Max. tool weight 10 kg Max. tool length 350 mm Max. tool diameter 80 mm Tool holder HSK-A63 according to DIN 69893 Number of tool positions in the magazine 60 Spindle speeds - infinitely variable 50-10,000 rpm Number of pallets 2 Max. pallet load 400 kg Pallet size (lxw) 500 x 400 mm Pallet change time 8/5 s Coolant tank 1100 l Machine length 5800 mm Machine width 4800 mm Machine weight approx. 12.8 t Spindle power 24 / 37 kW Auction-ID: A1-50373-18
USED WEEREN DH 20II GA MACHINE (STRAIGHTENING, CENTERING, EXTERNAL TURNING AND CHAMFERING) FOR SHAFT AND TUBE END MACHINING Year : 2008 Capacity: max. diameter: 36 mm Machining length: 35 mm Workpiece length: minimum: 150 mm - max: 1150mm Equipped with 1 SIEMENS PLC 2 GUHRING machining heads Dimensions and weight Machine: 3900x1550xH1800mm - Container: 1550x500xH1000mm - 2 pallets weight 6500 kg Auction-ID: A1-50950-80
Used Centerless grinding machine LIDKOPING 46 Working wheel Ø Exterior: 508 mm Width: 610 mm Control wheel Ø Exterior: 330 mm Width: 610 mm Thread work Plunge work CNC motor 0.001 Equipped with 1 Control cabinet with PLC SIEMENS 1 CNC plunge on the working wheel 1 CNC motor on the control wheel1 External lubrication pump tray 2 Hydraulic diamond cutters 1 Batten holder for working in a row Dimensions and weight Machine: 3800x2100xH1600mm - Electrical cabinet: 1000x400xH1700mm - 1 pallet - total weight 8500 kg Auction-ID: A1-50950-37
USED GHIRINGHELLI GRINDING MACHINE TYPE M12SP610 CNC6A Serial No.: C733.06 Year: 2006 Working wheel Outer diameter of the grinding wheel: 610 mm Equipped with 1 SIEMENS SINUMERIK CN Number of CNC axes: 6 1 Gantry loading and unloading between the grinding wheels 1 Double control wheel carriage driven by 2 Bruschless motors 1 Bruschless motor on the spindle 2 CNC diamond cutters with dimension adjustment Dimensions and weight Machine:4000x2500xH2550mm - weight 8000kg - electrical cabinet: 1900x600xH2400mm - weight 450 kg - loader: 3000x2400xH2400mm - weight 1200 kg Auction-ID: A1-50950-16
x-travel: 1016 mm y-travel: 610 mm z-travel: 760 mm Control: Heidenhain iTNC 530 total power requirement: kW weight of the machine ca.: 9,4 t dimensions of the machine ca.: m Heidenhain iTNC 530 CNC control Travel ranges: X-axis 1.016 mm Y-axis 610 mm Z-axis 760 mm Spindle speed 10.000 rpm Tool holder HSK 80 Power 12 kW Table clamping surface 1.250 x 590 mm Table load 900 kg Feed rate 40.000 mm/min. Machine weight 9.400 kg Equipment: Heidenhain iTNC 530 CNC contouring control Electronic handwheel 3D touch probe tool changer 2-position pallet table Coolant system with internal coolant supply (ICS) Chip conveyor Oil mist extraction system The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
turning diameter: 820 mm turning length: 3000 mm control: Siemens 840 D workpiece weight: 2,5 t drive of main spindle: 77 kW spindle nose: A15 spindle bore: 160 mm Workpiece head (C-axis): 0,005 grad max. torque on the working spindle: 2500 Nm main spindle speeds:: 0-2.430 U/min feeds z-axis: 0,1-18.000 mm/min rapid traverse Z-axis: 18 m/min feeds x-axis: 0,1-30.000 mm/min rapid traverse X-axis: 30 m/min steady: 50-350 Spannbereich tailstock - quill dia: 180 mm tailstock - travel of quill: 170 mm y-axis: -100/+150 mm rapid traverse y-axis: 12.000 mm/min b-axis: -105/+95 Grad milling spindle - taper: HSK100 milling spindle motor: 43 kW milling head speed: 1-5.500 U/min max. torque on the milling spindle: 336 Nm tool changer: 96 Plätze weight of tools max.: 15 kg chip conveyor: kW total power requirement: 166 KVA weight of the machine ca.: 40 t dimensions of the machine ca.: 112x4,4x3,85 ...
multitasking turning center, year 2003, CNC MSC 501. Used machine. More info & price on IndustrialBuyer.
multitasking turning center, year 2007, CNC NT425GCO188. Used machine. More info & price on IndustrialBuyer.
Key data: 560 mm, 560 mm, 600 mm
Manufacturer: Makino Model No.: A51 Year: 2006 Condition: Used Stock number: 9612 Work table length: 400 mm Work table width: 400 mm Maximum spindle speed: 12000 1/min X-axis travel: 560 mm Y-axis travel: 560 mm Z-axis travel: 600 mm Number of Stacking Positions: 134 pieces Machine weight: 7804 kg
Key data: 915 mm, 6000 mm
1 turning and milling center Make: Mazak Model: Integrex 650 H Year of Make: 2004 CNC control. Mazatrol 640 NT-Pro Turning diameter: 915 mm Turning length: 6000 mm Equipment / Accessories: Drill rods Tool measuring device Tool Changer 2 automatic setting sticks diameter 190 – 350 mm 1 automatic setting stick diameter 50 – 268 mm 1 manual setting stick diameter 400 - 610 mm 1 three-jaw chuck diameter 630 mm Cooling lubrication system Coolant tank 1150 l Coolant pump 70 bar otherwise according to the technical data in the appendix. Machine has been regularly serviced and is in very good condition.
The machine is in good technical condition; testing is possible by prior arrangement. Control system: Mazatrol MATRIX 2. Table clamping surface: 1300 × 550 mm. X-axis travel: 1050 mm. Y-axis travel: 530 mm. Z-axis travel: 510 mm. Spindle speed: 10 – 12,000 rpm. Number of controlled axes: 3. Through-spindle coolant: Yes. Coolant pressure: 15 bar. Spindle taper: ISO 40. Max. table load: 1200 kg. Tool magazine: Yes. Number of magazine positions: 30. Number of pallets: 2. Machine weight: 7700 kg. Coolant enclosure (required for chip evacuation). Rear chip conveyor outlet (left and right). Preparation for optical probe (MMS-B OMP60). Automatic tool length measurement and breakage detection. Automatic pre-drilling cycle with load detection. Synchronized tapping. 2-pallet changer with safety enclosure. Preparation for high-pressure coolant. Renishaw OMP 60 probe. Renishaw CAT 40 tool shank. ...
x-travel: 1020 mm y-travel: 700 mm z-travel: 500 mm control: Heidenhain iTNC530 total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
x-travel: 1060 mm y-travel: 520 mm z-travel: 610 mm control: Siemens total power requirement: kW weight of the machine ca.: 5900 kg dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
x-travel: 1600 mm y-travel: 820 mm z-travel: 700 mm control: Heidenhain iTNC530 total power requirement: kW weight of the machine ca.: 7500 kg dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
x-travel: 750 mm y-travel: 600 mm z-travel: 520 mm control: DMG Ergoline total power requirement: kW weight of the machine ca.: 9500 kg dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
vertical CNC turning center, year 2008, CNC OSP-P200L. Used machine. More info & price on IndustrialBuyer.
turning diameter: 275 mm turning length: 900 mm control: TRAUB TX8i Main- opposite spindle: spindle passage: 65 mm power capacity at 100 % load: 25,20 kW power capacity at 40 % load: 30,20 KW max. torque at 40% / 100% load: 180 / 135 Nm spindle turning speed - stepless: 1 - 5.000 U/min spindle diameter in front bearing: 110 mm C-axis: 1 - 500 U/min worktool support: No. 1 x-axis: 290 mm y-axis: 165 mm z-axis: 600/950 mm B - axis: 360 ° rapid traverse X/Y/Z: 18 / 18 / 30 m/min feed capacity X/Y/Z: 10 / 10 / 7 kN number of tools: 2x2 + 2x2 number of driven tools: 2x2 + 2x2 mm toolpiece turning speed range: 8.000 / 2.000 U/min power capacity at 25 % load: 5,80 kW max. torque at 25% load: 4x18,6 / 4x74 Nm tool taper: TRAUB Ø60 worktool support: No.2 / No.3 / No.4 x-axis: 170 mm z-axis: 600/950 mm y-axis: +/- 60 mm rapid traverse X/Y/Z: 18 / 15 / 30 m/min feed capacity X/Y/Z: 10 / 10 / 7 k ...
turning diameter: 210 mm turning length: 700 mm control: Okuma OSP-E 100 L total power requirement: 35,7 kVA weight of the machine ca.: 7,1 t dimensions of the machine ca.: 2660 x 2000 x 2330 mm CNC turning and milling center with C-axis and Y-axis, 2 turrets, and subspindle. CNC control: Okuma OSP-E 100 L Maximum turning diameter: 210 mm Swing over bed: 400 mm Distance between spindle noses: 960 mm Main spindle: Spindle bore: 53 mm Speed range: 50 to 6000 rpm Motor power: 11/7.5 kW Subspindle: Spindle nose: JIS A2-6 Speed range: 38 to 5000 rpm Motor power: 11/7.5 kW Z-axis: Travel: 700 / 700 mm (ZA + ZB) Rapid traverse: 40000 mm/min W-axis: Travel: 940 mm Rapid traverse: 40000 mm/min X-axis: Travel: 167 / 192 mm (XA + XB) Rapid traverse: 30000 mm/min Y-axis: Travel: 92 mm (+50/-42 mm) Rapid traverse: 15000 mm/min C-axis: Indexing: 360 x 0.001 deg. Rapid traverse: 400 rpm Disc turret: 2 ...
travel -x axis: 1.300 mm travel -y axis: 670 mm travel -z axis: 625 mm control: HEIDENHAIN - TNC 620 number of spindle speeds: 12.000 U/min tool taper: SK 40 table dimension (L x W): 1.500 x 670 mm numbers of positions in the tool changer: 30 Milling machining centers - vertical | DOOSAN - DNM 5700 equipped with 30-way tool changer, ITC cooling system and chip conveyor. The machine only has 13.600 spindle hours. The machine is in well-maintained condition, has been used exclusively for machining aluminium and plastics, and is available for inspection under power at any time. The machine video from the production plant will be shared on request. Please refer to further technical details in the attachement of the offer. - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - #Tags: DNM5700 | DNM-5700 The data for this ad was created with ModulMWS - the software s ...
x-travel: 700 mm y-travel: 550 mm z-travel: 500 mm control: TNC 426 table-size: 900 x 550 mm taper ISO: SK 40 speeds: 18000 U/min total power requirement: 50 kW weight of the machine ca.: 7 t dimensions of the machine ca.: 3,3 x 2,43 x 2,98 m DECKEL MAHO DMC 70 V Hi-dyn machining center featuring: 30-station tool changer Chip conveyor Oil mist filtration system Transport dimensions: 650 x 243 x 297 cm, 8 tonnes The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
x-travel: 650 mm y-travel: 650 mm z-travel: 680 mm rotary table tiltable: 360 Grad Number of working hours: 55.000 h tool taper: HSK 63 spindle turning speed range: 20.000 U/min max. torque on the spindle: 85 table-size: 400 x 500 mm table load: 0,5 t 4-axis machine Chain-type tool magazine: 60 positions Chip conveyor Pallet changer Coolant filtration system High-pressure coolant through the spindle The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
Key data: 640 mm, 640 mm, 640 mm
Vertical machining center Travel x/ y/ z = 640/640/640 mm Work table 850 x 600 mm Rapid traverse x/y/z 70/ 40/ 40 m/min Spindle speed up to 12,000 1/min Motor power 40/100 % 19/ 13 KW Torque 40/100 % 100/ 70 Nm Tool magazine 30-fold Tool holder SK 40 - Coolant system - Chip conveyors - Internal coolant supply - CNC control Heidenhain iTNC530
Key data: 550 mm, 400 mm, 415 mm
Manufacturer: Brother Model No.: TC-32BN QT Year: 2013 Condition: Used Stock number: 9616 Work table length: 600 mm Work table width: 425 mm Maximum table load (uniform): 200 kg Maximum vertical spindle speed: 16000 1/min X-axis travel: 550 mm Y-axis travel: 400 mm Travel Z axis: 415 mm Number of all tools: 26 pieces Machine weight: 7000 kg Equipment: Chip conveyor NC Rotary Table Kitagawa CKR160RY
Key data: 600 mm, 500 mm, 500 mm
Manufacturer: INAXES Model No.: IKC-600FB Year: 2017 Condition: Used Stock number: 9617 Control system: HEIDENHAIN TNC 620 HSCI Switch-on hours: 6656 h Operating hours: 2299 h Work table length: 650 mm Work table width: 500 mm Maximum table load (even): 300 kg Speed: 12000 1/min X-axis travel: 600 mm Y-axis travel: 500 mm Travel Z axis: 500 mm Cone: BT40 Number of all tools: 24 pieces Machine height: 2280 mm Machine length: 2600 mm Machine width: 2840 mm Machine weight: 4500 kg Equipment: Chip conveyor
Dinkel DTAJ 20000 extendable center axle trailer – 2006 – 20 tons – NL registration Specifications: Brand: Dinkel Type: DTAJ 20000 Year of construction: 2006 Date of first admission: 09-05-2006 Chassis number: W09799210D17079 Version: centre axle trailer / extendable rocker Body: open cargo floor Number of axles: 2 Tare weight: 6.380 kg Payload: 13,620 kg Maximum permissible weight: 20,000 kg Maximum axle load: 10,000 kg per axle Total length according to registration: approx. 10,100–12,100 mm Length of load floor retracted: approx. 8,550 mm Width: approx. 2,550 mm Floor height: approx. 900 mm Towing eye: 50 mm Features: Extendable open loading floor Rear can be extended approx. 1,750 mm Low floor construction for transporting machines and equipment Tandem axle Air suspension WABCO Trailer EBS Air brake system Steel chassis construction Checker pl ...
Manufacturer DMG Model DMU 160P Year 2002 CNC HEIDENHAIN iTNC-530 Table Dimensions of the Work Table 1,500 x 1,250 mm. Maximum weight allowed on table 4,000 kg. Table Rotation (C-Axis) 0.001º (Continuous) Routes and advances Longitudinal course (X-axis) 1,600 mm. Cross Span (Y-Axis) 1,250 mm Vertical course (Z Axis) 1,000 mm. Horizontal Automatic Swivel Head / Vertical (A-axis) 0.001º (continuous) Fast Axis Feed 60,000 mm/min SK-40 Spindle Cone DIN 69871 Speed range 20-18,000 rpm Main Motor Power 28 kW Equipment Automatic tool loader INCLUDED Positions in tool loader 60 Coolant tank capacity 200 l. HEIDENHAIN optical rulers INCLUDED Chip conveyor INCLUDED HEIDENHAIN HR-410 Portable Steering Wheel 3D-Rot INCLUDED Measuring probe piece HEIDENHAIN TS-631 M function for coolant Internal/external INCLUDED Prepared for internal cooling INCLUDED Mode 4 op ...
HAAS VF-2SS CNC vertical machining center was built in 2013 in the United States by HAAS AUTOMATION, INC. The machine is designed for the automatic machining of metal workpieces weighing up to 680 kg. It performs such operations as precision milling, threading and drilling. Its wide machining capabilities, combined with proven components, make it an excellent choice for the production of repeatable parts used in many industries. The HAAS VF-2SS is equipped with a spindle with Inline Direct-Drive drive, reaching a maximum speed of 12000 rpm. It cooperates with a 31-position tool magazine that automatically changes tools according to the machining program. Machining is performed in three axes, X, Y and Z, with feed ranges of 762 mm, 406 mm and 508 mm respectively. The worktable with T-slots allows for the quick clamping of the tooling and workpieces. The machine’s rigid design ensures ...
HAAS VF-4SS CNC vertical machining center was built in 2012 in the United States by HAAS AUTOMATION, INC. The machine is designed for the automatic machining of metal workpieces weighing up to 794 kg. It performs such operations as precision milling, threading and drilling. Its wide machining capabilities, combined with proven components, make it an excellent choice for the production of repeatable parts used in many industries. The HAAS VF-4SS is equipped with a efficient spindle reaching a maximum speed of 12000 rpm. It cooperates with a 31-position tool magazine that automatically changes tools according to the machining program. Machining is performed in three axes, X, Y and Z, with feed ranges of 1270 mm, 508 mm and 635 mm respectively. The worktable with T-slots allows for quick clamping of the tooling and workpieces. The machine’s rigid design ensures stable operation even du ...
\" WEEKE Optimat BHC 250 CNC Processing Centre Manufacturer: WEEKE Bohrsysteme GmbH / HOMAG Group Model: Optimat BHC 250 Machine type: CNC Processing / Machining Centre Year: 2004 Serial number: 0-250-04-2244 Quantity: 1 machine CNC machining centre designed for drilling, routing/milling and grooving of wood and wood-based panel materials. Equipped with movable vacuum consoles, vacuum workpiece clamping, integrated drilling/routing equipment and original WEEKE PC/CNC control system. Technical specifications: Connected load: 15 kW Electrical supply: 400 V, 50 Hz, 3+N Rated current: 35 A Control voltage: 24 V Working length: Approx. 2,750 mm configuration X-axis travel: Approx. 3,185 mm Y-axis travel: Approx. 1,080 mm Z-axis travel: 135 mm Pneumatic requirement: 7 bar Equipment / features: CNC drilling and routing/milling Integrated machining head Movable ...
With two machining modules, X-axis: -50 to 725mm, Y-axis: -200 to 300 / -250 to 250mm, rapid traverse X-, Y-, Z-axis: 18/12/30m/min, control: Siemens Sinumerik, temperature range: 5–40°C, power type/frequency: 3 PEN / 50Hz, rated voltage: AC 400V, control voltage: DC 24V, auxiliary voltage: AC 230V, connected load: 102kVA, rated current: 148A, rated current (fast): 148A, fuse (slow): 160A, length: 8000mm, width: 3000mm, height: 4000mm, weight: approx. 17t, operating hours: approx. 80,000h. The machine is fully functional, the ball screw drive (recirculating spindle) of the Z-axis was renewed in 2024 and it has been regularly maintained. Comes with documentation, control cabinet, hydraulic unit, filter elements, and chip conveyor. An on-site inspection is possible.
CNC Vertical Machining Center HERMLE C 22 U With Siemens 840 D sl Operate path control Year of Make: 2016 Travel : X 450 Y 600 Z 330 Speed range : 20 – 18,000 rpm continuously variable ( HSK 63) With the following accessories: NC Swivel rotary table 0 320 mm clamping surface Vertical tool changer with 55 magazine positions (HSK 63) Linear Axis Dynamic Version Internal coolant supply ( IKZ 80 bar) Scraper belt conveyor left Coolant Setup Blowing air d.d. spindle center Bed Wash Automatic Cabin Door , Automatic Cabin Roof Polycarbonate Safety Lenses Rotating transparent window (Rotoclear) Sealing air for scales Electr. Heat compensation Siemens 3 D Probe Heidenhain BLUM Wz-bruch/ Measurement Oil mist extraction 4 Pieces Height Adjustable Machine Shoes Operating Instructions
CNC Vertical Machining Center HERMLE C 22 U With Siemens 840 D sl Operate path control Year of Make: 2014 Travel : X 450 Y 600 Z 330 Speed range : 20 – 18,000 rpm continuously variable ( HSK 63) With the following accessories: NC Swivel rotary table 0 320 mm clamping surface Vertical tool changer with 55 magazine positions (HSK 63) Linear Axis Dynamic Version Internal coolant supply ( IKZ 80 bar) Scraper belt conveyor left Coolant Setup Bed Wash Automatic Cabin Door , Automatic Cabin Roof Polycarbonate Safety Lenses Rotating transparent window (Rotoclear) Sealing air for scales Electr. Heat compensation Siemens 3 D Probe Heidenhain BLUM Wz-bruch/ Measurement Oil mist extraction 4 Pieces Height Adjustable Machine Shoes Operating Instructions
turning diameter:120 mm turning length:100 mm control:Fanuc Spindle 1 power:7,5 kW Spindle 1 RPM:4500 1/min Spindle 2 power:7,5 kW Spindle 2 RPM:4500 1/min Distance between spindle noses:600 mm Turret No.1 stations / rotary tools:15/15 Power rotary tools turret 1:2,7 kW RPM of rotary tools turret 1:4000 1/min Turret No.2 stations / rotary tools:15/15 Power rotary tools turret 2:2,7 kW RPM of rotary tools turret 2:4000 1/min Travel x/z turret 1:250 / 300 mm Travel x/z turret 2:250 / 920 mm Bar capacity spindle 1:51 mm Bar capacity spindle 2:51 mm power chuck:165 mm Spindle bore sp. 1:62 mm Spindle bore sp. 2:62 mm dimensions of the machine ca.:3700 x 2300 x 3000 mm weight of the machine ca.:5600 kg Used CNC-2-spindle CNC turning and milling center with gantry loader - 2x 15 station turret -automatic gantry loader with turnaround station. 14 station-magazin right side Max. Parts size Ø 12 ...
turning diameter:370 mm turning length:200 mm Spindle 1 RPM:4000 1/min control:Siemens 840 D Spindle 2 RPM:4000 1/min power capacity:L / R 18/24 kW max. torque on the spindle:630 nM C-Axis:0,001° Turret No.1 stations / rotary tools:12/12 VDI 40 Turret No.2 stations / rotary tools:12/12 VDI 40 turning speed range - milling:3000 1/min power capacity - milling spindle:8,8 kW torque rotary tools:28 Nm Bar capacity spindle 1:85 mm total power requirement:65 kVA weight of the machine ca.:13 t dimensions of the machine ca.:5,7x2,4x2,1 m Travel x1:260 mm Travel x2:260 mm Travel Y1:600 mm Travel y2:600 mm Power Chuck:2 x 250 mm manual tool eye:l & r High performance 6-axis subspindle CNC-Lathe with twin turren and rotating tools.
standard turning dia.:200 turning length:max. 810 mm control:MSX-701 MAPPS IV greates pass round over bed:800 mm Max. distance between centres:1130 mm max. turning diameter:320 mm max. workpiecediameter:300 mm bar material dia.:65 mm Traverse X-Axis 1:210 Traverse X-Axis 2:210 mm Traverse X-Axis 3:210 mm Traverse Y-Axis 1:110 (+65/-45) mm Traverse Y-Axis 2:110 (+45,/-65) mm Traverse Z-Axis 1:300 mm Traverse Z-Axis 3:300 mm Traverse Z-Axis 2:810 mm Traverse B-Axis:870 mm turning speed range - spindle:5.000 1/min Number of spindle speed ranges:2 . spindle nose:JIS A2-6 spindle bore:73 mm spindle bearing diameter:120 mm C-Axis:0,001 ° turning speed range - spindle:5.000 1/min spindle nose:JIS A2-6 spindle bore:73 mm bar material dia. max:65/52 mm spindle bearing diameter:120 mm C-Axis:0,001 ° Number of Turrets:3 . Number of tool stations:16 x 3=48 pos Schank height for square tool:20 mm D ...
turning diameter:640 / 400 mm turning length:1500 mm control:Siemens 840 D Powerline Travel turret No.1 (milling spindle) x/y/z:550 / 180 (±90) / 1585 mm Swivle angle milling spindle (B-axis):±120° interpol. ° Rapid traverse feeds turret 1 (milling head) x/y/z:40/24/60 m/min RPM milling spindle:12000 1/min power capacity - milling spindle:12 / 23 kW Torque of milling spindle:100 Nm Tool magazine for milling spindle (turret 1):120 HSK-A 63 Tool change time tool/tool, milling spindle:1,6 s Spindle 1 RPM:4000 1/min Spindle 1 power:36/ 45 kW Spindle 1 Torque:730 Nm Spindle 1 max. bar diameter:90 Spindle 2 RPM:4000 1/min Spindle 2 power:36 / 45 kW Spindle 2 torque:730 Nm Spindle 2 max. bar diameter:90 c-axis:0,001 ° Travel turret 2 x:225 mm Travel Turret 2 z:1595 mm RPM of rotary tools turret 2:4000 1/min no. of tools in turret 2:12 VDI 40 high-pressure pump:20 bar total power requiremen ...
turning diameter:500 mm turning length:1000 mm control:Siemens 840 D spindle:42 / 28 kW spindle turning speed - stepless:31 - 4000 1/min max. torque on the spindle:345 Nm c-axis:360000 x 0,001° feeds -stepless-:0 - 10000 mm/min rapid traverse:10000 mm/min turret stations / rotary tool stations:12/12 VDI 40 RPM of rotary tools:2000 1/min diameter of quill:90 mm quill stroke:80 mm tailstock quill taper ISO:SK 30 Tailstock Travel:600 mm Power rotary tools:3,5 kW :22,5 Nm Rotary tool holders:4 ax./ 4 rad. spindle passage:66 mm total power requirement:30 kW weight of the machine ca.:7,5 t dimensions of the machine ca.:8x 3 x 4 m
standard turning dia.:200 turning length:max. 810 mm control:MSX-701 MAPPS III greates pass round over bed:800 mm Max. distance between centres:1130 mm max. turning diameter:320 mm max. workpiecediameter:300 mm bar material dia.:65 mm Traverse X-Axis 1:210 Traverse X-Axis 2:210 mm Traverse X-Axis 3:210 mm Traverse Y-Axis 1:110 (+65/-45) mm Traverse Y-Axis 2:110 (+45,/-65) mm Traverse Z-Axis 1:300 mm Traverse Z-Axis 3:300 mm Traverse Z-Axis 2:810 mm Traverse B-Axis:870 mm turning speed range - spindle:5.000 1/min Number of spindle speed ranges:2 . spindle nose:JIS A2-6 spindle bore:73 mm spindle bearing diameter:120 mm C-Axis:0,001 ° turning speed range - spindle:5.000 1/min spindle nose:JIS A2-6 spindle bore:73 mm bar material dia. max:65/52 mm spindle bearing diameter:120 mm C-Axis:0,001 ° Number of Turrets:3 . Number of tool stations:16 x 3=48 pos Schank height for square tool:20 mm ...
turning diameter:410 mm turning length:500 mm control:Fanuc 21i TB standard turning diameter:275 mm travel -x axis:277 mm travel -y axis:82 (±41) mm travel -z axis:500 mm Spindle 1 RPM:4500 1/min Spindle 1 Power:18,5/18,5/15 kW Spindle 1 max. bar diameter:65 mm turret stations / rotary tool stations:12/12 Power rotary tools:5,5 kW RPM of rotary tools:6000 1/min total power requirement:39,2 kVA weight of the machine ca.:6,2 t dimensions of the machine ca.:3,1 x 2,0 x 2,2 m collet chuck:Hainbuch High precision Turning and Milling Centre with Y-axis. Machine was running with oil, not coolant. A fire extinguisher system is installed.
max. turning diameter:350 mm turning length:1040 mm control:OSP E 100 L Fanuc greates pass round over bed:550 mm Max. distance between centres:1200 mm max. workpiecediameter:550 mm Traverse X-Axis 1:270 Traverse X-Axis 2:230 mm Traverse Y-Axis 1:120 (±60) mm Traverse Z-Axis 1:930 mm Traverse Z-Axis 2:920 mm Spindle 1 Power:22 / 15 kW Spindle 1 RPM:5000 1/min spindle nose:JIS A2-8 bar material dia.:65 mm C-Axis:0,001° Number of Turrets:2 Turret No.1 stations / rotary tools:12/12 VDI 40 Turret 1 tool RPM:4500 1/min Turret 1 power rotary tools:7.0 / 3,3 kW Turret No.2 stations / rotary tools:12/12 VDI 40 Turret 2 tool RPM:4500 1/min Turret 2 power rotary tools:7.0 / 3,3 kW rapid traverse X-axis:30 m/min rapid traverse Y-axis:26 m/min rapid traverse Z-axis:40 m/min total power requirement:33 kVA weight of the machine ca.:10 t dimensions of the machine ca.:7,0 x 2,3 x 2,3 m spindle load m ...
max. turning diameter:320 mm turning length:1040 mm control: OSP E 100 L Dialog Fanuc greates pass round over bed:530 mm standard turning dia.:350 Max. distance between centres:1200 mm max. workpiecediameter:525 mm Traverse X-Axis 1:500 Traverse X-Axis 2:350 mm Traverse Y-Axis 1:160 (+80/-80) mm Traverse Z-Axis 1:1200 mm Traverse Z-Axis 2:1200 mm Spindle 1 Power:22 kW Spindle 1 RPM:3800 1/min spindle nose:JIS A2-8 spindle bore:80 mm bar material dia.:65 mm C-Axis:0,001° Number of Turrets:2 Turret No.1 stations / rotary tools:12/12 Turret 1 tool RPM:4500 1/min Turret No.2 stations / rotary tools:12/12 rapid traverse X-axis:20 m/min rapid traverse Z-axis:25 m/min total power requirement:33 kVA weight of the machine ca.:10 t dimensions of the machine ca.:6,0 x 2,5x 2,3 m High pressure coolant system:INterlit 8/20 bar spindle load monitor:B Spindle 1 Chuck:SMW 300 mm CNC Turning-and Milli ...
workpiece diameter:5-125 mm grinding depth:50-1000 mm clamping length:1000 mm total power requirement:1.9 KVA weight of the machine ca.:630 kg max. workpiece weight:100 kg Center Hole Grinding Machine. Workpiece must be rotated by machine during grinding
max. workpiece diameter:29 mm min. workpiece diameter:26 mm workpiece length:66 mm the system was originally delivered for the following workpiece sizes: diameter 26mm - 29mm length 65mm - 66mm Changing parts in the clamping device, handling, etc. would probably result in diameters of up to approx. Ø50mm Total length will probably be almost 400 mm possible with a few conversions. Also dependent on tool lengths, machining lengths on the component, etc. Workpiece: Piston pin Drawing number: WHT 000 718, WHT 000 718 A Workpiece dimensions (Ø, WxH): Ø26 x 66; Ø29 x 65 Length: 66 or 65 mm Material: 17Cr3 Quantity: xxx parts / year Cycle time: 5 sec. However, workpiece lengths up to 600mm are manageable. The machining diameter can be adjusted if the appropriate tools are available. The clamping station can currently only accommodate this product. However, this can be adapted by changing th ...
turning diameter:270 mm turning length:710 mm weight of the machine ca.:6,5 t max. swing diameter:590 mm with automatic loading and unloading system G300 with "spindle bore clamping capacity 90mm" in tailstock version The machine has no driven tools. The information in the circuit diagram refers to the rotary drive for indexing the turret, not to driven tools.
turning diameter:270 mm turning length:710 mm weight of the machine ca.:6,5 t max. swing diameter:590 mm with live tools:VDI40 Live tooling VDI40 with automatic loading and unloading system G300 with "spindle bore clamping capacity 90mm" in tailstock version Chip conveyor, belt filter press, hydraulic unit, as well as infeed and outfeed chain conveyor EWAP, with 33 pallets. The machine has no driven tools. The information in the circuit diagram refers to the rotary drive for indexing the turret, not to driven tools.
turning diameter:270 mm turning length:710 mm weight of the machine ca.:6,5 t max. swing diameter:590 mm with automatic loading and unloading system, chip conveyor G300 with "spindle bore clamping capacity 90mm" in tailstock version The machine has no driven tools. The information in the circuit diagram refers to the rotary drive for indexing the turret, not to driven tools.
turning diameter:120 mm turning length:650 mm weight of the machine ca.:11 t dimensions of the machine ca.:5,032 x 3,048 x 2,445 m Gildemeister MF Twin 65-II lathe with loading automation. This machine is suitable as a counter spindle machine for 4-axis machining on the main and counter spindles, complete machining (turning, drilling, milling, Y-axis, B-axis) of bar and shaft parts.
turning diameter:120 mm turning length:650 mm weight of the machine ca.:11 t dimensions of the machine ca.:5,032 x 3,048 x 2,445 m max. swing diameter:250 mm Gildemeister MF Twin 65-II lathe with loading automation. This machine is suitable as a counter spindle machine for 4-axis machining on the main and counter spindles, complete machining (turning, drilling, milling, Y-axis, B-axis) of bar and shaft parts.
