max. wheel diameter: --- mm gear width: --- mm max. module: --- min. module: --- total power requirement: --- kW weight of the machine ca.: --- t dimensions of the machine ca.: --- m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
Stock number: 3984 GEAR MILLING MACHINE Manufacturer: STAEHELY, Type: SHA 506 Machines NO.: 10442, Year of manufacture: 0 Specifications: Module 6 Table size 300 mm Ø Spindle speeds 100-500 rpm Accessories: Zuadds gear Operating instructions Length: 2200 mm, Height: 2000 mm, Width: 1300 mm, Weight: 4860 kg
Key data: 4000 mm, 1560 mm, 32
CNC Gear Gringing machine HOFLER H4000 Year 1990 Maximum Workpiece Diameter 4000mm Gear Width 1560mm Module 3-32 Number of Teeth 12-768 Maximum Angle of Teeth 35 R/L Grad Pressure Angle 14-31 Degrees Table Diameter 1900mm Table Bore Diameter 750mm Maximum Workpiece Weight 35000kg Grinding Head Stroke 1600mm Ways hydrostatic Coolant, Filtration System Way Covers: rubber roll-up, metal telescopic and bellows neoprene Power 3 PH / 60 Hz / 230 – 460 V Equipped with: Reutlinger balancer Oil mist extraction system HOFLER TPF-40/1100 measuring machine Year: 1990 Max. Gear Diameter: 4000mm Both machines are in Excellent condition This machine was used to grind the gears for the US nuclear submarine transmissions (gearboxes). The machine was originally purchased new by General Electric for the Lynn Massachusetts Facility. We purchased it from them in excellent c ...
max. wheel diameter: 150 mm max. module: 5 min. module: 0,5 Control: weight of the machine ca.: 10.000 kg dimensions of the machine ca.: 6500 × 2700× 3600 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
Inv. Num. : 8631 Type: OFA 16 A Producer: TOS Created: 1976 Parameters: Machine weight: 3550 kg
Key data: 630 mm, 8
A used gear pusher Lorenz S8/630 with interchangeable wheels.
Key data: 630 mm, 8
Max. outer diameter (gear): 630 mm Max. inner diameter (gear): approx. 750 mm Max. tooth width: 180–200 mm Max. module: 8 Shock stroke: up to 220 mm Stroke rate: 47–300 strokes/min Tool holder: MK 4 Drive power: approx. 8 kW Total connected load: approx. 10–12 kW Njbmsww Er Hompw Spjwk Machine weight: approx. 5,500–5,800
Wheel diameter: 160mm, max. wheel width: 355mm, module range: 0.5-4.5, max. cutter diameter: 115mm, max. cutter length: 105mm, cutter head swivel range: 120°, speed: 400rpm, distance between centers: 410mm. Machine dimensions X/Y/Z: approx. 2000mm/1500mm/2000mm, weight: approx. 3500kg. An on-site inspection is possible.
MODUL ZFWZ 1250x14I gear hober (can do 1580 mm) Max. Diameter: 1250 mm Cutting width: 600 mm Module 2-16 Maximum size of the hob: 240 x 280 mm Table diameter: 1020 mm Speeds: 28 – 200 rpm Axial feed rates: 0.28 – 8 mm/min Radial feed rates: 0.1 – 2 mm/min Tangential feeds: 0.16 – 4 mm/min Stand tilt – left/right: +/- 45 Main motor power: 5 / 19.5 kW Power of the rapids motor: 12,5 kW Max. diameter of the part without tailstock: 1,250 mm Max. diameter of the part with tailstock: 800 mm Weight of the machine : 16 t Machine dimensions approx. 4.5 x 2.1 x h 3.3 m EQUIPMENT: Extended driven shaft for gear cutting up to Ø 1580 mm Capability to work with hob cutters Ø 235 mm and length 380 mm. Inverter control of the main electric motor. Expanded set of change gears
CHURCHILL PH3615 gear hobbing machine Max workpiece diameter 914 mm Max diametral/ pitch- 8 Module, 3 D.P. Horizontal centre distance:-63,5- 559 mm Max horizontal travel 469 mm Height hob centre to worktable: 127- 508 mm Max travel of vertical feed 381 mm Max height worktable to tailstock centre768 mm Table diameter 762 mm Table hole (diameter x depth) 89 x 381 mm Hob dia x length 178 x 203 mm Max travel of hob slide 127 mm Diameter of hob arbor 32 mm Hob spindle speeds, infinitely variable 50 – 200 rpm Vertical feeds 0.38 – 5 mm Main drive motor 10 HP Floor area 3960 x 2130 x 2300 mm Weight 11,500 kg Extended set of change gears Complete documentation Operational variable speed drives for main motor and feed drives
Key data: 3500 mm, 20
HÖFLER Porta 3500 CNC Gear Grinder – As Is” with Limited Use We are offering a unique opportunity to acquire a HÖFLER Porta 3500 CNC Spur/Helical, Internal/External Gear Grinding Machine – a rare and powerful machine with low hours, available in As Is” condition at a negotiable price. Machine Overview: • Make/Model: HÖFLER Porta 3500 CNC • Year New: 2007 • Installed: 2010 • Total Hours: Only 6,800 since installation • Design: Later-generation traveling gantry • Condition: Structurally and mechanically sound, but currently not operational due to uninstalled hydraulic drive motor (refurbished and included). • A full assembly report detailing remaining work can be provided upon request. Key Specs: • Max external grinding diameter: 137.8” (3500mm) • Max internal grinding diameter: 31.5” (800.1mm) • Max tooth profile height: 3.15 ...
Inv. Num. : 8799 Type: FO-10 Producer: TOS Created: 1958 Parameters: Maximum gear diameter: 1000 mm Maximum module: 10 Machine dimensions: 3120 x 1870 x 2525 mm Machine weight: 9000 kg
max. wheel diameter: 150 mm max. module: 5 min. module: 0,5 Control: weight of the machine ca.: 10.000 t dimensions of the machine ca.: 6500 × 2700× 3600 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
max. wheel diameter: 150 mm gear width: . mm max. module: 5 min. module: 0,5 Control: . total power requirement: . kW weight of the machine ca.: 10.000 t dimensions of the machine ca.: 6500 × 2700× 3600 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
Max. workpiece diameter... 1000mm Module ... 10- Main engine power ... 7.5kW L x W x H ... 3120 x 1870 x 2525mm Machine weight ... 10000kg
max. wheel diameter: 150 mm max. module: 5 min. module: 0,5 Control: weight of the machine ca.: 10.000 t dimensions of the machine ca.: 6500 × 2700× 3600 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
max. wheel diameter: 150 mm gear width: . mm max. module: 5 min. module: 0,5 Control: . total power requirement: . kW weight of the machine ca.: 10.000 t dimensions of the machine ca.: 6500 × 2700× 3600 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
The machine is in good technical condition, testing is possible by prior arrangement.
Spiral bevel gear machine ZFTKK 500/3V. Some of the change gears missing
Liebherr / Lorenz S800 Gear - Hobbing Machine -Max. workpiece length with counter holder 600mm -Max. workpiece length with retracted counter holder 800mm -Max. travel of the milling carriage 360mm -Largest millable pitch for the largest workpiece 5 Pi / in the normal power range 8 Pi -Pick-up taper - milling spindle MK 5 -Mandrel 22/27/32/40mm -Max. cutter diameter 186mm -Max. cutter length 170mm -Max. cutter displacement 80mm -Milling cutter speeds 40-220 rpm -Feeds infinitely variable / horizontal -Feeds infinitely variable / vertical -Feeds infinitely variable / tangential -Clamping table without water rim 550mm -Clamping table hole 100mm -Mandrel taper MK5 Accessories: 1x pallet interchangeable wheels 1x pallet hob 1x pallet clamping mandrels Documentation Machine feet Dimensions: LxWxH 3.6x1.8x1.9 meters / weight 5000Kg
Key data: 450
The Klingelnberg PEK 300 H bevel gear testing machine is designed for universal single-flank rolling testing of bevel gears and crown gears. Here, gears can be measured and graphically evaluated by means of single-flank rolling testing. These test methods are particularly suitable for determining defects in the gear geometry such as concentricity and axial running properties, rolling deviations or pitch errors. Here, a practical installation situation of a gear outside the gearbox is simulated under real load conditions and then evaluated. Deviations in the gear geometry, machining errors due to defective tools and damage to the gears can thus be detected and eliminated even before assembly. The following parameters can be measured here: » Single-flank deviations Fi', fi', fl', fk' » Crossing, Runout Roundness (Option) » Carrying diagram with digital camera » Pit ...
Key data: 540
The Klingelnberg GKP 90 bevel gear testing machine was designed as a universal machine and is used by manufacturers of gears and transmission technologies, for the process of noise and contact pattern tests on bevel gears and hypoid gears. Technical data Diameter: 540 (400) mm Hypoid: ±50 mm mm Pinion spindle Dm: 90 mm mm Dimensions: 1,800 x 1,800 x 1,600 m Machine weight: approx. 2,800 kg Information and data are non-binding, subject to prior sale Special features: The machine is intended for noise and contact pattern tests on bevel and hypoid gears of all gears. By simulating operating conditions, applying different speeds and changing the load states for drive and outlet, the optimal installation distance for standstill can be determined. Digital actual value display for 2 axes Stepless speed adjustment via frequency converter Electrically fused and acceptable ...
Inv. Num. : 8974 Type: OFA 16 SC Producer: TOS Generated: Parameters: Machine weight: 5 t
Technical data: Manufacturer: ogp Type: Smartscope CNC 250 Year of Make: 2004 Travel distances X/Y/Z: X 250 mm, Y 150 mm, Z 200 mm Scale resolution: 0.5 μm Condition Condition: Used Functional: Tested and fully functional
max. wheel diameter: 762 mm gear width: 116,84 mm max. module: min. module: total power requirement: 145 kW weight of the machine ca.: 27 t dimensions of the machine ca.: 5,5 x 5,3 x 3,4 m With the GLEASON Phoenix® 800HG bevel gear grinding machine, manufacturers of spiral, hypoid, and other bevel gears for large components can significantly increase their productivity. The machine enables faster grinding processes while maintaining the highest accuracy and excellent repeatability. Its extremely robust machine design forms the basis for stable machining processes, even for large workpiece diameters of up to 762 mm. Combined with a powerful FANUC CNC control system, the 800HG offers maximum flexibility for a wide range of gear geometries—from spiral and hypoid bevel gears to special forms. Thanks to its well-thought-out machine concept, the Phoenix® 800HG allows for reduced setup ti ...
Gear hobbing machine, milling machine, tool milling machine, vertical milling machine, roller milling machine, gear hobbing machine, gear hobbing machine, high-performance hobbing machine -Manufacturer: Liebherr, high-performance gear hobbing machine type SS 5- K/500 -Working area: Ø max. 500 mm -Max. cutter diameter: 186 mm -Accessories: including extensive accessories see photos -Machine dimensions: 2300/1460/H1870 mm -Dimensions accessories: pallets 1420/1300/H300 / 1200/800/300 mm -Weight: 5300 kg plus 535 kg accessories
max. wheel diameter: 406,4 mm gear width: 66 mm max. module: min. module: module: Control: FANUC Series 150M total power requirement: 61,6 kW weight of the machine ca.: 10 t dimensions of the machine ca.: 5,5x4,6 m The GLEASON Phoenix 400HG is a high-precision CNC bevel gear grinding machine designed for the grinding of spiral, hypoid, and Zerol bevel gears in various operations. The machine is based on a 6-axis design with an additional dressing axis (D-axis) and enables fully interpolated movements between the tool and the workpiece. This allows for both generating and formate processes. The CNC control system synchronizes all movements, resulting in very high profile accuracy, repeatability, and flexibility. • GLEASON PHOENIX 400HG CNC machine with FANUC 150M control system • Gleason HMI – user interface for easy entry of gear parameters and correction values • Automatic dr ...
Hydraulic tailstock, Ø max. gear: 250 with 3 cutter, Module: 5,5, Hobbing length: 70, Cutter module: 5,5, Outside ø max. acknowledged: 300 mm, Ø spindle: 85 mm, Ø hole table: 39 mm, Ø table: External centering Ø139,75, Power tool motor (b): 4 Cv, High: 1.800 mm, Long: 1.450 mm, Weight: 2.450 Kg, Width: 1.000 mm
Key data: 3500 mm
HÖFLER Porta 3500 CNC Gear Grinding Machine We are pleased to offer a rare opportunity to acquire a HÖFLER Porta 3500 CNC Spur/Helical, Internal/External Gear Grinding Machine, a large-capacity later-generation traveling gantry system with very low operating hours. Machine Overview Make/Model: HÖFLER Porta 3500 CNC Year of Manufacture: 2007 Installation Year: 2010 Total Operating Hours: approx. 6,800 hours Design: Later-generation traveling gantry system Condition: The machine is currently in still under power and requires reinstallation of a refurbished hydraulic drive motor (included) prior to recommissioning. Key Specifications (Maximum capacities as per OEM data) External Grinding Diameter: 3500 mm (137.8”) Internal Grinding Diameter: 800 mm (31.5”) Tooth Profile Height: 80 mm (3.15”) Helix Angle: ±45° Max Module: 20 (1.34 DP) Grindi ...
Wheel width: 600mm, module range: 2-16, cutter dimensions X/Y: 240mm/280mm, table diameter: 1020mm, speed: 200rpm, swiveling: +/-45°, max. wheel diameter with/without counterholder: 1250mm/800mm. Machine dimensions X/Y/Z: approx. 4500mm/2100mm/3300mm, weight: approx. 16200kg. An on-site inspection is possible.
Machine : Gear Hob 1 set of gear hobs 20 pcs. Angle of engagement 20 degrees Module : Set all sizes M 1 2x M 3 M 1.25 M 3.25 M 1.5 2 x M 3.5 M 1.75 M 3.75 M 2 M 4 M 2.25 M 4.5 M 2.5 M 5 M 2.75 M 5.5 M 6 Gear hobs : M 1 , 20 degrees , φ 70x50, 80% M 1.5 20 degrees, φ 54x56, 90%, M 2 20 degrees, φ 72x72 90% M 2.5 20 degrees, φ 60x65, 80% M 4 20 degrees, φ 90x78, 80% M 2.5 20 degrees φ 78x190, 30% M 1.6 30 degrees, φ 85x130, 90% M 1.5875, 30, φ 82x120, 90% Other tools : See photo
Key data: 3500 mm
HÖFLER Porta 3500 CNC Gear Grinding Machine We are pleased to offer a rare opportunity to acquire a HÖFLER Porta 3500 CNC Spur/Helical, Internal/External Gear Grinding Machine, a large-capacity later-generation traveling gantry system with very low operating hours. Machine Overview Make/Model: HÖFLER Porta 3500 CNC Year of Manufacture: 2007 Installation Year: 2010 Total Operating Hours: approx. 6,800 hours Design: Later-generation traveling gantry system Condition: The machine is currently in still under power and requires reinstallation of a refurbished hydraulic drive motor (included) prior to recommissioning. Key Specifications (Maximum capacities as per OEM data) External Grinding Diameter: 3500 mm (137.8”) Internal Grinding Diameter: 800 mm (31.5”) Tooth Profile Height: 80 mm (3.15”) Helix Angle: ±45° Max Module: 20 (1.34 DP) Grindi ...
Key data: 3500 mm
HÖFLER Porta 3500 CNC Gear Grinding Machine We are pleased to offer a rare opportunity to acquire a HÖFLER Porta 3500 CNC Spur/Helical, Internal/External Gear Grinding Machine, a large-capacity later-generation traveling gantry system with very low operating hours. Machine Overview Make/Model: HÖFLER Porta 3500 CNC Year of Manufacture: 2007 Installation Year: 2010 Total Operating Hours: approx. 6,800 hours Design: Later-generation traveling gantry system Condition: The machine is currently in still under power and requires reinstallation of a refurbished hydraulic drive motor (included) prior to recommissioning. Key Specifications (Maximum capacities as per OEM data) External Grinding Diameter: 3500 mm (137.8”) Internal Grinding Diameter: 800 mm (31.5”) Tooth Profile Height: 80 mm (3.15”) Helix Angle: ±45° Max Module: 20 (1.34 DP) Grindi ...
WMW MODUL ZFWZ 160/3 gear hobbing machine was built in 1971 in the GDR by VEB Werkzeugmaschinenkombinat 7. Oktober” Berlin. The machine is used in plants manufacturing extremely precise drive components for, among others, the automotive, aerospace and machinery industries. It enables the efficient machining of spur and worm gears with a maximum external diameter of 160 mm. The machining process is performed by means of a spindle with a cutter with a maximum diameter of 110 mm. The spindle of the MODUL ZFWZ 160X3 machine moves along the contour of the workpiece, cutting the material along its entire circumference. Using this method, it is possible to achieve the desired shapes and teeth finish with the highest accuracy. The WMW MODUL ZFWZ gear hobbing machine weighs 3000 kg. Technical specifications of the WMW MODUL ZFWZ 160/3 gear hobbing machine General data - maximum external di ...
PFAUTER PE 150 Hobbing machine GENERAL Project No.: 906008 Quantity: 1 pcs. Manufacturer: PFAUTER Type: PE 150 Control: Siemens 840 D powerline Year of manufacture: 1991/2009 Condition: Used machine Engine Approx (hrs): 33500 DESCRIPTION GEAR CUTTING Max. head circle diameter 150 mm Carriage stroke Z'-axis 200 mm Travel in X 150 mm Module 1-3 mm Bevel angle +30 to/to -45 degrees Max. tooth width 150 mm Max. diameter hob 130 mm Max. length of hob 220 mm Tailstock OTHER EQUIPMENT Splash protection cladding with fully encapsulated working area Lighting in the work area Electrostatic oil/emulsion mist extraction system Chip conveyor Engine is/was operated with oil Coolant Setup Circumferential Parts Storage Belt GENERAL TECHNICAL DATA Mains fuse 100 A Total power requirement 49 kVA Machine dimensions (LxWxH) approx. 5820x4047x2810 m ...
Workpiece diameter at ratio 1:10 = 300mm, workpiece diameter at ratio 1:1 = 212 mm, number of teeth: 6-200 Auction-ID: A1-47017-39
Year of manufacture approx. 1980, wheel diameter: 406mm, wheel width 420mm, module min.-max.: 0.5-+4.3, milling cutter speeds 49-246 rpm Auction-ID: A1-47017-11
Year of construction: approx. 1981 Accessories: - Universal milling head, tangential milling head, - Interchangeable wheels - 2 cutting equipment, - little used Auction-ID: A1-47017-85
GEAR HOBBING MACHINE LIEBHERR L 301 TECHNICAL DATA Table diameter: 315 mm Table hole diameter: 80 mm Maximum diameter gear cut: 300 mm Hobbing length: 225 mm Maximal module: 6,0 Hobbing length: 225 mm Maximum diameter of hob tool: 140 mm Maximum length of hob tool: 152 mm Maximum length of workpiece: 680 mm Minimum No. Of teeth cut: 4 Machine dimensions: 3,3 x 1,9 x 2,2 m Machine weight: ca. 6,0 t Auction-ID: A7-47067-17
