horizontal boring used for sale

Technical data Spindle dia 125mm ISA 50 taper stroke of the spindle 800 mm cross travel of table X 1200 mm vert. travel of headstock Y 1400 mm longit. ztravel of the table Z 1620 mm spindle speed infinitely variable 3,5-700 rpm table size 1200 x 1400 mm table load 6000 kg main motor DC 19 kw total input 22,79 kW spindle feed inf. variable 0 - 1,25 mm/rot working feeds inf. variable 0,3 - 1700 mm/min rapid traverse 2250 mm/min fine feed 3mm/min dimension LxWxH 7,4 x 4,8 x 3,6 m weight of the machine 21000 kg DRO Heidenhain

Skoda W 160 H/NR CNC Travel x= 14.500mm (bed is for the travel 18,500mm) Travel Y= 3.150mm Travel Z= 1.600mm Travel W= 1.250mm Spindle diameter 160mm Machine with ball screw Many accessories available: CNC control Siemens SINUMERIC 850 Rotary table ISO 16 2.200 x 2.200mm, capacity 16 ton included Chip conweyor : 19.000 mm + 12.000 mm Floor plates

Machine Type: CNC Plate Boring Machine Make WOTAN Type Rapid 5C Year of manufacture 2004 Control type HEIDENHAIN iTNC 530 Spindle diameter 160 mm X-off (mm) 10,000 Y-off (mm) 3,800 Z-off (mm) 700 W-way 700 mm Tool holder Iso 50 Speeds from (rpm) 1.25 - 1250 Feed rate (mm/rev) 1 - 5000 mm/min Rapid traverse 5 mtr/min. Total power(KW) 120 /spindle 83 Length (mm) 14.500 Width (mm) 3,850 Height (mm) 7,360 Weight 62,300 kg Information - 2004 completely overhauled and converted to CNC by Dorries Scharmann Control HEIDENHAIN iTNC 530 - 5 different angle milling heads - Hydrostatic spindle bearing - Aerostatic guideways - Coolant device -Conveyor -Oil cooler

W 200G with Siemens AC main motor. modernized the main drive by instalation of Siemens AC motor with SIMODRIVE 611. Original built ISO 60 taper and 630 rpm Main data: X=8000 mm Y=4150 mm Z =1600 mm W=2000 mm Spindle dia 200mm ISO 60 spindle speed max 800 rpm Accessories: DRO Philips available as original rotary table E 20 extra cost milling head IFH 1 and IV25, IFW 1, IFW2 IFW 3 NO floor plates

W100A Parameters 100mm, 1600mm Diameter of working spindle 100 mm Taper in spindle morse 6. Longitudinal adjustment of table (z) 1450 mm Cross adjustment of table (x) 1600 mm Motion of work head on frame (y) 1120 mm Slip out of working spindle (w) 900 mm Clamping area of table 1250 x 1250 mm Dimensions l x w x h 6710 x 3450 x 3000 mm Machine weight 14 000 kg Accessories: face plate, tail stock

HBM STANKO 2A622 CNC

Skoda W200H - CNC Plate Boring Machine – Bearing Sleeve (RAM) Year of construction : 1992 Electrical & Electronics Overhaul : 2021 Spindle : 200 mm ( Ø ) ISO 60 X : 7,800 mm Y : 5,400 mm W : 900 mm ( spindle ) Z : 900 mm ( Carrying sleeve / RAM 520 x 520 mm ) Z1 : 2,000 mm (table) CNC rotary table : 2500 x 2000 mm – 40 T Spindle speed : 0.8 - 800 rpm Rapid traverse speed : 6000mm/min Spindle motor : 75 kw Total power : 140 kW Machine weight : 84 T (approx.) Control : FAGOR 8055 Processing heads 3 pieces 1.Angular translation head 2. Vertical milling head 3.Horizontal milling head Base plate : 4,480 mm x 1,145mm Conveyor

Union boring mill CBFK 150/2 from 1990 for sale. Is currently still in use,. Technical details / accessories / addition: x-travel 3000 mm y-travel 2000 mm z-travel 1600 mm Spindle diameter 150 mm Spindle holder ISO 50 Spindle stroke 700 mm Spindle speeds - infinitely variable 5 - 2500 rpm Rapid traverses 10000 mm/min Table clamping area 1600 x 2000 mm Workpiece weight approx. 20 t Spindle drive motor 50 kW Feeds x/y/z - infinitely variable 1 - 9999 mm/min Table positioning 360,000 ° Total power requirement approx. 70 kW Machine weight approx. 40 t Dimensions approx. 6.0 x 8.0 x 4.5 m In 2005: new 5-axis CNC control Dr. Heidenhain TNC 430 - electron. Handwheel HR 410 for all axles with V24 interface, punched tape reader, new electrics, new hydraulics, new servo motors, 60-speed chain tool change magazine model WM III k02 B-axis (round table adjustment) 360,000  ...

Wohlhaupter turning head in the suitcase Wohlhaupter UPA6/3944 in a wooden case with accessories SK50 Type UPA6

DEFUM WFM-100 boring machine was built in 1984 in Poland by the Dąbrowska Fabryka Obrabiarek DEFUM. The machine is designed for precision machining of workpieces with complex geometry and high weight. All machining processes, i.e. drilling, milling, boring and thread cutting, are performed on a stable work table by means of a powerful spindle with a diameter of 100 mm. The WFM 100 horizontal boring machine weighs 11000 kg. Technical specifications of the DEFUM WFM-100 drilling and milling machine - feed in the X/Y/Z axis: 1200/1000/600 mm - work table dimensions (L x W): 1100 x 1100 mm - maximum workpiece weight: 3000 kg - maximum spindle rotational speed: 1600 rpm - spindle diameter: 100 mm - spindle drive power: 18.5 kW - dimensions (L x W x H): 4610 x 3620 x 3110 mm - weight of the DEFUM machine: 11000 kg

- Structure in stainless steel - Workpiece fixing system - Table adjustable - 2 milling spindles - 2 multifunction drilling spindles - Switch box

Code: 0253 Brand: LARI E LARI - ITALY Model: FR 20 - TA - CE Standard Working center for milling and boring on wood or plastic and composite materials, wooden doors, window frames - CE Standard Technical data: X-axis working stroke 3250 mm Y-axis working stroke with 90° cutter 130 mm Z-axis working stroke with 0° cutter 290 mm Z-axis working stroke with 90° cutter 175 mm X-axis working speed mt/min 40 Y-axis working speed mt/min 30 Z-axis working speed mt/min 30 Hinge boring inserting unit: Male/Female Speed control inverter Probe Tool holder collet ER 25 Power of anuba head drilling electric spindle 2,2 Kw Anuba head inclination -10 +90° Electric spindle for milling: 2,7 Hp at 18,000 rpm Collet chuck ER 32 Variable speed via inverter Inclination from 0 to 90° for both vertical and horizontal machining Machine computer: numerical control - Win ...

Machine : Tools for boring mill / radial drilling machine Type: MK5 5 drill rods φ 40 , 30, .. L- 280 – 400mm 3 extensions MK5 – MK4 , L-400-520mm 1 boring tool Oerlikon MK5, φ 70, 6-260 5 top-mounted milling mandrels MK5 - φ 16, 22, 27,32,40mm 2 Clarkson clamp chucks 1 MK5 boring tool, adjustable, φ 60mm 2 Shots 2 milling cutters: End mill roughing/plain φ 56x100mm, / groove milling cutter 4 milling cutters: 2 roughing/plain φ 40x12o, 2 roughing cutters 1 Reduction from MK5 to SK40 Weight: approx. 70kg kg PRICE : € 600,- ex works ! A - T-slot size: approx. 21.5mm, B-35, thread M20 16 T-slot nuts 20 pcs threaded rods M20, L-120 – 400mm 3 x 2 pcs clamping claws 4 nuts long, 6 nuts, washers 2 blocks for adjustment with adjustment screw 4 blocks 80 x 60 x40mm ( underlay )

Quill for jig boring mill, fine boring mill, plate boring mill, table boring mill, boring mill, milling machine, -Stroke: 60 mm -in: a wooden box -Dimensions: 390/340/H170 mm -Weight: 15.8 kg

Jig boring mill, fine boring mill, plate boring mill, table boring mill, boring mill, milling machine, -Table dimensions: 700 x 405 mm -Travel: Z 330 mm/Y 410 mm/X 630 mm -Quill stroke: 155 mm -Recording: MK4 -Speeds: 31 - 1500 rpm -Dimensions: 1570/1800/H2600 mm -Weight: 2600 kg

Spindle for plate boring mill, table boring mill, boring mill, milling machine, quill, boring head, Replacement spindle -SK50 holder for: screwing onto the faceplate -Adjustment: SK50 -Dimensions: 220/220/H160 mm -Weight: 20 kg

Boring head, spindle head, drill head, plunge drill head, plunge head, spindle drill head, boring head, spindle tool -spindle tool -Recording: SK50 -suitable for tool changers -spindle dimension -Dimensions: 290/120/H320 mm -Weight: 12 kg

Boring head, spindle head, drill head, plunge drill head, plunge head, spindle drill head, boring head, spindle tool -spindle tool -Recording: SK50 -suitable for tool changers -spindle dimension -Dimensions: 240/120/H320 mm -Weight: 10 kg

Boring head, spindle head, drilling head, grooving drilling head, grooving head, spindle drilling head, boring head, spindle tool, facing and boring head -Boring head: MK5 mount -Spindle size: Ø 120-140 mm -Dimensions: Ø 124 x 253 mm -Weight: 8.4 kg

Universal milling machine vertically / horizontally from a training workshop Manufacturer Hermle Type FW801 Tool holder SK40 automatic feed in three axes Digital display in three axes Machine technically in very good condition under electricity ready for demonstration Technical data: Travel: x=350mm y=150mm z=220mm Spindle speeds from 50 to 3,150 rpm can be infinitely variable Feed speed infinitely adjustable via rotary pot from 10 to 5,000 mm/min, aisle Special price Used milling machine Hermle FW 801

Boring head, spindle head, drilling head, grooving drilling head, grooving head, spindle drilling head, boring head, spindle tool, facing and boring head -Boring head: MK4 mount -Spindle size: Ø -93 mm -Dimensions: 93/64/H200 mm -Weight: 2.2 kg

Dowel drilling and drive-in machine Biesse type F/S Technical data: • Drill head: 21 spindles • Glue guns: 6

X axis travel 1000 mm Y axis travel 700 mm Spindle travel 300 mm Table dimension 1.100x842 mm Spindle speed 40-2000 rpm Max power input 10 kW Spindle motor 8 HP Total permissible load on worktable 1 ton Machine approximate weight 15 ton

Horizontal borer Wotan B105Y Spindle: 120 mm Travels: -X: 3000 mm -Y: 1450 mm -Z: 1280 mm Table: -1400 x 3000 mm -Rotating part: 1130 x 1500 mm (manually rotated to any degrees) -Max load: 7 tn Machine weight: about 25 ton

In-line hole drilling machine Scheer DB 4 L x W x H: 1500 x 1500 x 1900 mm Weight approx. 1000 kg Built in 1980 1 aggregate vertically up 1 aggregate horizontal - vertically pivotable The machine is in good condition, ready for operation. Changes, mistakes, intermediate sale reserved ! Service/spare parts by MATEC CH-4900 Langenthal/DE-79618 Rheinfelden MATEC system + technik GmbH Mechanical engineering Eisenbahnstrasse 25 CH-4900 Langenthal/Switzerland Tel. 0041 62 966 18 32 Fax 0041 62 966 21 12

Boring head, spindle head, drilling head, grooving drilling head, grooving head, spindle drilling head, boring head, spindle tool, facing and boring head -Boring head: SK40 holder -Tool holder: 16 x 16 mm see photos -Dimensions total: Ø 63 x 250 mm -Weight: 2.8 kg

Boring head, spindle head, drilling head, grooving drilling head, grooving head, spindle drilling head, boring head, spindle tool, cutter, circle cutter -Manufacturer: Marchner, die cutter, boring head, circle cutter -Recording: MK3 -Diameter range: 33 - 85 mm -Transport dimensions: 340/165/H100 mm -Weight: 5.3 kg

SN.: 16210512 Equipment / other information: Tool

Boring head, spindle head, drill head, plunge drill head, plunge head, spindle drill head, boring head, spindle tool -Recording: SK50 -Adjustment range: 20 mm -Tool shaft: Ø 30 mm -Weight: 10 kg

Boring head, spindle head, drill head, plunge drill head, plunge head, spindle drill head, boring head, spindle tool -Quantity: 2x spindle tools -Recording: SK50 -Spindle dimensions: 145-230/225-310 mm Price: complete -Weight: 14 kg/piece

oven 550 industrial 2x2x6m temperature range 100 - 550C Wärmebehandlungsöfen Wärmeofen Wärmeprozessöfen Warmhalteofen Warmluftofen Herdwagenofen Rollenherdofen Kammerofen Drehtellerofen Wagenherdofen & Tunnelofen Poreba Gurutzpe Tacchi Geminis Tos Amutio cazeneuve Skoda Morando Niles Colchester Heyligenstaedt Kramatorsk Mondiale Safop Cazeneuve Alzmetall mas stankoimport csepel carlton kolb soraluce bergonzi flott Erfurt Weingarten smeral schuler ebu mueller zts kosice wlochy minster Stanko stankoimport glaser huta zygmunt aft donaldson eumuko Elblag Engel Demag Arburg Krauss Maffei Battenfeld Manesty Mazak Voronezh Trumpf Amada Cincinnati Netstal Rose Forgrove Illig Foremost Nissei Sandretto Fette Mazak Mori seiki Haas Okuma Gildemeister Doosan Daewoo traub hwacheon index Wema zeulenroda mueller Erfurt tox presso technik dunkes galdabini hare ponar zeulenrdoda eitel  ...

Planausdrehkpof Wohlhaupter UPA 5 with accessories as shown. Cone ISO 50

UNUSED: Facinghead of a Wotan BF 160 Horizontal borer.

Code 71144 Description Horizontal table borer Make PFEIFER Model F 80 / 100 Serial number 2342 Year 1982 Spindle 100 mm Spindle taper 50 ISO Spindle out (W) 500 mm Table 1000 x 850 mm Cross (X) 1200 mm Longitudinal (Z) 800 mm Vertical (Y) 800 mm Distance table-spindle 0 x 800 mm Speeds 18 steps Spindle speeds 14 – 1500 rpm 16 Feeds 0,03 – 6,0 mm/rev Rapids 2500 mm/rev Rapids all directions ( X-Y-Z-W-B) Motor 7,5 kW 380 Volts Accessoiries X-Y-Z axis are BALLSCREWS Tool clamping Pendant control Condition Machine is in very good condition

diameter:500 mm tool adaptor:50 Weight:12 kg face movement each head:82 mm feeds:0,06 mm/U

bore diameter: 620 mm spindle diameter: 130 mm bore depth: 320 mm feed stepless: 0 - 12 mm/min turning speeds: 10 - 70 U/min voltage: 380 V / 50 Hz total power requirement: 4 kW weight of the machine ca.: 1,6 t dimensions of the machine ca.: 2,0 x 1,2 x 1,3 m transportable drilling out work, completely ready for connection gear of drill spindle runs over LENZE planetary drive advanced feed with LENZE direct current motor, output: 160 watt clockwise and counterclockwise with tool holder for Ø 420 x 620 mm, tool holder for tooling equipment fabri. LENZ LPAS 3, diverse turning steel The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Boring power:10 mm weight:590 kg connected load:2 kW dimensions::1500 x 1300 x 2300 mm

bore diameter: 550 mm Spindle diameter: 100 mm bore depth: 320 mm turning speeds: 10 70 U/min feed stepless: 0 - 12 mm/min voltage: 380 V / 50 Hz total power requirement: 3 kW weight of the machine ca.: 1.35 t dimensions of the machine ca.: 1,0 x 2,5 x 1,0 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

spindle diameter: . mm x-travel: . mm y-travel: . mm table length: 2000 mm table width: 2000 mm table load: 25 t total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

table length: 2000 mm table width: 1800 mm table load: 12,5 t table adjustment - longitudinal: 1.250 mm table rotating: 360 Grad table positioning: 4 x 90 ° feeds - longitudinal: 0,63 - 2.000 mm/min total power requirement: 4 kW weight of the machine ca.: 7,6 t The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Spindle speed: from 20 to 1800 rpm Table dimensions: 1600 x 1450 mm with 9 grooves, travel X-axis: approx. 1500 mm Travel Y-axis: approx. 1300 mm Travel Z-axis: approx. 1200 mm The machine is equipped with a 3-axis digital display from the manufacturer HEIDENHAIN, two clamping brackets, one dimension: 1850 x 850 mm and one 1250 x 800 mm, also various accessories

Machine already ready for transport, to be assessed on viewing day. Clamping block not included

CNC unit for routing and boring Brand: Atemag Type: Function Line Soft Touch One With surface copying function with fix spindle ER25 and fix bell Max. drive speed 18,000 R.P.M. Max. tool spindle speed 18,000 R.P.M. Gear ratio i = 1:1 Turning direction left/right Torque max. 10Nm Tool interface: fix ER25 Adjustment distance: 70mm

table length: 4000 mm table width: 3000 mm table load: 60 t total power requirement: 14.3 kW weight of the machine ca.: 48.5 t dimensions of the machine ca.: m Brand: FX Type: 83.300/400 Used machine Digital readout: Heidenhain ND 780 Table length: 4.000 mm Table width: 3.000 mm Table load: 60 T Movement: 2.000 mm Width T-slots: 58 mm (M30) mm Feeding: 4 - 1.500 mm/min Rapid traverse: 4.000 mm/min Power: 14,3 kW Machine weight: 48.500 kg The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Henri Hauser M5 DR Coordinate Drill Spindle diameter 90 mm x-displacement 700 mm y-way 500 mm Drilling capacity in steel 40 mm Spindle holder MK 4 Drilling spindle stroke 170 mm Number of spindle rotations 2 infinitely variable 10-2000 rpm Boring diameter max. 230 mm Table dimensions - longitudinal 900 mm Table dimension - transverse 770 mm Vertical path of the cross beam 630 mm Drilling spindle 6 pieces from/to 0.02-0..20 rpm Passage between the stands 900 mm Passage between spindle and table 815 Spindle motor 4.0 hp Total power requirement 380 V Machine weight approx. 3.9 t Complete plant closure, large selection of mezzanine, pallet racks, shelves, paternosters. High-quality industrial machines, lathes, grinding machines, manual machines

I sell a Top Dubel drill multi-spindle drill Detel M-13, built in 2007. 3-spindle See good condition. Available the same.

High precision drilling and milling machine Aciera 22 VA Good condition from school operations Year of construction approx. 1990 Table 600 x 320 mm Speed 40 - 3600 rpm Speed setting rpm 4 automatic feeds 40-280 80-560 275-1800 550-3600 Spindle diameter 65 mm Drilling spindle stroke 120 mm Spindle holder: Aciera quick-change system Automatic thread cutting Drilling capacity in solid material 25mm Max drilling capacity up to 30mm Height adjustment via hand crank Motor: 1.1 KW Lamp Some quick-change shots Dimension WxDxH 90 x 130 x 185 cm Weight approx. 800 kg Technical information subject to reservation

Multi-stand drill Prior sale reserved - errors possible Internal Reference Number: D-1143-1
