grinding mill used for sale

Peak height: 160 mm Tip width: 1500 mm Grinding wheel dimensions: 500 x 127 x 40 mm Grinding wheel speeds: 1570/2050 rpm electr. Connection: 380 V kW Space requirement: 4400/6400 x 2000 x 1400 mm Weight: approx. 4000 kg

Technical data: - Edge grinding machine for edge processing on - welded boxes, cabinets, safes, etc. - Control SIEMENS for clocks + oscillation - max. grinding height approx. 1200 mm - Grinding belt dimension 100 x 2240 mm - Grinding belt speed 12 + 24 m/s - Grinding unit swivelling - 2 magnetic clamping plates - Mot. Grinding dust extraction - Pneumatic connection 6 bar - Drive 400 V - Space requirement approx. W 2500 x H 2000 x D 2000 mm - Weight approx. 1500 kg

Tool Lapping and Grinding Machine make HAARMANN type DMPUFabr. -No: 1347 built in 1961Grinding wheel size: 200 x 50 mmRecess: 110 x 25 mmleft side table size: 175 x 400 mmleft side table inclinable and deliverableright side table size: 300 x 170 mmright side table tilt, tilt and height adjustablePower connection: 380 V, 50 HzMotor power: 0.55 kWDimensions L x W x H: 900 x 680 x 1300 mmused, from an operating resolution, despite the year of constructionin good conditionPrice on request.Delivery: ex warehouse or location free loading truck.Payment: net at takeover or by appointment.Technical data are not binding. Errors excepted.We would be pleased, if you like our offer and are always available for your queries.Best regardsM. WaldeckWAHO Machine Tools

4-point tool grinding machine make SOLID type DS 3 CDMachine -No: 146064 Year 1964Grinding wheel pre-sanding SC: 200 x 50 x 51 mmTable: 400 x 150 mmGrinding wheel regrind SC: 200 x 50 x 51 mmTable: 400 x 150 mmGrinding wheel lapping cut diamond: 125 x 12.5 x 51 mmTable: 400 x 150 mmChip breaker grinding wheel: 150 x 8 x 51 mm2 engine speeds: 1400/2800 rpm.Drive power: 0.5 / 0.8 hpDimensions L x W x H /: 1110 x 1000 x 1280 mmWeight approx: 300 kgWith- Cooling device- Underframeused, from a vocational school in very good conditionPrice on request.Delivery: ex warehouse or location free loading truck.Payment: net at takeover or by appointment.Technical data are not binding. Errors excepted.We would be pleased, if you like our offer and are always available for your queries.Best regardsM. WaldeckWAHO Machine Tools

Tool grinding machine make HAHN & KOLB type WS 54Year of construction 1975gr. workpiece diameter: 200 mmgr. clamping length between the tips: 230 mmMounting cone: MK 5Gr. grinding length: 110 mmCrossfeed: 140 mmPivoting the workpiece spindle head: +/- 7.5 °Swiveling the angle head horizontally and vertically: +/- 90 °Speeds of the grinding spindle: 4450 - 31000 rpm.Grinding wheel diameter: 125 mmMotor power: 0.55 kWDimensions L x W x H: 1400 x 1000 x 1500 mmMass. approx: 500 kgused, in good conditionPrice on request.Delivery: ex warehouse or location free loading truck.Payment: net at takeover or by appointment.Technical data are not binding. Errors excepted.We would be pleased, if you like our offer and are always available for your queries.Best regardsM. WaldeckWAHO Machine Tools

Grinding machine make DECKEL type SOMasch. -No: 89-24422 Year of construction 1989Technical specifications:gr. radius to be ground: 10 mmgr. lateral displacement of the milling cutter holders: 10 mmgr. Longitudinal displacement of the cutter holder: 40 mmgr. adjustable back grinding angle: 45 °gr.Bore of the collet: 17.5 mmGrinding spindle speed: 4500 rpm.Drive power: 0.25 kWDimensions L x W x H: 500 x 420 x 1400 mmWeight approx: 67 kgWith- baseused, in good conditionPrice on request.Delivery: ex warehouse or location free loading truck.Payment: net at takeover or by appointment.Technical data are not binding. Errors excepted.We would be pleased, if you like our offer and are always available for your queries.Best regardsM. WaldeckWAHO Machine Tools

Single-edge milling machine make DECKEL type SOMachine -No: 81659 built in 1981 (table model)Technical specifications:Tool holder: 17.5 mmTaper collets: MK 1 / MK 2 / GAGrinding spindle speed: 4500 rpm.Adjustment of the tool holder: 10 mmLongitudinal shift: 40 mmMax. Relief grinding angle: 45 °Drive power: 0.25 kWSpindle speed: 2800 rpm.Weight approx: 32 kgExternal dimensions approx: 510 x 565 x 290 mmWith- grinding wheel- several colletsused, in very good conditionPrice on request.Delivery: ex warehouse or location free loading truck.Payment: net at takeover or by appointment.Technical data are not binding. Errors excepted.We would be pleased, if you like our offer and are always available for your queries.Best regardsM. WaldeckWAHO Machine Tools

Single-edge milling machine make DECKEL type SOMachine -No: 0221 (table model)Technical specifications:Tool holder: 17.5 mmTaper collets: MK 1 / MK 2 / GAGrinding spindle speed: 4500 rpm.Adjustment of the tool holder: 10 mmLongitudinal shift: 40 mmMax. Relief grinding angle: 45 °Drive power: 0.25 kWSpindle speed: 2800 rpm.Weight approx: 32 kgExternal dimensions approx: 510 x 565 x 290 mmWith- grinding wheel- several colletsused, in very good conditionPrice on request.Delivery: ex warehouse or location free loading truck.Payment: net at takeover or by appointment.Technical data are not binding. Errors excepted.We would be pleased, if you like our offer and are always available for your queries.Best regardsM. WaldeckWAHO Machine Tools

0916: 1 gebr. Universal tool and flat grinding machine Fabr. HEMBRUG Arb.-Ber.: 500 x 200 x 260 mm, Accessories: Grinding dust extraction, tool cabinet Other: Grinding table swivel 60°, grinding spindle swivel 360°.

Machine details Bearing number 1105-03191 Machine type flat grinding machine Make sit Type RP 800 Built in 1991 Control type NC Warehouse LAGER Country of origin Germany Delivery time immediately Freight base from the exhibition hall, free Technical details Grinding length 800 mm Grinding width 400 mm Workpiece height 475 mm Table length 1100 mm Table width 500 mm max. workpiece weight 700 kg Auto. Cross feed adjustable 3-50 mm/stroke Vertical delivery, 1 tick mark 0.001 - 0.06 mm Grinding wheel diameter 300 mm Grinding wheel width 50 mm Grinding wheel bore diameter 76.2 mm Connection voltage 380 V Grinding spindle motor 3.7 / 4.5 kW Total power requirement 4.5 kW Machine weight approx. 4.5 t Room requirement approx. 3500x2000x2700 mm Information Automatic delivery, - Electro-magnetic clamping plate with straight fine pole division, dimensions 800x400mm  ...

Long belt grinding machine, roller spacing approx. 3000 mm

Grinding machine for curved parts Molded part grinding machine Make Calmbach & Söhne Double-sided grinding of shaped parts Oscillating rubberized grinding rollers Workpiece thickness maximum 120 mm Workpiece width maximum 130 mm Engine strength 2 motors 1.5 kW each Oscillation electromotor 4 speeds Suction connection diameter 120 mm Includes 20 grinding belts grit 60 + 120 Dimensions 1200 mm x 1500 mm x H 1550 mm

Description Universal flat grinding machine of the elb brand suitable for tooling, fixture construction, training and mould making Travel: 750 x 320mm Table size: 600 x 300mm Technical data Grinding length 750mm Grinding width 320mm Workpiece height 500mm Table size 600 x 300mm Connection 50Hz 380V Engine 4.5KW Machine weight approx. 2650kg Dimensions 2000 x 1650 x 2110 mm

Grinding length

Grinding area: 100 x 360 or 150 x 190 mm Grinding speed: 2870 rpm Table size: 150 x 250 mm Drive motor: 380 V, 3.3 kW Space requirement: 670 x 400 x 1600 mm Weight: Pot discs: 180 mm

grinding diameter max.: 50 mm workpiece length: - mm table adjustment: - mm x-travel: 250 mm y-travel: 170 mm z-travel: 140 mm number of spindle speeds: 2880 rpm height over floor: 1000 mm total power requirement: 3.0 kW weight of the machine approx.: 329 kg dimension machine approx. LxWxH: 0.95 x 1.15 x 1.35 m dimension coolant device: 0.6 x 0.24 x 0.5 m transport dimensions LxWxH: 1.0 x 1.0 x 1.4 m

ADJUSTMENT FOR INTERIOR MORARA MT250 ID CNC Model: Siemens X-Axis Stroke: 135mm Z-Axis Stroke: 255mm Spindle Rpm: 700 Maximum rectifiable piece diameter : 250mm Other technical data: ground tips height 1059 top speed 15 m/min Internal grinding wheel : 3 Kw - 90,000 RPM horizontal plane adjustability -1° / +1° Weight: 6600Kg

Tablebelt grinding machine Höfer Format: 2.50 x 1.20 m Engine: 4 kW L x W x H: 3.2 x 1.6 x 1.7m Weight approx. 680 kg The machine is in good condition, ready for operation. Changes, mistakes, intermediate sale reserved ! Service/spare parts by MATEC CH-4900 Langenthal/DE-79618 Rheinfelden MATEC system + technik GmbH Mechanical engineering Eisenbahnstrasse 25 CH-4900 Langenthal/Switzerland Tel. 0041 62 966 18 32 Fax 0041 62 966 21 12

Ref.Nr 00682 Designation of the machine grinding machine / calibration machine Manufacturer Ferrari & Cigarini s.r.i. Model Calibratrice Built in 2012 Current Use To Grind Flow Surface or reduce the height of the workpiece 67.9 kW 400 V- 50 Hz 3 + 6 Bar 4700 kg Delivery date by appointment

Heat treatment oven 1150 0.8x0.8x1.5m t max 1150 C possible various size ovens Öfen für die Wärmebehandlung Metalle einfache Härtesysteme Härterei-Zubehör gienanth Glühöfen Umluftöfen zum Glühen, Anlassen Salzbadöfen Schutzgasöfen Nitrieröfen und Plasmanitrieröfen Mehrzweckkammer-ofenanlagen kontinuierliche Ofenanlagen Vakuumprozesse Vakuumhärten Vakuumglühen, -anlassen, Nitrieren Vakuumlöten Metal Injection Moulding Induktionserwärmung Öfen für die Kunststofftechnik zum Trocken, Tempern, Polymerisieren, Einbrennen usw.; Ausführung als Kammeröfen, Haubenöfen, Herdwagenöfen, Schachtöfen; Herdwagen-Schmiedeöfen Umluftöfen Kammerofenlinien Nitrieröfen Plasmanitrieröfen Vakuumprozesse Schmelzöfen Trocknen Tempern Laboröfen Ersatzteile Öfen Kammeröfen Herd wagenöfen schoenheider Herdwagenöfen zirlguss Glühen Härten Tempern Umformen Vorw ...

No. 4959: 1 gebr. Universal cylindrical grinding machine Fabr. STÖCKEL, type RSU 100 NC-T, Bauj. 2010 with internal grinding device Arb.-Ber.: approx. 300 x 1000 mm, drive power: 4 / 1 kW accessories: Electronic handwheel Coolant device with magnetic separator documentation Other: External grinding spindle Discs- 400 x 50 / 250 x 30 mm 4 kW / max. 1400 min-1 Inner grinding spindle 1 kW / max. 1400 min-1 pivoting range: - Table: -6° / +10° - Grinding spindle stick 180° - Workpiece spindle stick +-90° Space requirement approx. 5 x 3 x 2.2 m Transport dimension approx. 6 LM Weight approx. 5,000 kg

KELLENBERGER UR 175-1000 Yes it is a machine that we are using in Exact. We replace it because a new Studer will arrive next week and we have no more space in the company. The machine works very well and has just been overhauled by us, replacing many electrical and mechanical parts. KELLENBERGER UR 175-1000 Hardinge

Stock No. : G15949v Machine type : Centering bore grinding machine Make : Technica Type : ZSM 510-810 Year of construction: 1988 specifications Workpiece clamping range (through..) 4 - 220 mm Workpiece length 50 - 1100 mm Workpiece weight approx. 120 kg Centering hole angle 30° Centering bore cone 2 - 60 mm Grinding spindle diameter 32 mm Depending on the abrasive, speeds of 13,000 to 45,000 rpm. Grinding spindle motor 0.25 KW Grinding head adjustment max. 160 mm Fine delivery max. 1 handwheel revolution 1 mm 1 tick mark 0.01 mm Weight approx. 460 kg Dimensions approx. 1.3 x 1.3 x 1.95 m 21/33.5/45/50 m/min Remarks / Accessories: incl. suction, etc.

Smallest / largest hole diameter 2 / 50 mm Material diameter 32 / 150 mm Workpiece length 50 - 1100 mm Spindle speed range 13,000 - 45,000 rpm

CATALOG NUMBER 6145 TECHNICAL DATA - max workpiece width 1100mm - max workpiece height 140mm 3 aggregates: 1) grooved rubber roller for 15kW calibration 2) grooved rubber roller for 11kW calibration 3) grooved rubber roller for 11kW calibration in advance: - metal skid roller - rubber skid roller - aggregate - 2 rubber rollers, sliding - aggregate - 2 rubber skid rollers - aggregate - rubber skid roller from down: - feeding table 3600x1000mm - feed speed adjustable on the inverter 0.25kW - pulling tape - 3 rubber rollers, sliding, leading out - oscillation of pneumatic strips on photocells - blowing off the tapes - electric table lifting - 0.75kW motor lifting - smooth regulation of the feed speed - 2.2kW feed motor - with a vacum pump - 4kW pump motor - diameter of the extraction port 110mm, 80mm - working pressure 6-8bar - diameter of the extraction port 3 ...

Inv. Num. : 5457 Type: UB 63/2000 Producer: HOL-MONTA Created: 2001 Parameters: Control system: Kavalír Maximum grinding length: 2000 mm Grinding diameter: 630 mm Tip stroke: 375 mm Total power requirement: 41 kW

specifications: - Load capacity positioning base approx. 750 kg - Flatplate diameter 500 mm - max. workpiece diameter 1600 mm - Height turntable with horizontal position approx. 750mm - Turntable with right,- + left run - Axis of rotation turntable endless 360 ° - Rotation time per revolution 12.5 sec. - Pan left + right - Swivel axis rotation angle 180 ° - Swivel time for 180° swivel angle 10 sec. - 2 x double foot button for turntable + swivel arm - hydr. Clamping bolt for clamping the workpiece in the middle of the turntable - Clamping stroke / clamping distance of the clamping bolt 32 mm - Clamping force pressing / pulling 80 / 48.9 kN - Clamping cylinder female thread M 27 x 40 - Positioning control SIEMENS - Operation manually or via control - Space required approx. W 1500 x D 2800 x H 1100 mm - Weight approx. 2500 kg - separa ...

STANKOIMPORT 5822M thread grinding machine was manufactured in the USSR. The machine is used for the process of grinding threads to give them the correct dimensions and roughness. During this process, a grinding wheel with a diameter of 400 mm is used to remove a small allowance from the workpiece, forming the thread shape on it. The grinding machine processes threads with a maximum diameter of 200 mm, a length of 500 mm and a weight of up to 30 kg. Depending on the choiceed disc, the diameter of the workpiece can be from 3 to 150 mm (grinding with a single-coil disc) or from 10 to 120 mm (grinding with a multi-coil disc). The total weight of the grinding machine is approximately 5 tons. Technical data of the STANKOIMPORT 5822M thread grinding machine - maximum workpiece diameter: 200 mm - diameter of the workpiece grinded with single-coil disc: 3-150 mm - diameter of the workpi ...

specifications: - maximum grinding length 360 mm - maximum grinding width 155 mm - maximum installation height 280 mm - Grinding wheel stroke approx. 240mm - Clamping area 400 x 160 mm - Magnetic clamping plate 300 x 150 mm - Grinding wheel dimensions approx. 200 x 80 x 78 mm - Grinding wheel speed 2800 rpm - Swivel range of the grinding arm approx. 180 ° - manual swivel arm clamping via clamping lever - Wet loop fitting - Drive 400 V / 3 kW - Space required approx. W 850 x H 1700 x D 950 mm - Weight approx. 550 kg

Grinding spindle to Hauser coordinate grinding machines. 2 electric spindles with mounting shaft 3mm and 1 compressed air grinding spindle for receiving shaft 3mm. All spindles are tested for function.

5 grinding wheels diameter 780-800mm price for all 5 together

Very well preserved crankshaft grinding machine RTM 260. Machine was newly scraped, spindles of eccentric adjustment replaced. Lots of accessories, 10 grinding wheels, user manual, balancing jack, tape filter system, etc.

Code 0736 Description hydraulic surface grinding machine Make ORION ( HAHN & KOLB ) Model 308 Serial No. 5128 Year 1978 Tablesize 1520 x 300 mm Table grinding size L x B x H 800 x 350 x 500 mm Magnetical plate size L x B 800 x 300 mm Speed table movement 2 - 30 m/min. Rapide vertical movement 0,4 m/min Max. distance table – centre grinding wheel 640 mm Max Grindingstone diameter x Wide x Taper 300 x 50 x Ø 76 mm Spindel power 5,5 and 7,5 kW Spindel speed 1440 and 2880 rpm Weight 3500 kgs Motor power 5,5 / 7,5 kW – 380 Volt Accessoiries Elec. Magneticplate 800 x 300 mm Coolant Condition Machine is in good condition

Code 5976 Description Hydr. Surface grinding machine Make DANOBAT Type RT – 1200 Machine No. 565 Manufacturing date 1989 ( 1990 in use ) Table size 1400 x 700 mm Grinding dimensions L x W x H 1200 x 750 ( 800 ) x 800 mm Magnetic plate size L x W 1000 x 600 mm Table speed movement 1 - 25 m/min. Max. distance table surface – centre grinding wheel 1000 mm Speeds cross 0,1 - 5 m/min. Vertical movement 0,005 – 0,05 mm Spindle rotation 1500 rpm Spindle power 7,5 kW Grinding wheel size Ø 400 x 50 ( 100 ) x Ø 127 mm Weight 8.500 kgs Total power 12 kW – 380 Volt Accessoiries Electro magnetic plate 1000 x 600 mm from Tecnomagnete Coolant Pendel control Condition Machine is in good condition

Code 4925 Description Surface grinding machine Make ELB Model OPTIMAL 1 VA II Serial No. 180730982 Year 1982 Tablesize 900 x 250 mm Table grinding size L x B x H 600 x 300 x 250 mm Magnetical plate size L x B 500 x 250 mm Speed table movement 1 – 25 m/min. Rapide vertical movement 0,15 m/min Max. distance table – centre grinding wheel 500 mm Grinding stone dim. Stone x Wide x Taper 300 x 50 x Ø 75 mm Spindel power 3,7 and 4,5 kW Spindel speed 1400 and 2800 rpm Weight 3500 kgs Motor power 3,7 and 4,5 kW – 380 Volt Accessoiries Elec. Magneticplate 500 x 250 mm Coolant with paperfilter 2 x DRO Grinding stones, etc. Condition Machine is in good condition

Code 61047 Description Hydr. Surface grinding machine Make ALPA Model RT 1000 Serial No. 53377 Year 1985 Tablesize 1200 x 300 mm Table grinding size L x B x H 1000 x 350 x 400 mm Base size L x B 1000 x 300 mm Speed table movement 3 – 40 m/min. Rapide vertical movement 0,15 m/min Max. distance table – centre grinding wheel 600 mm Grinding stone diam. Stone x Wide x Taper Ø 400 x 50 x 127 mm Spindel power 8,8 kW Spindel speed 1460 rpm Weight 3000 kgs Motor power 8,8 kW – 380 Volt Accessoiries Magneticplate 1000 x 300 mm Coolant Grinding stones, etc. Condition Machine is in normal condition

Code 61062 Description Hydr. Surface grinding machine Make DANOBAT Type RTS - 1600 Machine No. 16 220 Manufacturing date 1975 Table size 1800 x 550 mm Grinding dimensions L x W x H 1600 x 600 x 650 mm Magnetic plate size L x W 1600 x 550 mm Table speed movement 1 - 25 m/min. Max. distance table surface – centre grinding wheel 750 mm Speeds cross 0,1 - 5 m/min. Vertical movement 0,005 – 0,05 mm Spindle rotation 1500 rpm Spindle power 15 kW Grinding wheel size Ø 400 x 50 ( 100 ) x Ø 127 mm Weight 10.000 kgs Total power 20 kW – 380 Volt Accessoiries Electro magnetic plate 1600 x 550 mm from Tecnomagnete Coolant Vertical grinding spindel Condition Machine is in good condition

Code 61063 Description Surface grinding machine Make ABA Model FFU 2000/60 Serial No. 208 125 Control Abamatic 3 Year 1986 Tablesize 2510 x 500 mm Grinding surface L x B x H 2000 x 600 x 700 mm Magnetical plate size L x B 2000 x 500 mm Speed table movement 3 – 30 m/min. Max. distance table – centre grinding wheel 900 mm Grinding stone dim. Stone x Wide x Taper Ø 400 x 50 x Ø 127 mm Spindel power 26 kW Spindel speed 1600 - 3000 rpm Motor power 26 kW – 380 Volt Total electr.com. 34 kW Total space L x W x H 7000 x 3500 x 2650 mm Weight 10500 kgs Accessoiries Elec. Magneticplate 2000 x 500 mm Coolant with paperfilter Digital readout Grinding stones, etc. Condition Machine is in good condition

Gantry type grinding machine Make: Hiatachi Seiki Modell: 9GA-NRAA Table: 2500 x 1200 mm Max. Table travel: 2000 mm Capacity: 1500 x 900 x 500 mm Control: Fanuc 15 MA Year: 1995

Code 71164 Description Universal Hydraulic Cylindrical Grinder Make SHIGIYA SEIKI Model GU – 27.100 H Serial No. 10222 Year 1978 Grinding length, max. 1000 mm Grinding diameter, max. 265 mm Centre height 135 mm Max. Weight workpiece 130 kg Table tilting angle - 3° till + 7° Table speeds 0,05 – 7 m/min Diam. Grinding wheel 350 mm Width Grinding wheel, max. 25 – 50 mm Motorpower grindingwheel 3,7 kW Speeds workpieceholder steples from 17 – 250 rpm Total power 9,3 kVA 380 Volts Machine size L x W x H 4,0 x 1,8 x 1,6 meter Weight 3200 kg Accessories Coolant, books, electric cabinet,etc. Condition Machine is in good condition

Code 81199 Description Hydr. Surface grinding machine Make DANOBAT Type RT – 1200 Machine No. 504 Manufacturing date 1987 Table size 1400 x 450 mm Grinding dimensions L x W x H 1200 x 600 x 450 mm Magnetic plate size L x W 1200 x 450 mm Table speed movement 1 - 30 m/min. Max. distance table surface – centre grinding wheel 675 mm Speeds cross 0,1 - 5 m/min. Vertical movement 0,005 – 0,05 mm Spindle rotation 1200 rpm Spindle power 7,5 kW Grinding wheel size Ø 450 x 50 ( 100 ) x Ø 127 mm Weight 6000 kgs Size of machine 3250 x 1850 x 2600 mm Total power 19 kW – 380 Volt Accessoiries Electro magnetic plate 1200 x 450 mm from Tecnomagnete Coolant Pendel control Condition Machine is in normal condition

Code 171305 Description CNC surface grinding machine Make DANOBAT Model PSG - 1000 Serial No. 30102 A Control Fanuc 210i - M Year 2001 Tablesize 1000 x 500 mm Grinding surface L x W x H 1000 x 600 x 450 mm Long ( X axes ) 1150 mm Cross ( Z axes ) 500 mm Speed table movement 1 – 30 m/min. Max. distance table – centre grinding wheel 650 mm Max. workpiece weigth 1500 kg Max. table load 1500 kg Magnetical plate size L x W 1000 x 500 mm Grinding stone dim. Stone x Wide x Taper Ø 400 x 100 x Ø 127 mm Spindel power 7,5 kW Spindel speed 1500 rpm Motor power 7,5 kW – 380 Volt Total electr.com. 20 kW Total space L x W x H 3950 x 3150 x 2550 mm Weight 5500 kgs Accessoiries Elec. Magneticplate 1000 x 500 mm Coolant with paperfilter Digital readout Grinding stones, etc. Condition Machine is in g ...

Code 9602 DESCRIPTION Vertical JIG Grinder Make HAUSER Modell 3 SMO Serial No. 257 Machine No. 1519-2564 Table surface 600 x 320 mm Table movement longitude (X) 400 mm Table movement cross (Y) 250 mm Max. grinding diameter Ø 190 mm Column-Spindle 300 mm Max. height under spindle 500 mm Vertical movement spindle 90 mm Vertical movement grindinghead 500 mm Max. speeds grindingspindle up to 80.000 omw./min Weight 2000 kg Total power 6,6 kW – 380 Volts Accessories Grinding spindles, etc. Condition Machine is in good condition

Code 101237 Description Universal Cylindrical Grinder Make WMW Heckert Model SA 5 U x 630 Serial No. 3115 Year 1981 Grinding length, max. 630 mm Grinding diameter, max. 275 mm Centerheight 140 mm Max. Weight workpiece 125 kg Table tilting angle - 5° till + 11,5° Diam. Grinding wheel 500 mm Width Grinding wheel, max. 100 mm Motorpower grindingwheel 5,5 kW Speeds workpieceholder 31,5 – 710 rpm Total power 12,5 kVA 380 Volts Machine size L x W x H 3,9 x 2,3 x 1,6 meter Weight 4800 kg Accessories coolant with magnetic some tooling Condition Machine is in good condition

Drill grinding machine: Make: Michael Deckel Modell: SO S/N: 22822

Code: 0749 Brand: TAGLIABUE - COSTA LEVIGATRICI Model: TT 3 1300 Automatic sanding machine for worktops, furniture, panels, tables Technical data: Working width mm 1300 Max working thickness mm 130 Min working thickness mm 4 Composition: 1° Transversal belt - Motor Hp 15 - Electronic speed variator with display 2° Transversal belt - Motor Hp 15 - Electronic speed variator with display Transversal sanding belt size mm 1350 x 150 Chevron belt size mm 5510 x 140 Belt blowers Belt feed speed mt/min 5/25 Fixed table and mobile head for on-line set-up Panel cleaning rotary blowers Vacuum table Belt cleaning brush Infeed roller conveyor Installed power Kw 32 Compressed air 7 Atm Suction inlets: n° 2 diameter mm 200 - n° 2 diameter mm 150 - n° 2 diameter mm 100 Overall dimensions mmm 4400 x 2500 x 1600 h Weight kg 5000

internal diameter: 20/300 mm grinding depth: 250 mm swing diameter: 250 mm workpiece spindle - bore: 45 mm workpiece spindle swivable +/-: 25 ° taper setting angle of the workpiece column: 50 ° work piece spindle speed: 42 - 400 U/min grinding spindle speed: 10.000 U/min table speed -stepless-: 0,1 - 8 m/min grinding spindle drive: 4 kW power capacity: 10 kW weight of the machine ca.: 4.500 kg dimensions of the machine ca.: m : : : : : Internal grinding Æ, min./max. 20 / 300 mm Grinding depth 500 mm Table stroke, min./max. 5 / 800 mm Height of centres above table 250 mm Swing Æ in the table recess 600 mm Workspindle bore 62 / 45 mm Swivability of workpiece wheelhead 25 ° Max. taper angle which can be ground 50 ° Infeed, per stroke 0.0025 - 0.5 mm Worksp ...

grinding height: 60 mm grinding width: 120 mm grinding wheel diameter: 600 mm grinding length: mm workpiece height: 60 mm total power requirement: 50 kW weight of the machine ca.: 7000 kg dimensions of the machine ca.: m D I S K U S (Germany) Double Side Vertical Spindle Surface Grinder, C-Frame Design, with Rotary Workpiece Feeding System and Automatic Dressing Device Model DDS 600 CR-A Year 1969 Serial-No. 6672 ______________________________________________________________________ ________ Grinding wheels Ø x bore, each 600 mm Grinding wheels height x width, approx. 60 mm Workpiece dimensions: Grinding height x grinding width, approx. 60 x 120 mm Vertical adjustment of each grinding head 150 mm External Ø of workpiece carrier disk, approx. 810 mm Feeds of rotary workpiece feed system 1 ...

thread dia.: 254 mm grinding length: 350 mm thread pitch: 51 mm Control: SIEMENS S 8 total power requirement: 12 kW weight of the machine ca.: 5000 kg dimensions of the machine ca.: m B A H M Ü L L E R Automatic Internal Thread Grinding Machine Model IPE 12 i.S. Year 1985 Serial No. 103174 _______________________________________________________ workpiece Ø, max. 300 mm workpiece length, approx. 350 mm height of centers (WP spindle/grinding spindle) 300 mm table stroke approx. 450 mm thread diameter ground max. approx. 254 mm thread diameter ground min. approx. 25,4 mm thread length ground in one setting max. 250 mm Lead range, max. 51 mm Lead angle max. 10 ° Total electrical load, approx. 12 kW - 380 V - 50 Hz Weight, approx. 5,000 kg  ...
