gildemeister dmg used for sale

Gildemeister 6-spindle rotary machine, curve controlled max. rod passage: 32.0 mm for rods up to 3.30 m - incl. rod guide, - Steel processing, run with cutting oel - easily equipped with tools Sowiabeb - 1 set of clamping and feed pliers - Alternating wheels (on machine) - 1 set of curves for cross slides - 1 set of curves for main slide

CNC lathe GILDEMEISTER CTX ALPHA 300 with bar feeder and parts pick-up device Built in 2010 in good condition. Duty Cycle: 22930 Hours: 7326 Control Heidenhain CNC-Pilot 640 Circulation over bed: 380 mm Circulation via face slide: 290 mm Spindle bore: 73 mm Flat travel ( X ) : 190 mm Longitudinal travel ( Z ) : 335 mm Speed max. 6000 rpm C-axis 360° Number of driven tool stations 12 pos. Tool holder VDI 30 Accessories: 3 jaw chuck hydraulic 170 mm Conveyor Coolant system Hydraulic hollow clamping device Tool drive C-axis Parts pick-up device Bar Feeder Irco RBK10012 Tailstock

Gildemeister Multispindle Slot machine 6- Spindler Type: AS 25-6 Pick-up device back-valued processing pneumatic stop Balluff cam switch IEMCA PRA Bar loader Oil mist separator (electrostat.) Conveyor Machine has been retrofitted in the past

Year built 2004 OTHER TECHNICAL DATA POWER OF ROTATING TOOLS 4 Kw MACHINE EQUIPMENT Tool holder set supplied DIMENSIONS AND WEIGHT Length 3000 mm Width 2500 mm Height 2010 mm Weight 6700 Kg

turning diameter: 400 mm turning length: 600 mm control: swing diameter: 600 mm spindle bore: 73 mm chip conveyor: total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

GILDEMEISTER NEF Plus 500 CNC lathe was manufactured in 1997. The machine, designed for precision machining of workpieces with a maximum diameter of 500 mm, has two spindles (main spindle and sub-spindle) of high speed and power, which will improve even the most intensive machining. The installed GRUNDING CNC controller with colour screen and control panel also allows for cycles to control. The total weight of the machine is approximately 3000 kg. Technical specifications of the GILDEMEISTER NEF Plus 500 lathe - CNC control: GRUNDIG - maximum turning diameter (over bed): 500 mm - maximum turning diameter (over saddle): 290 mm - maximum turning length: 1500 mm - main spindle rotational speed range: 80-2800 rpm - main spindle passage: 70 mm - main spindle drive power: 11 kW - maximum sub-spindle rotational speed: 5000 rpm - sub-spindle drive power: 7.5 kW - total power require ...

Key data: 500 mm, 450 mm, 6000 1/min

1 used CNC lathe Make Gildemeister Model CTX 320 V5 Linear Year of manufacture 2004 Control Siemens 840 D ( ShopTurn ) Workspace: Max. circulation diameter over bed 500 mm Circumferential diameter via X-carriage 300 mm Turning length 450 mm Bar passage 60 mm Chuck diameter 170 mm Chuck diameter sub-spindle 165 mm Plane stroke 160 mm Rapid traverse X/Z axis 60/45 m/min Power main drive (100% ED) 16 kW Speed range 6000 rpm Power sub-spindle (100% ED) 7.5 kW Speed range 6000 rpm Number of tool stations 12 Cylindrical shank diameter 30 mm Number of driven tools 12 Drive power (40% ED) 10 kW RPM, max. 5000 min-1 C-axis speed range 0 - 200 min-1 C-axis positioning 0.001 degrees Connected load, total approx. 32 kVA Net weight with chip conveyor approx. 4300 kg Machine with chip conveyor L x W x H 3890 x 1555 x 1890 mm Accessories: Conveyor Pa ...

4x compound slide - Pos.1; Pos.2; Pos.4; Pos.5 4x indipenden feed - Pos.1; Pos.2; Pos.4; Pos.5 threading device 1x threading spindle pick-up spindle broaching device set of cams set of collets bar-loader Cucchi Giovanni (YOM 2004)

turning diameter: 210 mm turning length: 580 mm control: 840 D Siemens centre height: 190 mm turning diameter over bed: 330 mm turning dia. over face-slide: 260 mm Main spindle:: turning speed range - main spindle: max. 4.000 min/-1 power capacity - main spindel: 10 / 7,5 kW max. Torque: 115 / 86 Nm spindle bore: 68,5 mm max. usable bar diameter: 51 mm C - Axis: 0,001 ° axis stroke:: travel -x axis: 185 mm travel -z axis: 455 mm turret:: number of toolpositions: 12 pos. tool taper: VDI 30 Driven Tool Stations:: 6 pos. Tailstock:: tailstock adjustment: 400 mm intake pressure max.: 4.000 N feeds:: rapid traverse: X: 20 / Z: 30 m/min Feed force ( X / Y / Z ): 4,5 kN total power requirement: 21 kW weight of the machine ca.: 3,2 t dimensions of the machine ca.: 8,0 x 2,2 x 2,0 m Documents: Chip conveyor: Coolantsystem: Tailstock: parts catcher: C-axis: driven tool stations: Signa ...

Multi-spindle lathe (8 spindles) max. rod diameter 16 mm Guide tubes 4,000 mm Conveyor

turn - diameter over facing slide: 450 mm turning diameter over bed: 830 mm turning diameter: mm turning length: 3000 mm control: Siemens total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Control: SIEMENS 840D Max.turning length: 450 mm Max swing diametr over bed/Slide: 500 mm/375mm Workpiece diametr: 246 mm Material passage through the spindle: 0 mm Rotation speed(max.) 6000 rpm Quick Change Toolposts:12 Taper ? VDI30 Coolant tank:175l M

Machine Type: CNC Lathe Manufacturer: GILDEMEISTER Type CTX 500 S2 Year of construction 1998 Control CNC Pilot Heidenhain Country of origin Germany Delivery time by arrangement Freight base from location Technical details Turning diameter max. 445 mm Turning length 1,000 mm Control CNC Pilot Heidenhain Circumferential diameter 680 mm Main spindle: Speed range – main spindle 18 - 3,600 rpm/-1 Drive power – main spindle 23 kW Max. torque 650 Nm Spindle nose 220h5 Chuck diameter 315 / 400 Spindle bearing diameter 140 mm Spindle bore 107 mm Tool turret: Number of tool positions 12 pos. Tool holder 40 DIN69880 Travel: x-travel 320 mm z-travel 1,097 mm Tailstock: Quill stroke 120 mm Tailstock mount MK 5 Quill pressure 14 kN Feeds: Rapid traverse X : 24 / Z : 30 m/min Feed force X: 8 / Z: 15 kN Total power requirement 58 kVA Machine weight approx ...

Control: Heidenhain Max.turning length: 450 mm Max swing diameter over bed/slide: 500 mm/375mm Workpiece diametr: 246 mm Material passage through the spindle: 0 mm Rotation speed(max.) 6000 rpm Quick Change Toolposts:12 Taper ? VDI30 Coolant tank:175l Ma

Key data: 205 mm, 650 mm

For sale: Gildemeister CNC lathe type Sprint 65 Linear equipped with a Fanuc 310I control. This CNC lathe is equipped with 2 equal spindles with a bar passage of 65 mm. The machine also has three turrets with 12 positions where you can place driven holders in any position! The upper turret is equipped with a Y-axis with a displacement of 80 mm ( (+50, - 30 mm). The turning diameter is 205 mm. The maximum turning length is 650 mm. The movement X1, X2, X3 is 165mm, the Z1 axis movement is 220mm, the Z2 axis movement is 150mm, and the Z3 axis movement is 768mm. The W2 axis movement is 690 mm and the maximum rapid traverses are 30 meters/min. The maximum speed of both spindles is a speed of 5,000 rpm and both spindles have a full C-axis. The tool holder holder on all turrets is VDI-30. The machine is also equipped with a hinged belt chip conveyor with right ejection and the machine has an Ir ...

Key data: 320 mm, 750 mm

Manufacturer: Gildemeister Model N.E.F. 320 K Year of construction 2004 Condition Used Siemens control system Specifications Circulation diameter 320 mm Turning length 750 mm Speed range - main spindle 3500 rpm Drive power - main spindle 9 kW Bar diameter 50 mm Tool holder Multifix size B Tailstock mount MK 5 Rapid traverse X / Z 8 / 10 m/min Machine weight approx. 2.5 t Space requirement approx. 2500 x 1800 x 1885 mm Accessories: 3 Jaw chuck Forkardt 200 Tool package Documentation

Turning diameter 80 mm Bar diameter 20 mm Spindle speed 10000 rpm X1, Y1, Z1, X2,Z2 axes Controller Fanuc FANUC 160iB LNS barfeeder

Gildemeister Sprint 65 Linear CNC lathe (with 2nd spindle, 3 turrets and Y-axis) Diameter of spindle bore 65 mm Spindle speed 5,000 rpm Spindle motor 25/20 kW Spindle speed counter spindle 5,000 rpm X-axis movement 165 / 165 / 165 Movement Y-axis 80 mm Z-axis travel 220 / 150 / 650 mm Movement of the W-axis (counter spindle to the main spindle) 690 mm C-axis indexing 0.0001° Number of towers 3 Number of tools on turret 12 (3x 12) Tool cone VDI 30 Bar Feeder LNS Quick Load Servo 65 If you have any questions about the machine, as well as an appointment for a viewing, please contact us by phone or e-mail. Feel free to check out our other listings for a full overview of our stock.

Gildemeister Sprint 65 Linear CNC lathe (with 2nd spindle, 3 turrets and Y-axis) Diameter of spindle bore 65 mm Spindle speed 5,000 rpm Spindle motor 25/20 kW Spindle speed counter spindle 5,000 rpm X-axis movement 165 / 165 / 165 Movement Y-axis 80 mm Z-axis travel 220 / 150 / 650 mm Movement of the W-axis (counter spindle to the main spindle) 690 mm C-axis indexing 0.0001° Number of towers 3 Number of tools on turret 12 (3x 12) Tool cone VDI 30 Bar Feeder LNS Quick Load Servo 65 If you have any questions about the machine, as well as an appointment for a viewing, please contact us by phone or e-mail. Feel free to check out our other listings for a full overview of our stock.

control: 840 C control: 2x 840 D : Kühlmittelsystem chip conveyor: ja kW generator - rated current: 95,00 A connected load: 65,00 kW The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Control: Siemens 840D Solution line, Auto bar loader: Top Automazioni XF 375

General: Year of construction 2006 Management Heidenhain plus IT Travel X 150 mm Z 650 mm Y 80 mm Program duration 10,600 h Spindle: Spindle speed 5,000 rpm Spindle bore 65 mm Turning diameter over face slide 375 mm Turning length 635 mm Revolver: Tool holder VDI30 Number of stations 12-fold with AGW Dimensions and weight: Dimensions 5,000 mm x 2,500 mm x 2,800 mm Weight approx. 5,800 kg

GILDEMEISTER TWIN 65 CNC automatic lathe was built in 2005 in Germany by GILDEMEISTER Drehmaschinen GmbH. The machine is used for precise, multi-axis machining of workpieces with complex geometries. To increase overall production efficiency, a combination of two spindles and two 12-position turrets with excellent technical specifications are used inside the large working area. Both spindles feature a C-axis with a high indexing accuracy of ± 0.002 mm, which facilitates complex machining operations that require precise positioning of the workpiece. All this is complemented by an intelligent SIEMENS CNC control with an intuitive interface. The GILDEMEISTER CNC turning center weighs 10000 kg. Technical specifications of the GILDEMEISTER TWIN 65 CNC lathe General data - number of axes: 8 (X1, X2, X3, Y1, B, Z1, Z2, Z3) - feed in the X1/X2/X3 axis: 300/180/175 mm - feed in the Y1/B ax ...

Specifications: Main spindle: Max. turning diameter: 33 mm Max. speed: 8000 1/min Drive power: 5.5 kW Drive power at 60% ED: 7.5 kW Slide 1: Carriage path Z1: 320 mm Slide path X1: 50 mm Carriage path Y1: 255 mm Rapid traverse speed: 30 m/min Ball screw diameter: 25 mm Tool holder slide 1: Number of tools fixed with tool shank 16 x 16: 5 pieces Slide 2: Slide path X2: 165 mm Carriage path Z2: 200 mm Rapid traverse speed: 30 m/min Ball screw diameter: 30 mm Tool holder slide 2: Number of stations for turret with integrated spindle: 8 pieces Number of axially driven tools (integrated): 8 pieces Coolant pan, approx.: 400l Coolant pump, max. capacity: 80 l/min Dimensions (LxWxH), approx.: 2460 x 1510 x 1750 mm Equipment: - CNC control Fanuc iT - Workpiece unloading system - IEMCA bar loading magazine - 5-item tool carrier plate for carriage 1 - Elec ...

Please see the pictures for details

Control Siemens Bar passage 32 mm 2 x 12-speed revolver with attached revolver Competition. Main / sub-spindle Y-axis turret top Parts pick-up device Conveyor IRCO Bar Loading Magazine

Used machine in good condition. Available for immediate delivery. - Spindle power?: 28/21 kW - Control: 840 D SIEMENS - Axes: 5 - Workpiece diameter: 240 mm - Max. spindle speed: 5.000 rpm - Stroke (X): 190 mm - Stroke (Y): 40 mm - Stroke (Z): 555 mm - Maximum tool diameter ?: 200 mm - Main spindle bore: 79 mm - Weight: 6.500 kg

CNC controller: SIEMENS SINUMERIK 840D-ERGOLINE Capacity X-axis travel mm: 725 Y-axis travel mm: ± 50 Z-axis travel mm: 300 Turning length mm: 160 Max. turning diameter mm: ø: 250 Swing over bed mm: ø: 320 Tool magazine Magazine places: 16 Tool holder: VDI-30 Tool length max. mm: 390 Tool diameter max. mm: 140 Lower turret Number of tool slots St .: 12 Speed driven tools RPM: 4.000 Drive power driven tools kW: 11,7 Milling function: Yes Main spindle Speed spindle rpm: 5.000 Drive power spindle kW: 11,7 (40% ED) Maximun torque Nm: 280 / 360 (100% / 40% ED) Coolant system Tank capacity liter: 980 L High-pressure bar: 8 / 20 Equipment Chip conveyor CE conformity Coolant gun Air blast / coolant switch-over Internal coolant supply Paper band filter Automatic workpiece magazine loader - 16 positions x ø 220 Working time hours ...

turning diameter: 20 mm turning length: 230 mm control: Fanuc 16iT total power requirement: 0,55 kW weight of the machine ca.: 2,6 t dimensions of the machine ca.: 2275 x 1300 x 1760 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

turning diameter: 290 mm turning length: 450 mm control: CNC spindle passage: 65 mm turning diameter over slide: 185 mm turning speeds: 3000 U/min Tool changer: 12 work piece power: VDI 40 live tooling: chip conveyor: kW coolant: swing diameter: 600 mm total power requirement: 45 kW weight of the machine ca.: 4,7 t dimensions of the machine ca.: 4,5x2,5x2,3 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

CNC lathe GILDEMEISTER CTX 420 linear With Siemens 840 D powerline controller Year of Make: 2006 Max. rotatable diameter: 324 mm Max. rotatable length: 600 mm Max. circumferential diameter: 680 mm Spindle bore: 79 mm Max. spindle speed: 4500 rpm With the following accessories: Slide protection with interior lighting 12-speed turret with 12 driven stations Y axis , C axis Tool measuring device Parts collection facility 3 jaw chuck hydraulic 0 210 mm with foot switch Hydraulic Collet Chuck Hainbuch IRCO Breuning RBK 10012 Bar Feeder Signal lamp Tailstock with quill Conveyor Oil mist extraction Coolant system with IKZ and belt filter system Operating instructions

turning diameter: 320 mm turning length: 750 mm control: Siemens type: 810DL CCUO turning diameter over slide rest: 150 mm cross movement: 185 mm spindle passage: 52 mm turning speeds: 14-3550 U/min transmission ratio: 2 quill stroke: 120 mm rapid traverse: 6 m/min main drive motor: 7 kW 3-jaw-chuck diameter: 200 mm total power requirement: 10 kW weight of the machine ca.: 2 t dimensions of the machine ca.: 2,6x1,44x1,44 m 8950 turning hours The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

turning diameter: 710 mm turning length: 2000 mm control: Heidenhain type: Manuel Plus turning diameter over slide: 410 mm x-travel: 385 mm turning speeds: 9-1800 U/min transmission ratio: 2 drive capacity - workpiece: 22 kW Torque: 2500 Nm spindle diameter: 160 mm spindle passage: 92 mm total power requirement: 49 KVA weight of the machine ca.: 5,6 t dimensions of the machine ca.: 5x2x2,2 m The tech. Data are manufacturer or operator information and therefore for us not binding. We reserve the right to prior sale, it apply only our business and conditions of sale. About Us more than 400 own machines in stock over 12000 m² storage area, crane capacity 70 t more than 10000 articles accessories for your workshop You want to sell machines, production lines or your company, Then contact us. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

turning diameter: 325 mm turning length: 600 mm control: Siemens type: 840D Turret 12-fold, 12 stations: live tooling: turning speeds: 5000 U/min power capacity: 25 kW y-axis: mm c-axis: total power requirement: 35 kW weight of the machine ca.: 6,5 t dimensions of the machine ca.: 3,5x2,5x2,1 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Gildemeister sprint 208 + IEMCA Boss 338 HD 2016 Gildemeister Sprint 20/8 CNC Lathe – High-Precision Turning Machine Looking for a high-performance CNC lathe for precision machining? This 2016 Gildemeister Sprint 20/8 is a versatile, reliable, and efficient turning machine that’s perfect for complex part manufacturing. --------------------------------------------------------------- Machine Details: - Manufacturer: Gildemeister (DMG Mori) - Model: Sprint 20/8 - Year of Manufacture: 2016 - Control System: Fanuc 32i-B CNC - Type: Sliding Headstock Automatic Lathe - Condition: Excellent (well-maintained and regularly serviced) --------------------------------------------------------------- Specifications: - Max Bar Diameter: 20 mm - Max Turning Length: 200 mm - Number of Axes: 8 - Main Spindle Speed: Up to 10,000 RPM - Sub-Spindle Speed: Up to 10,000 RPM - Tool Capacity: - 22 Too ...

Control Siemens Sinumerik 840D Bar passage 65 mm Speeds 5,000 min-1 2 x 12-speed revolver with attached revolver Competition. Turret 1 with Y-axis Parts collection facility Belt filter system Conveyor Bar loading magazine IRCO Profimat

Tool holder, milling holder, milling tool -Intake: SK50 5 pieces -Sizes: see pictures -Price: complete -Dimensions box: 400/300/H270 mm -Weight: 42.1 kg

Tailstock, counter bearing for dividing head, dividing attachment -Tailstock comes: from a Gildemeister lathe -Tip height: 270 mm -Quill: electrically driven -Foot switch -Recording: MK5 -Number: 1x tailstocks available -Price: per piece -Dimensions: 820/250/H400 mm -Weight: 136 kg

Boring head, spindle head, drilling head, grooving drill head, grooving head, spindle drilling head, boring head, spindle tool -Adjustment: SK50 -Tool holder: M20 -Price: for both recordings -Weight: 16 kg

Hydraulic power pack, hydraulic pump, hydraulic pump -Hydraulic unit comes from a Gildemeister lathe -Drive: 1.1 kw -Speed: 1410 rpm -Max. Pressure: 25 bar -Liter output: l/min -Filter -Hydraulic tank -Dimensions: 500/680/H660 mm -Weight: 98 kg

max. Spindle speed: 5000 U/min. travel -x axis: 160 mm travel -z axis: 450 mm numbers of turret head positions: 12 tool taper: VDI 30 Control: Heidenhain iT Plus Dimensions (L x W x H): 4,5 x 2,5 x 2,5 m weight of the machine: 3700 kg CNC Turning- and Milling Center | DMG GILDEMEISTER - CTX 310 Additional equipment: - C-Axis The machine is in good condition. Please refer to further technical details in the attachement of the offer. - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - #Tags: CTX310 | CTX-310 The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Excellent condition - Fully operational - Loading / Transport possible! CNC automatic lathe GILDEMEISTER SPRINT 20 linear (2010) Connection hours 39836 h Cutting hours 10495 h Number of axes 8 Number of spindles 2 MAIN SPINDLE Bar diameter 20 mm Stroke 80 mm Spindle speed 10000 rpm Spindle power 3.7 kW C-axis indexing accuracy 0.001°. COUNTERSPINDLE Bar diameter 20 mm Stroke Z 300 mm Stroke X 240 mm Spindle speed 10000 rpm Spindle power 3.7 kW C-axis indexing accuracy 0.001° GUIDE BUSH SUPPORT Number of positions 11 Number of motorized positions 5 Tool speed 6000 rpm Stroke X 50 mm Beam Y 350 mm Automatic bar feeder IEMCA BOSS 332 E 32N (2010) Automatic translation
