haas wafer used for sale

x-travel: 1016 mm y-travel: 660 mm z-travel: 635 mm control: Haas table surface area: 1.372 x 610 mm table load: 1.814 kg rapid traverse: 18 m/min turning speed range: 7.500 U/min power capacity - milling spindle: 22,4 kW tool taper: SK 50 | no. of tools in the magazine: 30 Stück weight of the machine ca.: 7,5 t dimensions: 3,5 x 2,47 x 2,98 m Vertical Machining Center - chipconveyor - external handwheel - Dual tool change arm - internal coolant - filter - 4th axis, 190 mm centre hight with tailstock - Oil dust collector The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-axis: 700 mm y-axis: 410 mm z-axis: 500 mm feed range: 30000 mm/min A-Axis: 175 mm C-axis: 320 ° workpiece dia.: 340-500 mm workpiece length: 700-1000 mm workpiece weight max.: kg max. dia. of grinding wheel: mm speed spindle max.: 8000 U/min. power capacity: 11,5 / 14,5 kW Control: Siemens 840 Dsl tool taper: HSK 50E table-size: 1200 x 500 mm total power requirement: - kVA weight of the machine ca.: 8,5 t dimensions of the machine ca.: 3 x 2,6 x 3,55 m 5 AXIS CNC TOOL AND CUTTER GRINDER - CNC Control Siemens 840Dsl - Milling Unit – Tooling - high-pressure coolant system - Tool Changer The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Haas Laser HL 1203D Optics Construction: 22-31-21-BX Laser class 4 1500 W 1064 nm More items - new and used - can be found in our shop! International shipping costs on request!

Baking Plates for PRO 1 Baking Machine - Condition: used - Engraving (Lower Baking Plate): approx. 5 x 5 mm - Engraving Depth (Lower Baking Plate): approx. 1,45 mm - Wafer Sheet Thickness: approx. 3 mm - Connecting Shaft: approx. Ø 16 mm - Collar radius: approx. 96,5 mm

CNC lathe Type: ST-20 Y Manufacturer: Haas Year: 2023 Control: Haas Max.turning diameter: 298 mm Max.turning length: 572 mm Swing over support: 533 mm X: 213 mm Z: 572 mm C-axis Y-axis: +/- 50.8 mm Driven tools Tailstock Tool probe X/Y/Z axis rapid traverse - 24.0/12.7/24.0 m/min Spindle cone: A2-6 Max. power: 14.9 kW, spindle drive Vector Drive Max. torque: 203 Nm Max. spindle speed: 4000 rpm Spindle bore: 63.5 mm Automatic hydraulic chuck: 210 mm Turret MBT65 : 12 position Max. speed of driven tools: 4000 rpm Drive of all positions of the BMT65 turret Coolant tank: 208 l with pump El. connection 3x400V/50HZ, 14kVA Machine weight: 5300 kg Linear rollers pre-tensioned axis guide Central automatic lubrication - axes with grease / spindle with oil Lighting of the working space Automatic hydraulic 3-jaw chuck A set of tool holders (only for BOT or HYBRID revo ...

Standard Features 2 roller system for thorough depilation Head scratcher also for the difficult to access head area Mobile on 4 castors Newly developed, reinforced transmission Special rubber racket (also on the back wall) Electric heating in an oil bath Integrated control and operating unit in the machine housing Swing-out rollers for cleaning the machine

Travel X/Y/Z: 1016mm/508mm/635mm, speed: 10000rpm, table dimensions X/Y: 1219mm/457mm, max. table load: 1550kg, tool positions: 20, rapid traverse X/Y/Z: 25m/min/25m/min/25m/min. Machine dimensions X/Y/Z: approx. 4000mm/2800mm/2600mm, weight: approx. 5400kg. Documentation available. On-site inspection is possible.

HAAS SL-20 THE CNC turning center was manufactured in 2008 in the United States by HAAS AUTOMATION, INC. The machine, designed for machining workpieces with a maximum diameter of 262 mm, offers an excellent combination of functionality, productivity and precision. Its extensive equipment includes e.g. a tool probe, an advanced CNC control and a C-axis for machining complex shapes. Over its entire service life, the SL-20 THE CNC lathe has worked for a total of 9586 hours. Technical specifications of the HAAS SL-20 THE lathe - maximum turning diameter: 262 mm - maximum turning length: 508 mm - maximum turning length between centers: 610 mm - maximum spindle rotational speed: 4000 rpm - spindle bore: 52 mm - spindle drive power: 15 kW - lathe chuck diameter: 210 mm - operating hours: 9586 h - power supply of the HAAS SL20 THE machine: 3x 360-480 V; 50/60 Hz Equipment of the H ...

Travel X/Y/Z: 406mm/305mm/254mm, table dimensions X/Y: 914mm/305mm, max. table load: 227kg. Spindle speed: 10000rpm, tool holder: BT40, tool positions: 10, rapid traverse X/Y/Z: 15.2m/min. Machine dimensions X/Y/Z: approx. 2350mm/2300mm/2700mm, weight: approx. 1550kg. Including an additional control panel on request (not included in the price). Documentation available. On-site inspection is possible.

HAAS ST-10 CNC turning center was built in 2015 in the United States by HAAS AUTOMATION, INC. The machine, distinguished by its compact design and increased production cycle efficiency, is an excellent choice for both unit and series production. Workpieces with a maximum diameter of 356 mm are machined inside a large work space by means of a high-speed spindle and precision cutting tools taken from a 12-position turret. All this is complemented by intuitive CNC control with many useful functions. The HAAS ST10 CNC lathe weighs approximately 3600 kg. Technical specifications of the HAAS ST-10 metal lathe - CNC controller: HAAS - maximum turning diameter: 356 mm - maximum turning length: 356 mm - bar diameter: 44 mm - swing over tailstock: 597 mm - swing over cross slide: 413 mm - feed in the X/Z axis: 200/356 mm - rapid traverse in the X,Z axes: 30.5 m/min - maximum spindle ro ...

We are selling a Haas ST-20 turning center on behalf of a customer. The machine was installed and never used productively., - Control Options, - options package, - high-pressure coolant flow, - accessory package

HAAS DS-30 CNC lathe was built in 2013 in the United States by HAAS AUTOMATION, INC. The machine, designed for machining workpieces with a maximum diameter of 457 mm, offers excellent efficiency, reliability and precision. Inside a large workspace there are two spindles with a C-axis, which enable the machining of both sides of a workpiece in a single work cycle. The tool head, in turn, allows for the attachment of both fixed and driven tools. This solution increases the flexibility of the machine by enabling it to be adapted to specific production needs. All this is complemented by advanced CNC control with many useful functions. The HAAS DS30 CNC turning center weighs 7221 kg. Technical specifications of the HAAS DS-30 metal lathe - maximum turning diameter: 457 mm - maximum turning length: 660 mm - swing over bed: 806 mm - swing over cross slide: 527 mm - feed in the X/Z axis: ...

x-travel: 762 mm y-travel: 508 mm z-travel: 508 mm B-axis (table): +120/-35 Grad c-axis: 360 Grad control: HAAS für 5 Achsen tool piece magazine with: 40 Plätzen number of spindle speeds: 12000 U/min dimensions of the machine ca.: 4.3 x 2.35 x 2.8 m weight of the machine ca.: 8.5 t The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

HAAS ST-15 CNC lathe was built in 2020 in the United States by HAAS AUTOMATION, INC. This highly efficient machine with a compact design is an excellent choice for both unit and series production. Workpieces with a maximum length of 406 mm are machined inside a large workspace by means of a high-speed spindle and precision cutting tools, taken from a 12-position turret. All this is complemented by intelligent CNC control, in which advanced machining programmes are created in just a few steps. The HAAS ST15 CNC turning center weighs 3584 kg. Technical specifications of the HAAS ST-15 metal lathe - CNC controller: HAAS - swing over over bed: 419 mm - bar diameter: 64 mm - maximum turning length: 406 mm - feed in the X/Z axis: 200/406 mm - rapid traverse in the X,Z axis: 30.5 m/min - thrust force in the X,Z axis: 14679 N - maximum spindle rotational speed: 4000 rpm - maximum spi ...

Electrically heated process vessel capacity 90 litres Filling device Manufacturer: Haas Type FMSX composed of: Electrically heated agitator tank with a capacity of approx. 90 litres Heated Mouvex piston pump, electric heater, control cabinet with Siemens PLC and FU for pump and agitator, in a mobile stainless steel frame.

Inv. Num. : 8550 Type: VF-3 Producer: HAAS Created: 2017 Parameters: Control system: HAAS Work table length: 1219 mm Work table width: 457 mm Maximum table load (uniform): 1588 kg Spindle drive power: 22.4 kW Speed: 8100 1/min X-axis travel: 1016 mm Y-axis travel: 508 mm Z-axis travel: 635 mm Cone: BT 40 Machine weight: 5316 kg

Key data: 762 mm, 406 mm, 506 mm

CNC Vertical Machining Center CNC Control Haas CNC Table size 914 x 356 mm Table load 680 kg Number of pallets: 1 x X-axis travel 762 mm Y-axis travel 406 mm Travel Z-axis 508 mm Spindle holder DIN 68971A Spindle speed 12,000 1/min Spindle motor 22.4 kW Magazine capacity 24 + 1 If you have any questions about the machine, as well as an appointment for a viewing, please contact us by phone or e-mail. Feel free to check out our other ads for a full overview of our stock.

We are offering for sale a Haas SL-30BHE with a Iemca Barfeeder Haas SL-30BHE - Voltage: 360–480 - Phase: 3 - Frequency (Hz): 50/60 - Full Load Current: 40 Amps - Largest Load: 70 Amps - 3400 rpm Ø102mm bore - Hainbuch SK80 - USB - Conveyor - Toolsetter - Rigid tapping - 12 x VDI40 turret - Partcatcher Iemca Bar Feeder - Model: KID 80 - Year of Manufacture: 2008 - Weight Capacity: 500 Kg - Rated Voltage: 400 V - Phase: 3 ~ - Frequency: 50 Hz - Rated Current (Ie): 3.5 A - Short-circuit Capacity (Icn): 5 kA Find more here - / Contact us at -

Manufacturer: Haas Model: ST-30 Year of Manufacture: 2011 Voltage: 360–480 V Phase: 3 Frequency (Hertz): 50/60 Hz Full Load Current: 40 Amps Largest Load Current: 70 Amps Short Circuit Interrupting Capacity: 10,000 Amps Certification: CE 3400 rpm Ø75mm bore 10" chuck Livetool og C axis Toolsetter Conveyor 12 x VDI40 turret Tailstock Find more here - / Contact us at -

Dehairing machine Manufacturer: HAAS Stainless steel Engine: 2.2kW

Manufacturer: Haas Model: ST-20Y Year of Manufacture: 2016 Voltage: 400V Phase: 3 Frequency (Hertz): 50/60 Hz Full Load Current: 27 Amps Largest Load Current: 18 Amps Short Circuit Interrupting Capacity: 10,000 Amps Wiring Diagram Reference: 96-0284 Short Circuit Current Rating: 5,000 Amps RMS symmetrical Find more here - / Contact us at -

The machine is in good technical condition, after prior agreement it is possible to test it. 620 hours as new.

CNC vertical machining center Type: VF-9 D/40 HE Manufacturer: HAAS Year: 2006 Control: Haas X: 2134 mm Y: 1016 mm Z: 762 mm Table: 2134 x 914 mm Max table load: 1814 kg Max spindle speed: 10000 rpm Through spindle cooling Machine weight: 12837 kg In good condition, fully functional, under power Find more here - / Contact us at -

WORKING RANGE -CUBIC-   X-axis travel: 1270 mm   Y-axis travel: 660 mm   Z-axis travel: 635 mm SPINDLE / HEAD   spindle revolutions (max): 7500 /min BASIC FUNCTIONS   number of spindles: 1   number of turrets: 0   live positions: yes   number of c-axes: 0   number of y-axes: 1   number of b-axes: 0 ATTACHMENTS   chip conveyor: yes WORKING RANGE TURNING   swing diameter (max): 635 mm   worpiece length max.: 1372 mm   workpiece weight max.: 1814 kg MAIN SPINDLE   spindle revolutions (min): 0.001 /min   spindle revolutions (max): 7500 /min X/Z SLIDE   Z-axis travel: 635 mm   X-axis travel: 1270 mm   Y-axis travel: 660 mm TOOL MAGAZINE   tool diameter max.: 178 mm   tool length max.: 406 mm   tool weight max.: 13.6 kg

Inv. Num. : 8854 Type: MINIMILL HE Producer: HAAS Created: 2006 Parameters: Control system: HAAS Work table length: 914 mm Work table width: 305 mm Maximum table load (uniform): 227 kg Spindle drive power: 7.5 kW Maximum vertical spindle speed: 6000 1/min X-axis travel: 406 mm Y-axis travel: 326 mm Z-axis travel: 381 mm Cone: ISO 40 Number of all tools: 10 pieces Machine height: 2565 mm Machine length: 2119 mm Machine width: 2077 mm Machine weight: 2018 kg

HAAS ST-20Y CNC lathe was built in 2022 in the United States by Haas Automation Inc. The machine has only worked for 119 hours to date and is like brand new. The HAAS ST-20Y is an excellent choice for the modern business. This is because it makes it possible to perform versatile 4-axis machining of the highest quality on any workpiece. All machining processes, i.e. milling, threading and drilling are performed by means of driven tools and a spindle with synchronised C axis. The 12-position BMT turret offers high productivity thanks to the larger contact area between tooling, toolholder and the turret itself. The operator, on the other hand, has at their disposal an advanced HAAS CNC control with a Visual Programming System (VPS), which significantly improves the daily operation of the machine. The VPS uses graphical templates to facilitate the creation of G-codes for even the most  ...

Inv. Num. : 8856 Type: SL-10 THE Producer: HAAS Created: 2006 Parameters: Switch-on hours: 23550 h Hours: 13463 h Maximum turning length: 355 mm Maximum turning diameter: 279 mm Maximum turning diameter over bed: 252 mm Maximum turning diameter over support: 203 mm Maximum length of travel in the X-axis: 159 mm Max. travel length of the Z-axis: 356 mm Maximum spindle speed: 6000 1/min Weight: 2500 kg Equipment: Collet chuck Universal chuck

x-travel: 1016 mm y-travel: 660 mm z-travel: 635 mm control: Haas table surface area: 1.372 x 610 mm table load: 1.814 kg rapid traverse: 18 m/min turning speed range: 7.500 U/min power capacity - milling spindle: 22,4 kW tool taper: SK 50 | no. of tools in the magazine: 30 Stück weight of the machine ca.: 7,5 t dimensions: 3,5 x 2,47 x 2,98 m Vertical Machining Center with 4th axis - chipconveyor - external handwheel - Dual tool change arm - internal coolant - filter - 4th axis, HRT 210 A - prepared for cableless 3D touch probe - oil dust collector - tool measuring The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Franz Haas TRO 80 automatic line for the production of standard Wafer Cones Capacity: 5600 pieces/hour Incl. Drum Roller Incl. Transfer conveyor unit with wafer turner Incl. Cooling unit Incl. Automatic cone sleeving unit

Key data: 1270 mm, 508 mm, 635 mm

Haas VF-4DHE CNC Vertical Machining Center CNC Control Haas CNC Table size 1,321 x 457 mm Table load 1,588 kg Number of pallets: 1 x X-axis travel 1,270 mm Y-axis travel 508 mm Travel Z-axis 635 mm Spindle holder MAS BT40 Spindle speed 40 - 8,100 1/min Spindle motor 22.4 kW Magazine capacity 24 + 1 If you have any questions about the machine, as well as an appointment for a viewing, please contact us by phone or e-mail. Feel free to check out our other ads for a full overview of our stock.

Franz Haas VTRO 48 automatic line for the production of standard Wafer Cones Capacity: 3100 pieces/hour Incl. Drum Roller Incl. Transfer conveyor unit with wafer turner Incl. Cooling unit Incl. Automatic cone sleeving unit

- Number of baking plates: 76 - Output: approx. 4000 pieces / hour - Cone size: max. 195 mm Equipment: - Incl. winding head - incl. Stacking table - incl. cooling band

5-axis CNC machining center Type: UMC-750 Manufacturer: Haas Year: 2020 X: 762 mm Y: 508 mm Z: 508 mm Tool magazine 30+1 positions Spindel taper: ISO 40 Max spindle speed: 12000 rpm Chip conveyor Machine in good condition, under power. Find more here - / Contact us at -

This HAAS TM 2 Vertical Machining center was manufactured in the year 2021. It is equipped with a HAAS control unit. The machine has a spindle speed of 4000 rpm.

This HAAS SL-30 was manufactured in 2003. A robust horizontal turning machine featuring X/Z travel of 318/660 mm, turning diameter of 533 mm, and length of 660 mm. It includes a bar capacity of 76 mm, spindle power of 22.4 kW, and a maximum spindle speed of 3,200 rpm. Equipped with a 12-position tool turret and a semi-automatic hydraulic tailstock. Consider the opportunity to buy this HAAS SL-30 horizontal turning machine. Contact us for more information.

This 3-axis HAAS Vf-9/40 vertical machining center was manufactured in 2017. It offers robust capabilities for precision machining. Consider the opportunity to buy this HAAS Vf-9/40 vertical machining center. Contact us for more information.

This lathe machine was manufactured in 2015. Equipped with a D160 Hydraulic chuck and a D45mm main spindle bore, it boasts reliability and precision. Featuring a 12-piece turret head, VDI-40, and hydraulic programmable tailstock, it ensures versatile machining operations. With 42597 hours of power on and immediate availability, this HAAS ST-10 presents an opportunity for efficient production. For further details, contact us.

Key data: 762 mm, 508 mm, 508 mm

2023 HAAS UMC-750SS 5-Axis CNC Vertical Machining Center Condition: Used Location: USA Description This 2023 HAAS UMC-750SS is in excellent condition and ready for continued productive service. The machine has been well maintained and represents a strong opportunity for high-speed 5-axis machining. Specifications have been compiled from inspection, operator input, manuals, and OEM sources. Buyers are encouraged to independently verify all specifications, condition details, and availability prior to purchase. Price, location, and specifications are subject to change. Specifications Travels • X-Axis: 30” (762 mm) • Y-Axis: 20” (508 mm) • Z-Axis: 20” (508 mm) • Number of Axes: 5 Spindle • Power: 30 HP (22.4 kW) • Max Speed: 15,000 RPM • Taper: CT40 or BT40 Tool Changer • ATC Capacity: 40 tools Table • Table Width: 19.7 ...

This 3-axis HAAS ST-30Y horizontal turning machine was manufactured in 2022. It features a 10-inch chuck, a maximum cutting diameter of 13.75 inches, and a cutting length of 32.5 inches. The machine includes a 12-station BMT-65 turret and live tooling speeds up to 4,000 rpm. Y-axis capabilities allow for off-center milling, drilling, and tapping. Consider the opportunity to buy this HAAS ST-30Y horizontal turning machine. Contact us for more information.

This HAAS SL-30HE was manufactured in 2007. A robust horizontal turning machine featuring a turning diameter over bed of 762mm and a length of 860mm. It includes a VDI tool turret with 12 positions and a chip conveyor. Ideal for precise and efficient turning operations. Contact us for more information about this machine.

This HAAS TR160 with Sigma 5 was manufactured in 2016. It features a 2-axis table and is equipped with a Sigma 5 servo motor, ensuring precise and efficient operation. Ideal for those looking to enhance their machining capabilities. Contact us for more information.

This 3-axis HAAS SL-30 was manufactured in 2001. A robust horizontal turning machine featuring a 3400 rpm spindle, Ø76mm bore, and a 10 chuck. It includes a tailstock, 12 x VDI40 tool stations, a toolsetter, and a conveyor. If you are looking to get high-quality turning capabilities consider the HAAS SL-30 machine we have for sale. Contact us for more information.

The machine is in very good technical condition, testing is possible by prior arrangement.

This 4-axis HAAS ST-15Y was manufactured in 2019 and features Y and C axes with driven tools, D210 hydraulic chuck, 65 mm spindle bore, hydraulic programmable tailstock, 12-station VDI-40 turret, and chip conveyor. If you are looking to get high quality turning capabilities consider the HAAS ST-15Y machine we have for sale. Reach out for more information.

CONTROLS   CNC controls HAAS WORKING RANGE -CUBIC-   number of processing axes (excl parallel axes): 3   X-axis travel: 3048 mm   Y-axis travel: 1016 mm   Z-axis travel: 762 mm TABLE   table surface (left-right): 3048 mm   table surface (front-back): 711 mm SPINDLE / HEAD   drive power: 15 kW   tool fixture: ISO SK 40 TOOL MAGAZINE   magazin type: disc magazine   number of positions: 24 ELECTRICAL SPECIFICATIONS   total power consumption: 15 kW DIMENSIONS / WEIGHTS   space requirements -left/right-: 6528 mm   space requirements -front/back-: 3531 mm   total height: 3105 mm   total weight approx.: 15368 kg ATTACHMENTS   autom. tool clamping: yes   chip conveyor: yes   coolant unit: yes   closed cabin: yes   European CE standards: yes Under power A lot of tools Delivery to enduser 2008

This HAAS ST-40 was manufactured in 2018. It features a 15-inch chuck, a maximum part swing of 35.5 inches, and a cutting diameter of 30 inches. The machine includes a 2-speed gearbox spindle, capable of 2,400 rpm, and a 12-station BOT turret. Additional equipment includes a belt-type chip conveyor and a programmable servo tailstock. Consider the opportunity to buy this HAAS ST-40 horizontal turning machine. Contact us for more information about this machine.

This HAAS SL-30TBHE was manufactured in 2008. A robust horizontal turning machine featuring a spindle speed of 3400 1/MIN, 22 kW motor power, and a swing over bed of 762 mm. It includes a 12-position turret, hydraulic tailstock, and both 3 jaw and collet chucks. Dimensions are 3900x2000x1900 mm. Consider the opportunity to buy this HAAS SL-30TBHE horizontal turning machine. Contact us for more information.

control: Haas Automatic : 3 Backen x-travel: 850 mm changer: 12 fach serial number: 70422 total power requirement: 22 kW weight of the machine ca.: 4,5 t The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

This 3-axis HAAS ST-20Y was manufactured in 2014. It features a CNC lathe with C and Y-axis capabilities, a spindle speed of 4000 rpm, and a chuck size of 8 inches. Additional features include a 12-station turret, chip conveyor, and a programmable hydraulic tailstock. Ideal for precision turning operations. If you are looking to get high-quality turning capabilities consider the HAAS ST-20Y machine we have for sale. Contact us for more information about this machine.

This 4-axis HAAS MIKRON VCE 750 was manufactured in 1997. It features a table surface of 900x350 mm, a table capacity of 340 kg, and movements of X 750 mm, Y 410 mm, and Z 500 mm. The spindle operates at 8000 rpm with a power of 7.5 kW. Regular maintenance and recent updates ensure reliability. Consider the opportunity to buy this HAAS MIKRON VCE 750 vertical machining centre. Contact us for more information about this machine.
