horizontal lathe used for sale

cutting diameter: 520 mm saw band length: 6096 mm cutting width: 1,3 mm cutting range: 520x620 mm total power requirement: 6,578 kW weight of the machine ca.: 4 t dimensions of the machine ca.: 3,3 x 2,2 x 2,35 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

cutting diameter: 560 mm saw band length: 6000 mm cutting width: 750 mm table height: 590 mm : 560 mm Capacity 90° rectangular: 410 x 560 mm : 410 mm : 410 mm Capacity 45° rectangular: 410 x 560 mm speeds steplessly adjustable: 20 - 100 m/min dimensions of saw-band: 6000 x 41 x 1,3 mm total power requirement: 5,22 kW weight of the machine ca.: 2,045 t dimensions of the machine ca.: 3,4 x 1,0 x 2,05 m Horizontal band saw. The bow is made of heavy steel and the two pillars constitute a strong and rigid saw frame. This ensures high accuracy when cutting. The machines are fitted with an integrated coolant pump that supplies oolant to both guide assemblies. Blade guides with rollers and carbide pads provide precise support for the blade. The machines switch off automatically at the end of the cutting proces and the saw arm is lifted hydraulically. ?inverter ?hydromechanic blade tension ?swa ...

cutting diameter: 230 mm saw band length: 2730 x 27 x 0,9 mm cutting width: 240 mm : 230 x 230 mm capacity 90 degrees: flat: 240 x 230 mm speeds steplessly adjustable: 35 - 70 m/min table height: 590 mm total power requirement: 2,0 kW weight of the machine ca.: 590 kg dimensions of the machine ca.: 1,7 x 0,8 x 1,16 The HU 230 DG is a popular sawing machine and is heavily sold, due to its favourable price-quality relation. With adjustable sawing pressure, coolant pump with reservoir and electrical-mechanical saw blade tension adjustment, this machine is ideal for large workshops and small production lines. separate control panel sawing pressure hydraulically adjustable with cooling system easily moveable with stop gear wheel driven left – right mitre sawing The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

cutting diameter: 330 mm saw band length: 3010x27x0,9 mm cutting width: 330 mm work height max.: 830 mm band speed: 35/70 m/min Capacity 90° rectangular: 330x140 mm capacity 90 degrees: round: 260 mm capacity 45 degrees: round: 200 mm : 120 mm : 190x190 mm total power requirement: 1,8 kW weight of the machine ca.: 0,400 t dimensions of the machine ca.: 1,50 x 1,39 x 1,79 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

spindle diameter: 225 mm x-travel: 8000 mm y-travel: 5600 mm z-travel: 2100 mm w-axis: 1400 mm spindle turning speed - stepless: 0-650 U/min spindle taper ISO: 60 feed stepless: 5 - 3000 mm/min rapid traverse: 5 m/min weight of the machine ca.: 150 t dimensions of the machine ca.: 12 x 5 x 8 m total power requirement: 120 kW Ram type horizontal boring machine was reconditioned and modernized in 2006, original yom was 1972. Control Siemens 840 C. Machine will come with tools and a vertical milling head. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 630 mm y-travel: 550 mm z-travel: 500 mm total power requirement: 10 kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

spindle diameter: 130 mm x-travel: 7000 mm y-travel: 2000 mm taper ISO: 50 w-axis: 1100 mm z-axis: 350 mm voltage: 400 V total power requirement: 30 kW weight of the machine ca.: . t dimensions of the machine ca.: . m Universal milling head Heidenhain D.R.O. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

grinding length: 750 mm grinding width: 500 mm workpiece height: 500 mm total power requirement: 50 kW weight of the machine ca.: 5000 t Grinding length, max. 750 mm Grinding width, max. 500 mm Cross movement of grinding slide 450 mm Working height under grinding wheel, max. 500 mm Grinding wheel size Æ 400 x 100 mm Grinding wheel speeds, infinitely variable 300-3,000 rpm Table speed, hydr. 0 - 30 m/min Table speed, creep feed 0.02 - 1,000 mm/min Vertical infeed, infinitely variable 0.002 - 0.03 mm/stroke Grinding spindle drive, max. 32 kW Total electrical load, approx. 50 kW - 380 V - 50 Hz Weight approx. 5,000 kg Accessories / Special Features Creep feed: Electro-mechanical feed (but also hydraulic table movement), with digital display, programable by cam limit switches. Infinit ...

GeneralHorizontal Machining Centre; Control: 3D Control Siemens 840D solutionline Technical DataFeed rate longitudinal/transverse/vertical60000/60000/60000 mm/minRapid traverse longitudinal/transverse/vertical60/60/60 m/minWorking area 1Longitudinal700 mmCross700 mmVertical700 mmMiscellaneousClamping SystemHSK-A 63 CabineFull protection cabinMain driveDrive power (100% DC) 20 kWDrive power (40% DC) 20 kWSpeed range - 12000 rpmSpindle taper HSK-A 63NC rotary table with pallet changerType of Measuring system Direct measuring systemTable surface 500 x 500 mmCentre bore 50 mmMaximum load (table centre) 600 Kg4. Axes (swivelling range) 360 x 0,001 degreeRotation speed max.4. Axis 40 rpmDistance between T-Slots 100 mmNumber of Slots 5Slot width 14 mmSpindle taper HSK-A 63Spindle taper for HSK-A 63 to DIN 69893 (incl. adaptation working spindle, tool changer and tool magazine)Tool magazine, cha ...

GeneralHorizontal Machining Centre; Control: 3D Control Siemens 840D solutionline Technical DataFeed rate longitudinal/transverse/vertical60000/60000/60000 mm/minRapid traverse longitudinal/transverse/vertical60/60/60 m/minWorking area 1Longitudinal700 mmCross700 mmVertical700 mmMiscellaneousClamping SystemHSK-A 63 CabineFull protection cabinMain driveDrive power (100% DC) 20 kWDrive power (40% DC) 20 kWSpeed range - 12000 rpmSpindle taper HSK-A 63NC rotary table with pallet changerType of Measuring system Direct measuring systemTable surface 500 x 500 mmCentre bore 50 mmMaximum load (table centre) 600 Kg4. Axes (swivelling range) 360 x 0,001 degreeRotation speed max.4. Axis 40 rpmDistance between T-Slots 100 mmNumber of Slots 5Slot width 14 mmSpindle taper HSK-A 63Spindle taper for HSK-A 63 to DIN 69893 (incl. adaptation working spindle, tool changer and tool magazine)Tool magazine, cha ...

GeneralHorizontal Machining Centre; Control: 3D Control Siemens 840D solutionline Technical DataFeed rate longitudinal/transverse/vertical60000/60000/60000 mm/minRapid traverse longitudinal/transverse/vertical60/60/60 m/minWorking area 1Longitudinal700 mmCross700 mmVertical700 mmMiscellaneousClamping SystemHSK-A 63 CabineFull protection cabinMain driveDrive power (100% DC) 20 kWDrive power (40% DC) 20 kWSpeed range - 12000 rpmSpindle taper HSK-A 63NC rotary table with pallet changerType of Measuring system Direct measuring systemTable surface 500 x 500 mmCentre bore 50 mmMaximum load (table centre) 600 KgRotation speed max.4. Axis 40 rpmDistance between T-Slots 100 mmNumber of Slots 5Slot width 14 mm4. Axes (swivelling range) 360 x 0,001 degreeSpindle taper HSK-A 63Spindle taper for HSK-A 63 to DIN 69893 (incl. adaptation working spindle, tool changer and tool magazine)Tool magazine, cha ...

GeneralHorizontal Machining Centre; Control: 3D Control Siemens 840D solutionline Technical DataFeed rate longitudinal/transverse/vertical60000/60000/60000 mm/minRapid traverse longitudinal/transverse/vertical60/60/60 m/minWorking area 1Longitudinal700 mmCross700 mmVertical700 mmMiscellaneousClamping SystemHSK-A 63 CabineFull protection cabinMain driveDrive power (100% DC) 20 kWDrive power (40% DC) 20 kWSpeed range - 12000 rpmSpindle taper HSK-A 63NC rotary table with pallet changerType of Measuring system Direct measuring systemTable surface 500 x 500 mmCentre bore 50 mmMaximum load (table centre) 600 KgRotation speed max.4. Axis 40 rpmDistance between T-Slots 100 mmNumber of Slots 5Slot width 14 mm4. Axes (swivelling range) 360 x 0,001 degreeSpindle taper HSK-A 63Spindle taper for HSK-A 63 to DIN 69893 (incl. adaptation working spindle, tool changer and tool magazine)Tool magazine, cha ...

spindle diameter: 130 mm x-travel: 3000 mm y-travel: 2000 mm total power requirement: 4,5 kW weight of the machine ca.: 30 t Spindle Ø 130 mm Spindle taper SK 50 Working range: X = column, longitudinal 3,000 mm Y = headstock, vertical 2,000 mm Z = spindle stroke 1,000 mm Lower table 3,300 x 2.400 mm Max. weight on table 10 tons/m² Min./ max position of work spindle above table 770 / 2,770 mm Feeds 0.9 - 2,000 mm/min Quick feed for headstock and column 5,000 mm/min Quill feed 0.5 - 1,200 mm/min Speed range, partially infinitely variable 4.5 - 1,250 rpm Weight, approx. 30,000 kg Accessories / Special Features HEIDENHAIN Digital Display for 3 axes. Hardened guideways. Ball screw spindles. Infinitely variable spindle speeds and feeds. Feeds can be individually driven with motor. Moving operating platform. Hanging control panel. Manual operati ...

x-travel: 800 mm y-travel: 630 mm z-travel: 560 mm total power requirement: 60 kW weight of the machine ca.: 12.5 t dimensions of the machine ca.: m H E L L E R (Germany) 5 Axis - CNC Controlled Horizontal Machining Centre Model FST- MC 160 / 800 / E Year 1998 Only approx. 500 hours in operation _______________________________________________________ Working range: Longitudinal stroke X axis 800 mm Vertical stroke Y axis 630 mm Cross stroke Z axis 560 mm NC rotary table Tilting A axis 180 ° Turning B axis 360 ° Size of pallet, approx. 250 x 620 mm Tool holder HSK 63A Spindle speeds, infinitely variable 63 - 20,000 rpm Feeds / quick feeds XYZ 1 - 70,000 mm/min Spindle drive 24 kW Total electrical load, approx. 60 kW - 400 V - 50 Hz Weight, approx. 12,500 kg Accessories / Special Features 5-Axis SIEMENS CNC Path Control, Mode ...

cutting diameter: 320 mm saw band length: 4670 mm cutting width: 580 mm total power requirement: 7,4 kW weight of the machine ca.: 3 t Sawing range, circular, max. 100 - 320 mm vertical, max. 100/100 x 320/460 mm Length of cut, min./max. 0 - 580 mm Distance from column to saw band, max. 690 mm Cutting speed, infinitely variable 16 - 160 m/min Dimensions of saw band, length x Ø approx. 4,670 x 38 mm Length of remaining pieces, automatic/single cut 100/10 mm Saw blade drive, approx. 4.4 kW Total electrical load, approx. 7.4 kW - 380 V - 50 Hz Weight, approx. 3,000 kg Accessories / Special Features: Infinitely variable speeds of saw blade motor via servo motor and STOEBER drive. Display of cutting speed on control panel. Infinitely variable settings of sawing feed with display of the current cutting speed. Workpiece counter: Number of workpieces can be preset. Selection swi ...

Capacity round maximum diameter: 335 mm Angle degrees maximum: 0 Capacity square: 0 mm Workpiece height: 0 mm Workpiece width: 0 mm Capacity rectangle: 0 mm MACH-id    3721 MAKE         MEBA TYPE           335 DGA 1000 YEAR          2001 SPECIFICATIONS Bandsaw / Circelblade / Automat    Bandsaw Mitre  Cutting Angle L / R Degrees    Angle cutting L / R 45 / 30 Gr. Cutting capacity 90 ˚ Ø   335 mm Cuttting capacity 90 ˚ Flatt    500 x 335 mm Cutting capacity 45˚ Ø   330 mm Cuttting capacity 45 ˚ Flatt       320 x 335 mm blade dimensions    4400 x 34 x 1,1 mm roller conveyor / push up / measuring Push upCutting speed M/min      18 - 115 M/min DIMENSIONS Length   ...

spindle diameter: 125 mm x-travel: 2360 mm y-travel: 1570 mm z-travel: 780 mm w-axis: 410 mm total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

closing pressure: 11000 kN clamping plate: . mm distance between columns: . mm total power requirement: kW weight of the machine ca.: 45 t dimensions of the machine ca.: m Mold spraying machine available Manufacturer Acheson Model DAG 1000 FCT 2TB Year of construction 2002 Foundry robot available Manufacturer ABB Model IRB 6600 Control S4C-Plus Built in 2003 Deburring press available Manufacturer rice Model SEP 9-65 Built in 1988 Delivery time October 2018 An oven can optionally be purchased: Manufacturer Westofen Model W 90 SMC Capacity 900 kg Built in 1988 The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Rounds: 105 mm Squares: 0 mm Flats: 0 mm Flats on edge: 0 mm Angles: 0 mm (1) horizontal / (2) vertical: 1   MACH-id      3629 MAKE           PBT Swiss TYPE            35 YEAR          2004 SPECIFICATIONS Hydraulic / Mechanical    Hydraulic    Horizontal / Vertical / or   H + V     Horizontal Shaft Diameter ø  105 mm Roll diamter ø    Stroke = 390 mm Shaft length    Adj = 360 - 1100 mm Working speed M/Min.    1 - 16 M/Min Resistance moment Cm 3  Torq = 3000 Nm Cm3 Capacity IPN   IPE 160 x R = 1000 mm Capacity Tube walltickness x Ø114 x R = 300 mm Power   11 DIMENSIONS Length    1850 mm Width     1600 mm Height  &nbs ...

spindle diameter: 130 mm x-travel: 7700 mm y-travel: 1500 mm Control: Siemens type: Sinumerik 840 C spindle taper ISO: 130 turning speeds: 1490 U/min power capacity: 45 kW chip conveyor: Angle head: Angle head: Plate area: 9000x6000 mm workpiece weight: 100 t One direction thrust bearing: total power requirement: kW dimensions of the machine ca.: m Panel is optional and we charged extra The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Pallet length: 450 mm Pallet width: 450 mm Longitudinal X: 550 mm Cross Y: 510 mm Vertical Z: 500 mm Number of pallets: 0   Positions ATC: 24   CNC Brand: Fanuc CNC Model: Series 0 - MD MACH-id     3624 MAKE          Yang Eagle TYPE            SMH 450 YEAR           2000 SPECIFICATIONS X - Travel       550 mm Y - Travel       510 mm Z - Travel        500 mm Controll      Fanuc Series 0- MD Table    Length x Width    450 x 450 mm Table load in kG    350 Kg Spindle Taper   ISO 40 kW power on spindle   7.5 kW Spindle speeds / ranges    6000 Rpm ATC tool changer   24 DIMENSIONS Length    2.630 mm Width&n ...

spindle diameter: 225 mm x-travel: 8000 mm y-travel: 5600 mm z-travel: 2100 mm w-axis: 1400 mm spindle turning speed - stepless: 0-650 U/min spindle taper ISO: 60 feed stepless: 5 - 3000 mm/min rapid traverse: 5 m/min weight of the machine ca.: 150 t dimensions of the machine ca.: 12 x 5 x 8 m total power requirement: 120 kW Ram type horizontal boring machine was reconditioned and modernized in 2006, original yom was 1972. Control Siemens 840 C. Machine will come with tools and a vertical milling head. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Capacity round maximum diameter: 300 mm Angle degrees maximum: 330 Capacity square: 0 mm Workpiece height: 0 mm Workpiece width: 0 mm Capacity rectangle: 0 mm SPECIFICATIONS Bandsaw / Circelblade / Automat   Bandsaw automat Angle L / R Degrees   90 Gr. Cutting capacity 90 ˚ Ø   300 mm Cuttting capacity 90 ˚ Flatt  330 x 300 mm blade dimensions   4670 x 41 x 1,3 mm roller conveyor / push up / measuring AutomatCutting speed M/min  19 - 95 M/min DIMENSIONS Length   1880 mm Width   2140 mm Height   1700 mm

cutting diameter: 360 mm saw band length: 5000 mm cutting width: 610 mm speed: 20 -100 m/min main drive: 3 kW hydraulic pump: 0,55 kW coolant pump: 0,12 kW dimensions of saw-band: 5000 x 34 x 1,1 mm : 360 mm : 360 x 360 mm Capacity 90° rectangular: 610 x 360 mm : 360 x 360 mm : 360 x 360 mm Capacity 45° rectangular: 490 x 360 mm : 360 mm : 360 mm : 610 x 360 mm capacity 60 degrees: round: 3,67 mm capacity 60 degrees: square: 360 x 360 mm capacity 60 degrees: flat: 360 x 360 mm band speed: stufenlos 20 - 100 m/min total power requirement: 3,67 kW weight of the machine ca.: 1,47 t dimensions of the machine ca.: 2,75 x 1,21 x 1,87 m This twin-pillar horizontal bandsaws have been designed to provide a low cost, compact and rigid machine.The bow is constructed in heavy gauge steel. It is mounted at two chromed and grinded pillars offering a strong rigid sawframe. This design provides a high ...

cutting diameter: 810 mm saw band length: 8400 mm cutting width: 910 mm capacity 90 degrees: square: 770 x 770 mm : 910 x 750 mm : 600 mm : 600 mm Capacity 45° rectangular: 760 x 600 mm capacity 60 degrees: round: 360 mm capacity 60 degrees: square: 360 mm capacity 60 degrees: flat: 750 x 360 mm : 760 mm : 740 mm : 750 x 740 mm speeds steplessly adjustable: 20 - 100 m/min table height: 725 mm dimensions of saw-band: 8400 x 41 x 1,3 mm total power requirement: 5,62 kW weight of the machine ca.: 4,05 t dimensions of the machine ca.: 4,02 x 1,6 x 2,45 m Product Description PRODUCT DESCRIPTION Two way powered mitre with NC angle setting Features ?Powered mitre setting with NC control ?Mitre cuts to +/-60 deg with +/-0.1 deg tolerance ?5-deg inclined blade for optimum cutting performance ?Hydraulic blade tensioning ?Blade deviation control with auto shut off ?Cutting feed & pressure regulati ...

cutting diameter: 330 mm saw band length: 4160 x 34 x 1,1 mm cutting width: 500 mm : 320 mm Capacity 90° rectangular: 500 x 320 mm speeds steplessly adjustable: 20 - 100 m/min table height: 640 mm total power requirement: 3,0 kW weight of the machine ca.: 860 kg dimensions of the machine ca.: 2,10 x 0,85 x 1,30 m On semi-automatic models the saw arm is lifted up automatically after the sawing cycle has finished. inverter hydraulic clamping hydraulic saw blade tension adjustment automatic stop ?material transport system The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

cutting diameter: 320 mm saw band length: 3660 x 27 x 0,9 mm cutting width: 300 mm : 300 x 300 mm Capacity 90° rectangular: 320 x 300 mm speeds steplessly adjustable: 20 - 100 m/min work height max.: 640 mm total power requirement: 2,9 kW weight of the machine ca.: 765 kg dimensions of the machine ca.: 1,9 x 0,85 x 1,3 m after the sawing cycle has finished. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Capacity round maximum diameter: 300 mm Angle degrees maximum: 0 Capacity square: 0 mm Workpiece height: 0 mm Workpiece width: 0 mm Capacity rectangle: 0 mm MACH-id  3557 MAKE   Muller Germany TYPE   HBA 400 S YEAR   10 / 2003 SPECIFICATIONS Bandsaw / Circelblade / Automat    Bandsaw automat Angle L / R Degrees   90 Gr Cutting capacity 90 ˚ Ø   300 mm Cuttting capacity 90 ˚ Flatt   400 x 320 mm blade dimensions   4400 x 34 x 1,1 mm Cutting speed M/min15 - 105 M/min DIMENSIONS Length    1800 mm Width    2250 mm Height   1500 mm

cutting diameter: 320 mm saw band length: 3660 x 27 x 0,9 mm cutting width: 350 mm Capacity 90° rectangular: 350 x 320 mm : 320 mm : 260 mm : 180 mm : 250 x 180 mm : 160 mm : 150 x 150 mm speeds steplessly adjustable: 20 - 100 m/min : 180 x 180 mm work height max.: 740 mm Control: total power requirement: 3,42 kW weight of the machine ca.: 2,31 t dimensions of the machine ca.: 2100 x 2100 x 1810 m On semi-automatic models the saw arm is lifted up automatically after the sawing cycle has finished. inverter hydraulic clamping hydraulic saw blade tension adjustment automatic stop ?material transport system The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

speed: 35 - 70 m/min cutting diameter: 230 mm saw band length: 2720 x 27 x 0,9 mm cutting width: 130 mm cutting capacity - flat: 90° / 320 x 130 mm cutting capacity - round: 90° / 230 mm cutting capacity - square: 90° / 230 x 230 mm cutting capacity - flat: 45° / R 220x60 /L 230x140 mm cutting capacity - round: 45° / R 180 / L 220 mm cutting capacity - square: 45° / R 150 / L 190 mm cutting capacity - flat: 60° / 120 x 105 mm cutting capacity - round: 60° /120 mm cutting capacity - square: 60° / 105 mm total power requirement: 1,0 - 1,5 kW weight of the machine ca.: 390 kg dimensions of the machine ca.: 1,35 x 0,9 x 1,3 m The HU 230 DG is a popular sawing machine and is heavily sold, due to its favourable price-quality relation. With adjustable sawing pressure, coolant pump with reservoir and electrical-mechanical saw blade tension adjustment, this machine is ideal for large wor ...

Rounds: 40 mm Squares: 0 mm Flats: 0 mm Flats on edge: 0 mm Angles: 0 mm (1) horizontal / (2) vertical: 1   MACH-id  356 MAKE  PBT Swiss TYPE   ARKUS 12 + PC 200 YEAR   1999 SPECIFICATIONS Hydraulic / Mechanical  Hydraulic Horizontal / Vertical / or H + V   Horizontal Shaft Diameter ø  40 mm Shaft length  130 mm Working speed M/Min.  1 - 32 M/Min Resistance moment Cm   3500 Nm Cm3 Capacity IPNIPE 80 x R 500 mm Capacity HEBUNP 80 x R 400 mm Capacity Tube walltickness x Ø  2" x R 300 mm Capacity Flatt  70 x 12 x R 300 mm Power  3 x 0,37 kW DIMENSIONS Length   1125 mm Width   1000 mm Height  1200 mm

cutting diameter: 380 mm saw band length: 4800 x 34 x 1,1 mm cutting width: 430 mm : 380 mm Capacity 90° rectangular: 430 x 380 mm speeds steplessly adjustable: 20 - 100 m/min total power requirement: 4,2 kW weight of the machine ca.: 1,34 t dimensions of the machine ca.: 2,9 x 0,95 x 1,66 m Fully automatic band saw for cutting solid material, tubes and profiles of steel, cast-iron, light and non ferrous materials, at 90°. Entirely made of steel. The rear jaw of the hydraulic vice has a number of hardened rollers that are turned by an electric motor. The front jaw consist of a number of free running rollers. Once the work piece is clamped between the rollers no further clamping is needed. The material is fed through the vice to the material stop which contains a micro-switch controlling the feed motor. A counter controls the number of cuts. Should the blade brake the machines stop auto ...

Capacity round maximum diameter: 400 mm Angle degrees maximum: 0 Capacity square: 0 mm Workpiece height: 0 mm Workpiece width: 0 mm Capacity rectangle: 0 mm MACH-id  3509 MAKE   Kasto Germany TYPE   Twin A4 YEAR  2006 SPECIFICATIONS Bandsaw / Circelblade / Automat  Bandsaw Angle L / R Degrees   0 Gr / Straight cutting Cutting capacity 90 ˚ Ø  400 mm Cuttting capacity 90 ˚ Flatt  400 x 400 mm blade dimensions5700 x 41 x 1.3 mm Cutting speed M/min   20 - 110 M/min DIMENSIONS Length   2980 mm Width   2700 mm Height  2200 mm

Capacity round maximum diameter: 810 mm Angle degrees maximum: 480 Capacity square: 0 mm Workpiece height: 0 mm Workpiece width: 0 mm Capacity rectangle: 0 mm MACH-id   3542 MERK  Knuth Germany TYPE  HB 810 L YEAR   2008 SPECIFICATIES  Circel / Band zaagVol / Half automaat  Bandsaw Verstek zagen links en rechts ˚Graden  ANgle cutting 45 Gr .Capaciteit bij 90 ˚ Graden rond Ø  810 mm Capaciteit bij 90 ˚ Graden plat  810 x 850 mm Capaciteit bij 45 ˚ Graden rond Ø  810 mm Capaciteit bij 45 ˚ Graden plat  480 x 850 mm Zaag blad / band afmeting  8200 x 41 x 1,3 mm Zaag snelheid M/Min. 20 - 100 M/min AFMETINGEN Lengte  3900 mm Breedte  1200 mm Hoogte 3350 mm

cutting diameter: 320 mm saw band length: 3660 x 27 x 0,9 mm cutting width: 420 mm : 320 x 320 mm Capacity 90° rectangular: 420 x 200 mm : 280 mm : 260 x 260 mm Capacity 45° rectangular: 280 x 200 mm cutting speed: 20 - 100 m/min work height max.: 640 mm total power requirement: kW weight of the machine ca.: 1,62 t dimensions of the machine ca.: 1,8 x 0,82 x 1,19 m This bandsaw have been designed to give a low cost compact and rugged machines.Constructed in heavy gauge steel, it offers a strong rigid sawframe, providing a high degree of accurancy when cutting. The machines are fitted with a removable coolant tank incorporating a submerged electric coolant pump which supplies coolant to both guide assemblies. These models can cope with most types of material.Blade guides with rollers and carbide pads provide precise support for the blade. Thermal overload and no-volt release are standar ...

cutting diameter: 350 mm saw band length: 4160 mm cutting width: 400 mm : 350 mm : 350 x 350 mm Capacity 90° rectangular: 400 x 350 mm speed: 20 -100 m/min main drive: 2,2 kW hydraulic pump: 0,37 kW coolant pump: 0,12 kW dimensions of saw-band: 4160 x 34 x 1,1 mm work height max.: 860 mm total power requirement: 2,9 kW weight of the machine ca.: 1030 kg dimensions of the machine ca.: 2,23 x 0,88 x 1,89 m Description: • Fully automatic miter band saw for sawing thick-walled Profiles and solid materials • Motorized roll feed of the material with electrical contact stop • Delta touch screen controls • Miter cutting, up to 45 ° • 1 program with 10 steps • Length accuracy 0.5 mm The feed length of the material is manually adjustable via an Microswitches selected that • Robustly constructed monoblock saw frame with hydraulic vertical movement and linear guide • Rapid advanc ...

cutting diameter: 650 mm saw band length: 8400 mm cutting width: 1000 mm capacity 90 degrees: square: 600 x 600 mm : 1000 x 600 mm capacity 45 degrees: round: 650 mm : 600 x 600 mm : 660 x 600 mm capacity 60 degrees: round: 440 mm capacity 60 degrees: square: 440 x 440 mm : 440 x 600 mm : 650 mm : 600 mm : 840 x 600 mm table height: 880 mm speeds steplessly adjustable: 20 - 100 m/min dimensions of saw-band: 8400 x 54 x 1,6 mm total power requirement: 12 kW weight of the machine ca.: 6,25 t dimensions of the machine ca.: 4,75 x 2,27 x 2,63 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

cutting diameter: 150 mm saw band length: 1735 x 13 x 0,9 mm cutting width: 180 mm capacity 60 degrees: round: 70 mm cutting range: 125 mm capacity 45 degrees: flat: 150 x 125 mm capacity 90 degrees: flat: 150 x 180 mm Working height: 870 mm total power requirement: 0,37 kW weight of the machine ca.: 62 kg dimensions of the machine ca.: 1640 x 400 x 950 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Pallet length: 0 mm Pallet width: 0 mm Longitudinal X: 1600 mm Cross Y: 1050 mm Vertical Z: 1020 mm Number of pallets: 0   Positions ATC: 120   CNC Brand: Siemens CNC Model: 840 D SPECIFICATIONSX - Travel  1600 mm Y - Travel  1050 mm Z - Travel  1020 mm W - Travel  600 mm bed / plano / portal / moving column  HMCControll Siemens 840D Table Length x Width  1000 x 1000 mm Table load in kG  2500 Kg Spindle Taper  Bt50   kW power on spindle  30/40 kW Spindle speeds / ranges  3000 Rpm ATC tool changer  120 Coolant true spindle / Bar  20 Bar Number off controlled axis 5

cutting diameter: 170 mm saw band length: 2035 x 20 x 0,9 mm cutting width: 130 mm cutting speed: 30 80 m/min : 130 mm : 130 x 130 mm capacity 60 degrees: round: 75 mm capacity 60 degrees: square: 75 x 75 mm : 170 mm : 166 x 166 mm weight of the machine ca.: 184 kg Compact band saw with variable speed. Including stand and cooling system. No slack due to special construction and rigid saw arm. Adjustable blade tension. Features: ?supplied with bi-metal saw blade material stop The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

cutting diameter: 170 mm saw band length: 2085 x 20 x 0,9 mm cutting width: 180 mm cutting speed: 35 - 70 m/min : 110 mm : 90 x 90 mm capacity 60 degrees: round: 70 mm capacity 60 degrees: square: 70 x 70 mm : 185 mm : 180 x 180 mm drive capacity - workpiece: 0,75 kW range L-W-H: 1000 x 600 x 1500 mm weight of the machine ca.: 195 kg Sawing machine with base, European design. This machine is used for making small cuts. The saw blade tension can be adjusted manually. Quick-acting clamp. No vibrations due to heavy duty saw arm. The machine has a 2-speed motor, saw blade guide bearings. The sawing pressure can be adjusted through a hydraulic cylinder. Features: adjustable sawing pressure automatic stop with cooling system eccentric quick-acting clamp separate metal control panel 2-speed motor precision adjustment of the runners with material stop switch controlled saw blade cover gear whee ...

Pallet length: 0 mm Pallet width: 0 mm Longitudinal X: 1600 mm Cross Y: 1050 mm Vertical Z: 1020 mm Number of pallets: 0   Positions ATC: 120   CNC Brand: Siemens CNC Model: 840 D SPECIFICATIONS X - Travel   1600 mm Y - Travel  1050 mm Z - Travel   1020 mm W - Travel   600 mm bed / plano / portal / moving column HMC     Controll   Siemens 840D Table Length x Width   1000 x 1000 mm Table load in   kG   2500 Kg Spindle Taper   Bt50   kW power on spindle  30/40 kW Spindle speeds / ranges  3000 Rpm ATC tool changer   120 Coolant true spindle / Bar   20 Bar Number off controlled axis  5

cutting diameter: 270 mm saw band length: 3160 x 27 x 0,9 mm cutting width: 350 mm work height max.: 910 mm speed: 35 - 70 m/min : 270 mm Capacity 90° rectangular: 350 x 220 mm : 210 mm Capacity 45° rectangular: 270 x 210 mm : 180 mm capacity 60 degrees: round: 150 R mm capacity 60 degrees: square: 100 R mm total power requirement: 1,5 kW weight of the machine ca.: 465 kg dimensions of the machine ca.: 1750 x 770 x 1460 mm The HU 230 DG is a popular sawing machine and is heavily sold, due to its favourable price-quality relation. With adjustable sawing pressure, coolant pump with reservoir and electrical-mechanical saw blade tension adjustment, this machine is ideal for large workshops and small production lines. separate control panel sawing pressure hydraulically adjustable with cooling system easily moveable with stop gear wheel driven left – right mitre sawing The data for this ...

pressure: 300 t stroke: 450 mm throat: 450 mm work speed: 2,1 m/min ajustment speed: 10 mm/sec return speed: 16 mm/sec pressure: 320 bar diameter of piston: 60 mm opening stroke: 900 mm table-size: hinten / back 2500 x 750 mm Table dimensions: Main 750 x 750 mm total power requirement: 7,5 kW weight of the machine ca.: 15,3 t dimensions of the machine ca.: 3,35 x 2,5 x 1,6 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

cutting diameter: 260 mm saw band length: 2880 x 27 x 0,9 mm cutting width: 300 mm band speed: 35 / 70 m/min : 260 mm : 185 mm : 300 x 185 mm : 240 mm : 185 mm : 185 x 110 mm capacity 60 degrees: round: mm capacity 60 degrees: flat: 105 mm capacity 60 degrees: square: 105 mm work height max.: 900 mm total power requirement: 1/1,4 kW weight of the machine ca.: 285 kg dimensions of the machine ca.: 1840 x 1680 x 1990 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

cutting diameter: 330 mm saw band length: 3870 x 34 x 1,1 mm cutting width: 360 mm band speed: 15 - 90 m/min : 360 x 250 mm cutting capacity - round: 330 bei 90° mm : 250 x 150 mm cutting capacity - round: 250 bei 45° mm work height max.: 850 mm cutting capacity - square: 320 bei 90° mm cutting capacity - square: 240 bei 45° mm coolant tank: 40 l Control: total power requirement: 5,67 kW weight of the machine ca.: 1450 kg dimensions of the machine ca.: 1930 x 2070 x 200 mm Fully automated CNC band saw is generally suitable for cutting big series in the heaviest and non-stop operating plants, and also for cutting heavy workpieces of larger cross-sections. Compared to ARG 250 and 300 CF-NC using blade 27 x 0.9 mm, this model is fitted with the saw band 34 x 1.1 mm, which greatly increases the productivity of the machine and the accuracy of the cut, especially when cutting larger cross ...

cutting diameter: 540 mm saw band length: 6000 mm cutting width: 750 mm table height: 695 mm cutting speed: 20 - 100 m/min : 540 mm : 540 x 540 mm Capacity 90° rectangular: 750 x 540 mm : 540 mm : 540 mm : 600 x 540 mm : 510 mm : 450 mm Capacity 45° rectangular: 450 x 540 mm capacity 60 degrees: round: 270 mm capacity 60 degrees: square: 250 mm capacity 60 degrees: flat: 250 x 540 mm total power requirement: 4 kW weight of the machine ca.: 2,45 t dimensions of the machine ca.: 3,0 x 1,3 x 2,13 m Horizontal band saw. The bow is made of heavy steel and the two pillars constitute a strong and rigid saw frame. This ensures high accuracy when cutting. The machines are fitted with an integrated coolant pump that supplies oolant to both guide assemblies. Blade guides with rollers and carbide pads provide precise support for the blade. The machines switch off automatically at the end of the cu ...

pressure: 150 t stroke: 450 mm throat: 350 mm work speed: 2 m/min ajustment speed: 10 mm/sec return speed: 16 mm/sec pressure: 320 bar diameter of piston: 50 mm opening stroke: 700 mm table-size: hinten / back 2000 x 500 mm Table dimensions: Main500 x 500 mm total power requirement: 4 kW weight of the machine ca.: 6,7 t dimensions of the machine ca.: 2,95 x 2,0 x 850 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

cutting diameter: 260 mm saw band length: 2880 x 27 x 0,9 mm cutting width: 300 mm band speed: 35/70 m/min : 300 x 200 mm cutting capacity - round: 260 bei 90° mm : 190 x 100 mm cutting capacity - round: 175 bei 45° mm work height max.: 910 mm total power requirement: 1/1,4 kW weight of the machine ca.: 475 kg dimensions of the machine ca.: 1860 x 1680 x 1980 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

pressure: 220 t stroke: 450 mm throat: 375 mm work speed: 2,2 m/min ajustment speed: 10 mm/sec return speed: 18 mm/sec pressure: 320 bar diameter of piston: 60 mm opening stroke: 800 mm table-size: hinten / back 2500 x 600 mm Table dimensions: Main 600 x 600 mm total power requirement: 5,5 kW weight of the machine ca.: 12,15 t dimensions of the machine ca.: 3,25 x 2,5 x 0,90 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
