 mm Feed: 1 - 8000 mm/min Table size / table-size 2120 x 550 mm Table load / table load 2000 kp Rapid gear X-axis / rapid traverse X-axis 40 m/min Rapid gear Z-axis/ rapid traverse Z-axis 20 m/min Tool holder / tool taper HSK 63 A Spindle speeds - infinitely variable/ spindle turning speed 0 - 15000 rpm Spindle drive/spindle motor 20 kW Spindle bearing diameter / spindle bearing diam. 70 mm Position accuracy / position accuracy: 0.020 mm Control SIEMENS 840D Tool diameter: 63 / 126 mm Tool Magazine: Chain Magazine/ toolpiece magazine: 40 pieces Total power requirementm.65 kVA Machine w ...

5 axis machininng center (milling/turning from bar) multitasking Under power in our warehouse MAKE CHIRON MODEL MILL 800 5 axis CNC Fanuc 18iMBS (5 simoultaneous axis 1) X, Y, Z (mm) 800 ? 500 - 550 Rapids (Highspeed) 60 m/min Swivelling head CNC controlled (B axis) +/- 100° Turning spindle Peiseler Milling spindle 12.000 giri / 140 Nm (v nota 2) Tools 65 Tool type HSK-A 63 DIN 69893 Tool-change time 1,5 sec (v nota 3) Table 1400x500 Max table load 1200 kgs Coolant through spindle 70 bar (see note 4) CNC controlled clamping/rotating unit for 6th face machining (v. nota 5) Pressurised linear encoders Swarf conveyor Renishaw-ready Y.O.M. 2006 Weight 7500 kgs Turning package Max dia 65mm RPM: 15 / 4500 Max 42,5 KW / 90 Nm. Hydraulic clamping 800 Nm. Bar loader ILS-RBK- 10012 65 Diameters min ...

Table clamping surface: 2 x 350 x 300 mm traverse path x/y/z: 700/300/250 mm spindle retainer: BT 30 ISA kl. / gr. Table/spindle distance: 450 mm spindle speeds: 6-6000 rpm number of tool stations: 10 pieces feeds: 5-10000 mm / min rapid traverse: x & y/z 25/20 m / min spindle drive: 3,1/4,1 kW Electr. Supply: 400 V kW weight: 2600 kg

Machine-Details Stock-No. 1105-04006 Type of machine Machining Center - Vertical Make DMG MORI Type M 1 Year of manufacture 2022 Type of control CNC Storage location HAGUENAU FRANCE Country of origin Germany Delivery time IMMEDIATELY Freight basis EX WORK Price Technical details X-Travel 550 mm Y-Travel 550 mm Z-Travel 510 mm table-size 790 x 560 mm spindle taper ISO SK 40 turning speed range 10000 1/min Feeds longditudinal/cross/vertical 1 - 30000 mm/min Rapid Motion -Longitudinal/Cross/Vertical 30 m/min No. of tools in magazin 20 Workpiece diameter at full load 80 mm Wotkpiece diameter with 2 vacant positions 140 mm Workpiece length 300 mm Weight of tools max. 7 kg Table Load 600 kg spindle drive 9 / 11 kW control SIEMENS 828D total power requirement 30 kVA Additional information cnc SIEMENS 828 D ONLY 1400 SPINDEL HOURS VERY NICE El. handwheel, CH ...

STAMA Mod. MC 2 1997-325S pallet (Pendeltisch Peiseler ATK 520) Aufspannflaeche Pallet: 2 x 550 mm x 330 mm Max Werkstueckgewicht: 2x180kgs X = Y = Z 500 300 = 350 mm Min/Max Distance Spindelnase-Tisch: 200-550 mm rapid traverse X, Y, Z = 40/40/45 36 40 36 Werkzeuge ISO-9000 RPM Spindle IKZ CNC SIEMENS 840 c # 2 LEHMANN doppel 4. Achsen IKZ Unter Strom in unserem Lager It machined \\input shafts\\ (car power steering component) Special price for quick removal

Technical details x-travel 600 mm y-travel 560 mm z-travel 510 mm Steuerung Siemens Slim Line Multi Touch Control Main spindle: Max. speed 15,000 rpm/-1 Drive power - main spindle 20 / 14.5 kW Max. torque 121 / 84 Nm Tool holder SK 40 Distance between spindle nose and table 120 - 630 mm Workbench: Table clamping area 900 x 560 mm max. table load 600 kg T-slots 5 Working height 850 mm Tool magazine: Number of tool positions 60 pos. Tool holder SK 40 max. tool diameter 80 mm max. tool diameter. with a free neighboring box. 130 mm max. tool length 300 mm max. tool weight 8.0 kg Tool-tool changeover time 2.4 sec Changeover time chip - chip 6.7 sec Feeds: Rapid traverse 30 m/min Feed force 5 kN Feed speed max. 30,000 mm/min Total power requirement 32 kVA Machine weight approx. 5.0 t Space requirements approx. 4.0 x 5.0 x 3.0 m

With Indumatik Automation x-travel 500mm Y travel 450mm z-travel 400mm Control Siemens 810 D Shopmill Main spindle: Speed Range - Main Spindle ((( 20 - 8,000 )))min/-1 Drive power - main spindle 13 / 9kW Tool holder SK 40 Max. torque 83Nm NC rotary table: Table clamping area 630 x 500mm Max. table load 200kg Swivel range -5 / +110° Rotation range 0.001° T-slots 7x 14 x 63mm Tool magazine: Number of tool locations 16pos. max. tool weight 6kg max. tool diameter 80mm max. tool diameter. with a free neighboring box. 130mm max. workpiece length 300mm Feeds: Rapid traverse 12m/min Feed force 4.5kN Feed speed 1 - 12,000mm/min Total power requirement 18kW Machine weight approx. 5.0t Space requirements approx. 4.5 x 3.5 x 2.3m

CONTROL .. CNC Control HEIDENHAIN TNC426 WORKSPACE -CUBIC- .. Number of machining axes (without parallel axes): 3 .. X-axis travel: 500 mm .. Y-axis travel: 400 mm .. Travel Z-axis: 400 mm TABLE .. Clamping surface (left-right): 700 mm .. Clamping surface (front-rear): 500 mm SPINDLE / HEAD .. Speed range up to: 9000 rpm .. Tool holder: ISO SK 40 TOOL MAGAZINE .. Number of tool positions: 16 ELECTRICAL CONNECTION DATA .. Connection voltage: 400 V .. Mains frequency: 50 Hz DIMENSIONS / WEIGHTS Bsicvzmv7Vm .. Space requirement -left/right-: 5000 mm .. Space requirement -front/rear-: 3700 mm .. Total height: 2500 mm .. Total weight approx.: 4500 kg

This 3-axis EMCO EmcoMill E900 was manufactured in 2018. The vertical machining center is equipped with a Siemens 828D control system and offers a spindle speed of up to 12,000 rpm and a torque of 83 Nm. It has a travel of X 900mm, Y 500mm, Z 500mm and a rapid traverse speed of 24m/min. The machine has a 360l coolant pan and a 20-cavity tool magazine. If you are looking for a high-quality milling machine, you should consider the EMCO EmcoMill E900 machine that we have for sale. Contact us for more information. Brand: SIEMENS Model: 828 D Spindle Speed Range: 50-12000 Number of axes: 3 X-axis travel: 900 mm X-axis rapid traverse: 24 m/min Y-axis travel: 500 mm Rapid traverse Y-axis: 24 m/min Z-axis travel: 500 mm Rapid traverse Z-axis: 24 m/min Outer length: 1000 mm Outer width: 520 mm Minimum distance between vertical spindle and table: 100 mm Maximum distance between ver ...

Table size 2400 x 810 mm Feed speed 1 - 10000 mm/min Headstock travel 810 mm (Z-axis) Height of the machine 4000 mm Pull bolts MAS 403-P40T-I Table longitudinal displacement 2000 mm (X-axis) Table Transverse Displacement 810 mm (Y-axis) Spindle front face to table top 100 - 910 mm Distance from the floor to the table 1200 mm Distance between spindle center and column front 825 mm T - Slot No. 5 T - Slot Size 18 mm T - Slot Pitch 150 Max. load on the table 2500 kg Spindle cone BT-40 Hourly spindle speed 6000 rpm Footprint (L x W) 5400 x 3450 mm Weight of the basic machine 17000 kg Total connected load 50 kVA (basic standard machine), 60 kVA (basic standard machine with high-power spindle)

Key data: 490 mm, 515 mm

tock-No. 1105-04043 Type of machine CNC Turning- and Milling Center Make MORI SEIKI Type NL1500SY/500 Year of manufacture 2006 Type of control CNC Storage location HAGUENAU FRANCE Country of origin Japan Delivery time immediately Freight basis ex Warehouse Price Technical details turning diameter 490 mm turning length 515 mm control MSX-850 max. bar capacity 52 mm Travel -X Axis 280 mm Travel -Z AXIS 490 mm max. speed main spindle 6000 min-1 spindle taper 1 A2-6 C - Axis 0.001 ° Spindle bearing diameter 110/75 mm No. of tools in turret 1 12 Shaft Cross Cut 25 x 25 mm Shank diameter 50 / 32 mm Turret Change Time 0.25 s max. spindle speed driven tools 6000 min-1 rapid power traverse in X-and Z direction 30 m/min Rapids C - Axes 400 min -1 drive capacity - spindle motor 18.5 kW power capacity - driven tools 5.5 kW swing diameter over face slide 278 mm gre ...

CNC Milling-Turning Center Alzmetall GS 600/5-FDT Milling-turning machine Commissioning 05/2021 At call! Heidenhain TNC640 Spindle HSK-T 63 / 18,000 rpm Balancing system (only for FDT) Kinematics Opt Electr. Handwheel Skiving (only for FDT) Dyn. Collision Monitoring Heidenhain DNC Heidenhain Remote Desktop 3D model of the machine Advanced tool management Operating mode 3 Probe Heidenhain Tool Measurement Blum Laser Signal tower on the machine 18,000 spindle HSK-T 63 Continuous air through the spindle (with lubrication interval) Continuous air from the outside 76 mm tool magazine Spray gun Chip flushing of the working area (recommended for Al) Emulsion Mist Extraction Production package C, 80 bar, hinged belt conveyor Machine Interior Trim Remote diagnostics The options list is complete! No interest in dealer enquiries! No separate dealer price! WB me ...

FZ15KS HIGH SPEED 4 axis vertical machining center X: 550mm Y: 400mm Z: 360mm 4th axis original Peiseler CNC Siemens 840D Table surface 1050 x 450mm Toolchanger 48 posts ISO 40 Spindle speeds up to 12000 1/min with 4th axis Renishaw broken tool detector Coolant through spindle swarf conveyor Can be inspected under power in our warehouse. Mimu machine tools (Italy)

CNC Milling-Turning Center Alzmetall GS 600/5-FDT Milling-turning machine Commissioning 03/2019 At call! Heidenhain TNC640 Spindle HSK-T 63 / 18,000 rpm Balancing system (only for FDT) Kinematics Opt Electr. Handwheel Skiving (only for FDT) Dyn. Collision Monitoring Heidenhain DNC Heidenhain Remote Desktop 3D model of the machine Advanced tool management Operating mode 3 Probe Heidenhain Tool Measurement Blum Laser Signal tower on the machine 18,000 spindle HSK-T 63 Continuous air through the spindle (with lubrication interval) Continuous air from the outside 76 mm tool magazine Spray gun Chip flushing of the working area (recommended for Al) Emulsion Mist Extraction Production package C, 80 bar, hinged belt conveyor Machine Interior Trim Remote diagnostics The options list is complete! No interest in dealer enquiries! No separate dealer price! WB me ...

MAZAK INTEGREX 200 SY + FLEX GL-100C. 2001. MAZATROL 640 MT control maximum turning diameter 540 mm Z-axis travel 1,065 mm Main spindle maximum RPM 5,000 rpm Main spindle full C-axis Counter-spindle maximum speed 6,000 rpm Y-axis +/-80 mm Milling spindle for turning and milling Spindle maximum speed 6,000 rpm Full B-axis, 225° Tool changer with 40 tool positions KM-63 tool mount Tooleye 1 x 3 - jaw Chuck, diameter 210 mm 1 x 3 - jaw Chuck, diameter 170 mm Gantry loader Flex GL-100 C. High pressure cooling through spindle, 20 bar Chip conveyor CE mark

MAZAK INTEGREX turning/milling center 200Y Bu. 1999 Mazatrol fusion control Max Drehdurchm. 520 mm Max Schwingdurchm. 540 mm Maximum turning length 1,018 mm Bar passage 51 mm C-axis + angetr. Tools Y-axis +/-70 mm Distance between the top 500 mm Drive 30 kW Maximum main spindle spindle speed 5,000 rpm Maximum speed milling spindle 6,000 rpm Tool changer with 40 stations 3-jaw Chuck 200 mm Tool measuring arm Tailstock Chip conveyor Total connected load 31 kVA Machine dimensions 3.50 m x 2.10 m x 2.50 m Machine weight 6,800 kG 25 tool holder KM 36 duty hours approx. 36,000

Table size: 1000 x 490 mm traverse path x/y/z: 800/510/500 mm spindle retainer: ISO 40 ISA kl. / gr. Table/spindle distance: 120/620 mm spindle speeds: 40-6000 rpm number of tool stations: 22 pieces feeds: x/y 1-3200 / z 1-2000 mm / min rapid traverse: x/y 1-3.2, z 1-2 m / min. Supply: 380 V, 19 kW space: 2850 x 2150 x 2600 mm weight: 3800 kg

Technical data: -Drilling capacity in steel ST 60 25 mm -Spindle mount MT 3 8 spindle speed 100 2700 RPM - spindle stroke 130 mm -4 feeds 0.1-0.3 m / U -RADIUS 270 mm -Column diameter 115 mm -Boring Unit + table height adjustable with hand crank on rack -Table dimensions 350 mm -Drive: 400 V / 0.8 / 1.1 kW -Space requirement approx. B H 800 x 1850 X 900 mm -Weight approx. 250 kg

Winmax V10 X-axis: 1,067 mm Y-axis: 610 mm Iebtfb Tswt N Tgepmsic Z-axis: 610 mm Table size: 1,270 × 610 mm Tool holder: SK40 (DIN 69871) Max. speed: 12,000 rpm⁻¹ Drive power (S1/S6): approx. 15 / 22 kW IKZ (internal cooling) 20 bar Separate coolant tank with paper belt filter Rapid traverse X/Y/Z: 35 m/min (X/Y), 30 m/min (Z) Capacity: 30 tools (optionally 40) Changeover time: Tool-to-tool approx. 2 s Max. tool diameter: 80 mm (next to free space: up to 125 mm) Max. tool length: 300 mm Max. tool weight: 7 kg Machine weight: approx. 6,900 kg Space requirement (W × D × H): approx. 4,600 × 3,900 × 2,800 mm Spindle nose to table: 150 – 760 mm Table surface to floor: approx. 900 mm

X-axis: 730 mm Y-axis: 730 mm Z-axis: 740 mm NC Idex Table, 1° Table size: 500 × 500 mm Maximum table load: 500 kg Rapid traverse (X/Y/Z): up to 60 m/min (60,000 mm/min) Feed range: 1–60,000 mm/min Spindle nose height above table: approx. 70–810 mm Speed range: 35 – 15 000 rpm Spindle holder: BT 40 Spindle motor power: 30 kW Maximum torque: 176 mm Kobtfbswuku Uo Tpmodn Standard Magazine: 4 ́80 Slots Tool diameter: up to 95 mm (150 mm with free adjacent spaces) Max. tool weight: 12 kg Total connection: approx. 79.1 kVA Weight: approx. 11 350 kg Dimensions (L × W × H): approx. 4,650 mm × 2,600 mm × 3,000 mm

CNC multi-tasking lathe NAKAMURA SUPER NTX-S Reference No.: 18038 Mfg. year 2007 S/No. V300901 FANUC 16i-TB Luckbei-dialog system supercap Maximum turning diameter -Upper turret 390 mm -Lower turret 300 mm Maximum turning length 1,100 mm Max cash working capacity 65 mm Milling spindle AC 18.5/11 kW Milling spindle maximum speed 12,000 rpm Capto C6 Servo controlled B-axis, 230° Y-axis 160 mm ATC with 40 tools Main and sub spindle AC 22/18.5 kW Main and sub spindle maximum speed 4.500 rpm 12/24-station turret, all stations for driven tools Maximum speed of driven tools 3,600 rpm 2 off. 3-jawchuck 210 mm, SCHUNK Coolant tank 250 liters High pressure pumps Swarf conveyor 1 set of toolholders for lower turret -static 9, 3-driven weight 19,000 kg CE-mark

The machine is in good technical condition, a test run is possible by prior arrangement. OKUMA 5-axis vertical machining center MU-400VII with OSP-P300M-H – Tool magazine for 48 tools, BT40 (or Big Plus) – Tool breakage detection incl. automatic length measurement – Preparation for the function of automatic zero point shift (incl. software) – Collision avoidance system for 4-/5-axis milling centers – Coolant pump 0.8 kW instead of the standard version 0.25 kW – Flush cooling – Function for automatic zero point displacement incl. workpiece measurement, Renishaw OMP60 probe – Cutting edge control for 5-axis machining – Super NURBS Type A for 5-axis centers –Conveyor
