121,993 used machines on RESALE, but how to find them? Machine Search
maximum number of results exceeded > 1000
please refine your search
used
JOTES SPD 30B surface grinding machine of Polish production is a manufacturing machine with horizontal spindle axis that performs grinding on the periphery of the grinding wheel. The workpiece of maximum length 1000 mm and width 300 mm is mounted on a rectangular electromagnetic table or directly on the grinding machine table. The work table moves on the base guideways and the change of its direction of movement can be performed automatically by bumpers or manually by adjusting a suitable lever. The hydraulic drive of the machine’s work table allows continuous adjustment of the speed in the range from 2 to 30 m/min. The installed grinding wheels, with a diameter of 350 mm and a width of 63 mm, are driven by an electric motor mounted directly on the grinding wheel spindle. The grinding wheels are moving at a peripheral speed of 26 m/s. The total weight of the magnetic surface grin ...
used
The belt sanding machine Ghermandi Caliber 300 2NT, type CL 300M RT 2N, is a robust and reliable machine, perfect for sanding metals, wood and plastics. With an output of 33.5 amperes and 380 volts, it is particularly powerful and can easily handle even heavy grinding work. The machine has a wide grinding table that provides a large grinding surface and allows precise work. The grinding table is also height adjustable to ensure an optimal sanding position. In addition, the belt sanding machine Ghermandi Caliber 300 2NT is equipped with a powerful motor and a stable belt run, which ensures uniform grinding quality. Thanks to its compact design and sturdy housing, the belt sanding machine Ghermandi Caliber 300 2NT is very durable and easy to operate. It is perfect for craftsmen, industrial companies and workshops that place high demands on their grinding machines. If you are looki ...
used
grinding height: 60 mm grinding width: 120 mm grinding wheel diameter: 600 mm grinding length: mm workpiece height: 60 mm total power requirement: 50 kW weight of the machine ca.: 7000 kg dimensions of the machine ca.: m D I S K U S (Germany) Double Side Vertical Spindle Surface Grinder, C-Frame Design, with Rotary Workpiece Feeding System and Automatic Dressing Device Model DDS 600 CR-A Year 1969 Serial-No. 6672 ______________________________________________________________________ ________ Grinding wheels Ø x bore, each 600 mm Grinding wheels height x width, approx. 60 mm Workpiece dimensions: Grinding height x grinding width, approx. 60 x 120 mm Vertical adjustment of each grinding head 150 mm External Ø of workpiece carrier disk, approx. 810 mm Feeds of rotary workpiece feed system 1 ...
used
grinding length: 750 mm grinding width: 500 mm workpiece height: 500 mm total power requirement: 50 kW weight of the machine ca.: 5000 t Grinding length, max. 750 mm Grinding width, max. 500 mm Cross movement of grinding slide 450 mm Working height under grinding wheel, max. 500 mm Grinding wheel size Æ 400 x 100 mm Grinding wheel speeds, infinitely variable 300-3,000 rpm Table speed, hydr. 0 - 30 m/min Table speed, creep feed 0.02 - 1,000 mm/min Vertical infeed, infinitely variable 0.002 - 0.03 mm/stroke Grinding spindle drive, max. 32 kW Total electrical load, approx. 50 kW - 380 V - 50 Hz Weight approx. 5,000 kg Accessories / Special Features Creep feed: Electro-mechanical feed (but also hydraulic table movement), with digital display, programable by cam limit switches. Infinit ...
used
Internal circular grinding machine with plan grinding equipment, second-hand internal and face grinding machine, used Type / type: SI 6/1 x 315 Manufacturer / make: WMW Year / year of make: 1983 schleifbarer the protection of workpiece diameter / grinding diameter: inner / internal 20... 400 mm; outside / external 500 mm maximum workpiece diameter workpiece protection /. maximum diameter of work piece: 500 mm Max grinding depth / maximum grinding length: 315 mm schleifbarer angle of cone / cone grinding: 60 ° Internal grinding motor power / power drive motor grinding of internal: 7,5 kW Internal grinding spindle speeds / rev's of internal grinding spindle: 2640... 16500 RPM Power cylindrical grinding device / power drive of face grinding attachment: 4 kW Power work-piece motor / power drive of workpiece engine: 1.5 kW Workpiece spindle speeds / rev's piece of work s ...
used
The NEW CNC grinding VERECO RG 700/8500 is designed for the batch production of bench pins and connecting rod pins of crankshafts in a fully automatic cycle, or, for the production of individual parts in manual. It operates by means of a mobile grinding wheel unit both on the X axis and on the Z axis: this allows the grinding of different diameters in a single positioning of the piece. MAIN TECHNICAL FEATURES: Distance between tips: 8500 mm Drill height: 800 mm Maximum rotating Ø: 1600 mm Maximum weight of the balance piece: 10,000 kg Maximum grinding wheel dimensions (with recesses): 1600x900x160 mm Approximate machine weight: 98.000 kg NB: The aforementioned technical data, collected from the technical data sheet of the manufacturer, are to be considered non-binding and subject to change without notice. NUMERICAL CONTROL The Siemens 840 D electronic numerical contro ...
used
grinding diameter max.:10 - 175 mm regulating wheel width:610 mm max. width of grinding wheel:610 mm Maximum opening between new wheels:250 Recommended working range:10 - 175 mm Maximum workpiece lenght for infeed grinding - normal wheels:605 mm Maximum workpiece lenght for infeed grinding - recessed wheels:695 mm grinding wheel diameter:610 mm grinding wheel dia. (used wheel):380 mm grinding wheel width:610 mm Maximum witdth of receddes wheel:700 mm grinding wheel hole diameter:304,8 mm Peripheral speed:63 m/sec. dia. of control wheel:330 mm Outer diameter of worn wheel:255 mm regulating wheel width:610 mm Maximum witdth of receddes wheel:660 mm regulated disc boring:203 mm Speed of regulating wheel:10 - 850 1/min. control wheel inclined adjustable:5 Grad weight of the machine ca.:12 t dimensions of the machine ca.:4,8 x 2,1 x 1,1 m Centerless wide-wheel grinding machine for infeed oper ...
used
M 1105-02800 Machine type Cylindrical Grinding Machine - Universal Make ZIERSCH & BALTRUSCH Type URS 751 Built in 1982 Control type conventional Storage location HAGUENAU Country of origin Germany Delivery time immediately Freight base from stock Technical details Grinding diameter 270 mm Grinding length 1000 mm Tip height 135 mm Total power requirement 7.5 kW Machine weight approx. 2.8 t Room requirement approx. 3 X 2.7 X 2.5 m Information ZIERSCH & BALTRUSCH Hydraulic Universal ROUND SCHLEIFMASCHINR Type URS 751 1982 built _________________________________________________ Tip height 135 mm Tip width/grinding length 1000 mm Tip width approx. 1100 mm Grinding wheel size: Through. x Width 400 x 50 mm Grinding spindle speeds (belts) 1,800 2,200 rpm Delivery path/rapid path 0.001 / 30 mm Grinding wheels delivery 0.0 ...
used
grinding diameter: 100 mm grinding length: 250 mm feed in: 200 mm working area: mm speed: m/min Bar length: mm total power requirement: 25 kW weight of the machine ca.: 4.500 kg dimensions of the machine ca.: m K O E N I G & B A U E R (Germany) Centreless Grinder with Plunge-in Grinding Device Model Multimat 150 - 5 Year approx. 1978 S/Nr. 73 918 _______________________________________________________ Grinding Ø regular/maximal 2 – 50/100 mm Max. length of workpiece for Thru-Feed-grinding 250 mm Max. length of workpiece for plunge-cut grinding 200 mm Grinding wheel size, Ø x width 600 x 200 mm Regulating wheel size, Ø x width 300 x 200 mm Grinding wheel speed, max. 1.450 rpm/35 m/sec. Regulating wheel speeds (stepless) 10 – 140/230 rpm Regulating wheel tilt plus/minus ...
used
The grinding block machine from Oskar Pensel & Sohn Jserlohn is a powerful tool for professional use in workshops and industrial companies. With a robust construction and high-quality components, it offers a reliable and precise grinding solution. This grinder machine is equipped with two grinding wheels that offer speeds of 1700 and 2200 revolutions per minute (rpm). Thanks to the two independent motors, each with 2.2 hp power, you can adjust the speed to your requirements and efficiently process a wide range of materials. The machine type 764M15B is characterized by its high stability and durability. It provides a solid base for precise grinding and allows you to have precise control over the grinding process. The grinding block machine is ideal for deburring, sharpening, polishing and forming various workpieces. For further details about the grinder block machine, please do n ...
used
Description: Suitable for manual grinding of cutting, milling and drilling tools such as end mills, shell end mills, Radius milling cutters, end milling cutters, thread taps, step drills, etc. on the circumference, end face and spiral. Accesories : optical length and angle measuring device with measuring microscope cylindrical grinding device 1 dressing device for radii 3 grinding wheel guards 3 cover discs 2 dividing discs 10 grinding wheel mounts, Workpiece diameter between the centers: 238 mm, grinding stroke max.: 110 mm, Grinding stroke max.: 190 mm, Vertical adjustment of grinding head: 325 mm, Cross adjustment tool slide: 100 mm, Grinding head carrier swivelling: 360 °, Vertical adjustment of the grinding head: 325 mm, Tool carrier swivelling: 360 °, Grinding spindle speeds infinitely variable from: 2,000 - 10,000 rpm,, Connected load: 2.0kW (400V/50Hz), Dimensions L x W x H: 11 ...
used
max. grinding diameter: 300 mm grinding length: 500 mm workpiece length: mm Number of axles: 6 St. centre height: 220 mm centre distance: 500 mm x-axis: 500 mm y-axis: 320 mm z-axis: 320 mm total power requirement: 5 kW weight of the machine ca.: t dimensions of the machine ca.: m Height of centres 200 mm Distance between centres / clamping length 750 / 500 mm Table size 290 x 1,600 mm Intermediate table 110 x 1,200 mm X / Y / Z axes 500 / 320 / 320 mm Feed speeds, X, Y & Z axes 0.005 - 5 m/min Grinding head swivelling, vertical axis (B axis) 300 ° Grinding head tilting (C axis) +/- 30 ° Speed range of R axis 0 - 50 rpm Grinding spindle speeds, approx. 5,000 - 10,000 rpm Workpiece holding fixture 50 ISO Indexing 1 - 999 ° Leads 0.5 - 10,000 mm Spindle drive 4 kW Total electrical load, approx. 10 kW - 380 V - 50 Hz Weight, approx. 4,000 kg Accessories / Special Features SCHÜTTE CNC ...
used
TACCHELLA ELEKTRA 1518 MPC CNC grinding machine was built in Italy in 1999. Characterised by high reliability and performance, the machine is used in the process of highly accurate grinding of the external rotating surfaces of workpieces with a maximum length of 1500 mm and a diameter of 350 mm. The TACCHELLA CNC shaft grinding machine has a large workspace with tailstock, grinding wheel spindle and workpiece spindle. After placing a shaft with a maximum weight of 50 kg in the spindle holder, the workpiece is ground at high speed by an incremental encoder driven grinding wheel with a maximum diameter of 450 mm. In order to simplify the machining process, the ELEKTRA 1518 MPC CNC grinding machine is equipped with state-of-the-art features, such as the HOFLER BALANCE SYSTEMS VM 24 operator panel and a functional and user-friendly FAGOR CNC controller, which allows full control of the m ...
used
GEIBEL UND HOTZ FS 420 SC surface grinding machine manufactured in 2006 in Germany, is designed for single or serial grinding of workpieces. The machine, distinguished by its high performance and reliability, machines workpieces with a maximum weight of 150 kg with the circumference of grinding discs on a magnetic plate with holding force control and demagnetisation function. During the process, special sensors ensure that the grinding wheel is properly balanced, guaranteeing the highest precision and quality of machining. The GEIBEL & HOTZ FS 420 SC magnetic grinding machine uses an energy-efficient hydraulic system to drive the work table, which provides the exact oil flow required to move the table. The pump is equipped with special filters to remove ferromagnetic impurities and non-magnetic substances from the coolant, resulting in safe and trouble-free operation of the grinding m ...
new
3000 B CNC circular saw blade grinding machine was built in 2023 in Poland. The brand-new machine, equipped with intuitive software and a CNC controller with memory for 128 programmes, is used to sharpen the following types of circular saws, mainly used in the furniture industry for cutting laminated chipboard: – flat circular saws (GM) – alternately mitre circular saws (GS) – trapezoidal circular saws (GB) – trapezoidal-flat circular saws (GA) The 3000 B CNC circular saw sharpener allows for grinding tooth rake angles and tooth face angles in a single pass without removing the saw blade. The grinding wheel arrives at the tooth plane at two feed speeds – the slower feed increases grinding precision, while the faster one reduces sharpening time by up to half. To ensure precise feeding of the tooth under the grinding wheel, a claw feeder is used, which prevents the grindin ...
used
grinding diameter:250 mm grinding length:630 mm centre height:125 mm control:Siemens S7 swing diameter:280 mm centre distance:630 mm grinding head swivelling:90 ° table swivelabel +/-:+10/-7 ° grinding wheel dia. x width x bore:400 x 40 x 127 mm grinding wheel dia. according abrasion:250 mm max. grinding wheel width:63 mm swing in open rest:70 mm swing in closed rest:70 mm taper bore of workpiece spindle:4 Morse taper of tailstock quill:4 Morse stroke tailstock centers:30 mm clamping force tailstock center:50-1500 s grinding head swivellable +/-:+15/-45 ° output of wheelhead motor:4 kW work piece motor:0,7 hydraulic motor:1,1 kW cool pump motor:0,155 kW lubrication pump motor:0,155 kW electro motor internal grinding:0,75 kW total power requirement:10 kVA weight of the machine ca.:3000 kg dimensions of the machine ca.:L3000/B2300/H1600 mm stepless spindle speed:und Werkstückantrieb M ...
used
grinding diameter: 450 mm grinding length: 1000 mm centre height: 225 mm total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m As the world’s leading company in Kellenberger overhaul and retrofit we are not only able to deliver machines in a quality similar to a new machine and with warranty, but we can also offer you the service for your machines.The machine will be delivered overhauled. Mechanical overhaul: • Overhaul of the entire machine according to Kellenberger measuring protocol • A new service-friendly cabin • Repainting Electrical overhaul: • New, modern CNC cylindrical grinding machine control system • New built up control cabinet • New drive technology • Exchange of all electric lines, Berus pressure switch, etc. • New absolute glas scales in X- and Z- axis • New absolute rotary encoder (for B-axis) Please remark ...
used
internal diameter: 120 mm grinding depth: 200 mm swing diameter: mm total power requirement: 4 kW weight of the machine ca.: t dimensions of the machine ca.: m Grinding diameter, internal, max., approx. 3 - 120 mm Grinding depth, approx. 200 mm Height of centres above rotating workpiece slide 132 mm Max. swing Ø in front of rotating workpiece slide, approx. 450 mm Work spindle admission 40 mm Table stroke, max. (Z axis) 480 mm Workpiece cross adjustment (X axis) 50 mm Turret head cross adjustment (U axis) 50 mm Workspindle head swivelling (B axis) -30 / +45 ° (manual) Speeds of workspindle, infinitely variable 75 - 1,300 rpm Grinding spindle speeds 9,500 - 150,000 rpm Grinding spindle drive 4 kW Total electrical load, approx. 8 kW - 380 V - 50 Hz Weight, approx. 3,000 kg Accessories / Special Features TRIPET (Bruetsch) CNC Control for 3 axes (Z, X and U) with electric hand wheel, with ...
used
The ZVL BRH 40A II surface grinding machine was manufactured by the Czechoslovak concern ZVL, the Powaska Bystrzyca bearing production plant in 1985. The grinder is designed for grinding flat surfaces of various metal products, with a maximum length of 1500 mm, a width of 470 mm and a height of 500 mm. The machine has a work table with dimensions of 400 x 1500 mm and a 7.5 kW spindle, rotating at a speed of 1920 rpm. The total weight of the grinder is 4520 kg. The machine is offered with accessories. Characteristic parameters of the surface grinding machine ZVL BRH 40A II - working surface of the grinding table: 400 x 1500 mm - maximum grinding length: 1500 mm - the longest longitudinal table travel, manual: 1700 mm - maximum width of grinding: 470 mm - maximum height of grinding: 500 mm - the greatest load of the working table: 500 kg - the greatest transverse travel of the ...
used
PONAR KOWARY NUA 25 tool grinding machine was built by the Polish company PONAR KOWARY (LAKFAM) in 1984. A machine characterised by a robust construction of high stability, is used in tool shops and workshops for precision grinding of tools and tooling. Grinding of workpieces is performed on a table with a surface area (L x W) of 915 x 135 mm with two handwheels for manual longitudinal movement (X axis) and transverse movement (Z axis) of the work table. The reliable grinding wheel spindle moving at 3850 and 5635 rpm guarantees rapid and precise machining. The total weight of the machine is 910 kg. The machine is offered with the extensive range of equipment shown in the attached photos, which includes: – divider – angle vice 2 pcs. – moving tailstock: 2 pcs. – 3-jaw chuck fi 160 + spanner – workpiece centre positioning tool – fixed magnet – screw line tool – b ...
used
CN Centerless grinding machine, ROSSI MONZA 1500 CN, currently being overhauled and fully electrically/electronically retrofitted, Siemens electronics with touchscreen, brushless motor on Z (workpiece diameter) and regulating wheel (adjustable RPM), step motor on grinding wheel dressing increment, auto size compensation after grinding wheel dressing, Grinding wheel 350 mm 610 mm dia, This machine can be inspected in our warehouse in Gussago BS Italy Centreless grinding is a procedure for grinding cylindrical bodies and is used for mass production of rollers cylindrical, conical rollers, jet needles, pump pistons, hydraulic sliders, crosses, drills etc. During centerless plunge grinding, the workpiece is ground in one pass thanks to the translation of the grinding wheel. For this purpose, the grinding wheels and the adjustment discs have a negative profile of the piece to work which is g ...
used
Machine details 1105-02942 Machine type Flat Grinding Machine - Horizontal Make Sit Type R4 CA Built 1981 Control type Conventional Location France Origin Germany Delivery Right away Freight base EX WORK Price On request Technical details Grinding length 450 mm Grinding width 180 mm Workpiece height 300 mm Total performance requirements 9 kW Information Grinding length max. 500 mm Table stroke maximum 600 mm Grinding width max. 180 mm Table size 600 x 300 mm Working height under grinding wheel 500 mm Grinding head Vertical path 300 mm Vertical delivery 0.001 - 0.06 mm/stroke Grinding slide adjustment across 200 mm Grinding wheel size 400 x 150 x 305 mm Grinding wheel speed stfl. 47 - 970 rpm Table load.600 kg Table lifting speed max. 30 m/min. Grinding spindle drive 12 kW Total drive approx. 20 kW - 380 V - 50 Hz Weight approx. 2,00 ...
used
Grinding width mm 1300 Grinding units total 6 Ribbons 4 Grinding rollers 1 Steel roller Segment grinding shoe electronic Paint intermediate grinding Vacuum table Table height constant Grinding belt length mm 2620 Further technical data Machine control HEESEMANN SMA PC11/40 Oscillation HEESEMANN CSD Turning direction reversal Ionizing device Workpiece thickness min mm 3 Pass-through height mm 80 Grinding shoes total 1 Segment width mm 16 Grinding brush unit Roller grinding brushes Cleaning brush dust removal machine Main motor kW 31 Band speed max m/s 24 Grinding belt swarm. adjustable infinitely variable Feed max m/min 28 Feed Stepless Blow-off device grinding belt Segment control electromagnetic Aggregates frequency-controlled 5 Cross-bands adjustable infinitely variable Aggregate configuration w-q-s-q-q-q-b Pressure lamella rim unit transverse ...
used
Cylindrical grinding machine make RIBON type RUR-E-1000Year 1984Tip distance: 1000 mmTop height above table: 160 mmGr. grinding diameter: 320 mmhöchstzul. Weight between the tips: 70 kghöchstzul. Weight flying: 20 kgNormal size of the grinding wheel: 355 (410) x32x127 mmhöchstzul. Width of the grinding wheel: 60 mmDrm. the workpiece spindle bore: 24 mmMorse cone of the workpiece spindle: No. 4Morse cone of the tailstock: No. 3Morse taper of the red. Sleeve of the workpiece spindle head: no. 3Rotation speed of the grinding spindle: 1700/2100 rpm.Rotation speed of the workpiece spindle: 35-310 rpm.Table feed: 190-300-380-470-600-940 mm / p.Mautomatic grinding wheel feed p. Table turn: 0.005-0.01-0.015 mmGrinding wheel feed by hand lever: 0.005 mmGrinding wheel feed at each graduation of the handwheel: 0.005 mmMicro fine feed per line: 0.001 mmTilting of the table for taper grinding betw ...
used
Hydraulic internal and surface grinding machine make RIBON type RI 200Year of construction 1985sm. Grinding diameter: 6 mmmax. grinding diameter: 100 mmmax. grinding length: 200 mmmax. table lift: 400 mmTop height: 170 mm4 workpiece speeds: 155 - 455 rpm.2 spindle speeds: 14000/28000 rpm.Revolutions of the face grinding spindle: 4000 rpm.Speed of the table adjustable: 0 - 8 m / minkl. Feed of the internal grinding head: 0.005 mmautomat. Feed of the internal grinding head: 0.005 / 0.010 / 0.015 mmDrive power Workhead: 0.35 HPDrive power internal grinding head: 2 / 1.7 hpDrive power plane grinding head: 0.75 hpDrive power hydraulics: 1.4 hpDrive power cooling device: 0.15 hpDimensions L x W x H approx: 2200 x 1600 x 1600 mmWeight approx: 1500 kgWith- Internal grinding spindle- Face grinding head- Diamond stripperused, in very good conditionPrice on request.Delivery: ex warehouse or locatio ...
used
grinding diameter: 250,350,450 mm grinding length: 1000 mm centre height: 125,175,225 mm grinding wheel diameter: 400 mm grinding wheel width: 50 mm bore: 127 mm : MK5 work piece spindle speed: 20-400 U/min workpiece spindle - bore: mm grinding head swivelling: 360 ° grinding spindle head - swivable: 180 + - ° grinding spindle speed: 1500,1700,2200 U/min : 0,001-0,030 mm/Ø : 0-0,95 mm/Ø : ±8 ° longitudinal feed of the table: 1300 mm table speeds: 0,02-6 m/min : 130 kg : 130 inkl. Spannugkg kg : mm grinding depth: mm : 70 mm total power requirement: 6,5 kW weight of the machine ca.: 2,5 t dimensions of the machine ca.: 4,2 x 2,0 m As the world’s leading company in Kellenberger overhaul and retrofit we are not only able to deliver machines in a quality similar to a new machine and with warranty, but we can also offer you the service for your machines. Geometrically overhauled with ...
used
Suitable for automatic grinding of HM circular saw blades on the face and back in one clamping. All known Tooth geometries (flat, alternate, trapezoidal, etc.) can be ground automatically and in one pass. Accesories: full fairing wet grinding device Device for robot operation with automatic loading door Stepless grinding speed of the two grinding spindles from 1600 - 5500 rpm. Infinitely variable grinding speed and grinding path for each machining surface on the tooth. automatic central lubrication Software package for oscillating grinding of rake and clearance angles Automatic fire extinguishing device machine light Preparation for connection to central coolant supply, Circular saw blade diameter: 500 - 1440mm, Circular Saw Bore Diameter: from 16 mm, Tooth pitch: 6 - 180mm, grinding path: up to 25 mm, tangential relief angle: 0 to 25°, max. grinding wheel diameter: 200 mm, Grinding whe ...
used
WEINIG Rondamat 912, S/N 912-497 – fully automatic tool grinding machine • Automatic re-sharpening of straight planing knives in the cutter head with conventional or hydro-clamping • Automatic resharpening of cutters in the hydroplaning head (in front of the chest) • Automatic dividing head for up to 36 cutting edges • concentricity tolerance of less than 0.005 mm • Integrated coolant device • Table feed infinitely variable (forward / return) • Easy operation via membrane keypad and digital displays Specifications • Grinding mandrel D=50 mm • Planer head diameter min. 80 mm to max. 280 mm • Grinding length max. 260 mm • Table stroke 500 mm • Programmable knife count from 2 – 36 • Programmable grinding cycles per tool 1-9 • Clearance angle infinitely adjustable 15° – 35° • Axis angle max. 15° • Grinding spindle speed n=4,600 r ...
used
Monzesi Rossi Monza 500 centerless grinding Grinding wheel 250 500 auto plunge also available The machine is in our warehouse in Gussago BS, under power Mimu machine tools, Centreless grinding is a procedure for grinding cylindrical bodies and is used for mass production of rollers, cylindrical, conical rollers, jet needles, pump pistons, hydraulic sliders, crosses, drills etc., During centerless plunge grinding, the workpiece is ground in one pass, thanks to the translation of the grinding wheel. For this purpose, the grinding wheels and the adjustment discs have a negative profile of the piece, to work which is given to them with the aid of a tool., The through-feed grinding or also through grinding and longitudinal grinding: pieces, to be worked proceed uninterruptedly with axial feed through the rectification gap.ith axial advancement through the grinding gap.
used
Swivel Arm Vertical Grinding Machine DELTA Type LB 300 Swivel Arm Grinding Machine Fabr. No.: 0495 Year of construction 2004 Grinding range 330 x 140 mm Magnet 250 x 150 mm Grinding height Grinding wheel - magnet approx. 220 mm Grinding height Grinding wheel - clamping surface approx. 280 mm Center of center of column to center of spindle 300mm Grinding wheel diameter 178 mm Fine adjustment 0.01 mm Grinding wheel speed 2840 rpm. Motor power 2.2 kW Mains connection 380 volts, 50 Hz - Depth adjustment via handwheel on the right side of the spindle housing, fine adjustment via knurled wheel on the handwheel - mechanical magnet 250 x 150 mm, overall height 63 mm (grinding height without magnet approx. 280 mm) - Wet grinding device in the machine base - Dressing diamond for swivelling in Space requirement L x W x H 850 x 800 x 1630 mm Weight 380 kg very good condition; used
used
Description: High-quality Precision Rotary Table Grinding Machine with a grinding range of 800 mm and a table load of up to 1000 kg. Control system and Machine number Control system: SIEMENS , Machine number: 10 3419 0709 Working area Max. grinding area: Ø 800 x 500 mm Magnetic disc diameter: 800 mm Max. table load: 1000 kg Traverse paths and Speeds Max. grinding spindle speed: 3150 rpm Table speed: 0 - 50 rpm Max. transverse movement: 600 mm Transverse and vertical speed: 5 - 4000 mm/min Grinding medium data Standard cup grinding wheel (Øoutside x w x Øinside): 300 x 80 x 127 mm Standard grinding disc holder , Grinding wheel bore: 127 mm Clamping width: 25 - 40 mm Flange diameter: 175 mm Please take a look at the technical data and the layout plan s in the PDF file. grinding depth: 500 mm, grinding spindle speed: 3,150 rpm, control: SIEMENS, a ...
used
Center distance: 0 mm Grinding head Z-axis: 0 mm Center height: 0 mm CNC Brand: 0 CNC Model: 0 Technical data Centre height: 200 mm Distance between centres: 280 mm Max. grinding diameter: 200 mm Grinding-wheel diameter: 125 mm Taper in spindle:: 5 MT grinding spindle: Longitudinal way of table: 150 mm Transversal way of the table: 140 mm Slewing range of grinding head: horizontal: 90 ° vertical: 90 ° Grinding spindle speeds: number (steps): 3 from: 4500 rpm up to: 7100 rpm Voltage 50 Hz 3x: 380 Volt Grinding spindle motor: 3 HP Machine´s weight about: 560 kg Overall dimensions machine: Length: 620 mm Width: 500 mm Height: 1500 mm Various accessories: Set of collets Set of grinding wheel arbors Dividing plates Set of grinding wheels Grinding wheel guard
used
CNC Universal circular grinding machine SHU321C Brand new, never used. Control FANUC Series Oi-TC 2-axes machine. Diameter of grinding workpiece -external 8-320 mm -internal 30-250 mm Center height 165 mm Maximum grinding length -external grinding (center grinding) 710 mm -internal grinding (in chuck) 135 mm Maximum angle of table rotation -clockwise 3 degrees -counterclockwise 11 degrees Grinding wheel -dimensions for external grinding 450x50x203 mm -peripheral speed 35 m / sec Rotation angle of the grinding wheel ± 90 degrees Front saddle -30 degrees clockwise rotation angle -90 degrees rotation angle -speed range for external grinding 30-400 rpm Back saddle -size of the fixed center Morse N4 -Pinolite stroke 35 mm Cross feeding range 0.1- 4000 mm/min Range of longitudinal feeds 0.05-8 m / min Minimum cross feed 0.0005 mm Main motor power kW 5.5
used
Center distance: 0 mm Grinding head Z-axis: 0 mm Center height: 0 mm CNC Brand: 0 CNC Model: 0 Technical data Centre height: 200 mm Distance between centres: 280 mm Max. grinding diameter: 200 mm Grinding-wheel diameter: 125 mm Taper in spindle:: 5 MT grinding spindle: Longitudinal way of table: 150 mm Transversal way of the table: 140 mm Slewing range of grinding head: horizontal: 90 ° vertical: 90 ° Grinding spindle speeds: number (steps): 3 from: 4500 rpm up to: 7100 rpm Voltage 50 Hz 3x: 380 Volt Grinding spindle motor: 3 HP Machine´s weight about: 560 kg Overall dimensions machine: Length: 620 mm Width: 500 mm Height: 1500 mm Various accessories: Set of collets Set of grinding wheel arbors 6-jaw chuck diameter Cylindrical grinding attachment Set of grinding wheels Lamp Tool cabinet
used
internal diameter: 20/300 mm grinding depth: 250 mm swing diameter: 250 mm workpiece spindle - bore: 45 mm workpiece spindle swivable +/-: 25 ° taper setting angle of the workpiece column: 50 ° work piece spindle speed: 42 - 400 U/min grinding spindle speed: 10.000 U/min table speed -stepless-: 0,1 - 8 m/min grinding spindle drive: 4 kW power capacity: 10 kW weight of the machine ca.: 4.500 kg dimensions of the machine ca.: m : : : : : Internal grinding Æ, min./max. 20 / 300 mm Grinding depth 500 mm Table stroke, min./max. 5 / 800 mm Height of centres above table 250 mm Swing Æ in the table recess 600 mm Workspindle bore 62 / 45 mm Swivability of workpiece wheelhead 25 ° Max. taper angle which can be ground 50 ° Infeed, per stroke 0.0025 - 0.5 mm Worksp ...
used
grinding diameter max.: 130 mm regulating wheel width: 250 mm max. width of grinding wheel: 250 mm Control: Siemens Sinumerik 3 total power requirement: 35 kW weight of the machine ca.: 6500 kg dimensions of the machine ca.: m max.workpiece length for plunge-cut grinding 250 mm max.workpiece length for throughfeed grinding 300 mm grinding wheel size: diam. x width 600 x 250 mm regulating wheel size: diam. x width 350 x 250 mm grinding speed 35 / 45 / 60 m/sec. regulating wheel speed stfl. 8- 100 rpm (360 rpm) control wheel slide swivels + 2 to - 7° grinding wheel drive 22 kW total drive 35 kW equipped with: - Standard version with double bearing mounted grinding spindle and control spindle. - SIEMENS CNC control type Sinumerik 3 for control of all feeds, speeds and dressing programs. For rapid traverse approach, roughing, finishing, fine finishing and spark out, all feed and time ...
used
Centerless grinding machine - centerless Ghiringhelli M100 CNC 1A 400x100mm wheel CN 1 axis plunge + through feed grinding The machine can be seen working in our warehouse in Gussago BS. Mimu(dot)com machine tools Centreless grinding is a procedure for grinding cylindrical bodies and is used for mass production of rollers, cylindrical, conical rollers, jet needles, pump pistons, hydraulic sliders, crosses, drills etc., During centerless plunge grinding, the workpiece is ground in one pass, thanks to the translation of the grinding wheel. For this purpose, the grinding wheels and the adjustment discs have a negative profile of the piece, to work which is given to them with the aid of a tool., The through-feed grinding or also through grinding and longitudinal grinding: pieces, to be worked proceed uninterruptedly with axial feed through the rectification gap., Wheel width: 100, Wheel diam ...
used
Schneeberger Aries ENP4 CNC Precision Tool Grinding Machine Manufacturer [manufacturer]: Schneeberger Type [ type]: Aries ENP4 Control unit: Fanuc control, 2 CNC axes, simultaneous interpolation 10.4" LCD color touchscreen, RS232 Baujahr[construction year]: 10/2008 Tool and cutter grinder Note: Ideal for tooling and sharpening Optimal grinder for grooving, circumferential, flank, front, rear and flank surfaces Axes Longitudinal travel X mm 400 (CNC) Transverse travel Y mm 260 (CNC) Vertical travel Z mm 300 (CNC) Workpiece rotation A degree free (CNC) C-axis, manual, position indicator integrated in the control unit. Resolution of the measuring system: 0.001°, grinding head ±180° rotatable Center height mm 210 Landing cone ISO50 Spindle Drive power kW 2.2 / 7.5 Double spindle HSK 50 - (2 + 2 grinding wheels) Spindle speed 1/min 9000 Grinding wheel diameter ...
used
grinding diameter:600 mm grinding length:3000 mm centre height:315 mm workpiece weight max.:3000 kg work piece spindle speed:8 - 120 U/min grinding wheel motor:25 kW grinding wheel speed:45 m/sec grinding wheel width x diameter:750 x 80 mm table speeds:30 - 4500 mm/min feeds of grinding head:0 - 5 mm/min table swivelabel +/-:7,5 ° total power requirement:55 kVA weight of the machine ca.:18 t dimensions of the machine ca.:11,5 x 4 x 2,2 m - Internal grinding device - taper grinding up to 10,1° based on diameter - automatic grinding cycle - grinding wheels and flanges - dressing device - coolant attachment - dust exhauster, various steady rests
used
grinding diameter: 250,350,450 mm grinding length: 1500 mm centre height: 125,175,225 mm grinding wheel diameter: 400 mm grinding wheel width: 50 mm bore: 127 mm : MK5 work piece spindle speed: 20-400 U/min workpiece spindle - bore: mm grinding head swivelling: 360 ° grinding spindle head - swivable: 180 + - ° grinding spindle speed: 1500,1700,2200 U/min : 0,001-0,030 mm/Ø : 0-0,95 mm/Ø : ± 6 ° longitudinal feed of the table: 1750 mm table speeds: 0,02-6 m/min : 130 kg : 130 inkl. Spannugkg kg : mm grinding depth: mm : 80 mm total power requirement: 6,5 kW weight of the machine ca.: 2,9 t dimensions of the machine ca.: 5,6 x 2,0 m As the world’s leading company in Kellenberger overhaul and retrofit we are not only able to deliver machines in a quality similar to a new machine and with warranty, but we can also offer you the service for your machines. Overhauled with geometric KEL ...
used
STANKOIMPORT 5822M thread grinding machine was manufactured in the USSR. The machine is used for the process of grinding threads to give them the correct dimensions and roughness. During this process, a grinding wheel with a diameter of 400 mm is used to remove a small allowance from the workpiece, forming the thread shape on it. The grinding machine processes threads with a maximum diameter of 200 mm, a length of 500 mm and a weight of up to 30 kg. Depending on the choiceed disc, the diameter of the workpiece can be from 3 to 150 mm (grinding with a single-coil disc) or from 10 to 120 mm (grinding with a multi-coil disc). The total weight of the grinding machine is approximately 5 tons. Technical data of the STANKOIMPORT 5822M thread grinding machine - maximum workpiece diameter: 200 mm - diameter of the workpiece grinded with single-coil disc: 3-150 mm - diameter of the workpi ...
used
workpiece diameter: 8-125 mm grinding depth: 130 mm clamping length: 50-1100 mm max. workpiece diameter: 0 mm min. workpiece diameter: 0 mm workpiece length: mm total power requirement: 1 kW weight of the machine ca.: 500 kg dimensions of the machine ca.: m T E C H N I C A (Switzerland) Centre Hole Grinding Machine Model ZSM 1000 Year approx. 1975 Serial No. J 1400 _______________________________________________________ Distance between centres 50 – 1,100 mm Height of centres 145 mm Workpiece Ø 8 – 125 mm Max. centre hole taper Ø 2 – 50 mm Max. centre hole taper angle 60 ° Clamping range of vice 4 – 150 mm Stroke of grinding head 130 mm Stroke of grinding tool on workpiece 0.75 – 5 mm Grinding tool Ø ...
used
3B161 shaft grinding machine built in the USSR, performs machining of rotating surfaces with high precision and quality along the entire length of the grinded workpiece. Distinguished for its exceptional reliability, the machine uses a large grinding wheel with a diameter of 500 mm, which is driven by a reliable 5.5 kW spindle. The XC3 3B161 grinding machine, thanks to its combination of a grinding wheel and claws with 1000 mm spacing, allows a significant reduction in machining time while maintaining high productivity. The shaft grinding machine weighs 4850 kg. Technical specifications of the 3B161 grinder - maximum workpiece length: 1000 mm - maximum workpiece diameter: 300 mm - grinding wheel diameter: ø 500 mm - maximum grinding wheel width: 60 mm - minimum grinding wheel width: 30 mm - grinding wheel spindle drive power: 5.5 kW - guaranteed elementary interval: 0.005 mm ...
used
Center distance: 0 mm Grinding head Z-axis: 0 mm Center height: 0 mm CNC Brand: 0 CNC Model: 0 Technical data Centre height: 300 mm Distance between centres: 380 mm Table length: 1100 mm Max. grinding diameter: 238 / 620 mm Max. grinding wheel diamter: 125 mm Longitudinal way of table Transversal way of the table: 220 mm Vertical adjustment of grinding head: 325 mm Slewing range of grinding head: horizontal: 360 ° vertical: 360 ° rotary axis of the grinding spindle head: 360 ° Grinding spindle speeds: number (steps): 2 from: 2000 rpm up to: 10000 rpm Voltage 50 Hz 3x: 380 Volt Grinding spindle motor: 2 kW Machine´s weight about: 500 kg Overall dimensions machine: Length: 1100 mm Width: 800 mm Height: 1750 mm Various accessories: Set of collets Set of collets: ESX Lamp Tool cabinet Grinding wheel guard
used
Naxos CNC Multi-Axis Cylindrical Grinder Year: 1987/2013 Max. swing: 630mm Max. distance workhead face to tailstock face: 4850mm Max. travel for Z axis: 5000mm Max. grinding distance for main wheel: 4520mm X axis infeed travel for both headstocks: 720mm Approx. weight between centers: 4000kg Power requirements: 460/3/60 This machine was completely remanufactured to new specifications in 2013 and installed in 2014. It was stripped down to the bare casting, table/base/wheel heads/work head and tailstock and the second z axis ways were fit and rescrapped. New electrical cabinet with all new wiring to the machine and new all components, hydraulic lines, air lines and new cable carriers were added. New Marathon 60HP motors for both grinding wheel heads. (The drives in the cabinet are set for 40 Hp) The spindle drives in the cabinet are Yakawa built in the USA along with the workh ...
used
grinding diameter: 200 mm grinding length: 620 mm centre height: 100 mm grinding wheel diameter: 350 mm grinding wheel width: 50 mm bore: 127 mm : work piece spindle speed: 65-500 U/min workpiece spindle - bore: mm grinding head swivelling: 360 ° grinding spindle head - swivable: 5° + - ° grinding spindle speed: U/min : +-8 ° longitudinal feed of the table: 620 mm table speeds: 0-5 m/min : kg : kg : mm grinding depth: mm : mm total power requirement: 5 kW weight of the machine ca.: 2,6 t dimensions of the machine ca.: m Geometrically overhauled and new painted. Pictures of a machine which is already delivered with perhaps special equipment. -internal grinding device not included. -2-axis digital read out Heidenhain -tailstock without adjustment Die Werkzeugmaschine entspricht zum derzeitigen Zeitpunkt nicht den grundlegenden Sicherheits- und Schutzanforderungen wie in der BetrSich ...
used
CNC centerless grinding machine Monzesi mod Monza 510 CNC 6 axes complete with piece loading and unloading system CNC Fanuc 160i-T Under power in our warehouse in Gussago BS., Mimu machine tools Italy, Centreless grinding is a procedure for grinding cylindrical bodies and is used for mass production of rollers, cylindrical, conical rollers, jet needles, pump pistons, hydraulic sliders, crosses, drills etc., During centerless plunge grinding, the workpiece is ground in one pass, thanks to the translation of the grinding wheel. For this purpose, the grinding wheels and the adjustment discs have a negative profile of the piece, to work which is given to them with the aid of a tool., The through-feed grinding or also through grinding and longitudinal grinding: pieces, to be worked proceed uninterruptedly with axial feed through the rectification gap., Wheel width: 250, Wheel diameter: 510, C ...
used
Description: Year of construction: presumably 1986 Center distance: 600 mm Travel: max. 900 mm Cross slide: Travel, with feed handwheel in fine or coarse gear: 245 mm Travel per handwheel rotation, coarse/fine: 8/1 mm/diameter Rapid feed and return, hydraulic: 40 mm Grinding headstock: Grinding wheel for external cylindrical grinding: 400 x 50 x 127 mm Grinding wheel for right spindle end: 225 x 20 x 76.2 mm Grinding spindle speeds: 1500/1700/2200 rpm Swivel range of the sanding headstock: 270° With indexing every 90 Internal grinding spindle mounting hole: 70 (80) mm diameter Workpiece headstock: Swivel range: 340° For further technical data see pictures Center height: 125 mm Workpiece diameter: max. 249 mm With accessories as shown in the pictures, e.g. collets, grinding wheels and other grinding tools and accessories for the cylindrical grinding machine weight approx.: 3,000 kg, App ...
used
Center distance: 0 mm Grinding head Z-axis: 0 mm Center height: 0 mm CNC Brand: 0 CNC Model: 0 Control: GE FANUC Series 160i-MB Operating hours: 0 Technical data Number of axis simultaneous: 5 Table length: 500 mm Table width: 145 mm X axis: 380 mm Y axis: 300 mm Z axis: 280 mm grinding diameter: 240 mm Grinding-wheel diameter: 50 - 250 mm A axis (grinding head rotaion): 360 ° C axis (tool rotaion): 210 ° Resolution: 0.0001 ° Spindle nose: HSK: 50 Grinding spindle speeds: stepless from: 50 rpm up to: 10000 rpm Max forwarding speed: 20 m/min Max. forwarding speed cross: 5 m/min Max forwarding speed vertical: 20 m/min Voltage 50 Hz 3x: 400 Volt Spindle power: 9 kW Total power required: 27 kVA Machine´s weight about: 8000 kg Overall dimensions machine: Length: 2270 mm Width: 1700 mm Height: 2260 mm Various accessories: 3D measuring feeler gauge Set of collets Set of flanges Set of ...
used
Stock number 1105-02617 Machine type flat grinding machine Make Elf Type OPTIMALLY 4250 NC-K Built in 1993 Control type NC Storage warehouse Country of origin Germany Delivery time immediately Exhibition Hall, ver free freight basis Technical details Grinding length 450 mm Grinding width 250 mm Workpiece height 375 mm Table length 800 mm Table width 250 mm maximum work-piece weight 400 kg Autom. Cross feed adjustable 3-50 mm / stroke Vertical delivery, 1 Division 0.001 - 0.06 mm Grinding wheel diameter 300 mm Grinding wheel width 50 mm Grinding wheel diameter 36 mm Voltage 380 V Grinding spindle motor 3.7 / 4.7 kW Total power demand 9 kW Machine weight approx. 2.6 t Space requirement of approx. 2800 X 2500 2300 mm Additional information automatic delivery -Electro magnetic clamping plate with straight fine pole pitch, dimens ...
