horizontal machining center used for sale

Technical data: Manufacturer: DMG MORI Model: CLX 450 V4 Year of manufacture: 2023 Control: SIEMENS Operate 4.7 on SLIMline® Multi-Touch (19\") Main spindle: A2-8, 17 / 25.5 kW, max. 4,000 rpm C-axis and Y-axis (±60 mm) 12-fold servo turret VDI 40 with 12 driven tool stations and 6 BT stations Max. bar passage: 80 mm Direct position measuring system in X and Y axes Hydraulically movable tailstock External Electronic Handwheel DMG MORI IoTconnector Special equipment: Hydraulic 3-jaw chuck SMW KNCS-N 225 with quick-change system (Ø66 mm passage) Automatic NC tailstock with programmable compression force (1.4–8.0 kN) incl. foot pedal High-pressure coolant system 12 bar with double filter system Coolant spray gun (5 bar) Mechanical oil mist separator AFS 600 (600 m³/h, filter class H13) Coolant/compressed air switchover via turret head DXF import for SIEMENS cont ...

control: SIEMENS - 840 D - - -: - - - - - - - - -: - - - - - - 5-axis simultaneous machining center | SPINNER - U 620 equipped with ITC, NC swivel rotary table, tool changer & chip conveyor. The machine is in a well-maintained condition. Technical data of the machine will follow soon. We ask for your understanding ! - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - #Tags: U620| U-620 The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

swing over bed: 1.050 mm Swing over cross slide: 825 mm max. working diameter: 825 x 2.500 mm control: FANUC main spindle speeds: 1.200 U/min CNC Turning- and Milling Center | HWACHEON - HI-TECH 850 YMC equipped with a turret for driven tools as well as C- and Y-axis, programmable steady rest and tailstock. The machine is in a well-maintained condition and can be inspected at any time under power. Please note that the technical details were added from comparable machines. We ask for your understanding ! - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - #Tags: HI TECH 850 | HI-TECH 850YMC | HITECH850YMC The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Loose 4th axle. Auction-ID: A1-40982-10

With Supply-station infeed. Video of full-working condition available. Dismantled for transport. Auction-ID: A1-40982-139

turning diameter: 376 mm turning length: 1245 mm control: FANUC i-Series turning diameter over bed: 376 mm x-travel: 230 mm z - travel: 1350 mm rapid travel x/y/z: 24/30 m/min main spindle speeds:: 2800 spindle motor: 35 / 26 kW max. torque on the spindle: 1613 Nm spindle passage: 102 mm total power requirement: 33,91 Kva weight of the machine ca.: 7 t dimensions of the machine ca.: 4,6 x 2,11 x 2,3 m Equipped with: - Fanuc i-Series CNC control - C-axis - 3-jaw chuck, 304 mm diameter - 12-station tool turret - Tailstock - Chip conveyor - CE Only 2,300 spindle hours The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

turning diameter: 700 mm turning length: 3074 mm control: Mazatrol Matrix Smooth X : 91 mm : JIS A2-11 : 4000 1/min spindle motor: 30 / 22 kW Positioning speed: 12000 1/min milling spindle drive: 24 / 22 kW : 845 mm : 430 mm : 3126 mm : -30 / +210 ° Feeds (X,z,u,w-axis): 360 ° : HSK 100 : 36 Rapid Travel X / Y / Z-Achse: 50 / 50 / 40 m/min tailstock quill taper MT: 5 total power requirement: 77,73 kVA weight of the machine ca.: 25,5 t dimensions of the machine ca.: 7,3 x 3,4 x 2,95 m - Mazatrol Smooth X CNC control - 5-axis lathe - 36-position tool changer - IKZ / spindle cooling - Standard tool set (HSK T100) included - C-axis 0.001° - Tailstock - Milling head with milling spindle speed of 12,000 rpm -- B-axis 240° (-30° / +210°) - Smw 5.1 fixed tailstock (range 85–350 mm) - Kitagawa 21 3-jaw chuck - Renishaw RMP60 wireless probe - Engraving function, thread cutting, thread star ...

Turning diameter: 920 mm Turning length: 6000 mm Control: Mazatrol Matrix Spindle bore diameter: 170 mm Spindle nose: A2-11 spindle motor: 45/37 kW spindle turning speed range: 35 - 1600 U/min Spindle nose sub spindle: Turning speed sub spindle: 35 - 1600 U/min Movement X-axis: 1025 mm Movement Y-axis: 650 mm Movement Z-axis: 6170 mm w-axis: 4816 mm B-Axis travel: +210 / -30 ° C-Axis indexing: 0,0001 ° Tool Taper: BT 50 Tools in tool magazine: 80 Milling head speed: 10000 1/min milling drive: 37 kW total power requirement: 120 kVA dimensions of the machine ca.: 13267 x 3,300 x 3,200 mm Total weight, approx.: 44 t The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

The machine is in good technical condition; testing is possible by prior arrangement. Spindle speed: 12,000 rpm. Travel ranges: Z 510 mm, Y 510 mm, X 835 mm. Feed rate: 30 m/min. Tool holder: SK 40. Tool magazine capacity: 30 stations. Table load capacity: 800 kg. Table dimensions: 1000 x 560 mm. Overall dimensions including chip removal system: approx. 4300 x 2500 mm (footprint). Machine weight: approx. 4450 kg. Coolant system with belt filter unit, 20 bar. Maintenance/repair history: -Tool changer adjustment: 11/2025 -Coolant rail: 11/2024 -Coaxial valve, power chain: 10/2024 -X-axis ball screw replacement, new motor belt, new lubrication dispenser: 10/2024 -HDD: 7/2023 -X-axis cover plate: 2/2023 -Rotary union: 4/2022 -Gripper set: 5/2022 -Spindle braking resistor: 5/2022 -Spindle refurbishment by Vopss: 10/2020

The machine is in good technical condition and available for testing by prior arrangement. It features a FANUC i control system, cast-iron construction, linear guideways, X/Y/Z axis travels of 1270/670/625 mm, a 1300 x 670 mm table with T-slots, a table load capacity of 1000 kg, and a 30-position tool changer. Extensive accessories included: 4th axis (rotary table), hydraulic vise, RENISHAW tool and workpiece probes, oil skimmer, 3-color signal light, belt-type chip conveyor, Filtermist 6002 mist collector, tool holders, etc.

The machine is in good technical condition and can be tested by prior arrangement. It is fully functional. It is equipped with a new tool magazine but comes without a workpiece probe, clamping fixtures, or tools.

As well as wall-mounted tool grinder Pick up is possible by appointment. After the auction closes, you will be contacted to make this appointment. Auction-ID: A1-50251-596

Technical data Max. turning diameter: approx. 430 mm Max. turning length: approx. 744 mm Circumferential diameter over bed: approx. 600 mm Circumferential diameter over slide: approx. 500 mm Max. rod diameter: approx. 65 mm Distance between main and counter spindle: approx. 975 mm Main spindle Speed: up to approx. 5,000 rpm Power: approx. 29 kW Torque: approx. 250 Nm Sub-spindle Speed: up to approx. 7,000 rpm Power: approx. 22 kW

We are pleased to offer the following CNC turning center: DOOSAN PUMA 400LMB Year: 2011 Serial No.: ML0136-004494 Specifications: 15” chuck Spindle bore: 132 mm / 5.197” Through drawbar: 116 mm / 4.56” Maximum work length: 2,028 mm / 80” Approximately 13,000 cutting hours Long-bed configuration Machine reported to be in very good condition

Total 11 pieces, unused, Item No: 22 470 020, 60°, further details see photos

turning diameter: 540 mm turning length: 1020 mm control: FANUC 18 i-TB swing diameter: mm bar diameter: 65 mm travel -x axis: 555 / 185 mm travel -y axis: 160 mm travel -z axis: 1095 mm travel -z axis (sub spindle): 1065 mm spindle speed:: 5000 / 5000 1/min spindle bore: 76 / 76 mm C-Axis: 360 x 0,001°/360 x 0,001° turret head: BMT 65P / 12 Pos. milling spindle turning speeds: 10000 U/min Driven Tools: 4.000 U/min b-axis: 240 ° rapid traverse X-axis: 24 m/min rapid traverse Z-axis: 24 m/min drive capacity - spindle motor: 22 / 22 kW voltage: 400 V toolpiece magazine: chain magazine: 40 Pos. tool taper: HSK-A 63 milling drive: 15 kW driven Tools: 5,5 kW total power requirement: 60 kVA weight of the machine ca.: 12,5 t dimensions of the machine ca.: 4,30 x 2,30 x 2,90 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

multitasking turning center, year 2006, CNC 180is-TB. Used machine. More info & price on IndustrialBuyer.

multitasking turning center, year 2010, CNC MSX-701 III (Fanuc 31i-T). Used machine. More info & price on IndustrialBuyer.

turning diameter:120 mm turning length:100 mm control:Fanuc Spindle 1 power:7,5 kW Spindle 1 RPM:4500 1/min Spindle 2 power:7,5 kW Spindle 2 RPM:4500 1/min Distance between spindle noses:600 mm Turret No.1 stations / rotary tools:15/15 Power rotary tools turret 1:2,7 kW RPM of rotary tools turret 1:4000 1/min Turret No.2 stations / rotary tools:15/15 Power rotary tools turret 2:2,7 kW RPM of rotary tools turret 2:4000 1/min Travel x/z turret 1:250 / 300 mm Travel x/z turret 2:250 / 920 mm Bar capacity spindle 1:51 mm Bar capacity spindle 2:51 mm power chuck:165 mm Spindle bore sp. 1:62 mm Spindle bore sp. 2:62 mm dimensions of the machine ca.:3700 x 2300 x 3000 mm weight of the machine ca.:5600 kg Used CNC-2-spindle CNC turning and milling center with gantry loader - 2x 15 station turret -automatic gantry loader with turnaround station. 14 station-magazin right side Max. Parts size Ø 12 ...

turning diameter:370 mm turning length:200 mm Spindle 1 RPM:4000 1/min control:Siemens 840 D Spindle 2 RPM:4000 1/min power capacity:L / R 18/24 kW max. torque on the spindle:630 nM C-Axis:0,001° Turret No.1 stations / rotary tools:12/12 VDI 40 Turret No.2 stations / rotary tools:12/12 VDI 40 turning speed range - milling:3000 1/min power capacity - milling spindle:8,8 kW torque rotary tools:28 Nm Bar capacity spindle 1:85 mm total power requirement:65 kVA weight of the machine ca.:13 t dimensions of the machine ca.:5,7x2,4x2,1 m Travel x1:260 mm Travel x2:260 mm Travel Y1:600 mm Travel y2:600 mm Power Chuck:2 x 250 mm manual tool eye:l & r High performance 6-axis subspindle CNC-Lathe with twin turren and rotating tools.

standard turning dia.:200 turning length:max. 810 mm control:MSX-701 MAPPS IV greates pass round over bed:800 mm Max. distance between centres:1130 mm max. turning diameter:320 mm max. workpiecediameter:300 mm bar material dia.:65 mm Traverse X-Axis 1:210 Traverse X-Axis 2:210 mm Traverse X-Axis 3:210 mm Traverse Y-Axis 1:110 (+65/-45) mm Traverse Y-Axis 2:110 (+45,/-65) mm Traverse Z-Axis 1:300 mm Traverse Z-Axis 3:300 mm Traverse Z-Axis 2:810 mm Traverse B-Axis:870 mm turning speed range - spindle:5.000 1/min Number of spindle speed ranges:2 . spindle nose:JIS A2-6 spindle bore:73 mm spindle bearing diameter:120 mm C-Axis:0,001 ° turning speed range - spindle:5.000 1/min spindle nose:JIS A2-6 spindle bore:73 mm bar material dia. max:65/52 mm spindle bearing diameter:120 mm C-Axis:0,001 ° Number of Turrets:3 . Number of tool stations:16 x 3=48 pos Schank height for square tool:20 mm D ...

turning diameter:640 / 400 mm turning length:1500 mm control:Siemens 840 D Powerline Travel turret No.1 (milling spindle) x/y/z:550 / 180 (±90) / 1585 mm Swivle angle milling spindle (B-axis):±120° interpol. ° Rapid traverse feeds turret 1 (milling head) x/y/z:40/24/60 m/min RPM milling spindle:12000 1/min power capacity - milling spindle:12 / 23 kW Torque of milling spindle:100 Nm Tool magazine for milling spindle (turret 1):120 HSK-A 63 Tool change time tool/tool, milling spindle:1,6 s Spindle 1 RPM:4000 1/min Spindle 1 power:36/ 45 kW Spindle 1 Torque:730 Nm Spindle 1 max. bar diameter:90 Spindle 2 RPM:4000 1/min Spindle 2 power:36 / 45 kW Spindle 2 torque:730 Nm Spindle 2 max. bar diameter:90 c-axis:0,001 ° Travel turret 2 x:225 mm Travel Turret 2 z:1595 mm RPM of rotary tools turret 2:4000 1/min no. of tools in turret 2:12 VDI 40 high-pressure pump:20 bar total power requiremen ...

turning diameter:500 mm turning length:1000 mm control:Siemens 840 D spindle:42 / 28 kW spindle turning speed - stepless:31 - 4000 1/min max. torque on the spindle:345 Nm c-axis:360000 x 0,001° feeds -stepless-:0 - 10000 mm/min rapid traverse:10000 mm/min turret stations / rotary tool stations:12/12 VDI 40 RPM of rotary tools:2000 1/min diameter of quill:90 mm quill stroke:80 mm tailstock quill taper ISO:SK 30 Tailstock Travel:600 mm Power rotary tools:3,5 kW :22,5 Nm Rotary tool holders:4 ax./ 4 rad. spindle passage:66 mm total power requirement:30 kW weight of the machine ca.:7,5 t dimensions of the machine ca.:8x 3 x 4 m

standard turning dia.:200 turning length:max. 810 mm control:MSX-701 MAPPS III greates pass round over bed:800 mm Max. distance between centres:1130 mm max. turning diameter:320 mm max. workpiecediameter:300 mm bar material dia.:65 mm Traverse X-Axis 1:210 Traverse X-Axis 2:210 mm Traverse X-Axis 3:210 mm Traverse Y-Axis 1:110 (+65/-45) mm Traverse Y-Axis 2:110 (+45,/-65) mm Traverse Z-Axis 1:300 mm Traverse Z-Axis 3:300 mm Traverse Z-Axis 2:810 mm Traverse B-Axis:870 mm turning speed range - spindle:5.000 1/min Number of spindle speed ranges:2 . spindle nose:JIS A2-6 spindle bore:73 mm spindle bearing diameter:120 mm C-Axis:0,001 ° turning speed range - spindle:5.000 1/min spindle nose:JIS A2-6 spindle bore:73 mm bar material dia. max:65/52 mm spindle bearing diameter:120 mm C-Axis:0,001 ° Number of Turrets:3 . Number of tool stations:16 x 3=48 pos Schank height for square tool:20 mm  ...

turning diameter:410 mm turning length:500 mm control:Fanuc 21i TB standard turning diameter:275 mm travel -x axis:277 mm travel -y axis:82 (±41) mm travel -z axis:500 mm Spindle 1 RPM:4500 1/min Spindle 1 Power:18,5/18,5/15 kW Spindle 1 max. bar diameter:65 mm turret stations / rotary tool stations:12/12 Power rotary tools:5,5 kW RPM of rotary tools:6000 1/min total power requirement:39,2 kVA weight of the machine ca.:6,2 t dimensions of the machine ca.:3,1 x 2,0 x 2,2 m collet chuck:Hainbuch High precision Turning and Milling Centre with Y-axis and robot loading. Stäubli Robot for shaft loading can be supplied. Machine was running with oil, not coolant. A fire extinguisher system is installed

max. turning diameter:350 mm turning length:1040 mm control:OSP E 100 L Fanuc greates pass round over bed:550 mm Max. distance between centres:1200 mm max. workpiecediameter:550 mm Traverse X-Axis 1:270 Traverse X-Axis 2:230 mm Traverse Y-Axis 1:120 (±60) mm Traverse Z-Axis 1:930 mm Traverse Z-Axis 2:920 mm Spindle 1 Power:22 / 15 kW Spindle 1 RPM:5000 1/min spindle nose:JIS A2-8 bar material dia.:65 mm C-Axis:0,001° Number of Turrets:2 Turret No.1 stations / rotary tools:12/12 VDI 40 Turret 1 tool RPM:4500 1/min Turret 1 power rotary tools:7.0 / 3,3 kW Turret No.2 stations / rotary tools:12/12 VDI 40 Turret 2 tool RPM:4500 1/min Turret 2 power rotary tools:7.0 / 3,3 kW rapid traverse X-axis:30 m/min rapid traverse Y-axis:26 m/min rapid traverse Z-axis:40 m/min total power requirement:33 kVA weight of the machine ca.:10 t dimensions of the machine ca.:7,0 x 2,3 x 2,3 m spindle load m ...

workpiece diameter:5-125 mm grinding depth:50-1000 mm clamping length:1000 mm total power requirement:1.9 KVA weight of the machine ca.:630 kg max. workpiece weight:100 kg Center Hole Grinding Machine. Workpiece must be rotated by machine during grinding

max. workpiece diameter:29 mm min. workpiece diameter:26 mm workpiece length:66 mm the system was originally delivered for the following workpiece sizes: diameter 26mm - 29mm length 65mm - 66mm Changing parts in the clamping device, handling, etc. would probably result in diameters of up to approx. Ø50mm Total length will probably be almost 400 mm possible with a few conversions. Also dependent on tool lengths, machining lengths on the component, etc. Workpiece: Piston pin Drawing number: WHT 000 718, WHT 000 718 A Workpiece dimensions (Ø, WxH): Ø26 x 66; Ø29 x 65 Length: 66 or 65 mm Material: 17Cr3 Quantity: xxx parts / year Cycle time: 5 sec. However, workpiece lengths up to 600mm are manageable. The machining diameter can be adjusted if the appropriate tools are available. The clamping station can currently only accommodate this product. However, this can be adapted by changing th ...

turning diameter:270 mm turning length:710 mm weight of the machine ca.:6,5 t max. swing diameter:590 mm with automatic loading and unloading system G300 with "spindle bore clamping capacity 90mm" in tailstock version The machine has no driven tools. The information in the circuit diagram refers to the rotary drive for indexing the turret, not to driven tools.

turning diameter:270 mm turning length:710 mm weight of the machine ca.:6,5 t max. swing diameter:590 mm with live tools:VDI40 Live tooling VDI40 with automatic loading and unloading system G300 with "spindle bore clamping capacity 90mm" in tailstock version Chip conveyor, belt filter press, hydraulic unit, as well as infeed and outfeed chain conveyor EWAP, with 33 pallets. The machine has no driven tools. The information in the circuit diagram refers to the rotary drive for indexing the turret, not to driven tools.

turning diameter:270 mm turning length:710 mm weight of the machine ca.:6,5 t max. swing diameter:590 mm with automatic loading and unloading system, chip conveyor G300 with "spindle bore clamping capacity 90mm" in tailstock version The machine has no driven tools. The information in the circuit diagram refers to the rotary drive for indexing the turret, not to driven tools.

turning diameter:120 mm turning length:650 mm weight of the machine ca.:11 t dimensions of the machine ca.:5,032 x 3,048 x 2,445 m Gildemeister MF Twin 65-II lathe with loading automation. This machine is suitable as a counter spindle machine for 4-axis machining on the main and counter spindles, complete machining (turning, drilling, milling, Y-axis, B-axis) of bar and shaft parts.

turning diameter:120 mm turning length:650 mm weight of the machine ca.:11 t dimensions of the machine ca.:5,032 x 3,048 x 2,445 m max. swing diameter:250 mm Gildemeister MF Twin 65-II lathe with loading automation. This machine is suitable as a counter spindle machine for 4-axis machining on the main and counter spindles, complete machining (turning, drilling, milling, Y-axis, B-axis) of bar and shaft parts.

turning diameter:200 mm turning length:600 mm capacity X-axis:190 mm capacity Z-axis:555 mm double spindle units: spindle distance:800 mm spindle drive:Links (40/100%ED): 18/14 kW spindle turning speed range:31-6300 U/min spindle drive:Rechts (40/100%ED): 18/14 kW spindle turning speed range:31-6300 U/min speeds of tool:2x12 Werkzeuge: 7/5 KW, 40-4200 U/min dimensions of the machine ca.:5,032 x 3,048 x 2,445 m weight of the machine ca.:6500 Kg Gildemeister MF Twin 65-II lathe with loading automation. This machine is suitable as a counter spindle machine for 4-axis machining on the main and counter spindles, complete machining (turning, drilling, milling, Y-axis, B-axis) of bar and shaft parts.

turning diameter:33 mm turning length:330 mm control: 840 total power requirement:20 kW weight of the machine ca.:6 t dimensions of the machine ca.:3850,2000,2100 m 17 axes 3 revolvers with the powered tools 1 gantry with the driven tools Main and counter spindle with C axes Barfeeder Machine On-time 58,133 hours

turning diameter over bed:350 mm turning diameter over slide rest:240 mm turning length:800 mm Spindle RPM:40 - 2000 in 8 Stufen 1/min total power requirement:3 kW Spindle bore:26 mm tailstock quill taper MT:MK 2 dimensions of the machine ca.:1,5 x 1,0 x 1,6 m weight of the machine ca.:1,9 t Very well maintened center lathe with accessories - 3-jaw, 4-jaw chuck - tailstock with center - 1 boring head - RAPID quick tool change device with 3 holder - saddle mounted steady rest - collant device - set of collets appr. 75% size B 32

turning diameter over bed:500 mm turning diameter over slide rest:310 mm turning length:1500 mm spindle turning speed range:7 - 710 U/min feed range:5,6 - 224 mm/min total power requirement:15 kW weight of the machine ca.:3,7 t dimensions of the machine ca.:2,9 x 1,4 x 1,6 m Machine with 2-axis digital readout - MULTIFIX quick tool change device - 3-jaw chuck

turning diameter over bed:1000 mm turning diameter over slide rest:750 mm turning length:3000 mm weight of the machine ca.:12 t dimensions of the machine ca.:6x2,5x1,8 m spindle bore:110 mm turning speed range:900 U/min Year:1986 Equipment: - Coolant device - 1 static steady rest - 1 rotating steady rest - Faceplate 1.000 mm - Digital display - Rapid traverse

turning diameter:220 mm turning length:- mm control:- distance between milling spindels:800 mm spindle speed max.:12.000 U/min daylight:66 mm machine weight ab.:11 t total power requirement:90 kVA Fanuc control Two turrets Two spindles Spindle bore 66 mm on both spindles Two Y-axes Parts gripper Hainbuch chuck on both spindles Tailstock function Chip conveyor Tool eye Short bar loader Tool holder package

turning diameter over bed:1000 mm turning diameter over slide rest:745 mm turning length:3000 mm turning speed range:4,5 - 900 U/min spindle bore:110 mm max. workpiece weight between centres:12500 kg total power requirement:30 kW weight of the machine ca.:9 t dimensions of the machine ca.:5,2 x 2,3 x 2 m 3-axes digital readout rapid feed, feed at upper support 350 mm 1 fixed steady face plate diameter 1000 mm coolant attachment

turning diameter:275 mm turning length:900 mm spindle passage:65 mm power capacity at 100 % load:25/20 kW spindle turning speed range:1 - 5000 U/min spindle diameter in front bearing:110 mm c-axis:1 - 500 U/min. number of workpiece supports:4 tool turret:1 x-axis:290 mm y-axis:165 mm z-axis:360 mm b-axis:360 ° rapid speed:18/30 m/min number of tools:2x2 + 2x2 number of driven tools:2x2 + 2x2 mm toolpiece turning speed range:8000 / 2000 U/min power capacity:25% ED 5,8 kW tool taper:TRAUB 60 tool turret:2/3/4 x-axis:170 mm z-axis:600/950 mm y-axis:+/- 60 mm rapid speed:18/15/30 m/min number of driven tools:10 mm toolpiece turning speed range:1 - 6000 U/min power capacity:25% ED 5,8 kW tool taper:DIN 69880 40 x 63 total power requirement:95 kW weight of the machine ca.:16 t dimensions of the machine ca.:10,0 x 3,5 x 3,0 m with CNC TRAUB TX 8i, Barloader TRAUB Stamag DNH61 / 3000, Main and  ...

turning diameter over bed:1450 mm turning diameter over slide rest:1000 mm turning length:8000 mm spindle bore:160 mm turning speed range:2,8 - 560 U/min bed width:850 mm faceplate diameter max.:1400 mm turning diameter in the gap:1800 mm length of gap:600 mm dimensions of the machine ca.:12 x 2 x 2,5 m with Digital Readout 2 fixed steadies dia 1070 mm chip conveyor

turning diameter over bed:400 mm turning diameter over slide rest:250 mm turning length:1000 mm max swing over gap:520 mm Height of centres:200 mm crossed path:230 mm bed width:218 mm main spindle bore:52 mm spindle size:MK 6 speeds::55-2000 U/min turning angle of tool post:90 grad tail stock:50 mm taper in tailstock:MK 4 threading metric:0,4-7 mm threading WHITWORTH:4-60 TPI total power requirement:2,2 kW dimensions of the machine ca.:1940 x 820 x 1545 mm weight of the machine ca.:750 kg tailstock quill:110 mm tapping modul:0,4-3 mm tapping diametral:8-84 Gang/Zoll
